8650 J . Org. Chem., Vol. 62, No. 25, 1997
Carr et al.
3.20 (1H, m), 3.03 (1H, dd, J ) 18, 6.0 Hz), 2.63 (1H,
ddd, J ) 18, 12, 2.0 Hz), 2.45 (4H, t, J ) 9.0 Hz), 2.19
(1H, dt, J ) 6.0, 3.0 Hz), 1.45 (5H, m), 0.89 (6H, t, J )
9.0 Hz); 13C NMR (CDCl3) δ 154.0, 137.4, 134.0, 130.7,
119.2, 105.7, 99.6, 57.4, 55.7, 52.8, 38.9, 29.7, 27.6, 22.6,
11.8; EI-MS m/z ) 283, 254, 240, 183, 156, 128, 98, 72;
UV (EtOH) λmax ) 296 (ꢀ ) 16 500), 231 (ꢀ ) 14 100),
205 (ꢀ ) 16 300) in EtOH; TLC Rf ) 0.30 (SiO2, Hex:
EtOAc:TEA 65:35:5). Anal. Calcd for C18H25N3: C,
76.28; H, 8.89; N, 14.83. Found: C, 76.56; H, 8.85; N,
14.71. [R]D ) -34.0 (THF, c ) 1). [R]365 ) -217.7.
(-)-4-(Dip r op yla m in o)-1,2,2a ,3,4,5-h e xa h yd r o-
[cd ]in d ole-6-ca r boxa m id e (16b). Polyphosphoric acid
(PPA, 300 mL) was placed into a 500-mL, 3-neck flask
equipped with a mechanical stirrer, a stopper, and a
condenser topped with a N2 inlet. The reaction vessel
was degassed by vacuum/purge cycles (5×) and then
heated to 85-90 °C (internal temperature) while the
nitrile 16a (22.65 g, 0.080 mol) was added portionwise.
The reaction mixture became homogeneous as the hy-
drolysis occurred. After all of the nitrile had been added,
the mixture was stirred at this temperature for an
additional 2.0 h to ensure complete hydrolysis. The
reaction mixture was then carefully poured onto crushed
ice and stirred vigorously. After the ice had melted, the
pH was adjusted with 5 N NaOH to 11/12, and the
solution was extracted with several portions of CH2Cl2.
The organic phase was dried over Na2SO4, filtered, and
concentrated to afford 23.53 g of the amide as a foam:
mp 161-164 °C; IR (KBr) 3381 (s), 3377 (s), 2956 (m),
136.2, 134.5, 130.8, 128.6, 127.4, 115.9, 92.4, 58.1, 49.2,
42.8, 38.1, 36.8. IR (KBr) 1640 cm-1; FD mass spectrum
m/z 404 (M+). Anal. Calcd for C18H17IN2O: C, 53.48; H,
4.24; N, 6.93. Found: C, 53.20, H, 4.11; N, 6.64.
(2a S,4S)-1-Ben zoyl-4-(d i-n -p r op yla m in o)-6-iod o-
1,2,2a ,3,4,5-h exa h yd r oben z[cd ]in d ole (14d ). Primary
amine 14b (100 g, 0.25 mol), potassium carbonate (137
g, 1.0 mol), and 1-iodopropane (97 mL, 1.0 mol) were
slurried together in 1 L of CH3CN. The heterogeneous
reaction mixture was warmed to approximately 75 °C and
stirred for 17 h. The mixture was cooled to room
temperature, and water (500 mL) and tert-butyl methyl
ether (500 mL) were added. The organic layer was
separated and washed with water. CH3CN (500 mL) was
added to the organic layer, and the volume was reduced
in half by evaporation. A small amount of precipitated
black solids was removed by hot gravity filtrataion. The
filtrate was cooled to room temperature, and orange
crystals formed. The mixture was cooled in an bath and
filtered. The solid was washed with cold CH3CN (2 ×
75 mL) and vacuum-dried to give 100 g (83% yield) of
tertiary amine 14d : mp 109-110 °C; [R]D ) 17.0 (c ) 1,
1
THF); H NMR (300 MHz, CDCl3) δ 7.50 (m, 7H), 4.28
(bs, 1H), 3.66 (t, J ) 11 Hz, 1H), 3.34 (m, 1H), 3.20 (m,
1H), 3.05 (dd, J ) 18, 6 Hz, 1H), 2.47 (m, 5H), 2.16 (m,
1H), 1.38 (m, 5H), 0.91 (t, J ) 7 Hz, 6H); 13C NMR (75
MHz, CDCl3) δ 168.6, 141.7, 137.9, 137.6, 137.6, 136.3,
130.7, 127.4, 106.8, 93.3, 58.0, 52.9, 38.5, 35.1, 29.1, 22.6,
11.9; IR (KBr) 1638 cm-1; FD mass spectrum m/z 488
(M+). Anal. Calcd for C24H29IN2O: C, 59.02; H, 5.99; N,
5.74. Found: C, 59.03, H, 5.87; N, 5.64.
1
2932 (m), 1645 (s), 1616 (s), 1585 (m), 1379 (s) cm-1; H
NMR (CDCl3) δ 7.30 (d, 1H, J ) 8.0 Hz), 6.40 (d, 1H, J
) 8.0 Hz), 5.67 (br s, 2H), 3.92 (br s, 1H), 3.70 (m, 1H),
3.24 (m, 1H), 3.18 (m, 3H), 2.82 (dd, 1H, J ) 10.1, 17.0
Hz), 2.46 (m, 4H), 2.17 (m, 1H), 1.46 (m, 5H), 0.87 (t, 6H,
J ) 7.3 Hz); 13C NMR (CDCl3) δ 171.2, 152.4, 133.9,
130.6, 128.4, 122.8, 104.8, 57.5, 55.5, 52.5, 39.2, 29.0,
27.8, 22.3, 11.5; EI-MS m/z ) 301 (fd); UV (EtOH) λmax
) 273 (ꢀ ) 15 400), 214 (ꢀ ) 22 300); TLC Rf ) 0.44 (SiO2,
CH2Cl2:MeOH, 1:1). Anal. Calcd for C18H27N3O: C,
71.72; H, 9.02; N, 13.94. Found: C, 71.44; H, 8.88; N,
13.75. [R]D ) -70.5 (c ) 1.02, MeOH).
(2a S ,4S )-1-Be n zoyl-4-a m in o-6-iod o-1,2,2a ,3,4,5-
h exa h yd r oben z[cd ]in d ole (14b). H2SO4 (4.4 g, 45
mmol) was added dropwise to a solution of amine 13 (10.0
g, 36 mmol) in 1:1 acetic acid/water (50 mL). Periodic
acid (2.2 g, 9.6 mmol) and I2 (4.8 g, 18.9 mmol) were
added in rapid succession. The solution was heated to
60 °C for 1 h. With vigorous agitation, a 20% NaHSO3
solution (10 mL) was added to the warm mixture. After
the solution was cooled with an ice bath, CH2Cl2 (50 mL)
was added and the pH adjusted to 12 with a 10 N NaOH
solution (60 mL). The two-phase mixture was warmed
to 25 °C, and 50 mL of CH2Cl2 was added. The organic
layer was separated, and the aqueous layer was extracted
with CH2Cl2. The combined CH2Cl2 layers were dried
with Na2SO4‚CH3CN (70 mL) was added, and a solvent
exchange to CH3CN was affected. A mixture with a
yellow precipitate resulted, which was cooled to -15 °C
overnight. The cold mixture was filtered, and the solid
was washed with cold CH3CN (2 × 30 mL). After
vacuum-drying, 13.1 g (90% yield) of 14b was obtained
as a white solid; mp 178-80 °C. [R]D ) 5.0 (c ) 1, THF).
1H NMR (300 MHz, CDCl3) δ 7.55 (m, 7H), 4.27 (bs, 1H),
3.70 (t, J ) 15 Hz, 1H), 3.30 (m, 2H), 3.05 (dd, J ) 17, 6
Hz, 1H), 2.18 (m, 2H), 1.30 (q, J ) 12 Hz, 1H). 13C NMR
(75 MHz, CDCl3) δ 168.5, 141.8, 137.7, 136.8, 136.2,
(2a S,4S)-1-Ben zoyl-4-(d i-n -p r op yla m in o)-6-(a m i-
n oca r b on yl)-1,2,2a ,3,4,5-h exa h yd r ob en z[cd ]in d ole
(15b). To a 500-mL stainless stell autoclave were added
10.0 g (20.5 mmol) of iodoindoline 14d , 0.12 g (1.1 mmol)
of Pd black, 1.07 mmol of triphenylphosphine, and 150
mL of toluene. The autoclave was sealed, purged with
anhydrous ammonia (3 × 50 psi), and then pressured to
50 psi with ammonia. Carbon monoxide was added to
bring the final pressure to 85 psi. The stirred mixture
was heated to 110 °C for 14 h and then cooled to 35 °C
and vented. The warm reaction mixture was filtered, and
the autoclave was rinsed with an additional 50 mL of
toluene. The filtrate was concentrated to 50 mL, and
then 10 mL of hexane was added. The resulting slurry
was cooled to -15 °C for 24 h and filtered. The filter
cake was rinsed with cold toluene (25 mL) and hexanes
(2 × 30 mL) and then vacuum-dried at 50 °C to give 7.39
g (89% yield) of the product as a white crystalline solid:
mp 120-122 °C; [R]D ) -14.5 (c ) 1, THF); 1H NMR (500
MHz, CDCl3) δ 7.59 (d, J ) 7.0 Hz, 2H), 7.51 (m, 1H),
7.47 (m, 3H), 7.31 (bs, 1H), 5.81 (bs, 2H), 4.30 (bs, 1H),
3.69 (t, 1H, J ) 7.3 Hz), 3.34 (m, 1H), 3.27 (dd, J ) 17.5,
6.0 Hz), 3.19 (m, 1H), 2.89 (dd, 1H, J ) 17.5, 10.0 Hz),
2.47 (m, 4H), 2.19 (m, 1H), 1.48 (m, 4H), 0.90 (t, J ) 5.9
Hz, 6H); 13C NMR (75 MHz, CDCl3) δ 170.9, 168.9, 143.3,
138.2, 134.6, 134.2, 130.8, 129.2, 128.6, 127.7, 127.4, 57.4,
52.9, 38.4, 29.2, 27.9, 22.6, 11.8; IR (KBr) 3347, 3177,
2958, 2932, 2871, 1676, 1639, 1579, 1465, 1450, 1368
cm-1; FD mass spectrum m/z 405 (M+). Anal. Calcd for
C25H31N3O2: C, 74.03; H, 7.70; N, 10.36. Found: C,
74.33, H, 7.90; N, 10.48.
(2aS,4S)-4-(Di-n -p r op yla m in o)-6-(a m in oca r bon yl)-
1,2,2a ,3,4,5-h exa h yd r oben z[cd ]in d ole (16b). To a
solution of 71.95 g (177 mmol) of indoline 15b in 720 mL
of EtOH were added 650 mL of deionized water and 47
mL of 50% NaOH. The solution was heated to 80 °C for
