Organometallics
ARTICLE
added to a solution of 2-methoxybenzyl bromide (14.0 mmol, obtained
in situ from 2-methoxybenzyl alcohol, 1.93 g, and PBr3, 1.33 g)21 in
toluene (15 mL), and the mixture refluxed for 12 h. The white solid
formed was separated by decantation, washed with hot n-hexane, and
dried under vacuum. Yield: 97%. Anal. Calcd for C12H15BrN2O: C,
50.90; H, 5.34; N, 9.89. Found: C, 51.23; H 6.01; N, 9.93. 1H NMR (298
K, CD3OD): δ 10.37 (s, 1H, NCHN), 7.59 (dd, J = 7.4, 1.4, 1H, CH Ar),
7.51, 7.35 (m, 1H, 1H, CH Ar), 6.95 (td, J = 7.4, 1.0, 1H, CH Ar), 6.91 (s,
1H, CH Im), 6.88 (s, 1H, CH Im), 5.47 (s, 2H, NCH2), 4.08 (s, 3H,
OMe), 3.89 (s, 3H, MeIm). 13C{1H} NMR (298 K, CDCl3): δ 157.45
(C Ar), 137.41 (NCHN), 131.49, 131.48 (CH Ar), 123.33, 122.13 (CH
Im), 121.32 (C Ar), 121.24, 110.97 (CH Ar), 55.79 (OMe), 48.79
(CH2), 36.75 (MeIm). ESI-MS (CH3OH): m/z 203.2 [M]+.
General Procedure for the Preparation of [MBr(cod)-
(MeImXOMe)] (M = Rh, Ir; X = (CH2)2, CH2C6H4). The rhodium
and iridium complexes containing methoxy-functionalized NHC ligands
were synthesized through the following procedure. A mixture of [{M(μ-
OMe)(cod)}2] (M = Rh, Ir) and [MeImHXOMe)]Br in THF (10 mL)
was stirred overnight at room temperature to give an orange suspension.
The solid was removed by filtration, and the resulting orange solution
was concentrated and evaporated to dryness. Treatment of the yellow
residue with pentane rendered a yellowish solid, which was separated by
decantation, washed with pentane, and dried under vacuum.
DCTB matrix, CH2Cl2): m/z 431.2 [M]+, 351.8 [M ꢀ Br]+. ΛM
(acetone): 0.6 Ωꢀ1 cm2 molꢀ1
.
[RhBr(cod)(MeIm(2-methoxybenzyl))] (9). [{Rh(μ-OMe)-
(cod)}2] (150 mg, 0.310 mmol) and [MeImH(2-methoxybenzyl)]Br
(166 mg, 0.620 mmol) were used. Yield: 90%. Anal. Calcd for
C20H26BrN2ORh: C, 48.70; H, 5.31; N, 5.68. Found: C, 49.16; H,
5.68; N, 5.50. 1H NMR (298 K, CDCl3): δ 7.32, 6.94 (m, 2H, 2H, CH
Ar), 6.78, 6.70 (s, 1H, 1H, CH Im), 5.60 (AB system, δA = 5.74, δB =
5.46, JAB = 14.7, 2H, NCH2), 5.12 (m, 2H, CH cod), 4.11 (s, 3H, OMe),
3.88 (s, 3H, MeIm), 3.44 (br, 2H, CH cod), 2.37, 1.91 (m, 4H, 4H, CH2
cod). 13C{1H} NMR (CDCl3): δ 182.81 (d, JRhꢀC = 50.0, NCN),
157.75 (C Ar), 130.78, 129.88 (CH Im), 125.18 (CH Ar), 122.50 (C
Ar), 121.12, 121.05, 110.89 (CH Ar), 97.84 (d, JRhꢀC = 6.7, CH cod),
97.70 (d, JRhꢀC = 6.7, CH cod), 69.65 (d, JRhꢀC = 14.6, CH cod), 69.13
(d, JRhꢀC = 14.5, CH cod), 55.75 (OMe), 49.41 (NCH2), 38.06
(MeIm), 33.47, 32.70, 29.75, 29.21 (CH2 cod). MS (MALDI-TOF,
DCTB matrix, CH2Cl2) m/z
=
413.5 [M
ꢀ
Br]+, 203.5
[MeHIm(CH2)C6H4OMe]+. ΛM (acetone): 1.4 Ωꢀ1 cm2 molꢀ1
.
Preparation of [IrBr(cod)(MeIm(pyridin-2-ylmethyl))] (10).
A mixture of [{Ir(μ-OMe)(cod)}2] (100 mg, 0.150 mmol) and
[MeImH(pyridin-2-ylmethyl)]Br (76.6 mg, 0.302 mmol) in acetone
(10 mL) was stirred for 4 h at room temperature, giving an orange
suspension. The solid was removed by filtration, and the resulting
solution was evaporated to dryness. The compound was extracted with
diethyl ether, and the solution concentrated to ca. 1 mL and then treated
with n-hexane until a solid was formed. The orange solid was isolated by
decantation, washed with n-hexane (2 ꢁ 2 mL), and dried under
vacuum. Yield: 81%. Anal. Calcd for C18H23BrN3Ir: C, 39.06; H, 4.19;
N, 7.59. Found: C, 39.21; H, 4.15; N, 8.13. 1H NMR (298 K, CDCl3): δ
8.62 (d, J = 5.5, 1H, CH py), 7.64 (ddd, J = 7.9, 7.8, 1.7, 1H, CH py), 7.40
(d, J = 7.8, 1H, CH py), 7.17 (dd, J = 7.9, 5.5, 1H, CH py), 6.86, (s, J =
1.9, 1H, CH Im), 6.75 (d, J = 1.9, 1H, CH Im), 5.53 (AB system, δA =
5.73, δB = 5.32, JAB = 14.6, 2H, NCH2), 4.65, 4.37 (br, 1H, 1H, CH cod),
3.91 (s, 3H, MeIm), 2.82, 2.69 (br, 1H, 1H, CH cod), 2.22, 2.02, 1.61,
1.50 (m, 2H, 2H, 2H, 2H, CH2 cod). 13C{1H} NMR (298 K, CDCl3): δ
155.59 (C py), 150.74, 136.88, 123.58, 122.89 (CH py), 122.02, 120.38
(CH Im), 101.32, 99.58 (br, CH cod), 56.00 (NCH2), 52.75, 51.00 (br,
CH cod), 37.65 (MeIm), 32.15, 31.50, 29.67, 28.36 (CH2 cod). MS
(MALDI-TOF, DCTB matrix, CH2Cl2): m/z 554.1 [M + H]+, 474.0
[IrBr(cod)(MeIm(CH2)2OMe)] (6). [{Ir(μ-OMe)(cod)}2] (270
mg, 0.407 mmol) and [MeImH(CH2)2OMe)]Br (180 mg, 0.814 mmol)
were used. Yield: 74%. Anal. Calcd for C15H24BrN2OIr: C, 34.61; H,
1
4.65; N, 5.38. Found: C, 34.31; H, 4.59; N, 5.36. H NMR (298 K,
CDCl3): δ 7.01, (d, J = 1.9, 1H, CH Im), 6.77 (d, J = 1.9, 1H, CH Im),
4.71 (ddd, J = 13.9, 4.8, 3.5, 1H, NCH2), 4.58 (m, 2H, CH cod), 4.36
(ddd, J = 14.1, 7.6, 4.3, 1H, NCH2), 3.90 (s, 3H, MeIm), 3.76
(m, 2H, CH cod), 3.35 (s, 3H, OMe), 2.95 (ddd, J = 7.0, 7.0, 3.2, 1H,
CH2O), 2.84 (ddd, J = 7.0, 7.0, 3.2, 1H, CH2O), 2.17, 1.72, 1.49 (m, 4H,
2H, 2H, CH2 cod). 13C{1H} NMR (298 K, CDCl3): δ 180.16 (NCN),
121.72, 120.60 (CH Im), 84.49, 83.92 (CH cod), 72.12 (CH2O), 59.50
(OMe), 52.24, 51.99 (CH cod), 50.03 (NCH2), 37.34 (MeIm), 33.36,
33.24, 29.93, 29.74 (CH2 cod). MS (MALDI-TOF, DCTB matrix,
CH2Cl2) m/z: 522.5 [M + H]+, 441.0 [M ꢀ Br]+. ΛM (acetone): 16
Ω
ꢀ1 cm2 molꢀ1
.
[IrBr(cod)(MeIm(2-methoxybenzyl))] (7). [{Ir(μ-OMe)(cod)}2]
[M ꢀ Br]+. ΛM (acetone): 15 Ωꢀ1 cm2 molꢀ1
.
(125 mg, 0.188 mmol) and [MeImH(2-methoxybenzyl)]Br (107 mg, 0.377
mmol) were used. Yield: 73%. Anal. Calcd for C20H26BrN2OIr: C, 41.23; H,
4.50; N, 4.81. Found: C, 41.38; H, 4.56; N, 4.80. 1H NMR (298 K, CDCl3):δ
7.33ꢀ7.18, 6.93ꢀ6.80 (m, 2H, 2H, CH Ar), 6.70 (d, J = 1.6, 1H, CH Im),
Preparation of [IrCl(cod)(MeIm(CH2)nNMe2)] (n = 2, 3).
[MeImH(CH2)nNHMe2)]Cl2 (0.301 mmol) was added to a solution of
[{Ir(μ-OMe)(cod)}2] (100 mg, 0.150 mmol) in tetrahydrofuran
(10 mL), and the solution was stirred overnight. The resulting suspen-
sion was treated with NaH (7.22 mg, 0.301 mmol) and H2O (0.1 mL)
and stirred for 10 min. The solid was removed by filtration to give a
yellow solution, which was evaporated until ca. 1 mL. The pale yellow
solids formed after treatment with n-hexane were washed with diethyl
ether, separated by decantation, and dried under vacuum.
6.65 (d, J = 1.6, 1H, CH Im), 5.53 (AB system, δA = 5.70, δB = 5.42, JAB
=
14.7, 2H, NCH2), 4.61 (m, 2H, CH cod), 3.88 (s, 3H, OMe), 3.80 (s, 3H,
MeIm), 2.96 (br, 2H, CH cod), 2.13, 2.01, 1.70, 1.61, 1.48, 1.37 (m, 3H, 1H,
1H, 1H, 1H, 1H, CH2 cod). 13C{1H} NMR (CDCl3): δ 178.37 (NCN),
155.23 (C Ar), 129.12, 127.22 (CH Im), 124.82 (C Ar), 123.25, 121.12,
120.45, 110.25 (CH Ar), 83.85, 82.95 (CH cod), 55.24 (OMe), 52.51, 52.02
(CH cod), 49.12 (NCH2), 37.51 (MeIm), 33.54, 32.21, 29.58, 28.12 (CH2
cod). MS (MALDI-TOF, DCTB matrix, CH2Cl2): m/z 582.2 [M]+, 503.3
[IrCl(cod)(MeIm(CH2)2NMe2)] (11). Yield: 69%. Anal. Calcd for
C16H27ClN3Ir: C, 39.29; H, 5.56; N, 8.59. Found: C, 39.11; H, 5.32; N,
8.11. 1H NMR (298 K, CDCl3): δ 6.99 (d, J = 2.0, 1H, CH Im), 6.77 (d,
J = 2.0, 1H, CH Im), 4.51 (m, 2H, CH cod and 1H, NCH2), 4.31 (m, 1H,
NCH2), 3.88 (s, 3H, MeIm), 2.91, 2.81 (m, 1H, 1H, CH cod), 2.70 (m,
2H, CH2N), 2.21 (s, 6H, NMe2), 2.14, 1.72, 1.60, 1.51 (m, 4H, 1H, 2H,
1H, CH2 cod). 13C{1H} NMR (298 K, CDCl3): δ 180.05 (NCN),
121.15, 120.06 (CH Im), 85.58, 84.32 (CH cod), 60.24 (NCH2), 53.15,
51.58 (CH cod), 49.78 (CH2N), 44.85 (NMe2), 39.78 (MeIm), 35.56,
33.11, 29.10, 27.85 (CH2 cod). MS (MALDI-TOF, DCTB matrix,
CH2Cl2): m/z 489.0 [M]+, 454.0 [M ꢀ Cl]+. ΛM (acetone): 14 Ωꢀ1
[M ꢀ Br]+. ΛM (acetone): 14 Ωꢀ1 cm2 molꢀ1
.
[RhBr(cod)(MeIm(CH2)2OMe)] (8). [{Rh(μ-OMe)(cod)}2] (370
mg, 0.764 mmol) and [MeImH(CH2)2OMe)]Br (338 mg, 1.53 mmol)
were used. Yield: 64%. Anal. Calcd for C15H24BrN2ORh: C, 41.78; H,
1
5.61; N, 6.49. Found: C, 41.42; H, 5.54; N, 6.30. H NMR (298 K,
CDCl3): δ 6.95, 6.71 (s, 1H, 1H, CH Im), 4.97 (m, 2H, CH cod), 4.81,
4.40 (m, 1H, 1H, >CH2), 4.11 (s, 3H, OMe), 3.76 (m, 2H, >CH2), 3.28
(s, 3H, MeIm), 3.21 (br, 2H, CH cod), 2.26, 1.86 (m, 4H, 4H, CH2 cod).
13C{1H} NMR (CDCl3): δ 181.99 (d, JRhꢀC = 50.5, NCN), 121.96,
121.77 (CH Im), 98.00 (d, JRhꢀC = 6.5, CH cod), 97.82 (d, JRhꢀC = 6.6,
CH cod), 72.13 (CH2O), 69.06 (d, JRhꢀC = 11.1, CH cod), 68.91
(d, JRhꢀC = 11.0, CH cod), 58.97 (OMe), 50.48 (NCH2), 37.69
(MeIm), 32.77, 32.67, 29.15, 29.06 (CH2 cod). MS (MALDI-TOF,
cm2 molꢀ1
.
[IrCl(cod)(MeIm(CH2)3NMe2)] (12). Yield: 72%. Anal. Calcd for
C17H29ClN3Ir: C, 40.50; H, 5.81; N, 8.55. Found: C, 39.89; H, 5.76;
N, 8.39. 1H NMR (298 K, CDCl3): δ 6.81 (d, J = 1.8, 1H, CH Im), 6.73
5504
