JOURNAL OF CHEMICAL RESEARCH 2011 359
(CDCl3): δ = 4.3 (s, 2H, CH2), 7.10–8.15 (m, 12 H, ArH), 9.60 (s, 1H,
OH, exchangeable); Anal. Calcd for C24H15N3O6S (473.46): C, 60.88;
H, 3.19; N, 8.88. Found: C, 60.61; H, 3.02; N, 8.99%.
1HNMR (DMSO-d6): δ = 3.85 (s, 2H, CH2), 4.20 (s, 2H, OCH2), 5.85
(brs, 2H, NH2), 7.10–8.12 (m, 12H, ArH), 8.95, 9.10 (2s, 2H, 2NH,
exchangeable); Anal. Calcd for C26H20N6O6S (544.54): C, 57.35; H,
3.70; N, 15.43. Found: C, 57.49; H, 3.91; N, 15.21%.
[4-(3-Nitrophenyl)-6-(phenoxathiin-2-yl)pyrimidin-2-yloxy]acetyl
azide (7b): A saturated solution of sodium azide (0.33 g, 5 mmol) in
water (5 mL) was added dropwise to a stirred solution of pyrimidi-
nyloxyacetyl chloride 7a (3 mmol) [prepared from the refluxing of
pyrimidinyloxyacetic acid 6 (2 g) and thionyl chloride (8 mL) on a
water bath for 2 h, then cooled and added to petroleum ether 40/60
(40 mL). The solid formed was filtered off and dried to give 7a] at
0–5 °C, then the reaction mixture was stirred for further 1 h at room
temperature. The reaction mixture was added to crushed ice (50 g) and
the precipitated product was collected by filtration to give 7b which
used in situ.
Preparation of compounds (11a–c); general procedure
Compound 9 (2.7 g, 5 mmol) was dissolved in a mixture of [acetic
acid (8 mL), HCl (5 mL) and water (10 mL)], the solution was cooled
to 0 °C. To this cold solution was added a solution of sodium nitrite
(1 g) in water (5 mL) dropwise over 10 min. and the reaction was
allowed to proceed for another 15 min at 0 °C. The acid azide 10 was
precipitated as a syrup which taken up in cold ethyl acetate (40 mL),
then washed with cold 5% NaHCO3 (25 mL) and dried over anhy-
drous Na2SO4. The dried solution of azide 10 was added to α-amino
acids methyl ester hydrochloride (6 mmol) viz glycine, DL-alanine
and DL-phenylalanine in ethyl acetate (25 mL) containing triethyl-
amine (3 mL). The reaction mixture was stirred for 5 h at 5 °C and
then for another 10 h at room temperature, then washed with 1N HCl
(20 mL), 5% NaHCO3 (20 mL) and dried over anhydrous Na2SO4.
The dried solution was evaporated in vacuo and the residue was
recrystallised from n-butanol to give 11a–c.
Methyl (2-{2-[4-(3-nitrophenyl)-6-(phenoxathiin-2-yl)pyrimidin-2-
yloxy]acetylamino}acetylamino)acetate (11a): Yield, (67%); M.p.
212–214 °C; IR: ν = 3240–3190 (NH), 1725, 1680–1675 cm−1 (CO);
1H NMR (DMSO-d6): δ = 2.90 (s, 3H, CH3), 3.95, 4.10 (2s, 4H, 2CH2),
4.30 (s, 2H, OCH2), 7.13–8.10 (m, 12H, ArH), 8.80, 8.90 (2s, 2H,
2NH, exchangeable);Anal. Calcd for C29H23N5O8S (601.59): C, 57.90;
H, 3.85; N, 11.64. Found: C, 57.70; H, 3.63; N, 11.81%.
Methyl 2-(2-{2-[4-(3-nitrophenyl)-6-(phenoxathiin-2-yl)pyrimidin-
2-yloxy]acetylamino}acetylamino)propionate (11b): Yield, (60%);
M.p. 202–204 °C; IR: ν = 3250–3200 (NH), 1723, 1680–1670 cm−1
(CO); 1H NMR (DMSO-d6): δ = 1.95 (d, 3H, CH3), 2.95 (s, 3H, CH3),
3.90 (s, 2H, CH2), 4.25 (s, 2H, OCH2), 4.35 (q, 1H, CH), 7.12–8.15
(m, 12H, ArH), 8.75, 8.80 (2s, 2H, 2NH, exchangeable); Anal. Calcd
for C30H25N5O8S (615.61): C, 58.53; H, 4.09; N, 11.38. Found:
C, 58.72; H, 4.23; N, 11.19%.
Methyl 2-(2-{2-[4-(3-nitrophenyl)-6-(phenoxathiin-2-yl)pyrimidin-
2-yloxy]acetylamino}acetylamino)-3-phenylpropionate (11c): Yield,
(57%); M.p. 197–199 °C; IR: ν = 3245–3185 (NH), 1720, 1680–
1675 cm−1 (CO); Anal. Calcd for C36H29N5O8S (691.71): C, 62.51; H,
4.23; N, 10.12. Found: C, 62.38; H, 4.10; N, 10.26%.
Preparation of compounds (8a–c); general procedure
Method a: To a solution of α-amino acids methyl ester hydrochloride
viz glycine, DL-alanine and DL-phenylalanine (6 mmol) in tetrahy-
drofuran (40 mL) was added triethylamine (3 mL). The solution was
kept for 30 min at 0–5 °C and the precipitated triethylamine hydro-
chloride was filtered off. To the filtrate at 0 °C was added pyrimidi-
nyloxyacetic acid 6 (4 mmol) and N,N′-dicyclohexylcarbodiimide
(4 mmol). The reaction was allowed to proceed for 3 h at 0 °C with
stirring, for 3 h at 5 °C and for 24 h at room temperature. The precipi-
tated dicyclohexylurea was filtered off, the filtrate was evaporated to
dryness under reduced pressure and the residue was recrystallised
from tetrahydrofuran to give 8a–c. Yield for 8a (74%), 8b (72%),
8c (68%).
Method b: Pyrimidinyloxyacetyl chloride 7a (4 mmol) was dis-
solved in dioxane (40 mL) and added to a solution of the same α-
amino acids methyl ester hydrochloride (6 mmol) in dioxane (20 mL)
containing triethylamine (3 mL). The reaction mixture was stirred for
30 min at room temperature followed by refluxing for 3–4 h (TLC).
The reaction mixture was cooled, then the precipitated triethylamine
hydrochloride was filtered off and the filtrate was washed with 5%
NaHCO3 (20 mL), then dried over anhydrous Na2SO4. Evaporation of
the solvent under reduced pressure gave the solid product which
recrystallised to give 8a–c. Yield for 8a (69%), 8b (65%), 8c (61%).
Method c: To a solution of pyrimidinyloxyacetyl azide 7b (4 mmol)
in ethyl acetate was added the same α-amino acids methyl ester hydro-
chloride (6 mmol) and triethylamine (3 mL). The reaction mixture
was stirred for 5 h at 5 °C and for 10 h at room temperature, then
cooled, added to 1N HCl (25 mL), 5% NaHCO3 (25 mL) and dried
over anhydrous Na2SO4. The solution was evaporated under reduced
pressure and the residual material was recrystallised to give 8a–c.
Yield for 8a (63%), 8b (61%), 8c (65%).
Preparation of compounds (12a,b): A mixture of compounds (2a or
2b) (2 mmol) was dissolved in ethanol (20 mL) containing KOH
(2 mmol) and stirred at room temperature for 30 min. The tetra-O-
acetyl-α-D-glucopyranosyl bromide (2 mmol) was then added to the
reaction mixture which was stirred at rom temperature for 12 h. The
mixture was filtered, washed with water and recrystallised from proper
solvent to give the compounds 12a,b; IR for compounds 12a,b:
υ = 1705–1700 cm−1 (CO).
Methyl{2-[4-(3-nitrophenyl)-6-(phenoxathiin-2-yl)pyrimidin-2-yloxy]-
acetylamino}acetate (8a): M.p. 210–212 °C; IR: ν = 3340–3230
(NH), 1725, 1680 cm−1 (CO); 1H NMR (CDCl3): δ = 2.95 (s, 3H, CH3),
3.90 (s, 2H, CH2), 4.30 (s, 2H, OCH2), 7.16–8.10 (m, 12H, ArH), 8.95
(s, 1H, NH, exchangeable); Anal. Calcd for C27H20N4O7S (544.54):
C, 59.55; H, 3.70; N, 10.29. Found: C, 59.68; H, 3.86; N, 10.13%.
Methyl 2-{2-[4-(3-nitrophenyl)-6-(phenoxathiin-2-yl)pyrimidin-2-
yloxy]acetylamino}propionate (8b): M.p. 236–238 °C; IR: ν = 3350–
4-(3-Nitrophenyl)-6-(phenoxathiin-2-yl)-2-(tetra-O-acetyl-β-D-
glucopyranosyloxy)pyrimidine (12a): Yield, 56% (n-butanol); m.p.
1
122–124 °C; H NMR (CDCl3): δ = 1.90–2.10 (4s, 12H, 4 CH3CO),
3.30–4.10 (m, 5H, H-sugar), 4.30 (m, 2H, CH2), 6.98–8.10 (m, 12H,
ArH); Anal. Calcd for C36H31N3O13S (745.71): C, 57.98; H, 4.19;
N, 5.63. Found: C, 57.65; H, 4.25; N, 5.74%.
1
3220 (NH), 1720, 1675 cm−1 (CO); H NMR (CDCl3): δ = 1.60 (d,
4-(3-Nitrophenyl)-6-(phenoxathiin-2-yl)-2-(tetra-O-acetyl-β-D-glu-
copyranosylsulfanyl)pyrimidine (12b): Yield, 50% (ethanol); m.p.
3H, CH3), 2.90 (s, 3H, CH3), 4.20 (s, 2H, CH2), 4.80 (q, 1H, CH),
7.10–8.15 (m, 12H, ArH), 8.75 (s, 1H, NH, exchangeable); Anal.
Calcd for C28H22N4O7S (558.56): C, 60.21; H, 3.97; N, 10.03. Found:
C, 60.03; H, 3.62; N, 10.21%.
1
131–133 °C; H NMR (CDCl3): δ = 1.92–2.30 (4s, 12H, 4 CH3CO),
3.20–4.10 (m, 5H, H-sugar), 4.25 (m, 2H, CH2), 7.10–8.25 (m, 12H,
ArH); Anal. Calcd for C36H31N3O12S2 (761.78): C, 56.76; H, 4.10;
N, 5.52. Found: C, 56.51; H, 4.18; N, 5.41%.
Methyl 2-{2-[4-(3-nitrophenyl)-6-(phenoxathiin-2-yl)pyrimidin-2-
yloxy]acetylamino}-3-phenylpropionate (8c): M.p. 205–257 °C; IR:
1
ν = 3330–3190 (NH), 1722, 1670 cm-1 (CO); H NMR (DMSO-d6):
The author is grateful to the Botany Department, Benha
University, for biological screening.
δ = 2.90 (s, 3H, CH3), 4.10 (s, 2H, OCH2), 4.25 (d, 2H, CH2), 4.90
(t, 1H, CH), 7.10–8.15 (m, 17H, ArH), 8.98 (s, 1H, NH); Anal. Calcd
for C34H26N4O7S (634.66): C, 64.34; H, 4.13; N, 8.83. Found:
C, 64.46; H, 4.25; N, 8.62%.
N-Hydrazinocarbonylmethyl-2-[4-(3-nitrophenyl)-6-(phenoxathiin-
2-yl)pyrimidin-2-yloxy]acetamide (9): Compound 8a (2.7 g, 5 mmol)
was suspended in ethanol (25 mL) and refluxed, until a clear solution
was obtained. To this solution, hydrazine hydrate (0.3 mL, 6 mmol)
was added and the solution was kept at 0–5 °C for 24 h, the solvent
was removed in vacuo and to the dried residue was added (10 mL) of
0.5N hydrochloric acid and the solid which separated was recrystal-
lised from ethanol to give 9.Yield, 1.7 g (63%); M.p. 231–233 °C; IR:
ν = 3410–3200 (multiple bands, NH2 and NH), 1680–1675 cm−1 (CO);
Received 27 April2011; accepted 8 June 2011
Paper 1100677 doi: 10.3184/174751911X13083314900282
Published online: 11 July 2011
