Synthesis and Biological Activity of Kalkitoxin and its Analogues
Taiki Umezawa, Manabu Sueda, Takao Kamura, Teppei Kawahara, Xuerong Han, Tatsufumi Okino,
and Fuyuhiko Matsuda*
Division of Environmental Materials Science, Graduate School of Environmental Science, Hokkaido University, Sapporo 060-0810,
Japan
S
* Supporting Information
ABSTRACT: Total syntheses of kalkitoxin, isolated from the Caribbean Lyngbya
majuscula, and its analogues, 3-epi-, 7-epi-, 8-epi-, 10-epi-, 10-nor-, and 16-nor-kalkitoxin,
were achieved via oxazolidinone-based diastereoselective 1,4-addition reaction of a
methyl group and efficient TiCl4-mediated thiazoline ring formation as the key steps.
The biological activities of synthetic kalkitoxin and its analogues were evaluated with
brine shrimp.
thiol amide and benzyl-protected thiol amide, and their IC50
values were found to be 1.0, 190, and 400 ng/mL, respectively.
We have been attracted by the intriguing biological activities
and structure−activity relationships of 1 and its congeners, such
as diastereomers and demethylated kalkitoxins (nor-kalkitoxins).
With the synthesis of various analogues in mind, a flexible syn-
thetic route to easily change each stereogenic center was
required. In the present paper, we describe the highly stereo-
selective synthesis of 1 and its analogues, 3-epi-kalkitoxin (2),
7-epi-kalkitoxin (3), 8-epi-kalkitoxin (4), 10-epi- kalkitoxin (5),
10-nor-kalkitoxin (6), and 16-nor-kalkitoxin (7), via the Hruby
method with excellent stereochemical control of both the C7
and C10 stereogenic centers and a highly efficient thiazoline
ring formation from trityl-protected thiol amide with TiCl4 as
the key steps (Figure 1). The biological activities, i.e., LC50
values, of the synthetic kalkitoxins were also evaluated with
brine shrimp.
INTRODUCTION
■
Kalkitoxin (1) was isolated from the cyanobacterium Lyngbya
majuscula in the Caribbean Sea by Gerwick and co-workers in
2000.1 It is reported that 1 possesses some interesting
biological activities. For example, 1 shows strong ichthyotoxic
activity toward the common goldfish (Carassius auratus, LC50
=
700 nM) and brine shrimp (Artemia salina, LC50 = 170 nM).1
Also, 1 exhibits strong neurotoxicity (LC50 = 3.86 nM) in
cerebellar granule neurons (CGN) as an inhibitor of N-methyl-
D-aspartate (NMDA) receptor antagonists3 and is a highly
potent blocker of the voltage-dependent sodium channel in
mouse neuro-2a cells (EC50 = 1 nM).1,4 As a structural feature,
1 has five asymmetric centers: four methyl groups and a
thiazoline ring containing a vinyl group. Due to its interesting
biological activities as well as its intriguing structure, two total
syntheses have been reported to date. The first total synthesis
of 1 was reported by the Shioiri’s group using Hruby’s diastereo-
selective 1,4-addition reaction5 of methyl cuprate controlled
by Evans chiral oxazolidinone auxiliary6 for construction of
the stereogenic center at the C7 position and thiazoline ring
formation via an oxazoline ring as the key steps.1,2 In the course
of the synthesis, the structure of 1 including absolute and
relative configurations was unambiguously determined through
the synthesis of its stereoisomers (kalkitoxin, 2′-epi-kalkitoxin,
di-3,2′-epi-kalkitoxin, di-10,2′-epi-kalkitoxin, ent-kalkitoxin, 3-epi-
ent-kalkitoxin, and di-3,8-epi-ent-kalkitoxin) based on the fore-
cast with 1D and 2D NMR spectra of natural kalkitoxin.1,2
They also reported LC50 values of the synthetic kalkitoxins
toward brine shrimp (550 nM for 2′-epi-kalkitoxin, 1700 nM
for di-3,2′-epi-kalkitoxin, 1100 nM for di-10,2′-epi-kalkitoxin,
9300 nM for ent-kalkitoxin, inactive for 3-epi-ent-kalkitoxin, and
inactive for di-3,8-epi-ent-kalkitoxin). The second synthesis was
achieved by White’s group.7 The key reaction in the synthesis
was a diastereoselective 1,4-addition reaction of an alkyl cuprate
to install the stereochemistry at C10 followed by alkylation of
the resultant enolate with MeI (3.6:1 diastereomeric ratio) to
construct the contiguous stereochemistry at C7 and C8 in a
one-pot reaction.8 This group also conducted a clonogenic
assay using HCT-116 cells with 1 and its two intermediates,
RESULTS AND DISCUSSION
■
The retrosynthetic analysis of 1 was designed to overcome the
challenges for the synthesis of some isomers and is described in
Scheme 1. We envisioned that 1 would be accessed from the
amide 8 with a S-trityl group by highly effective TiCl4-mediated
thiazoline ring formation via removal of the trityl group
followed by dehydration. The amide 8 would be synthesized by
coupling between the carboxylic acid 9 and the amine 10
derived from L-cysteine with the stereochemical center set at
C3. The stereogenic center at C7 of 9 would be installed by
the application of the Hruby method to the α,β-unsaturated
imide 11, obtained through coupling between the known
carboxylic acid 12 and the amine 13. The stereochemistry at
C10 of 13 was constructed in a similar manner, employing the
α,β-unsaturated imide 14 prepared from the commercially
available ester 15. To access the epimers, we would employ
either the Evans chiral oxazolidinone auxiliary with the opposite
Received: September 25, 2011
Published: November 23, 2011
© 2011 American Chemical Society
357
dx.doi.org/10.1021/jo201951s | J. Org. Chem. 2012, 77, 357−370

The Journal of Organic Chemistry
Article
Figure 1. Kalkitoxin and its congeners.
Scheme 1
stereochemistry or enantiomers of the building blocks (ent-15
or D-cysteine).
The synthesis of 1 started with the preparation of the α,β-
unsaturated imide 14 according to a known procedure through
the Horner−Wadsworth−Emmons (HWE) reaction of the
aldehyde 16,9 derived from the commercially available ester
15, with the phosphonate 1710 and NaHMDS (Scheme 2).
auxiliary from 18 with LiBH4 gave the alcohol 19, which was
converted into the amine 13 by the following sequence of
reactions: (1) mesylation of the primary alcohol with MsCl and
Et3N; (2) SN2 reaction with NaN3;14 and (3) Staudinger reaction
with PPh3.15 Coupling between 13 and the known carboxylic
acid 1216 using (EtO)2P(O)CN and Et3N under Shioiri’s con-
ditions2,17 afforded the amide 21 in excellent yield (Scheme 3).
Scheme 2
Scheme 3
After methylation of 21 with MeI and n-BuLi to give 22,18 the
second 1,4-addition precursor 11 was synthesized in 3 steps:
(1) deprotection of the TBDPS group with TBAF; (2) Swern
oxidation; and (3) HWE reaction with 17 and NaHMDS. 1,4-
Addition of 11 with methyl cuprate prepared from CuBr·Me2S
1,4-Addition of 14 with methyl cuprate generated from
CuBr·Me2S and MeMgBr gave the imide 18 as a 9:1 mixture
of diastereomers.8,11,12 Reductive removal13 of the chiral
358
dx.doi.org/10.1021/jo201951s | J. Org. Chem. 2012, 77, 357−370

The Journal of Organic Chemistry
Article
and MeMgBr occurred smoothly with 15:1 stereoselectiv-
ity,12,19 and hydrolysis20 of the resultant imide 23 with LiOH
and H2O2 gave the carboxylic acid 9.
of 1 by changing the stereochemistry of the oxazolidinone
auxiliaries or building blocks. First, 3-epi-kalkitoxin (2) was
synthesized as shown in Scheme 6. To access 2, the amine
With the carboxylic acid 9 in hand, we then turned our
attention to the synthesis of the amine 10 employing the
Weinreb amide 24, which was produced from L-cysteine
following a known synthetic scheme.21 First, we attempted
Wittig olefination of the aldehyde obtained by reduction of 24
with LiAlH4. However, partial racemization was observed under
the strong basic conditions required for generation of Ph3P
CH2.22 To avoid the racemization, a novel olefination proce-
dure using 24 was developed. After addition of MeMgBr to
24, conversion of the resultant methyl ketone into the enol
triflate 2523 with PhNTf2 and KHMDS, followed by successive
reduction of 25 with Bu3SnH and LiCl catalyzed by Pd(0),24
successfully provided the olefin 26 in good yield (Scheme 4).
Scheme 6
Scheme 4
ent-10 was prepared from D-cysteine following the same
synthetic procedure as that for the preparation of 10 from
L-cysteine (Scheme 4). The condensation reaction between 9
and ent-10 with EDCI and DMAP gave the amide 28, which
was subjected to TiCl4-promoted thiazoline ring formation to
afford 2.
Removal of the Boc group with TFA25 yielded the amine 10 in
enantiomerically pure form.26 Condensation between 9 and 10
with EDCI and DMAP gave the amide 27 in excellent yield
(Scheme 5). The deprotection of the trityl group of 27
Scheme 7
Scheme 5
Scheme 7 illustrates the synthesis of 7-epi-kalkitoxin (3).
HWE reaction of the aldehyde synthesized from 22 with the
phosphonate ent-1710 and NaHMDS gave the α,β-unsaturated
imide 29. 1,4-Addition of methyl cuprate to 29 took place with
26:1 stereoselectivity.12 The imide 30 so obtained was trans-
formed to 3 by the same reaction sequence as that employed
in the total synthesis of 1: (1) hydrolysis of imide with LiOH
and H2O2; (2) condensation with the amine 10, employing
EDCI and DMAP; and (3) thiazoline ring formation induced
by TiCl4.
proceeded efficiently accompanied by thiazoline ring forma-
tion in the presence of TiCl4 to give 1 in high yield. All
27
spectroscopic data of synthetic 1 were identical with those of
natural 1.1,2
We then began the synthesis of the other kalkitoxins 2−7
based on the synthetic method developed for the total synthesis
We next synthesized 8-epi-kalkitoxin (4). The synthesis com-
menced with the aldehyde ent-16 prepared from the commercially
359
dx.doi.org/10.1021/jo201951s | J. Org. Chem. 2012, 77, 357−370

The Journal of Organic Chemistry
Article
Scheme 8
available ester ent-15 (Scheme 8). HWE reaction of ent-16 with
17 afforded the α,β-unsaturated imide 32. Installation of the
methyl group via 1,4-addition was stereocontrolled to furnish
the imide 33 with 5:1 selectivity,12 which led to the amine 35
through the same sequence of reactions as for the preparation
of 13 from 18 (Scheme 2). The amine 35 so obtained was
converted to 4 via construction of C7 stereochemistry12 using
the same synthetic protocol as for the total synthesis of 1.
The synthesis of 10-epi-kalkitoxin (5) is shown in Scheme 9.
The synthesis started from the amine ent-35, derived from 16
the total synthesis of 1.28 As shown in Scheme 11, 7 was
elaborated from 21 using the same synthetic method as for
the total synthesis of 1 without methylation of the amide
moiety of 21.28
With seven kalkitoxins in hand, we examined their biological
activities. The biological activities were evaluated as LC50
(median lethal concentration) values against brine shrimp.
The results are shown in Table 1. Our synthetic kalkitoxin (1)
exhibited an LC50 value (0.18 μM) that corresponded closely
to that of the natural kalkitoxin (0.17 μM) and the synthetic
kalkitoxin (0.17 μM) previously synthesized by Shioiri. LC50
values for unnatural epi-kalkitoxins, 3-epi-kalkitoxin (2), 7-epi-
kalkitoxin (3), 8-epi-kalkitoxin (4), and 10-epi-kalkitoxin (5)
were 15, 3.6, 1.7, and 0.62 μM, respectively. These unnatural
analogues were 3.3−80 times less potent than the natural
kalkitoxin. The nor-kalkitoxins, 10-nor-kalkitoxin (6) and 16-
nor-kalkitoxin (7), were also less active than kalkitoxin
(LC50 1.8 μM for 6, and inactive for 7). In addition, Shioiri
reported an LC50 value (0.55 μM) for 2′-epi-kalkitoxin similar
to those for the other epi-kalkitoxins. Clearly, all of the meth-
yl groups within kalkitoxin and the stereochemistry of the five
chiral centers is important for the biological activities of
kalkitoxins. Furthermore, the N-methyl group was found to be
essential.
Scheme 9
CONCLUSION
■
In summary, the total synthesis of kalkitoxin and its analogues
was achieved through the oxazolidinone-based diastereoselec-
tive 1,4-addition reaction of a methyl group and highly efficient
thiazoline ring formation mediated by TiCl4 from trityl-
protected thiol amide. The flexible synthetic route allowed
the synthesis of epi- and nor-kalkitoxins by simply changing the
stereochemistry of the chiral auxiliaries or building blocks.
The biological activities of the synthetic kalkitoxins revealed
that all of the methyl groups and the stereochemistry of the five
chiral centers, as well as the N-methyl group, were vital for the
toxicity of kalkitoxin.
and ent-17 through the same reaction sequence as for the
preparation of 35 from ent-16 and 17 (Scheme 8). The amine
ent-35 was successfully converted to 5 following the synthetic
procedure for the elaboration of 1.28
Synthesis of novel congeners 10-nor-kalkitoxin (6) and 16-
nor-kalkitoxin (7) was also performed. The synthesis of 6
commenced with 16 (Scheme 10). Wittig reaction of 16 with
Ph3PCHCO2Me produced the α,β-unsaturated ester 44,
which was transformed into the alcohol 46 through hydro-
genation of the olefin using Pd−C as catalyst and reduction
of the ester moiety with DIBAL. The alcohol 46 was then
converted to 6 according to the synthetic scheme developed for
EXPERIMENTAL SECTION
■
General Methods. The IR spectra were recorded using a NaCl
1
cell or KBr board. The H and 13C NMR spectra were recorded at
360
dx.doi.org/10.1021/jo201951s | J. Org. Chem. 2012, 77, 357−370

The Journal of Organic Chemistry
Article
Scheme 10
Scheme 11
THF (0.5 mL) was added to the mixture. The mixture was warmed to
room temperature, stirred for 2.5 h, quenched with saturated
NaHCO3, extracted with AcOEt (×3), washed with brine, dried
over Na2SO4, filtered, and concentrated in vacuo. The residue was
purified by silica gel column chromatography (AcOEt/hexane =
10:90) to give α,β-unsaturated imide 14 (44.1 mg, 0.0836 mmol, 50%)
as a colorless oil: [α]23D −21.9 (c 0.70, CHCl3); 1H NMR (CDCl3) δ
0.89 (3H, d, J = 6.8 Hz), 1.03 (9H, s), 1.84−1.87 (1H, m), 2.07−2.15
(1H, m), 2.49−2.54 (1H, m), 3.42−3.52 (2H, m), 4.28 (1H, dd, J =
3.9, 8.8 Hz), 4.70 (1H, t, J = 8.8 Hz), 5.48 (1H, dd, J = 3.9, 8.8 Hz),
7.03−7.09 (1H, m), 7.29−7.40 (12H, m), 7.61−7.63 (4H, m); 13C
NMR (CDCl3) δ 164.3, 153.5, 150.8, 139.1, 135.5, 133.6, 129.5, 129.1,
128.6, 127.5, 125.9, 121.2, 69.9, 68.2, 57.8, 36.6, 35.5, 26.9, 19.3, 16.5;
IR (neat) 3064, 2952, 2924, 2850, 1777, 1685, 1631, 1425, 1382, 1357,
1336, 1193, 1109, 1006, 897, 822, 704; FAB-MS m/z 550 (M+ + Na);
high-resolution FAB-MS m/z 550.2401 (M+ + Na, calcd for
C32H37NO4SiNa 550.2390).
(R)-3-((3S,5S)-6-((tert-Butyldiphenylsilyl)oxy)-3,5-dimethyl-
hexanoyl)-4-phenyloxazolidin-2-one (18). To a solution of
CuBr·Me2S complex (890 mg, 4.33 mmol) in THF (14.4 mL) was
added dropwise MeMgBr (0.84 M in THF, 8.65 mL, 7.26 mmol)
at −78 °C under Ar atmosphere. After 10 min, a solution of α,β-
unsaturated imide 14 (914 mg, 1.73 mmol) in THF (21.6 mL) was
added to the mixture. The mixture was stirred for 30 min, warmed
to −40 °C, stirred for 2 h, quenched with saturated NaHCO3, extracted
with AcOEt (×3), washed with brine, dried over Na2SO4, filtered, and
concentrated in vacuo. The residue was purified by silica gel column
chromatography (AcOEt/hexane = 20:80) to give imide 18 (898 mg,
Table 1. Biological Activities of Synthetic Kalkitoxins
compound
LC50 (μM)
kalkitoxin (1)
0.18
15
3-epi-kalkitoxin (2)
7-epi-kalkitoxin (3)
8-epi-kalkitoxin (4)
10-epi-kalkitoxin (5)
10-nor-kalkitoxin (6)
16-nor-kalkitoxin (7)
3.6
1.7
0.62
1.8
4.15 mmol, 96%) as a colorless oil: [α]23 −32.2 (c 0.80, CHCl3);
D
1H NMR (CDCl3) δ 0.84 (6H, d, 6.6 Hz), 1.04 (9H, s), 1.24−1.28
(2H, m), 1.68−1.69 (1H, m), 2.07−2.15 (1H, m), 2.73−2.90 (2H, m),
3.34−3.43 (2H, m), 4.25 (1H, dd, J = 3.6, 8.8 Hz), 4.66 (1H, t, J = 8.8
Hz), 5.41 (1H, dd, J = 3.7, 8.6 Hz), 7.29−7.41 (11H, m), 7.63−7.64
(4H, m); 13C NMR (CDCl3) δ 171.9, 153.6, 139.1, 135.5, 134.0,
129.3, 129.1, 128.6, 127.5, 125.8, 69.8, 69.4, 57.6, 43.4, 40.0, 33.2, 27.1,
26.9, 19.4, 19.3, 16.3; IR (neat) 3064, 2952, 2924, 2850, 1780, 1705,
1458, 1425, 1383, 1321, 1193, 1109, 1004, 823, 703; FAB-MS m/z 544
(M+ + H); high-resolution FAB-MS m/z 544.2858 (M+ + H, calcd for
C33H42NO4Si 544.2883).
inactive
400 and 100 MHz, respectively. Chemical shifts were reported in ppm
downfield from the peak of Me4Si used as the internal standard.
Splitting patterns are designated as s, d, t, q, and m; these symbols
indicate singlet, doublet, triplet, quartet, and multiplet, respectively.
Tetrahydrofuran (THF) and ether were distilled from Na metal/
benzophenone ketyl. Dichloromethane (CH2Cl2), triethylamine (Et3N),
iodomethane (MeI), and hexamethylphosphoramide (HMPA) were
distilled from CaH2. All commercially obtained reagents were used
as received. Analytical and preparative TLC was carried out using
precoated silica gel plates.
(R)-3-((S,E)-6-((tert-Butyldiphenylsilyl)oxy)-5-methylhex-2-
enoyl)-4-phenyloxazolidin-2-one (14). To a solution of phos-
phonate 17 (68.9 mg, 0.202 mmol) in THF (0.5 mL) was added
NaHMDS (0.99 M in THF, 0.204 mL) at 0 °C under Ar atmosphere.
After 30 min, a solution of aldehyde 16 (57.1 mg, 0.168 mmol) in
(3S,5S)-6-((tert-Butyldiphenylsilyl)oxy)-3,5-dimethylhexan-1-ol
(19). To a solution of imide 18 (898 mg, 1.65 mmol) in THF (8.0
mL) were added MeOH (133 μL, 3.30 mmol) and LiBH4 (54.0 mg,
2.48 mmol) at room temperature under Ar atmosphere. The mixture
was stirred for 30 min, quenched with saturated NaHCO3, extracted
with AcOEt (×3), washed with brine, dried over Na2SO4, filtered, and
concentrated in vacuo. The residue was purified by silica gel column
361
dx.doi.org/10.1021/jo201951s | J. Org. Chem. 2012, 77, 357−370

The Journal of Organic Chemistry
Article
chromatography (AcOEt/hexane = 20:80) to give alcohol 19 (429 mg,
1.11 mmol, 68%) as a colorless oil: [α]23D −8.61 (c 2.31, CHCl3); 1H
NMR (CDCl3) δ 0.85 (3H, d, J = 6.6 Hz), 0.89 (3H, d, J = 6.8 Hz),
1.05 (9H, s), 1.20−1.28 (1H, m), 1.34−1.41 (1H, m), 1.48−1.60 (3H,
m), 1.72−1.75 (1H, m), 3.40−3.50 (2H, m), 3.59−3.70 (2H, m),
7.35−7.43 (6H, m), 7.65−7.66 (4H, m); 13C NMR (CDCl3) δ 135.5,
134.0, 129.4, 127.5, 69.5, 61.1, 40.9, 40.8, 33.2, 27.0, 26.8, 19.5, 19.4,
16.7; IR (neat) 3336, 3064, 3044, 2922, 2852, 1468, 1425, 1386, 1359,
1188, 1109, 1007, 823, 740, 703; MS FAB-MS m/z 385 (M+ + H);
high-resolution FAB-MS m/z 385.2555 (M+ + H, calcd for C24H37O2Si
385.2565).
(((2S,4S)-6-Azido-2,4-dimethylhexyl)oxy)(tert-butyl)-
diphenylsilane (20). To a solution of alcohol 19 (363 mg, 0.945
mmol) in CH2Cl2 (9.5 mL) were added Et3N (263 μL, 1.89 mmol)
and MsCl (110 μL, 1.42 mmol) at room temperature under Ar
atmosphere. The mixture was stirred for 3 h, quenched with saturated
NaHCO3, extracted with AcOEt (×3), washed with brine, dried over
Na2SO4, filtered, and concentrated in vacuo. The crude mesylate was
employed directly in the next reaction.
δ 0.82−0.92 (9H, m), 1.05, 1.06 (total 9H, each s), 1.05−1.11
(3H, m), 1.16−1.57 (4H, m), 1.58−1.80 (4H, m), 2.44−2.61 (1H, m),
2.90, 2.98 (total 3H, each s), 3.19−3.50 (4H, m), 7.32−7.44 (6H, m),
7.63−7.67 (4H, m); 13C NMR (CDCl3) δ 176.3, 176.0, 135.5, 134.0,
133.9, 129.5, 129.4, 127.5, 69.5, 69.4, 48.0, 46.2, 40.7, 40.6, 37.7, 37.4,
37.2, 37.0, 35.2, 33.7, 33.2, 28.1, 27.5, 27.1, 26.9, 19.4, 19.3, 17.9, 17.2,
16.6, 12.2, 12.1; IR (neat) 3064, 2954, 2924, 2852, 1642, 1462, 1425,
1408, 1259, 1191, 1110, 1008, 822, 740, 703; MS FAB-MS m/z 504
(M+ + Na); high-resolution FAB-MS m/z 504.3262 (M+ + Na, calcd
for C30H47NO2SiNa 504.3274).
(R)-N-((3S,5S)-6-Hydroxy-3,5-dimethylhexyl)-N,2-dimethyl-
butanamide (S-1). To a solution of N-methyl amide 22 (1.30 g,
2.69 mmol) in THF (11.8 mL) was added TBAF (1 M in THF, 3.50
mL, 3.5 mmol) at room temperature. The mixture was stirred for 2 h,
quenched with saturated NH4Cl, extracted with AcOEt (×3), washed
with brine, dried over Na2SO4, filtered, and concentrated in vacuo. The
residue was purified by silica gel column chromatography (AcOEt/
hexane = 40:60) to give alcohol S-1 (613 mg, 2.52 mmol, 94%) as a
1
pale oil: [α]23 −33.5 (c 1.35, CHCl3); H NMR (CDCl3) (rotamer)
D
To a solution of crude mesylate in DMF (9.4 mL) was added NaN3
(246 mg, 3.78 mmol) at room temperature. The mixture was heated to
40 °C for 12 h, quenched with saturated NaHCO3, extracted with
AcOEt (×3), washed with brine, dried over Na2SO4, filtered, and
concentrated in vacuo. The residue was purified by silica gel column
chromatography (AcOEt/hexane = 10:90) to give azide 20 (360 mg,
0.880 mmol, 93%) as a colorless oil: [α]23D −7.30 (c 1.23, CHCl3); 1H
NMR (CDCl3) δ 0.86 (3H, d, J = 6.4 Hz), 0.93 (3H, d, J = 6.6 Hz),
1.05 (9H, s), 1.30−1.40 (3H, m), 1.54−1.61 (2H, m), 1.71−1.73 (1H,
m), 3.20−3.29 (2H, m), 3.40−3.51 (2H, m), 7.35−7.44 (6H, m),
7.64−7.67 (4H, m); 13C NMR (CDCl3) δ 135.5, 134.0, 129.4, 127.5,
69.4, 49.5, 40.5, 36.6, 33.2, 27.7, 27.0, 19.4, 19.2, 16.6; IR (neat) 3064,
2924, 2852, 2090, 1461, 1425, 1387, 1359, 1188, 1110, 1008, 823, 738,
702; MS FAB-MS m/z 432 (M+ + Na); high-resolution FAB-MS m/z
432.2440 (M+ + Na, calcd for C24H35N3OSiNa 432.2447).
(R)-N-((3S,5S)-6-((tert-Butyldiphenylsilyl)oxy)-3,5-dimethyl-
hexyl)-2-methylbutanamide (21). To a solution of azide 20 (550 mg,
1.34 mmol) in THF (13.4 mL) were added H2O (120 μL) and PPh3
(879 mg, 3.35 mmol) at room temperature. The mixture was heated to
40 °C for 12 h, cooled to room temperature, dried over Na2SO4,
filtered, and concentrated in vacuo. The crude amine was employed
directly in the next reaction.
δ 0.85−0.94 (9H, m), 1.02 (3H, d, J = 6.3 Hz), 1.15−1.47 (6H, m),
1.51−1.73 (2H, m) 1.96 (1H, br), 2.49−2.52 (1H, m), 2.92, 3.01
(total 3H, each s), 3.24−3.52 (4H, m); 13C NMR (CDCl3) δ 176.4,
176.1, 68.8, 68.6, 48.1, 46.1, 40.6, 40.4, 37.4, 37.2, 37.0, 35.3, 35.1,
33.7, 33.1, 28.0, 27.9, 27.4, 27.1, 26.9, 19.5, 19.3, 17.8, 17.1, 16.4, 16.3,
12.2, 12.0; IR (neat) 3404, 2958, 2922, 2866, 1625, 1462, 1413, 1377,
1259, 1131, 1082; MS EI-MS m/z 243 (M+); high-resolution EI-MS
m/z 243.2200 (M+, calcd for C14H29NO2 243.2198).
(R)-N-((3S,5S,E)-3,5-Dimethyl-8-oxo-8-((R)-2-oxo-4-phenyl-
oxazolidin-3-yl)oct-6-en-1-yl)-N,2-dimethylbutanamide (11).
To a solution of (COCl)2 (28 μL, 0.318 mmol) in CH2Cl2 (0.2 mL)
was added DMSO (30 μL, 0.424 mL) at −78 °C under Ar atmo-
sphere. After 30 min, a solution of alcohol S-1 (25.7 mg, 0.106 mmol)
in CH2Cl2 (0.2 mL) was added to the mixture. After an additional
45 min, Et3N (74 μL, 0.530 mmol) was added to the mixture. The
mixture was warmed to room temperature, stirred for 1 h, quenched
with saturated NH4Cl, extracted with CH2Cl2 (×3), washed with
brine, dried over Na2SO4, filtered, and concentrated in vacuo. The
crude aldehyde was employed directly in the next reaction.
To a solution of phosphonate 17 (54 mg, 0.159 mmol) in THF
(0.5 mL) was added NaHMDS (0.99 M in THF, 160 μL, 0.159 mmol)
at 0 °C under Ar atmosphere. After 30 min, a solution of aldehyde in
THF (0.5 mL) was added to the mixture. The mixture was warmed to
room temperature, stirred for 12 h, quenched with saturated NaHCO3,
extracted with AcOEt (×3), washed with brine, dried over Na2SO4,
filtered, and concentrated in vacuo. The residue was purified by silica
gel column chromatography (AcOEt/hexane = 20:80) to give α,β-
unsaturated imide 11 (40.2 mg, 0.0938 mmol, 89%). All spectral data
were identical with those of the reported compound.1
(R)-N,2-Dimethyl-N-((3S,5S,6R)-3,5,6-trimethyl-8-oxo-8-((R)-
2-oxo-4-phenyloxazolidin-3-yl)octyl)butanamide (23). To a
solution of CuBr·Me2S complex (298 mg, 1.45 mmol) in THF
(2.9 mL) was added dropwise MeMgBr (0.96 M in THF, 2.03 mL,
1.95 mmol) at −78 °C under Ar atmosphere. After 20 min, a solution
of α,β-unsaturated imide 11 (249 mg, 0.581 mmol) in THF (2.9 mL)
was added to the mixture. The mixture was warmed to −40 °C, stirred
for 1 h, quenched with saturated NaHCO3, extracted with AcOEt
(×3), washed with brine, dried over Na2SO4, filtered, and concentrated
in vacuo. The residue was purified by silica gel column chromatography
(AcOEt/hexane = 20:80) to give imide 23 (240 mg, 0.540 mmol,
93%). All spectral data were identical with those of the reported
compound.1
To a solution of crude amine and caroboxlic acid 12 (164 mg,
1.61 mmol) in CH2Cl2 (13.4 mL) were added Et3N (281 μL, 2.01 mmol)
and (EtO)2POCN (244 μL, 1.61 mmol) at room temperature under
Ar atmosphere. The mixture was stirred for 2.5 h, quenched with
saturated NaHCO3, extracted with AcOEt (×3), washed with brine,
dried over Na2SO4, filtered, and concentrated in vacuo. The residue
was purified by silica gel column chromatography (AcOEt/hexane =
10:90) to give amide 21 (595 mg, 1.27 mmol, 95%) as a colorless oil:
1
[α]23 −11.6 (c 1.78, CHCl3); H NMR (CDCl3) δ 0.75−0.84 (9H,
D
m), 0.98 (9H, s), 1.03 (3H, d, J = 6.8 Hz), 1.10−1.71 (8H, m), 1.90−
2.00 (1H, m), 3.08−3.26 (2H, m), 3.31−3.42 (2H, m), 5.19 (1H, brs),
7.27−7.41 (6H, m), 7.55−7.66 (4H, m); 13C NMR (CDCl3) δ 176.1,
135.5, 134.0, 129.4, 127.5, 69.4, 43.3, 40.6, 37.7, 37.4, 33.2, 27.9,
27.4, 26.9, 19.4, 19.3, 17.6, 16.7, 12.0; IR (neat) 3290, 3064,
2954, 2924, 2852, 2090, 1640, 1549, 1459, 1425, 1385, 1263, 1234,
1109, 1008, 823, 739, 702; MS FAB-MS m/z 490 (M+ + Na);
high-resolution FAB-MS m/z 490.3104 (M+ + Na, calcd for C29H45-
NO2SiNa 490.3117).
(R)-N-((3S,5S)-6-((tert-Butyldiphenylsilyl)oxy)-3,5-dimethyl-
hexyl)-N,2-dimethylbutanamide (22). To a solution of amide 21
(321 mg, 0.685 mmol) in THF (6.8 mL) were added n-BuLi (2.73 M
in hexanes, 451 μL) and MeI (171 μL, 2.74 mmol) at −78 °C under
Ar atmosphere. The mixture was stirred for 10 min at −78 °C, warmed
to room temperature, stirred for 1 h, quenched with saturated
NaHCO3, extracted with AcOEt (×3), washed with brine, dried over
Na2SO4, filtered, and concentrated in vacuo. The residue was purified
by silica gel column chromatography (AcOEt/hexane = 20:80) to give
N-methyl amide 22 (310 mg, 0.644 mmol, 94%) as a colorless
(3R,4S,6S)-8-((R)-N,2-Dimethylbutanamido)-3,4,6-trimethyl-
octanoic Acid (9). To a solution of imide 23 (216 mg, 0.486 mmol)
in THF/H2O (2.0 mL, 4:1) were added 30% H2O2 (278 μL) and
0.5 M LiOH (2.86 mL) at room temperature. The mixture was stirred
for 12 h, 1 N NaOH was added, and the mixture was washed with
AcOEt. The aqueous layer was acidified with 1 N HCl, extracted with
AcOEt (×3), washed with brine, dried over Na2SO4, filtered, and
concentrated in vacuo. The crude carboxylic acid was employed
directly in the next reaction.
oil: [α]23 −11.5 (c 1.85, CHCl3); 1H NMR (CDCl3) (rotamer)
D
362
dx.doi.org/10.1021/jo201951s | J. Org. Chem. 2012, 77, 357−370

The Journal of Organic Chemistry
Article
1
(R)-3-((tert-Butoxycarbonyl)amino)-4-(tritylthio)but-1-en-2-
yl trifluoromethanesulfonate (25). To a solution of Weinreb
amide 24 (681 mg, 1.34 mmol) in THF (6.0 mL) was added MeMgBr
(1.08 M in THF, 6.23 mL, 6.72 mmol) at 0 °C under Ar atmosphere.
The mixture was warmed to room temperature, stirred for 1 h,
quenched with 1 N HCl, extracted with AcOEt (×3), washed with
brine, dried over Na2SO4, filtered, and concentrated in vacuo. The
crude methyl ketone was employed directly in the next reaction.
To a solution of crude methyl ketone in THF (6.0 mL) was added
PhNTf2 (526 mg, 1.47 mmol) at room temperature under Ar atmo-
sphere. The mixture was cooled to −78 °C, added KHMDS (0.5 M in
toluene, 8.04 mL, 4.02 mmol), stirred for 1 h, quenched with saturated
NaHCO3, extracted with AcOEt (×3), washed with brine, dried over
Na2SO4, filtered, and concentrated in vacuo. The residue was purified
by silica gel column chromatography (AcOEt/hexane = 3:97) to give
enol triflate 25 (519 mg, 0.874 mmol, 65%) as a pale oil, which was
immediately used for next reaction.
(R)-tert-Butyl (1-(Tritylthio)but-3-en-2-yl)carbamate (26). To
a solution of LiCl (110 mg, 2.59 mmol) in degassed THF (0.5 mL)
was added enol triflate 25 (515 mg, 0.868 mmol) in degassed THF,
Bu3SnH (257 μL, 0.954 mmol), and Pd(PPh3)4 (10.0 mg, 8.68 μmol)
at room temperature under Ar atmosphere. The mixture was heated
to reflux, stirred for 3 h, and concentrated in vacuo. The residue
was purified by silica gel column chromatography (AcOEt/hexane =
2:98) to give olefin 26 (371 mg, 0.833 mmol, 96%) as a colorless oil:
[α]23D +10.2 (c 1.51, CHCl3); 1H NMR (CDCl3) δ1.47 (9H, s), 2.32−
2.49 (2H, m), 4.20 (1H, br), 4.66 (1H, d, J = 8.0 Hz), 5.10 (1H, d, J =
10.0 Hz), 5.12 (1H, d, J = 16.6 Hz), 5.67 (1H, ddd, J = 5.1, 10.0, 16.6
Hz), 7.24−7.50 (15H, m); 13C NMR (CDCl3) δ 144.4, 137.1, 129.4,
127.4, 127.1, 126.6, 123.5, 115.3, 77.2, 66.7, 37.0, 28.4; IR (neat) 3059,
1685, 1597, 1495, 1426, 1371, 1235, 1209, 1142, 1031, 948, 748, 699;
MS EI-MS m/z 626 (M+); high-resolution ESI-MS m/z 468.1968
(M+ + Na, calcd for C28H31NNaO2S 468.1973).
colorless oil: [α]23 +11.6 (c 0.22, CHCl3); H NMR (benzene-d6)
D
δ 0.76 (3H, d, J = 6.8 Hz), 0.85 (3H, d, J = 6.1 Hz), 0.88 (3H, d, J =
7.5 Hz), 0.95(3H, d, J = 6.8 Hz), 1.02 (1H, m), 1.10 (1H,m), 1.10
(3H, d, J = 6.7 Hz), 1.24 (1H, m), 1.34 (1H, m), 1.38 (1H, m), 1.39
(1H, m), 1.54 (1H, m), 1.87 (1H, m), 2.05 (1H, m), 2.28 (1H, m),
2.31 (1H, m), 2.43 (3H, s), 2.55 (1H, m), 2.72 (1H, dd, J = 8.4, 10.7
Hz), 2.94 (1H, dd, J = 8.8, 10.5 Hz), 3.35 (2H, m), 4.75 (1H, dd, J =
7.5, 7.8 Hz), 5.01 (1H, d, J = 10.3 Hz), 5.24 (1H, ddd, J = 1.6, 1.6, 17.2
Hz), 5.85 (1H, ddd, J = 6.1, 10.3, 17.2 Hz); 13C NMR (benzene-d6) δ
176.1, 175.8, 170.7, 170.5, 139.2, 139.0, 116.2, 116.1, 80.2, 48.8, 47.0,
43.6, 41.4, 41.3, 39.9, 39.8, 39.6, 38.7, 38.6, 38.4, 37.0, 35.7, 35.6, 35.5,
34.6, 29.5, 29.1, 28.7, 20.6, 20.4, 19.5, 18.8, 17.6, 17.5, 13.7, 13.5; IR
(neat) 2954, 2918, 2868, 1640, 1461, 1406, 1377, 1264, 1196, 1131,
1082, 1007, 924; MS FAB-MS m/z 367 (M+ + H); high-resolution
FAB-MS m/z 367.2767 (M+ + H, calcd for C21H39N2OS 367.2783).
(3R,4S,6S)-8-((R)-N,2-Dimethylbutanamido)-3,4,6-trimethyl-
N-((S)-1-(tritylthio)but-3-en-2-yl)octanamide (28). To a solution
of ent-10 (36.1 mg, 0.105 mmol) and caroboxlic acid 9 (22.8 mg,
0.0761 mmol) in CH2Cl2 (0.7 mL) was added EDCI (20.0 mg,
0.105 mmol) and DMAP (1.0 mg, 8.1 μmol) at room temperature
under Ar atmosphere. The mixture was stirred for 5 h, quenched with
1 N HCl, extracted with AcOEt (×3), washed with brine, dried over
Na2SO4, filtered, and concentrated in vacuo. The residue was purified
by silica gel column chromatography (AcOEt/hexane = 30:70) to give
amide 28 (36.2 mg, 0.0577 mmol, 82%) as a pale oil: [α]23 −23.5
D
(c 1.15, CHCl3), 1H NMR (CDCl3) δ 0.67−0.98 (12H, m), 1.03 (3H,
t, J = 6.9 Hz), 1.05−1.52 (8H, m), 1.53−1.60 (1H, m), 1.72−2.12
(2H, m), 2.28−2.31 (1H, m), 2.38−2.61 (2H, m), 2.84, 2.93 (total
3H, each s), 3.28−3.30 (2H, m), 4.47 (1H, s), 5.01 (2H, d, J = 12.2
Hz), 5.56−5.60 (1H, m), 7.11−7.34 (15H, m); 13C NMR (CDCl3) δ
176.4, 171.9, 144.4, 136.7, 129.4, 127.9, 126.7, 115.6, 66.7, 50.0, 48.1,
46.2, 42.2, 40.8, 40.6, 40.1, 37.4, 37.3, 36.6, 35.7, 35.4, 34.2, 33.7, 29.7,
28.3, 27.4, 27.1, 19.2, 17.8, 17.2, 16.6, 16.3, 14.5, 12.2, 12.1; IR (neat)
3288, 3052, 2956, 2918, 2868, 1625, 1535, 1488, 1457, 1443, 1413,
1378, 1294, 1081, 1033, 986, 920, 700; MS EI-MS m/z 626 (M+);
high-resolution EI-MS m/z 626.3906 (M+, calcd for C40H54N2O2S
626.3900).
(R)-1-(Tritylthio)but-3-en-2-amine (10). To a solution of olefin
26 (52.5 mg, 0.114 mmol) in CH2Cl2 (0.5 mL) was added TFA
(0.3 mL) at room temperature. The mixture was stirred for 30 min,
concentrated in vacuo added 1 N NaOH, extracted with CH2Cl2 (×3),
dried over Na2SO4, filtered, and concentrated in vacuo. The crude
amine was employed directly in the next reaction.
(R)-N,2-Dimethyl-N-((3S,5S,6R)-3,5,6-trimethyl-7-((S)-4-vinyl-
4,5-dihydrothiazol-2-yl)heptyl)butanamide (2). To a solution of
amide 28 (10.2 mg, 0.0163 mmol) in CH2Cl2 (0.3 mL) was added
TiCl4 (5.4 μL, 0.0489 mmol) at room temperature under Ar atmo-
sphere. The mixture was stirred for 12 h, quenched with saturated
Rochelle salt, stirred for 1 h, extracted with AcOEt (×3), washed with
brine, dried over Na2SO4, filtered, and concentrated in vacuo. The
residue was purified by silica gel column chromatography (AcOEt/
hexane = 30:70) to give 3-epi-kalkitoxin 2 (4.4 mg, 0.0120 mmol, 74%)
as a colorless oil: [α]23D −59.1 (c 0.425, CHCl3), 1H NMR (benzene-d6)
δ 0.45−1.53 (21H, m), 1.01−1.25 (1H, m), 1.53−1.60 (1H, m), 1.75
(1H, m), 1.97 (1H, m), 2.08 (1H, m), 2.12 (3H, s), 2.22 (1H, m), 2.40
(1H, dd, J = 10.7, 8.3 Hz), 2.63 (1H, dd, J = 10.7, 8.8 Hz), 3.04 (2H,
m), 4.47 (1H, m), 4.70 (1H, d, J = 10.0 Hz), 4.94 (1H, d, J = 16.8 Hz),
5.53 (1H, ddd, J = 6.1, 10.0, 16.8); 13C NMR (benzene-d6) δ 176.1,
175.8, 170.7, 170.5, 139.2, 139.0, 116.2, 116.1, 80.2, 48.8, 47.1,
41.4, 41.3, 39.9, 39.6, 38.7, 38.3, 37.1, 35.8, 35.5, 34.8, 34.6, 34.3, 32.0,
31.4, 30.5, 29.5, 29.4, 28.7, 25.3, 24.5, 21.6, 20.5, 20.3, 19.5, 18.8, 17.6,
16.0, 13.7, 13.5; IR (neat) 2954, 2918, 2866, 1640, 1459, 1410, 1377,
1259, 1193, 1084, 1026, 921, 802, 701; MS EI-MS m/z 366 (M+);
high-resolution EI-MS m/z 366.2698 (M+, calcd for C21H38N2OS
366.2705).
(R)-N,2-Dimethyl-N-((3S,5S,6S)-3,5,6-trimethyl-8-oxo-8-((S)-
2-oxo-4-phenyloxazolidin-3-yl)octyl)butanamide (30). To a
solution of (COCl)2 (230 μL, 2.64 mmol) in CH2Cl2 (1.7 mL) was
added DMSO (250 μL, 3.52 mL) at −78 °C under Ar atmosphere.
After 15 min, a solution of alcohol S-1 (214 mg, 0.881 mmol) in
CH2Cl2 (1.7 mL) was added to the mixture. After an additional
45 min, Et3N (616 μL, 4.41 mmol) was added to the mixture. The
mixture was warmed to room temperature, stirred for 1 h, quenched
with saturated NH4Cl, extracted with CH2Cl2 (×3), washed with
brine, dried over Na2SO4, filtered, and concentrated in vacuo. The
crude aldehyde was employed directly in the next reaction
(3R,4S,6S)-8-((R)-N,2-Dimethylbutanamido)-3,4,6-trimethyl-
N-((R)-1-(tritylthio)but-3-en-2-yl)octanamide (27). To a solution
of crude amine and caroboxlic acid 9 (22.8 mg, 0.0761 mmol) in
CH2Cl2 (0.7 mL) was added EDCI (22.0 mg, 0.114 mmol) and
DMAP (1.0 mg, 8.1 μmol) at room temperature under Ar atmosphere.
The mixture was stirred for 5 h, quenched with 1 N HCl, extracted
with AcOEt (×3), washed with brine, dried over Na2SO4, filtered, and
concentrated in vacuo. The residue was purified by silica gel column
chromatography (AcOEt/hexane = 30:70) to give amide 27 (40.8 mg,
0.0651 mmol, 86%) as a pale oil: [α]23 +12.2 (c 0.30, CHCl3);
D
1H NMR (CDCl3) δ 0.80−0.89 (12H, m), 1.08 (3H, t, J = 6.7 Hz),
1.23−1.50 (8H, m), 1.65−1.70 (1H, m), 1.90−1.95 (1H, m), 2.13−
2.20 (1H, m), 2.37−2.39 (1H, m), 2.41−2.59 (2H, m), 2.90, 3.00
(total 3H, each s), 3.28−3.40 (2H, m), 4.54 (1H, br), 5.04−5.08 (2H,
d, J = 14.9 Hz), 5.62−5.66 (1H, m), 7.20−7.41 (15H, m); 13C NMR
(CDCl3) δ 176.3, 176.0, 171.9, 171.7, 144.4, 136.7, 129.4, 127.8, 126.7,
115.6, 66.7, 50.0, 48.1, 46.1, 40.8, 40.7, 37.4, 37.2, 36.6, 35.7, 35.3,
34.2, 33.7, 31.0, 29.7, 28.4, 27.4, 27.1, 19.2, 17.8, 17.2, 16.5, 16.3, 16.2,
16.1, 12.2, 12.0; IR (neat) 3290, 3052, 2956, 2920, 2868, 1624, 1535,
1487, 1443, 1413, 1377, 1296, 1081, 1033, 989, 922, 700; MS EI-MS
m/z 626 (M+); high-resolution EI-MS m/z 626.3906 (M+, calcd for
C40H54N2O2S 626.3900).
(R)-N,2-Dimethyl-N-((3S,5S,6R)-3,5,6-trimethyl-7-((R)-4-vinyl-
4,5-dihydrothiazol-2-yl)heptyl)butanamide (1). To a solution of
amide 27 (23.4 mg, 0.0373 mmol) in CH2Cl2 (0.7 mL) was added
TiCl4 (12 μL, 0.112 mmol) at room temperature under Ar atmo-
sphere. The mixture was stirred for 12 h, quenched with saturated
Rochelle salt, stirred for 1 h, extracted with AcOEt (×3), washed with
brine, dried over Na2SO4, filtered, and concentrated in vacuo. The
residue was purified by silica gel column chromatography (AcOEt/
hexane = 30:70) to give kalkitoxin 1 (10.4 mg, 0.0283 mmol, 76%) as a
363
dx.doi.org/10.1021/jo201951s | J. Org. Chem. 2012, 77, 357−370

The Journal of Organic Chemistry
Article
To a solution of phosphonate ent-17 (451 mg, 1.32 mmol) in THF
(4.4 mL) was added NaHMDS (0.99 M in THF, 1.33 mL, 1.32 mmol)
at 0 °C under Ar atmosphere. After 30 min, a solution of crude
aldehyde in THF (4.4 mL) was added to the mixture. The mixture was
warmed to room temperature, stirred for 12 h, quenched with
saturated NaHCO3, extracted with AcOEt (×3), washed with brine,
dried over Na2SO4, filtered, and concentrated in vacuo. The crude
α,β-unsaturated imide 29 was employed directly in the next reaction.
To a solution of CuBr·Me2S complex (452 mg, 2.20 mmol) in THF
(4.4 mL) was added dropwise MeMgBr (0.96 M in THF, 3.07 mL,
2.95 mmol) at −78 °C under Ar atmosphere. After 20 min, a solu-
tion of crude α,β-unsaturated imide (249 mg, 0.581 mmol) in THF
(4.4 mL) was added to the mixture. The mixture was warmed to
−40 °C, stirred for 1 h, quenched with saturated NaHCO 3, extracted
with AcOEt (×3), washed with brine, dried over Na2SO4, filtered, and
concentrated in vacuo. The residue was purified by silica gel column
chromatography (AcOEt/hexane = 20:80) to give imide 30 (255 mg,
0.573 mmol, 65%) as a colorless oil: [α]25D −55.5 ( c 1.54, CHCl3), 1
brine, dried over Na2SO4, filtered, and concentrated in vacuo. The
residue was purified by silica gel column chromatography (AcOEt/
hexane = 30:70) to give 7-epi-kalkitoxin 3 (13.6 mg, 0.0371 mmol,
47%) as a colorless oil: [α]26 +17.7 (c 0.79, CHCl3), 1H NMR
D
(benzene-d6) δ 0.65−1.32 (21H, m), 1.46−1.53 (1H, m), 1.79−1.90
(1H, m), 1.98 (1H, m), 2.25 (1H, m), 2.31 (1H, m), 2.41 (3H, s), 2.48
(1H, m), 2.65 (1H, dd, J = 8.3, 15.6 Hz), 2.89 (1H, dd, J = 8.8, 15.6
Hz), 3.30 (2H, m), 4.73 (1H, m), 4.96 (1H, d, J = 10.5 Hz), 5.19 (1H,
d, J = 17.3 Hz), 5.78 (1H, ddd, J = 6.3, 10.5, 17.3 Hz); 13C NMR
(benzene-d6) δ 175.2, 174.9, 169.7, 169.4, 138.2, 138.1, 115.3, 115.2,
79.3, 71.7, 56.1, 47.8, 46.0, 42.5, 40.0, 38.9, 37.6, 37.0, 36.8, 36.4, 35.5,
34.7, 33.7, 33.6, 33.6, 28.4, 28.1, 27.7, 19.8, 19.6, 18.4, 17.7, 14.8, 14.7,
14.5, 14.5, 12.6, 12.4; IR (neat) 2954, 2918, 2868, 1640, 1460, 1410,
1377, 1260, 1193, 1084, 1026, 921, 802, 701; MS FAB-MS m/z FAB-
MS m/z 367 (M+ + H); high-resolution FAB-MS m/z 367.2802 (M+ +
H, calcd for C21H39N2OS 367.2783).
(R)-3-((R,E)-6-((tert-Butyldiphenylsilyl)oxy)-5-methylhex-2-
enoyl)-4-phenyloxazolidin-2-one (32). To a solution of phospho-
nate 17 (104.0 mg, 0.304 mmol) in THF (1.3 mL) was added
NaHMDS (1.06 M in THF, 0.287 mL) at 0 °C under Ar atmosphere.
After 30 min, a solution of ent-16 (93.9 mg, 0.276 mmol) in THF
(1.3 mL) was added to the mixture. The mixture was warmed to room
temperature, stirred for 2.5 h, quenched with saturated NaHCO3,
extracted with AcOEt (×3), washed with brine, dried over Na2SO4,
filtered, and concentrated in vacuo. The residue was purified by silica
gel column chromatography (AcOEt/hexane = 10:90) to give α,β-
H NMR (CDCl ), δ 0.63−0.97 (12H, m), 1.04 (3H, d, J = 6.9 Hz,
3
1 rotamer), 1.09 (3H, d, J = 6.9 Hz, 1 rotamer), 1.12−1.19 (2H, m),
1.24−1.75 (6H, m), 1.92−2.08 (1H, m), 2.50−2.62 (1H, m), 2.74−
2.83 (2H, m), 2.85−2.95 (1H, m), 2.89, 2.97 (total 3H, each s), 3.14−
3.47 (2H, m), 4.23−4.29 (1H, m), 4.66 (1H, t, J = 8.8 Hz), 5.38−5.47
13
(1H, m), 7.25−7.55 (5H, m) ; C NMR (CDCl ), 176.3, 176.0,
3
172.5, 172.4, 153.6, 139.1, 139.0, 129.1, 129.05, 129.02, 128.8, 128.6,
125.9, 125.85, 125.79, 125.77, 72.5, 69.8, 57.7, 56.3, 48.1, 48.0, 46.1,
45.8, 39.9, 39.8, 39.0, 38.3, 37.4, 37.24, 37.21, 37.18, 35.4, 35.2, 34.8,
34.7, 34.38, 34.35, 34.06, 34.04, 33.7, 33.3, 29.7, 28.2, 27.4, 27.1, 20.5,
18.9, 17.8, 17.2, 16.7, 16.4, 16.31, 16.27, 14.1, 12.2, 12.1; IR (neat)
2961, 2926, 2874, 1780, 1703, 1637, 1456, 1384, 1321, 1196, 1135,
1080, 1043, 963, 916, 762, 704; MS ESI-MS m/z 467 (M + Na+);
high-resolution ESI-MS m/z 467.2875 (M+ + Na, calcd for
C26H40N2O4Na 467.2880)
unsaturated imide 32 (80.9 mg, 0.153 mmol, 55%) as a colorless oil:
1
[α]23 −12.2 (c 1.78, CHCl3); H NMR (CDCl3) δ 0.88 (3H, d,
D
6.8 Hz), 1.05 (9H, s), 1.83−1.88 (1H, m), 2.07−2.16 (1H, m), 2.47−
2.53 (1H, m), 3.43−3.53 (2H, m), 4.28 (1H, dd, J = 3.9, 8.8 Hz), 4.70
(1H, t, J = 8.8 Hz), 5.48 (1H, dd, J = 3.9, 8.8 Hz), 7.03−7.11 (1H, m),
7.30−7.43 (12H, m), 7.62−7.66 (4H, m); 13C NMR (CDCl3) δ 164.3,
153.5, 150.7, 139.1, 135.5, 133.6, 129.5, 129.1, 128.6, 127.6, 125.9,
121.2, 69.9, 68.3, 57.7, 36.6, 35.5, 26.9, 19.3, 16.5; IR (neat) 3064,
2950, 2924, 2852, 1776, 1685, 1630, 1425, 1382, 1358, 1336, 1193,
1109, 1005, 896, 823, 703; FAB-MS m/z 550 (M+ + Na); high-resolu-
tion FAB-MS m/z 550.2374 (M+ + Na, calcd for C32H37NO4SiNa
550.2390).
(3S,4S,6S)-8-((R)-N,2-Dimethylbutanamido)-3,4,6-trimethyl-
N-((R)-1-(tritylthio)but-3-en-2-yl)octanamide (31). To a solution
of imide 30 (255 mg, 0.574 mmol) in THF/H2O (2.4 mL, 4: 1) was
added 30% H2O2 (328 μL) and 0.5 M LiOH (3.4 mL) at room
temperature. The mixture was stirred for 12 h, 1 N NaOH was added,
and the mixture was washed with AcOEt. The aqueous layer was
acidified with 1 N HCl, extracted with AcOEt (×3), washed with
brine, dried over Na2SO4, filtered, and concentrated in vacuo. The
crude carboxylic acid was employed directly in the next reaction.
To a solution of amine 10 (47.5 mg, 0.138 mmol) and caroboxlic
acid (27.4 mg, 0.0920 mmol) in CH2Cl2 (0.9 mL) were added EDCI
(26.5 mg, 0.138 mmol) and DMAP (1.0 mg, 8.1 μmol) at room
temperature under Ar atmosphere. The mixture was stirred for 5 h,
quenched with 1 N HCl, extracted with AcOEt (×3), washed with
brine, dried over Na2SO4, filtered, and concentrated in vacuo. The
residue was purified by silica gel column chromatography (AcOEt/
hexane = 30:70) to give amide 31 (49.2 mg, 0.0577 mmol, 85%) as a
pale oil: [α]26D +45.8 (c 0.70, CHCl3), 1H NMR (CDCl3) δ 0.80−0.89
(12H, m), 1.08 (3H, t, J = 6.7 Hz), 1.23−1.50 (8H, m), 1.65−1.70
(1H, m), 1.90−1.95 (1H, m), 2.13−2.20 (1H, m), 2.37−2.39 (1H, m),
2.41−2.59 (2H, m), 2.90, 3.00 (total 3H, each s), 3.28−3.40 (2H, m),
4.54 (1H, s), 5.04−5.08 (2H, d, J = 14.9 Hz), 5.62−5.66 (1H, m),
7.20−7.41 (15H, m); 13C NMR (CDCl3) δ 176.3, 176.0, 171.8, 171.5,
144.5, 136.8, 136.7, 129.4, 127.9, 127.8, 126.7, 126.7, 126.0, 115.4,
66.7, 66.7, 56.4, 49.9, 49.9, 48.0, 46.2, 42.2, 42.2, 41.9, 37.4, 37.2, 36.9,
36.6, 35.3, 34.9, 34.9, 34.9, 33.9, 33.8, 33.7, 33.7, 29.7, 29,7, 28.2, 27.5,
27.2, 27.1, 19.5, 19.3, 17.8, 17.2, 14,6, 14.6, 14.4, 12.2, 12.1; IR (neat)
3288, 3052, 2956, 2919, 2868, 1625, 1535, 1489, 1457, 1443, 1413,
1378, 1294, 1081, 1033, 988, 922, 700; MS EI-MS m/z 626 (M+);
high-resolution EI-MS m/z 626.3906 (M+, calcd for C40H54N2O2S
626.3900).
(R)-3-((3S,5R)-6-((tert-Butyldiphenylsilyl)oxy)-3,5-dimethyl-
hexanoyl)-4-phenyloxazolidin-2-one (33). To a solution of
CuBr·Me2S complex (1.12 g, 5.45 mmol) in THF (30 mL) was
added dropwise MeMgBr (0.96 M in THF, 9.54 mL, 9.16 mmol) at
−78 °C under Ar atmosphere. After 10 min, a solution of α,β-unsaturated
imide 32 (1.15 g, 2.18 mmol) in THF (30 mL) was added to the mixture.
The mixture was stirred for 30 min, warmed to −40 °C, stirred for 2 h,
quenched with saturated NaHCO3, extracted with AcOEt (×3), washed
with brine, dried over Na2SO4, filtered, and concentrated in vacuo. The
residue was purified by silica gel column chromatography (AcOEt/hexane =
20:80) to give imide 33 (1.16 mg, 2.13 mmol, 98%) as a colorless oil:
[α]23D +19.4 (c 1.52, CHCl3); 1H NMR (CDCl3) δ 0.82 (3H, d, 6.6 Hz),
0.91 (3H, d, 6.6 Hz), 1.04 (9H, s), 1.31−1.35 (2H, m), 1.70−1.71
(1H, m), 2.00−2.08 (1H, m), 2.77−2.81 (2H, m), 3.34 (1H, dd, J = 6.8,
10.0 Hz), 3.49 (1H, dd, J = 5.4, 10.0 Hz), 4.24 (1H, dd, J = 3.9, 9.0 Hz),
4.65 (1H, t, J = 8.8 Hz), 5.39 (1H, dd, J = 3.9, 8.8 Hz), 7.29−7.42 (11H,
m), 7.62−7.66 (4H, m); 13C NMR (CDCl3) δ 172.1, 153.5, 139.1, 135.5,
133.9, 129.4, 129.0, 128.5, 127.5, 125.8, 69.8, 68.8, 57.6, 42.4, 40.9, 33.2,
27.4, 26.9, 20.4, 19.4, 17.7; IR (neat) 3064, 2950, 2922, 2850, 1780, 1704,
1456, 1425, 1382, 1322, 1195, 1109, 1003, 823, 703; EI-MS m/z 544
(M+ + H); high-resolution ESI-MS m/z 544.2863 (M+ + H, calcd for
C33H42NO4Si 544.2883).
(3S,5R)-6-((tert-Butyldiphenylsilyl)oxy)-3,5-dimethylhexan-1-ol
(34). To a solution of imide 33 (964 mg, 1.78 mmol) in THF (18
mL) were added MeOH (162 μL, 3.56 mmol) and LiBH4 (155 mg,
7.12 mmol) at room temperature under Ar atmosphere. The mixture
was stirred for 30 min, quenched with saturated NaHCO3, extracted
with AcOEt (×3), washed with brine, dried over Na2SO4, filtered,
and concentrated in vacuo. The residue was purified by silica gel
column chromatography (AcOEt/hexane = 20:80) to give alcohol
34 (487 mg, 1.26 mmol, 71%) as a colorless oil: [α]23D +5.95 (c 1.60,
(R)-N,2-Dimethyl-N-((3S,5S,6S)-3,5,6-trimethyl-7-((R)-4-vinyl-
4,5-dihydrothiazol-2-yl)heptyl)butanamide (3). To a solution of
amide 31 (49.2 mg, 0.0785 mmol) in CH2Cl2 (1.5 mL) was added
TiCl4 (25.3 μL, 0.230 mmol) at room temperature under Ar atmo-
sphere. The mixture was stirred for 12 h, quenched with saturated
Rochelle salt, stirred for 1 h, extracted with AcOEt (×3), washed with
1
CHCl3); H NMR (CDCl3) δ 0.82 (3H, d, J = 6.6 Hz), 0.93 (3H, d,
364
dx.doi.org/10.1021/jo201951s | J. Org. Chem. 2012, 77, 357−370

The Journal of Organic Chemistry
Article
J = 6.6 Hz), 1.04 (9H, s), 1.30−1.42 (3H, m), 1.55−1.66 (2H, m),
1.72−1.76 (1H, m), 2.50 (1H, br), 3.42 (1H, dd, J = 6.4, 9.8 Hz), 3.50
(1H, dd, J = 5.1, 9.8 Hz), 3.58−3.70 (2H, m), 7.34−7.42 (6H, m),
7.62−7.67 (4H, m); 13C NMR (CDCl3) δ 135.5, 133.9, 129.4, 127.5,
68.8, 61.1, 41.2, 39.8, 33.2, 27.0, 26.9, 20.3, 19.4, 17.7; IR (neat) 3344,
3064, 3044, 2950, 2924, 2852, 1468, 1425, 1387, 1359, 1110, 1008,
823, 739, 702; MS FAB-MS m/z 385 (M+ + H); high-resolution FAB-
MS m/z 385.2573 (M+ + H, calcd for C24H37O2Si 385.2563).
(((2R,4S)-6-Azido-2,4-dimethylhexyl)oxy)(tert-butyl)-
diphenylsilane (S-2). To a solution of alcohol 34 (487 mg,
1.27 mmol) in CH2Cl2 (12 mL) were added Et3N (353 μL, 2.54 mmol)
and MsCl (148 μL, 1.91 mmol) at room temperature under Ar
atmosphere. The mixture was stirred for 3 h, quenched with saturated
NaHCO3, extracted with AcOEt (×3), washed with brine, dried over
Na2SO4, filtered, and concentrated in vacuo. The crude mesylate was
employed directly in the next reaction.
(CDCl3) δ 176.2, 175.9, 135.5, 133.9, 133.8, 129.5, 129.4, 127.5, 68.9,
68.6, 48.0, 46.1, 41.2, 41.0, 37.4, 37.2, 35.9, 35.2, 34.0, 33.7, 33.2, 28.3,
27.4, 27.1, 26.9, 20.3, 19.3, 17.9, 17.7, 17.2, 12.2, 12.1; IR (neat) 3064,
3044, 2952, 2924, 2852, 1643, 1462, 1425, 1408, 1259, 1191, 1110,
1087, 1008, 823, 739, 703; MS ESI-MS m/z 504 (M+ + Na); high-
resolution ESI-MS m/z 504.3254 (M+ + Na, calcd for C30H47NO2SiNa
504.3274).
(R)-N-((3S,5R)-6-Hydroxy-3,5-dimethylhexyl)-N,2-dimethyl-
butanamide (37). To a solution of N-methyl amide S-3 (278 mg,
0.577 mmol) in THF (2.9 mL) was added TBAF (1 M in THF,
0.75 mL, 0.75 mmol) at room temperature. The mixture was stirred
for 2 h, quenched with saturated NH4Cl, extracted with AcOEt (×3),
washed with brine, dried over Na2SO4, filtered, and concentrated
in vacuo. The residue was purified by silica gel column chromatography
(AcOEt/hexane = 40:60) to give alcohol 37 (132 mg, 0.542 mmol,
1
94%) as a colorless oil: [α]23 −4.29 ( c 1.41, CHCl3); H NMR
D
To a solution of crude mesylate in DMF (12 mL) was added NaN3
(330 mg, 5.08 mmol) at room temperature. The mixture was heated to
40 °C for 12 h, quenched with saturated NaHCO3, extracted with
AcOEt (×3), washed with brine, dried over Na2SO4, filtered, and
concentrated in vacuo. The residue was purified by silica gel column
chromatography (AcOEt/hexane = 10:90) to give azide S-2 (392 mg,
(CDCl ) δ 0.87−0.95 (6H, m), 1.08 (3H, d, J = 6.6 Hz, 1 rotamer),
3
1.10 (3H, d, J = 6.6 Hz, 1 rotamer), 1.37−1.46 (4H, m), 1.67−1.73
(2H, m), 1.82 (3H, m), 2.58 (1H, m), 2.92, 3.01 (total 3H, each s),
13
3.24−3.52 (4H, m); C NMR (CDCl ) δ 176.7, 176.3, 67.8, 66.6,
3
48.0, 45.4, 40.9, 39.8, 37.5, 37.2, 35.7, 35.1, 34.5, 33.7, 33.0, 32.9, 28.2,
27.6, 27.4, 27.0, 20.7, 20.3, 18.0, 17.8, 17.3, 17.0, 12.2, 12.1; IR (neat)
3404, 2956, 2922, 2866, 1624, 1461, 1412, 1375, 1297, 1256, 1195,
1133, 1082, 1044, 985; MS EI-MS m/z 243 (M+); high-resolution EI-
MS m/z 243.2195 (M+, calcd for C14H29NO2 243.2198).
(R)-N-((3S,5R,E)-3,5-Dimethyl-8-oxo-8-((R)-2-oxo-4-phenyl-
oxazolidin-3-yl)oct-6-en-1-yl)-N,2-dimethylbutanamide (38).
To a solution of (COCl)2 (64 μL, 0.738 mmol) in CH2Cl2 (0.5 mL)
was added DMSO (70 μL, 0.984 mL) at −78 °C under Ar atmo-
sphere. After 15 min, a solution of alcohol 37 (59.8 mg, 0.246 mmol)
in CH2Cl2 (0.5 mL) was added to the mixture. After an additional
45 min, Et3N (172 μL, 1.23 mmol) was added to the mixture. The
mixture was warmed to room temperature, stirred for 1 h, quenched
with saturated NH4Cl, extracted with CH2Cl2 (×3), washed with
brine, dried over Na2SO4, filtered, and concentrated in vacuo. The
crude aldehyde was employed directly in the next reaction.
To a solution of phosphonate 17 (126 mg, 0.369 mmol) in THF
(1.2 mL) was added NaHMDS (0.99 M in THF, 373 μL, 0.369 mmol)
at 0 °C under Ar atmosphere. After 30 min, a solution of crude
aldehyde in THF (1.2 mL) was added to the mixture. The mixture was
warmed to room temperature, stirred for 12 h, quenched with
saturated NaHCO3, extracted with AcOEt (×3), washed with brine,
dried over Na2SO4, filtered, and concentrated in vacuo. The residue
was purified by silica gel column chromatography (AcOEt/hexane =
0.957 mmol, 75%) as a colorless oil: [α]23 +11.4 (c 1.41, CHCl3);
D
1H NMR (CDCl3) δ 0.86 (3H, d, J = 6.4 Hz), 0.93 (3H, d, J = 6.6 Hz),
1.05 (9H, s), 1.30−1.41 (3H, m), 1.54−1.62 (2H, m), 1.71−1.73
(1H, m), 3.20−3.29 (2H, m), 3.42−3.51 (2H, m), 7.35−7.44 (6H, m),
7.64−7.67 (4H, m); 13C NMR (CDCl3) δ 135.5, 133.9, 129.5, 127.5,
68.7, 49.4, 41.0, 35.5, 33.2, 27.9, 27.0, 20.1, 19.4, 17.7; IR (neat) 3064,
2950, 2924, 2852, 2090, 1460, 1425, 1387, 1359, 1189, 1110, 1007,
822, 739, 702; MS ESI-MS m/z 432 (M+ + Na); high-resolution ESI-
MS m/z 432.2436 (M+ + Na, calcd for C24H35N3OSiNa 432.2547).
(R)-N-((3S,5R)-6-((tert-Butyldiphenylsilyl)oxy)-3,5-dimethyl-
hexyl)-2-methylbutanamide (36). To a solution of azide S-2
(392 mg, 0.957 mmol) in THF (9.5 mL) were added H2O (86 μL)
and PPh3 (656 mg, 2.39 mmol) at room temperature. The mixture was
heated to 40 °C for 12 h, cooled to room temperature, dried over
Na2SO4, filtered, and concentrated in vacuo. The crude amine was
employed directly in the next reaction.
To a solution of crude amine and caroboxlic acid 12 (117 mg,
1.15 mmol) in CH2Cl2 (9.5 mL) were added Et3N (201 μL,
1.44 mmol) and (EtO)2POCN (174 μL, 1.15 mmol) at room
temperature under Ar atmosphere. The mixture was stirred for 2.5 h,
quenched with saturated NaHCO3, extracted with AcOEt (×3),
washed with brine, dried over Na2SO4, filtered, and concentrated in
vacuo. The residue was purified by silica gel column chromatography
20:80) to give α,β-unsaturated imide 38 (88.1 mg, 0.205 mmol, 84%)
(AcOEt/hexane = 10:90) to give amide 36 (438 mg, 0.937 mmol,
1
as an inseparable mixture. [α]25 −83.3 (c 0.54, CHCl3), H NMR
1
98%) as a colorless oil: [α]23 +0.211 (c 1.13, CHCl3); H NMR
D
D
(CDCl3), δ 0.84−0.93 (6H, m), 0.99−1.09 (6H, m), 1.18−1.50 (4H,
m), 1.59−1.72 (3H, m), 2.50−2.58 (2H, m), 2.90, 2.98 (total 3H, each
s), 3.25 (1H, dt, J = 5.1, 10.3 Hz), 3.34 (1H, t, J = 10.3 Hz), 4.29 (1H,
m), 4.70 (1H, dt, J = 2.2, 8.6 Hz), 5.48 (1H, dd, J = 3.4, 8.6 Hz), 6.89,
6.92 (total 1H, dd, J = 15.1 Hz), 7.20−7.26 (1H, m), 7.31−7.38 (5H,
m); 13C NMR (CDCl3), 176.3, 176.0, 164.5, 156.8, 156.1, 153.5,
139.0, 138.9, 129.09, 129.07, 128.63, 128.55, 125.92, 125.91, 119.0,
118.6, 72.5, 69.97, 69.93, 57.79, 57.77, 47.9, 46.1, 43.6, 37.4, 37.2, 36.6,
35.3, 34.7, 34.6, 34.5, 33.7, 29.7, 28.65, 28.60, 27.4, 27.1, 22.7, 20.5,
20.3, 19.3, 19.2, 18.9, 17.8, 17.2, 14.2, 12.2, 12.0; IR (neat) 2962, 2925,
2872, 1779, 1687, 1636, 1456, 1381, 1362, 1326, 1197, 1102, 1044,
762, 706; MS ESI-MS m/z 451 (M + Na+); high-resolution ESI-MS
m/z 451.2566 (M+, calcd for C25H36N2O4Na 451.2567)
(R)-N,2-Dimethyl-N-((3S,5R,6R)-3,5,6-trimethyl-8-oxo-8-((R)-
2-oxo-4-phenyloxazolidin-3-yl)octyl)butanamide (39). To a
solution of CuBr·Me2S complex (298 mg, 1.45 mmol) in THF (2.9 mL)
was added dropwise MeMgBr (0.96 M in THF, 2.03 mL, 1.95 mmol)
at −78 °C under Ar atmosphere. After 20 min, a solution of α,β-
unsaturated imide 38 (249 mg, 0.581 mmol) in THF (2.9 mL) was
added to the mixture. The mixture was warmed to −40 °C, stirred for
1 h, quenched with saturated NaHCO3, extracted with AcOEt (×3),
washed with brine, dried over Na2SO4, filtered, and concentrated
in vacuo. The residue was purified by silica gel column chromatography
(CDCl3) δ 0.76−0.93 (9H, m), 1.05 (9H, s), 1.10 (3H, d, J = 6.8 Hz),
1.18−1.75 (8H, m), 1.95−2.02 (1H, m), 3.18−3.31 (2H, m), 3.38−
3.52 (2H, m), 5.27 (1H, brs), 7.35−7.41 (6H, m), 7.64−7.66 (4H, m);
13C NMR (CDCl3) δ 176.1, 135.6, 135.5, 133.9, 129.4, 127.5, 68.9,
43.3, 41.2, 37.4, 36.7, 33.1, 28.2, 27.4, 26.9, 20.1, 19.4, 17.6, 12.0; IR
(neat) 3290, 3064, 2954, 2924, 2852, 2090, 1640, 1549, 1459, 1425,
1385, 1263, 1234, 1109, 1008, 823, 739, 702; MS FAB-MS m/z 490
(M+ + Na); high-resolution FAB-MS m/z 490.3104 (M+ + Na, calcd
for C29H45NO2SiNa 490.3117).
(R)-N-((3S,5R)-6-((tert-Butyldiphenylsilyl)oxy)-3,5-dimethyl-
hexyl)-N,2-dimethylbutanamide (S-3). To a solution of amide 36
(438 mg, 0.957 mmol) in THF (9.5 mL) were added n-BuLi (2.69 M
in hexanes, 625 μL, 1.68 mmol) and MeI (233 μL, 3.74 mmol)
at −78 °C under Ar atmosphere. The mixture was stirred for 10 min
at −78 °C, warmed to room temperature, stirred for 1 h, quenched with
saturated NaHCO3, extracted with AcOEt (×3), washed with brine,
dried over Na2SO4, filtered, and concentrated in vacuo. The residue
was purified by silica gel column chromatography (AcOEt/hexane =
20:80) to give N-methyl amide S-3 (394 mg, 0.818 mmol, 88%) as a
1
colorless oil: [α]23 −4.29 (c 1.41, CHCl3); H NMR (CDCl3) δ
D
0.84−0.93 (9H, m), 1.05, 1.06 (total 9H, each s), 1.13−1.58 (9H, m),
1.65−1.74 (2H, m), 2.54 (1H, m), 2.90, 2.97 (total 3H, each s), 3.26−
3.52 (4H, m), 7.35−7.41 (6H, m), 7.64−7.66 (4H, m); 13C NMR
365
dx.doi.org/10.1021/jo201951s | J. Org. Chem. 2012, 77, 357−370

The Journal of Organic Chemistry
Article
(AcOEt/hexane = 20:80) to give imide 39 (240 mg, 0.540 mmol,
93%) as an inseparable mixture.
(2H, m), 3.40 (1H, dd, J = 9.7, 6.6 Hz), 3.50 (1H, dd, J = 9.7, 5.3 Hz),
5.40 (1H, brs), 7.34−7.43 (6H, m), 7.64−7.66 (4H, m); 13C NMR
(CDCl3) δ 176.1, 135.5, 133.9, 129.5, 127.5, 68.8, 43.3, 41.1, 37.3,
36.7, 33.1, 28.1, 27.4, 26.9, 20.1, 19.3, 17.7, 16.8, 12.0. IR (neat) 3290,
3064, 2954, 2924, 2852, 2090, 1640, 1549, 1459, 1425, 1385, 1263,
1234, 1109, 1008, 823, 739, 702; MS FAB-MS m/z 468 (M+ + H);
high-resolution FAB-MS m/z 468.3289 (M+ + H, calcd for C29H46-
NO2Si 468.3298).
(R)-N-((3R,5S)-6-((tert-Butyldiphenylsilyl)oxy)-3,5-dimethyl-
hexyl)-N,2-dimethylbutanamide (S-5). To a solution of amide 40
(511 mg, 1.09 mmol) in THF (10.9 mL) were added n-BuLi (2.63 M
in hexanes, 745 μL, 1.96 mmol) and MeI (271 μL, 4.36 mmol)
at −78 °C under Ar atmosphere. The mixture was stirred for 10 min
at −78 °C, warmed to room temperature, stirred for 1 h, quenched with
saturated NaHCO3, extracted with AcOEt (×3), washed with brine,
dried over Na2SO4, filtered, and concentrated in vacuo. The residue
was purified by silica gel column chromatography (AcOEt/hexane =
(3R,4R,6S)-8-((R)-N,2-Dimethylbutanamido)-3,4,6-trimethyl-
N-((R)-1-(tritylthio)but-3-en-2-yl)octanamide (S-4). To a solu-
tion of imide 39 (59.4 mg, 0.134 mmol) in THF/H2O (0.5 mL, 4: 1)
were added 30% H2O2 (77 μL) and 0.5 M LiOH (0.7 mL) at room
temperature. The mixture was stirred for 12 h, 1 N NaOH was added,
and the mixture was washed with AcOEt. The aqueous layer was
acidified with 1 N HCl, extracted with AcOEt (×3), washed with
brine, dried over Na2SO4, filtered, and concentrated in vacuo. The
crude carboxylic acid was employed directly in the next reaction.
To a solution of amine 10 (17.6 mg, 0.0510 mmol) and caroboxlic
acid (10.1 mg, 0.0340 mmol) in CH2Cl2 (1.0 mL) were added EDCI
(10.0 mg, 0.051 mmol) and DMAP (0.4 mg, 3.0 μmol) at room
temperature under Ar atmosphere. The mixture was stirred for 5 h,
quenched with 1 N HCl, extracted with AcOEt (×3), washed with
brine, dried over Na2SO4, filtered, and concentrated in vacuo. The
residue was purified by silica gel column chromatography (AcOEt/
hexane = 30:70) to give amide S-4 (16.6 mg, 0.0265 mmol, 78%) as a
pale oil: [α]23D +12.1 (c 1.32, CHCl3); 1H NMR (CDCl3) δ 0.77−0.95
(12H, m), 1.07 (3H, t, J = 7.1 Hz), 1.25−1.69 (9H, m), 1.92 (1H, m),
2.13−2.20 (1H, m), 2.37−2.39 (1H, m), 2.46−2.56 (2H, m), 2.91,
2.99 (total 3H, each s), 3.27−3.37 (2H, m), 4.54 (1H, s), 5.06 (2H, d,
J = 14.9 Hz), 5.61−5.69 (1H, m), 7.20−7.56 (15H, m); 13C NMR
(CDCl3) δ 176.3, 176.0, 171.8, 171.5, 144.5, 136.8, 129.5, 127.9, 126.7,
115.6, 66.8, 50.0, 48.1, 46.0, 42.5, 42.2, 37.4, 37.3, 36.6, 36.0, 35.3,
34.0, 33.9, 33.7, 33.2, 31.0, 29.7, 28.2, 27.5, 27.1, 20.4, 20.1, 17.9, 17.2,
15.3, 15.1, 14.2, 13.9, 12.3, 12.1; IR (neat) 3284, 3052, 2954, 2918,
2866, 1625, 1535, 1487, 1442, 1413, 1378, 1296, 1081, 1034, 988, 923,
700; MS EI-MS m/z 626 (M+); high-resolution EI-MS m/z 626.3902
(M+, calcd for C40H54N2O2S 626.3900).
20:80) to give N-methyl amide S-5 (437 mg, 0.908 mmol, 83%) as a
1
colorless oil: [α]22 −13.4 (c 0.969, CHCl3); H NMR (CDCl3) δ
D
0.84−0.93 (9H, m), 1.05, 1.06 (total 9H, each s), 1.07−1.09 (total
3H), 1.19−1.58 (5H, m), 1.62−1.76 (2H, m), 2.50−2.58 (1H, m),
2.90, 2.96 (total 3H, each s), 3.23−3.30 (2H, m), 3.39−3.52 (2H, m),
7.35−7.41 (6H, m), 7.64−7.66 (4H, m); 13C NMR (CDCl3) δ 176.3,
175.9, 135.49, 135.47, 133.9, 133.8, 129.4, 129.3, 127.5, 127.5, 68.9,
68.6, 48.0, 46.0, 41.2, 41.0, 37.4, 37.2, 36.0, 35.2, 33.9, 33.7, 33.2, 28.4,
27.5, 27.1, 26.9, 20.2, 19.4, 17.8, 17.7, 17.1, 12.2, 12.0; IR (neat) 3064,
3044, 2952, 2924, 2852, 1643, 1462, 1425, 1408, 1259, 1191, 1110,
1087, 1008, 823, 739, 703; MS FAB-MS m/z 482 (M+ + H); high-
resolution FAB-MS m/z 482.3451 (M+ + H, calcd for C30H48NO2Si
482.3454).
(R)-N-((3R,5S)-6-Hydroxy-3,5-dimethylhexyl)-N,2-dimethyl-
butanamide (41). To a solution of N-methyl amide S-5 (399 mg,
0.828 mmol) in THF (8.2 mL) was added TBAF (1 M in THF, 1.07 mL,
1.07 mmol) at room temperature. The mixture was stirred for 2 h,
quenched with saturated NH4Cl, extracted with AcOEt (×3), washed
with brine, dried over Na2SO4, filtered, and concentrated in vacuo. The
residue was purified by silica gel column chromatography (AcOEt/
hexane = 40:60) to give alcohol 41 (160 mg, 0.655 mmol, 79%) as a
pale oil: [α]23D −29.3 ( c 0.940, CHCl3); 1 H NMR (CDCl 3) δ 0.83−
0.96 (9H, m), 1.10 (3H, d, J = 6.8 Hz, 1 rotamer), 1.30−1.44 (4H, m),
1.54−1.74 (4H, m), 2.55−2.59 (1H, m), 2.92, 3.00 (total 3H, each s),
(R)-N,2-Dimethyl-N-((3S,5R,6R)-3,5,6-trimethyl-7-((R)-4-vinyl-
4,5-dihydrothiazol-2-yl)heptyl)butanamide (4). To a solution of
amide S-4 (16.6 mg, 0.0265 mmol) in CH2Cl2 (0.5 mL) was added
TiCl4 (8.6 μL, 0.0780 mmol) at room temperature under Ar atmo-
sphere. The mixture was stirred for 12 h, quenched with saturated
Rochelle salt, stirred for 1 h, extracted with AcOEt (×3), washed with
brine, dried over Na2SO4, filtered, and concentrated in vacuo. The
residue was purified by silica gel column chromatography (AcOEt/
hexane = 30:70) to give kalkitoxin 4 (5.1 mg, 0.0139 mmol, 53%) as a
1
colorless oil: [α]23 +25.3 (c 0.40, CHCl3); H NMR (benzene-d6)
D
δ 0.80−1.03 (15H, m), 1.17 (1H, d, J = 6.8 Hz), 1.26 (1H, d, J =
6.6 Hz), 1.39−1.74 (6H, m), 1.97 (1H, m), 2.18 (1H, m), 2.37 (1H,
m), 2.52 (3H, s), 2.81 (1H, m), 2.90 (1H, m), 3.03 (1H, m), 3.45 (2H,
m), 4.85 (1H, m), 5.09 (1H, d, J = 10.2 Hz), 5.32 (1H, d, J = 17.1 Hz),
5.94 (1H, m); 13C NMR (benzene-d6) δ 176.1, 175.8, 170.5, 170.3,
139.2, 139.0, 116.2, 116.1, 80.3, 48.8, 47.0, 43.7, 41.3, 41.1, 40.3, 39.9,
39.2, 37.7, 37.3, 36.3, 35.7, 35.1, 34.6, 34.3, 32.0, 31.4, 30.5, 29.7, 29.4,
29.1, 25.3, 24.5, 21.6, 21.4, 19.5, 18.8, 16.0, 15.8, 15.5, 13.7, 13.5; IR
(neat) 2954, 2918, 2866, 1639, 1461, 1408, 1378, 1262, 1195, 1081,
923; MS FAB-MS m/z 367 (M+ + H); high-resolution FAB-MS m/z
367.2773 (M+ + H, calcd for C21H39N2OS 367.2783).
(R)-N-((3R,5S)-6-((tert-Butyldiphenylsilyl)oxy)-3,5-dimethyl-
hexyl)-2-methylbutanamide (40). To a solution of ent-35 (166 mg,
0.404 mmol) in THF (4.0 mL) were added H2O (36 μL) and PPh3
(265 mg, 1.01 mmol) at room temperature. The mixture was heated to
40 °C for 12 h, cooled to room temperature, dried over Na2SO4,
filtered, and concentrated in vacuo. The crude amine was employed
directly in the next reaction.
3.30−3.81 (4H, m); 13C NMR (CDCl ) δ 176.7, 176.4, 67.8, 66.6,
3
48.0, 45.2, 40.9, 39.7, 37.5, 37.2, 35.8, 34.9, 34.4, 33.7, 33.0, 32.9, 28.2,
27.6, 27.4, 27.0, 20.7, 20.3, 17.9, 17.8, 17.3, 17.0, 12.2, 12.0.; IR (neat)
3404, 2956, 2922, 2866, 1624, 1461, 1412, 1375, 1297, 1256, 1195,
1133, 1082, 1044, 985; MS FAB-MS m/z 244 (M+ + H); high-
resolution FAB-MS m/z 244.2267 (M+ + H, calcd for C14H29NO2
244.2277).
(R)-N,2-Dimethyl-N-((3R,5S,6R)-3,5,6-trimethyl-8-oxo-8-((R)-
2-oxo-4-phenyloxazolidin-3-yl)octyl)butanamide (43). To a
solution of (COCl)2 (66 μL, 0.756 mmol) in CH2Cl2 (0.5 mL) was
added DMSO (72 μL, 1.01 mL) at −78 °C under Ar atmosphere.
After 15 min, a solution of alcohol 41 (61.3 mg, 0.252 mmol) in
CH2Cl2 (0.5 mL) was added to the mixture. After an additional
45 min, Et3N (176 μL, 1.26 mmol) was added to the mixture. The
mixture was warmed to room temperature, stirred for 1 h, quenched
with saturated NH4Cl, extracted with CH2Cl2 (×3), washed with
brine, dried over Na2SO4, filtered, and concentrated in vacuo. The
crude aldehyde was employed directly in the next reaction.
To a solution of crude amine and caroboxlic acid 12 (50.0 mg, 0.485
mmol) in CH2Cl2 (2.0 mL) were added Et3N (85.0 μL, 0.606 mmol)
and (EtO)2POCN (74.0 μL, 0.485 mmol) at room temperature under
Ar atmosphere. The mixture was stirred for 2.5 h, quenched with
saturated NaHCO3, extracted with AcOEt (×3), washed with brine,
dried over Na2SO4, filtered, and concentrated in vacuo. The residue
was purified by silica gel column chromatography (AcOEt/hexane =
To a solution of phosphonate 17 (129 mg, 0.378 mmol) in THF
(1.7 mL) was added NaHMDS (0.99 M in THF, 382 μL, 0.378 mmol)
at 0 °C under Ar atmosphere. After 30 min, a solution of crude
aldehyde in THF (1.7 mL) was added to the mixture. The mixture was
warmed to room temperature, stirred for 12 h, quenched with
saturated NaHCO3, extracted with AcOEt (×3), washed with brine,
dried over Na2SO4, filtered, and concentrated in vacuo. The crude
α,β-unsaturated imide 42 was employed directly in the next reaction.
To a solution of CuBr·Me2S complex (130 mg, 0.630 mmol) in
THF (1.2 mL) was added dropwise MeMgBr (0.96 M in THF, 1.10 mL,
1.06 mmol) at −78 °C under Ar atmosphere. After 20 min, a solution
10:90) to give amide 40 (169 mg, 0.351 mmol, 87%) as a colorless oil:
1
[α]22 −7.66 (c 1.03, CHCl3); H NMR (CDCl3) δ 0.83−0.94 (9H,
D
m), 1.05 (9H, s), 1.10 (3H, d, J = 6.8 Hz), 1.16−1.26 (1H, m), 1.32−
1.53 (4H, m), 1.57−1.76 (2H, m), 1.98−2.03 (1H, m), 3.22−3.25
366
dx.doi.org/10.1021/jo201951s | J. Org. Chem. 2012, 77, 357−370

The Journal of Organic Chemistry
Article
of α,β-unsaturated imide in THF (1.2 mL) was added to the mixture.
The mixture was warmed to 0 °C, stirred for 1 h, quenched with
saturated NaHCO3, extracted with AcOEt (×3), washed with brine,
dried over Na2SO4, filtered, and concentrated in vacuo. The residue
was purified by silica gel column chromatography (AcOEt/hexane =
20:80) to give imide 43 (64.4 mg, 58%) as an inseparable mixture.
(3R,4S,6R)-8-((R)-N,2-Dimethylbutanamido)-3,4,6-trimethyl-
N-((R)-1-(tritylthio)but-3-en-2-yl)octanamide (S-6). To a solu-
tion of imide 43 (41.2 mg, 0.0927 mmol) in THF/H2O (0.4 mL, 4: 1)
were added 30% H2O2 (37 μL) and 0.5 M LiOH (0.3 mL) at room
temperature. The mixture was stirred for 12 h, 1 N NaOH was added,
and the mixture was washed with AcOEt. The aqueous layer was
acidified with 1 N HCl, extracted with AcOEt (×3), washed with
brine, dried over Na2SO4, filtered, and concentrated in vacuo. The
crude carboxylic acid was employed directly in the next reaction.
To a solution of amine 10 (10.3 mg, 0.0300 mmol) and crude caro-
boxlic acid in CH2Cl2 (1.0 mL) were added EDCI (6.0 mg, 0.0300
mmol) and DMAP (0.2 mg, 2.0 μmol) at room temperature under Ar
atmosphere. The mixture was stirred for 5 h, quenched with 1 N HCl,
extracted with AcOEt (×3), washed with brine, dried over Na2SO4,
filtered, and concentrated in vacuo. The residue was purified by silica
gel column chromatography (AcOEt/hexane = 30:70) to give amide
36.1, 35.4, 26.9, 19.3, 16.4; IR (neat) 3408, 3052, 2970, 2918, 2848,
1695, 1593, 1491, 1441, 1421, 1366, 1210, 1163, 1143, 743, 699; MS
FAB-MS m/z 419 (M+ + Na); high-resolution EI-MS m/z 419.2017
(M+, calcd for C24H32O3SiNa 419.2018).
(S)-((6-Azido-2-methylhexyl)oxy)(tert-butyl)diphenylsilane
(S-7). To a solution of α,β-unsaturated ester 44 (375 mg, 0.946 mmol)
in EtOAc (5.0 mL) was added Pd−C (37.5 mg) at room temperature.
The mixture was stirred for 17 h under H2 atmosphere, fitered through
a Celite pad, and concentrated in vacuo. The crude reductant was
employed directly in the next reaction.
To a solution of crude reductant in CH2Cl2 (5.0 mL) was added
DIBAL (0.99 M in toluene, 2.38 mL, 2.36 mmol) at 0 °C under Ar
atmosphere. The mixture was stirred for 15 min, quenched with 1 N
HCl, extracted with AcOEt (×3), washed with brine, dried over
Na2SO4, filtered, and concentrated in vacuo. he crude alcohol was
employed directly in the next reaction.
To a solution of crude alcohol in CH2Cl2 (5.0 mL) were added
Et3N (263 μL, 1.89 mmol) and MsCl (109 μL, 1.42 mmol) at room
temperature under Ar atmosphere. The mixture was stirred for 1 h,
quenched with saturated NaHCO3, extracted with AcOEt (×3), washed
with brine, dried over Na2SO4, filtered, and concentrated in vacuo. The
crude mesylate was employed directly in the next reaction.
To a solution of crude mesylate in DMF (5.0 mL) was added NaN3
(184 mg, 2.83 mmol) at room temperature. The mixture was heated to
40 °C for 15 h, quenched with saturated NaHCO3, extracted with
AcOEt (×3), washed with brine, dried over Na2SO4, filtered, and
concentrated in vacuo. The residue was purified by silica gel column
chromatography (AcOEt/hexane = 10:90) to give azide S-7 (350 mg,
0.886 mmol, 93%) as a colorless oil: [α]23D −1.65 (c 1.19, CHCl3); 1H
NMR (CDCl3) δ 0.91 (3H, d, J = 6.6 Hz), 1.05 (9H, s), 1.08−1.17
(2H, m), 1.28−1.41 (2H, m), 1.42−1. 54 (2H, m), 1.62−1.67 (1H,
m), 3.23 (2H, d, J = 7.1 Hz), 3.43−3.51 (2H, m), 7.35−7.44 (6H, m),
7.64−7.66 (4H, m); 13C NMR (CDCl3) δ 135.5, 133.9, 129.4, 127.5,
68.7, 51.5, 35.6, 32.7, 29.2, 27.0, 24.2, 19.4, 16.8; IR (neat) 3064, 3012,
2926, 2852, 2092, 1468, 1425, 1387, 1359, 1188, 1109, 1008, 822, 738,
702; MS FAB-MS m/z 396 (M+ + H); high-resolution FAB-MS m/z
396.2478 (M+ + H, calcd for C23H34N3OSi 396.2471).
(R)-N-((S)-6-((tert-Butyldiphenylsilyl)oxy)-5-methylhexyl)-2-
methylbutanamide (48). To a solution of azide S-7 (1.15 g, 2.90
mmol) in THF (29 mL) were added H2O (261 μL) and PPh3 (1.90 g,
7.24 mmol) at room temperature. The mixture was heated to 40 °C
for 12 h, cooled to room temperature, dried over Na2SO4, filtered, and
concentrated in vacuo. The crude amine 47 was employed directly in
the next reaction.
S-6 (9.9 mg, 0.0265 mmol, 79%) as a pale oil: [α]24 +12.6 (c 1.43,
D
1
CHCl3); H NMR (CDCl3) δ 0.75−0.89 (12H, m), 1.05−1.09 (3H,
m), 1.25−1.83 (9H, m), 1.93−2.04 (1H, m), 2.13−2.22 (1H, m),
2.33−2.41 (1H, m), 2.45−2.60 (2H, m), 2.92, 2.99 (total 3H, each s),
3.24−3.45 (2H, m), 4.55 (1H, s), 5.05−5.09 (2H, m), 5.40, 5.89 (total
1H, each d, J = 7.5 Hz), 5.62−5.71 (1H, m), 7.21−7.44 (15H, m); 13C
NMR (CDCl3) δ 176.3, 176.0, 172.1, 171.8, 144.5, 136.8, 129.5, 127.9,
126.7, 115.5, 66.7, 50.1, 48.0, 45.7, 41.3, 40.6, 40.1, 39.8, 37.4, 37.2,
36.6, 36.5, 35.5, 35.2, 34.9, 34.8, 34.6, 34.4, 33.7, 28.4, 27.5, 27.1, 20.8,
20.4, 17.8, 17.3, 17.2, 16.8, 16.2, 12.2, 12.1.; IR (neat) 3284, 3052,
2954, 2918, 2866, 1625, 1535, 1487, 1442, 1413, 1378, 1296, 1081,
1034, 988, 923, 700; MS EI-MS m/z 626 (M+); high-resolution EI-MS
m/z 626.3904 (M+, calcd for C40H54N2O2S 626.3900).
(R)-N,2-Dimethyl-N-((3R,5S,6R)-3,5,6-trimethyl-7-((R)-4-vinyl-
4,5-dihydrothiazol-2-yl)heptyl)butanamide (5). To a solution of
amide S-6 (9.9 mg, 0.0159 mmol) in CH2Cl2 (0.3 mL) was added
TiCl4 (4.9 μL, 0.0450 mmol) at room temperature under Ar atmo-
sphere. The mixture was stirred for 12 h, quenched with saturated
Rochelle salt, stirred for 1 h, extracted with AcOEt (×3), washed with
brine, dried over Na2SO4, filtered, and concentrated in vacuo. The
residue was purified by silica gel column chromatography (AcOEt/
hexane = 30:70) to give 10-epi-kalkitoxin 5 (2.2 mg, 0.0060 mmol,
37%) as a colorless oil: [α]24 +12.6 (c 1.43, CHCl3); 1H NMR
To a solution of crude amine 47 and caroboxlic acid 12 (355 mg,
3.48 mmol) in CH2Cl2 (14.5 mL) were added Et3N (610 μL, 4.35 mmol)
and (EtO)2POCN (530 μL, 3.48 mmol) at room temperature under
Ar atmosphere. The mixture was stirred for 2.5 h, quenched with
saturated NaHCO3, extracted with AcOEt (×3), washed with brine,
dried over Na2SO4, filtered, and concentrated in vacuo. The residue
was purified by silica gel column chromatography (AcOEt/hexane =
D
(benzene-d6) δ 0.78−0.85 (3H, m), 0.92−1.02 (12H, m), 1.13−1.63
(7H, m), 1.97 (1H, m), 1.87−2.05 (1H, m), 2.13 (1H, br), 2.31−2.39
(2H, m), 2.45−2.57 (1H, m), 2.50, 2.90 (total 3H, each s), 2.73−2.80
(1H, m), 2.96−3.02 (2H, m), 3.20−3.27, 3.57−3.64 (total 1H, each
m), 4.77−4.84 (1H, m), 5.09 (1H, d, J = 7.8 Hz), 5.31 (1H, d, J = 17.3
Hz), 5.82−5.94 (1H, m); 13C NMR (benzene-d6) δ 176.2, 175.9,
170.9, 170.5, 139.2, 139.0, 116.3, 116.1, 80.2, 48.8, 46.8, 42.0, 41.8,
39.8, 38.9, 38.8, 38.6, 38.5, 37.5, 37.4, 36.8, 35.8, 35.6, 34.6, 31.2, 29.6,
29.0, 28.6, 21.8, 21.6, 19.3, 18.6, 17.8, 17.7, 17.6, 13.5, 13.3; IR (neat)
2952, 2918, 2866, 1639, 1461, 1409, 1377, 1262, 1197, 1080, 923; MS
FAB-MS m/z 367 (M+ + H); high-resolution FAB-MS m/z 367.2763
(M+ + H, calcd for C21H39N2OS 367.2783).
(S,E)-Methyl 6-((tert-Butyldiphenylsilyl)oxy)-5-methylhex-2-
enoate (44). To a solution of aldehyde 16 (994 mg, 2.94 mmol)
in CH2Cl2 (20 mL) was added (methoxycarbonylmethylene)-triphenyl-
phosphorane (1.18 g, 3.52 mmol) at room temperature under Ar
atmosphere. The mixture was stirred for 17 h, and concentrated in
vacuo. The residue was purified by silica gel column chromatography
10:90) to give amide 48 (1.09 g, 2.40 mmol, 83%) as a colorless oil:
1
[α]23 −3.4 (c 1.18, CHCl3); H NMR (CDCl3) δ 0.87−0.91 (6H,
D
m), 1.05 (9H, s), 1.12 (3H, d, J = 7.1 Hz), 1.23−1.68 (9H, m), 2.01−
2.06 (1H, m), 3.19−3.25 (2H, m), 3.41−3.51 (2H, m), 5.34 (1H, brs),
7.35−7.43 (6H, m), 7.64−7.65 (4H, m); 13C NMR (CDCl3) δ 176.1,
135.5, 134.0, 129.4, 127.5, 68.8, 43.4, 39.3, 35.7, 32.9, 30.1, 27.4, 26.9,
24.3, 19.4, 17.6, 16.9, 12.0; IR (neat) 3290, 3064, 2954, 2924, 2852,
2090, 1640, 1549, 1459, 1425, 1385, 1263, 1234, 1109, 1008, 823, 739,
702; MS ESI-MS m/z 476 (M+ + Na); high-resolution ESI-MS m/z
476.2945 (M+ + Na, calcd for C28H43NO2SiNa 476.2961).
(R)-N-((S)-6-((tert-Butyldiphenylsilyl)oxy)-5-methylhexyl)-
N,2-dimethylbutanamide (S-8). To a solution of amide 48 (1.06 g,
2.34 mmol) in THF (23.4 mL) were added n-BuLi (2.63 M in hexanes,
1.60 mL, 4.21 mmol) and MeI (583 μL, 9.36 mmol) at −78 °C under
Ar atmosphere. The mixture was stirred for 10 min at −78 °C, warmed
to room temperature, stirred for 1 h, quenched with saturated
NaHCO3, extracted with AcOEt (×3), washed with brine, dried over
Na2SO4, filtered, and concentrated in vacuo. The residue was purified
by silica gel column chromatography (AcOEt/hexane = 20:80) to give
(AcOEt/hexane = 5:95) to give α,β-unsaturated ester 44 (1.03 g,
1
2.59 mmol, 88%) as a colorless oil: [α]24 −4.7 (c 1.36, CHCl3); H
D
NMR (CDCl3) δ 0.90 (3H, d, J = 6.8 Hz), 1.06 (9H, s), 1.80−1.88
(12, m), 2.01−2.09 (1H, m), 2.40−2.47 (1H, m), 3.43−3.54 (2H, m),
3.73 (3H, s), 5.82 (1H, dt, J = 15.6, 1.4 Hz), 6.94 (1H, dt, J = 15.6,
7.5 Hz), 7.35−7.43 (6H, m), 7.64 (4H, dd, J = 7.3, 0.7 Hz); 13C NMR
(CDCl3) δ 166.8, 148.1, 135.3, 133.6, 129.5, 127.5, 122.0, 68.1, 51.3,
367
dx.doi.org/10.1021/jo201951s | J. Org. Chem. 2012, 77, 357−370

The Journal of Organic Chemistry
Article
N-methyl amide S-8 (990 mg, 2.05 mmol, 88%) as a colorless oil:
3.01 (total 3H, each s), 3.26−3.31 (1.5H, m), 3.42−3.52 (0.5H, m);
13C NMR (CDCl3) δ 178.4, 178.0, 176.8, 176.6, 49.9, 47.9, 47.4, 37.7,
[α]23 −11.4 (c 1.06, CHCl3); 1H NMR (CDCl3) δ 0.84−0.92
D
(6H, m), 1.05, 1.06 (total 9H, each s), 1.07−1.10 (3H, m), 1.21−1.70
(9H, m), 2.54−2.59 (1H, m), 2.91, 2.99 (total 3H, each s), 3.23−3.27
(2H, m), 3.40−3.51 (2H, m), 7.35−7.43 (6H, m), 7.64−7.66 (4H, m);
13C NMR (CDCl3) δ 176.4, 176.0, 135.5, 134.0, 133.9, 129.5, 129.4,
127.5, 68.9, 68.7, 49.8, 47.8, 37.4, 37.1, 35.8, 35.7, 35.3, 33.7, 33.0,
32.9, 29.4, 27.6, 27.5, 27.1, 26.9, 24.3, 24.2, 19.4, 17.9, 17.2, 16.8, 12.2,
12.1; IR (neat) 3064, 2954, 2924, 2852, 1642, 1462, 1425, 1408, 1259,
1191, 1110, 1008, 822, 740, 703; MS ESI-MS m/z 490 (M+ + Na);
high-resolution FAB-MS m/z 490.3113 (M+ + Na, calcd for C29H45-
NO2SiNa 490.3117).
37.5, 37.2, 37.1, 36.4, 35.3, 34.2, 34.1, 33.8, 33.7, 32.9, 29.3, 27.4, 26.9,
24.7, 24.5, 17.7, 17.0, 16.9, 16.1, 16.0, 14.6, 14.5, 12.1, 12.0; IR (neat)
2963, 2932, 2874, 1726, 1610, 1460, 1404, 1378, 1269, 1186, 1082,
875; MS ESI-MS m/z 308 (M + Na+); high-resolution ESI-MS m/z
308.2193 (M+ + Na, calcd for C16H31NO3Na 308.2196).
(3R,4S)-8-((R)-N,2-Dimethylbutanamido)-3,4-dimethyl-N-
((R)-1-(tritylthio)but-3-en-2-yl)octanamide (S-10). To a solution
of amine 10 (34.9 mg, 0.0950 mmol) and crude caroboxlic acid S-9
(18.9 mg, 0.0630 mmol) in CH2Cl2 (1.0 mL) were added EDCI
(18.2 mg, 0.0950 mmol) and DMAP (0.7 mg, 5.8 μmol) at room
temperature under Ar atmosphere. The mixture was stirred for 5 h,
quenched with 1 N HCl, extracted with AcOEt (×3), washed with
brine, dried over Na2SO4, filtered, and concentrated in vacuo. The
residue was purified by silica gel column chromatography (AcOEt/
hexane = 30:70) to give amide S-10 (34.9 mg, 0.0568 mmol, 90%) as a
pale oil: [α]24D +15.7 (c 0.76, CHCl3); 1H NMR (CDCl3) δ 0.86−0.94
(9H, m), 1.09−1.11 (3H, m), 1.41−2.00 (10H, m), 2.30 −2.54 (5H,
m), 2.92, 3.03 (total 3H, each s), 3.27−3.47 (2H, m), 4.54 (1H, m),
5.06−5.10 (2H, m), 5.39−5.41 (1H, m), 5.61−5.68 (1H, m), 7.20−
7.74 (15H, m); 13C NMR (CDCl3) δ 176.4, 176.1, 172.0, 171.8, 144.5,
144.4, 136.75, 136.72, 129.4, 127.8, 126.7, 126.6, 115.5, 66.7, 49.95,
49.90, 47.78, 47.69, 42.4, 42.3, 40.6, 40.4, 37.5, 37.4, 37.3, 37.1, 36.7,
36.6, 35.3, 35.1, 34.9, 34.5, 34.3, 34.2, 33.7, 33.2, 32.6, 29.7, 29.4, 27.4,
27.1, 24.8, 24.7, 17.8, 17.2, 16.9, 16.5, 16.3, 16.1, 14.8, 14.6, 14.5, 14.3,
12.1, 12.0; IR (neat) 3284, 3052, 2954, 2918, 2866, 1625, 1535, 1487,
1442, 1413, 1378, 1296, 1081, 1034, 988, 923, 700; MS EI-MS m/z
613 (M+); high-resolution EI-MS m/z 613.3815 (M+, calcd for C39-
H53N2O2S 613.3828).
(R)-N-((S)-6-Hydroxy-5-methylhexyl)-N,2-dimethylbuta-
namide (49). To a solution of N-methyl amide S-8 (960 mg,
2.05 mmol) in THF (10.3 mL) was added TBAF (1 M in THF,
2.67 mL, 2.67 mmol) at room temperature. The mixture was stirred
for 2 h, quenched with saturated NH4Cl, extracted with AcOEt (×3),
washed with brine, dried over Na2SO4, filtered, and concentrated in
vacuo. The residue was purified by silica gel column chromatography
(AcOEt/hexane = 20:80) to give alcohol 49 (418 mg, 1.82 mmol,
89%) as a pale oil: [α]23D −30.5 ( c 1.20, CHCl3); 1 H NMR (CDCl 3)
δ 0.86−0.93 (6H, m), 1.08−1.11 (3H, m), 1.14−1.73 (10H, m), 2.55−
2.64 (1H, m), 2.92, 3.01 (total 3H, each s), 3.28−3.31 (3H, t, J =
13
7.6 Hz), 3.38−3.52 (3H, m); C NMR (CDCl ) δ 176.5, 176.4,
3
67.7, 68.4, 49.8, 47.2, 37.4, 37.0, 35.6, 35.5, 35.1, 33.6, 32.9, 32.3, 29.2,
27.3, 27.2, 27.0, 24.2, 23.5, 17.7, 17.1, 16.6, 16.5, 12.0, 11.9; IR (neat)
3404, 2958, 2922, 2866, 1625, 1462, 1413, 1377, 1259, 1131, 1082;
MS EI-MS m/z 229 (M+); high-resolution EI-MS m/z 229.2040
(M+, calcd for C13H27NO2 229.2042).
(R)-N,2-Dimethyl-N-((S,E)-5-methyl-8-oxo-8-((R)-2-oxo-4-
phenyloxazolidin-3-yl)oct-6-en-1-yl)butanamide (50). To a
solution of (COCl)2 (148 μL, 1.70 mmol) in CH2Cl2 (1.2 mL) was
added DMSO (161 μL, 2.27 mL) at −78 °C under Ar atmosphere.
After 15 min, a solution of alcohol 49 (130 mg, 0.567 mmol) in
CH2Cl2 (1.2 mL) was added to the mixture. After an additional
45 min, Et3N (396 μL, 2.84 mmol) was added to the mixture. The
mixture was warmed to room temperature, stirred for 1 h, quenched
with saturated NH4Cl, extracted with CH2Cl2 (×3), washed with
brine, dried over Na2SO4, filtered, and concentrated in vacuo. The
crude aldehyde was employed directly in the next reaction.
(R)-N-((5S,6R)-5,6-Dimethyl-7-((R)-4-vinyl-4,5-dihydrothiazol-
2-yl)heptyl)-N,2-dimethylbutanamide (6). To a solution of
amide S-10 (15.2 mg, 0.0258 mmol) in CH2Cl2 (0.3 mL) was added
TiCl4 (8.5 μL, 0.0774 mmol) at room temperature under Ar atmo-
sphere. The mixture was stirred for 12 h, quenched with saturated
Rochelle salt, stirred for 1 h, extracted with AcOEt (×3), washed with
brine, dried over Na2SO4, filtered, and concentrated in vacuo. The
residue was purified by silica gel column chromatography (AcOEt/
hexane = 30:70) to give 10-nor-kalkitoxin 6 (5.4 mg, 0.0152 mmol,
59%) as a colorless oil: [α]24 +16.6 (c 0.54, CHCl3); 1H NMR
D
To a solution of phosphonate 17 (290 mg, 0.851 mmol) in THF
(2.8 mL) was added NaHMDS (0.99 M in THF, 860 μL, 0.851 mmol)
at 0 °C under Ar atmosphere. After 30 min, a solution of crude
aldehyde in THF (2.8 mL) was added to the mixture. The mixture was
warmed to room temperature, stirred for 12 h, quenched with
saturated NaHCO3, extracted with AcOEt (×3), washed with brine,
dried over Na2SO4, filtered, and concentrated in vacuo. The residue
was purified by silica gel column chromatography (AcOEt/hexane =
20:80) to give α,β-unsaturated imide 50 (154 mg, 0.371 mmol, 65%)
as an inseparable mixture:
(3R,4S)-8-((R)-N,2-Dimethylbutanamido)-3,4-dimethylocta-
noic Acid (S-9). To a solution of CuBr·Me2S complex (81.5 mg,
0.395 mmol) in THF (1.0 mL) was added dropwise MeMgBr (1.08 M
in THF, 587 μL, 0.632 mmol) at −78 °C under Ar atmosphere. After
20 min, a solution of α,β-unsaturated imide 50 (65.7 mg as an
inseparable mixture, theoretical 0.158 mmol) in THF (1.0 mL) was
added to the mixture. The mixture was warmed to −40 °C, stirred for
1 h, quenched with saturated NaHCO3, extracted with AcOEt (×3),
washed with brine, dried over Na2SO4, filtered, and concentrated
in vacuo. The crude imide was employed directly in the next reaction.
To a solution of crude imide in THF/H2O (1.5 mL, 4:1) were
added 30% H2O2 (100 μL) and 0.5 M LiOH (1.0 mL) at room
temperature. The mixture was stirred for 12 h, 1 N NaOH was added,
and the mixture was washed with AcOEt. The aqueous layer was
acidified with 1 N HCl, extracted with AcOEt (×3), washed with
brine, dried over Na2SO4, filtered, and concentrated in vacuo to give
(benzene-d6) δ 0.76−0.80 (3H, m), 0.88−1.00 (6H, m), 1.14, 1.19
(total 3H, each d, J = 6.6 Hz), 1.23−1.48 (7H, m), 1.88−2.02
(1H, m), 2.07−2.15 (1H, m), 2.30 (3H, m), 2.52−2.58 (1H, m), 2.73−
2.78 (1H, dd, J = 10.8, 8.0 Hz), 2.86−2.91 (1H, m), 2.98 (1H, dd, J =
10.8, 8.7 Hz), 2.46, 2.84 (total 3H, each s), 3.24−3.47 (1H, m), 4.76−
4.84 (1H, m), 5.04 (1H, d, J = 10.2 Hz), 5.27 (1H, d, J = 17.3 Hz),
5.84−5.92 (1H, m); 13C NMR (benzene-d6) δ 175.2, 175.0, 169.9,
169.6, 138.2, 138.1, 115.2, 115.1, 79.17, 79.13, 49.5, 47.7, 40.1, 38.8,
38.4, 38.3, 37.6, 37.4, 37.0, 36.9, 36.6, 36.1, 35.9, 34.8, 34.7,
33.5, 32.99, 32.93, 29.6, 29.5, 28.0, 27.6, 25.2, 25.1, 18.4, 17.7, 16.8,
16.7, 16.5, 16.4, 14.6, 14.4, 12.5, 12.4; IR (neat) 2952, 2918, 2866, 1639,
1461, 1409, 1377, 1262, 1197, 1080, 923; MS FAB-MS m/z 353 (M+ +
H); high-resolution FAB-MS m/z 353.2639 (M+ + H, calcd for
C20H37N2OS 353.2627).
(R)-N-((3S,5S)-6-Hydroxy-3,5-dimethylhexyl)-2-methylbuta-
namide (52). To a solution of amide 21 (673 mg, 1.44 mmol) in
THF (7.2 mL) was added TBAF (1 M in THF, 1.87 mL, 1.87 mmol)
at room temperature. The mixture was stirred for 2 h, quenched with
saturated NH4Cl, extracted with AcOEt (×3), washed with brine, dried
over Na2SO4, filtered, and concentrated in vacuo. The residue was purified
by silica gel column chromatography (AcOEt/hexane = 20:80) to give
alcohol 52 (285 mg, 1.24 mmol, 86%) as a colorless oil: [α]23 −23.0
D
(c 0.920, CHCl3); 1H NMR (CDCl3) δ 0.88−0.94 (9H, m), 1.13 (3H,
d, J = 6.8 Hz), 1.18−1.46 (3H, m), 1.32−1.52 (2H, m), 1.59−1.75
(2H, m), 2.07−2.09 (2H, m), 3.17−3.37 (2H, m), 3.40−3.49 (2H, m),
5.39 (1H, brs); 13C NMR (CDCl3) δ 176.3, 68.8, 43.3, 40.5, 37.7, 37.4,
33.1, 27.8, 27.4, 19.4, 17.6, 16.4, 12.0; IR (neat) 3404, 2958, 2922,
2866, 1625, 1462, 1413, 1377, 1259, 1131, 1082; MS EI-MS m/z 229
(M+); high-resolution EI-MS m/z 229.2037 (M+, calcd for C13H27NO2
229.2042).
pure carboxylic acid S-9 (28.4 mg, 0.0998 mmol, 63%) as a colorless
1
oil: [α]25 −18.1 (c 1.03, CHCl3); H NMR (CDCl3) δ 0.77−0.94
D
(9H, m), 1.07−1.10 (3H, m), 1.15−1.54 (8H, m), 1.62−1.73 (1H, m),
1.98−2.20 (2H, m), 2.30−2.42 (1H, m), 2.54−2.62 (1H, m), 2.92,
368
dx.doi.org/10.1021/jo201951s | J. Org. Chem. 2012, 77, 357−370

The Journal of Organic Chemistry
Article
(R)-N-((3S,5S,E)-3,5-Dimethyl-8-oxo-8-((R)-2-oxo-4-phenyl-
oxazolidin-3-yl)oct-6-en-1-yl)-2-methylbutanamide (53). To a
solution of (COCl)2 (114 μL, 1.31 mmol) in CH2Cl2 (0.8 mL) was
added DMSO (124 μL, 1.75 mL) at −78 °C under Ar atmosphere.
After 15 min, a solution of alcohol 52 (100 mg, 0.438 mmol) in
CH2Cl2 (0.8 mL) was added to the mixture. After an additional
45 min, Et3N (306 μL, 2.19 mmol) was added to the mixture. The
mixture was warmed to room temperature, stirred for 1 h, quenched
with saturated NH4Cl, extracted with CH2Cl2 (×3), washed with
brine, dried over Na2SO4, filtered, and concentrated in vacuo. The
crude aldehyde was employed directly in the next reaction.
To a solution of phosphonate 17 (224 mg, 0.657 mmol) in THF
(2.2 mL) was added NaHMDS (0.99 M in THF, 620 μL, 0.657 mmol)
at 0 °C under Ar atmosphere. After 30 min, a solution of crude
aldehyde in THF (2.2 mL) was added to the mixture. The mixture was
warmed to room temperature, stirred for 12 h, quenched with
saturated NaHCO3, extracted with AcOEt (×3), washed with brine,
dried over Na2SO4, filtered, and concentrated in vacuo. The residue
was purified by silica gel column chromatography (AcOEt/hexane =
20:80) to give α,β-unsaturated imide 53 (77.3 mg, 0.186 mmol, 42%)
as an inseparable mixture:
(3R,4S,6S)-3,4,6-Trimethyl-8-((R)-2-methylbutanamido)-
octanoic Acid (S-11). To a solution of CuBr·Me2S complex (96.0 mg,
0.465 mmol) in THF (0.9 mL) was added dropwise MeMgBr (1.06 M
in THF, 737 μL, 0.781 mmol) at −78 °C under Ar atmosphere.
After 20 min, a solution of α,β-unsaturated imide 53 (77.3 mg as an
inseparable mixture, theoretical 0.186 mmol) in THF (0.9 mL) was
added to the mixture. The mixture was warmed to −40 °C, stirred
for 1 h, quenched with saturated NaHCO3, extracted with AcOEt
(×3), washed with brine, dried over Na2SO4, filtered, and concentrated
in vacuo. The crude imide 54 was employed directly in the next
reaction.
To a solution of crude imide 54 in THF/H2O (0.3 mL, 4: 1) was
added 30% H2O2 (29 μL) and 0.5 M LiOH (0.3 mL) at room
temperature. The mixture was stirred for 12 h, 1 N NaOH was added,
and the mixture was washed with AcOEt. The aqueous layer was
acidified with 1 N HCl, extracted with AcOEt (×3), washed with
brine, dried over Na2SO4, filtered, and concentrated in vacuo to give
(R)-2-Methyl-N-((3S,5S,6R)-3,5,6-trimethyl-7-((R)-4-vinyl-4,5-
dihydrothiazol-2-yl)heptyl)butanamide (7). To a solution of
amide S-12 (9.5 mg, 0.0150 mmol) in CH2Cl2 (0.3 mL) was added
TiCl4 (5.0 μL, 0.0450 mmol) at room temperature under Ar atmo-
sphere. The mixture was stirred for 12 h, quenched with saturated
Rochelle salt, stirred for 1 h, extracted with AcOEt (×3), washed with
brine, dried over Na2SO4, filtered, and concentrated in vacuo. The
residue was purified by silica gel column chromatography (AcOEt/
hexane = 30:70) to give 16-nor-kalkitoxin 7 (4.0 mg, 0.0113 mmol,
75%) as a colorless oil: [α]23D +6.2 (c 0.120, CHCl3)1H NMR (benzene-
d6) δ 0.75 (3H, d, J = 6.8 Hz), 0.78 (3H, d, J = 6.6 Hz), 0.86 (3H, t, J =
7.3 Hz), 0.94 (3H, d, J = 6.8 Hz), 1.09 (3H, d, J = 6.5 Hz), 1.23- 1.78
(7H, m),, 2.03−2.13 (2H, m), 2.33 (1H, dd, J = 14.8, 8.8 Hz), 2.52
(1H, dd, J = 14.8, 5.4 Hz), 2.71 (1H, dd, J = 10.7, 8.2 Hz), 2.93 (1H,
dd, J = 10.7, 8.8 Hz), 3.07−3.24 (2H, m), 4.29−4.33 (1H, m), 4.58
(1H, br), 4.73−4.76 (1H, m), 5.01 (1H, d, J = 10.2 Hz), 5.24 (1H, d,
J = 17.1 Hz), 5.94 (1H, ddd, J = 17.1, 10.2, 6.3 Hz); 13C NMR
(benzene-d6) δ 175.8, 171.0, 139.0, 116.3, 80.2, 51.7, 44.4, 41.3, 39.9,
39.7, 39.5, 35.4, 31.4, 29.4, 28.9, 20.5, 19.2, 17.8, 17.5, 13.5; IR (neat)
3290, 2954, 2918, 2848, 1641, 1452, 1380, 1258, 1090, 1023, 798; MS
EI-MS m/z 352 (M+); high-resolution EI-MS m/z 352.2548 (M+,
calcd for C20H36N2OS 352.2548).
Brine Shrimp Toxicity Assay. We tested the toxicity of the CSLs
using a modified method.29 Ten hatched brine shrimp, in ∼4.95 mL of
seawater, were added to each well containing different concentrations
of the compounds in 50 μL of EtOH or 50% EtOH to make a total
volume of 5 mL. Samples and controls were tested in duplicate. The
numbers of live and dead brine shrimp were counted after 24 h at 25 °C.
ASSOCIATED CONTENT
■
S
* Supporting Information
1
Copies of H NMR and 13C NMR spectra. This material is
available free of charge via the Internet at http://pubs.acs.org.
AUTHOR INFORMATION
■
Corresponding Author
pure carboxylic acid S-11 (53.0 mg, 0.124 mmol, 67%) as a colorless
*E-mail: fmatsuda@ees.hokudai.ac.jp.
1
oil: [α]25 −23.0 (c 1.08, CHCl3); H NMR (CDCl3) δ 0.78−0.91
D
(12H, m), 1.07−1.10 (6H, m), 1.23−1.52 (5H, m), 1.57−1.66 (1H,
m), 1.90−1.98 (1H, m), 2.03−2.09 (1H, m), 2.33 (1H, dd, J = 14.7,
4.8 Hz), 3.20−3.35 (2H, m), 5.59 (1H, br); 13C NMR (CDCl3) δ
178.8, 176.6, 49.9, 43.2, 40.2, 38.0, 37.8, 37.4, 35.1 34.2, 19.0, 17.5,
16.6, 16.0, 14.5, 11.9; IR (neat) 3297, 2963, 2931, 2876, 1708, 1627,
1552, 1457, 1380, 1269, 1189, 1109, 891; MS ESI-MS m/z 308 (M +
Na+); high-resolution ESI-MS m/z 308.2195 (M+ + Na, calcd for
C16H31NO3Na 308.2196).
(3R,4S,6S)-3,4,6-Trimethyl-8-((R)-2-methylbutanamido)-N-
((R)-1-(tritylthio)but-3-en-2-yl)octanamide (S-12). To a solution
of amine 10 (34.2 mg, 0.0930 mmol) and crude caroboxlic acid
S-11 (17.8 mg, 0.0620 mmol) in CH2Cl2 (0.6 mL) were added EDCI
(17.8 mg, 0.0950 mmol) and DMAP (0.7 mg, 5.8 μmol) at room
temperature under Ar atmosphere. The mixture was stirred for 5 h,
quenched with 1 N HCl, extracted with AcOEt (×3), washed with
brine, dried over Na2SO4, filtered, and concentrated in vacuo. The
residue was purified by silica gel column chromatography (AcOEt/
ACKNOWLEDGMENTS
■
This work was financially supported by a research grant for
young scientists from the Global COE program “Establishment
of Center for Integrated Field Environmental Science”.
REFERENCES
■
(1) Wu, M.; Okino, T.; Nogle, L. M.; Marquez, B. L.; Williamson,
R. T.; Sitachitta, N.; Berman, R. W.; Murray, T. F.; McGough, K.;
Jacobs, R.; Colsen, K.; Asano, T.; Yokokawa, F.; Shioiri, T.; Gerwick,
W. H. J. Am. Chem. Soc. 2000, 122, 12041−12042.
(2) Yokokawa, F.; Asano, T.; Okino, T.; Gerwick, W. H.; Shioiri, T.
Tetrahedron 2004, 60, 6859−6880.
(3) Berman, R. W.; Gerwick, W. H.; Murray, T. F. Toxicon 1999, 37,
1645−1648.
(4) Lepage, K. T.; Goeger, D.; Yokokawa, F.; Asano, T.; Shioiri, T.;
Gerwick, W. H.; Murray, T. F. Toxicol. Lett. 2005, 158, 133−139.
hexane = 30:70) to give amide S-12 (25.7 mg, 0.0419 mmol, 68%) as a
1
pale oil: [α]23 +10.5 (c 0.270, CHCl3); H NMR (CDCl3) δ 0.79−
́
(5) (a) Nicolas, E.; Russell, K. C.; Hruby, V. J. J. Org. Chem. 1993, 58,
D
0.93 (12H, m), 1.11 (3H, d, J = 6.8 Hz), 1.28−1.76 (10H, m), 1.87
(1H, m), 1.90−1.97 (1H, m), 2.01−2.08 (1H, m), 2.16 (1H, dd, J =
13.7, 4.1 Hz), 2.37 (1H, dd, J = 12.3, 5.1 Hz), 2.49 (1H, dd, J = 12.3,
6.4), 3.20−3.35 (2H, m), 4.54 (1H, br), 5.07 (1H, d, J = 12.4 Hz),
5.40 (1H, d, J = 8.0 Hz), 5.65 (1H, ddd, J = 12.4, 8.0, 5.1 Hz), 7.12−
7.34 (15H, m); 13C NMR (CDCl3) δ 176.0, 171.7, 144.4, 136.6, 129.4,
127.8, 126.7, 115.5, 68.2, 50.0, 43.4, 40.8, 40.5, 37.9, 37.5, 36.6, 35.5,
34.4, 28.2, 27.5, 19.4, 17.7, 16.6, 16.4, 12.1; IR (neat) 3288, 3052,
2954, 2918, 2868, 1641, 1539, 1487, 1442, 1413, 1377, 1079, 1033,
989, 921, 700; MS ESI-MS m/z 635 (M+ + Na); high-resolution ESI-
MS m/z 635.3620 (M+ + Na, calcd for C39H52N2O2SNa 635.3647).
766−770. (b) Li, G.; Patel, D.; Hruby, V. J. Tetrahedron: Asymmetry
1993, 4, 2315−2319. (c) Li, G.; Jaroginski, M. A.; Hruby, V. J.
Tetrahedron Lett. 1993, 34, 2561−2564.
(6) For recent examples for diastereoselective 1,4-addition reaction
controlled by oxazolidinone, see: (a) Yamada, T.; Sakaguchi, K.;
Shinada, T.; Ohfune, Y.; Soloshonok, V. A. Tetrahedron: Asymmetry
2008, 19, 2789−2795. (b) Esumi, T.; Shimizu, H.; Kashiyama, A.;
Sasaki, C.; Yoyota, M.; Fukuyama, Y. Tetrahedron Lett. 2008, 49,
6846−6849. (c) Nakamura, S.; Kikuchi, F.; Hashimoto, S. Tetrahedron:
Asymmetry 2008, 19, 1059−1067. (d) Morita, M.; Ishiyama, S.;
Koshino, H.; Nakata, T. Org. Lett. 2008, 10, 1675−1678. (e) Wu, H.;
369
dx.doi.org/10.1021/jo201951s | J. Org. Chem. 2012, 77, 357−370

The Journal of Organic Chemistry
Article
Moeller, K. D. Org. Lett. 2007, 9, 4599−4602. (f) Davies, S. G.;
Roberts, P. M.; Smith, A. D. Org. Biomol. Chem. 2007, 5, 1405−1415.
(7) (a) White, J. D.; Lee, C. -S.; Xu, Q. Chem. Commun. 2003, 16,
2012−2013. (b) White, J. D.; Xu, Q.; Lee, C.; Valeriote, F. A. Org.
Biomol. Chem. 2004, 2, 2092−2102.
(8) (a) Williams, D. R.; Turske, R. A. Org. Lett. 2000, 2, 3217−3220.
(b) Williams, D. R.; Lowder, P. D.; Gu, Y. Tetrahedron Lett. 2000, 41,
9397−9401.
(9) (a) Qian, K.; Nagasawa-Goto, K.; Yu, D.; Morrus-Natschke, S. L.;
Nitz, T. J.; Kilgore, N.; Allaway, G. P.; Lee, K.-H. Bioorg. Med. Chem.
Lett. 2007, 17, 6553−6557. (b) Marshall, J. A.; Sedrani, R. J. Org. Chem.
1991, 56, 5496−5498.
(25) Ionita, P.; Volkov, A.; Jeschke, G.; Chechik, V. Anal. Chem.
2008, 80, 95−106.
(26) Although an amide that was synthesized from (−)-O-methyl
mandelic acid and 10 obtained through Wittig olefination was a
mixture of epimers (1.5−9:1), condensation between (−)-O-methyl
mandelic acid and 10 prepared via Pd(0)-catalyzed reduction gave the
corresponding amide as a single diastereomer; see Supporting Information.
(27) Raman, P.; Razavi, H.; Kelly, J. W. Org. Lett. 2000, 2, 3289−
3292.
(28) In 1,4-addition reactions of 42, 50, and 53, diastereomeric ratios
at C7 could not be estimated employing the same HPLC analysis
method as that for determination of isomeric ratios of addition
1
reactions to 11, 29, and 38; see ref 12. However, in H NMR spectra
(10) For the preparation of phosphonate 16, see refs 10a and 10b, for
ent-16, see ref 10c: (a) Rzasa, R. M.; Shea, H. A.; Romo, D. J. Am.
Chem. Soc. 1998, 120, 591−592. (b) Romo, D.; Rzasa, R. M.; Shea,
H. A.; Park, K.; Langenham, J. M.; Sun, L.; Akhiezer, A.; Liu, J. O.
J. Am. Chem. Soc. 1998, 120, 12237−12254. (c) Ishizaki, M.; Hara, Y.;
Kojima, S.; Hoshino, O. Heterocycles 1999, 50, 779−790.
(11) Willams, D. R.; Kissel, W. S.; Li, J. J.; Mullins, R. Tetraheron Lett.
2002, 43, 3723−3727.
of the carboxylic acids yielded through hydrolysis of the addition prod-
ucts 43, 51, and 54, peaks due to trace amounts of the corresponding
7-epi isomers only were observed. Therefore, it seems feasible that
these addition reactions occurred with high diastereoselectivity.
(29) Meyer, B. N.; Ferrigni, N. R.; Putnam, J. E.; Jacobsen, L. B.;
Nichols, D. E.; McLaughlin, J. L. Planta Med. 1982, 45, 31−34.
(12) In 1,4-addition reactions to 14 and 32, diastereomeric ratios
were determined from 1H NMR spectra and HPLC chromatograms of
1
the addition products 18 and 33. In contrast, H NMR spectra of the
adducts 23, 30, and 39 produced by 1,4-addition of 11, 29, and 38
were too complex due to the presence of rotamers with regard to the
amide moieties to estimate isomeric ratios. In these cases, diastereo-
meric ratios were determined by HPLC analysis of the corresponding
methyl esters derived from 23, 30, and 39; see Supporting Information.
(13) (a) David A., Kummer, D. A.; Brenneman, J. B.; Martin, S. F.
Tetrahedron 2006, 62, 11437−11449. (b) Smith, A. B. III; Cantin, L-D;
Pasternak, A.; Guise-Zawacki, L.; Yao, W.; Charnley, A. K.; Barbosa, J.;
Sprengeler, P. A.; Hirschmann, R.; Munshi, S.; Olsen, D. B.; Schleif,
W. A.; Kuo, L. C. J. Med. Chem. 2003, 46, 1831−1844.
(14) (a) Druais, V.; Hall, M. J.; Corsi, C.; Wendeborn, S. V.; Meyer,
C.; Cossy, J. Org. Lett. 2009, 11, 935−938. (b) Higuchi, K.; Sato, Y.;
Tsuchimochi, M.; Sugiura, K.; Hatori, M.; Kawasaki, T. Org. Lett.
2009, 11, 197−199.
̌
(15) (a) Solaja, B. A.; Opsenica, D.; Smith, K. S.; Milhous, W. K.;
Terzic, N.; Opsenica, I.; Burnett, J. C.; Nuss, J.; Gussio, R.; Bavari, S.
́
J. Med. Chem. 2008, 51, 4388−4391. (b) Fusz, S.; Srivatsan, S. G.;
Ackermann, D.; Famulok, M. J. Org. Chem. 2008, 73, 5069−5077.
(16) (a) Evans, D. A.; Ennis, M. D.; Mathre, D. J. J. Am. Chem. Soc.
1982, 104, 1737−1739. (b) Evans, D. A.; Chapman, K. T.; Hung,
D. T.; Kawaguchi, T. Angew. Chem., Int. Ed. Engl. 1987, 26, 1184−
1187. (c) Belelie, J. L.; Chong, J. M. J. Org. Chem. 2001, 66, 5552−
5555. (d) Guerlavais, V.; Carroll, P. J.; Joullie, M. M. Tetrahedron:
Asymmetry 2002, 13, 675−680.
(17) Takuma, S; Hamada, Y.; Shioiri, T. Chem. Pharm. Bull. 1982, 30,
3147−3153, and refereces therein.
(18) Kim, Y.; Shin, E.-K.; Beak, P.; Park, Y.-S. Synthesis 2006, 3805−
3808.
(19) We found that 1,4-addition reaction of 11 took place with high
stereoselectivity by using only THF as a solvent, although the
combination of THF and Me2S was employed as a solvent in the
1,4-addition of 11 during the total synthesis of 1 by Shioiri’s group;
see ref 1.
(20) Evans, D. A.; Britton, T. C.; Ellman, J. A. Tetrahedron Lett. 1987,
28, 6141−6144.
(21) Dose, C.; Seitz, O. Org. Lett. 2005, 7, 4365−4368.
(22) Moriwake, T.; Hamano, S.; Saito, S.; Torii, S. Chem. Lett. 1987,
2085−2088.
(23) (a) Katagiri, T.; Fujiwara, K.; Kawai, H.; Suzuki, T. Tetraheron
Lett. 2008, 49, 3242−3247. (b) Innitzer, A.; Brecker, L.; Mulzer, J. Org.
Lett. 2007, 9, 4431−4434.
(24) (a) Cesati, R. R. III; Armas, J.; Hoveyda, A. H. J. Am. Chem. Soc.
2004, 126, 96−101. (b) Choi, Y.; White, J. D. J. Org. Chem. 2004, 69,
3758−3764. (c) Yamamoto, K.; Heathcock, C. H. Org. Lett. 2000, 2,
1709−1712. (d) Oikawa, M.; Ueno, T.; Oikawa, H.; Ichihara, A. J. Org.
Chem. 1995, 60, 5048−5068.
370
dx.doi.org/10.1021/jo201951s | J. Org. Chem. 2012, 77, 357−370
