Organometallics
Article
31.4 (Caliphatic), 50.0 (Caliphatic), 116.9 (Caromatic), 122.0 (Caromatic),
122.7 (Caromatic), 123.4 (Caromatic), 125.8 (Caromatic), 126.1 (Caromatic),
126.4 (Caromatic), 127.3 (Caromatic), 127.4 (Caromatic), 128.3 (Caromatic),
129.9 (Caromatic), 131.5 (Caromatic), 134.5 (Caromatic), 137.3 (Caromatic),
138.7 (Caromatic), 139.2 (Caromatic), 140.0 (Caromatic), 140.5 (NCN).
4.4. Synthesis of 2b. To a solution of 1 (1.29 g, 5 mmol) in
acetonitrile (50 mL) was added MeI (1.41 g, 10 mmol). The reaction
mixture was refluxed for 24 h. After cooling to room temperature, the
precipitate was filtered and washed with CH3OH (20 mL). The
combined organic fractions were then evaporated under vacuum, and
the crude product was recrystallized from CH3OH/Et2O to give 2b
(1.88 g) as a yellow solid in 88% yield. Mp: 200.4−201.0 °C. Calcd
for C20H18IN3 (427.29 g/mol): C, 56.22; H, 4.25; N, 9.83. Found: C,
55.97; H, 4.17; N, 9.69. 1H NMR (300 MHz, DMSO-d, 298 K, ppm):
3.81 (s, 3H, CH3), 6.62−6.85 (dd, J = 8.2 Hz, 1.0 Hz, 1H, Harom),
7.04−7.09 (m, 2H, Harom), 7.35−7.44 (m, 2H, Harom), 7.50−7.55 (m,
3H, Harom), 7.66−7.69 (d, J = 9 Hz, 1H, Harom), 7.77−7.78 (t, J = 3
Hz, Harom), 7.92−8.09 (m, 4H, Harom), 9.56 (s, 1H, NH). 13C NMR
(75 MHz, DMSO-d, 298 K, ppm): 36.3 (Caliphatic), 118.7 (Caromatic),
119.8 (Caromatic), 120.9 (Caromatic), 124.1 (Caromatic), 124.3 (Caromatic),
126.2 (Caromatic), 126.5 (Caromatic), 126.7 (Caromatic), 128.7 (Caromatic),
131.8 (Caromatic), 134.6 (Caromatic), 138.3 (Caromatic), 138.6 (Caromatic),
141.6 (NCN).
concentrated n-pentane solution. Yield: 67 mg, 14%. Mp: 172.0−
172.5 °C. Calcd for C26H34CoN3P2 (509.50 g/mol): C, 61.30; H,
6.73; N, 8.25. Found: C, 61.51; H, 6.79; N, 8.11. IR (Nujol mull, KBr,
1
cm−1): 1920 ν(Co−H), 943 ρ(PCH3). H NMR (300 MHz, C6D6,
298 K, ppm): −22.14 (t, J = 69 Hz, 1H, CoH), 0.62 (t′, J = 6 Hz,
18H, PCH3), 3.16 (s, 3H, CH3), 6.20 (d, J = 3 Hz, 1H, Harom), 6.61−
6.66 (t, J = 6 Hz, 1H, Harom), 7.02−7.05 (dd, J = 9 Hz, 3 Hz, 1H,
H
arom), 7.09−7.15 (td, J = 6 Hz, 3 Hz, 2H, Harom), 7.37−7.40 (d, J = 9
Hz, 1H, Harom), 7.49−7.58 (m, 3H, Harom), 7.68−7.71 (m, 1H, Harom),
7.97−8.00 (d, J = 9 Hz, 1H, Harom), 8.92−8.95 (dd, J = 9 Hz, 1.1 Hz,
1H, Harom). 31P NMR (121 MHz, C6D6, 298 K, ppm): 17.82 (s,
PCH3). 13C NMR (75 MHz, C6D6, 298 K, ppm): 15.5 (t, JP,C
=
2
12.75, PCH3), 35.9 (Caliphatic), 110.1 (Caliphatic), 112.2 (Caliphatic), 113.9
(Caliphatic), 116.6 (Caliphatic), 116.9 (Caliphatic), 118.8 (Caliphatic), 119.5
(Caliphatic), 119.9 (Caliphatic), 124.3 (Caliphatic), 124.5 (Caliphatic), 124.6
(Caliphatic), 125.6 (Caliphatic), 133.9 (Caliphatic), 134.5 (Caliphatic), 145.0
(Caliphatic), 146.6 (Caliphatic), 158.4 (t, J = 1.7 Hz, NCN).
4.7. General Procedure for Cobalt-Catalyzed Hydrosilyla-
tion Reactions. Under a N2 atmosphere, 1 mol % cobalt hydride 3
was added to a 20 mL Schlenk tube containing a magnetic stirrer
without any solvent. Then, the alkene (1.00 mmol), n-dodecane (170
mg, 1.00 mmol), pyridine N-oxides (1 mol %, 0.9 mg, 0.01 mmol),
and Ph2SiH2 (1.2 equiv, 221 mg, 1.2 mmol) were added in order. The
reaction mixture was stirred at room temperature for 24 h. The
resulting solution was quenched with ethyl acetate. The combined
organic fractions were concentrated in vacuum, and the crude product
was purified by column chromatography on silica gel with petrol ether
as eluent. The pure product was characterized by NMR analysis.
4.8. X-ray Crystal Structure Determination. Intensity data
were collected on a Stoe Stadi Vari diffractometer with graphite-
monochromated Ga Kα radiation (λ = 0.71073 Å). The structure was
solved using the charge-flipping algorithm, as implemented in the
program SUPERFLIP,32 and refined by full-matrix least-squares
techniques against F2 (SHELXL)33 through the OLEX interface.34 All
non-hydrogen atoms were refined anisotropically, and all hydrogen
atoms except for those of the disordered solvent molecules were
placed using AFIX instructions. Appropriate restraints or constraints
were applied to the geometry and the atomic displacement parameters
contain the supplementary crystallographic data for this paper.
4.5. Synthesis of 3a and 4a. A 0.63 mL sample of n-BuLi (2.5 M
in hexane, 1.58 mmol) was added slowly to 30 mL of a THF solution
of ligand 2a (0.6080 g, 1.44 mmol) at −78 °C, and the solution
turned red. When the temperature returned to room temperature, the
mixture was stirred for 30 min. After that, a solution of CoMe(PMe3)4
(0.5451 g, 1.44 mmol) in THF (30 mL) was added slowly to the
resulting solution at −78 °C. The reaction mixture was allowed to stir
for 48 h at room temperature to provide a deep yellow solution. After
the reaction, the solvents were removed under vacuum, and the
residue was extracted with 100 mL of n-pentane and 50 mL of diethyl
ether, respectively. The dark-orange crystals of 4a were obtained at
−10 °C from the concentrated diethyl ether solutions. Yield: 289 mg,
27%. Mp: 189.8−190.3 °C. Calcd for C46H44CoN6 (739.83 g/mol):
C, 74.68; H, 5.99; N, 11.36. Found: C, 74.77; H, 5.80; N, 11.55. The
light yellow crystals of 3a were obtained at −20 °C from the
concentrated n-pentane solutions. Yield: 72 mg, 9%. Mp: 180.5−
181.1 °C. Calcd for C29H40CoN3P2 (551.54 g/mol): C, 63.15; H,
7.31; N, 7.62. Found: C, 62.89; H, 7.48; N, 7.74. IR (Nujol mull, KBr,
1
cm−1): 1904 ν(Co−H), 944 ρ(PCH3). H NMR (300 MHz, C6D6,
ASSOCIATED CONTENT
* Supporting Information
The Supporting Information is available free of charge at
■
298 K, ppm): −21.21 (t, J = 66 Hz, 1H, CoH), 0.65 (t′, J = 6 Hz,
18H, PCH3), 0.90 (t, J = 6 Hz, 3H, CH3), 1.20 (m, 2H, CH2), 1.46
(m, 2H, CH2), 3.87 (t, J = 6 Hz, 2H, CH2), 6.34 (d, J = 3 Hz, 1H,
sı
H
arom), 6.65 (t, J = 6 Hz, 1H, Harom), 6.99−7.17 (m, 3H, Harom),
7.38−7.40 (d, J = 6 Hz, 1H, Harom), 7.51−7.69 (m, 4H, Harom), 7.94−
X-ray crystallographic data and IR, NMR, and GC
7.97 (d, J = 9 Hz, 1H, Harom), 8.91−8.94 (d, J = 9 Hz, 1H, Harom). 31
P
NMR (121 MHz, C6D6, 298 K, ppm): 17.18 (s, PCH3). 13C NMR
2
Accession Codes
(75 MHz, C6D6, 298 K, ppm): 12.5 (Caliphatic), 15.4 (t, JP,C = 13.5,
supplementary crystallographic data for this paper. These
uk, or by contacting The Cambridge Crystallographic Data
Centre, 12 Union Road, Cambridge CB2 1EZ, UK; fax: +44
1223 336033.
PCH3), 18.8 (Caliphatic), 32.0 (Caliphatic), 48.9 (Caliphatic), 110.5
(Caromatic), 112.2 (Caromatic), 114.1 (Caromatic), 116.4 (Caromatic), 116.9
(Caromatic), 118.6 (Caromatic), 120.3 (Caromatic), 124.6 (Caromatic), 133.9
(Caromatic), 134.3 (Caromatic), 145.3 (Caromatic), 147.0 (Caromatic), 158.3
(NCN).
4.6. Synthesis of 3b and 4b. A 0.41 mL sample of n-BuLi (2.5
M in hexane, 1.03 mmol) was added slowly to 30 mL of a THF
solution of 2b (400 mg, 0.94 mmol) at −78 °C and the solution
turned red. When the temperature returned to room temperature, the
mixture was stirred for 30 min. After that, a solution of CoMe(PMe3)4
(0.356 g, 0.94 mmol) in THF (30 mL) was added slowly to the
resulting solution at −78 °C. The reaction mixture was allowed to stir
for 48 h at room temperature to provide a deep yellow solution. After
the reaction, the solvents were removed under vacuum, and the
residue was extracted with 100 mL of n-pentane and 50 mL diethyl
ether, respectively. The dark-orange crystals of 4b were obtained at
−10 °C from the concentrated diethyl ether solutions. Yield: 197 mg,
32%. Mp: 195.4−196.5 °C. Calcd for C40H32CoN6 (655.67 g/mol):
C, 73.27; H, 4.92; N, 12.82. Found: C, 73.36; H, 5.06; N, 12.67. The
light yellow crystals of 3b were obtained at −20 °C from the
AUTHOR INFORMATION
Corresponding Authors
■
Hongjian Sun − School of Chemistry and Chemical Engineering,
Key Laboratory of Special Functional Aggregated Materials,
Ministry of Education, Shandong University, Jinan, Shandong
Xiaoyan Li − School of Chemistry and Chemical Engineering,
Key Laboratory of Special Functional Aggregated Materials,
Ministry of Education, Shandong University, Jinan, Shandong
G
Organometallics XXXX, XXX, XXX−XXX
