indoles and furans with al-
kynes.[13] In the case of the
gold-catalysed reaction with al-
kynes and heteroarenes, the
Markovnikov product is observ-
ed,[13b] whereas in the case of
acceptor-substituted
allenes
a two-fold hydroarylation with
Markovnikov regioselectivity is
observed and in this case the
first addition is faster than the
second.[13c] However, to the best
of our knowledge, this is the
Scheme 3. Deuteration experiments.
first example of platinum-catalysed bisindolylation of al-
lenes.
was used as an additive (Scheme 3). The deuteration in the
platinum-catalysed dihydroalkoxylation of allenes was
shown to be greater than 98%. If acetals are intermediates
in the formation of the bisindoles, the deuterium from the
first dihydroalkoxylation should be retained because these
positions are not involved in the reaction to form the bisin-
doles, so the fact that the deuterium incorporation is low in
the final products rules out the hypothesis of acetals being
intermediates of the bisindolylation reaction.
The substitution on the indole and the allene were studied
by using the optimum conditions obtained under platinum
catalysis. Table 1 shows the bisindolylation process is general
under these conditions and it works well for unsubstituted
indoles, as well as N-alkyl and differently substituted indole
derivatives (see entries 1–6 and 8–10, Table 1).[15] The 2-
methyl-substituted indole 3 f gave the 3-allyl-indole 5af in
It was found that methanol is a key additive in this pro-
cess (an increased of yield from 23 to 62% was found in the
reaction of 1a with indole 3a when three equivalents of
MeOH were added).[6] At first sight, a straightforward ex-
planation for this observation would be a stepwise process
in which a previously reported Pt-catalysed dihydroalkoxyla-
tion reaction occurs,[6] followed by indolylation through
known simple pathways. However, it is important to note
that the reaction works without the addition of methanol,
albeit in lower yields; most likely methanol stabilises the
zwitterionic intermediates involved in the course of the re-
action or it could also take the role of a proton shuttle, as
reported for small water and water–alcohol clusters.[14] How-
ever, this possibility was excluded because of the results ob-
tained in the deuterium labelling experiments carried out
and detailed in the paragraph below. Besides, we have ob-
served that reaction of isolated dimethyl acetal 2a in the
presence of three equivalents of indole 3a under our Pt-cat-
51% yield, as well as the expected bisACTHNUTRGNEUNG(indolyl) derivative
4af (entry 5, Table 1). This derivative was also observed in
the reaction with 5-OH indole derivative 3i (entry 8,
Table 1), indicating a pronounced influence of the substitu-
ent on the reactivity. When the C3 position of the indole
alysed conditions, gives bisACTHNUTRGENUGN(indolyl) 4aa in 58% yield. The
reaction also works without a Pt catalyst, in THF at 708C,
but only 77% conversion was achieved after three days.
However, we have never observed the formation of acetal
2a during the Pt-catalysed reaction of 1a and 3a in the pres-
ence of MeOH, even at short reaction times (45 min, 2 or
4 h), which rules out the hypothesis of this being the main
reaction pathway under our reaction conditions.
The reaction using indole 3a and MeOD gave the corre-
sponding bisindole 4a with no deuterium incorporation in
any position. Moreover, deuteration studies were also per-
formed with C3-[D]indoles with and without MeOH/D. Al-
though the same deuteration pattern was observed in the
formation of products 4[D2] as for the Pt-catalysed dihy-
droalkoxylation of allenes (one deuterium added to the in-
ternal (more substituted) carbon from the 3 position of the
indole transferred in the first step to the internal carbon to
form the platinum-carbene intermediate key in the reaction,
and one deuterium incorporated in the central carbon of the
allene from the last step of protonolysis of the platinum
complex (see later, Scheme 7),[6] deuterium incorporation
was low in all the conditions tested and the excess of indole
3[D] left over in the reaction was recovered with partial or
total loss of deuterium in all the cases, even when MeOD
was blocked, the bisACTHNGUTERN(UNG indolyl) product from attack at C2 po-
sition was obtained (4ah, entry 7, Table 1). Pyrrole 3l also
gave the [2+1] adduct 4al under these platinum-catalysed
conditions, although in a lower yield (entry 11, Table 1).[16]
The reaction also works with allenes with different func-
tionalities (entries 1–5, Table 2).[17] In contrast to the dihy-
droalkoxylation of allenes described previously,[6] the bisin-
dolylation reaction of 1,3- and 1,1-disubstituted allenes also
worked under the platinum-catalysed reaction conditions to
give the bisACTHNUGRTNEUNG(indolyl) products 4, albeit in lower yields (en-
tries 6 and 7, Table 2).
Moreover, the products from the platinum-catalysed bisin-
dolylation of allenes are not limited to the addition of the
same indoles and cross-products could be obtained by reac-
tion of the allenes with different indoles, which increases the
utility of this reaction and gives the possibility of new bis-
AHCTUNGTREGUN(NN heteroarene) compounds. One example is shown in
Scheme 4.
The reaction of N-(2,3-butadienyl)indole derivatives 6
(Scheme 5) was also studied in the presence of platinum cat-
alysis and again, we found a divergent reactivity compared
with the reactivity found with gold.[18] The platinum-cata-
lysed reaction of 6a and the 3-methyl derivative 6b gave the
4500
