Angewandte
Chemie
DOI: 10.1002/anie.201202856
Enantioselective Catalysis
Copper-Catalyzed Enantioselective Allylic Substitution with Readily
Accessible Carbonyl- and Acetal-Containing Vinylboron Reagents**
Fang Gao, James L. Carr, and Amir H. Hoveyda*
Catalytic enantioselective allylic substitution (EAS) reactions
are of prominent utility in chemical synthesis.[1] Such trans-
formations generate a stereogenic center adjacent to an
alkene, which can be further functionalized to afford a range
of other enantiomerically enriched molecules. Despite note-
worthy advances, several issues remain unresolved in this
area. Nearly all the existing protocols require nucleophilic
metal-based reagents, which, while often the source of high
reactivity, are not well suited when certain commonly
occurring functional groups are present. Moreover, whereas
significant focus has been placed on additions of alkyl
groups,[1] reported examples of catalytic processes that lead
to incorporation of aryl or heteroaryl,[2] allyl,[3] alkynyl,[4] or
Scheme 1. A route for enantioselective synthesis of Pummerer ketone
might involve catalytic allylic substitution with a carbonyl-containing
allenyl[5] moieties are markedly small in number.
The corresponding reactions resulting in additions of vinyl
units have received attention only recently. Efforts in these
laboratories have led to the development of catalytic EAS
with vinylmetal species, generated through hydroalumina-
tions of alkynes[6] (with di-iso-butylaluminum hydride) and
vinyl group, followed by a catalytic diastereoselective intramolecular
conjugate addition and catalytic ring-closing metathesis. pg=protect-
ing group, pin=pinacolato.
À
used in situ for site- and enantioselective C C bond forma-
Herein, we outline a method for catalytic EAS reactions
that proceed with vinylboron reagents,[11] including those that
contain a carboxylic ester or an acetal unit, which are either
purchased or can be prepared by Cu-catalyzed processes.[12]
The coupling reactions are promoted by sulfonate-bridged
bidentate N-heterocyclic carbene (NHC) complexes of
copper and generate all-carbon quaternary stereogenic cen-
ters.[13] The desired products, including those with an ester, an
aldehyde, or an acetal group, are formed in up to 98% yield,
more than 98% SN2’ selectivity and more than 98:2 enantio-
meric ratio (e.r.). Utility is demonstrated by concise enantio-
selective syntheses of Pummerer ketone as well as its hitherto
undisclosed anti isomer, where diastereoselective intramolec-
ular conjugate additions, controlled by cinchona alkaloid
catalysts, and Ru-catalyzed ring-closing metathesis comple-
ment the NHC–Cu-catalyzed EAS process.
tion.[7] Nonetheless, vinylaluminum reagents with a hetero-
atom substituent at their allylic position cannot be efficiently
prepared by hydrometalation.[8] The above shortcoming is
underlined by the sequence shown in Scheme 1, regarding
a projected enantioselective synthesis of Pummerer ketone,[9]
an intermediate in morphine biosynthesis.[10] The key step
would ideally involve EAS with a carbonyl-substituted
reagent, leading to the formation of an a,b-unsaturated
ester that could then be subjected to a diastereoselective
intramolecular conjugate addition. The analogous vinylalu-
minum species are inaccessible. In contrast, the correspond-
ing vinylboron reagents are prepared readily; however, an
efficient method for catalytic EAS involving such entities
does not exist. Such protocols would notably enhance the
general utility of this important class of transformations.
We initiated our investigations by probing the ability of
different NHC–Cu complexes to promote reaction between
commercially available n-hexyl(pinacolato)vinylboron 9 and
o-methoxyphenyl-containing allylic phosphate 7a; the
expected product (8a) contains an ortho-alkoxy-substituted
aryl unit, as required in the proposed approach to enantio-
selective synthesis of Pummerer ketones (see Scheme 1). The
presence of NaOMe is to assist the formation of the NHC–
Cu-vinyl intermediate (via the methoxy-bearing boronate).[14]
Preliminary studies indicated that the transformation is
sluggish at ambient temperature (ꢀ 30% conversion with
various catalysts). Therefore, in contrast to Cu-catalyzed
reactions with the related allenylboron reagent,[5] which
proceed to completion at 228C, it appeared that EAS with
the relatively more hindered vinylboron demands more
[*] F. Gao, Dr. J. L. Carr, Prof. A. H. Hoveyda
Department of Chemistry, Merkert Chemistry Center
Boston College
Chestnut Hill, MA 02467 (USA)
E-mail: amir.hoveyda@bc.edu
[**] Financial support was provided by the NIH (GM-47480) and the
NSF (CHE-1111074). F.G. was an AstraZeneca (2010–11) and is
a Bristol-Myers Squibb graduate fellow (2011–12). We are grateful to
Dr. B. Jung and Dr. F. Haeffner for helpful discussions, to Frontier
Scientific, Inc. for gifts of vinylboronic acid pinacol esters, and to
Boston College Research Services for providing access to compu-
tational facilities.
Supporting information for this article is available on the WWW
Angew. Chem. Int. Ed. 2012, 51, 6613 –6617
ꢀ 2012 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
6613
