Angewandte
Chemie
DOI: 10.1002/anie.201205723
À
C H Activation
À
Rhodium-Catalyzed Direct C H Amination of Benzamides with Aryl
Azides: A Synthetic Route to Diarylamines**
Jaeyune Ryu, Kwangmin Shin, Sae Hume Park, Ji Young Kim, and Sukbok Chang*
Dedicated to Professor Chang Kiu Lee
Diarylamines are widely present in biologically active natural
products, and are also an important synthetic unit in
numerous pharmaceuticals, agrochemicals, dyes, and func-
tional materials.[1] Among the diarylamines, derivatives bear-
ing an ortho-carbonyl group serve as important pharmaco-
phores and are key components in a wide range of bioactive
compounds (Scheme 1a).[2,3] Furthermore, they are easily
converted into various heterocycles of high synthetic utility.[4]
Conventional methods for the preparation of diarylamines
rely on the Cu-mediated coupling between aryl halides and
anilines,[5] and generate stoichiometric amounts of copper
waste. The subsequent development of catalytic methods for
this N-arylation has been predicated upon the choice of
suitable ligands (Scheme 1b).[6,7]
In recent years, new research has been focused on metal-
À
catalyzed direct C H amination (or amidation) of (hetero)-
arenes without the need for pre-functionalized aryl halides.[8]
Although this approach is highly promising, it still generates
stoichiometric amounts of by-products from the external
oxidants,[9] halide salts, or bases employed;[10] the substrate
scope is also often rather limited.
In our continuing efforts to develop highly efficient
amination reactions,[11] we recently reported a Rh-catalyzed
À
direct arene C H amidation using sulfonyl azides as the
amine source.[12] It proceeds without external oxidants and
releases N2 as a single by-product. This result led us to attempt
the direct amination of arenes with aryl azides, which can be
readily prepared with wide diversity, to afford diarylamines.[13]
In particular, we were interested in the direct installation of
an amino group onto benzamides to afford 2-anilinobenz-
amides (Scheme 1c). Although some elegant examples of
À
catalytic C H amination were previously reported using aryl-
or vinyl azides, they were mainly limited to intramolcular
conversions.[14,15] In contrast, only a few examples of inter-
molecular reactions are known, primarily for the amination of
3
[14,16,17]
À
allylic or benzylic sp C H bonds.
It is in this context
that we herein describe a highly efficient and selective Rh-
À
catalyzed direct intermolecular C H amination of benza-
mides and ketoximes using aryl azides.
À
At the outset of our study, we searched for optimal C H
amination conditions (Table 1). All reactions were catalyzed
by a cationic RhIII species, which was generated in situ by
treating [{RhCp*Cl2}2] with a silver salt. No conversion was
observed with primary or tertiary benzamides (entries 1 and
2) or with N-pivaloyloxy benzamide (entry 3), whereas
amination of N-methylbenzamide with 4-nitrophenyl azide
(2a) was found to proceed, albeit with moderate yield
(entry 4). We were pleased to observe that high yield was
obtained when N-tert-butylbenzamide (1.8 equiv relative to
2a) was applied, even with a lower loading of the rhodium
catalyst (2.5 mol%), when conducted at 858C in 1,2-dichloro-
ethane (1,2-DCE; entry 5). Reactions at lower temperatures
resulted in decreased reactivity (entries 6 and 7). Other
catalytic systems tested were largely ineffective under these
conditions (entries 8 and 9). Other carbonyl groups, including
ketone, ester, or carboxylic acids, were not found to be viable
for direct amination (entries 10–12).
Scheme 1. Utility and synthesis of diarylamines.
[*] J. Ryu, K. Shin, S. H. Park, J. Y. Kim, Prof. Dr. S. Chang
Department of Chemistry and Molecular-Level Interface Research
Center, Korea Advanced Institute of Science and Technology
(KAIST), Daejeon 305–701 (Korea)
E-mail: sbchang@kaist.ac.kr
[**] This research was supported by the Korea Research Foundation
Grant (KRF-2008-C00024), MIRC (NRF-2011–0001322), and
a Global Ph.D. Fellowship (NRF-2011-0008452) to J.R.
With the optimal conditions established, we next inves-
tigated the substrate scope of various aryl amides in the
reaction with 4-nitrophenyl azide (Scheme 2). The reaction
Supporting information for this article is available on the WWW
Angew. Chem. Int. Ed. 2012, 51, 1 – 6
ꢀ 2012 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
1
