Anatomic variations
Double hepatomesenteric artery a rare anatomical variant
1
2
1
1
1
N. Hentati , A. Pasco , H.-D. Fournier , X. Papon , P. Mercier
1 Laboratoire d'Anatomie, Faculté de médecine, rue Haute de Reculée, F-49045 Angers cedex, France
2 Service de Radiologie C, Hôpital Larrey, CHU d'Angers, F-49045 Angers cedex, France
Received October 03, 2000 / Accepted in final form April 10, 2001
Key words: Hepatic pedicle - Variants of hepatic arteries - Vascular variants -Variations
Correspondence to: Ph Mercier E-mail :philippe.mercier@univ-angers.fr
Abstract
Abstract: A case of a "double hepatomesenteric artery", i.e. two persisting hepatic arteries arising from the superior
mesenteric artery, is reported. Also observed was a lack of systematisation of the pancreaticoduodenal arteries. The variant,
which does not appear to have been previously reported in the literature, was observed when dissecting the vessels of the
duodenal bulb in a preserved male cadaver injected with neoprene latex. Its embryological origin, as well as the clinical,
radiological (diagnostic or interventional) and surgical implications, are discussed.
The arterial blood supply to the liver has become of increasing interest for a number of specialists (anatomists, radiologists,
surgeons), because of the development of new techniques for vascular investigation, surgery on the stomach and pancreas,
but most importantly because of liver transplantation. Consequently, variants of the hepatic aa., which are much more
common than those of the portal system, have triggered new studies.
The case of an unusual arterial variant is presented, which appears not to have been previously described in literature.
Clinical case
The variant, described using the Tandler [20 ] classification, was observed during an investigation of the vessels of the
duodenal bulb. Dissection was performed on specimens removed from cadavers, which had been preserved in Winckler's
fluid and completely injected with neoprene latex specimens comprised the stomach, duodenum, pancreas, spleen, hepatic
pedicle (sectioned at the porta hepatis) and abdominal aorta. The object of the investigation was to dissect and follow the
arteries supplying the duodenal bulb from their origin to their termination.
Arterial variations
In one case, while dissecting the supraduodenal pedicle, a hepatic pedicle with an unusual disposition was observed. Having
exposed the portal v. on its anterior aspect, the hilar segment was crossed by two hepatic aa. (right and left hepatic branches)
of identical diameter. The two arteries were interconnected by a full canal anastomosis, with a calibre of 50% of the two
hepatic aa. (Fig. 1a). Further dissection revealed that both arteries originated from two distinct arteries (Fig. 1b). The artery
supplying the left hepatic a. was equivalent to a proper hepatic a., arising from a trunk emerging from the dorsal aspect of the
isthmus of the pancreas the other terminal branch being the right gastro-omental a. The artery supplying the right hepatic
branch arose from the dorsal aspect of the head of pancreas, close to the descending duodenum.

Fig. 1a, b a. Overall view of the hepatic pedicle. b. Dissection of the abdominal part of aorta, celiac and mesenteric branches.
1, left hepatic branch 2, right hepatic branch 3, anastomosis 4, right hepatic a. 5, middle hepatic a. 6, splenic a. 7, left gastric
a. 8, aorta 9, right inferior diaphragmatic a. 10 , portal v. 11, right gastric a. 12, right gastro-omental a. 13 , main bile duct 14,
celiac trunk 15, left inferior diaphragmatic a. 16, superior mesenteric a. 17 , dorsal pancreatic a. 18, duodenal branches of
right hepatic a. 19, dorsal pancreatic branch
Having identified this unusual arrangement, dissection was continued to the aorta in an attempt to identify the territories
supplied by each trunk. Two persisting hepatic aa. with identical diameter were found, both arising from the superior
mesenteric a. (SMA). The celiac trunk was represented by the left gastric and splenic aa., together with a right inferior
diaphragmatic a. arising from its side. Less than 1cm below the origin of the celiac trunk was the origin of a very large SMA,
which divided into two parts. The nearly horizontal proximal part passed anteriorly, while at 90 ° a vertical descending part
with an anterior concavity passed along the posterior aspect of the body of the pancreas. The left inferior diaphragmatic a.
arose at the level of the ostium of the SMA from the left side of the aorta.
From the angle between the two parts of the SMA arose the hepatic a., which, after a short vertical course, turned through
90˚ to lie horizontally behind the pancreas. The hepatic a. passed toward the hepatic pedicle, crossing the anterior
aspect of the retroduodenal pancreatic portion of the portal v., to reach the porta hepatis. The artery was equivalent (Tandler
classification) to a middle hepatic a. (MHA) that continues as a left hepatic branch (LHB).
Branches of the preportal part of the hepatic a. were a posterior pancreatic a. passing toward the head of the pancreas, and a
right gastro-omental a., which followed the usual course of the gastroduodenal a., supplying numerous small branches to the
anterior aspect of the pancreas. Branches of the pedicular part of the artery included several small duodenal and pancreatic
branches. Near its anastomosis with the second hepatic a. it gave off a group of branches, namely ventral transverse
pancreatic and ventral vertical pancreatic aa., and a biliary a. for the main bile duct. The left hepatic branch gave the right
gastric a.
From the left side of the second part of the SMA arose the intestinal aa. and from the right side a dorsal pancreatic a. Near the

lower margin of the pancreas the SMA gave rise to a second hepatic a., which passed behind the pancreas and the superior
duodenal flexure before terminating with the right hepatic branch. Based on its course, this artery was identified as being a
right hepatic a. (RHA), since it supplied branches to adjacent parts of the duodenum during its retropancreaticoduodenal
course. Near its origin the right hepatic branch supplied the cystic a.
Unusual findings in the hepatic pedicle
The portal v. was almost entirely visible, being crossed only in its hilar portion by the bile ducts and branches of the hepatic
a. The main bile duct was to the right of the portal v. being crossed anteriorly by the MHA and left hepatic branch (LHB).
The right hepatic a. and LHB were on the right of the main bile duct, which received two groups of arteries a superior pedicle
from the LHB and an inferior pedicle from the MHA.
Unusual findings in the arteries of pancreas
Arteries of the pancreas were not systematised in this subject, however two peculiarities were noted the lack of
pancreaticoduodenal arcades, and the arterial blood supply for the duodenum and pancreas being entirely separate. According
to previous descriptions the duodenum is supplied by the right hepatic a.
The head of the pancreas was supplied by branches arising directly from the middle hepatic and right gastro-omental aa. The
dorsal aspect of the isthmus of the pancreas was crossed by a dorsal pancreatic a., which supplied both the head and body.
The body and tail were supplied by splenic branches that anastomosed with the ventral transverse pancreatic a. posteriorly
and the posterior pancreatic a., both of which originated from the MHA, and with the dorsal pancreatic a. (Fig. 2A, B). From
a macroscopic viewpoint both the liver and pancreas were morphologically normal, as were the other intraperitoneal
abdominal organs.

Fig. 2a, b a. Anterior view of the hepatic pedicle and pancreaticoduodenal specimen. b. Posterior view of
pancreaticoduodenal specimen. 1, right hepatic branch 2, anastomosis 3, gallbladder 4, right gastro-omental a. 5, transverse
pancreatic branch 6, vertical pancreatic branch 7, right hepatic a. 8, superior mesenteric a. 9, splenic a. 10 , left gastric a. 11,
celiac trunk 12, aorta 13, middle hepatic a. 14, portal v. 15 , main bile duct 16, left hepatic branch 17, right gastric a. 18,
dorsal pancreatic branch 19, dorsal pancreatic a. 20 , duodenal branches of right hepatic a.
Discussion
The multiplicity of hepatic aa. is well known, however the implications vary widely. For some investigators a common or
middle hepatic a. is normal regardless of its origin, the other arteries supplying the liver being considered in this case as
anomalies [7, 8, 10, 22]. For others, the common hepatic a. is the main artery, with the smaller arteries being considered as
accessory [7, 17]. In contrast to both of the above some investigators believe that arteries supplying the liver should all be
considered as being hepatic aa. with different functional roles [8, 13, 21]. These discordant opinions highlight the diverging
embryological concepts in the derivation of arteries supplying the liver, and also explain the wide range of reported statistical
data (Table 1). Finally, there are some who consider that arteries originating from the common hepatic or gastroduodenal aa.
are accessory hepatic aa. [13, 17], while others consider them to be collateral branches of a main artery [7].
Table 1 . Prevalence of hepatic a. variations as reported in literature
The development of new investigative techniques, such as angiography and ultrasonic tomography [9, 12, 13, 16], may have
accentuated the divergence of opinion, especially when investigators do not use classic dissection anatomy as their reference
[12 , 16 ]. The new techniques cannot be considered to be definitive studies of the hepatic aa. due the possibility of false
identifications. The problem is further compounded by the fact that investigators from different specialties use different
nomenclatures.

However, despite the differences three arteries regularly appear in the descriptions of most studies [2, 7, 11, 12, 13, 17, 20].
Firstly, a left hepatic a. arising from the left gastric a., running in the pars condensa of the lesser omentum and reaching the
liver in the left part of the porta hepatis. Secondly, a middle (or common) hepatic a. arising from the celiac trunk, aorta or
SMA, running in the pars vasculosa of the lesser omentum anterior to the portal v. It gives two terminal branches, the
gastroduodenal and proper hepatic aa. the latter usually dividing into two terminal branches as it enters the liver [1]. Finally,
a right hepatic a. arising from the SMA running behind the pancreas and duodenum, passing behind or to the right of the
portal v., becoming anterior again near the porta hepatis.
The previous conclusions that have been drawn tend to be based on the findings of Tandler [20 ] and Vincens [23 ] on the
origins of the arteries of the digestive system. According to Tandler [20], these arteries are derived from the rearrangement of
segmental arteries arising from the anterior aspect of the aorta that are united via a ventral longitudinal anastomosis. All three
previously mentioned hepatic aa. are, according to Tandler [20 ], the main arteries supplying the liver. After a series of
regressions and obliterations, only a single artery remains, usually the middle artery, however two or three of the arteries may
persist.
This mechanism does not, however account for all variants described in the literature. Vincens [23], therefore suggested a
slightly more elaborate model according to which the liver is initially formed as two separate entities, each being supplied by
a different group of arteries. A superior group for the left lobe, comprising branches of the left gastric a. (gastric
hepatocoronary a.) and the inferior diaphragmatic a. (hepatodiaphragmatic a.). An inferior group for the right lobe, with the
arteries originating from the celiac trunk or the aorta (hepatogastroduodenal a.) and the SMA (hepatomesenteric a.). All other
origins, whether from the renal, inferior diaphragmatic or splenic a., fits into one of these groups. It should be noted, however
that in human and comparative embryology the liver is not classically described as being derived from two separate precursor
organs. At best a horizontal development of right and left lobes is mentioned [13, 14], but these have never been shown to be
supplied by different segmental arteries.
The present observation of two persisting hepatic aa. (right and middle) can be explained by Tandler's theory [20], by shifting
the origin of the middle hepatic a. to the SMA. However, the additional findings of variant pancreatic aa., the lack of
pancreaticoduodenal arcades and a separate blood supply to the duodenum and pancreas cannot be explained by this theory,
because the theory states that arteries for the digestive system and liver have separate segmental origins, while those for the
pancreas originate from neighbouring segmental arteries for other organs [3, 4, 6]. Neither does Vincens' [23] theory provide
a basis for understanding the present case, as it only applies to the arteries of the liver.
Most studies on the arteries of the digestive system consider a single organ at a time [3, 4, 5, 17 ]. There appears to be no
report in the literature which includes descriptions of variants of the arteries of the entire superior celiac and mesenteric area,
as well as morphological variants of the associated organs. Such a study would prove invaluable in the understanding of the
embryological origin and development of the arteries based on the morphological variations of a single organ, as well as of
the entire region.
Not only do the present findings raise questions concerning the origin of variants, it also highlights the technical problems
that may occur in abdominal surgery and interventional radiology. Ligature of the right gastro -omental a. for total or distal
gastrectomy may jeopardize the blood supply to the head of pancreas. Vascular dissection and ligatures in cephalic
duodenopancreatectomy may prove difficult and seriously endanger the blood supply to the liver, especially if the variant is
not identified preoperatively. Because of the close relationship between the bile ducts and the hepatic aa., the surgical
approach may prove particularly difficult and dangerous. In liver transplantation, for example, if the subject with the variant
is the donor, reconstruction of the arteries on the recipient may be a problem, e.g. anastomosis with a single hepatic a.,
however if the subject with the variant is the recipient anastomosis with the artery on the transplanted liver will also be a
problem.
In interventional radiology selective catheterisation of the right hepatic a. may present technical difficulties, especially, for
example, if the catheter needs to be advanced into the right branch for chemical embolization. If the embolizing agent is
released before the anastomosis with the hepatic a., it may affect the duodenal territory of the right hepatic a. causing pain,
ischemia and perforation. The same may occur if the embolizing agent is released into the middle hepatic a. before it
anastomoses with the right hepatic a.
In conclusion, persisting hepatic aa. originating from the SMA do not have a satisfactory explanation according to current
embryological theories. An awareness of the variation presented here is essential because of its clinical implications.

References
1. Adachi B (1928) Das Arteriensystem der Japaner. Verlag der Kaiserlich-Japanischen Universität zu Kyoto, Band II, pp 18-
70
2. Almenar-Garcia V, Sanchez del Campo F, Puchades Orts A, Cort Gomis A, Correa Lacarcel J (1993) One further case of
unusual origin of three hepatic arteries. Surg Radiol Anat 14 155 -157
3. Bertelli E, Di Gregorio F, Bertelli L, Civeli L, Mosca S (1996) The arterial blood supply of the pancreas a review. II The
posterior superior pancreaticoduodenal artery. An anatomical and radiological study. Surg Radiol Anat 18 1-9
4. Bertelli E, Di Gregorio F, Bertelli L, Civeli L, Mosca S (1996) The arterial blood supply of the pancreas a review. III The
inferior pancreaticoduodenal artery. An anatomical review and a radiological study. Surg Radiol Anat 18 67-74
5. Busnardo AC, DiDio LJA, Thomford NR (1988) Anatomicosurgical segments of the human pancreas. Surg Radiol Anat
10 77-82
6. Calas F, Martin R, Bouchet Y, Polliak D (1995) Les artères de la t ête du pancréas. CR Ass Anat 89 362-367
7. Couinaud C (1957) Le foie. Etudes anatomiques et chirurgicales. Masson, Paris, Tome I, 265 p
8. Duval JM, Prevot J, Loescher JP (1959) Un cas de tronc coeliaco-mésentérique donnant deux art ères h épatiques. C R Ass
Anat 106 237 -242
9. Fontaine R, Pietri J, Tangio J, Negrero L (1970) Etude angiographique des variations anatomiques des artères hépatiques
basée sur 402 examens spécialis és. Angiology 110-113
10. Godlewski G, Hedon B, Castel C (1975) Contribution à l' étude de l'origine de l'art ère hépatique chez l'embryon et le
foetus. Bull Ass Anat 165 411 -417
11. Ibukuro K, Tsukiyama T, Mori K, Inoue Y (2000) The congenital anastomoses between hepatic arteries angiographic
appearance. Surg Radiol Anat 22 41-45
12. Lamarque JL, Semac JP, Bruel JM, Gaul A, Taulza A (1976) Anatomie radiologique de l'artère hépatique. Anat Radiol 19
316-318
13. Laude M, Libersa C (1970) Radio-anatomie du tronc de l'art ère hépatique. Bull Ass Anat 149 820-825
14. Martin M, Convert A (1960) Reconstruction du foie et de ses pédicules vasculaires sur un embryon humain de 26 mm.
CR Ass Anat 107 473-475
15. Michels NA (1953) Variational anatomy of the hepatic, cystic and retroduodenal arteries. Arch Surg 66 20-34
16. Ralls PW, Quinn MF, Rogers W, Halls J (1981) Sonographic anatomy of the hepatic artery A J R 136 1059-1063
17. Rigaud A, Cabanié H, Gouazé A, Dejussieu J (1955) Considérations sur les artères h épatiques accessoires (A propos de
120 dissections). C R Ass Anat 42 1197-1205
18. Rio Branco da Silva P (1912) Essai sur l'anatomie et la médecine op ératoire du tronc coeliaque et de ses branches, de
l'artère hépatique en particulier. Steinheil, Paris, 828 p
19. Sohier HML, Laffont J, Fuster R (1962) Les artères à destinée hépatique chez l'Africain d'Afrique Occidentale. Bull Ass
Anat 114 758 -768
20. Tandler J (1904) Zur Entwickelungsgeschichte der menschlichen Darmarterien. Anat Heft 23 188-209
21. Taviaux R (1979) Etude anatomique et fonctionnelle des artères du bloc duodéno -pancréatico-colique transverse. Thèse,
Angers, 223 p
22. Testut L, Latarjet A (1949) Traité d'anatomie humaine. Tome IV Appareil de la digestion, Doin, Paris, 754 p

23. Vincens (1910) Etude anatomique du tronc coeliaque et des artères hépatiques. Thèse, Bordeaux, 236 p
Surg Radiol Anat 23: 285-289
© Springer-Verlag France 2001
