Use of Strain-Release for the Diastereoselective Construction of
Quaternary Carbon Centers
Tobias Pinkert, Mowpriya Das, Malte L. Schrader, and Frank Glorius*
Cite This: J. Am. Chem. Soc. 2021, 143, 7648−7654
Read Online
sı
*
Metrics & More
Article Recommendations
Supporting Information
ACCESS
ABSTRACT: Herein, we describe the formation of quaternary carbon centers with excellent diastereoselectivity via a strain-release
protocol. An organometallic species is generated by Cp*Rh(III)-catalyzed C−H activation, which is then coupled with strained
bicyclobutanes (BCBs) and a prochiral carbon electrophile in a three-component reaction. This work illustrates a rare example of
BCBs in transition metal catalysis and demonstrates their broad potential to access novel reaction pathways. The method developed
exhibits ample functional group tolerance, and the products can be further transformed into valuable α-quaternary β-lactones.
Preliminary mechanistic investigations suggest a twofold C−C bond cleavage sequence involving σ-bond insertion and an ensuing β-
carbon elimination event.
uring the past decades strain-release driven trans-
formations have gathered significant attention in
catalyzed cycloisomerization-cyclopropanation sequence that
resulted in the formation of pyrrolidines and azepines (Figure
1c).15 The development of novel metal catalyzed method-
ologies and exploration of further reaction pathways of BCBs is
therefore highly desirable.5g,15c In order to expand the library
of known reactivity, we envisioned the reaction of an
organometallic species with a BCB and identified C−H
activation as a suitable strategy, since it enables the mild
generation of these intermediates from ubiquitous C−H bonds
that are known to engage a multitude of different coupling
partners (Figure 1d).16 In this context, especially multi-
component reactions have recently17 revealed their potential in
generating complex molecular structures in a single step, which
represents an attractive feature for organic synthesis.18
We began our studies to develop such a transition metal
catalyzed, three-component protocol by reacting oxime ether
1a together with benzyl BCB ester 2a and ethyl glyoxylate 3 as
an additional electrophile in the presence of
[Cp*Rh(CH3CN)3](SbF6)2 as the catalyst and CsOAc as a
base in TFE. We were intrigued when we observed the anti-
product 4aa in 60% yield with excellent E-selectivity and
diastereoselectivity that was formed upon twofold C−C bond
cleavage of the BCB moiety and subsequent addition to
aldehyde 3 (Table 1, entry 1). This class of compounds
containing an α-carbonyl quaternary center was recently
utilized as a key intermediate in the synthesis of novel
pantothenamide analogues displaying promising antiplasmoi-
dal activity.19 We continued to optimize the reaction
conditions, and a solvent screen revealed TFE to be essential
D
synthetic organic chemistry,1,2 materials science,3 and bio-
conjugation.4 Accordingly, molecules that bear a bridging bond
between opposite carbon or nitrogen atoms such as
[1.1.1]propellane, bicyclo[1.1.0]butanes (BCBs), or 1-
azabicyclo[1.1.0]butanes have emerged as a privileged class
of compounds.5 Owing to their relative destabilization, arising
from bond length and bond angle distortions, torsional strain,
and nonbonded as well as transannular steric interactions,6
these “spring-loaded“7 compounds display π-bond-type behav-
ior towards nucleophiles, electrophiles, and radicals.5 Such
versatile reactivity is especially desirable in the field of
medicinal chemistry where they are commonly used to install
the bicyclo[1.1.1]pentane, cyclobutane, and azetidine moieties,
motifs which serve as bioisosteres in the development and
modification of pharmaceuticals.8
Since Baran’s fundamental work on C−N bond formation by
a strain-release approach,9 chemists’ interest in utilizing the
unique properties of these molecules has been renewed.10,11 In
2019, the group of Aggarwal expanded the toolbox of BCB
chemistry by carbopalladation of the central C−C σ-bond of
BCB boronate complexes triggered by a 1,2-metalate
rearrangement (Figure 1a). Subsequent cross-coupling gave
access to valuable difunctionalized cyclobutyl boronates.12 To
overcome the inherent electrophilic reactivity of electron-
deficient BCBs, Gryko and co-workers reported a formal
polarity-reversal approach. Co(I)-catalysis allowed the gen-
eration of nucleophilic radicals upon light-induced homolysis
of the intermediate Co(III)−alkyl species. These radicals could
be coupled with electrophiles to afford disubstituted cyclo-
butanes (Figure 1b).13 Besides these inspiring examples,
transition metal catalyzed transformations involving BCBs
remain scarce.14 Wipf and co-workers hinted at the various
mechanistic pathways of reactions of BCBs that might be
enabled by the application of transition metal catalysis. They
showed that nitrogen-tethered BCBs could undergo a Rh(I)-
Received: April 1, 2021
Published: May 11, 2021
© 2021 The Authors. Published by
American Chemical Society
https://doi.org/10.1021/jacs.1c03492
J. Am. Chem. Soc. 2021, 143, 7648−7654
7648

Journal of the American Chemical Society
pubs.acs.org/JACS
Communication
a
for the reaction outcome, with other solvents leading to low
yields or no reactivity (entries 2−4). Variation of the
temperature did not improve the yield (entries 5−7). We
examined different bases, including Na2CO3, KOAc, NaOAc,
and K3PO4, which all resulted in diminished yields (entries 8−
11). To our delight, the use of 2.0 equiv of BCB ester 2a
delivered the desired product in 82% yield with perfect
diastereoselectivity and E-selectivity (entry 12). Subsequent
control experiments showed that the rhodium catalyst was
essential for the reaction, and an absence of base led to a
decreased yield (entries 13 and 14).
Table 1. Optimization of the Reaction Conditions
entry
solvent
TFE
DCE
1,4-dioxane
HFIP
TFE
TFE
TFE
TFE
TFE
additive
T
dr
yield
1
2
3
4
5
6
7
8
CsOAc
CsOAc
CsOAc
CsOAc
CsOAc
CsOAc
CsOAc
Na2CO3
KOAc
NaOAc
K3PO4
CsOAc
CsOAc
−
60 °C
60 °C
60 °C
60 °C
rt
40 °C
80 °C
60 °C
60 °C
60 °C
60 °C
60 °C
60 °C
60 °C
>20:1
−
60%
traces
−
8%
9%
40%
47%
28%
55%
49%
30%
82%
−
−
>20:1
>20:1
>20:1
>20:1
>20:1
>20:1
>20:1
>20:1
>20:1
−
9
10
11
12
TFE
TFE
TFE
TFE
b
c
13
14
TFE
>20:1
52%
a
Reactions were performed on a 0.10 mmol scale with
[Cp*Rh(CH3CN)3](SbF6)2 as the catalyst. Yields and diastereomeric
ratios (dr) were determined by LC-UV using 1-fluoronaphthalene as
the internal standard. The E-isomer was observed exclusively in all
b
c
cases. 2.0 equiv of 2a. No catalyst. HFIP = hexafluoroisopropanol. rt
= room temperature.
4ua, the diminished yield was attributed to the strong
coordinating properties of the sulfur atom. Notably, meta-
substituted oxime ethers could be successfully applied and
reacted with perfect site selectivity (4va, 4wa). Similar
reactivity was observed for disubstituted substrates that
provided the products in moderate to good yields with
outstanding selectivities (4xa, 4ya). We were delighted that
even an ortho-substituted oxime ether was suitable in the
developed strain-release reaction despite the high steric
congestion (4za). In addition to the broad functional group
tolerance, several BCB esters could be applied. Ethyl and
isobutyl esters gave the corresponding products (4ab, 4ac) and
gratifyingly, a Weinreb amide was also reactive in this protocol
(4ad). In terms of the aldehyde scope, we examined alkyl as
well as aryl aldehydes. However, only trace amounts of product
were observed in these cases (see the Supporting Information
for further details). The relative configuration of the stereo-
centers was unambiguously assigned by X-ray crystallographic
analysis of a derivative of sulfone 4sa that was obtained after
esterification and subsequent debenzylation (see the Support-
ing Information for further details).
In addition, to further illustrate the synthetic value of this
protocol we sought to convert the products into valuable β-
lactones.20 Indeed, compound 4aa was successfully debenzy-
lated and hydrogenated under reducing conditions using Pd/C
as the catalyst (Figure 2). The resulting carboxylic acid 5 was
then transformed into the corresponding α-quaternary β-
lactone 6 (PyBOP, NEt3) in good yield and without the
observation of isomerization. NOE experiments confirmed the
stereochemistry indicated.
Figure 1. Transition metal catalyzed reactions of BCBs. (a) C−C σ-
bond carbopalladation. (b) Photochemical polarity reversal via Co(I)-
catalysis. (c) Rh(I)-catalyzed cycloisomerization. (d) This work:
diastereoselective formation of quaternary carbon centers by twofold
C−C bond cleavage. FG = functional group. TFE = 2,2,2-
trifluoroethanol.
With the optimized conditions in hand, we set out to explore
the substrate scope of the strain-release reaction and started
with the exploration of the arene scope (Table 2). Halides
were well tolerated and delivered the corresponding products
in good yields and with excellent diastereo- and E-selectivities
(4ba−4da, 4wa). Triflate and ester substituents underwent the
reaction smoothly and the products were isolated in moderate
to good yields (4ea−4ga). Substrates bearing electron-
donating functionalities, such as methoxy, phenol, and Boc-
protected amino groups (4ha−4ja), could also be employed
and furnished the products in moderate to very good yields. In
addition, sterically demanding alkyl and aryl substituents were
tolerated as well (4ka, 4la). We continued to investigate
naphthalene (4ma) and thiophene (4na) derivatives and were
pleased to obtain the respective products in moderate to good
yields with perfect diastereoselectivity, E-selectivity, and site
selectivity in favor of the more accessible or more reactive
position, respectively. A wide range of electron-deficient
functional groups, including cyano, nitro, trifluoromethyl,
trifluoromethoxy as well as sulfonyl, sulfamoyl, and a
challenging sulfenyl moiety were well tolerated and afforded
the desired products in moderate to very good yields with
excellent selectivities (4oa−4ua). In the case of the thioether
Furthermore, the respective epimer could be accessed
complementarily under Mitsunobu conditions (see the
Supporting Information for further details).
7649
https://doi.org/10.1021/jacs.1c03492
J. Am. Chem. Soc. 2021, 143, 7648−7654

Journal of the American Chemical Society
pubs.acs.org/JACS
Communication
a
Table 2. Scope of the Strain-Release Construction of Quaternary Carbon Centers
a
Standard reaction conditions: 1 (0.20 mmol, 1.0 equiv), 2 (0.40 mmol, 2.0 equiv), 3 (0.40 mmol, 2.0 equiv), [Cp*Rh(CH3CN)3](SbF6)2 (5 mol
%), CsOAc (30 mol %), TFE (0.10 M), 60 °C, 16 h. Diastereomeric ratios and site selectivities were determined by LC-UV of the crude reaction
mixture. All products were obtained exclusively as the E-isomer. See the Supporting Information for full experimental details.
b
c
d
[Cp*Rh(CH3CN)3](SbF6)2 (10 mol %) was used. Performed on 1.00 mmol scale. >20:1 site selectivity. Tf = trifluoromethylsulfonyl. Cy =
cyclohexyl.
rate-determining step (Figure 3a).21 Moreover, two-compo-
nent experiments were performed under the optimized
reaction conditions (Figure 3b). In the absence of aldehyde
3, olefinated product 7 was obtained in 19% yield. In contrast,
omission of BCB ester 2a led to selective addition of the
organometallic species generated to aldehyde 3 yielding
alcohol 8. These results suggest that a stepwise mechanism
of an initial rearrangement-olefination and subsequent aldol-
type addition might be operative. Nevertheless, when olefin 7
and aldehyde 3 were exposed to the standard conditions, the
desired product 4aa was obtained in low yield and with a
decreased dr of 7:1 (Figure 3c). A stepwise mechanism is
therefore unlikely to proceed. In addition, we conducted an
isomerization experiment of BCB ester 2a under the conditions
developed to examine whether a rhodium catalyzed diene
isomerization might be part of the catalytic cycle.14a However,
no isomers were detected and 2a was recovered in 83% yield
(see the Supporting Information for further details). Based on
these experiments and literature known mechanistic character-
istics of Cp*Rh(III)-catalyzed C−H activation,22 we propose
the following catalytic cycle (Figure 3d): The catalytically
Figure 2. Synthesis of an α-quaternary β-lactone. Ar = 2-(C(Me)
=NOMe)-C6H4.
In order to get insight into the underlying reaction
mechanism a preliminary series of mechanistic experiments
was conducted (Figure 3). First, the kinetic isotope effect was
determined by two parallel experiments. A KIE value of 1.2
indicates that the C−H activation might not be involved in the
7650
https://doi.org/10.1021/jacs.1c03492
J. Am. Chem. Soc. 2021, 143, 7648−7654

Journal of the American Chemical Society
pubs.acs.org/JACS
Communication
by twofold C−C bond cleavage. The reaction proceeds under
mild conditions and tolerates a wide range of common
functional groups. The products could be further transformed
into valuable α-quaternary β-lactones. The high diastereose-
lectivity was rationalized by mechanistic investigations that
suggest a catalytic cycle proceeding through a key C−C σ-
bond insertion, followed by a β-carbon elimination and a
subsequent allylation via a six-membered transition state. This
method exhibits a rare example of transition metal catalysis in
the field of BCB chemistry and showcases the diversity of
reactivity pathways accessible to these strained compounds.
Ultimately, we believe that this work will inspire researchers to
further explore the potential of these fascinating molecules in
transition metal catalysis.
ASSOCIATED CONTENT
* Supporting Information
The Supporting Information is available free of charge at
https://pubs.acs.org/doi/10.1021/jacs.1c03492.
■
sı
Experimental and details (PDF)
Accession Codes
CCDC 2070494 contains the supplementary crystallographic
data for this paper. These data can be obtained free of charge
via www.ccdc.cam.ac.uk/data_request/cif, or by emailing
data_request@ccdc.cam.ac.uk, or by contacting The Cam-
bridge Crystallographic Data Centre, 12 Union Road,
Cambridge CB2 1EZ, UK; fax: +44 1223 336033.
AUTHOR INFORMATION
Corresponding Author
■
Frank Glorius − Organisch-Chemisches Institut, Westfälische
Wilhelms-Universität Munster, 48149 Munster, Germany;
̈ ̈
orcid.org/0000-0002-0648-956X; Email: glorius@uni-
muenster.de
Authors
Tobias Pinkert − Organisch-Chemisches Institut, Westfälische
Wilhelms-Universität Munster, 48149 Munster, Germany
Mowpriya Das − Organisch-Chemisches Institut, Westfälische
Wilhelms-Universität Munster, 48149 Munster, Germany
Malte L. Schrader − Organisch-Chemisches Institut,
Westfälische Wilhelms-Universität Munster, 48149 Mu
Germany
̈
̈
̈
̈
̈
̈
nster,
Figure 3. Mechanistic investigations and proposed catalytic cycle.
[Cp*Rh(III)] = [Cp*Rh(CH3CN)3](SbF6)2.
Complete contact information is available at:
https://pubs.acs.org/10.1021/jacs.1c03492
Notes
active species I is generated from the catalyst precursor
[Cp*Rh(CH3CN)3](SbF6)2 and CsOAc by ligand exchange.
Oxime ether 1 coordinates to the metal center, and rhodacycle
II is formed by C−H activation. BCB ester 2 associates to the
metal center and inserts into the Rh−C bond to give Rh−
cyclobutyl species III. This intermediate undergoes β-carbon
elimination to generate IV, that is transformed into π-allyl
species VI via a syn-β-hydride elimination-reinsertion sequence
through diene V. This species isomerizes to the corresponding
σ-allyl intermediate before adding to aldehyde 3 via chairlike
transition state VII,17g which leads to the observed stereo-
chemistry. Finally, protodemetalation delivers product 4 and
closes the catalytic cycle to regenerate the active species I.
In conclusion, we have developed a highly diastereoselective
and E-selective three-component protocol for the construction
of quaternary carbon centers via strain-release from BCB esters
The authors declare no competing financial interest.
ACKNOWLEDGMENTS
■
We thank Roman Kleinmans, Dr. Frederik Sandfort, Dr. J.
Luca Schwarz, Dr. Andreas Lerchen, Toryn Dalton, Tobias
Wagener (all WWU), Mariusz Milewski, and Prof. Karol Grela
(both University of Warsaw) for helpful discussions; Dr. Klaus
Bergander for NMR analysis; and Dr. Constantin G. Daniliuc
and Birgit Wibbeling for X-ray crystallographic analysis.
Financial support from the Deutsche Forschungsgemeinschaft
(Leibniz Award, SFB 858) is gratefully acknowledged.
REFERENCES
■
(1) For selected reviews, see: (a) Liebman, J. F.; Greenberg, A. A
survey of strained organic molecules. Chem. Rev. 1976, 76, 311−365.
7651
https://doi.org/10.1021/jacs.1c03492
J. Am. Chem. Soc. 2021, 143, 7648−7654

Journal of the American Chemical Society
pubs.acs.org/JACS
Communication
(b) de Meijere, A.; Kozhushkov, S. I.; Schill, H. Three-Membered-
Ring-Based Molecular Architectures. Chem. Rev. 2006, 106, 4926−
4996. (c) Shi, M.; Shao, L.-X.; Lu, J.-M.; Wei, Y.; Mizuno, K.; Maeda,
H. Chemistry of Vinylidenecyclopropanes. Chem. Rev. 2010, 110,
5883−5913. (d) Souillart, L.; Cramer, N. Catalytic C−C Bond
Activations via Oxidative Addition to Transition Metals. Chem. Rev.
2015, 115, 9410−9464.
useful reagents for the synthesis of functionalized azetidines. Org.
Biomol. Chem. 2020, 18, 5798−5810.
(6) Wiberg, K. B. The Concept of Strain in Organic Chemistry.
Angew. Chem., Int. Ed. Engl. 1986, 25, 312−322.
(7) (a) Kolb, H. C.; Finn, M. G.; Sharpless, K. B. Click Chemistry:
Diverse Chemical Function from a Few Good Reactions. Angew.
Chem., Int. Ed. 2001, 40, 2004−2021. (b) Lopchuk, J. M.; Fjelbye, K.;
Kawamata, Y.; Malins, L. R.; Pan, C.-M.; Gianatassio, R.; Wang, J.;
Prieto, L.; Bradow, J.; Brandt, T. A.; Collins, M. R.; Elleraas, J.;
Ewanicki, J.; Farrell, W.; Fadeyi, O. O.; Gallego, G. M.; Mousseau, J.
J.; Oliver, R.; Sach, N. W.; Smith, J. K.; Spangler, J. E.; Zhu, H.; Zhu,
J.; Baran, P. S. Strain-Release Heteroatom Functionalization:
Development, Scope, and Stereospecificity. J. Am. Chem. Soc. 2017,
139, 3209−3226.
(2) For selected examples, see: (a) Huffman, M. A.; Liebeskind, L. S.
Rhodium(I)-Catalyzed intramolecular carbocyclic ring fusion: a new
approach to medium-sized-ring ketones. J. Am. Chem. Soc. 1993, 115,
4895−4896. (b) Nishimura, T.; Ohe, K.; Uemura, S. Palladium(II)-
Catalyzed Oxidative Ring Cleavage of tert-Cyclobutanols under
Oxygen Atmosphere. J. Am. Chem. Soc. 1999, 121, 2645−2646.
(c) Converso, A.; Burow, K.; Marzinzik, A.; Sharpless, K. B.; Finn, M.
G. 2,6-Dichloro-9-thiabicyclo[3.3.1]nonane: A Privileged, Bivalent
Scaffold for the Display of Nucleophilic Components. J. Org. Chem.
2001, 66, 4386−4392. (d) Young, I. S.; Kerr, M. A. A Homo [3 + 2]
Dipolar Cycloaddition: The Reaction of Nitrones with Cyclo-
propanes. Angew. Chem., Int. Ed. 2003, 42, 3023−3026. (e) Wipf,
P.; Stephenson, C. R. J.; Okumura, K. Transition-Metal-Mediated
Cascade Reactions: C,C-Dicyclopropylmethylamines by Way of
Double C,C-σ-Bond Insertion into Bicyclobutanes. J. Am. Chem.
Soc. 2003, 125, 14694−14695. (f) Wipf, P.; Walczak, M. A. A.
Pericyclic Cascade Reactions of (Bicyclo[1.1.0]butylmethyl)amines.
Angew. Chem., Int. Ed. 2006, 45, 4172−4175. For selected examples
in total synthesis, see: (g) Wender, P. A.; Howbert, J. J. Synthetic
Studies on Arene-Olefin Cycloadditions: Total Synthesis of ( )-α-
Cedrene. J. Am. Chem. Soc. 1981, 103, 688−690. (h) Eckelbarger, J.
D.; Wilmot, J. T.; Gin, D. Y. Strain-Release Rearrangement of N-
Vinyl-2-Arylaziridines. Total Synthesis of the Anti-Leukemia Alkaloid
(−)-Deoxyharringtonine. J. Am. Chem. Soc. 2006, 128, 10370−10371.
(i) Panish, R. A.; Chintala, S. R.; Fox, J. M. A Mixed-Ligand Chiral
Rhodium(II) Catalyst Enables the Enantioselective Total Synthesis of
Piperarborenine B. Angew. Chem., Int. Ed. 2016, 55, 4983−4987.
(3) For selected reviews, see: (a) Hall, H. K., Jr.; Padias, A. B.
Bicyclobutanes and Cyclobutenes: Unusual Carbocyclic Monomers. J.
(8) (a) Boström, J.; Brown, D. G.; Young, R. J.; Keseru, G. M.
̈
Expanding the medicinal chemistry synthetic toolbox. Nat. Rev. Drug
Discovery 2018, 17, 709−727. (b) Bauer, M. R.; Di Fruscia, P.; Lucas,
S. C. C.; Michaelides, I. N.; Nelson, J. E.; Storer, R. I.; Whitehurst, B.
C. Put a ring on it: application of small aliphatic rings in medicinal
chemistry. RSC Med. Chem. 2021, 12, 448−471.
(9) Gianatassio, R.; Lopchuk, J. M.; Wang, J.; Pan, C.-M.; Malins, L.
R.; Prieto, L.; Brandt, T. A.; Collins, M. R.; Gallego, G. M.; Sach, N.
W.; Spangler, J. E.; Zhu, H.; Zhu, J.; Baran, P. S. Strain-release
amination. Science 2016, 351, 241−246.
(10) For recent selected synthetic applications of [1.1.1]propellane,
see: (a) Kanazawa, J.; Maeda, K.; Uchiyama, M. Radical Multi-
component Carboamination of [1.1.1]Propellane. J. Am. Chem. Soc.
2017, 139, 17791−17794. (b) Makarov, I. S.; Brocklehurst, C. E.;
Karaghiosoff, K.; Koch, G.; Knochel, P. Synthesis of Bicyclo[1.1.1]-
pentane Bioisosteres of Internal Alkynes and para-Disubstituted
Benzenes from [1.1.1]Propellane. Angew. Chem., Int. Ed. 2017, 56,
12774−12777. (c) Caputo, D. F. G.; Arroniz, C.; Durr, A. B.;
̈
Mousseau, J. J.; Stepan, A. F.; Mansfield, S. J.; Anderson, E. A.
Synthesis and applications of highly functionalized 1-halo-3-
substituted bicyclo[1.1.1]pentanes. Chem. Sci. 2018, 9, 5295−5300.
(d) Shelp, R. A.; Walsh, P. J. Synthesis of BCP Benzylamines From 2-
Azaallyl Anions and [1.1.1]Propellane. Angew. Chem., Int. Ed. 2018,
57, 15857−15861. (e) Yu, S.; Noble, A.; Bedford, R. B.; Aggarwal, V.
K. Methylenespiro[2.3]hexanes via Nickel-Catalyzed Cyclopropana-
tions with [1.1.1]Propellane. J. Am. Chem. Soc. 2019, 141, 20325−
20334. (f) Yu, S.; Jing, C.; Noble, A.; Aggarwal, V. K. 1,3-
Difunctionalizations of [1.1.1]Propellane via 1,2-Metallate Rearrange-
ments of Boronate Complexes. Angew. Chem., Int. Ed. 2020, 59,
3917−3921. (g) Kim, J. H.; Ruffoni, A.; Al-Faiyz, Y. S. S.; Sheikh, N.
S.; Leonori, D. Divergent Strain-Release Amino-Functionalization of
[1.1.1]Propellane with Electrophilic Nitrogen-Radicals. Angew. Chem.,
Int. Ed. 2020, 59, 8225−8231. (h) Zhang, X.; Smith, R. T.; Le, C.;
McCarver, S. J.; Shireman, B. T.; Carruthers, N. I.; MacMillan, D. W.
C. Copper-mediated synthesis of drug-like bicyclopentanes. Nature
2020, 580, 220−226. (i) Wong, M. L. J.; Sterling, A. J.; Mousseau, J.
J.; Duarte, F.; Anderson, E. A. Direct catalytic asymmetric synthesis of
α-chiral bicyclo[1.1.1]pentanes. Nat. Commun. 2021, 12.
Polym. Sci., Part A: Polym. Chem. 2003, 41, 625−635. (b) Dilmac,̧ A.
M.; Spuling, E.; de Meijere, A.; Bräse, S. Propellanes − From a
Chemical Curiosity to “Explosive” Materials and Natural Products.
Angew. Chem., Int. Ed. 2017, 56, 5684−5718.
(4) For selected examples, see: (a) Agard, N. J.; Prescher, J. A.;
Bertozzi, C. R. A Strain-Promoted [3 + 2] Azide-Alkyne Cyclo-
addition for Covalent Modification of Biomolecules in Living
Systems. J. Am. Chem. Soc. 2004, 126, 15046−15047. (b) Zhang,
P.; Zhuang, R.; Wang, X.; Liu, H.; Li, J.; Su, X.; Chen, X.; Zhang, X.
Highly Efficient and Stable Strain-Release Radioiodination for Thiol
Chemoselective Bioconjugation. Bioconjugate Chem. 2018, 29, 467−
472. (c) Tokunaga, K.; Sato, M.; Kuwata, K.; Miura, C.; Fuchida, H.;
Matsunaga, N.; Koyanagi, S.; Ohdo, S.; Shindo, N.; Ojida, A.
Bicyclobutane Carboxylic Amide as a Cysteine-Directed Strained
Electrophile for Selective Targeting of Proteins. J. Am. Chem. Soc.
2020, 142, 18522−18531.
(11) For recent selected examples involving 1-azabicyclo[1.1.0]
butanes, see: (a) Fawcett, A.; Murtaza, A.; Gregson, C. H. U.;
Aggarwal, V. K. Strain-Release-Driven Homologation of Boronic
Esters: Application to the Modular Synthesis of Azetidines. J. Am.
Chem. Soc. 2019, 141, 4573−4578. (b) Gianatassio, R.; Kadish, D.
Direct Alkylation of 1-Azabicyclo[1.1.0]butanes. Org. Lett. 2019, 21,
2060−2063. (c) Musci, P.; von Keutz, T.; Belaj, F.; Degennaro, L.;
Cantillo, D.; Kappe, O.; Luisi, R. Flow Technology for Telescoped
Generation, Lithiation and Electrophilic (C3) Functionalization of
Highly Strained 1-Azabicy-clo[1.1.0]butanes. Angew. Chem., Int. Ed.
2021, 60, 6395−6399. (d) Gregson, C. H. U.; Noble, A.; Aggarwal, V.
K. Divergent, Strain-Release Reactions of Azabicyclo[1.1.0]butyl
Carbinols: Semipinacol or Spiroepoxy Azetidine Formation. Angew.
Chem., Int. Ed. 2021, 60, 7360−7365.
(5) For selected reviews, see: (a) Hoz, S. In The Chemistry of the
Cyclopropyl Group; Rappoport, Z., Ed.; Wiley: New York, 1987; pp
1121−1191. (b) Wiberg, K. B.; Waddell, S. T. Reactions of
[1.1.1]propellane. J. Am. Chem. Soc. 1990, 112, 2194−2216.
(c) Bartnik, R.; Marchand, A. P. Synthesis and Chemistry of
Substituted 1-Azabicyclo[1.1.0]butanes. Synlett 1997, 1997, 1029−
1039. (d) Levin, M. D.; Kaszynski, P.; Michl, J. Bicyclo[1.1.1]-
pentanes, [n]Staffanes, [1.1.1]Propellanes, and Tricyclo[2.1.0.02,5]-
pentanes. Chem. Rev. 2000, 100, 169−234. (e) Kanazawa, J.;
Uchiyama, M. Recent Advances in the Synthetic Chemistry of
Bicyclo[1.1.1]pentane. Synlett 2019, 30, 1−11. (f) Fawcett, A. Recent
advances in the chemistry of bicyclo- and 1-azabicyclo[1.1.0]butanes.
Pure Appl. Chem. 2020, 92, 751−765. (g) Turkowska, J.; Durka, J.;
Gryko, D. Strain release − an old tool for new transformations. Chem.
Commun. 2020, 56, 5718−5734. (h) Andresini, M.; Degennaro, L.;
Luisi, R. The renaissance of strained 1-azabicyclo[1.1.0]butanes as
(12) Fawcett, A.; Biberger, T.; Aggarwal, V. K. Carbopalladation of
C−C σ-bonds enabled by strained boronate complexes. Nat. Chem.
2019, 11, 117−122.
7652
https://doi.org/10.1021/jacs.1c03492
J. Am. Chem. Soc. 2021, 143, 7648−7654

Journal of the American Chemical Society
pubs.acs.org/JACS
Communication
(13) Ociepa, M.; Wierzba, A. J.; Turkowska, J.; Gryko, D. Polarity-
Reversal Strategy for the Functionalization of Electrophilic Strained
Molecules via Light-Driven Cobalt Catalysis. J. Am. Chem. Soc. 2020,
142, 5355−5361.
Carbonyls, Imines, and Related Polarized π Bonds. Chem. Rev. 2017,
ller, T.; Zell, D.; Cera, G.;
Warratz, S.; Ackermann, L. 3d Transition Metals for C−H Activation.
Chem. Rev. 2019, 119, 2192−2452.
117, 9163−9227. (h) Gandeepan, P.; Mu
̈
(14) (a) Bishop, K. C., III Transition metal catalyzed rearrange-
ments of small ring organic molecules. Chem. Rev. 1976, 76, 461−486.
For other recent synthetic applications of BCBs, see: (b) Panish, R.;
Chintala, S. R.; Boruta, D. T.; Fang, Y.; Taylor, M. T.; Fox, J. M.
Enantioselective Synthesis of Cyclobutanes via Sequential Rh-
catalyzed Bicyclobutanation/Cu-catalyzed Homoconjugate Addition.
J. Am. Chem. Soc. 2013, 135, 9283−9286. (c) Milligan, J. A.; Busacca,
C. A.; Senanayake, C. H.; Wipf, P. Hydrophosphination of
Bicyclo[1.1.0]butane-1-carbonitriles. Org. Lett. 2016, 18, 4300−
4303. (d) Wu, X.; Hao, W.; Ye, K.-Y.; Jiang, B.; Pombar, G.; Song,
Z.; Lin, S. Ti-Catalyzed Radical Alkylation of Secondary and Tertiary
Alkyl Chlorides Using Michael Acceptors. J. Am. Chem. Soc. 2018,
140, 14836−14843. (e) Silvi, M.; Aggarwal, V. K. Radical Addition to
Strained σ-Bonds Enables the Stereocontrolled Synthesis of Cyclo-
butyl Boronic Esters. J. Am. Chem. Soc. 2019, 141, 9511−9515.
(f) Ma, X.; Sloman, D. L.; Han, Y.; Bennett, D. J. A Selective
Synthesis of 2,2-Difluorobicyclo[1.1.1]pentane Analogues: “BCP-F2.
Org. Lett. 2019, 21, 7199−7203. (g) Bychek, R. M.; Hutskalova, V.;
Bas, Y. P.; Zaporozhets, O. A.; Zozulya, S.; Levterov, V. V.;
Mykhailiuk, P. K. Difluoro-Substituted Bicyclo[1.1.1]pentanes for
Medicinal Chemistry: Design, Synthesis, and Characterization. J. Org.
Chem. 2019, 84, 15106−15117. (h) Pratt, C. J.; Aycock, R. A.; King,
M. D.; Jui, N. T. Radical α-C−H Cyclobutylation of Aniline
Derivatives. Synlett 2020, 31, 51−54. (i) Ernouf, G.; Chirkin, E.;
Rhyman, L.; Ramasami, P.; Cintrat, J.-C. Photochemical Strain-
Release-Driven Cyclobutylation of C(sp3)-Centered Radicals. Angew.
Chem., Int. Ed. 2020, 59, 2618−2622. (j) Schwartz, B. D.; Zhang, M.
Y.; Attard, R. H.; Gardiner, M. G.; Malins, L. R. Structurally Diverse
Acyl Bicyclobutanes: Valuable Strained Electrophiles. Chem. - Eur. J.
2020, 26, 2808−2812. (k) Bennett, S. H.; Fawcett, A.; Denton, E. H.;
Biberger, T.; Fasano, V.; Winter, N.; Aggarwal, V. K. Difunctionaliza-
tion of C−C σ-Bonds Enabled by the Reaction of Bicyclo[1.1.0]butyl
Boronate Complexes with Electrophiles: Reaction Development,
Scope, and Stereochemical Origins. J. Am. Chem. Soc. 2020, 142,
16766−16775. (l) Guo, L.; Noble, A.; Aggarwal, V. K. α-Selective
Ring-Opening Reactions of Bicyclo[1.1.0]butyl Boronic Ester with
Nucleophiles. Angew. Chem., Int. Ed. 2021, 60, 212−216. (m) Yu, X.;
(17) For selected three-component reactions in the field of C−H
activation, see: (a) Boerth, J. A.; Ellman, J. A. Rh(III)-catalyzed
diastereoselective C−H bond addition/cyclization cascade of enone
tethered aldehydes. Chem. Sci. 2016, 7, 1474−1479. (b) Boerth, J. A.;
Hummel, J. R.; Ellman, J. A. Highly Stereoselective Cobalt(III)-
Catalyzed Three-Component C−H Bond Addition Cascade. Angew.
Chem., Int. Ed. 2016, 55, 12650−12654. (c) Boerth, J. A.; Ellman, J. A.
A Convergent Synthesis of Functionalized Alkenyl Halides through
Cobalt(III)-Catalyzed Three-Component C−H Bond Addition.
Angew. Chem., Int. Ed. 2017, 56, 9976−9980. (d) Zhang, S.-S.; Xia,
J.; Wu, J.-Q.; Liu, X.-G.; Zhou, C.-J.; Lin, E.; Li, Q.; Huang, S.-L.;
Wang, H. Three-Component Catalytic Carboxygenation of Activated
Alkenes Enabled by Bimetallic Rh(III)/Cu(II) Catalysis. Org. Lett.
2017, 19, 5868−5871. (e) Boerth, J. A.; Maity, S.; Williams, S. K.;
Mercado, B. Q.; Ellman, J. A. Selective and synergistic cobalt(III)-
catalysed three-component C−H bond addition to dienes and
aldehydes. Nat. Catal. 2018, 1, 673−679. (f) Tang, M.; Li, Y.; Han,
S.; Liu, L.; Ackermann, L.; Li, J. Rhodium(III)-Catalyzed C−H
Alkylation/Nucleophilic Addition Domino Reaction. Eur. J. Org.
Chem. 2019, 2019, 660−664. (g) Li, R.; Ju, C.-W.; Zhao, D.
Rhodium(III) vs. cobalt(III): a mechanistically distinct three-
component C−H bond addition cascade using a Cp*RhIII catalyst.
Chem. Commun. 2019, 55, 695−698. (h) Dongbang, S.; Shen, Z.;
Ellman, J. A. Synthesis of Homoallylic Alcohols with Acyclic
Quaternary Centers through CoIII-Catalyzed Three-Component C−
H Bond Addition to Internally Substituted Dienes and Carbonyls.
Angew. Chem., Int. Ed. 2019, 58, 12590−12594. (i) Pinkert, T.;
Wegner, T.; Mondal, S.; Glorius, F. Intermolecular 1,4-Carboamina-
tion of Conjugated Dienes Enabled by Cp*RhIII-Catalyzed C−H
Activation. Angew. Chem., Int. Ed. 2019, 58, 15041−15045. (j) Wang,
X.-G.; Li, Y.; Liu, H.-C.; Zhang, B.-S.; Gou, X.-Y.; Wang, Q.; Ma, J.-
W.; Liang, Y.-M. Three-Component Ruthenium-Catalyzed Direct
Meta-Selective C−H Activation of Arenes: A New Approach to the
Alkylarylation of Alkenes. J. Am. Chem. Soc. 2019, 141, 13914−13922.
(k) Maity, S.; Potter, T. J.; Ellman, J. A. α-Branched amines by
catalytic 1,1-addition of C−H bonds and aminating agents to terminal
alkenes. Nat. Catal. 2019, 2, 756−762. (l) Dongbang, S.; Ellman, J. A.
Synthesis of Nitrile Bearing Acyclic Quaternary Centers through
Co(III)-Catalyzed Sequential C−H Bond Addition to Dienes and N-
Cyanosuccinimide. Angew. Chem., Int. Ed. 2021, 60, 2135−2139.
(m) Brandes, D. S.; Sirvent, A.; Mercado, B. Q.; Ellman, J. A. Three-
Component 1,2-Carboamidation of Bridged Bicyclic Alkenes via RhIII-
Catalyzed Addition of C−H Bonds and Amidating Reagents. Org.
Lett. 2021, 23, 2836−2840.
Lubbesmeyer, M.; Studer, A. Oligosilanes as Silyl Radical Precursors
̈
through Oxidative Si−Si Bond Cleavage Using Redox Catalysis.
Angew. Chem., Int. Ed. 2021, 60, 675−679.
(15) (a) Walczak, M. A. A.; Wipf, P. Rhodium(I)-Catalyzed
Cycloisomerizations of Bicyclobutanes. J. Am. Chem. Soc. 2008, 130,
6924−6925. For further examples of transition metal catalyzed
cycloisomerizations of BCBs, see: (b) Walczak, M. A. A. Synthesis and
Reactions of Bicyclo[1.1.0]butanes; Ph.D. Thesis, University of
Pittsburgh, Pittsburgh, PA, 2010. (c) Walczak, M. A. A.; Krainz, T.;
Wipf, P. Ring-Strain-Enabled Reaction Discovery: New Heterocycles
from Bicyclo[1.1.0]butanes. Acc. Chem. Res. 2015, 48, 1149−1158.
(16) For selected reviews, see: (a) Chen, X.; Engle, K. M.; Wang, D.-
H.; Yu, J.-Q. Palladium(II)-Catalyzed C−H Activation/C−C Cross-
Coupling Reactions: Versatility and Practicality. Angew. Chem., Int. Ed.
2009, 48, 5094−5115. (b) Colby, D. A.; Bergman, R. G.; Ellman, J. A.
Rhodium-Catalyzed C−C Bond Formation via Heteroatom-Directed
C−H Bond Activation. Chem. Rev. 2010, 110, 624−655. (c) Lyons, T.
W.; Sanford, M. S. Palladium-Catalyzed Ligand-Directed C−H
Functionalization Reactions. Chem. Rev. 2010, 110, 1147−1169.
(d) Wencel-Delord, J.; Dröge, T.; Liu, F.; Glorius, F. Towards mild
metal-catalyzed C−H bond activation. Chem. Soc. Rev. 2011, 40,
4740−4761. (e) Yang, L.; Huang, H. Transition-Metal-Catalyzed
Direct Addition of Unactivated C−H Bonds to Polar Unsaturated
Bonds. Chem. Rev. 2015, 115, 3468−3517. (f) Wang, F.; Yu, S.; Li, X.
Transition metal-catalysed couplings between arenes and strained or
reactive rings: combination of C−H activation and ring scission.
Chem. Soc. Rev. 2016, 45, 6462−6477. (g) Hummel, J. R.; Boerth, J.
A.; Ellman, J. A. Transition-Metal-Catalyzed C−H Bond Addition to
(18) (a) de Graaff, C.; Ruijter, E.; Orru, R. V. A. Recent
developments in asymmetric multicomponent reactions. Chem. Soc.
Rev. 2012, 41, 3969−4009. (b) Cho, H. Y.; Morken, J. P. Catalytic
bismetallative multicomponent coupling reactions: scope, applica-
tions, and mechanisms. Chem. Soc. Rev. 2014, 43, 4368−4380.
(19) Hoegl, A.; Darabi, H.; Tran, E.; Awuah, E.; Kerdo, E. S. C.;
Habib, E.; Saliba, K. J.; Auclair, K. Stereochemical modification of
geminal dialkyl substituents on pantothenamides alters antimicrobial
activity. Bioorg. Med. Chem. Lett. 2014, 24, 3274−3277.
(20) Robinson, S. L.; Christenson, J. K.; Wackett, L. P. Biosynthesis
and chemical diversity of β-lactone natural products. Nat. Prod. Rep.
2019, 36, 458−475.
(21) Simmons, E. M.; Hartwig, J. F. On the Interpretation of
Deuterium Kinetic Isotope Effects in C−H Bond Functionalizations
by Transition-Metal Complexes. Angew. Chem., Int. Ed. 2012, 51,
3066−3072.
(22) For selected reviews, see: (a) Kuhl, N.; Schröder, N.; Glorius,
F. Formal SN-Type Reactions in Rhodium(III)-Catalyzed C−H Bond
Activation. Adv. Synth. Catal. 2014, 356, 1443−1460. (b) Song, G.; Li,
X. Substrate Activation Strategies in Rhodium(III)-Catalyzed
Selective Functionalization of Arenes. Acc. Chem. Res. 2015, 48,
7653
https://doi.org/10.1021/jacs.1c03492
J. Am. Chem. Soc. 2021, 143, 7648−7654

Journal of the American Chemical Society
pubs.acs.org/JACS
Communication
1007−1020. (c) Kazerouni, A. M.; McKoy, Q. A.; Blakey, S. B. Recent
advances in oxidative allylic C−H functionalization via group IX-
metal catalysis. Chem. Commun. 2020, 56, 13287−13300. See also ref
16e−g.
7654
https://doi.org/10.1021/jacs.1c03492
J. Am. Chem. Soc. 2021, 143, 7648−7654
