Helicenes of type 1, 2, and 3 were then prepared using
[9][BF4] as single common precursor. The diaza derivatives
1a–d (Scheme 2) were synthesized by treatment of [9][BF4]
with the corresponding anhydrous aliphatic amines (25 equiv,
Scheme 3. Reagents and reaction conditions: a) HNO3, 15 min, 258C;
b) NCS (3 equiv), CHCl3, AcOH, 15 h, 258C; c) NBS (3 equiv), CHCl3,
AcOH, 15 h, 258C; d) NIS (3 equiv), CHCl3, AcOH, 15 h, 258C; e) H2,
PtO2 (10 wt%), EtOH, 1 h, 258C; f) [Pd(PPh3)4] (10%), PhB(OH)2
(5 equiv), K2CO3 (5 equiv), 1,4-dioxane, 15 h, 808C; g) [Pd(PPh3)4]
Scheme 2. Reagents and reaction conditions: a) Anhydrous RNH2
(25 equiv), NMP, MW 1708C, 10 min; b) PPh3, DIAD, CH3COSH, THF,
258C; c) n-PrNH2, 498C, 30 min, then heated neat at 2008C, 5 min;
d) Pyr·HCl, 2248C, 2 min then ion exchange metathesis with HBF4.
DIAD=diisopropyl azodicarboxylate, MW=microwave, NMP=
N-methyl-2-pyrrolidone, THF=tetrahydrofuran.
ꢂ
(20%), CuI (30%), PhC CH (10 equiv), Et3N, 3 h, 908C. NBS=
N-bromosuccinimide, NCS=N-chlorosuccinimide, NIS=
N-iodosuccinimide.
NMP) and rapid heating under microwave irradiation (1708C,
10 min).[9] The resulting blue salts, 1a–d, were isolated in
moderate yields (43–47%). In the case of 1d, facile trans-
formation of the diol side chains into thioacetyl groups using
Mitsunobu-type conditions was achieved to give 1e (90%).
To obtain the purple azaoxa salt 2a, 9 was heated in neat
anhydrous n-propylamine at reflux (498C, 30 min). Then,
after complete evaporation of the amine in vacuo at 208C,
application of a burst of heat (2008C, 5 min) afforded the
mixed azaoxo derivative [2a][BF4] in 40% yield. Finally, rapid
treatment of [9][BF4] in molten Pyr·HCl (2248C, 2 min) and
ion-exchange metathesis (HBF4, 258C) afforded the red dioxo
helicene 3 as its BF4 salt in excellent yield (95%).
rings to react with nucleophiles,[11] [1a][BF4] was treated with
an excess of NaCN (3 equiv) in an open flask (Scheme 4).[12]
Full conversion was achieved but the resulting salt, [17][BF4],
bearing two nitrile groups at positions 5 and 13, was found to
With these derivatives in hand, in particular salt [1a][BF4],
orthogonal routes to the selective functionalization of the
helical core were developed. Electrophilic aromatic substitu-
tion reactions were first studied. A higher reactivity of the
median phenyl ring over the flanking naphthyl subunits was
predicted on account of the two donor nitrogen atoms
attached to this ring (instead of one for the naphthyl
groups). This assumption was rapidly confirmed. Treatment
of [1a][BF4] under nitration or halogenation reaction con-
ditions (Scheme 3) afforded the corresponding dinitro 10,
dichloro 11, and dibromo 12 derivatives in good to excellent
yields (77, 97, and 96% respectively). A perfect regioselec-
tivity was observed, wherein only positions 8 and 10 of the
helical core, ortho/para to the two N atoms, reacted under
these reaction conditions. Interestingly, with NIS, a milder
monoiodination was obtained (13, 90%). Moreover, addi-
tional derivatizations were feasible with 10 and 12. For
example, [10][BF4] was readily reduced (H2, cat. PtO2) to the
corresponding diamino derivative 14 (56%), and [12][BF4]
was reacted under Suzuki–Miyaura and Sonogashira condi-
tions to yield the corresponding diphenyl 15 (69%) and
diphenylethynyl 16 (62%) derivatives.[10]
Scheme 4. a) NaCN (3 equiv), DMF, 60 h, 258C; b) n-PrNH2, 16 h,
258C; c) TMSN3 (3 equiv), Bu2SnO (20%), PhCl, 16 h, 608C.
DMF=N,N-dimethylformamide, TMS=trimethylsilyl.
be sensitive to purification conditions (SiO2, 17%). A similar
reactivity was obtained in the treatment of [12][BF4] with
n-PrNH2 (neat, 258C) to afford the trisubstituted [18][BF4] in
good yield (74%). These vicarious nucleophilic substitutions
afford, therefore, another means by which to modify the
helical core under orthogonal (nucleophilic oxidative rather
than electrophilic) conditions.[13] Salt [17][BF4] can be further
transformed by reaction with trimethylsilyl azide to obtain the
bis(tetrazole) analogue [19][BF4] (60%).
Crystals of [12][BF4] were grown by slow diffusion of Et2O
into a CH2Cl2 solution. Structural analysis by X-ray diffrac-
tion revealed, as expected, a helical conformation of the
ortho-condensed framework (Figure 2).[14] The compound 12
presents a larger helical pitch (3.31 ꢀ) and angle (64.58)
between the two mean planes defined by the edge rings in
Alternatively, taking into consideration the cationic
character of the compounds 1 and the propensity of naphthyl
