Organic Process Research & Development 2003, 7, 559−570
Process Research of (R)-Cyclohexyl Lactic Acid and Related Building Blocks:
A Comparative Study‡
Thomas Storz* and Peter Dittmar
Process Research and DeVelopment, Chemical and Analytical DeVelopment; NoVartis Pharma AG,
CH-4002 Basel, Switzerland
Pierre Franc¸ois Fauquex and Philippe Marschal
Biotechnology DeVelopment, NoVartis Pharma AG, CH-4002 Basel, Switzerland
Willy Urs Lottenbach and Heinz Steiner
Hydrogenation and High-Pressure SerVice, SolVias AG, CH-4002 Basel, Switzerland
Abstract:
leukocyte surface via interaction with the common tetrasac-
charide epitope sialyl Lewisx (sLex, 1).5 Analogues of sialyl
Lewisx have therefore been proposed as potential therapeutics
for a host of inflammatory disorders (e.g., ischemia/reper-
fusion injury following organ transplantation).6 The sLex
analogue 2 (Figure 1) was discovered by Thoma et al. at
Novartis Pharmaceuticals Corporation.7 Compared to sLex,
2 showed a 30-fold improved affinity in a cell-free E-selectin-
ligand binding assay.8
As a simplified analogue of SLex, 2 features the (S)-
cyclohexyl lactic acid moiety as a substitute9 for the
structurally more complex N-acetylneuraminic acid residue.
The former is introduced into the trisaccharide precursor of
2 via nucleophilic displacement reaction of a 2-O-sulfonyl
substituted (R)-cyclohexyl lactic acid building block. Enan-
tiomerically pure (R)-cyclohexyl lactic acid10 is not com-
mercially available. Hence, an efficient synthetic access to
this hydroxy acid needed to be elaborated.
(S)-Cyclohexyl lactic acid is a component of the selective
E-selectin inhibitor 2 ((S)-cHexLact-2-O-(3-Galâ(1f3)ddGlc-
(4f1)rFuc). We describe the evaluation of various synthetic
routes to this building block: (A) diazotation of phenylalanine
followed by phenyl ring hydrogenation; (B) phenyl ring
hydrogenation of phenyl alanine followed by diazotation; (C)
acidic hydrolysis of the cyanohydrin derived from phenylac-
etaldehyde, enantiomeric resolution of the resulting, racemic
phenyl lactic acid via diasteromeric salt formation and phenyl
ring hydrogenation; (D) enantioselective dihydroxylation of a
cinnamate ester, followed by hydrogenation of the benzylic
hydroxy group and the aromatic nucleus; (E) enantioselective
biocatalytic reduction of phenylpyruvic acid, followed by phenyl
ring hydrogenation. The development of (2R)-2-O-(4-nitrophe-
nyl)sulfonyl-cyclohexyl lactic acid p-bromobenzylester 21 as a
buidling block with improved crystallinity and stability is also
described.
Results and Discussion
(A) The Medicinal Chemistry Synthesis. The synthesis
(Scheme 1)7 of the (R)-cyclohexyl lactic acid building
block 6 started from commercially available (R)-3-phenyl
lactic acid10b (3). Hydrogenation of the aromatic nucleus,
followed by benzyl ester formation with CsCO3/BnBr and
O-sulfonylation with triflic anhydride, gave the building
block 6 in three steps and 60% total yield after two
chromatographies. The triflate 6 proved to be an unstable
oil at room temperature and resisted all attempts to crystal-
lization.
Introduction
Excessive leukocyte influx from blood vessels into the
surrounding tissues has been linked to acute or chronic
reactions as observed in reperfusion injuries, psoriasis, stroke,
rheumatoid arthritis or respiratory diseases.1-3 Selectin-
dependent leukocyte adhesion is the first step in the cascade
of events that leads to the extravasation of leukocytes.4 In
particular, E-Selectin on the surface of the endothelial blood
vessel walls recognizes complex glycoprotein ligands on the
‡ Dedicated to Professor Andrea Vasella on the occasion of his 60th birthday.
* To whom correspondence should be addressed. Current address: Amgen
Inc., One Amgen Center Drive, Thousand Oaks, CA 91320-1799, U.S.A.
E-mail: tstorz@amgen.com.
(5) Kansas, G. S. Blood 1996, 88, 3259.
(6) For a review, see: Simanek, E. E.; McGarvey, G. J.; Jablonowsky, J. A.;
Wong, C.-H. Chem. ReV. 1998, 98, 833.
(7) Thoma, G.; Kinzy, W.; Bruns, C.; Patton, J. T.; Magnani, J. L.; Ba¨nteli, R.
J. Med. Chem. 1999, 42, 4909.
(8) Ba¨nteli, R.; Herold, P.; Bruns, C.; Patton, J. T.; Magnani, J. L.; Thoma, G.
HelV. Chim. Acta 2000, 83, 2893.
(9) Kolb, H. C.; Ernst, B. Chem. Eur. J. 1997, 1571.
(10) (a) v. Braun, J.; Nelles, J. Chem. Ber. 1933, 66, 1464 (racemate). (b) Bajusz,
S.; Baraba´s, E.; Fauszt, I.; Fehe´r, A.; Horva´th, Gy.; Juha´sz, A.; Szabo´, A.
G.; Sze´ll, E. Bioorg. Med. Chem. 1995, 3, 1079 (R-enantiomer).
(1) Mousa, S. A. Drugs Fut. 1996, 21, 283.
(2) Mousa, S. A.; Cheresh, D. A. Drug DiscoVery Today 1997, 2, 187.
(3) Cines, D. B.; Pollak, E. S.; Buck, C. A.; Loscalzo, J.; Zimmermann, G. A.;
McEver, R. P.; Pober, J. S.; Wick, T. M.; Konkle, B. A.; Schwartz, B. S.;
Barnathan, E. S.; McCrae, K. R.; Hug, B. A.; Schmidt, A.-M.; Stern, D.
M. Blood 1998, 91, 3527.
(4) Spertini, O.; Luscinskas, F. W.; Gimbrone, M. A.; Tedder, T. F. J. Exp.
Med. 1992, 175, 1789.
10.1021/op030202q CCC: $25.00 © 2003 American Chemical Society
Published on Web 06/27/2003
Vol. 7, No. 4, 2003 / Organic Process Research & Development
•
559

Figure 1.
Table 1. Aromatic ring hydrogenation of phenyl lactic acid: catalyst screening
(concentration, mmol)
batch size (%)
catalyst,
solvent (%),
reaction time, h
entry
1
H2 pressure
temperature (°C)
yield (%)/purity (%)
12.0
(5)
5% Rh/C
(10 wt %/wt)
15 bar
EtOH (94)
50
2
92.9 (GLC)
conversion: 99.8
2
3
4
5
300.9
(5)
5% Rh/C
(10 wt %/wt)
15 bar
10% Ru/C
(15 wt %/wt)
15 bar
5% Rh/C
(10 wt %/wt)
15 bar
10% Ru/C
(10 wt %/wt)
30 bar
EtOH (94)
50
5
99.6, crude
12.0
(5)
AcOH
50-70-100
59 h
89.4% (GLC)
conversion: 99.9%
12.0
(14.3)
AcOH/H2O
(8:6) 50-80
108
70.6 (GLC)
conversion: 99.9
12.0
(13.5)
1 M NaOH
60
16
7.0 (GLC)
conversion: 13.2
Scheme 1. Medicinal chemistry synthesis
nucleus of the resulting phenyl lactic acid over a more
economic catalyst: Although literature reports11-14 had
claimed that diazotation of (R)-phenyl alanine to (R)-phenyl
lactic acid 3 proceeds under complete retention of config-
uration (only optical rotation values were cited as proof of
enantiomeric purity), we invariably observed a loss of
enantiomeric purity as unequivocally determined by HPLC
analysis on a chiral column (2-5%, see Experimental
Section). The hydrogenation of the aromatic nucleus in 3
was investigated under various conditions (Table 1). In
general, none, or only insignificant loss (<0.1%) of enan-
tiomeric purity was observed (see typical result in Experi-
mental Section).
(B) Process R&D. Surprisingly, there is only one
literature report for the production of (R)-cyclohexyl lactic
acid (4): aromatic ring hydrogenation of D-(+)-3-phenyl
lactic acid (3) over a platinum oxide catalyst.10b Due to the
high price and limited availability of 3, and the unfavorable
physicochemical properties combined with the instability of
the triflate 6, we aimed to find a more economic access to
4 and, ultimately, also to replace the triflate 6 by a crystalline,
more stable activated building block.
In our first strategy, (R)-phenyl alanine (7) was chosen
as starting material. Two variants were investigated:
(A) diazotation of phenylalanine under retention of
configuration,11 followed by hydrogenation of the aromatic
The best overall results of approach A are summarized
in Scheme 2.
(B) Hydrogenation of the aromatic nucleus of phenyl-
alanine,15 followed by diazotation of the resulting cyclohexyl
alanine 8 under retention of configuration: The hydrogena-
tion of phenylalanine showed less variability than the
corresponding hydrogenation of phenyl lactic acid (Table 2).
(12) Yamada, S.-I.; Koga, K.; Juang, T. M.; Achiwa, K. Chem. Lett. 1976, 927.
(13) Terashima, S.; Tseng, C. C.; Koga, K. Chem. Pharm. Bull. 1979, 27, 747.
(14) Urban, F. J.; Moore, B. S. J. Heterocycl. Chem. 1992, 29, 431.
(15) Bain, J. D.; Wacker, D. A.; Kuo, E. E.; Chamberlin, A. R. Tetrahedron
1991, 47, 2389.
(11) Cohen, S. G.; Weinstein, S. Y. J. Am. Chem. Soc. 1964, 86, 5326.
560
•
