Phosphorus-containing bisazomethines based on terephthalic aldehyde as tetradentate ligand of new type

Full text of DOI:10.1134/S1070363214060334

ISSN 1070-3632, Russian Journal of General Chemistry, 2014, Vol. 84, No. 6, pp. 1249–1250. © Pleiades Publishing, Ltd., 2014.
Original Russian Text © R.Kh. Bagautdinova, A.P. Vanichkina, E.M. Pudovik, A.R. Burilov, M.A. Pudovik, 2014, published in Zhurnal Obshchei Khimii,
2014, Vol. 84, No. 6, pp. 1049–1050.
LETTERS
TO THE EDITOR
Phosphorus-containing Bisazomethines Based on Terephthalic
Aldehyde as Tetradentate Ligand of New Type
R. Kh. Bagautdinovaa, A. P. Vanichkinaa, E. M. Pudovikb, A. R. Burilova, and M. A. Pudovika
a Arbuzov Institute of Organic and Physical Chemistry, Kazan Scientific Center of the Russian Academy of Sciences,
ul. Akademika Arbuzova 8, Kazan, Tatarstan, 420088 Russia
e-mail: pudovik@iopc.ru
b Kazan (Volga) Federal University, Kazan, Tatarstan, Russia
Received April 10, 2014
Keywords: terephthalic aldehydes, bisazomethines, phosphorylation
DOI: 10.1134/S1070363214060334
Recently, hydroxyl-containing bisazomethines and
complexes based on them attract a great interest. A
wide range of metals including biogenic Zn(II), Cu(II),
Cd(II), Co(II), Ni(II), Fe(III), Pd(II), Zr(IV), U(II) was
used to obtain metal complexes catalyzing enantio-
selective epoxidation of unsubstituted olefins [1, 2],
selective ortho-hydroxylation of phenols [3], epoxida-
tion of styrene [4], oxidation of styrene to carbonyl
compounds under the action of hydrogen peroxide [5],
oxidation of alcohols to carbonyl compounds [6],
oxidation of organic sulfides to sulfoxides [7],
heterogeneous hydrogenation of alkenes and alkynes
[8], butadiene polymerization [9]. Some of metal
complexes showed high fungicidal, antibacterial,
antimicrobial, anticancer activity [10–15].
ligands for metal complexes. We performed phospho-
rylation of diimine I with P(V) acid chlorides IIa–IIc
in the presence of a base to obtain diphosphorylated
derivatives IIIa–IIIc. The latter are promising tetra-
dentate ligands. Compounds IIIa–IIIc are crystalline
substances. Their composition and structure were
proved by elemental analysis, mass spectrometry, IR,
1H and 31P NMR spectroscopy methods (Scheme 1).
1,2-Phenylenebis(methanylidene)bis(azanylidene)-
bis(2,1-phenylene) bis(diphenylphosphinate) (IIIa).
To a suspension of 0.30 g of diimine I and 0.2 g of
triethylamine in 10 mL of anhydrous benzene was
added dropwise a solution of 0.45 g of diphenyl-
chlorophosphine oxide in 5 mL of benzene. After 12 h,
the precipitated triethylamine hydrochloride was se-
parated, and the solvent was removed. To the residue
was added 20 mL of hexane, and then the precipitate
At the same time there are no data on the O-
phosphorylated bisazomethines, which can be used as
Scheme 1.
HC
CH
HC
CH
N
N
N
N
Et3N
+ R2P(X)Cl
HO
O
OH
O
P(X)R2
P(X)R2
I
IIа−IIc
IIIа−IIIc
R = Ph, X=O (а); R = Ph, X = S (b); R = OPh, X = O (c).
1249

1250
BAGAUTDINOVA et al.
was separated. Yield 0.48 g (71%), mp 201–204°C. 1H
NMR spectrum (CDCl3), δ, ppm: 6.50–8.07 m (32H,
Ph), 8.44 s (2H, CH=N). 31P NMR spectrum (CDCl3):
δР 30.81 ppm. Mass spectrum (MALDI-TOF): m/z
716. Found P, %: 9.06. C44H34N2O4P2. Calculated P,
%: 8.86.
ACKNOWLEDGMENTS
This work was supported by the Russian Founda-
tion for Basic Research (grant no. 12-03-00204).
REFERENCES
1,2-Phenylenebis(methanylidene)bis(azanylidene)-
bis(2,1-phenylene) bis(diphenylthiooxophosphinate)
(IIIb). To a suspension of 0.30 g of diimine I and 0.2 g
of triethylamine in 10 mL of anhydrous benzene was
added dropwise a solution of 0.48 g of diphenyl chloro-
thiophosphinate. The reaction mixture was refluxed for
15 h. The resulting triethylamine hydrochloride was
separated, and the solvent was removed. To the residue
was added 10 mL of ethanol, and the precipitate was
separated. Yield 0.47 g (66%), mp 176–179°C. IR
1. Wei Zhang, Loebach, J.L., Wilson, S.R., and Jacobsen, E.N.,
J. Am. Chem. Soc., 1990, vol. 112, no. 7, p. 1002.
2. Geon Joong Kim, and Ji-Hoon Shin, Tetrahedron Lett.,
1999, vol. 40, no. 37, p. 6827.
3. Karakhanov, E.A., Maximov, A.L., Kardasheva, Yu.S.,
Skorkin, V.A., Kardashev, S.V., Ivanova, E.A., Lurie-
Luke, E.S., Seeley, J.A., and Cron, S.L., Industr. Eng.
Chem. Res., 2010, vol. 49, no. 10, p. 4607.
4. Zhang Zhang Ye Zhi-Wu, Zhang Min, and Fan Chun Yan,
Synth. React. Inorg. Metal-Org. Nano-Metal Chem.,
2008, vol. 38, no. 4, p. 352.
1
spectrum (KBr), ν, cm–1: 1586 (Ph), 1616 (C=N). H
NMR spectrum (CDCl3), δ, ppm: 7.38–8.03 m (32H,
Ph), 8.39 s (2H, CH=N). 31P NMR spectrum
[(CD3)2CO]: δР 80.81 ppm. Mass spectrum (MALDI-
TOF): m/z 749. Found, %: P 8.66; S 8.90.
C44H34N2O2P2S2. Calculated, %: P 8.27; S 8.56.
5. Velusamy, S. and Punniyamurthy, T., Eur. J. Org.
Chem., 2003, no. 20, p. 3913.
6. Adam, W., Gelalcha, F.G., Saha-Moeller, C.R., and
Stegmann, V.R., J. Org. Chem., 2000, vol. 65, no. 7,
p. 1915.
1,2-Phenylenebis(methanylidene)bis(azanylidene)-
(2,1-phenylene) bis(diphenylphosphate) (IIIc). To a
suspension of 0.30 g of diimine I and 0.2 g of triethyl-
amine in 10 mL of anhydrous benzene was added
dropwise a solution of 0.51 g of diphenyl chloro-
phosphate. The next day, the precipitated triethylamine
hydrochloride was separated, and the solvent was
removed. To the residue was added 20 mL of hexane,
and the precipitate was separated. Yield 0.7 g (95%),
7. Sevel, R., Rajagopal, S., Srinivasan, C., Alhaji, N.I., and
Chellamani, A., J. Org. Chem., 2000, vol. 65, no. 11,
p. 3334.
8. Kerr, J.M. and Suckling, C.J., Tetrahedron Lett., 1998,
vol. 29, no. 43, p. 5545.
9. Endo Kiyoshi, and Nakatani Kenji, Nippon Gomu
Kyokaishi, 2007, vol. 80, no. 1, p. 13.
10. Mashaly Mahmoud, M., Abd-Elwahab, Z.H., and
Faheim, A.A., Synth. React. Inorg. Metal-Org. Nano-
Metal Chem., 2004, vol. 34, no. 2, p. 233.
1
mp 114–115°C. H NMR spectrum [(CD3)2CO], δ,
ppm: 7.14–8.11 m (32H, Ph), 8.65 s (2H, CH). 31P
NMR spectrum [(CD3)2CO]: δР –17.70 ppm. Mass spec-
trum (MALDI-TOF): m/z 781. Found P, %: 7.92.
C44H34N2O8P2. Calculated P, %: 7.94.
11. El-Wahab, Z.H., Mashaly, M.M., Salman, A.A., El-
Shetary, B.A., and Faheim, A.A., Spectrochim. Acta
(A), 2004, no. 12, p. 2861.
12. Yildiz, M, Duelger, B, Koyuncu, S.Y., and Yapici, B.M.,
The IR spectra were recorded on a Bruker Vector-
22 spectrometer in the range of 400–3600 cm–1 from
mulls in mineral oil. The H NMR spectra were taken
on an Avance 600 instrument operating at 600.13 MHz
relative to the signals of residual protons of the deute-
rated solvent (d-chloroform). The 31P NMR spectra
were registered on a Bruker MSL-400 Fourier spec-
trometer (100.62 MHz). Mass spectra (MALDI-TOF)
were obtained on an Ultraflex III instrument (p-nitro-
aniline matrix).
J. Indian Chem. Soc., 2004, vol. 81, no. 1, p. 7.
13. Ahmed, A.K.S., Salam, M.A., Sattar Anowara, Alam, S.B.,
and Mridha, A.U., J. Bangladesh Chem. Soc., 2003,
vol. 5, no. 1, p. 73.
1
14. Abdallah, S.M., Mohamed, G.G., Zayed, M.A., and El-
Ela, M.S., Spectrochim. Acta (A), 2009, vol. 73, no. 5,
p. 833.
15. Ansari, K.I., Grant, J.D., Kasiri, S., Woldemariam, G.,
Shrestha, B., and Mandal, S.S., J. Inorg. Biochem.,
2009, vol. 103, no. 5, p. 818.
RUSSIAN JOURNAL OF GENERAL CHEMISTRY Vol. 84 No. 6 2014
