Communication
tions that provide several intermediates that can potentially be
of value in the design of a range of unnatural aminocyclitols,
such as 2-deoxystreptamine analogues and other condura-
mines.
1S,4R-(5-Oxo-7-oxa-bicyclo[4.1.0]hept-2-yl)-carbamic acid
tert-butyl ester
Tetra-n-propylammonium perruthenate (0.66 g, 1.88 mmol) and ac-
tivated 4 ꢁ molecular sieves (19 g) were added to a solution of 15
(8.62 g, 37.62 mmol) in dichloromethane (268 mL). Solid 4-methyl-
morpholine N-oxide (6.61 g, 56.43 mmol) was added, and the slurry
was stirred at RT for 8 h. The reaction was poured onto a bed of
silica gel and eluted with dichloromethane. The eluent was con-
centrated, and the crude product was purified by using silica-gel
flash chromatography (30% ethyl acetate/hexanes) to afford 7.36 g
(86%) of the title compound as solid. A white Rf =0.25 in 20%
ethyl acetate/hexanes; m.p. 86–888C; [a]2D3 = +178.0 (c 0.2,
Experimental Section
1S,4R- Benzoic acid 4-tert-butoxycarbonylamino-cyclohex-2-
enyl ester
To a flame-dried round-bottomed flask was added [(h3-C3H5)PdCl]2
(29.0 mg, 0.079 mmol), (S,S)-9 (164 mg, 0.2376 mmol), and diben-
zoate 8 (12.5 g, 39.62 mmol). The flask was the placed under re-
duced pressure (vacuum pump) for ten seconds and refilled with
Ar; this purging procedure was repeated three times to ensure
that no oxygen remained in the reaction vessel. After being placed
in an Ar atmosphere, degassed THF (17 mL) was added, and the
mixture was stirred for 10 min at RT. Freshly distilled azidotrime-
thylsilane (6.31 mL, 47.54 mmol) was added dropwise at 08C, and
the reaction was stirred at this temperature for 1.5 h. Water
(30 mL) was added to the reaction mixture followed by a dropwise
addition of solution of trimethyl phosphine (100 mL of a 1m solu-
tion in THF) over 2 h. Upon complete disappearance of the inter-
mediate allylic azide, triethylamine (13.0 mL) and di-tert-butyl-dicar-
bonate (13.3 g, 66.66 mmol) were added, and the reaction was
stirred for 12 h at RT. The reaction was diluted with diethyl ether
(300 mL) and washed with saturated sodium bicarbonate, brine,
dried (MgSO4), and concentrated. Silica-gel chromatography by
using 10% ethyl acetate/hexanes gave 10.69 g (87%) of the title
compound as oil. A clear Rf =0.5 in 20% ethyl acetate/hexanes;
[a]2D4 =À75.84 (c 0.18, CH2Cl2); 1H (400 MHz, CDCl3): d=8.03 (dd,
J=8.0, 1.6 Hz, 2H), 7.54 (dd, J=8.0, 8.0 Hz, 1H), 7.42 (dd, J=
8.0 Hz, 2H), 5.93 (ddd, J=10.1, 3.4, 1.0 Hz, 1H), 5.89 (dd, J=10.1,
2.4 Hz, 1H), 5.42 (m, 1H), 4.60 (bd, J=7.9 Hz, 1H), 4.19 (m, 1H),
2.01–1.89 (m, 3H), 1.72 (m, 1H), 1.4 ppm (s, 9H); 13C NMR (75 MHz,
CDCl3): d=166.1, 155.2, 133.8, 133.0, 130.4, 129.6, 128.4, 128.1,
79.6, 67.4, 46.0, 28.4, 26.0 ppm; IR (thin film): n˜max =3411, 3315,
3065, 3027, 2943, 2867, 1702, 1530, 1246, 1064 cmÀ1; HRMS (EI,
[MC18H23NO4À(C4H9)]+) calcd for C14H15NO4: 261.1001; found:
261.1010.
1
CH2Cl2); H NMR (400 MHz, CDCl3): d=4.86 (d, J=9 Hz, 1H), 4.25 (q,
J=9 Hz, 1H), 3.65 (d, J=4 Hz, 1H), 3.29 (d, J=4 Hz, 1H), 2.53 (ddd,
J=18.0, 4.0, 4.0 Hz, 1H), 2.18 (ddd, J=18.0, 4.0, 4.0 Hz, 1H), 1.85
(m, 1H), 1.46 ppm (s, 9H); 13C NMR (125 MHz, CDCl3): d=203.2,
155.1, 80.2, 57.5, 55.9, 46.3, 34.9, 28.3, 22.9 ppm; IR (thin film):
n˜max =3331, 2976, 1693, 1524, 1455, 1391, 1365, 1306, 1249, 1167,
1056, 1007, 957, 876 cmÀ1; HRMS (EI, [MC11H17NO4À(C4H9)]+) calcd
for C7H9NO4: 171.0532; found: 171.0539; elemental analysis calcd
(%) for C7H9NO4: C 58.14, H 7.54, N 6.16; found C 57.96, H 7.54, N
6.04.
Acknowledgements
We thank NIH-GM and the National Science Foundationfor the
generous support of our programs. S.M. thanks Eli Lilly (for
a graduate fellowship). Palladium salts were generously sup-
plied by Johnson-Matthey. The authors would like to thank Vic-
tor G. Young, Jr., and the X-Ray crystallographic laboratory for
elucidating.
Keywords: aminoglycoside · azidization · conduramines ·
palladium · synthetic methods
[3] a) S. Hanessian, K. Pachamuthu, J. Szychowski, A. Giguere, E. E. Swayze,
2010, 20, 7097; b) S. Hanessian, S. Adhikari, J. Szychowski, K. Pachamu-
b) M.-P. Mingeot-Leclerco, P. M. Tulkens, Antimicrob. Agents Chemother.
1999, 43, 1003; c) L. P. Kotra, J. Haddad, S. Mobashery, Antimicrob.
[6] a) S. J. Sucheck, W. A. Greenberg, T. J. Tobert, C.-H. Wong, Angew. Chem.
Kotra, B. Llano-Sotelo, C. Kim, E. F. Azucena Jr., M. Liu, S. B. Vakulenko,
Greenberg, E. S. Priestley, P. S. Sears, P. B. Alper, C. Rosenbohm, M. Hen-
[7] a) G. F. Busscher, van S. A. M. W. den Broek, F. P. J. T. Rutjes, F. L. van
Littlefield, B. K. Ayida, D. Vourloumis, G. C. Winters, M. Takahashi, S.
1S,4R-(5-Hydroxy-7-oxa-bicyclo[4.1.0]hept-2-yl)-carbamic
acid tert-butyl ester
To a solution of alcohol 14 (56 mg, 0.26 mmol) in anhydrous
chloroform (20 mL) was added m-chloroperoxybenzoic acid
(50 mg, 0.29 mmol). The reaction was stirred at RT for 24 h (con-
sumption of starting material was monitored by GC). Upon com-
pletion, the reaction mixture was washed with saturated sodium
hydrogen carbonate, brine, dried (MgSO4), and concentrated to
afford 60 mg (99%) of title compound as a clear oil that slowly
crystallized to solid. A white Rf =0.7 in 100% ethyl acetate; [a]D26
=
1
+22.12 (c 2.2, CH2Cl2); H NMR (400 MHz, [D6]DMSO) : d=6.72 (d,
J=8.0 Hz), 4.82 (d, J=5.3 Hz, 1H), 3.82 (m, 1H), 3.74 (m, 1H), 3.24
(dd, J=4.0 Hz, 1H), 3.17 (dd, J=4.0, 2.6 Hz, 1H), 1.48–1.27 ppm (m,
4H), 1.38 (s,1H); 13C NMR (100 MHz, [D6]DMSO): d=155.1, 77.7,
64.6, 56.1, 54.7, 44.7, 28.2, 26.4, 24.7 ppm; IR (thin film) n˜max =3348,
2977, 2938, 2871, 1702, 1506, 1456, 1392, 1367, 1326, 1249, 1170,
1068, 1003, 929, 895, 848, 776 cmÀ1; HRMS (EI, [M]+) calcd for
C11H19NO4: 229.1314; found: 229.1315. The stereochemistry of the
desired product was initially based on hydrogen-bond-directed ep-
oxidation and later assigned by X-ray analysis of a downstream in-
termediate.[15]
