Tandem Pummerer-Diels-Alder Reaction Sequence
mers as a white solid: mp 144-145 °C; IR (neat) 3066, 1461,
J . Org. Chem., Vol. 61, No. 11, 1996 3713
In a flame-dried 250 mL round-bottomed flask equipped
with an addition funnel, was dissolved 4.4 mL (29.4 mmol) of
1
1449, 1323, 1152 cm-1; H-NMR (CDCl3, 300 MHz) δ 1.34 (t,
3H, J ) 7.5 Hz), 2.83 (t, 2H, J ) 7.5Hz), 4.52 (d, 2H, J ) 4.3
Hz), 4.86 (d, 2H, J ) 4.3 Hz), 7.07-7.71 (m, 17H), 7.03 (m,
2H); 13C-NMR (75 MHz, CDCl3) δ 15.2, 24.4, 71.8, 73.7, 89.3,
93.4, 120.1, 123.7, 126.2, 127.9, 128.0, 128.1, 128.5, 128.6,
128.6, 128.8, 129.1, 133.3, 134.2, 138.7, 139.9, 141.6, 145.1,
148.6. HRMS (FAB) Calcd for C30H26O5S3: 563.1021.
Found: 563.1033 (M + H+).
1,8-diazabicyclo[5.4.0]undec-7-ene in 100 mL of benzene.
A
2.2 mL (29.7 mmol) sample of ethanethiol was added to the
colorless solution. To this mixture was added dropwise a
solution of 8.60 g (29.3 mmol) of dibromide 32 in 50 mL of
benzene which caused the precipitation of the DBU hydro-
bromide salt. The mixture was stirred overnight, diluted with
H2O, and extracted with CH2Cl2. The organic extracts were
washed with 10% NaOH, dried over Na2SO4, and concentrated
under reduced pressure to give 7.90 g (98%) of 5-bromo-6-
ethylthiomethylbenzo[1,3]dioxole as a clear light yellow oil: IR
P r ep a r a tion of 4-(Eth ylth io)-2,9-d ip h en ylben zo[f]iso-
in d ole-1,3-d ion e (26). Cycloadduct 21 was also obtained
using trifluoroacetic anhydride as the Pummerer promotor at
25 °C. To a solution of 1.15 g (4.22 mmol) of sulfoxide 18, 1.06
g (6.12 mmol) of N-phenylmaleimide, and 0.69 g (6.77 mmol)
of triethylamine in 15 mL of CH2Cl2 was added dropwise a
solution of 1.30 g (6.19 mmol) of trifluoroacetic anhydride in
3 mL of CH2Cl2 at 0 °C. After stirring at rt for 1 h, the mixture
was washed successively with 2 N HCl and H2O. The organic
layer was dried (Na2SO4) and concentrated in vacuo to leave
cycloadduct 21 as a single diastereomer. Treatment of a
sample of 21 with 5 mg of p-TsOH in CH2Cl2 for 18 h at rt
resulted in the loss of water producing 4-(ethylthio)-2,9-
diphenylbenzo[f]isoindole-1,3-dione (26) (72%) as pale yellow
solid: mp 169-170 °C; IR (KBr) 3050, 1764, 1718, 1490, 1375
cm-1; 1H-NMR (CDCl3) δ 1.29 (t, 3H, J ) 7.4 Hz), 3.22 (q, 2H,
J ) 7.4 Hz), 7.32-7.83 (m, 13H), 9.13 (d, 1H, J ) 8.4 Hz);
13C-NMR (CDCl3) δ 15.2, 31.5, 124.1, 126.7, 127.9, 128.0, 128.1,
128.4, 128.4, 128.7, 128.9, 129.3, 129.4, 129.6, 131.7, 134.5,
135.6, 138.3, 140.6, 165.6. Anal. Calcd for C26H19NO2S: C,
76.26; H, 4.68; N, 3.42. Found: C, 75.98; H, 4.71; N, 3.32.
P r ep a r a tion of 4-(Eth ylth io)-1-oxo-2-p h en yl-1,2-d ih y-
d r on a p h t h a len e-2,3-d ica r b oxylic Acid Dim et h yl E st er
(29). A 421 mg (1.55 mmol) sample of sulfoxide 18 was treated
with 950 µL (7.73 mmol) of DMAD in 3 mL of Ac2O to give
230 mg (38%) of cycloadduct 29 as a yellow oil: IR (neat) 3064,
1771, 1740, 1719, 1669, 1447 cm-1; 1H-NMR (CDCl3, 300 MHz)
δ 1.25 (t, 3H, J ) 7.4 Hz), 2.86 (q, 2H, J ) 7.4 Hz), 3.35 (s,
3H), 3.87 (s, 3H), 7.09 (d, 1H, J ) 7.7 Hz), 7.17 (d, 1H, J ) 7.3
Hz), 7.30-7.55 (m, 5H), 7.80 (d, 1H, J ) 7.7 Hz), 8.45 (d, 1H,
J ) 7.6 Hz); 13C-NMR (CDCl3, 75 MHz) δ 14.5, 30.6, 52.2, 64.6,
68.8, 127.7, 128.1, 128.2, 128.4, 128.6, 129.3, 129.4, 129.5,
130.9, 131.8, 133.8, 134.1, 134.4, 140.1, 166.1, 166.7. HRMS
(FAB) Calcd for C22H21O5S: 397.1110. Found: 397.1108 (M
+ H+).
(neat) 2970, 2925, 1503, 1450, 1231 cm-1 1H-NMR (CDCl3,
;
300 MHz) δ 1.29 (t, 3H, J ) 7.3 Hz), 2.51 (q, 2H, J ) 7.3 Hz),
3.77 (s, 1H), 5.96 (s, 1H), 6.89 (s, 1H), 6.99 (s, 1H); 13C-NMR
(CDCl3, 75 MHz) δ 14.6, 25.6, 36.0, 101.7, 110.1, 112.7, 114.6,
131.1, 147.1, 147.3.
In a flame-dried, 250 mL, three-necked, round-bottomed
flask equipped with a low temperature thermometer and septa
was dissolved 7.51 g (27.3 mmol) of the above sulfide in 50
mL of THF. The solution was cooled below -90 °C using a
liquid N2-Et2O bath, and 34 mL (57.8 mmol) of 1.7 M t-BuLi
solution was added dropwise. In a separate 25 mL, flame-
dried, round-bottomed flask was dissolved 4.10 g (27.3 mmol)
of piperonal in 20 mL of THF. After addition of the t-BuLi
solution to the sulfide was complete, the solution was stirred
for 30 min below -90 °C, and the piperonal solution was added
to the dark reddish-orange lithiate solution. The solution was
stirred overnight, acidified with 5% HCl solution, and ex-
tracted with CH2Cl2. The organic extracts were washed with
a saturated aqueous NaHCO3, brine, dried over Na2SO4, and
concentrated under reduced pressure to give 8.51 g (90%) of
benzo[1,3]dioxol-5-yl-[6-[(ethylthio)methyl]benzo[1,3]dioxol-5-
yl)methanol (33) as a light yellow oil: IR (neat) 3408, 2898,
1
1486, 1241, 1040 cm-1; H-NMR (CDCl3, 300 MHz) δ 1.23 (t,
3H, J ) 7.4 Hz), 2.48 (q, 2H, J ) 7.4 Hz), 2.86 (d, 1H, J ) 3.7
Hz), 3.62 (d, 1H, J ) 13.1 Hz), 3.72 (d, 1H, J ) 13.1 Hz), 5.90
(d, 2H, J ) 1.4 Hz), 5.92 (s, 2H), 6.06 (d, 1H, J ) 3.7 Hz), 6.69
(s, 1H), 6.75 (d, 1H, J ) 8.5 Hz), 6.81 (s, 1H), 6.82-6.84 (m,
2H); 13C-NMR (CDCl3, 75 MHz) δ 14.5, 25.9, 33.5, 71.6, 101.0,
101.1, 107.3, 108.0, 108.6, 110.3, 119.9, 129.0, 136.2, 137.0,
146.7, 147.1, 147.2, 147.7.
In a flame-dried, 500 mL, round-bottomed flask was dis-
solved 8.34 g (24.1 mmol) of alcohol 33 in 75 mL of CH2Cl2. To
the yellow solution was added 10.18 g (117 mmol) of activated
MnO2 (85%). The mixture was stirred at rt for 24 h, filtered
over Celite and concentrated under reduced pressure to give
7.62 g (92%) of benzo[1,3]dioxol-5-yl-[6-[(ethylthio)methyl]-
benzo[1,3]dioxol-5-yl)methanone as a light yellow oil: IR (neat)
2905, 1654, 1603, 1485 cm-1; 1H-NMR (CDCl3, 300 MHz) δ 1.13
(t, 3H, J ) 7.4 Hz), 2.39 (q, 2H, J ) 7.4 Hz), 3.77 (s, 2H), 6.02
(s, 2H), 6.06 (s, 2H), 6.77 (s, 1H), 6.82 (d, 1H, J ) 8.1 Hz),
6.98 (s, 1H), 7.32 (dd, 1H, J ) 8.1 and 1.7 Hz), 7.35 (s, 1H);
13C-NMR (CDCl3, 75 MHz) δ 14.5, 25.8, 33.1, 101.6, 101.9,
107.7, 109.2, 109.5, 110.6, 127.1, 132.2, 132.6, 133.5, 145.7,
148.0, 149.0, 151.9, 195.2. HRMS (FAB) Calcd for
C18H16O5S: 345.0797. Found: 345.0793.
P r ep a r a tion of 4-(Eth ylth io)-1-oxo-2-p h en yl-1,2-d ih y-
d r on a p h th a len e-2-ca r boxylic Acid Meth yl Ester (30). A
436 mg (1.60 mmol) sample of sulfoxide 18 was treated with
0.8 µL (9.57 mmol) of methyl propiolate in 2 mL of Ac2O to
give 276 mg (51%) of cycloadduct 30 as pale yellow solid: mp
1
99-100 °C; IR (neat) 3064, 1777, 1740, 1593, 1684 cm-1; H-
NMR (CDCl3, 300 MHz) δ 1.39 (t, 3H, J ) 7.4 Hz), 2.94 (q,
2H, J ) 7.4 Hz), 3.76 (s, 3H), 6.35 (s, 1H), 7.27-7.49 (m, 6H),
7.63 (td, 1H, J ) 7.4 and 1.0 Hz), 7.83 (d, 1H, J ) 8.0 Hz),
8.02 (dd, 1H, J ) 8.0 and 1.0 Hz); 13C-NMR (CDCl3, 75 MHz)
δ 13.6, 26.4, 53.2, 65.9, 125.2, 127.1, 127.8, 127.8, 127.9, 128.1,
128.3, 128.4, 129.1, 132.5, 134.7, 136.1, 136.4, 170.2, 193.4.
HRMS (FAB) Calcd for C20H19O3S: 339.1055. Found: 339.1069
(M + H+). Anal. Calcd for C20H18O3S: C, 70.98; H, 5.36.
Found: C, 70.73; H, 5.43. The X-ray structure of 30 was solved
by direct methods using the SHELXTL program.42
In
a 250 mL round-bottomed flask equipped with an
addition funnel was dissolved 12.9 g (60.5 mmol) of NaIO4 in
100 mL of H2O, and the mixture was cooled in an ice-bath. A
19.8 g (57.4 mmol) sample of the above sulfide was dissolved
in 100 mL of 1,4-dioxane and added dropwise to the aqueous
solution which resulted in the eventual precipitation of a white
solid. The ice-bath was removed, and the mixture was stirred
overnight, diluted with water, and extracted with CH2Cl2. The
organic extracts were dried over Na2SO4 and concentrated
under reduced pressure to give 17.47 g (88%) of benzo[1,3]-
diox-ol-5-yl-[6-[(ethylsulfinyl)methyl]benzo[1,3]dioxol-5-yl)-
methanone (34) as a colorless oil: IR (neat) 2910, 1650, 1603,
P r epar ation of Ben zo[1,3]dioxol-5-yl-[6-[(eth ylsu lfin yl)-
m eth yl]ben zo[1,3]d ioxol-5-yl)m eth a n on e (34). In a 100
mL round-bottomed flask was dissolved 5.0 g (3.29 mmol) of
piperonyl alcohol (31) in 10 mL of acetic acid. The flask was
cooled in an ice-bath, and a mixture of 2.0 mL of bromine (38.8
mmol) and 6 mL of acetic acid was added dropwise. The
reaction mixture was stirred at rt overnight during which time
a white solid precipitated. The mixture was filtered, and the
filtercake was washed with water. The solid was dried in
vacuo to give 7.62 g of 5-bromo-6-(bromomethyl)benzo[1,3]-
dioxole (32). The filtrate was extracted with CH2Cl2, and the
extracts were dried over Na2SO4, concentrated, and chromato-
graphed to afford an additional 1.42 g (92% total) of dibromide
1487 cm-1; H-NMR (CDCl3, 300 MHz) δ 1.30 (t, 3H, J ) 7.6
1
Hz), 2.70 (m, 2H), 3.87 (d, 2H, J ) 12.8 Hz), 4.27 (d, 2H, J )
12.8 Hz), 6.04-6.06 (m, 4H), 6.82-6.85 (m, 1H), 6.90 (s, 1H),
6.99, (s, 1H), 7.28-7.33 (m, 2H); 13C-NMR (CDCl3, 75 MHz) δ
6.7, 45.3, 55.5, 101.9, 102.0, 107.7, 109.6, 110.5, 112.2, 126.2,
127.2, 132.1, 132.4, 146.8, 148.0, 149.6, 152.0, 194.8. HRMS
(FAB) Calcd for C18H16O5S: 345.0797. Found: 345.0793.
1
32 as a white solid: mp 88-89 °C (lit.54 91-92 °C); H-NMR
(CDCl3, 300 MHz) δ 4.55 (s, 2H), 5.99 (s, 2H), 6.91 (s, 1H),
7.01 (s, 1H); 13C-NMR (CDCl3, 75 MHz) δ 34.1, 102.1, 110.5,
113.1, 115.6, 129.9, 147.6, 148.8.
