Organometallics
Article
m, 659 m, 634 m. Anal. Calcd for C34H56LuN3OSi3: C, 52.22; H,
7.22; N, 5.37. Found: C, 52.49; H, 7.38; N, 5.09. Mp: 130−132 °C.
Y{N(SiHMe2)dipp}3NC5H5 (4c·py). Y{N(SiHMe2)dipp}3 (0.142
g, 0.179 mmol) was dissolved in benzene (3 mL), and pyridine
(0.0144 mL, 0.179 mmol) was added to the solution. The reaction
mixture was stirred for 10 min, and the solvent was evaporated under
reduced pressure. The resulting oily residue was extracted with
pentane (3 × 5 mL) and the extract was concentrated and cooled to
−30 °C to provide the desired product as a white crystalline solid
(0.0893 g, 0.102 mmol, 57.2%). 1H NMR (benzene-d6, 600 MHz, 25
°C): δ 8.07 (br s, 2 H, o-NC5H5), 7.15 (br s, 6 H, m-C6H5), 7.05 (t, 3
H, 3JHH = 7.3 Hz, p-C6H5), 6.60 (br s, 1 H, p-NC5H5), 6.35 (br s, 2 H,
4.33 (SiMe2), 3.10 (SiHMe2). 29Si{1H} NMR (benzene-d6, 119.3
MHz, 40 °C): δ −24.1 (SiHMe2), 4.84 (SiMe2). IR (KBr, cm−1):
3387 w, 3062 w, 2962 s, 2929 s, 2869 m, 2108 w (SiH, from
hydrolysis), 1965 w (SiH), 1886 w (SiH), 1620 w, 1588 w, 1459 s,
1425 s, 1382 w, 1360 w, 1306 s, 1251 s, 1235 s, 1187 s, 1148 w, 1110
m, 1056 m, 1040 m, 998 s, 933 s, 914 s, 861 m, 837 s, 814 m, 782 s,
745 s, 702 s, 678 w, 632 w. Anal. Calcd for C55H82N3OSi3Y: C, 67.79;
H, 8.48; N, 4.31. Found: C, 68.24; H, 7.94; N, 3.95. Mp: 187−189
°C.
Lu{N(SiMe2OCHPh2)dipp}{N(SiHMe2)dipp}2 (5e). Lu{N-
(SiHMe2)dipp}3 (0.0533 g, 0.0607 mmol) was dissolved in benzene
(3 mL), and benzophenone (0.0110 g, 0.0609 mmol) was added to
the solution. The reaction mixture was stirred for 15 min, and the
solvent was evaporated under reduced pressure. The resulting oily
residue was extracted with pentane (3 × 5 mL), and the extract was
concentrated and cooled to −30 °C to provide the desired product as
1
m-NC5H5), 5.33 (br s, 3 H, JSiH = 150.5 Hz, SiHMe2), 3.64 (br s, 6
H, CHMe2), 1.24 (br s, 18 H, CHMe2), 1.00 (br s, 18 H, CHMe2),
0.21 (br s, 18 H, SiHMe2). 13C{1H} NMR (benzene-d6, 150 MHz, 25
°C): δ 149.51 (o-NC5H5), 148.78 (ipso-C6H5), 143.50 (o-C6H5),
140.24 (p-NC5H5), 124.89 (m-NC5H5), 124.53 (m-C6H5), 121.91 (p-
C6H5), 27.92 (CHMe2), 26.84 (CHMe2), 25.67 (CHMe2), 2.45
(SiHMe2). 29Si{1H} NMR (benzene-d6, 119.3 MHz, 25 °C): δ
−26.54. IR (KBr, cm−1): 3067 w, 3049 w, 2963 s, 2869 m, 2103 m
(SiH), 1959 w (SiH), 1623 w, 1604 m, 1588 w, 1462 s, 1444 m, 1425
s, 1383 w, 1361 w, 1309 m, 1259 s, 1188 s, 1156 w, 1144 w, 1107 s,
1055 s, 1040 s, 1011 s, 933 s, 912 s, 864 w, 786 s, 756 s, 704 m, 675 w,
631 w. Anal. Calcd for C47H77N4Si3Y: C, 64.79; H, 8.91; N, 6.43.
Found: C, 64.66; H, 8.83; N, 6.43. Mp: 156−158 °C.
1
a white crystalline solid (0.0375 g, 0.0352 mmol, 58.0%). H NMR
(benzene-d6, 600 MHz, 25 °C): δ 7.24−6.87 (19 H, aromatic region),
1
6.62 (s, 1 H, OCHPh2), 5.29 (br s, 2 H, JSiH = 133.1 Hz, SiHMe2),
3.72 (br s, 6 H, CHMe2), 1.26 (br, 24 H, CHMe2), 1.12 (br, 12 H
CHMe2), 0.26 (br s, 12 H, SiHMe2), 0.05 (s, 6 H, SiMe2). 13C{1H}
NMR (benzene-d6, 150 MHz, 25 °C): δ 148.69, 146.15, 144.94,
143.15, 141.11, 129.41, 129.14, 124.95, 124.31, 122.54, 122.09
(aromatic region), 83.58 (OCHPh2), 28.24(CHMe2), 27.79
(CHMe2), 26.80 (CHMe2), 26.65 (CHMe2), 4.49 (SiMe2), 3.12
(SiHMe2). 29Si{1H} NMR (benzene-d6, 119.3 MHz, 40 °C): δ −21.79
(SiHMe2), −4.10 (SiMe2). IR (KBr, cm−1): 3387 w, 3059 w, 3046 w,
3008 s, 2963 s, 2869 m, 2110 w (SiH, from hydrolysis), 1957 m
(SiH), 1619 w, 1587 w, 1497 w, 1458 s, 1425 s, 1382 m, 1360 w, 1317
m, 1305 s, 1248 s, 1235 s, 1188 s, 1147 w, 1098 m, 1059 m, 1040 m,
994 s, 935 s, 910 s, 875 m, 834 s, 804 m, 781 s, 749 m, 738 m, 702 s,
681 w, 655 w, 628 w Anal. Calcd for C55H82N3OSi3Lu: C, 62.29; H,
7.79; N, 3.96. Found: C, 62.35; H, 8.16; N, 3.85. Mp: 190−192 °C.
Y{N(SiMe2OCHMe2)dipp}2{N(SiHMe2)dipp} (4f). Y{N-
(SiHMe2)dipp}3 (0.105 g, 0.132 mmol) was dissolved in toluene (3
mL) and cooled to −78 °C. Acetone (0.0215 mL, 0.291 mmol) was
added to the cold solution, and the reaction mixture was stirred for 10
min. The solvent was evaporated under vacuum. The resulting oily
residue was washed with pentane (3 × 5 mL) and dried under
reduced pressure to provide the desired product as a white solid
(0.0678 g, 0.0746 mmol, 56.3%). Recrystallization from pentane at
Lu{N(SiMe2OCHMePh)dipp}{N(SiHMe2)dipp}2 (5d). Lu{N-
(SiHMe2)dipp}3 (0.1781 g, 0.203 mmol) was dissolved in benzene
(3 mL), and acetophenone (23.6 μL, 0.203 mmol) was added to the
solution. The reaction mixture was stirred for 15 min, and the solvent
was evaporated under reduced pressure. The resulting oily residue was
extracted with pentane (3 × 5 mL), and the extract was concentrated
and cooled to −30 °C to provide the desired product as a white
crystalline solid (0.133 g, 0.125 mmol, 61.4%). 1H NMR (benzene-d6,
600 MHz, 25 °C): δ 7.19−6.95 (14 H, aromatic region), 5.57 (br s, 2
1
3
H, JSiH = 135.3 Hz, SiHMe2), 5.06 (q, 1 H, JHH = 6.5 Hz,
3
OCHMePh), 3.85 (br vt, 4 H, CHMe2), 3.66 (v pentet, 2 H, JHH
=
5.7 Hz, CHMe2), 1.39 (d, 3 H, 3JHH = 6.5 Hz, OCHMePh), 1.32 (br,
12 H, CHMe2), 1.26 (br, 12 H, CHMe2), 1.19 (d, 6 H, 3JHH = 6.6 Hz,
CHMe2), 1.00 (br s, 6 H, CHMe2), 0.40 (br s, 12 H, SiHMe2), 0.21 (s,
3 H, SiMe2), −0.24 (s, 3 H, SiMe2). 13C{1H} NMR (benzene-d6, 150
MHz, 25 °C): δ 148.25, 145.07, 144.60, 143.62, 143.42, 141.81,
129.40, 129.30, 128.68, 127.22, 124.83, 124.28, 122.46, 122.35
(aromatic region), 78.09 (OCHMePh), 27.95 (CHMe2), 27.71
(CHMe2), 27.30 (CHMe2), 27.09 (CHMe2), 26.48 (OCHMePh),
26.19 (CHMe2), 24.23 (CHMe2), 4.23 (SiMe2), 3.91 (SiHMe2), 2.57
(SiMe2). 29Si{1H} NMR (benzene-d6, 119.3 MHz, 40 °C): δ 3.46
(SiMe2). IR (KBr, cm−1): 3388 w, 3051 w, 2962 s, 2929 m, 2868 m,
2109 w (SiH, from hydrolysis), 2001 w (SiH), 1881 m (SiH), 1621 w,
1588 w, 1494 w, 1460 s, 1427 s, 1382 w, 1361 w, 1307 m, 1251 s,
1238 s, 1190 s, 1148 w, 1110 s, 1060 m, 1038 s, 1009 w, 996 w, 951
m, 922 s, 910 s, 859 m, 838 s, 812 m, 781 s, 763 m, 748 m, 702 m, 676
w, 637 w, 606 w. Anal. Calcd for C55H92N3OSi3Lu (includes C5H12):
C, 61.76; H, 8.66; N, 3.93. Found: C, 61.85; H, 8.65; N, 3.75. Mp:
184−186 °C.
1
−30 °C provided X-ray-quality crystals. H NMR (benzene-d6, 600
MHz, 25 °C): δ 7.24−7.03 (9 H, aromatic region), 5.57 (br s, 1 H,
3
1JSiH = 138.7 Hz, SiHMe2), 4.17 (v pent, 2 H, JHH = 6.5 Hz,
OCHMe2), 3.98 (v pent, 2 H, 3JHH = 6.5 Hz, CHMe2), 3.71 (br, 3 H,
3
CHMe2), 3.54 (v triplet, 1 H, JHH = 6.5 Hz, CHMe2), 1.52 (br d, 6
H, 3JHH = 7 Hz, CHMe2), 1.48 (d, 3 H, 3JHH = 6.6 Hz, CHMe2), 1.42
3
3
(d, 6 H, JHH = 6.6 Hz CHMe2), 1.29 (v triplet, 6 H, JHH = 5.5 Hz,
3
3
CHMe2), 1.23 (d, 6 H, JHH = 6.4 Hz CHMe2), 1.19 (d, 3 H, JHH
=
3
6.7 Hz, CHMe2), 0.93 (br s, 6 H, CHMe2), 0.88 (d, 6 H, JHH = 6.1
Hz OCHMe2), 0.84 (d, 6 H, 3JHH = 6.1 Hz, OCHMe2), 0.49 (d, 3 H,
3JHH = 2.2 Hz, SiHMe2), 0.34 (d, 3 H, JHH = 2.4 Hz, SiHMe2), 0.32
3
(s, 6 H, SiMe2), 0.23 (s, 6 H, SiMe2). 13C{1H} NMR (benzene-d6, 150
MHz, 25 °C): δ 150.03 (ipso-dipp), 147.24 (ipso-dipp), 144.36
(CCHMe2), 144.09 (CCHMe2), 143.55 (CCHMe2), 143.12
(CCHMe2), 124.85 (m-dipp), 124.72 (m-dipp), 124.60 (m-dipp),
123.91 (m-dipp), 123.80 (p-dipp), 121.79 (p-dipp), 71.33
(OCHMe2), 28.38 (CHMe2), 28.28 (CHMe2), 28.09 (CHMe2),
27.95 (CHMe2), 27.40 (CHMe2), 27.35 (CHMe2), 27.29 (CHMe2),
26.87 (CHMe2), 26.70 (CHMe2), 26.37 (CHMe2), 25.59 (OCHMe2),
24.91(OCHMe2), 5.21 (SiHMe2), 4.99 (SiMe2), 4.12 (SiMe2), 3.55
(SiHMe2). 29Si{1H} NMR (benzene-d6, 119.3 MHz, 40 °C): −25.4
(SiHMe2), 0.23 (SiMe2). IR (KBr, cm−1): 3050 w, 2964 s, 2870 m,
1991 w (SiH), 1622 w, 1588 w, 1462 s, 1423 s, 1381 m, 1361 w, 1306
s, 1251 s, 1229 s, 1181 s, 1143 w, 1109 s, 1039 w, 960 s, 937 s, 873 w,
859 w, 836 s, 812 m, 779 s, 745 w, 701 w, 680 w, 629 w. Anal. Calcd
for C48H84N3O2Si3Y: C, 63.47; H, 9.32; N, 4.63. Found: C, 63.02; H,
9.34; N, 4.50. Mp: 215−217 °C.
Y{N(SiMe2OCHPh2)dipp}{N(SiHMe2)dipp}2 (4e). Y{N-
(SiHMe2)dipp}3 (0.0614 g, 0.0775 mmol) was dissolved in benzene
(3 mL), and benzophenone (0.0141 g, 0.0775 mmol) was added to
the solution. The reaction mixture was stirred for 15 min, and the
solvent was evaporated under reduced pressure. The resulting oily
residue was extracted with pentane (3 × 5 mL), and the extract was
concentrated and cooled to −30 °C to provide the desired product as
1
a white crystalline solid (0.0426 g, 0.0437 mmol, 56.4%). H NMR
(benzene-d6, 600 MHz, 25 °C): δ 7.29−6.88 (19 H, aromatic region),
1
6.53 (s, 1 H, OCHPh2), 5.01 (br s, 2 H, JSiH = 131.9 Hz, SiHMe2),
3.71 (v pentet, 2 H, 3JHH = 6.5 Hz, CHMe2), 3.65 (br, 4 H CHMe2),
1.26 (br, 24 H, CHMe2), 1.13 (br, 12 H CHMe2), 0.21 (br s, 12 H,
SiHMe2), 0.05 (s, 6 H, SiMe2). 13C{1H} NMR (benzene-d6, 150 MHz,
25 °C): δ 148.59, 146.13, 144.30, 142.60, 140.94, 129.64, 129.30,
124.85, 124.42, 122.31, 121.87 (aromatic region), 83.42 (OCHPh2),
28.19(CHMe2), 27.94 (CHMe2), 26.68 (CHMe2), 26.56 (CHMe2),
1667
Organometallics 2021, 40, 1654−1669
