Ruthenium-catalyzed aromatization of enediynes via highly regioselective nucleophilic additions on a π-alkyne functionality. A useful method for the synthesis of functionalized benzene derivatives

Article abstract of DOI:10.1021/ja043047j

TpRu(PPh₃)(CH₃CN)₂PF₆ (10 mol %) catalyst effected the nucleophilic addition of water, alcohols, aniline, acetylacetone, pyrroles, and dimethyl malonate to unfunctionalized enediynes under suitable conditions (100 °C, 12-24 h) and gave functionalized benzene products in good yields. In this novel cyclization, nucleophiles very regioselectively attack the internal C1′ alkyne carbon of enediynes to give benzene derivatives as a single regioisomer. Experiments with methoxy substituents exclude the possible involvement of naphthyl cations as reaction intermediates in the cyclization of (o-ethynylphenyl) alkynes. Deuterium-labeling experiments indicate that the catalytically active species is ruthenium-π-alkyne rather than ruthenium-vinylidene species. This hypothesis is further confirmed by the aromatization of o-(2′-iodoethynyl)phenyl alkynes with alcohols. We propose a nucleophilic addition/insertion mechanism for this nucleophilic aromatization on the basis of a series of experiments.

Full text of DOI:10.1021/ja043047j

Published on Web 02/19/2005
Ruthenium-Catalyzed Aromatization of Enediynes via Highly
Regioselective Nucleophilic Additions on a π-Alkyne
Functionality. A Useful Method for the Synthesis of
Functionalized Benzene Derivatives
Arjan Odedra, Chang-Jung Wu, Taduri Bhanu Pratap, Chun-Wei Huang,
Ying-Fen Ran, and Rai-Shung Liu*
Contribution from the Department of Chemistry, National Tsing-Hua UniVersity, Hsinchu,
Taiwan, ROC
Received November 18, 2004; E-mail: rsliu@mx.nthu.edu.tw
Abstract: TpRu(PPh3)(CH3CN)2PF6 (10 mol %) catalyst effected the nucleophilic addition of water, alcohols,
aniline, acetylacetone, pyrroles, and dimethyl malonate to unfunctionalized enediynes under suitable
conditions (100 °C, 12-24 h) and gave functionalized benzene products in good yields. In this novel
cyclization, nucleophiles very regioselectively attack the internal C1′ alkyne carbon of enediynes to give
benzene derivatives as a single regioisomer. Experiments with methoxy substituents exclude the possible
involvement of naphthyl cations as reaction intermediates in the cyclization of (o-ethynylphenyl) alkynes.
Deuterium-labeling experiments indicate that the catalytically active species is ruthenium-π-alkyne rather
than ruthenium-vinylidene species. This hypothesis is further confirmed by the aromatization of o-(2′-
iodoethynyl)phenyl alkynes with alcohols. We propose a nucleophilic addition/insertion mechanism for this
nucleophilic aromatization on the basis of a series of experiments.
Scheme 1
Introductions
Bergman aromatization of enediynes1 has attracted consider-
able attention because of its potential applications in medicinal
and materials chemistry (Scheme 1, eq 1).2,3 The Bergman
reaction of unstrained enediynes can be implemented by an
excess (>1.0 equiv) of metal complexes under mild conditions
via metal-vinylidene intermediates4a,b (eq 2) or through a metal-
chelated effect.4c-f The metal-vinylidene process mimics the
cyclization of 5-allene-3-en-1-ynes (Saito-Myers cyclization)5
occurring at 50-100 °C (eq 3).4-6 Uemura et al. recently
reported6 rhodium-catalyzed Bergman reactions via this protocol,
(1) (a) Bergman, R. G. Acc. Chem. Res. 1973, 6, 25. (b) Lockhart, T. P.; Comita,
P. B.; Bergman, R. G. J. Am. Chem. Soc. 1981, 103, 4082.
(2) Reviews: (a) Enediyne Antibiotics as Antitumor Agents; Borders, D. B.,
Doyle, T. W. Eds.; Marcel Dekker: New York, 1995. (b) Xi, Z.; Goldberg,
I. H. In ComprehensiVe Natural Product Chemistry; Barton, D. H. R.,
Nakanishi, K. Eds.; Pergamon: Oxford, 1999; Vol. 7, p 553.
(3) Recent reviews: (a) Basak, A.; Mandal, S.; Bag, S. S. Chem. ReV. 2003,
103, 4077. (b) Rawat, D. S.; Zaleski, J. M. Synlett. 2004, 393. (c) Bowles,
D. M.; Palmer, G. J.; Landis, C. A.; Scott, J. L.; Anthony J. E. Tetrahedron
2001, 57, 3753. (d) Grissom, J. W.; Gunawardena, G. U.; Klingberg, D.;
Huang, D. Tetrahedron 1996, 52, 6453. (e) Wang, K. K. Chem. ReV. 1996,
96, 207.
(4) For selected examples of stoichiometric metal-mediated Bergman cycliza-
tion, see: (a) Wang, Y. S.; Finn, M. G. J. Am. Chem. Soc. 1995, 117,
8045. (b) O’Connor, J. M.; Friese, S. J.; Tichenor, M. J. Am. Chem. Soc.
2002, 124, 3506. (c) Zaleski, J. M.; Rawat, D. S. J. Am. Chem. Soc. 2001,
123, 9675. (d) Warner, B. P.; Millar, S. P.; Broene, R. D.; Buchwald, S. L.
Science 1995, 269, 814. (e) Konig, B.; Hollnagel, H.; Ahrens, B.; Jones,
P. G. Angew. Chem., Int. Ed. Engl. 1995, 34, 2538. (f) Landis, C. A.; Payne,
M. M.; Eaton, D. L.; Anthony, J. E. J. Am. Chem. Soc. 2004, 126, 1338.
(5) (a) Myers, A. G.; Kuo, E. Y.; Finney, N. S. J. Am. Chem. Soc. 1989, 111,
8057. (b) Nagata, R.; Yamanaka, H.; Okazaki, E.; Saito, I. Tetrahedron
Lett. 1989, 30, 4995.
which led to dehydrogenation or C-H bond insertion of an
tethered alkane (eq 2). In all examples reported to date, the
cyclization of enediynes via metal-vinylidene intermediates has
followed the traditional diradical mechanism, and these reactions
have very limited applications in organic synthesis because they
cannot give functionalized benzenes from unstrained and
unfunctionalized enediynes.1-5
In contrast, the aromatization of enediynes via nucleophilic
addition (anionic Bergman cyclization) is more useful because
organic functionality can be introduced onto aromatic products
via suitable nucleophiles.7,8 Although anionic Bergman cycliza-
tion was first reported by Magnus in the early 1990s,7c such
reactions have never been implemented by metal catalysts. The
(6) (a) Ohe, K.; Kojima, M.-a; Yohehara, K.; Uemura, S. Angew. Chem., Int.
Ed. Engl. 1996, 35, 1823. (b) Manabe, T.; Yanagi, S.-I.; Ohe, K.; Uemura,
S. Organometallics 1998, 17, 2942.
9
3406
J. AM. CHEM. SOC. 2005, 127, 3406-3412
10.1021/ja043047j CCC: $30.25 © 2005 American Chemical Society

Ruthenium-Catalyzed Aromatization of Enediynes
A R T I C L E S
Scheme 2
widespread use of this protocol has been restricted by its limited
scope: the reactions required either anionic nucleophiles, such
as sodium methoxide and thiophenoxide,7 or strained cyclic
enediynes.8 Techniques for the cyclization of unstrained ene-
diynes using mild nucleophiles and metal catalysts are currently
unavailable and thus provide a challenge in synthetic chemistry.
This report describes a novel ruthenium-catalyzed aromatization
of unstrained enediynes with mild nucleophiles. This new
pathway is mechanistically interesting because it does not follow
the traditional Saito-Myers protocol; the active intermediate
is metal-alkyne rather than metal-vinylidene species.4a,b,6
Results and Discussions
Although cyclization of unfunctionalized enediynes has been
performed with different approaches, including diradical
pathways,1b,9 eletrophilic additions,10a-c and radical cation,10d
these reactions only gave benzene1b,9 or fulvene products10 of
special types. We seek to find a new method to realize the
aromatization of functionalized enediynes with various nucleo-
philes. We selected TpRuPPh3(CH3CN)2PF6 [Tp ) tris(1-
