An Integrated Continuous Flow Micro-Total Ultra-Fast
Process System (-TUFPS) for the Synthesis of Celecoxib
and other Cyclooxygenase Inhibitors
9
Sthalam Vinay Kumar, a,b Ajay K. Singh, a*, Srihari Pabbaraja,a,b,*
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
aDepartment of Organic Synthesis and Process Chemistry, CSIR-Indian Institute of
Chemical Technology, Hyderabad-500007, India.
bAcademy of Scientific and Innovative Research (AcSIR), CSIR-Human Resource
Development Centre (CSIR-HRDC) Campus, Ghaziabad-201002, Uttar Pradesh
E-mail: ajaysingh015@gmail.com; srihari@iict.res.in
ACS Paragon Plus Environment

Organic Process Research & Development
Page 2 of 20
1
2
3
4
TOC Figure
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
ACS Paragon Plus Environment

Page 3 of 20
Organic Process Research & Development
1
2
3
4
5
6
ABSTRACT: Integrated continuous manufacturing has emerged as a promising device
7
8
9
for the rapid manufacturing of an active pharmaceutical ingredients (APIs). We herein
report a newly designed continuous flow micro-total process system platform for the
rapid manufacturing of celecoxib, a selective non-steroidal anti-inflammatory drug
(NSAID). This approach has been proven general for the synthesis of several alkyl and
aryl substituted pyrazoles. In order to minimize the tedious work up process of potential
reaction intermediates/products, we have developed a continuous flow extraction and
separation platform to carry out the entire reaction sequence resulting in short residence
time with good yield. The present process was further extended to gram scale synthesis
of COX-2 related active pharmaceutical ingredient (API), viz. celecoxib in the
continuous flow process.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Keywords: Pyrazoles API, Integrated Continuous flow, Ultra-fast Synthesis, COX-2
inhibitor, In-line IR.
Introduction
Pyrazoles have
a
wide range of applications in the field of natural
products/pharmaceutical therapeutic agents, including anti-inflammatory and anti-
diabetic etc and thus attracted attention from both academia and industry. (Fig. 1).1-13
Celecoxib is a non-arylamine benzene sulfonamide derived cyclooxygenase-2 (COX-2)
inhibitor that can be used for the treatment of many human diseases (e.g., rheumatoid
arthritis, osteoarthritis, acute pain and painful menstruation) in addition to cancer.14-22
Pyrazole derivatives are conventionally prepared by condensation of a diketone with
hydrazine using ethanol or water as solvent under reflux conditions.7,22 API
manufacturing is usually performed at multiple locations in non-continuous or “batch”
synthesis involving extraction, product separation and formulation.23-29 The main
disadvantages of the batch approach include long production times, the high cost of
transportation and the potential disruption of the supply chain.23,24
ACS Paragon Plus Environment

Organic Process Research & Development
Page 4 of 20
1
2
3
4
H2NO2S
5
6
N
N
CHF2
7
8
9
MeO
F
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
H2NO2S
Deracoxib
MeO
COX inhibitor
N
N
CF3
N
N
CF3
Br
SC-558
R3
Cl
F2C
Human Lungs Cancer
Suppression
COX inhibitor
N
R2
N
R1
ra
Py
le
zo
H2NO2S
H2NO2S
N
N
N
N
CF3
CF3
Cl
F
N
N
Celecoxib
COX inhibitor
Mavacoxib
COX inhibitor
CF3
MeO
SC-560
COX inhibitor
Fig. 1: Biologically active 3-fluoro methyl pyrazole motif containing selective non-
