Synthesis of 4-Dendronized b-Lactams
S
ynthesis of 4-D
n
endronize
d
r
b
-Lactam
i
s
que Díez-Barra, Joaquín C. García-Martínez, Julián Rodríguez-López*
Área de Química Orgánica, Facultad de Química, Universidad de Castilla-La Mancha, 13071-Ciudad Real, Spain
Fax +34(926)295318; E-mail: julian.rodriguez@uclm.es
Received 9 May 2003
Classical condensation of the dendritic aldehydes with a
slight excess of p-anisidine in CH2Cl2 in the presence of
molecular sieves (4 Å) afforded smoothly the expected
dendritic imines (Table 1).11 Purification of these com-
pounds was performed easily and efficiently by washing
the crude product with ethanol in order to solubilize the
excess of amine, and filtering off the pure desired imine.
Abstract: The first synthesis of 4-dendronized b-lactams using the
standard Staudinger ketene–imine cyclization is described. Both
p-conjugated and Fréchet’s aromatic polyether dendrons having
imine focal points were used as starting materials. Exclusive cis-
stereochemistry was observed for all the b-lactams prepared.
Key words: dendrimers, b-lactams, imines, ketenes, Staudinger re-
action
The synthesis of the 4-dendronized b-lactams was
achieved following a standard methodology.8b Thus, treat-
ment of imines 1a,b with isobutyryl chloride and phe-
noxyacetyl chloride, respectively, in dichloromethane at
room temperature and in the presence of triethylamine
gave b-lactams 2a,b. In addition, enantiomerically pure 2-
azetidinones 2c–f12 were obtained from (+)-(S)-(4-phe-
nyl-2-oxo-1,3-oxazolidin-3-yl)acetic acid and the corre-
sponding imines 1b–e in the presence of triethylamine and
dichlorophenylphosphate as condensating agent in the
same solvent (Table 2).
Dendrimers are a unique class of compounds, which have
been largely studied during the last two decades. Synthet-
ic methodologies for dendrimers are well known1 and the
wide scope of their applications is continuously growing.2
One of the more promising field for dendrimers is their
use for biomedical applications. Their ability to be used
for diagnostics and therapy (including magnetic reso-
nance imaging, drug-delivery, DNA biosensors, boron
neutron-capture therapy, etc.), and as new polymeric bio-
materials for tissue engineering, has been recently re-
viewed.3
It is noteworthy that exclusive cis-stereochemistry was
observed for all b-lactams 2 prepared as determined by
1
On the other hand, the synthesis of new 2-azetidinone de-
rivatives is a permanent goal4 because of the wide pres-
ence of this ring in antibiotics, the increased bacterial-
resistance to natural b-lactam antibiotics and, more re-
cently, the development of nonantibiotic uses.5
high field H NMR analysis of the crude reaction mix-
tures. It was established by the value of coupling constants
of the H3-H4 protons (J = ca. 5 Hz). No traces of the
trans-isomers were detected in any case. As exemplified
by compound 2f, the stereochemical outcome of the reac-
tion did not suffer any variation even with substituents as
large as a third generation Fréchet dendron.
Thus, dendronized b-lactams would incorporate in a
unique structure two of the most interesting classes of
compounds. However, surprisingly, b-lactams having
dendritic substituents attached to the four-membered ring
have not been reported yet. To the best of our knowledge,
there are only two papers where dendrimers and b-lactams
are related. One of them describes the use of a carbosilane
dendrimer for the synthesis of a library of b-lactams;6 the
other one concerns the use of PAMAM for preparing
densely penicilloylated dendrimers.7
The clean and high efficiency of the reactions employed
facilitated product isolation and purification. The struc-
ture and purity of all the new compounds described herein
has been confirmed using MS, NMR, IR, and elemental
analysis. HRMS analyses of 2a,b,e gave the expected mo-
lecular ions. The MALDI-TOF spectra of 2c,d,f showed
peaks matching the calculated values for the expected mo-
lecular weights (Table 3).
Herein we describe the first synthesis of a set of b-lactams
that incorporates different dendritic wedges (up to third
generation) at the 4-position of the 2-azetidinone ring.
The synthesis has been envisaged following the classical
Staudinger approach based on the reaction of imines and
ketenes.8
In conclusion, we have demonstrated that the standard
Staudinger ketene–imine cyclization can be used to effi-
ciently prepare in a complete stereoselective manner the
hitherto unknown cis-3-substituted-4-dendronized b-lac-
tams 2. This strategy is extremely general, permitting not
only the use of different ketene derivatives as starting ma-
terials but also the introduction at the 4-position of the 2-
azetidinone ring of both p-conjugated and Fréchet’s type
dendritic branches.
The required dendritic imines were prepared from both p-
conjugated dendrons, previously reported by us,9 and
Fréchet’s type dendrons10 having formyl focal points.
Further transformations and applications of the prepared
dendronized b-lactams are currently investigated in our
laboratories.
Synlett 2003, No. 11, Print: 02 09 2003. Web: 05 08 2003.
Art Id.1437-2096,E;2003,0,11,1587,1590,ftx,en;G10403ST.pdf.
DOI: 10.1055/s-2003-40990
© Georg Thieme Verlag Stuttgart · New York

1588
E. Díez-Barra et al.
LETTER
Table 1 Preparation of Dendritic Imines
