New synthesis of allylidenecyclobutanes by the reaction of
cyclobutylmagnesium carbenoids with vinyl sulfones
⇑
Masashi Ishigaki, Mio Inumaru, Tsuyoshi Satoh
Graduate School of Chemical Sciences and Technology, Tokyo University of Science, Ichigaya-funagawara-machi 12, Shinjuku-ku, Tokyo 162 0826, Japan
a r t i c l e i n f o
a b s t r a c t
Article history:
The reaction of cyclobutylmagnesium carbenoids, which were generated from 1-chlorocyclobutyl p-tolyl
sulfoxides with EtMgCl via the sulfoxide–magnesium exchange reaction at low temperature, with carba-
nions derived from vinyl sulfones with n-BuLi or LDA resulted in the formation of allylidenecyclobutanes
in moderate to good yields. The actual reactive species of the sulfones in this reaction were proved to be
Received 27 June 2011
Revised 27 July 2011
Accepted 3 August 2011
Available online 19 August 2011
the lithium a-sulfonyl carbanion of allyl sulfones derived from the vinyl sulfones by double bond migra-
tion with the bases used. Mono- and di-substituted allylidenecyclobutanes can be obtained by using a
variety of vinyl sulfones.
Keywords:
Magnesium carbenoid
Cyclobutylmagnesium carbenoid
Cyclobutane
Ó 2011 Elsevier Ltd. All rights reserved.
Allylidenecyclobutane
Vinyl sulfone
Introduction
magnesium carbenoid 2 via the sulfoxide–magnesium exchange
reaction.7 In an another flask, vinyl sulfone 38 in THF at low tem-
Small ring strained molecules such as cyclopropanes and cyclob-
utanes, and their derivatives, have been known as versatile interme-
diates in organic synthesis for long time.1 Small ring compounds
reveal characteristic reactivity by their strain release. Innumerable
studies for the chemistry, synthesis, and synthetic uses of cyclopro-
panes have been carried out; however, those for cyclobutanes are
still limited.2 Alkylidenecyclobutanes are also very interesting
highly strained cyclobutane derivatives and often used in organic
synthesis3; however, adequate methods for their synthesis are still
lacking.4
perature was treated with n-BuLi (or LDA) and this solution was
transferred to the solution of cyclobutylmagnesium carbenoid 2
through a cannula and the whole reaction mixture was slowly
allowed to warm to 0 °C to afford allylidenecyclobutane 4 in mod-
erate to good yield. This is an unprecedented new method for the
synthesis of allylidenecyclobutanes 4 from easily available 1-chlo-
rocyclobutyl p-tolyl sulfoxides 1.6 Preliminary results of this study
and mechanistic discussion of this reaction are reported in this
Letter.
We recently started to investigate the chemistry and synthetic
uses of cyclobutylmagnesium carbenoid (carbenacyclobutane)
and many interesting reactions have appeared.5,6 Synthesis of alky-
lidenecyclobutanes by the reaction of cyclobutylmagnesium carb-
R1CH2
R2
R3
SO2Tol
enoids with lithium
a-sulfonyl carbanions as nucleophiles was
R
Cl
R
Cl
3
one of the most interesting results from the investigations.6 In con-
tinuation of our studies concerning the reaction of cyclobutylmag-
nesium carbenoids with nucleophiles, we recently found that the
reaction of cyclobutylmagnesium carbenoids with the carbanions
derived from vinyl sulfones with n-BuLi (or LDA) resulted in the
formation of allylidenecyclobutanes in moderate to good yields
(Scheme 1).
EtMgCl
THF
STol
MgCl
R
R
n-BuLi (or LDA)
O
2
1
4
R3
R
H
Thus, treatment of 1-chlorocyclobutyl p-tolyl sulfoxide 1 in THF
with EtMgCl at À90 °C resulted in the generation of cyclobutyl-
R
R2
R1
⇑
Corresponding author. Tel.: +1 81 3 5228 8272; fax: +1 81 3 5261 4631.
E-mail address: tsatoh@rs.kagu.tus.ac.jp (T. Satoh).
Scheme 1.
0040-4039/$ - see front matter Ó 2011 Elsevier Ltd. All rights reserved.
doi:10.1016/j.tetlet.2011.08.018

5564
M. Ishigaki et al. / Tetrahedron Letters 52 (2011) 5563–5566
occur relatively easily,10 vinyl sulfone 5 must be isomerized to allyl
sulfone 7 by n-BuLi in the reaction medium. -Hydrogen of allyl
sulfone 7 was easily deprotonated to give lithium -sulfonyl carb-
anion 8. Carbenoid 2a was attacked from back side of the chlorine
EtMgCl (2.5 eq)
THF, -90 °C
C2H5OCH2
C2H5OCH2
Cl
C2H5OCH2
Cl
a
MgCl
C2H5OCH2
S(O)Tol
a
2a
1a
atom by a-sulfonyl carbanion 8 to give cyclobutylmagnesium chlo-
ride intermediate 9,11 from which b-elimination must have oc-
curred to afford allylidenecyclobutane 6.
H3C
H3C
H
n-BuLi
SO2Tol
The double bond migration of vinyl sulfone 5 to allyl sulfone 7
was confirmed from the experiment shown in Scheme 3. Thus,
treatment of vinyl sulfone 5 with n-BuLi at À70 °C for 10 min fol-
C2H5OCH2
C2H5OCH2
H
5
H
-90 to 0 °C, 69%
H3C
H
lowed by CH3OD gave a-deuterio allyl sulfone 10 in 85% yield with
6
over 99% deuterium content. In order to make sure that this reac-
tion proceeds via -sulfonyl carbanion of allyl sulfones, cyclobutyl-
magnesium carbenoid 2a was reacted with 3 equiv of lithium
-sulfonyl carbanion generated from allyl sulfone 7 under the
a
Scheme 2.
a
same conditions described above. As expected, this reaction gave
allylidenecyclobutane 6 in 71% yield, which was almost the same
as that of the reaction with vinyl sulfone 5 (69%, see Scheme 2).
As we recognized that this reaction is unprecedented and would
become a new method for the synthesis of allylidenecyclobutanes,
generality was investigated and the results are summarized in Ta-
ble 1. The result shown in entry 1 has been mentioned above. The
reaction of 1b with the carbanion derived from 5 gave allylidene-
cyclobutane 11a in somewhat better yield (77%, entry 2). When
the vinyl sulfone has a phenyl group at the b-position, yield of
the reaction markedly diminished (entries 3 and 4).
Disubstituted allylidenecyclobutanes 11d and 11e were synthe-
sized from 1a and 1b with 2,2-diethylvinyl sulfone in moderate
yields (entries 5 and 6). Interestingly, only the geometrical isomer
depicted in Table 1 was obtained and the structures of 11d and
11e were determined from their NOESY spectra. The vinyl sulfones
synthesized from cyclopentanone and cyclohexanone gave allylid-
enecyclobutanes bearing a cyclopentene- and cyclohexene ring,
respectively, in moderate to good yields (entries 7–10). In order to
make sure that this reaction is not affected by the substituents on
the 3-position of the cyclobutane ring, we investigated the reaction
starting from 1-chlorocyclobutyl p-tolyl sulfoxide bearing no substi-
tuent 1c and the vinyl sulfone having higher molecular weight, 2-
benzyl-3-phenyl-1-propenyl p-tolyl sulfone, whichwas synthesized
Results and discussion
As a representative example for this investigation, the reaction
using 1-chlorocyclobutyl p-tolyl sulfoxide 1a and 2-methyl-1-pro-
penyl p-tolyl sulfone 59 is reported (Scheme 2). In our previous stud-
ies, we reported the reactions of cyclobutylmagnesium carbenoids
with carbon nucleophiles, including lithium a-sulfonyl carbanions,
followed by electrophiles to give multi substituted cyclobutanes.6
Based on the experiences of these studies, we treated cyclobutyl-
magnesium carbenoid 2a, generated from 1a with EtMgCl in THF
at À90 °C, with 3 equiv of an anion generated from vinyl sulfone 5
with n-BuLi. The temperature of the reaction mixture was slowly al-
lowed to warm to 0 °C.
This reaction cleanly gave a product, which has C14H24O2 as the
molecular formula, in 69% yield as colorless oil. The product had
three olefin protons (d 4.74, 2H, broad singlet and d 5.83, 1H, quin-
tet, J=2.3 Hz) and one olefinic methyl group (d 1.85, broad singlet).
The structure of this product was easily assigned to be allylidene-
cyclobutane 6 as shown in Scheme 2. We investigated to find bet-
ter conditions for this reaction; however, the conditions mentioned
above were found to be the best.
A plausible mechanism of this quite interesting reaction is
proposed as follows (Scheme 3). Thus, as the double bond migra-
tion of vinyl sulfones to allyl sulfones by a base was reported to
H2C
H
n-BuLi
H3C
H3C
H
n-BuLi
H2C
H3C
H
H3C
SO2Tol
SO2Tol
SO2Tol
double bond
migration
H
5
8
7
SO2Tol
CH2
CH3
MgCl
C2H5OCH2
C2H5OCH2
H
C2H5OCH2
C2H5OCH2
MgCl
Cl
C2H5OCH2
C2H5OCH2
H
H
H3C
2a
6
9
H3C
H3C
H
n-BuLi
H2C
H3C
D
SO2Tol
CH3OD
SO2Tol
THF, -70°C , 10 min
10
5
H2C
CH2SO2Tol
n-BuLi
H3C
C2H5OCH2
C2H5OCH2
MgCl
Cl
C2H5OCH2
C2H5OCH2
H
7
H
H
71%
H3C
2a
6
Scheme 3. A plausible mechanism for the reaction of cyclobutylmagnesium carbenoid 2a with the carbanion generated from vinyl sulfone 5 with n-BuLi giving
allylidenecyclobutane 6.
