Tandem 1,3-dipolar cycloaddition of mesoionic 2,4-diphenyl-1,3- oxathiolium-5-olate with cycloocta-1,5-diene. A new synthesis of the tetracyclo[6.2.0.04,10.05,9]decane ring system

Article abstract of DOI:10.1016/S0040-4039(00)00042-3

The mesoionic heterocycle 2,4-diphenyl-1,3-oxathiolium-5-olate (5) undergoes a tandem 1,3-dipolar cycloaddition reaction with cycloocta-1,5- diene (6) to give cycloadduct sulfide 7 in modest yield. Oxidation to sulfone 8 and photochemical extrusion of SO₂ affords 9,10- diphenyltetracyclo[6.2.0.0^4,10.0^5,9]decane (9) in high yield. (C) 2000 Elsevier Science Ltd.

Full text of DOI:10.1016/S0040-4039(00)00042-3

TETRAHEDRON
LETTERS
Pergamon
Tetrahedron Letters 41 (2000) 1687–1690
Tandem 1,3-dipolar cycloaddition of mesoionic 2,4-diphenyl-
1,3-oxathiolium-5-olate with cycloocta-1,5-diene. A new
synthesis of the tetracyclo[6.2.0.04,10.05,9]decane ring system
William R. Sponholtz III,† Hernando A. Trujillo ‡ and Gordon W. Gribble ∗
Department of Chemistry, Dartmouth College, Hanover, New Hampshire 03755, USA
Received 6 December 1999; accepted 29 December 1999
Abstract
The mesoionic heterocycle 2,4-diphenyl-1,3-oxathiolium-5-olate (5) undergoes a tandem 1,3-dipolar cycloaddi-
tion reaction with cycloocta-1,5-diene (6) to give cycloadduct sulfide 7 in modest yield. Oxidation to sulfone 8 and
photochemical extrusion of SO2 affords 9,10-diphenyltetracyclo[6.2.0.04,10.05,9]decane (9) in high yield. © 2000
Elsevier Science Ltd. All rights reserved.
Keywords: 1,3-oxathiolium-5-olate; mesoionic; 1,3-dipolar cycloaddition; tetracyclo[6.2.0.04,10.05,9]decane.
1,3-Dipolar cycloaddition reactions of mesoionic heterocycles, such as sydnones 1 (1,2,3-
oxadiazolium-5-olates), münchnones 2 (1,3-oxazolium-5-olates), isomünchnones 3 (1,3-oxazolium-4-
olates), thioisomünchnones 4 (1,3-thiazolium-4-olates) and related conjugated heterocyclic mesomeric
betaines,1 have seen a resurgence of applications to synthesis.2,3
In continuation of our interest in 1,3-dipolar cycloaddition reactions of sydnones and münchnones with
cyclic dienes4 and nitro-substituted heterocycles,5 we now report that 2,4-diphenyl-1,3-oxathiolium-5-
olate (5), a mesoionic heterocycle that has been neglected since its original generation and trapping
(with dimethyl acetylenedicarboxylate),6 undergoes a tandem 1,3-dipolar cycloaddition reaction with
cycloocta-1,5-diene (6) to afford 9,11-diphenyl-10-thiatetracyclo[6.3.0.04,11.05,9]undecane (7) in 32%
∗
Corresponding author. Tel: 1-603-646-3118; fax: 1-603-646-3946; e-mail: grib@dartmouth.edu (G. W. Gribble)
Permanent address: Department of Sciences, Cushing Academy, Ashburnham, MA 01430, USA.
Permanent address: Department of Chemistry, Albright College, Reading, PA 19612, USA.
†
‡
0040-4039/00/$ - see front matter © 2000 Elsevier Science Ltd. All rights reserved.
PII: S0040-4039(00)00042-3
tetl 16322

1688
yield after column chromatography (Scheme 1). Mesoionic 5 was generated in situ from S-benzoyl-α-
phenylthioglycolic acid6 and diisopropylcarbodiimide (DIPC), conditions that we have used previously
to generate münchnones.4b,5 Cycloadduct 7 was fully characterized.7,8
Scheme 1.
The facile photochemical elimination of sulfur dioxide from benzylic sulfones9 suggested to
us that the sulfone 8 derived from 7 might undergo a similar extrusion of SO2 to form 9,10-
diphenyltetracyclo[6.2.0.04,10.05,9]decane (9). Indeed, as shown in Scheme 2 this sequence has been
realized. Treatment of sulfide 7 with m-chloroperbenzoic acid (m-CPBA)10 gave sulfone 8 in 94%
yield.11 After some experimentation12 it was found that photolysis of sulfone 8 in 1:1 benzene–acetone
(350 W Hanovia medium pressure lamp, pyrex filter, 2 h) gave the desired hydrocarbon 9 (mp
105–105.5°C) in 95% yield.13 The identity of 9 was confirmed by comparison with a known sample,
prepared by photolysis of 6 and diphenylacetylene to give 9 (mp 105–106°C) in 48% yield.14 The two
samples were identical by IR and 1H and 13C NMR spectroscopy.
Scheme 2.
Along the lines of our previous work involving the 1,3-dipolar cycloaddition reaction of münchnones
with cyclooctatetraene (COT),4b we are currently examining the reaction of COT with 1,3-oxathiolium-
5-olate 5 as a route to the pentaprismane ring system. Also, efforts to extend this chemistry to additional
reactions of 1,3-oxathiolium-5-olates and other mesoionic heterocycles are in progress.
In conclusion, we have shown that the mesoionic heterocycle 2,4-diphenyl-1,3-oxathiolium-5-olate (5)
undergoes a tandem 1,3-dipolar cycloaddition reaction with cycloocta-1,5-diene to form cycloadduct 7.
This sulfide is easily transformed by oxidation and photochemical extrusion of SO2 to caged hydrocarbon
9 in high yield.
