B. Schmidt, S. Hauke
FULL PAPER
were dried with MgSO4 and filtered, and the solvents were evapo-
rated. The residue was purified by chromatography on silica to give
4a (80 mg, 0.35 mmol, 50%) as a colourless liquid, along with unre-
acted starting material 3 (40 mg, 0.18 mmol, 26%).
13C NMR (75 MHz, CDCl3): δ = 134.0 (1), 119.9 (2), 94.3 (2), 81.9
(1), 69.3 (1), 55.5 (3), 17.8 (3) ppm. IR (neat): ν = 3445 (w), 2889
˜
(w), 1152 (m), 1096 (s), 1026 (s), 919 (s) cm–1. MS (EI): m/z (%) =
147 (39) [M + H]+, 141 (33), 115 (42), 99 (100). HRMS (ESI):
calcd. for C7H15O3 [M + H]+ 147.1021; found 147.1033. C7H14O3
(146.18): calcd. C 57.5, H 9.7; found C 57.5, H 9.8.
1
Analytical data for 4a: [α]2D4 = –12.2 (c = 0.63, CH2Cl2). H NMR
(300 MHz, CDCl3): δ = 5.71 (ddd, J = 17.3, 10.5, 7.6 Hz, 1 H),
5.28–5.18 (m, 2 H), 3.77 (qd, J = 6.2, 5.0 Hz, 1 H), 3.34 (ddm, J
= 7.5, 5.0 Hz, 1 H), 3.30 (s, 3 H), 1.14 (d, J = 6.2 Hz, 3 H), 0.85
(s, 9 H), 0.04 (s, 3 H), 0.03 (s, 3 H) ppm. 13C NMR (75 MHz,
CDCl3): δ = 136.2, 118.3, 87.8, 70.8, 56.8, 25.9, 19.9, 18.1, –4.5,
(R)-3-(Methoxymethoxy)pent-4-en-2-one (7): Dess–Martin
periodinane (3.82 g, 9.0 mmol) was added to a solution of 6 (1.32 g,
9.0 mmol) in dry, degassed CH2Cl2 (30 mL) at 0 °C. The mixture
was warmed to ambient temperature and stirred for 1 h. Then it
was diluted with CH2Cl2 and washed repeatedly with a saturated
aqueous solution of NaHCO3 and Na2S2O3·5H2O (250 g/L). The
aqueous layer was separated and extracted with CH2Cl2, the com-
bined organic extracts were dried with MgSO4 and filtered, and
the solvents were evaporated. The residue was purified by column
chromatography to give ketone 7 (1.23 g, 8.6 mmol, 95 %) as a
colourless liquid. [α]2D2 = –35.6 (c = 0.56, CH2Cl2). 1H NMR
(300 MHz, CDCl3): δ = 5.77 (ddd, J = 17.0, 10.4, 6.5 Hz, 1 H),
5.46 (ddd, J = 17.2, 1.3, 1.3 Hz, 1 H), 5.36 (ddd, J = 10.4, 1.3,
1.3 Hz, 1 H), 4.71 (d, J = 6.7 Hz, 1 H), 4.62 (d, J = 6.7 Hz, 1 H),
4.51 (ddd, J = 6.5, 1.3, 1.3 Hz, 1 H), 3.37 (s, 3 H), 2.18 (s, 3 H)
ppm. 13C NMR (75 MHz, CDCl3): δ = 206.3 (0), 132.4 (1), 119.9
–4.6 ppm. IR (neat): ν = 2929 (m), 2856 (m), 1252 (m), 1116 (s),
˜
924 (s), 830 (s), 777 (s) cm–1. MS (EI): m/z (%) = 231 (37)
[M + H]+, 227 (57), 213 (93), 199 (100), 99 (8). HRMS (ESI): calcd.
for C12H27O2Si [M + H]+ 231.1780; found 231.1784. C12H26O2Si
(230.42): calcd. C 62.6, H 11.4; found C 62.5, H 11.8.
Analytical data for 4b: [α]2D2 = –1.5 (c = 0.68, CH2Cl2). H NMR
1
(300 MHz, CDCl3): δ = 5.86 (ddd, J = 17.2, 10.5, 5.8 Hz, 1 H),
5.24 (ddd, J = 17.2, 1.7, 1.7 Hz, 1 H), 5.14 (ddd, J = 10.4, 1.9,
1.4 Hz, 1 H), 4.07 (dddd, J = 5.7, 4.2, 1.4, 1.4 Hz, 1 H), 3.36 (s, 3
H), 3.22 (qd, J = 6.3, 4.2 Hz, 1 H), 1.09 (d, J = 6.3 Hz, 3 H), 0.91
(s, 9 H), 0.07 (s, 3 H), 0.03 (s, 3 H) ppm. 13C NMR (75 MHz,
CDCl3): δ = 138.6, 115.4, 80.9, 76.2, 57.1, 25.9, 18.2, 14.9, –4.5,
(2), 94.9 (2), 83.1 (1), 55.9 (3), 25.6 (3) ppm. IR (neat): ν = 2893
˜
–4.7 ppm. IR (neat): ν = 2929 (m), 2857 (m), 1252 (m), 1102 (s),
˜
(w), 1719 (s), 1152 (s), 1036 (s), 919 (s) cm–1. MS (EI): m/z (%) =
167 (5) [M + Na]+, 143 (58), 121 (20), 113 (100), 99 (8). HRMS
(ESI): calcd. for C7H12O3Na [M + Na]+ 167.0684; found 167.0697.
1031 (m), 834 (s), 775 (s) cm–1. MS (EI): m/z (%) = 231 (26) [M +
H]+, 227 (33), 213 (100), 199 (17), 113 (20), 99 (35). HRMS (ESI):
calcd. for C12H28O2Si [M + H]+ 231.1780; found 231.1799.
C12H27O2Si (230.42): calcd. C 62.6, H 11.4; found C 62.7, H 11.1.
(R)-3-(Methoxymethoxy)-2-methylpent-4-ene-2-ol (8): A solution of
7 (1.01 g, 7.0 mmol) in dry, degassed CH2Cl2 (30 mL) was cooled
to 0 °C. MeMgCl (3 m in THF; 4.7 mL, 14.0 mmol) was slowly
added by syringe, and the reaction mixture was stirred at 0 °C for
1 h. The reaction mixture was poured into a stirred water/diethyl
ether mixture, and a saturated aqueous solution of tartaric acid
was added. The organic layer was separated, the aqueous layer was
extracted with diethyl ether, and the combined organic layers were
washed with brine and then dried with MgSO4. The residue was
purified by column chromatography on silica to give 8 (937 mg,
5.9 mmol, 84%) as a colourless liquid. [α]2D2 = –78.5 (c = 0.98,
CH2Cl2). 1H NMR (300 MHz, CDCl3): δ = 5.72 (ddd, J = 17.2,
10.5, 8.2 Hz, 1 H), 5.35–5.24 (m, 2 H), 4.72 (d, J = 6.7 Hz, 1 H),
4.57 (d, J = 6.7 Hz, 1 H), 3.77 (d, J = 8.2 Hz, 1 H), 3.39 (s, 3 H),
2.44 (s, 1 H), 1.20 (s, 3 H), 1.16 (s, 3 H) ppm. 13C NMR (75 MHz,
CDCl3): δ = 134.5 (1), 120.2 (2), 94.2 (2), 84.8 (1), 71.8 (0), 55.7
(2S,3R)-2-(tert-Butyldimethylsilyloxy)-3-(methoxymethoxy)pent-4-
ene (5): A solution of 3 (2.00 g, 9.2 mmol) in dry, degassed CH2Cl2
(100 mL) was cooled to 0 °C. MOM bromide (90 wt.-%; 1.7 mL,
18.7 mmol) and NEt(iPr)2 (4.7 mL, 33.8 mmol) were added, and
the reaction mixture was heated to reflux for 12 h. The reaction
was quenched by the addition of water, then the aqueous layer was
separated and extracted with MTBE. The combined organic ex-
tracts were dried with MgSO4 and filtered, and the solvents were
evaporated. The residue was purified by column chromatography
on silica to give 5 (2.35 g, 9.0 mmol, 98%) as a colourless liquid.
[α]2D2 = –56.0 (c = 0.53, CH2Cl2). H NMR (300 MHz, CDCl3): δ
1
= 5.73 (ddd, J = 16.9, 10.8, 7.4 Hz, 1 H), 5.29–5.19 (m, 2 H), 4.70
(d, J = 6.6 Hz, 1 H), 4.58 (d, J = 6.6 Hz, 1 H), 3.87–3.77 (m, 2 H),
3.37 (s, 3 H), 1.15 (d, J = 6.1 Hz, 3 H), 0.88 (s, 9 H), 0.06 (s, 3 H),
0.05 (s, 3 H) ppm. 13C NMR (75 MHz, CDCl3): δ = 135.6 (1),
118.6 (2), 94.0 (2), 81.7 (1), 70.8 (1), 55.4 (3), 25.8 (3), 19.6 (3), 18.1
(3), 26.1 (3), 24.6 (3) ppm. IR (neat): ν = 3465 (w), 2976 (w), 1372
˜
(w), 1146 (m), 1030 (s), 919 (s) cm–1. MS (EI): m/z (%) = 161 (55)
[M + H]+, 139 (24), 129 (73), 113 (44), 99 (23), 91 (100). HRMS
(ESI): calcd. for C8H17O3 [M + H]+ 161.1178; found 161.1182.
C8H16O3 (160.21): calcd. C 60.0, H 10.1; found C 60.2, H 9.9.
(0), –4.6 (3), –4.7 (3) ppm. IR (neat): ν = 2929 (w), 2857 (w), 1252
˜
(m), 1100 (m), 1034 (s), 830 (s), 774 (s) cm–1. MS (EI): m/z (%) =
283 (4) [M + Na]+, 265 (19), 227 (100), 213 (82), 199 (33), 159 (33),
147 (21), 133 (28), 115 (49). HRMS (ESI): calcd. for C13H28O3NaSi
[M + Na]+ 283.1705; found 283.1719. C13H28O3Si (260.45): calcd.
C 60.0, H 10.8; found C 60.0, H 11.0.
(R)-3-[(Methoxymethoxy)-2-methylpent-4-en-2-yl]acrylate (9):
NEt(iPr)2 (1.00 mL, 12.6 mmol) and acryloyl chloride (2.7 mL,
15.7 mmol) were added to a solution of 8 (1.00 g, 6.3 mmol) in dry,
degassed CH2Cl2 (20 mL). The mixture was heated to reflux for
8 h, and then it was stirred at ambient temperature for 10 h. The
reaction was quenched by the addition of aqueous NaHCO3 solu-
tion, and the mixture was extracted with MTBE. The organic layer
was separated, dried with MgSO4 and filtered, and the solvents
were evaporated. The residue was purified by column chromatog-
raphy on silica to give 9 (1.20 g, 5.5 mmol, 87%) as a colourless
liquid. [α]2D5 = –64.0 (c = 0.84, CH2Cl2). 1H NMR (300 MHz,
CDCl3): δ = 6.31 (dd, J = 17.3, 1.4 Hz, 1 H), 6.05 (dd, J = 17.3,
(2S,3R)-3-(Methoxymethoxy)pent-4-ene-2-ol (6): Compound 5
(2.30 g, 8.8 mmol) and TBAF·3H2O (4.62 g, 17.7 mmol) were dis-
solved in THF (100 mL), and the mixture was stirred for 16 h at
ambient temperature. The mixture was diluted with diethyl ether
and washed with brine. The organic layer was separated, dried with
MgSO4, and filtered, and the solvents were evaporated. The residue
was purified by column chromatography on silica using pentane/
diethyl ether (5:1) as eluent, to give 6 (1.19 g, 8.2 mmol, 93%) as a
colourless liquid. [α]2D1 = –111.6 (c = 0.68, CH2Cl2). 1H NMR
(300 MHz, CDCl3): δ = 5.76 (ddd, J = 17.4, 10.6, 7.6 Hz, 1 H),
5.37–5.25 (m, 2 H), 4.71 (d, J = 6.7 Hz, 1 H), 4.60 (d, J = 6.7 Hz, 10.3 Hz, 1 H), 5.82–5.68 (m, 2 H), 5.36–5.28 (m, 2 H), 4.70 (d, J
1 H), 3.93 (dd, J = 7.6, 3.8 Hz, 1 H), 3.87 (qd, J = 6.3, 3.8 Hz, 1
H), 3.38 (s, 3 H), 2.28 (br. s, 1 H), 1.14 (d, J = 6.4 Hz, 3 H) ppm.
= 6.7 Hz, 1 H), 4.56 (d, J = 6.7 Hz, 1 H), 4.36 (d, J = 7.8 Hz, 1
H), 3.37 (s, 3 H), 1.51 (s, 3 H), 1.53 (s, 3 H) ppm. 13C NMR
