Atropisomerization, C-H activation, and dissociative substitution at some biphenyl platinum(II) complexes

Article abstract of DOI:10.1021/ja030486u

The reaction of 2,2′-dilithiumbiphenyl with cis-[PtCl ₂(SEt₂)₂] at -10 °C in diethyl ether not only leads to the main product [Pt₂(μ-SEt₂) ₂(bph)₂], containing the planar 2,2′-bi

Full text of DOI:10.1021/ja030486u

Published on Web 04/28/2004
Atropisomerization, C-H Activation, and Dissociative
Substitution at Some Biphenyl Platinum(II) Complexes
Maria Rosaria Plutino,‡ Luigi Monsu’ Scolaro,†,§ Alberto Albinati,| and
Raffaello Romeo*,†
Contribution from the Dipartimento di Chimica Inorganica, Chimica Analitica e Chimica Fisica,
UniVersita` di Messina - Salita Sperone, 31 - Vill. S. Agata - 98166 Messina, Italy,
ISMN - CNR, Sezione di Palermo, Unita` di Messina, INFM, Unita` di Messina, and
Dipartimento di Chimica Strutturale e Stereochimica Inorganica, Facolta` di Farmacia,
UniVersita` di Milano, 20133 Milano, Italy
Received August 7, 2003; E-mail: raf.romeo@chem.unime.it
Abstract: The reaction of 2,2′-dilithiumbiphenyl with cis-[PtCl2(SEt2)2] at -10 °C in diethyl ether not only
leads to the main product [Pt2(µ-SEt2)2(bph)2], containing the planar 2,2′-biphenyl dianion (bph2-), but also
forms a new dinuclear platinum(II) compound of formula [Pt2(µ-SEt2)2(Hbph)4], 1a (Hbph- ) η1-biphenyl
monoanion), in which each metal is in a square-planar environment. NMR spectroscopy and molecular
mechanics (MMFF) calculations were used to characterize 1a. The results suggest that the favored
conformation for the four Hbph biphenyl groups is RââR. In chloroform solution, 1a undergoes atrop-
isomerization to 1b (RâRâ) (kis ) 1.03 × 10-4 s-1, at 298 K) that subsequently cyclometalates (kobs ) 4.48
× 10-6 s-1, at 298 K) to yield [Pt2(µ-SEt2)2(bph)2] and biphenyl. Both processes, atropisomerization and
C-H activation, presumably involve preliminary thioether bridge splitting. The dinuclear complex 1a has
been shown to be a versatile and useful precursor to a variety of mononuclear η1-biphenyl platinum(II)
complexes. By reaction with diethyl sulfide, dimethyl sulfoxide, or with rigid dinitrogen containing ligands,
such as 2,2′-bipyridine or 1,10-phenanthroline, complexes cis-[Pt(Hbph)2(dmso)2] 3, cis-[Pt(Hbph)2(SEt2)2]
4, [Pt(Hbph)2(bpy)] 5, and [Pt(Hbph)2(phen)] 6 were obtained, respectively. The crystal structures of
compounds 5 and 6 were determined. Only the head-to-tail isomer of these compounds was recognized
in the solid state and in solution, where restricted rotation around the Pt-C bond prevents interconversion
to the head-to-head form. A detailed kinetic study of ligand (dmso) exchange and substitution (by 2,2′-
bipyridine and 1,10-phenanthroline) has been performed on complex 3 in CDCl3 and toluene-d8 by 1H
NMR magnetization transfer experiments, and in toluene by UV/vis spectroscopy, respectively. The rates
of both processes show no dependence on ligand concentration, the rate of ligand substitution being in
reasonable agreement with that of ligand exchange at the same temperature. The kinetics are characterized
by largely positive entropies of activation. The results are consistent with a dissociative mode of activation
analogous to the pattern already found for compounds with a similar [Pt(C,C)(S,S)] set of coordinating
ligands. The role of ML3 d8 T-shaped 14-electron species, as elusive reaction intermediates or structurally
characterized compounds, is discussed.
Introduction
picture currently appears to be reasonably clear, and it involves
the direct attack of a nucleophile on the substrate with formation
A rational design of square-planar platinum(II) compounds
with specific therapeutic properties requires a deep knowledge
of their substitution behavior, because it is necessary to predict
what happens along the way to the biological target and what
the reactivity will be in a biological environment.1 Thus,
following Rosenberg’s discovery of the antitumor properties of
cis-platin,2 studies on substitution reactions of Pt(II) complexes
have received an increasing renewal of interest. The mechanistic
of a transient five-coordinate intermediate.3 Old concepts have
been revisited, such as the trans and cis effects in their σ and π
components,4 steric effects, nucleophilic and nucleofuge abilities
(3) (a) Tobe, M. L.; Burgess, J. Inorganic Reaction Mechanisms; Addison-
Wesley Longman: Essex, England, 1999. (b) Wilkins, R. G. Kinetics and
Mechanisms of Reactions of Transition Metal Complexes; VCH: Weinheim,
Germany, 1991. (c) Tobe, M. L. In Comprehensive Coordination Chemistry;
Wilkinson, G., Ed.; Pergamon Press: Oxford, U.K., 1987; Vol. 1, pp 311-
329. (d) Atwood, J. D. Inorganic Organometallic Reaction Mechanisms;
Brook/Cole: Monterey, CA, 1985. (e) Basolo, F.; Pearson, R. G. Mech-
anisms of Inorganic Reactions; Wiley: New York, 1968. (f) Langford, C.
H.; Gray, H. B. Ligand Substitution Processes; W. A. Benjamin: New
York, 1965. (g) Basolo, F. Coord. Chem. ReV. 1996, 154, 151-161.
(4) (a) Otto, S.; Elding, L. I. J. Chem. Soc., Dalton Trans. 2002, 2354-2360.
(b) Wendt, O. F.; Elding, L. I. Inorg. Chem. 1997, 36, 6028-6032. (c)
Wendt, O. F.; Elding, L. I. J. Chem. Soc., Dalton Trans. 1997, 4725-
4731. (d) Schmu¨lling, M.; Grove, D. M.; van Koten, G.; van Eldik, R.;
Veldman, N.; Spek, A. L. Organometallics 1996, 15, 1384-1391.
† Dipartimento di Chimica Inorganica, Universita` di Messina.
‡ ISMN - CNR, Unita` di Messina.
§ INFM, Unita` di Messina.
| Universita` di Milano.
(1) Cisplatin: Chemistry and Biochemistry of a Leading Anticancer Drug;
Lippert, B., Ed.; Wiley-VCH: Weinheim, 1999.
(2) Rosenberg, B.; Van Camp, L.; Trosko, J. E.; Mansour, V. H. Nature 1969,
222, 385-386.
9
6470
J. AM. CHEM. SOC. 2004, 126, 6470-6484
10.1021/ja030486u CCC: $27.50 © 2004 American Chemical Society

Biphenyl Platinum(II) Complexes
A R T I C L E S
