reasonable that 1-ethylpyrazole and other alkylpyrazoles
could be reactive as well.
Optimization was carried out with respect to the silver
source and additives (Table 1). A reasonable arylation rate
was observed at 1308C in acetic acid, while reactions in other
solvents, such as H2O, DMF, acetonitrile, t-butanol, dioxane,
Table 1: Optimization of reaction conditions.[a]
Entry
Ag source
Additive(s)
Yield [%]
1
2
3
4
AgOAc
AgOAc
AgOAc
AgOAc
AgOCOCF3
AgOAc
Ag2O
none
NaOCOCF3
NaOTf
LiOTf
LiOTf
LiOTf/TFA
LiOTf/TFA
LiOTf/TFA
LiOTf/TFA/LiOAc
18
48
63
63
79
75
77
76
81
Scheme 2. Other directing groups.
5
6[b]
7[c]
8[d]
9[e]
methyl-substituted compounds gave arylation products in
yields that are slightly lower than those for 1-ethyl-3,5-
dimethylpyrazole (2-1 to 2-3). Pyrazoles possessing aryl
substituents are also reactive, and products were obtained in
fair to good yields (2-4, 2-5). Ethyltriazoles were not arylated
under the optimized conditions (2-6 and 2-7). This result
demonstrates the higher efficiency of bidentate coordination
Ag2O
Ag2O
[a] Pyrazole 0.2 mmol, 4-iodotoluene 0.6 mmol, AcOH 0.2 mL, additive
0.3 mmol. Yields were determined by GC analysis. [b] Additives: LiOTf
1.2 equiv, trifluoroacetic acid 1.5 equiv. [c] Silver oxide 0.75 equiv,
additives: LiOTf 1.2 equiv, trifluoroacetic acid 1.5 equiv. [d] Silver oxide
0.75 equiv, additives: LiOTf 1.2 equiv, trifluoroacetic acid 1.5 equiv,
hexafluoropropanol/AcOH solvent (3:1), 1208C. [e] Silver oxide
0.8 equiv, additives: LiOTf 1.2 equiv, trifluoroacetic acid 1.7 equiv, LiOAc
1.6 equiv, 1058C, yield of isolated product. OTf=ÀOSO2CF3,
TFA=CF3CO2H.
À
in C H functionalization, since triazoles possessing an addi-
À
tional chelating group are efficient auxiliaries for C H
functionalization.[4j,13] Overall, 3,5-dimethylpyrazole is the
optimal auxiliary for the arylation, based both on reactivity
and cost.
The reaction scope with respect to the aryl iodides is
presented in Table 2. The reactions were successful with both
electron-rich (entries 1–6) and electron-poor (entries 8–13)
aryl iodides. Various functionalities, such as methoxy
(entries 4, 6), chloro (entries 7, 8), trifluoromethyl (entry 9),
ester (entry 10), ketone (entry 11), trifuoromethoxy
(entry 12), and fluoro (entry 13) groups are tolerated. The
reaction can be scaled to 10 mmol without any loss in yield
(entry 7). Typically, the arylations with electron-poor aryl
iodides were slower than those with electron-rich substrates.
dichloroethane, and cyclooctane afforded very low conver-
sions. Entry 1 shows that arylation in acetic acid by using
silver acetate as the base and halide-removing agent gives
product in only 18% yield. Addition of sodium trifluoroace-
tate improved the yield to 48% (entry 2). Even higher yields
are obtained if sodium triflate is employed as an additive
(entry 3). Lithium triflate as an additive gave the same yield
as the sodium salt, thus showing that the anion is important in
arylation (entry 4). The use of silver trifluoroacetate in
combination with lithium triflate further improved the yield
to 79% (entry 5). Attempts to replace the expensive silver
trifluoroacetate with a cheaper silver source were fruitful, as
shown in entries 6 and 7. The use of a silver acetate mixture
with trifluoroacetic acid gave a 75% yield of arylation
product (entry 6). It is possible to replace AgOAc with
Ag2O, which is one of the cheapest commercially available
silver salts (entry 7). An acetic acid/hexafluoroisopropanol
solvent mixture gives the same yield as the reaction run in
pure acetic acid (entry 8); however, for electron-poor aryl
iodides, this is the best solvent combination. Finally, addition
of LiOAc slightly increases the yield, allows the reaction to
occur at 1058C, and gives more reproducible reaction yields at
larger scale (entry 9). No reaction was observed if Pd(OAc)2
was omitted. The use of bases other than silver salts resulted
in very low conversions.
À
This trend is also often observed for C H functionalization
when employing bidentate auxiliaries.[3b]
The reaction scope with respect to the alkyl on the
pyrazoles is presented in Table 3. The isopropyl derivative
was arylated in 50% yield (entry 1), while the s-butyl-
substituted compound reacted at the methyl group to afford
product in 60% yield (entry 2). Larger alkyl groups are
tolerated as well (entries 3 and 4). Phenethyl and phenyl-
propylpyrazoles afforded the products in 53 and 56% yields
(entries 5 and 6). A compound possessing an ester substitu-
tion was arylated in 55% yield (entry 7).
Directed functionalization of secondary, unactivated (not
3
À
benzylic or a to heteroatom) sp C H bonds is relatively rare.
Besides bidentate monoanionic auxiliaries, which can pro-
mote the activation of even some tertiary positions,[14] few
À
directing groups can effect methylene C H bond functional-
Other directing groups were tested under the optimized
conditions (Scheme 2). Unsubstituted ethylpyrazole and
ization. We were pleased to discover that dimethylpyrazole
À
directs the arylation of some secondary and even tertiary C
2
