Following the method described by Feng et al.,25 the phosphonate 2 (0.9 g, 2.7 mmol) was placed
under argon and dissolved in dry THF (15mL). To this was added t-BuOLi (0.2 g, 2.2 mmol) and
the suspension was stirred for 15 minutes. After this time a solution of the 6-azido mannose
derivative 5b (0.4 g, 1.6 mmol) in dry THF (10 ml) was added via syringe to the reaction mixture.
The reaction mixture was heated to ~50oC and was then stirred for 1 hour. The reaction mixture
was diluted with saturated NH4Cl (~20 mL) and any non-aqueous solvent was removed under
reduced pressure. The aqueous residue was then extracted with EtOAc (3 x 20 mL). The organic
phases were combined, dried (Na2SO4), filtered and concentrated under reduced pressure. The
resulting residue was then used in the next step without further purification.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
The residue was dissolved in THF (5 mL) and the reaction mixture was cooled to 0oC with an ice
bath. To this was added 20% AcOH/H2O (5.6 mL) and 1M TBAF in THF (1.6 g, 6.0 mL, 6.0
mmol). The reaction mixture was warmed to room temperature and was stirred for 3 hours. The
reaction mixture was then neutralized with the addition of NaHCO3, filtered and concentrated
under reduced pressure. The residue was then dissolved in EtOAc (50 mL), washed with saturated
NaHCO3, dried (Na2SO4), filtered and concentrated under reduced pressure. The residue was
purified via (1:2, EtOAc:hexane, v/v, Rf: 0.19) to give the 8-azido KDO derivative 6b (292 mg,
0.88 mmol, 54%) as a slightly yellow, viscous liquid.
1H NMR (400MHz, CDCl3, α/β mixture): δ (ppm) α anomer (major) – δ 4.56-4.52 (1H, m, H4),
4.33 (1H, dd, J5,4 = 6.2, J5,6 = 2.4 Hz, H5), 4.27 (2H, q, J = 6.9 Hz, CO2CH2CH3), 4.10 (1H, ddd,
J7,6 = 8.2, J7,8’ = 5.9, J7,8 = 2.9 Hz, H7), 4.04 (1H, dd, J6,7 = 8.2, J6,5 = 2.4 Hz, H6), 3.57 (1H, dd,
J8,8’ = 12.6, J8,7 = 2.9 Hz, H8), 3.46 (1H, dd, J8’,8 = 12.6, J8’,7 = 5.9 Hz, H8’), 2.58 (1H, d, J3e,4 = 7.4
Hz, H3e), 1.93 (1H, dd, J3a,3e = 14.2, J3a,4 = 5.3 Hz, H3a), 1.48, 1.36 (2 x 3H, 2 x s, 2 x (CH3)2CO),
1.32 (3H, t, J = 6.9 Hz, CO2CH2CH3); β anomer (minor) 4.74 (1H, ddd, J4,5 = 7.9, J4,3e = J4,3a = 3.1
Hz, H4), 4.53 (1H, dd, J5,4 = 7.9, J5,6 = 1.9 Hz, H5), 4.27 (2H, q, J = 6.9 Hz, OCH2CH3), 4.00 (1H,
ddd, J7,6 = 8.8, J7,8’ = 6.0, J7,8 = 2.9 Hz, H7), 3.66 (1H, dd, J8,8’ = 12.6, J8,7 = 2.9 Hz, H8), 3.59-3.53
(1H, m, H6), 3.45 (1H, dd, J8’,8 = 12.6, J8’,7 = 6.0 Hz, H8’), 2.38 (1H, dd, J3a/3e = 14.2, J3a,4 = 3.1
Hz, H3a), 2.32 (1H, d, J3e/4 = 3.1 Hz, H3e), 1.55, 1.38 (2 x 3H, 2 x s, 2 x (CH3)2CO), 1.33 (3H, t,
13
J = 6.9 Hz, CO2CH2CH3); C NMR {DEPTQ-135} (100MHz, CDCl3, α/β mixture): δ (ppm) α
isomer (major)- 169.7 (C1), 109.4 ((CH3)2CO)), 94.6 (C2), 71.1, 70.2, 70.1, 69.9 (all CH, C4, C5,
C6, C7), 62.7 (CO2CH2CH3), 53.9 (C8), 32.7 (C3), 27.6, 26.1 (2 x (CH3)2CO), 14.1 (CO2CH2CH3);
β anomer (minor)-169.0 (C1), 109.8 ((CH3)2CO)), 95.6 (C2), 72.8, 72.3, 70.9, 69.4 (all CH, C4,
C5, C6, C7), 62.3 (CO2CH2CH3), 54.0 (C8), 31.2 (C3), 26.3, 24.5 (2 x (CH3)2CO), 14.2
(CO2CH2CH3). IR (neat) 3440, 2102, 1740cm-1. HRMS (ESI-QTOF) m/z: [M+Na]+ Calcd for
C13H21O7N3Na (354.1272), found 354.1269.
