of the order of 1 ꢀm in size to cause such
a failure. Traditionally, this problem was
addressed in two ways: by modifying
materials in order to enhance thin-film
strength and interface adhesion as well
as to reduce various stresses, and by
rigorous reliability testing to reveal any
weak links that can be fixed by altering
local structures. While these approaches
were not systematic, they did apply
thin-film fracture mechanics empirically
or intuitively. In fact, because fracture-
related failures were often observed
to occur after exposure to moisture or
temperature cycles, reliability tests were
designed to mimic such environments,
and structures—guard rings and
passivation layers—were widely used
to keep moisture out.
Mechanical
Properties in
Small Dimensions:
Comments from
Industry
Recently, it is increasingly being
recognized that more systematic studies
of fracture mechanisms/mechanics are of
critical importance. This has been driven
by shortened technology-development
cycles and the adoption of new
interconnect materials such as copper
and low-k dielectrics. Progress made so
far has already provided more accurate
root-cause analyses for observed failures
and several clear directions for further
materials development. Studies are
also showing that failure sites in IC
interconnects are often isolated with a
locally maximized fracture driving force;
therefore, eliminating vulnerable
structures by using fracture-mechanics-
based design rules can dramatically
increase the reliability safety margin.
Qing Ma
The following are commentaries provided by representatives from industry.
These short articles lend an additional context in which to appreciate the
importance of the issues and mechanisms discussed in the technical articles.
The authors of the commentaries point out that the basic principles that
underlie the influence of scale on material behavior are not only interesting
in their own right, but also are directly applicable to issues of great
significance to designers and manufacturers of small-scale devices and
structures. In addition, directions for future emphasis are suggested.
Richard P. Vinci
Shefford P. Baker
Guest Editors
Control of Stresses in Silicon-Device
Technical Manager, Intel Laboratories
Intel Corporation
The article provides a discussion of
Manufacturing
several prior models and mechanisms
related to thin-film stresses and gives
enough detail to examine the differences
experimentally. Since many of the thin
films used in silicon devices, such as
contacts and diffusion-barrier layers,
are barely thicker than their coalescence
thickness, a careful evaluation of the
mechanisms described by Floro et al.
may help to control their properties to
even smaller dimensions.
In the development and manufacturing
of silicon devices, the control of thin-film
stresses continues to be a major challenge.
High stresses can cause deformation,
delamination, cracking, and void
formation. They may also directly affect
device characteristics. In multilevel
interconnections now being developed,
low-dielectric-constant insulators are
being introduced that have drastically
weaker mechanical properties than
the glassy SiO2 used for decades.
These factors, together with rapidly
decreasing dimensions, require a greater
understanding of the origins of thin-film
stresses. High stresses are created by
thermal-expansion mismatch during
the heating cycles required for fabrication,
and they are also a by-product of the film
microstructure. These microstructure-
induced stresses are referred to as
“intrinsic” stresses and are the subject of
the article by Floro et al. in this issue.
Diffusion and Stresses in
Interconnect Structures
Diffusion processes play an important
role in determining the reliability of
interconnect structures in semiconducting
devices. In particular, diffusional growth
of voids in metal lines can cause
resistance shifts in interconnects that
lead to circuit failure. The driving force
for diffusion is frequently a gradient
in hydrostatic stress, although shear
deformation by diffusional-creep
mechanisms can be important in some
instances. One of the primary sources
of stress is the mismatch in thermal
expansion between the metal
interconnects and the surrounding
dielectric. On cooling from processing
temperatures, the metal lines tend to
contract more than the surrounding
dielectric, resulting in hydrostatic tension
in the lines that can exceed 1 GPa. In the
James M.E. Harper
Manager, Thin-Film Metallurgy and
Interconnections
IBM T.J. Watson Research Center
Fracture in Small Dimensions
Ensuring long-term integrated-circuit
interconnect reliability has always been
challenging, given that a single electrical
failure of an individual interconnect
line or via, among millions of such
microfeatures, can destroy the whole
chip. Furthermore, a crack need only be
52
MRS BULLETIN/JANUARY 2002

Mechanical Properties in Small Dimensions: Comments from Industry
absence of preexisting imperfections,
only shear stresses in a line are relaxed.
Relaxation of the hydrostatic-stress
component requires the nucleation of
a void. Once formed, voids can locally
relax hydrostatic tension, leading to
hydrostatic-stress gradients that drive
further void growth. A second process
that can lead to void growth is
electromigration. In this case, diffusion
takes place due to the momentum
transfer from an electron flux in the line
to metal atoms in the line. The motion of
atoms due to the electron “wind” can
result in atoms piling up at one end of
the line, leaving a void at the other end.
In lines that are confined in a dielectric,
a corresponding hydrostatic-stress
gradient arises that opposes the atom
flux. In short lines, this gradient can
become sufficient to completely shut
down the electromigration flux.
It can be seen that diffusion and void
growth in interconnect structures is
intimately connected with their stress
state. Complete modeling of void-
growth phenomena therefore requires
simultaneous modeling of both the stress
state and diffusional fluxes in the
structure. Considerable advances have
been made in understanding the behavior
of isotropic metal lines encased in a rigid
dielectric. While such models are
appropriate for the case of aluminum
lines encased in an oxide dielectric, more
advanced modeling is required when
considering the case of anisotropic
metals such as copper and soft, low-
permittivity dielectrics that are currently
being introduced to enhance circuit
performance. With anisotropic metals,
discontinuities in the elastic modulus
can occur on crossing grain boundaries,
resulting in grain-to-grain variations in
the stress state of a line. Such effects may
enhance void nucleation and growth
when specific grain orientations or
textures are present. An understanding of
the specific effects that details of the line
microstructure have on void growth is
likely to require computer models in
which stress and diffusion modeling are
linked at the microstructure scale.
significant effect on diffusion at one
or more of these interfaces. A classic
example is copper at grain boundaries in
aluminum metal lines that can reduce the
rate of void growth by electromigration
by orders of magnitude. Despite more
than 30 years of study, the fundamental
origin of this effect has still to be found.
Such understanding is likely to require
detailed atomistic modeling of the
interaction of solutes with grain
boundaries as well as simulations of
how diffusion processes take place at
grain and phase boundaries. Thus,
computer modeling has an important
role to play in understanding diffusion
in interconnects at both the atomistic
and microstructural scales.
unstable, even at room temperature, due
to the small grain size and the presence of
a significant number of atomic defects.
The grain size is often on the nanometer
scale, and the dislocation density can be
large, leading to a ꢀ20% higher electrical
resistance than in bulk copper. These
characteristics are undesirable in an
interconnect material.
As a result, atomic defects need to be
removed during processing in order to
improve circuit performance and device
reliability. One of the common techniques
is to employ thermal annealing, which
promotes grain growth and reduces
electrical resistance. However, due to the
copper/dielectric thermal-mismatch-
induced stress and other unknown
mechanisms, trench and via voids can
form if the annealing condition is not
optimized. To avoid the formation of
stress-induced voids, process engineers
require knowledge of dislocation-
mediated stress-relaxation behavior for
different thermal conditions, film textures,
and interconnect-structure geometries.
Other length-scale-dependent mechanical
properties such as strain-gradient
plasticity should also be investigated
as circuit design layout reduces to
sub-0.1-ꢀm dimensions for the coming
generations of devices.
Thomas M. Shaw
Research Staff Member,
Silicon Technology Department
IBM T.J. Watson Research Center
The Industrial Significance of
Understanding Dislocation Behavior
inThin Films
Electrochemically deposited (ECD)
copper films are now commonly used in
the high-performance microelectronics
industry to increase ULSI (ultralarge-scale
integration) circuit performance and to
reduce manufacturing costs. However,
ECD copper has unique physical
Ting Y. Tsui
properties that pose significant challenges
during ULSI processing. For example,
as-deposited ECD copper thin films are
Member of Technical Staff,
Silicon Technology Research
Texas Instruments Inc.
Ad Deadlines • 2002 MRS Bulletin
March
February 1, 2002
Theme: Alternative Gate Dielectrics for Microelectronics
Guest Editors: Glen D. Wilk (Agere Systems) and Robert Wallace (University of North Texas)
Bonus Distribution: 2002 MRS Spring Meeting & Exhibit; International Conference on
Characterization and Metrology for ULSI Technology (Endorsed); 45th Society of Vacuum
Coaters (SVC) Annual Conference
April
March 1, 2002
A further important aspect of void
growth is understanding the diffusion
paths that contribute to vacancy fluxes.
Rarely is bulk diffusion active at the
operating temperatures for semi-
Theme: Combinatorial Materials Science
Guest Editors: Eric J. Amis (National Institute of Standards and Technology), Xiao-Dong
Xiang (Intematix Corporation), and Ji-Cheng Zhao (GE Corporate Research & Development)
May
conductors, and frequently there are
multiple parallel paths that contribute
to void growth. These may include
metal/metal grain boundaries and phase
boundaries and metal/dielectric interfaces.
In many cases, the addition of small
amounts of additives can have a
April 1, 2002
Theme: Optical Fiber Sensors
Guest Editors: Gerard Franklyn Fernando (Royal Military College of Science, United Kingdom),
David J. Webb (Aston University, Birmingham) and Pierre Ferdinand (CEA Leti, France)
Bonus Distribution: 8th International Conference on Electronic Materials, China (C-MRS)
