918 Journal of Medicinal Chemistry, 2008, Vol. 51, No. 4
Rodríguez et al.
was rinsed with EtOAc. The organic phase was extracted with water
(2 × 30 mL), washed with brine (1 × 30 mL), dried over anhydrous
Na2SO4, and concentrated under vacuum to give a residue that was
purified by column chromatography as specified.
4,4′-Bis[2,3-di(tert-butoxycarbonyl)guanidino]benzanilide (9d).
Following the general synthetic method A, the crude residue was
purified by silica gel column chromatography, eluting with hexane/
EtOAc (2:1) to yield 1.3 g (61%) of 9d as a white solid: mp >300
°C; MS (ESI+) m/z 712.3635 [M + H]+; IR (Nujol) ν 3368, 3291,
3261 (NH), 1738, 1720, 1645, 1627, 1608 (CO, CN) cm-1; 1H NMR
(CDCl3) δ 1.48 (s, 9H, (CH3)3), 1.51 (s, 9H, (CH3)3), 1.56 (s, 18H,
(CH3)3), 7.54 (d, 2H, J ) 8.6 Hz, Ar), 7.64 (d, 2H, J ) 8.0 Hz, Ar),
7.68 (d, 2H, J ) 8.0 Hz, Ar), 7.82 (d, 2H, J ) 8.6 Hz, Ar), 8.19
(broad s, 1H, PhNHCOPh), 10.30 (broad s, 1H, NHGu), 10.51 (broad
s, 1H, NHGu), 11.63 (broad s, 2H, NHGu); 13C NMR (CDCl3) δ 27.9,
28.0 ((CH3)3), 79.6, 80.0, 83.6, 84.0 (C(CH3)3), 120.6, 122.1, 123.4,
128.1, 131.2, 132.1, 135.9, 139.3 (Ar), 153.2, 153.7, 154.0
((CH3)3COCO), 163.1, 163.4 (CN), 165.2 (PhNHCOPh).
General Method B for the Removal of the Boc-Protecting
Groups and Regeneration of the Hydrochloride Salts. A solution
of the corresponding Boc-protected derivative (0.5 mmol) in 20
mL of CH2Cl2/TFA (1:1) was stirred at room temperature for the
appropriate duration. After that time, the solvent was eliminated
under vacuum to generate the trifluoroacetate salt. This salt was
dissolved in 20 mL of water and treated for 24 h with IRA400
Amberlyte resin in its Cl- form. Then the resin was removed by
filtration and the aqueous solution washed with CH2Cl2 (2 × 10
mL). Evaporation of the water afforded the pure dihydrochloride
salt as a hygroscopic solid. Absence of the trifluoroacetate salt was
checked by 19F NMR.
Alternative Method C for the Synthesis of the Boc-Protected
Guanidines 20d, 21d, and 23d. A solution of 4-[2,3-di(tert-
butoxycarbonyl)guanidino]aniline 8 in dry CH2Cl2 was treated under
an inert atmosphere and at 0 °C with the corresponding electrophile
(phenyl isocyanate for 20d, phenyl isothiocyanate for 21d, and
benzoyl chloride for 23d) and with Et3N (only in the case of 23d).
After the reaction mixture was allowed to reach room temperature,
it was stirred for the appropriate duration. Further workup followed
by column cromatography as specified afforded the corresponding
Boc-protected guanidine.
4,4′-Bis[1,3-di(tert-butoxycarbonyl)-2-imidazolidinylimino]ben-
zanilide (9e). Following the general synthetic method A, the crude
residue was purified by neutral alumina column flash chromatog-
raphy, eluting with hexane/EtOAc (1:4). The residue obtained after
the column was recrystallized from Et2O to yield 1.040 g (45%) of
9e as a white solid: mp 198–200 °C; IR (Nujol) ν 3346 (NH), 1733,
1
1709, 1689, 1663, 1598 (CO, CN) cm-1; H NMR (DMSO-d6) δ
1.30 (s, 36H, (CH3)3), 3.77 (s, 4H, CH2), 3.80 (s, 4H, CH2), 6.83
(d, 2H, J ) 8.5 Hz, Ar), 6.92 (d, 2H, J ) 8.5 Hz, Ar), 7.66 (d, 2H,
J ) 8.5 Hz, Ar), 7.89 (d, 2H, J ) 8.5 Hz, Ar), 9.92 (broad s, 1H,
NH); 13C NMR (DMSO-d6) δ 28.4, 28.5 ((CH3)3), 43.9, 44.0 (CH2),
82.4, 82.6 (C(CH3)3), 121.3, 121.6, 121.7, 128.6, 129.3, 134.8,
139.8, 141.0 (Ar), 145.1, 150.4, 150.6, 152.9 ((CH3)3COCO), CN),
165.4 (PhNHCOPh).
1,3-Bis(4-[2,3-di(tert-butoxycarbonyl)guanidino]phenyl)urea
(7d). Following the general synthetic method A, the crude residue
was purified by silica gel column chromatography, eluting with
hexane/EtOAc (3:1) to yield 1.24 g (57%) of 7d as a white solid:
mp >300 °C; MS (ESI+) m/z 727.3777 [M + H]+; IR (Nujol) ν
1,4-Bis[4-(N2,N3-bis(tert-butyloxycarbonyl)guanidino)phe-
nyl]piperidine (11d). General method A was used, with 598 mg
(2.2 mmol) of HgCl2, 268 mg (1.0 mmol) of 11, 553 mg (2.0 mmol)
of N,N′-di(tert-butoxycarbonyl)thiourea, and 0.9 mL (6.4 mmol)
of Et3N in CH2Cl2/DMF (1:2) (8 mL) at 0 °C. The resulting mixture
was stirred at 0 °C for 1 and 36 h more at room temperature. After
general workup, the residue was purified by silica gel column
chromatography, eluting with hexane/EtOAc (3:1) to yield 483 mg
(64%) of 11d as a white solid: mp, decomposes at 220 °C; MS
(ESI+) m/z 752.4326 [M + H]+; IR (Nujol) ν 3291, 3266 (NH),
3368, 3307, 3264 (NH), 1720, 1644, 1624, 1605 (CO, CN) cm-1
;
1H NMR (CDCl3) δ 1.46 (s, 18H, (CH3)3), 1.58 (s, 18H, (CH3)3),
7.25 (d, 4H, J ) 8.5 Hz, Ar), 7.29 (d, 4H, J ) 8.5 Hz, Ar), 7.40
(broad s, 2H, NHCONH), 10.14 (broad s, 2H, NHGu), 11.64 (broad
s, 2H, NHGu); 13C NMR (CDCl3) δ 28.0, 28.1 ((CH3)3), 80.0, 83.8
(C(CH3)3), 118.8, 124.8, 129.9, 137.6 (Ar), 152.1, 153.1
((CH3)3COCO), 155.3, 163.2 (NHCONH, CN).
1
1728, 1638, 1608 (CO, CN) cm-1; H NMR (CDCl3) δ 1.52 (s,
1,3-Bis(4-[1,3-di(tert-butoxycarbonyl)-2-imidazolidinylimi-
no]phenyl)urea (7e). Following the general synthetic method A,
the crude residue was purified by neutral alumina column flash
chromatography, eluting with CH2Cl2/EtOAc (1:5). The residue
obtained after the column was precipitated with cold hexane to yield
1.25 g (63%) of 7e as a white solid: mp 180–182 °C; IR (Nujol) ν
3357 (NH), 1757, 1704, 1648 (CO, CN) cm-1; 1H NMR (CDCl3)
δ 1.33 (s, 36H, (CH3)3), 3.83 (s, 8H, CH2), 6.90 (d, 4H, J ) 7.0
Hz, Ar), 7.14–7.26 (m, 6H, 4Ar + 2NH); 13C NMR (CDCl3) δ
27.8 ((CH3)3), 43.1 (CH2), 82.9 (C(CH3)3), 120.6, 121.8, 133.9,
139.3 (Ar), 143.4 ((CH3)3COCO), 150.2, 153.5 (NHCONH, CN).
Dihydrochloride Salt of 1,3-Bis(4-guanidinophenyl)urea (7a).
Following general method B, an amount of 210 mg (95%) of the
pure dihydrochloride salt of 7a was obtained as a white solid: mp,
18H, (CH3)3), 1.55 (s, 18H, (CH3)3), 1.82–2.00 (m, 4H, H3Pip),
2.56–2.69 (m, 1H, H4Pip), 2.71–2.89 (m, 2H, H2ePip), 3.71–3.82
(m, 2H, H2aPip), 6.95 (d, 2H, J ) 8.0 Hz, Ar), 7.22 (d, 2H, J )
7.0 Hz, Ar), 7.48 (d, 2H, J ) 8.0 Hz, Ar), 7.54 (d, 2H, J ) 7.0 Hz,
Ar), 10.19 (broad s, 1H, NH), 10.29 (broad s, 1H, NH), 11.68 (broad
s, 2H, NH); 13C NMR (CDCl3) δ 28.0, 28.1, 28.2 ((CH3)3), 33.1
(C3Pip), 41.8 (C4Pip), 50.8 (C2Pip), 79.3, 79.4, 83.3, 83.5 (C(CH3)3),
117.0, 122.4, 123.3, 127.2, 128.7, 134.7, 142.5, 149.0 (Ar), 153.2,
153.3, 153.4, 153.5 (CO), 163.5, 163.6 (CN).
Di-tert-butyl-2-(4-[4-(4-[1,3-bis(tert-butyloxycarbonyl)tetrahy-
dro-1H-2-imidazolyliden]aminophenyl)piperidino]phenylimino)-
1,3-imidazolidinedicarboxylate (11e). Method A was used, with
598 mg (2.2 mmol) of HgCl2, 268 mg (1.0 mmol) of 11, 605 mg
(2.0 mmol) of N,N′-di(tert-butoxycarbonyl)imidazolidine-2-thione,
and 0.9 mL (6.4 mmol) of Et3N in CH2Cl2/DMF (1:2) (8 mL) at 0
°C. The resulting mixture was stirred at 0 °C for 1 and 41 h more
at room temperature. The reaction was worked up and purified by
silica gel column chromatography, eluting with hexane/EtOAc (1:1).
The residue obtained after the column was recrystallized from
hexane/Et2O (1:1) to yield 523 mg (65%) of 11e as a white solid:
mp 191–193 °C; MS (ESI+) m/z 804.4681 [M + H]+; IR (Nujol)
1
decomposes at 248 °C; MS (ESI+) m/z 327.1928 [M + H]+; H
NMR (D2O) δ 7.27 (d, 4H, J ) 8.5 Hz, Ar), 7.43 (d, 4H, J ) 8.5
Hz, Ar); 13C NMR (D2O) δ 121.6, 126.4, 129.1, 137.0 (Ar), 155.0,
156.0 (CO, CN). Anal. (C15H20Cl2N8O·2.3H2O) C, H, N.
1,3-Bis(4-[2,3-di(tert-butoxycarbonyl)guanidino]phenyl)thiourea-
(8d). A solution of 701 mg (2.0 mmol) of 4-[2,3-di(tert-butoxy-
carbonyl)guanidino]aniline 8 and 3.0 mL (50.0 mmol) of carbon
disulfide in 20 mL of CH2Cl2 was stirred at reflux for 54 h.
Afterward, the solvent was evaporated to give a residue that was
purified by silica gel column chromatography, eluting with hexane/
EtOAc (3:2) to yield 240 mg (32%) of 8d as a white solid: mp
>300 °C; MS (ESI+) m/z 743.3412 [M + H]+; IR (Nujol) ν 3396,
1
ν 1753, 1704, 1662, 1606 (CO, CN) cm-1; H NMR (CDCl3) δ
1.32 (s, 18H, (CH3)3), 1.34 (s, 18H, (CH3)3), 1.83–1.98 (m, 4H,
H3Pip), 2.49–2.61 (m, 1H, H4Pip), 2.66–2.79 (m, 2H, H2ePip),
3.60–3.71 (m, 2H, H2aPip), 3.83 (s, 8H, CH2), 6.85–7.0 (m, 6H,
Ar), 7.11 (d, 2H, J ) 8.0 Hz, Ar); 13C NMR (CDCl3) δ 27.8, 27.9
((CH3)3), 33.4 (C3Pip), 41.8 (C4Pip), 43.0 (CH2), 51.8 (C2Pip), 82.5,
82.7 (C(CH3)3), 117.8, 121.4, 122.2, 126.9, 138.4, 139.0, 140.4,
141.1 (Ar), 146.4, 148.0 (CO); 150.3, 150.4 (CN).
3291, 3169 (NH), 1720, 1646, 1630, 1152 (CO, CN, CS) cm-1
;
1H NMR (CDCl3) δ 1.50 (s, 18H, (CH3)3), 1.55 (s, 18H, (CH3)3),
7.34 (d, 4H, J ) 8.0 Hz, Ar), 7.61 (d, 4H, J ) 8.0 Hz, Ar), 7.98
(broad s, 2H, NHCSNH), 10.36 (broad s, 2H, NHGu), 11.63 (broad
s, 2H, NHGu); 13C NMR (CDCl3) δ 27.8, 27.9 ((CH3)3), 79.6, 83.6
(C(CH3)3), 123.4, 124.9, 134.0, 134.8 (Ar), 152.9, 153.8 (CO), 163.1
(CN), 179.4 (CS).
Trihydrochloride Salt of 1,4-Bis(4-guanidinophenyl)piperi-
dine (11a). Following method B, an amount of 224 mg (90%) of
the pure hydrochloride salt of 11a was obtained as a brown solid:
