1056 Journal of Medicinal Chemistry, 2007, Vol. 50, No. 5
Vrudhula et al.
of 15 afforded alcohol 16 (0.038 g, 80%, LC-MS tR ) 1.7 min) as
conformations of 3 were initially calculated using the Schrodinger
Ligprep utility and minimized for 500 steps using the Polak-Ribier
conjugate gradient method.25 Starting from this conformation, the
dihedral angle of interest was rotated from -180° to 180° in 5°
increments using the Macromodel Dihedral Drive utility. At each
of these angles, the structure was minimized in vacuum and the
total force-field self-energy of the minimized structure was recorded.
The barrier height was estimated as the difference in peak and
trough energies calculated during the dihedral rotation.
1
white solid. MS [M + H] ) 456. H NMR (CD3OD) δ 7.81 (d, J
) 8.8 Hz, 1H), 7.74 (d, J ) 8.9 Hz, 1H), 7.32 (s, 1H), 7.26 (s,
1H), 6.98 (d, J ) 2.4 Hz, 1H), 3.83 (s, 3H), 3.69 (m, 2H), 3.60 (t,
J ) 6.3 Hz, 2H), 2.82 - 2.69 (m, 4H), 1.87 (m, 2H). 13C
NMR (CD3OD) 163.9, 152.2, 146.0, 142.5, 134.0, 132.1, 132.0,
128.5, 127.4 (m), 126.2, 126.0, 125.6, 125.4 (m), 125.3 (m), 122.4,
116.8, 61.9, 61.1, 34.0, 33.5, 30.8, 27.6. Anal. (C22H21ClF3NO4)
C, H, N, Cl.
Electrophysiology Experiments.18 To evaluate the maxi-K
channel opening characteristics of the test compounds, experiments
were performed using standard two-electrode voltage clamp
techniques in Xenopus laeVis oocytes expressing the human maxi-K
hSlo channel. Oocytes were each injected with 50 ng of hSlo cRNA
and recorded from 2 to 5 days postinjection. From a holding
potential of -60 mV, outward potassium currents were evoked over
the voltage range of -40 to +140 mV using 20 mV depolarizing
steps. In all cases, a minimum of four to five different oocytes
were used to evaluate the effect of each compound at 5, 10, or 20
µM applied for 5 min. To determine the level of hSlo expression
and current in an oocyte, each experiment ended with a 10 min
application of the specific maxi-K channel blocker iberiotoxin
(IbTX; 100nM).26 Compound effects are presented in Tables 1 and
2 and are expressed as percent IbTX-sensitive currents relative to
compound-free control values measured at the peak effect.
Chiral Separation of 11. A solution of 11 (∼50 mg) in i-PrOH:
hexane (1:1, 2 mL) was applied in four injections on to a ChiralPak
AD, 21 × 250 mm, 10 µm particle size column. Elution with iPrOH:
hexane (1:19) was carried out for 50 min at a flow rate of 10 mL/
min. A detector with UVmax at 234 nm was employed. Fractions
containing the faster moving isomer, upon evaporation, gave 20.6
mg, [R]22 (EtOH) ) +20.7°, while the evaporation of fractions
D
containing the later peak gave 19.9 mg of the other isomer [R]22
D
(EtOH) ) -18.6° (98.7% enantiomeric purity). The two isomers
had identical proton NMR and LC-MS characteristics. Crystalliza-
tion of (+)-11 from ethyl acetate gave crystals suitable for X-ray
crystallographic analysis.
Chiral Separation of 15. Diol 15 was separated on the same
column as above by isocratic elution with 93:7 solvents B:A (A )
i-PrOH, B ) 0.05% TFA in hexane) for 130 min. Optical rotational
characterization of the diastereomers: Isomer A (peak 1), [R]22
D
(MeOH) ) +3.5°; Isomer B + C (peaks 2 + 3), [R]22 (MeOH)
) +2.7°; and Isomer D (peak 4), [R]22 (MeOH) ) -D5.3°.
D
Acknowledgment. The authors would like to thank Dr.
Stella Huang for conducting the NMR experiments in chiral
solvents.
Chiral Separation of 3. The conditions used were essentially
the same as those for 11 except that a longer run time (60 min)
was used. Characteristics of isomer eluting as first peak tR ) 46.1
min; NMR characteristics are the same as that of the racemate;
Supporting Information Available: Microanalyses data for
compounds 11-16. X-ray data information for (+)-3 and (+)-11.
Supporting information is available free of charge via the Internet
[R]22 (MeOH) ) -8.8°. The later peak (tR ) 48.3 min) had the
D
same NMR spectral characteristics as the earlier peak with [R]22
D
(MeOH) ) +9.6°. Crystallization of (+)-3 from EtOH-H2O gave
single crystals suitable for X-ray crystallographic analysis.
Chiral Separation of 4. The racemate was separated as described
above for 15 except that a ratio of B:A ) 4:1 was used in a 25 min
isocratic run. Characteristics of the isomer eluting as first peak tR
) 8.5 min; NMR characteristics are the same as that of the
racemate;9 [R]22D (MeOH) ) -6.9°. The later peak (tR ) 19.0 min)
References
(1) Potassium Ion Channels: Molecular Structure, Function, and
Diseases; Kurachi, Y.; Jan, L. Y.; Lazdunzki, M., Eds.; Academic
Press: San Diego, CA, 1999.
(2) Gribkoff, V. K.; Dworetzky, S. I.; Starrett, J. E., Jr.; Maxi-K
potassium channels: form, function, and modulation of a class of
endogenous regulators of intracellular calcium. The Neuroscientist
2001, 7, 166-177.
(3) Shieh, C.; Coghlan, M.; Sullivan, J. P.; Gopalakrishnan, M. Potassium
Channels: Molecular Defects, Diseases, and Therapeutic Opportuni-
ties. Pharmacol. ReV. 2000, 52, 557-593.
(4) Gribkoff, V. K.; Starrett, J. E., Jr.; Dworetzky, S. I.; Hewawasam,
P.; Boissard, C. G.; Cook, D. A.; Frantz, S. W.; Heman, K.; Hibbard,
J. R.; Huston, K.; Johnson, G.; Krishnan, B. S.; Kinney, G. G.;
Lombardo, L. A.; Meanwell, N. A.; Molinoff, P. B.; Myers, R. A.;
Moon, S. L.; Ortiz, A.; Pajor, L.; Pieschl, R. L.; Post-Munson, D. J.;
Signor, L. J.; Srinivas, N.; Taber, M. T.; Thalody, G.; Trojnacki, J.
T.; Wiener, H.; Yeleswaram, K.; Yeola, S. W. Targeting acute
ischemic stroke with a calcium-sensitive opener of maxi-K potassium
channels. Nat. Med. 2001, 7, 471-477.
(5) Cheney, J. A.; Weisser, J. D.; Bareyre, F. M.; Laurer, H. L.; Saatman,
K. E.; Raghupathi, R.; Gribkoff, V.; Starrett, J. E., Jr.; McIntosh, T.
K. The maxi-K channel opener BMS-204352 attenuates regional
cerebral edema and neurologic motor impairment after experimental
brain injury. J. Cereb. Blood Flow Metab. 2001, 4, 396-403.
(6) Tanaka, M.; Sasaki, Y.; Fukui, T.; Hamada, K.; Ukai, Y. A novel
pyrrole derivative NS-8, suppresses the rat micturition reflex by
inhibiting afferent pelvic nerve activity. BJU Int. 2003, 92, 1031-
1036.
(7) Christ, G. J.; Rehman, J.; Day, N.; Salkoff, L.; Valcic, M.; Melman,
A.; Geliebter, J. Intracorporal injection of hSlo cDNA in rats produces
physiologically relevant alterations in penile function. Am. J. Physiol.
1998, 275, 600-8.
(8) Knaus, H. G.; McManus, O. B.; Lee, S. H.; Schmalhofer, W. A.;
Garcia-Calvo, M.; Helms, L. M.; Sanchez, M.; Giangiacomo, K.;
Reuben, J. P.; Smith, A. B., III. Tremorgenic indole alkaloids potently
inhibit smooth muscle high-conductance calcium-activated potassium
channels. Biochemistry 1994, 33, 5819-5828.
(9) Hewawasam, P.; Starrett, J. E., Jr. 3-Substituted-4-arylquinolin-2-
one Derivatives as Potassium Channel Modulators. US 2001/6184231
B1 and references cited therein.
had the same NMR spectral characteristics8 with [R]22 (MeOH)
D
) + 5.0°.
X-ray Crystallographic Data. Data obtained for (+)-3 and (+)-
11 are included in Supporting Information. X-ray crystallographic
data for compounds (+)-3 and (+)-11 have been deposited with
the Cambridge Crystallographic Data Center as CCDC 620426 and
CCDC 620427, respectively. The crystallographic data can be
obtained free of charge by writing to CCDC, 12 Union Rd.,
Cambridge, CB2, IEZ, UK [fax (+44) 1223 336033, e-mail:
deposit@ccdc.cam.ac.uk].
Stability of (-)-3 at 80 °C. A 1 mM solution of (-)-3 in
n-butanol was maintained at 80 °C. Aliquots (0.2 mL) drawn at
various times were analyzed by SFC chromatography (see General
section). After 72 h, 19.6% conversion of (-)-3 to (+)-3 was
observed.
Stability of (-)-3 in Human Serum at 37 °C. Pooled human
serum (0.99 mL) was incubated at 37 °C for 5 min. A 0.1 M
solution of (-)-3 in DMSO (0.01 mL) was added to the human
serum at 37 °C and mixed to give an overall concentration of 1
mM (-)-3 in human serum containing 1% DMSO. The solution
was maintained at 37 °C, and at various times, aliquots (0.2 mL)
were diluted with an equal volume of MeCN. The precipitated
proteins were centrifuged and the pellet was separated from the
supernatant. The supernatant was evaporated under a stream of N2.
The residue was dissolved in 0.3 mL of EtOH and analyzed by
SFC chromatography. No racemization was observed up to the
termination of the experiment at 30 h.
Calculation of Energy Barrier for Rotation around Rings B
and C in 3. All calculations were performed using the Schrodinger
Maestro suite of software (version 7.5, Schrodinger, LLC, New
York, NY 2005) and the MMFF94s force-field.24 Three-dimensional
