Hydrogen-bond-mediated self-assembly of aminopyrazolones: Macrocyclic quartets - Single and stacked one-dimensional motifs

Article abstract of DOI:10.1002/anie.200502539

The fab four: Aminopyrazolones which incorporate two ditopic hydrogen-bond donor-acceptor pairs of amide and amidine functional groups can self-assemble through formation of four hydrogen bonds. Single-crystal X-ray diffraction analysis reveals that homom

Full text of DOI:10.1002/anie.200502539

Angewandte
Chemie
ular components has garnered considerable success as a
procedure for the spontaneous generation of well-defined
discrete and recurrent architectures.[2,3] Hydrogen-bond-
mediated self-assembly has proven especially effective,[3]
largely because of the design of tailored recognition elements
in the form of hydrogen-bond donor–acceptor arrays, which
allows the free energy and “orthogonality” of recognition
events to be tuned.[3c] The utility of hydrogen-bond recog-
nition elements is highlighted by their application to the
design of oligomers (foldamers) that adopt specific secondary
structures,[4,5] molecular strands that engage in specific modes
of intermolecular aggregation,[6] polymers possessing non-
covalent main chains[7] and side chains,[8] as well as the self-
assembly of dendritic macromolecules.[9]
We recently developed duplex molecular strands based on
the aminotriazine and diaminopyridazine hydrogen-bonding
motifs as part of a program concerning hydrogen-bond-
mediated self-assembly.[10] These systems engage in high-
affinity twofold self-association, as established by isothermal
1
titration calorimetry (ITC), H NMR dilution studies, vapor
pressure osmometry (VPO), and single-crystal X-ray diffrac-
tion analysis. With the goal of developing synthetic strands
that self-assemble to form transmembrane channels,[11] we
sought oligomers incorporating recognition elements that
direct fourfold self-association. While quadruplexes based on
guanosine and their structural relatives are commonplace,[12]
other heterocyclic molecules that participate in hydrogen-
bond-mediated fourfold self-association are exceptionally
uncommon.[13] 3,5-Disubstituted pyrazoles are known to
form dimers A, as well as cyclic trimers B and tetramers C,
in solution and in the solid state (Scheme 1).[14] It was
postulated that the hitherto unexplored aminopyrazolones 1
should preferentially engage in fourfold self-association
through heteromeric aggregation (amide–amidine), as the
quadruplex type arrangement is reinforced by four additional
hydrogen bonds as in 14. However, homomeric association
(amide–amide, amidine–amidine) of aminopyrazolone 1 may
compete to provide 1-dimensional motif 1n. Finally, because
ditopic association is relatively weak, arrangements involving
unrequited hydrogen-bond donor–acceptor sites are probable
in the solid state.[15]
Self-Assembly
DOI: 10.1002/anie.200502539
Hydrogen-Bond-Mediated Self-Assembly of
Aminopyrazolones: Macrocyclic Quartets—
Single and Stacked One-Dimensional Motifs**
Aminopyrazolones 1a–1c were synthesized according to a
literature procedure.[16] Specifically, ethyl cyanoacetate was
subjected to exhaustive alkylation followed by hydrazination
to afford dibutylaminopyrazolone 1a, didodecylaminopyra-
zolone 1b, and dibenzylaminopyrazolone 1c. Synthesis of the
optically pure C2-symmetric bis(aminopyrazolone) 1d was
achieved through the alkylation of a chirally modified
cyanoacetate ester based on (1S,2R,4R)-10-dicyclohexylsulf-
amoylisoborneol (Scheme 2).[17]
Single crystals of compounds 1a–1d were obtained and
subjected to X-ray diffraction analysis to determine the mode
of assembly in the solid state. Analysis of crystals of
dibutylaminopyrazolone 1a obtained from ethyl acetate
reveal a 1-dimensional hydrogen-bonding motif involving
homomeric association of the ditopic hydrogen-bond donor–
acceptor sites (amide–amide, amidine–amidine; Figure 1).
Hegui Gong and Michael J. Krische*
A broad goal of modern research resides in the development
of selective protocols for the organization of matter across
length scales.[1] Toward this end, the self-assembly of molec-
[*] H. Gong, Prof. M. J. Krische
University of Texas at Austin
Department of Chemistry and Biochemistry
1 University Station–A5300
Austin, TX 78712-1167 (USA)
Fax: (+1)512-471-8696
E-mail: mkrische@mail.utexas.edu
[**] Acknowledgment is made to the Research Corporation Cottrell
Scholar Award (CS0927), the Alfred P. Sloan Foundation, the
Dreyfus Foundation, and the NSF-CAREER Program.
À
À
The N H···N and N H···O hydrogen bonds in the linear
aggregate (1a)n have equal lengths of 3.07 Š. In contrast, X-
Supporting information for this article is available on the WWW
under http://www.angewandte.org or from the author.
Angew. Chem. Int. Ed. 2005, 44, 7069 –7071
ꢀ 2005 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
7069

Communications
Figure 1. Top: Solid-state structure of dibutylaminopyrazolone 1a.
Bottom: Solid-state structure of C2-symmetricbis(aminopyrazolone)
1d. Solvent is omitted for clarity.
Scheme 1. Assembly modes established for 3,5-disubstituted pyrazoles
and those proposed for aminopyrazolones 1.
Figure 2. Solid-state structure of didodecylaminopyrazolone 1b.
aggregate are 3.02 Š and 2.93 Š, respectively. A pore size of
approximately 2.6 Š is estimated when the van der Waals
radii are taken into account; hence, the pore size is sufficiently
large to accommodate lithium, sodium, and potassium ions.
The solid-state structure of dibenzylaminopyrazolone 1c
reveals a non-coplanar arrangement of the aminopyrazolone
rings.[18] The energetic driving force represented by the
packing preferences of the phenyl moieties in 1c, appears to
supercede the free energy of hydrogen-bond formation, as
only one of the four hydrogen-bond donor–acceptor sites
forms a contact with another aminopyridazine molecule.
Finally, X-ray diffraction analysis of a crystal of C2-symmetric
bis(aminopyrazolone) 1d obtained from 1,3-dimethyl-2-imi-
dazolidinone reveals a stacked 1-dimensional motif. In this
Scheme 2. Synthesis of bis(aminopyrazolone) 1d. Reagents: a) PCl5
(100 mol%), Et2O (0.3m), 258C. b) R*OH (50 mol%), AgCN
(75 mol%), PhCH3 (0.1m), 608C, 70% over two steps. c) LDA
(120 mol%), 1,3-diiodopropane (50 mol%), HMPA (150 mol%), THF
(0.1m), À788C to 258C, 38%. d) LiOH in MeOH (1.83n,
1830 mol%), 258C, 83%. e) PCl5 (212 mol%), Et2O (0.1m). f) MeOH
(excess), 258C, 97% over two steps. g) NH2NH2-H2O (1000 mol%),
1058C, 70%. LDA=lithium diisopropylamide, HMPA=hexamethyl
phosphoramide.
À
À
stacked motif, N H···N and N H···O hydrogen-bond lengths
of 3.01/3.02 Š and 2.89 Š are observed, respectively.
ray diffraction analysis of crystals of didodecylaminopyrazo-
lone 1b obtained from 1,2-dichloroethane reveals the desired
cyclic quartet structure (1b)4 derived through heteromeric
association (amide–amidine, amide–amidine; Figure 2). The
In summary, initial studies on the hydrogen-bond-medi-
ated self-assembly of aminopyrazolones have established that
two primary modes of aggregation are evident for n-alkyl-
substituted aminopyrazolones 1a, 1b, and 1d in the solid
À
À
N H···N and N H···O hydrogen-bond lengths in the cyclic
7070 www.angewandte.org
ꢀ 2005 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
Angew. Chem. Int. Ed. 2005, 44, 7069 –7071

Angewandte
Chemie
Xu, E. J. Kramer, Macromolecules 1998, 31, 1292 – 1304; d) D.
state. Homomeric aggregation (amide–amide, amidine–ami-
dine) of aminopyrazolones 1a and 1d gives rise 1-dimensional
architectures (1)n, while heteromeric aggregation (amide–
amidine) generates the desired macrocyclic quartets (1)4. The
self-assembly of aminopyrazolones in solution is currently
under investigation. These studies suggest that suitably
tailored aminopyrazolone oligomers may spontaneously
assemble to form channel-type aggregates.
Stewart, C. T. Imrie, Macromolecules 1997, 30, 877 – 884; e) T.
Kato, H. Kihara, S. Ujiie, T. Uryu, J. M. J. FrØchet, Macro-
molecules 1996, 29, 8734 – 8739; f) R. F. M. Lange, E. W. Meijer,
Macromol. Symp. 1996, 102, 301 – 308; g) T. Kato, H. Kihara, T.
Uryu, A. Fujishima, J. M. J. FrØchet, Macromolecules 1992, 25,
6836 – 6841; h) T. Kato, N. Hirota, A. Fujishima, J. M. J. FrØchet,
J. Polym. Sci. Polym. Chem. Ed. 1996, 34, 57 – 62.
[9] For examples, see: a) B. Huang, J. R. Parquette, J. Am. Chem.
Soc. 2001, 123, 2689 – 2690; b) J. Recker, D. J. Tomcik, J. R.
Parquette, J. Am. Chem. Soc. 2000, 122, 10298 – 10307; c) S. C.
Zimmerman, F. Zeng, D. E. C. Reichert, S. V. Kolotuchin,
Science 1996, 271, 1095 – 1098.
Received: July 20, 2005
Published online: October 7, 2005
[10] a) H. Gong, M. J. Krische, J. Am. Chem. Soc. 2005, 127, 1719 –
1725; b) E. A. Archer, M. J. Krische, J. Am. Chem. Soc. 2002,
124, 5074 – 5083.
[11] For reviews encompassing the self-assembly of tubular struc-
tures, see: a) G. W. Gokel, W. M. Leevy, M. E. Weber, Chem.
Rev. 2004, 104, 2723– 2750; b) D. T. Bong, T. D. Clark, J. R.
Granja, M. R. Ghadiri, Angew. Chem. 2001, 113, 1016 – 1041;
Angew. Chem. Int. Ed. 2001, 40, 988 – 1011; c) G. W. Gokel, O.
Murillo, Acc. Chem. Res. 1996, 29, 425 – 432.
[12] For reviews encompassing G quartets and their structural
relatives in molecular self-assembly, see: a) J. T. Davis, Angew.
Chem. 2004, 116, 684 – 716; Angew. Chem. Int. Ed. 2004, 43, 668 –
698; b) G. Gottarelli, G. P. Spada, A. Garbesi in Comprehensive
Supramolecular Chemistry (Eds.: J. L. Atwood, J. E. D. Davies,
D. D. MacNicol, F. Vögtle), Elsevier, New York, 1996, pp. 483–
506; c) see also F. Seela, R. Kroschel, Bioconjugate Chem. 2001,
12, 1043, and references therein.
[13] To our knowledge, other than guanosines and pyrazoles, only
one example of a heterocycle that engages in fourfold self-
association through hydrogen-bond-mediated self-assembly has
been reported: M. Mazik, D. Blꢀser, R. Boese, Chem. Eur. J.
2000, 6, 2865 – 2873.
[14] For an exhaustive account of the self-assembly of 3,5-disubsti-
tuted pyrazoles, see: O. Klein, F. Aguilar-Parilla, J. M. Lopez, N.
Jagerovic, J. Elguero, H.-H. Limbach, J. Am. Chem. Soc. 2004,
126, 11718 – 11732, and references therein.
[15] 2-Aminopyrimidines which incorporate ditopic hydrogen-bond
donor–acceptor arrays often adopt arrangements in the solid
state that result in unrequited hydrogen-bond donor–acceptor
sites: a) M. J. Krische, J.-M. Lehn, N. Kyritsakas, J. Fischer, Helv.
Chim. Acta 1998, 81, 1909 – 1920; b) M. J. Krische, J.-M. Lehn, N.
Kyritsakas, J. Fischer, E. K. Wegelius, M. J. Nissinen, K. Rissa-
nen, Helv. Chim. Acta 1998, 81, 1921 – 1930.
[16] A. Echevarrꢁa, J. Elguero, G. I. Yranzo, E. Diez-Barra, A. Hoz,
A. Moreno, M. A. Garcꢁa-Martꢁn, J. Chem. Soc. Perkin Trans. 1
1993, 2229 – 2232.
[17] N. Martin, A. Martinez-Grau, C. Seoane, J. L. Marco, A. Albert,
F. H. Cano, J. Heterocycl. Chem. 1996, 33, 27 – 31.
Keywords: donor–acceptor systems · host–guest systems ·
hydrogen bonds · noncovalent interactions · self-assembly
.
[1] For selected reviews, see: a) G. A. Ozin, Chem. Commun. 2000,
419 – 432; b) G. M. Whitesides, J. P. Matthias, C. T. Seto, Science
1991, 254, 1312 – 1319; c) A. P. Alivisatos, P. F. Barbara, A. W.
Castleman, J. Chang, D. A. Dixon, M. L. Klein, G. L. McLendon,
J. S. Miller, M. A. Ratner, P. J. Rossky, S. I. Stupp, M. E.
Thompson, Adv. Mater. 1998, 10, 1297 – 1336; d) Y. Xia, J. A.
Rogers, K. E. Paul, G. M. Whitesides, Chem. Rev. 1999, 99,
1823– 1848.
[2] For reviews on the general topic of self-assembly, see: a) D.
Philp, J. F. Stoddart, Angew. Chem. 1996, 108, 1242 – 1286;
Angew. Chem. Int. Ed. 1996, 35, 1154 – 1196; b) D. S. Lawrence,
T. Jiang, M. Levett, Chem. Rev. 1995, 95, 2229 – 2260; c) S. J.
Langford, J. F. Stoddart, Pure Appl. Chem. 1996, 68, 1255 – 1260;
d) J.-H. Fuhrhop, B. Rosengarten, Synlett 1997, 1015 – 1028;
e) J. S. Lindsey, New J. Chem. 1991, 15, 153– 180.
[3] For reviews on hydrogen-bond-mediated self-assembly, see:
a) D. C. Sherrington, K. A. Taskinen, Chem. Soc. Rev. 2001, 30,
83– 93; b) M. J. Krische, J.-M. Lehn, Struct. Bonding (Berlin)
2000, 94, 3– 30; c) S. C. Zimmerman, P. S. Corbin, Struct.
Bonding (Berlin) 2000, 94, 63– 94; d) J. R. Fredericks, A. D.
Hamilton in Comprehensive Supramolecular Chemistry (Eds.:
J. L. Atwood, J. E. D. Davies, D. D. MacNicol, F. Vögtle),
Elsevier, New York, 1996, pp. 565 – 594; e) J. C. MacDonald,
G. M. Whitesides, Chem. Rev. 1994, 94, 2383 – 2420; f) M. C.
Etter, Acc. Chem. Res. 1990, 23, 120 – 126.
[4] For reviews encompassing foldamers, see: a) D. J. Hill, M. J. Mio,
R. B. Prince, T. S. Hughes, J. S. Moore, Chem. Rev. 2001, 101,
3893 – 4011; b) S. H. Gellman, Acc. Chem. Res. 1998, 31, 173–
180.
[5] For a seminal contribution to the field of foldamer chemistry,
see: R. S. Lokey, B. L. Iverson, Nature 1995, 375, 303 – 305.
[6] For reviews encompassing duplex association of molecular
strands, see: a) A. R. Sanford, K. Yamato, X. Yang, L. Yuan,
Y. Han, B. Gong, Eur. J. Biochem. 2004, 271, 1416 – 1425; b) B.
Gong, Synlett 2001, 582 – 589; c) E. A. Archer, H. Gong, M. J.
Krische, Tetrahedron 2001, 57, 1139 – 1159.
[18] Detailed depictions of the solid-state structure of 1c are
provided in the Supporting Information.
[7] For reviews encompassing hydrogen-bonded main-chain poly-
mers, see: a) L. Brunsveld, B. J. B. Folmer, E. W. Meijer, R. P.
Sijbesma, Chem. Rev. 2001, 101, 4071 – 4097; b) J. S. Moore, Curr.
Opin. Colloid Interface Sci. 1999, 4, 108 – 116; c) N. Zimmerman,
J. S. Moore, S. C. Zimmerman, Chem. Ind. 1998, 604 – 607;
d) C. T. Imrie, Trends Polym. Sci. 1995, 3, 22 – 29; e) C.
Alexander, C. P. Jariwala, C.-M. Lee, A. Griffin, C Macromol.
Chem. Macromol. Symp. 1994, 77, 283– 294; f) J.-M. Lehn,
Macromol. Symp. 1993, 69, 1 – 17.
[8] For examples of polymers possessing hydrogen-bonded side
chains, see: a) L. P. Stubbs, M. Weck, Chem. Eur. J. 2003, 9, 992 –
999; b) B. D. Edgecombe, J. M. J. FrØchet, Chem. Mater. 1998, 10,
994 – 1002; c) B. D. Edgecombe, J. A. Stein, J. M. J. FrØchet, Z.
Angew. Chem. Int. Ed. 2005, 44, 7069 –7071
ꢀ 2005 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
www.angewandte.org
7071
