typical orientations were observed in this STM image, labeled a and
b in Fig. 2A. For the distinct patterns observed of domain a, the
average distances between each spot along lines A and B were
approximately 0.8 and 1.0 nm, respectively, and the angle between
lines A and B was around ~ 57°. These results suggest the
formation of a A7 3 A13 R20° structure. In the case of domain b,
the distances between each spot along both lines C and D were the
same (0.85 nm), and the angle between line C and D was around 60
°, indicating a 3 3 3 structure. Interestingly, these two domain
structures show less-packed patterns than a well ordered (2A3 3
A3) R30° structure of oligo(p-phenylene–ethynylene)thiolates on
Au that was reported previously.12 We expect this less efficient
packing will make it easier to protonate/deprotonate the adsorbed
molecule.
The spectrum of a self-assembled monolayer of compound 1 on
Au (sample I) reveals only one peak at 398.4 eV, which is assigned
to the nitrogens of the bipyridine. The protonated SAM (sample II)
consists of two peaks at 399.0 and 402.0 eV with almost identical
intensities, in good agreement with our observations of compound
3, as mentioned above. This suggests that under these conditions,
bipyridine exists solely as a monoprotonated species, even on the
surface. Interestingly, soaking the protonated SAM surface in
ethanol (sample III) leads to complete recovery of the peak arising
from a nonprotonated bipyridine at 398.7 eV. These results suggest
we can control the “catch-and-release” of a proton on the bipyridine
rings of compound 1 when present in a SAM using the
aforementioned conditions.
Scheme 1 Structures for phenylene–ethynylene thiol derivatives containing
the bipyridine studied here.
free surfaces, 0.50 and 0.56 nm (Fig. 3A and C). Furthermore, the
acid-free surfaces have a larger statistical distribution of apparent
heights, 0.180 and 0.213, relative to the protonated surface, 0.143.
It is noteworthy that the changes in the average height and the
height distribution are almost reversible through the protonation/
deprotonation process. A control experiment was performed using
a compound incorporating a biphenyl unit instead of the bipyridine
unit in compound 1, resulting in that no change in either the height
and the distribution was observed upon the addition of TfOH. This
clearly suggests that those changes we observed in the STM images
arise from the protonation/deprotonation of the bipyridine.
This work was partly supported by NEDO under the Nano-
technology Materials Program.
Notes and references
‡ Crystal data for compound 3: C25H24N2O3S2F3Br, M = 601.50, triclinic,
a = 10.50(1), b = 11.15(2), and c = 12.58(2) Å, a = 98.96(7)°, b =
¯
93.25(6)°, g = 106.31(5)°, V = 1388.1(3) Å3, T = 168 K, space group P1,
Z = 2, m = 16.84 cm21, 11 489 reflections measured, 5781 unique (Rint
=
0.110), final R indices [I > 2t(I)] R1 = 0.077, wR2 = 0.146. CCDC number
graphic data in .cif format.
Finally, we have investigated the molecular level response to the
protonation/deprotonation of the bipyridine in compound 1 on Au
by using STM. In this case, because of the difficulty in measuring
the absolute height changes of the uniform SAM of compound 1
before and after the addition of TfOH by STM, we utilize a matrix
of octanethiol to isolate compound 1 on Au so that apparent height
changes upon protonation/deprotonation in the STM images can be
measured as a constant. The apparent height difference is
potentially a function of physical height, conductance, or both.
Compound 1 isolated in a matrix of octanethiol was prepared by
soaking the matrix monolayer in 0.14 mM ethanolic solution of
compound 1 for 30 min. The STM image of the matrix-isolated 1 is
shown in Fig. 2. The images were acquired in constant current
mode at a bias of 1.0 V and a current of 25 pA. The bright spots
protruding through the matrix layer, which were not observed in the
octanethiol-only monolayer, are due to either an isolated molecule
or a small collection of compound 1. The substrate is then
processed as described above to effect the “catch-and-release”
process. STM images of both the protonated and deprotonated
surface were acquired. Typical bright spots from each these three
images, are summarized as histograms (n = 50) of the apparent
height in Fig. 3.
1 L. A. Bumm, J. J. Arnold, M. T. Cygan, T. D. Dunbar, T. P. Burgin, L.
Jones, II, D. L. Allara, J. M. Tour and P. S. Weiss, Science, 1996, 271,
1705–1707.
2 J. Chen, M. A. Reed, A. M. Rawlett and J. M. Tour, Science, 1999, 286,
1550–1552.
3 Z. J. Donhauser, B. A. Mantooth, K. F. Kelly, L. A. Bumm, J. D.
Monnell, J. J. Stapleton, D. W. Price Jr., A. M. Rawlett, D. L. Allara, J.
M. Tour and P. S. Weiss, Science, 2001, 292, 2303–2307; Z. J.
Donhauser, B. A. Mantooth, T. P. Pearl, K. F. Kelly, S. U. Nanayakkara
and P. S. Weiss, Jpn. J. Appl. Phys., 2002, 41, 4871–4877.
4 T. Ishida, W. Mizutani, N. Choi, U. Akiba, M. Fijihira and H.
Tokumoto, J. Phys. Chem. B, 2000, 104, 11680–11688; T. Ishida, H.
Fukushima, T. Tamaki and H. Tokumoto, Jpn J. Appl. Phys, 2003, 42,
5342–5346.
5 C. Kaes, A. Katz and M. W. Hosseini, Chem. Rev., 2000, 100,
3553–3590.
6 L. Oresmaa, M. Haukka, P. Vainiotala and T. A. Pakkanen, J. Org.
Chem., 2002, 67, 8216–8219; J.-F. Pan, Z.-K. Chen, S.-J. Chua and W.
Huang, J. Phys. Chem. A, 2001, 105, 8775–8781.
7 P.-M. Windscheif and F. Vogtle, Synthesis, 1994, 87–92.
8 S. Oae, T. Kawai and N. Furukawa, Phosphorus Sulfur, 1987, 34,
123–132.
9 R. P. Hsung, J. R. Babcock, C. E. D. Chidsey and L. R. Sita,
Tetrahedron Lett., 1995, 36, 4525–4528.
The average heights protruding from the surface, 0.3 nm are
clearly lower in the protonated surface (Fig. 3B) relative to the acid-
10 XPS spectra were recorded using a Thermo VG Scientific Inc., Theta
Probe system with a focused monochromatic Al Ka X-ray source
(1486.6 eV). The binding energy was calibrated using the Au (4f7/2
)
peak energy (84.0 eV) as an energy standard. The X-ray power was set
at 200 W. The pass energy of the analyser in standard mode was set at
30 eV. The fwhm of Au (4f7/2) peak of standard mode and simultaneous
angle resolve mode were 0.51 eV.
11 STM images were observed using a Seiko Instruments SPA340 unit
under ambient conditions with a typical tunneling current of 20–100 pA
and tip biases of +0.5–1. 0V.
Fig. 3 Histograms of the apparent height of 50 typical bright spots collected
from each STM image for 1 inserted into octanethiol SAM on Au, (A)
before soaking in TfOH, (B) after soaking in TfOH, and (C) after further
soaking in ethanol.
12 Al-A. Dhirani, R. W. Zehner, R. P. Hsung, P. Guyot-Sionnest and L. R.
Sita, J. Am. Chem. Soc., 1996, 118, 3319–3320; G. Yang, Y. Qian, C.
Engtrakul, L. R. Sita and G.-Y. Liu, J. Phys. Chem. B, 2000, 104,
9059–9062.
