obtained in 98% yield. The substituents on the N-aryl ring can
be varied, with product yields mostly ranging from good to
excellent (4a–4g). N-Benzyl protection (4q) is another good
option, giving b-lactam in very good yield too. The substitu-
tions on the aryl rings of a-diketone 1, electron-donating or
-withdrawing, can also be largely tolerated, affording cyclo-
addition products smoothly (4h–4n). It is worth mentioning
that two monocyclic b-lactam molecules with potent anti-
[15]
bacterial and antifungal activities
(4o, 4p) were synthe-
sized in good yields by our concise strategy, comparing
favorably with the originally reported method.[15] The Ar1
group of the aldimine 3 could be tuned with different
substitutions on the phenyl ring (4r–4u) or other aromatic
systems (4y) to give the desired cycloadducts in up to 99%
yields. Cyclic imines incorporated in fused ring systems (4v,
4w) are also viable substrates for our strategy. In addition to
aldimines, ketimines derived from aromatic ketones are also
compatible substrates for the [2+2] cycloaddition, as exem-
plified by 4x, thus greatly extending the imine scope of our
method.
Mechanistic studies were carried out to gain insights into
the reaction mechanism (Scheme 2). Firstly, control experi-
ments showed that 1,3,2-dioxaphosphole INT1 prepared in
advance could be converted to diphenylacetate 2a directly
under the same conditions (Scheme 2a), suggesting that INT1
might be the key intermediate to undergo the photoredox
cycle. Then, when ethanol was applied as the solvent for the
model Wolff rearrangement reaction, in addition to 2a, two
new products, that is, 5 and 6, which could be generated
Figure 1. Free energy profiles of the photoredox Wolff rearrangement
from benzil and triethyl phosphite. [a] Free energy with one mole of
triethyl phosphate included.
To help further elucidate the detailed process of ketene
generation, DFT computation at the M06-2X/def2-TZVPP/
SMD(DCE)// B3LYP-D4/def2-TZVP level of theory[16] was
conducted (Figure 1). As can be seen from the free energy
À
profile of this transformation, the fission of the P O bond in
radical cation INT2 is very fast, with an energy barrier of only
6.2 kcalmolÀ1. Reduction of the radical cation INT3 is highly
exothermic (À63.4 kcalmolÀ1), affording diradical INT4,
which could undergo straightforward decomposition (energy
barrier: 2.0 kcalmolÀ1) to release the crucial a-keto carbene
intermediate. Triplet carbene INT5B, only 4.2 kcalmolÀ1
more stable, is in fast equilibrium with the singlet state
structure INT5A. However, Wolff rearrangement from
INT5B to ketene INT6 has a remarkably higher energy
barrier than that from INT5A (18.8 vs. 9.1 kcalmolÀ1),
indicating that the rearrangement proceeds mainly from the
singlet carbene intermediate at room temperature. This is
consistent with the fact that halogenated solvents (such as
DCE), which can selectively stablize singlet carbenes via
halogen–carbene complexation,[17] greatly promote the Wolff
rearrangement (Table 1, entry 6). The overall transformation
from benzil and triethyl phosphite to ketene INT6 is energeti-
cally favorable by À12.3 kcalmolÀ1.
À
through trapping a-keto carbene by HAT and H O bond
insertion reactions,[10] were obtained in 20% and 14% yield,
respectively (Scheme 2b), serving as solid evidence for a step-
wise Wolff rearrangement process. A cyclic voltammetry
study showed that 1,3,2-dioxaphosphole INT1 had a half-
wave oxidation potential of + 0.696 V (vs. SCE in CH3CN,
Scheme 2c, see Supporting Information for details), well
below the reduction potential of excited state DPZ (Et(S*/
SCÀ) =+ 1.42 V vs. SCE in CH3CN).[14] Fluorescence quench-
ing experiments (Scheme 2d) finally concluded that INT1 was
an active reductive quencher of the excited DPZ (*DPZ).
Based on mechanistic study results and our DFT compu-
tation study above, a photoredox catalytic Wolff rearrange-
ment from a-diketones and phosphites is proposed herein
(Figure 2). 1,3,2-Dioxaphosphole INT1, formed in situ at the
initial stage, undergoes photoredox decomposition with the
catalysis of the excited sensitizer DPZ*, to give a-keto
carbene INT5B, which is in fast equilibrium with the singlet
state INT5A. The Wolff rearrangement from the singlet state
is the dominant process at room temperature, affording
ketene INT6 exothermically. Trapping the ketenes with
alcohols yields diphenyl acetates 2, while [2+2] cycloaddition
with imines gives valuable b-lactams 4. The intermediate
À
carbene could also be trapped by alcohol via HAT or O H
bond insertion reaction to yield single-carbonyl reduced
product 5 and a-alkoxy ketone 6.
To demonstrate the application potential of this method,
the Staudinger synthesis of b-lactams 4q was scaled up to
1.0 mmol without noticeable decrease in yield, proving its
Scheme 2. Mechanistic studies.
