Total synthesis of a marine alkaloid - Rigidin E

Article abstract of DOI:10.3390/md10061412

In the present paper, we report an efficient total synthesis of a marine alkaloid, rigidin E. The key tetrasubstituted 2-amino-3-carboxamidepyrrole intermediate was synthesized by cascade Michael addition/intramolecular cyclization between N-(2-(4-(benzyloxy)phenyl)-2-oxoethyl)methanesulfonamide and 3-(4-(benzyloxy) phenyl)-2-cyano-N-methylacrylamide. Subsequent carbonylation with triphosgene catalyzed by I₂ and deprotection of benzyl groups afforded rigidin E in 21% overall yield. This strategy has the merits of metal-free reactions, low cost, mild reaction protocols, and easy access to diversity-oriented derivatives for potential structure-activity relationship investigation.

Full text of DOI:10.3390/md10061412

Mar. Drugs 2012, 10, 1412-1421; doi:10.3390/md10061412
OPEN ACCESS
Marine Drugs
ISSN 1660-3397
www.mdpi.com/journal/marinedrugs
Communication
Total Synthesis of a Marine Alkaloid—Rigidin E
Banpeng Cao, Haixin Ding, Ruchun Yang, Xiaoji Wang * and Qiang Xiao *
Jiangxi Key Laboratory of Organic Chemistry, Jiangxi Science and Technology Normal University,
Nanchang 330013, China; E-Mails: caobanpeng@126.com (B.C.); dinghaixin@yahoo.cn (H.D.);
ouyangruchun@yahoo.cn (R.Y.)
* Authors to whom correspondence should be addressed; E-Mails: 13767101659@163.com (X.W.);
xiaoqiang@tsinghua.org.cn (Q.X.); Tel.: +86-791-86422903; Fax: +86-791-86422903.
Received: 28 May 2012; in revised form: 7 June 2012 / Accepted: 8 June 2012 /
Published: 20 June 2012
Abstract: In the present paper, we report an efficient total synthesis of a marine
alkaloid, rigidin E. The key tetrasubstituted 2-amino-3-carboxamidepyrrole intermediate
was synthesized by cascade Michael addition/intramolecular cyclization between
N-(2-(4-(benzyloxy)phenyl)-2-oxoethyl)methanesulfonamide
and
3-(4-(benzyloxy)
phenyl)-2-cyano-N-methylacrylamide. Subsequent carbonylation with triphosgene
catalyzed by I2 and deprotection of benzyl groups afforded rigidin E in 21% overall
yield. This strategy has the merits of metal-free reactions, low cost, mild reaction protocols,
and easy access to diversity-oriented derivatives for potential structure-activity
relationship investigation.
Keywords: pyrrolo[2,3-d]pyrimidine; alkaloids; total synthesis; domino reaction; marine
natural products
1. Introduction
Rigidin A (1), a pyrrolo[2,3-d]pyrimidine alkaloid, was first isolated by Kobayashi et al. from
Okinawa marine tunicate Eudisromu cf. rigida in 1990 [1]. Later on, a series of its analogues,
Rigidin B–E (2–5) (Figure 1), which were consequently isolated from the same marine species [2],
were found to have strong inhibitory activity against calmodulin brain phosphodiesterase [3]. The core
structure of rigidin A–E is a tetrasubstituted pyrrole fused to a pyrimidine, which is an important
structural subunit in a variety of biologically active compounds. In the past decades, much attention

Mar. Drugs 2012, 10
1413
have been drawn on the pyrrolo[2,3-d]pyrimidine analogues for biological and pharmaceutical
applications [4–11].
Figure 1. Structures of marine alkaloids rigidin A–E.
Due to the fact that the content of rigidins in localized tunicate species is very low (0.0015% wet
weight), only very limited amount of rigidins could be isolated for biological study. Therefore, total
synthesis of rigidin was employed to provide sufficient samples for their biological assays.
Currently, there are four published synthetic routes for the total synthesis of rigidins. In 1993,
Edstrom et al. presented the first report of total synthesis of rigidin A (1) with 1,3-dibenzyl protected
6-chlorouracil in 26% overall yield [12]. After a SN2 substitution of the 6-chloro group with
N-benzylglycine, the pyrrolo[2,3-d]pyrimidine skeleton was formed by reflux in acetic anhydride. The
two substitutes at 5- and 6-position were then attached on Stille cross-coupling and Friedel-Crafts
acylation respectively.
Soon after, Sakamoto and his co-workers reported the second strategy for total synthesis of
rigidin A (1) in 1994 [13,14]. With a multi-substituted bromopyrimidine as starting material, the
pyrrolo[2,3-d]pyrimidine core was built by Stille cross-coupling reaction with vinylstannane and
subsequent acidic hydrolysis. The two substitutes were then introduced by similar reactions reported
by Edstrom [12]. Rigidin A (1) was obtained in less than 10% overall yield.
In 2006, Gupton et al. reported the third total synthesis strategy for rigidin A (1) and rigidin E (5),
which used a symmetrical vinamidinium salt to construct 2,4-disubstituted pyrrole [15]. After C-6
substitute was introduced by Friedel-Crafts acylation, the pyrimidine moiety was constructed to
accomplish the total synthesis of rigidin A (1) and rigidin E (5).
The first and second synthetic routes employed substituted pyrimidine as the starting material and
subsequently constructed the pyrrole moiety. In contrast, the third route constructed multi-substituted
pyrrole moiety before pyrimidine formation. All three routes suffered from harsh reaction conditions,
expensive Palladium-based catalyst, lengthy route and lack of variability for diversity-oriented derivatives.
In 2011, Magedov reported that tetra- and pentasubstituted 2-aminopyrroles can be prepared via
multi-component reactions of structurally diverse aldehydes and N-(aryl-, heteroaryl-, alkylsulfonamido)
acetophenones with cyanoacetic acid derivatives, such as malononitrile and cyanoacetate [16].
Furthermore, this methodology was used successfully in total synthesis of rigidins A–D in moderate

Mar. Drugs 2012, 10
1414
overall yield, which is the fourth total synthetic route [16]. So far, this is the most efficient total
synthetic strategy. However, this protocol’s generality and reproducibility still needs to be proved. We
describe herein an improved and practical synthetic route for the total synthesis of rigidin E.
2. Results and Discussion
Rigidin E contains many H-bond donor/acceptors, which may coordinate with heavy metal ions and
form metal-rigidin complexes. The resulting metal contamination cannot usually be easily removed by
a normal purification process. This promoted us to develop a metal-free strategy.
Our retrosynthetic analysis is showed in Figure 2. Principally, rigidin E may be synthesized from
rigidin A through regioselective methylation at N-3. This reaction is very difficult to realize due to the
three NH groups in rigidin E. Therefore, it is preferable to introduce the methyl group before
constructing the tetrasubstituted 2-aminopyrrole.
Figure 2. Retrosynthetic analysis of rigidin E.
Regioselective bromination of acetophenone 7 with phenyltrimethylammonium tribromide in anhydrous
THF afforded 2-bromoacetophenone 8 in 80% yield [17]. 2-Amino-acetophenone 9 was synthesized
using hexamethylenetetramine as an NH2 source in anhydrous chlorobenzene. Subsequent reaction
with methanesulfonyl chloride gave methanesulfonamide 10 in 60% yield over two steps (Scheme 1).
In order to introduce the methyl group to N-3, 2-cyano-N-methylacetamide 11 was synthesized
from ethyl cyanoacetate and methylamine in 90% yield [18,19]. Attempts to synthesize key intermediate
14 using the reported three-components reaction of compound 10, 11, and 12 proceeded in very low
yield and was complicated by undesired byproducts (Scheme 2). As reported by Magedov [16],
Knoevenagel adduct 13 may be the intermediate in the three-component reaction. We speculated that
the intermediate 13 could not form efficiently because of the higher pKa of the methylene of
N-methylacetamide compare to N-unsubstituted acetamide. Therefore, it is possible to solve this
problem through synthesis of the intermediate 13 independently.

Mar. Drugs 2012, 10
Scheme 1. Synthesis of methanesulfonamide 10. Reagents and conditions: (a) K2CO3,
1415
acetone, BnBr, 0 °C , 98%; (b) phenyltriethylammonium tribromide, THF, 80%;
(c) hexamethylenetetramine, chlorobenzene, then conc. HCl; (d) MsCl, Et3N, acetone/H2O
2:1, 60% over two steps.
Scheme 2. Three-components reaction for synthesis the key intermediate 14 failed.
Reagents and conditions: (a) K2CO3, EtOH, reflux.
After Knoevenagel condensation of 2-cyano-N-methylacetamide 11 and 4-(benzyloxy)benzaldehyde
12 using piperidine as a catalyst, 3-(4-(benzyloxy)phenyl)-2-cyano-N-methylacrylamide 13 was obtained
in 80% yield as a mixture of E/Z in about 1:1 ratio (Scheme 3) [20]. Then, a variation of the reported
three-components reaction was conducted to synthesize the precursor 14.
Scheme 3. Synthesis of N-methylacrylamide 13. Reagents and conditions: (a) methylamine,
H2O, 90%; (b) K2CO3, acetone, BnBr, 0 °C , 95%; (c) 11, piperidine, toluene, 80%.

Mar. Drugs 2012, 10
1416
After a careful screening of reaction conditions, the key intermediate 14 was successfully prepared
by a cascade Michael addition/intermolecular cyclization between N-methylacrylamide 13 and
methanesulfonamide 10 in one pot, with K2CO3 as base and ethanol as solvent under refluxing
conditions. The present result proves that phenyl-2-cyanoacrylamide like Knoevenagel adduct was the
intermediate for cyclization in the reported three-component reaction [21].
Carbonylation with oxalyl chloride in diglyme failed to give pyrimidinedione 15 [16]. Various
reagents and conditions were tested, and triphosgene was found ideal to promote the I2-catalyzed
cyclization in anhydrous THF to give pyrimidinedione 15 in 60% yield [22,23]. The final deprotection
of benzyl groups using catalytic hydrogenation resulted in a complicated mixture. The reason might be
the accompanied reduction of carbonyl at C-14. Finally, the protective groups were successfully
removed by TMSI in situ prepared by TMSCl and NaI to afford rigidin E (5) in 88% yield (Scheme 4).
All spectral data are consistent with those of the reported natural product [3].
Scheme 4. Total synthesis of rigidin E. Reagents and conditions: (a) K2CO3, EtOH, reflux,
50%; (b) triphosgene, I2, THF, 60%; (c) TMSCl, NaI, CH3CN, 88%.

Mar. Drugs 2012, 10
1417
3. Experimental Section
3.1. General
All reagents and catalysts were purchased from commercial sources (Acros or Sigma Aldrich) and
used without purification. MeCN, chlorobenzene and DCM were dried with CaH2 and distilled prior to
use. THF was dried with LiAlH4 and distilled prior to use. Thin layer chromatography was performed
using silica gel GF-254 plates (Qing-Dao Chemical Company, China) with detection by UV (254 nm)
or charting with 10% sulfuric acid in ethanol. Column chromatography was performed on silica gel
(200–300 mesh, Qing-Dao Chemical Company, China). NMR spectra were recorded on a Bruker
AV400 spectrometer, and chemical shifts (δ) are reported in ppm. 1H NMR and 13C NMR spectra were
calibrated with TMS as internal standard, and coupling constants (J) are reported in Hz. The
ESI-HRMS were obtained on a Bruker Dalton microTOFQ II spectrometer in positive ion mode.
Melting points were measured on an electrothermal apparatus uncorrected.
3.2. 1-(4-(Benzyloxy)phenyl)-2-bromoethanone 8
To a solution of 1-(4-(benzyloxy)phenyl)ethanone 7 (2.26 g, 10 mmol) in anhydrous THF (20 mL)
was added phenyltrimethylammonium tribromide (3.76 g, 10 mmol). The resulting solution was stirred
at room temperature. A white precipitate was formed and the solution became yellowish over several
minutes. After 30 min, the mixture was poured into ice water (50 mL) and extracted with ethyl
acetate (20 mL × 3). The combined organic layer was dried over anhydrous Na2SO4, filtered, and
concentrated. The crude product was recrystallized from ethanol (15 mL) to afford the title product 8
(2.43 g, 80% yield).
MP: 67–69 °C; Rf = 0.30 (PE–EtOAc, 50:1). 1H NMR (400 MHz, CDCl3): δ = 4.40 (s, 2H, CH2Br),
5.14 (s, 2H, C6H5CH2), 7.03 (d, J = 8.8 Hz, 2H, C6H4, H-3,5), 7.35–7.44 (m, 5H, C6H5), 7.96 (d,
J = 8.8 Hz, 2H, C6H4, H-2,4). 13C NMR (100 MHz, CDCl3): δ = 30.7, 70.2, 114.9, 127.5, 128.3, 128.7,
130.6, 131.4, 135.9, 163.3, 190.0. MS (ESI): m/z = 304.8 [M + H]+.
3.3. N-(2-(4-(Benzyloxy)phenyl)-2-oxoethyl)methanesulfonamide 10
1-(4-(Benzyloxy)phenyl)-2-bromoethanone 8 (3.04 g, 10 mmol) was dissolved in anhydrous
chlorobenzene (8.5 mL). The solution was added dropwise to a solution of hexamethylenetetramine
(1.15 g, 11 mmol) in anhydrous chlorobenzene (10 mL) at 30 °C . The reaction mixture was stirred at
30 °C for 4 h and filtered. The filter cake was washed with ethanol (10 mL) and dried in vacuo. The
filter cake was redissolved in a mixture of concentrated hydrochloric acid (10 mL) and ethanol (20 mL)
with vigorous stirring. The resulting reaction mixture was stirred occasionally under N2 atmosphere for
48 h. The reaction mixture was cooled to 0 °C and filtered to give compound 9. It was redissolved in
H2O/acetone (1:2, 600 mL). Then methanesulfonyl chloride (1.71 g, 15 mmol) was added to the
mixture. The mixture was placed in an ice bath and triethylamine (2.53 g, 25 mmol) was added
dropwise over 30 min. Then acetone (14 mL) was added to the above mixture. The reaction mixture
was stirred at room temperature for 10 h, and then the volatiles were evaporated under reduced
pressure. The solid started to precipitate. To the obtained slurry were added ethyl acetate (20 mL) and

Mar. Drugs 2012, 10
1418
saturated NH4Cl (20 mL) aqueous solution. The organic layer was separated and washed with saturated
NaHCO3 (20 mL) aqueous solution and brine (20 mL), dried with anhydrous MgSO4, and concentrated
to afford the title product 10 (1.91 g, 60% yield).
Mp: 138–140 °C; Rf = 0.43 (CH3OH–CH2Cl2, 1:50). 1H NMR (400 MHz, CDCl3): δ = 2.99 (s, 3H,
CH3), 4.61 (s, 2H, CH2NH), 5.15 (s, 2H, C6H5CH2), 5.32–5.49 (b, 1H, NH), 7.04 (d, J = 8.8 Hz, 2H,
13
C6H4, H-3,5), 7.25–7.42 (m, 5H, C6H5), 7.91 (d, J = 8.8 Hz, 2H, C6H4, H-2,4). C NMR (100 MHz,
CDCl3): δ = 40.7, 48.8, 70.3, 115.1, 126.9, 127.5, 128.4, 128.7, 130.3, 135.8, 163.7, 191.6. MS (ESI):
m/z = 342.5 [M + Na]+.
3.4. 4-(Benzyloxy)benzaldehyde 12
To a mixture of 4-hydroxybenzaldehyde (1.22 g, 10 mmol) and K2CO3 (1.45 g, 10.5 mmol) in
acetone (10 mL) was added benzyl bromide (1.80 g, 10.5 mmol). The resulting mixture was heated to
reflux for 3 h. After cooling, the reaction mixture was poured into water (5 mL) and extracted with
Et2O (5 mL × 3). The combined organic layers were washed with brine (20 mL), dried over anhydrous
MgSO4, filtered, and concentrated under reduced pressure to give a white solid. The solid was washed
with 95% ethanol (2 mL) to afford pure product 12 (2.01 g, 95% yield).
1
MP: 69–71 °C; Rf = 0.49 (PE–EtOAc, 4:1). H NMR (400 MHz, CDCl3): δ = 5.15 (s, 2H,
C6H5CH2), 7.08 (d, J = 8.4 Hz, 2H, C6H4, H-3,5), 7.35–7.45 (m, 5H, C6H5CH2), 7.84 (d, J = 8.4 Hz,
13
2H, C6H4, H-2,4), 9.89 (s, 1H, CHO). C NMR (100 MHz, CDCl3): δ = 70.6, 115.5, 127.8, 128.6,
129.1, 130.5, 132.3, 136.3, 164.1, 191.1. MS (ESI): m/z = 213.2 [M + Na]+.
3.5. 2-Cyano-N-methylacetamide
To an ice cooled solution of methylamine (2.17 g, 75 mmol) in water, ethyl cyanoacetate (5.65 g,
50 mmol) was added dropwise. The solution was stirred at room temperature for 3 h. Most of the
solvent were evaporated under reduced pressure. The obtained solid was filtered and redissolved in
ethyl acetate (200 mL). The solution was dried over anhydrous Na2SO4. The solvent was evaporated to
give the title product (4.14 g, 90% yield).
1
MP: 81–83 °C. H NMR (400 MHz, DMSO): δ = 2.58 (d, J = 4.4 Hz, 3H, CH3), 3.57 (s, 2H, CH2),
8.14 (s, 1H, NH). 13C NMR (100 MHz, DMSO-d6): δ = 24.6, 25.4, 115.6, 161.9. MS (ESI): m/z = 99.4
[M + H]+.
3.6. 3-(4-(Benzyloxy)phenyl)-2-cyano-N-methylacrylamide 13
To a mixture of 4-(benzyloxy)benzaldehyde 12 (2.12 g, 10 mmol) and piperidine (34 mg, 0.4 mmol)
in toluene (10 mL) was added 2-cyano-N-methylacetamide (1.08 g, 11 mmol). The resulting mixture
was heated to reflux for 15 h. After cooling, the reaction mixture was filtered. The filter cake was washed
with 95% ethanol (20 mL), and then dried in vacuo to afford the title product 13 (2.34 g, 80% yield).
1
MP: 170–172 °C; Rf = 0.37 (PE–EtOAc, 2:1). H NMR (400 MHz, DMSO-d6): δ = 2.72 (d,
J = 4.4 Hz, 3H, CH3), 5.19 (s, 2H, CH2), 7.18 (d, J = 8.8 Hz, 2H, C6H4, H-3,5), 7.31–7.46 (m, 5H,
C6H5), 7.95 (d, J = 8.8 Hz, 2H, C6H4, H-2,4), 8.08 (s, 1H, NH), 8.27 (d, J = 4.4 Hz, 1H, CH2).

Mar. Drugs 2012, 10
1419
13C NMR (100 MHz, DMSO-d6): δ = 27.2, 70.0, 103.0, 116.0, 117.4, 125.1, 128.4, 128.5, 129.0,
132.9, 136.8, 150.4, 162.0. MS (ESI): m/z = 315.1 [M + H]+.
3.7. 2-Amino-5-(4-(benzyloxy)benzoyl)-4-(4-(benzyloxy)phenyl)-N-methyl-1h-pyrrole-3-carboxamide 14
To a mixture of 3-(4-(benzyloxy)phenyl)-2-cyano-N-methylarcylamide 13 (3.21 g, 11 mmol) and
K2CO3 (0.69 g, 5 mmol) in ethanol (10 mL) was added N-(2-(4-(benzyloxy)phenyl)-2-oxoethyl)
methanesulfonamide 10 (3.19 g, 10 mmol). The resulting mixture was refluxed for 12 h under N2
atmosphere. After the solvent was evaporated, the residue was purified by column chromatography
with CH3OH/CH2Cl2 = 1:60 to afford the title product 14 (2.66 g, 50% yield).
1
MP 247–249 °C; Rf = 0.40 (CH3OH–CH2Cl2, 1:60). H NMR (400 MHz, DMSO-d6): δ = 2.46 (d,
J = 4.8 Hz, 3H, CONHCH3), 5.01 (s, 2H, C6H4OCH2C6H5), 5.03 (s, 2H, CH2), 5.24 (b, 1H), 6.25 (s,
2H, NH2), 6.62 (d, J = 8.8 Hz, 2H), 6.77 (d, J = 8.4 Hz, 2H), 6.94 (d, J = 8.4 Hz, 2H), 7.09 (d, 2H,
J = 8.8 Hz), 7.33–7.36 (b, 10 H), 10.80 (s, 1H). 13C NMR (100 MHz, DMSO-d6): δ = 25.7, 69.8, 99.2,
113.6, 114.7,121.5, 126.5, 127.8, 128.2, 128.7, 130.2, 131.0, 132.1, 132.2, 137.0, 137.2, 148.8, 158.2,
159.8, 166.3, 183.3. MS (ESI): m/z = 570.2 [M + K]+.
3.8. 6-(4-(Benzyloxy)benzoyl)-5-(4-(benzyloxy)phenyl)-3-methyl-1H-pyrrolo[2,3-d]pyrimidine-2,4
(3H,7H)-dione 15
A mixture of pyrrolocarboxamide 14 (5.31 g, 10.0 mmol), triphosgene (1.48 g, 5.0 mmol) and
iodine (0.127 g, 0.5 mmol) in anhydrous THF (10 mL) was heated to reflux for 20 h before the
volatiles were removed in vacuo. The residue was dissolved in ethyl acetate (10 mL) and washed with
brine (10 mL), dried over anhydrous MgSO4, and purified by column chromatography
(MeOH/CH2Cl2 = 1:10) to afford the title product 15 (3.34 g, 60% yield).
MP: 226–228 °C; Rf = 0.35 (MeOH–CH2Cl2, 1:10). 1H NMR (400 MHz, DMSO-d6): δ = 3.14 (s, 3H,
CH3), 5.00 (s, 2H, CH2), 5.03 (s, 2H), 6.67–6.73 (m, 4H), 7.03–7.05 (m, 2H), 7.28–7.35 (m, 12H), 11.65
(s, 1H), 11.96 (s, 1H). 13C NMR (100 MHz, DMSO-d6): δ = 27.2, 69.7, 69.9, 98.4, 113.7, 114.2, 125.1,
125.7, 127.9, 128.0, 128.2, 128.4, 128.9, 130.9, 131.7, 132.7, 136.9, 137.5, 140.1, 151.2, 158.0, 159.5,
161.4, 185.7. MS (ESI): m/z = 596.2 [M + Na]+.
3.9. Rigidin E 5
A
mixture of 6-(4-(benzyloxy)benzoyl)-5-(4-(benzyloxy)phenyl)-3-methyl-1H-pyrrolo[2,3-d]
pyrimidine-2,4(3H,7H)-dione 15 (1.114 g, 2 mmol) and NaI (9.0 g, 60 mmol) in CH3CN (20 mL)
under N2 was stirred at room temperature for 20 min. Chlorotrimethylsilane (17.8 g, 60 mmol) was
then added. The mixture was stirred at 60 °C for 18 h before the volatiles were removed in vacuo. The
residue was extracted with petroleum ether (10 mL × 3) in order to remove benzyl iodide, and then
treated with water (5 mL) and ethyl acetate (10 mL). The mixture was stirred vigorously at room
temperature for 2 h and extracted with more ethyl acetate (40 mL × 2). The combined organic layers
were washed with brine (5 mL) containing a small amount of sodium thiosulfate, dried over anhydrous
MgSO4, and purified by column chromatography (PE/Ethyl Acetate/MeOH/AcOH = 9:18:1:1) to
afford the title product rigidin E (5) (664 mg, 88% yield).

Mar. Drugs 2012, 10
1420
1
MP > 300 °C ; Rf = 0.31 (PE–Ethyl Acetate–MeOH–AcOH = 9:18:1:1). H NMR (400 MHz,
DMSO-d6): δ = 3.14 (s, 3H, CH3), 6.44 (t, J = 8.0 Hz, 4H), 6.93 (d, J = 7.6 Hz, 2H), 7.27 (d, J = 8.0 Hz,
2H). 13C NMR (100 MHz, DMSO-d6): δ = 27.2, 98.2, 114.2, 114.7, 123.4, 125.3, 128.7, 129.2, 132.0,
132.8, 152.4, 156.8, 159.9, 161.0, 185.7. HRMS–ESI: m/z [M + H]+ calcd for C20H15N3O5: 378.1012;
found: 378.1098.
4. Conclusions
In conclusion, we have developed an efficient approach for the total synthesis of rigidin E using
readily available starting materials and routine chemical transformations. This strategy is especially
useful to access different N-3 substituted rigidin derivatives.
Acknowledgments
We thank NSFC (No. 20962009, 21062006), NCET (11-1000), Education Department of Jiangxi
Province (GJJ 11223) and Bureau of Science & Technology of Nanchang City for financial support.
References
1. Kobayashi, J.; Cheng, J.; Kikuchi, Y.; Ishibashi, M.; Yamamura, S.; Ohizumi, Y.; Ohtac, T.;
Nozoec, S. Rigidin, a novel alkaloid with calmodulin antagonistic activity from the okinawan
marine tunicate Eudistoma cf. rigida. Tetrahedron Lett. 1990, 31, 4617–4620.
2. Tsuda, M.; Nozawa, K.; Shimbo, K.; Kobayashi, J. Rigidins B–D, new pyrrolopyrimidine
alkaloids from a tunicate Cystodytes species. J. Nat. Prod. 2003, 66, 292–294.
3. Davis, R.A.; Christensen, L.V.; Richardson, A.D.; Da Rocha, R.M.; Ireland, C.M. Rigidin E, a
new pyrrolopyrimidine alkaloid from a Papua New Guinea tunicate Eudistoma species.
Mar. Drugs 2003, 1, 27–33.
4. Ölgen, S.; Isgör, Y.G.; Coban, T. Synthesis and Activity of Novel 5-Substituted Pyrrolo[2,3-d]
pyrimidine Analogues as pp60c-Src Tyrosine Kinase Inhibitors. Arch. Pharm. 2008, 341, 113–120.
5. Bhat, U.G.; Gartel, A.L. Differential sensitivity of human colon cancer cell lines to the nucleoside
analogs ARC and DRB. Int. J. Cancer 2008, 122, 1426–1429.
6. Seela, F.; Peng, X.; Budow, S. Advances in the Synthesis of 7-Deazapurine—pyrrolo[2,3-d]
pyrimidine 2′-Deoxyribonucleosides Including D- and L-Enantiomers, Fluoro Derivatives and
2′,3′-Dideoxyribonucleosides. Curr. Org. Chem. 2007, 11, 427–462.
7. Matthew, M.; Xu, F.; Waters, M.; Williams, J.M.; Savary, K.A.; Cameron, J.; Yang, C.; Buck, E.;
Song, Z.J.; Tschaen, D.M. Practical synthesis of a potent hepatitis C virus RNA replication
inhibitor. J. Org. Chem. 2004, 69, 6257–6266.
8. Gangjee, A.; Vidwans, A.; Elzein, E.; McGuire, J.J.; Queener, S.F.; Kisliuk, R.L. Synthesis,
antifolate, and antitumor activities of classical and nonclassical 2-amino-4-oxo-5-substituted-pyrrolo
[2,3-d] pyrimidines. J. Med. Chem. 2001, 44, 1993–2003.
9. Renau, T.E.; Kennedy, C.; Ptak, R.G.; Breitenbach, J.M.; Drach, J.C.; Townsend, L.B. Synthesis
of non-nucleoside analogs of toyocamycin, sangivamycin, and thiosangivamycin: The effect of
certain 4- and 4,6-substituents on the antiviral activity of pyrrolo[2,3-d] pyrimidines. J. Med.
Chem. 1996, 39, 3470–3476.

Mar. Drugs 2012, 10
1421
10. Sun, J.; Dou, Y.; Ding, H.; Yang, R.; Sun, Q.; Xiao, Q. First Total Synthesis of a Naturally
Occurring Iodinated 5′-Deoxyxylofuranosyl Marine Nucleoside. Mar. Drugs 2012, 10, 881–889.
11. Song, Y.; Ding, H.; Dou, Y.; Yang, R.; Sun, Q.; Xiao, Q.; Ju, Y. Efficient and practical synthesis
of 5′-deoxytubercidin and its analogues via Vorbruggen glycosylation. Synthesis 2011, 2011,
1442–1446.
12. Edstrom, E.D.; Wei, Y. Synthesis of a novel pyrrolo[2,3-d] pyrimidine alkaloid, rigidin. J. Org.
Chem. 1993, 58, 403–407.
13. Sakamoto, T.; Kondo, Y.; Sato, S.; Yamanaka, H. Condensed heteroaromatic ring systems.
Part 24. Synthesis of rigidin, a pyrrolo[2,3-d] pyrimidine marine alkaloid. J. Chem. Soc. Perkin
Trans. 1 1996, 459–464.
14. Sakamoto, T.; Kondo, Y.; Sato, S.; Yamanaka, H. Total synthesis of a marine alkaloid, rigidin.
Tetrahedron Lett. 1994, 35, 2919–2920.
15. Gupton, J.T.; Banner, E.J.; Scharf, A.B.; Norwood, B.K.; Kanters, R.P.F.; Dominey, R.N.;
Hempel, J.E.; Kharlamova, A.; Bluhn-Chertudi, I.; Hickenboth, C.R. The application of
vinylogous iminium salt derivatives to an efficient synthesis of the pyrrole containing alkaloids
Rigidin and Rigidin E. Tetrahedron 2006, 62, 8243–8255.
16. Frolova, L.V.; Evdokimov, N.M.; Hayden, K.; Malik, I.; Rogelj, S.; Kornienko, A.; Magedov,
I.V. One-Pot Multicomponent Synthesis of Diversely Substituted 2-Aminopyrroles. A Short
General Synthesis of Rigidins A, B, C, and D. Org. Lett. 2011, 13, 1118–1121.
17. Jaques, J.; Marquet, A. Selective α-bromination of an aralkyl ketone with phenyltrimethylammonium
tribromide: 2-bromoacetyl-6-methoxynaphthalene and 2,2-dibromoacetyl-6-methoxynaphthalene.
Org. Synth. 1976, 53, 111.
18. Basheer, A.; Yamataka, H.; Ammal, S.C.; Rappoport, Z. Enols of substituted cyanomalonamides.
J. Org. Chem. 2007, 72, 5297–5312.
19. Laliberté, R.; Médawar, G. β-Ketoalkylthioacrylic acid derivatives as precursors of thiophenes,
thiazolines, and thienopyrimidines. Can. J. Chem. 1970, 48, 2709–2717.
20. Lyons, D.M.; Huttunen, K.M.; Browne, K.A.; Ciccione, A.; Trapani, J.A.; Denny, W.A.; Spicer, J.A.
Inhibition of the cellular function of perforin by 1-amino-2,4-dicyanopyrido[1,2-a] benzimidazoles.
Biorg. Med. Chem. 2011, 19, 4091–4110.
21. Magedov, I.V.; Luchetti, G.; Evdokimov, N.M.; Manpadi, M.; Steelant, W.F.A. Novel
three-component synthesis and antiproliferative properties of diversely functionalized pyrrolines.
Bioorg. Med. Chem. Lett. 2008, 18, 1392–1396.
22. Wang, S.L.; Yang, K.; Yao, C.S.; Wang, X.S. Green Synthesis of Quinazolinone Derivatives
Catalyzed by Iodine in Ionic Liquid. Synth. Commun. 2012, 42, 341–349.
23. Kirincich, S.J.; Xiang, J.; Green, N.; Tam, S.; Yang, H.Y.; Shim, J.; Shen, M.W.H.; Clark, J.D.;
McKew, J.C. Benzhydrylquinazolinediones: Novel cytosolic phospholipase A 2 α inhibitors with
improved physicochemical properties. Biorg. Med. Chem. 2009, 17, 4383–4405.
Samples Availability: Available from the authors.
© 2012 by the authors; licensee MDPI, Basel, Switzerland. This article is an open access article
distributed under the terms and conditions of the Creative Commons Attribution license
(http://creativecommons.org/licenses/by/3.0/).
