Asymmetric synthesis of the epimeric (3S)-3-((E)-hex-1-enyl)-2- methylcyclohexanones

Article abstract of DOI:10.3390/12020237

The asymmetric rhodium-catalysed 1,4-addition of alkenylzirconium reagents to 2-cyclohexenone can be useful in the synthesis of 3-alkenyl-2- methylcyclohexanones, provided that formaldehyde is used in trapping the intermediate zirconium enolates. In this

Full text of DOI:10.3390/12020237

Molecules 2007, 12, 237-244
molecules
ISSN 1420-3049
http://www.mdpi.org
Full Paper
Asymmetric Synthesis of the Epimeric (3S)-3-((E)-Hex-1-enyl)-
2-methylcyclohexanones
Freek A. Vrielynck and Pierre J. De Clercq*
Ghent University, Department of Organic Chemistry, Laboratory for Organic Synthesis, Krijgslaan
281 (S4), B-9000 Gent, Belgium
* Author to whom correspondence should be addressed. E-mail: pierre.declercq@UGent.be
Received: 9 January 2007; in revised form: 20 February 2007 / Accepted: 20 February 2007 /
Published: 21 February 2007
Abstract: The asymmetric rhodium-catalysed 1,4-addition of alkenylzirconium reagents
to 2-cyclohexenone can be useful in the synthesis of 3-alkenyl-2-methylcyclohexanones,
provided that formaldehyde is used in trapping the intermediate zirconium enolates. In
this manner a four-step sequence leading to the two epimeric 3-hexenyl-2-
methylcyclohexanones in enantiomeric form was developed.
Keywords: Enantioselective 1,4-addition, zirconium O-enolate trapping, 2-cyclo-
hexenone.
Introduction
In the context of the development of CD-ring modified structural analogs of calcitriol, the
hormonally active metabolite of vitamin D3 [1], we required the epimeric ketones 4a and 4b (Scheme
1) in enantiopure form. Both cyclohexanones are being converted to derivatives in which the bicyclic
CD-entity is replaced by a single six-membered D-ring and in which the hexenyl substituent serves as
a latent aldehyde for the introduction of the A-ring [2]. We describe herein in detail a synthesis of 4a
and 4b featuring a highly enantioselective 1,4-addition of alkenylzirconocene to 2-cyclohexenone
catalysed by the chiral rhodium complex generated from [Rh(cod)Cl]2 and (R)-BINAP [3], followed
by trapping of the O-enolate with formaldehyde.

Molecules 2007, 12
238
Results and Discussion
The synthesis of the two epimeric cyclohexanones 4a and 4b rests on the asymmetric 1,4-
introduction of the hexenyl side chain on 2-cyclohexenone followed by trapping of the resulting metal
O-enolate with an electrophilic reagent.
Scheme 1. Synthetic pathway to epimeric (3S)-3-((E)-hex-1-enyl)-2-methylcyclo-
hexanones 4a and 4b.
H
ZrCp2Cl
H
Cp2Zr(H)Cl
n-C4H9 C CH
C C
n-C4H9
O
O
O
[Rh(cod)Cl]2
(R)-BINAP
b
HO
HO
+
a
1a
1b
n-Bu
n-Bu
O
OH
OH
O
d
e
RO
+
n-Bu
n-Bu
n-Bu
n-Bu
1a R = H
3aa
3ab
4a
c
2a R = Ms
O
OH
OH
O
d
e
RO
+
n-Bu
n-Bu
n-Bu
n-Bu
1b R = H
3ba
3bb
4b
c
2b R = Ms
(a) Cp2Zr(H)Cl, n-C4H9C≡CH, THF, rt, 45 min; [Rh(cod)Cl]2, (R)-BINAP, THF, rt, 30 min; 2-
cyclohexenone, rt, 3 h. (b) CH2O (from paraformaldehyde), –78 °C (89%). (c) MsCl, Et3N,
CH2Cl2, 0 °C (a: 96%; b: 99%). (d) LiAlH4, Et2O, reflux, 2 h (a: 95%; b: 98%). (e) (COCl)2,
DMSO, Et3N, –78 °C J rt (a: 89%; b: 96%).
Among several known enantioselective 1,4-additions of organometallic reagents to α,β-unsaturated
ketones, we obtained the best results with the recently reported rhodium(I)-catalysed addition of
alkenylzirconocene chlorides with BINAP as chiral ligand [3,4]. This result also follows Nicolaou’s
report of the tandem reaction of the rhodium-catalysed asymmetric additions of alkenylzirconium
reagents followed by trapping of the zirconium enolate by aldehydes [5]. In our case, the 1,4-addition
was performed on 2-cyclohexenone using (E)-1-hexenylzirconocene chloride [6], prepared from 1-

Molecules 2007, 12
239
hexyne and bis(cyclopentadienyl)zirconium chloride hydride (Cp2Zr(H)Cl or Schwartz reagent) in the
presence of a catalytic amount of the Rh(I)-complex [Rh(cod)Cl]2 and (R)-BINAP as a chiral ligand.
As previously observed by Schwartz, we were unable to directly alkylate the intermediate zirconium
O-enolate [7]; however, reaction with gaseous formaldehyde at –78 °C led, after acid work-up, to a
2.7:1 mixture (89% yield) of 1a and 1b, respectively [8], with an excellent ee (better than 96%) [9].
The obtained mixture was readily separated by flash chromatography. The assignment of the trans-
and cis-relationship to the alkyl substituents in the a- and b-series, respectively, rests on the analysis of
NMR spectral data of 1a. The diequatorial orientation in 1a follows from the large vicinal J-value of
11.7 Hz for the coupling between Ha and Hb. The same coupling in epimer 1b (5.3 Hz) is indicative of
a cis-relationship (Figure 1). The absolute configuration was assigned on the basis of the results
obtained by Oi and Inoue [3].
Figure 1. 1H-NMR structural assignment of 1a.
Hc
Ha
Jab = 11.7 Hz, Jbc = 11.5 Hz
Jbd = 3.7 Hz, Jae = 6.4 Hz
Jaf = 3.2 Hz
Hd
HO
O
C4H9
Hf
Hb
He
1a
Figure 2. 1H-NMR structural assignments of the intermediate alcohols 3aa, 3ab, 3ba, and 3bb.
Hb
H
H
H
H
Ha
HO
C4H9
C4H9
H
CH3
CH3
Ha
HO
H
H
3aa
3ab
δHa = 3.88 ppm
ΣJ = 25 Hz
δHa = 3.15 ppm
ΣJ = 39 Hz
W-coupling with Hb
C4H9
H
H
nOe
H
H
CH3
Ha
H
H
HO
C4H9
HO
CH3
H
Hb
Ha
Hc
nOe
Hc
Hb
3ba
3bb
δHb = 1.59 ppm
δHc = 2.41 ppm
δHb = 1.97 ppm
δHc = 2.11 ppm
Ha: dt, J = 3.8, 7.7 Hz
Ha: dt, J = 10.6, 4.1 Hz
The further conversion of 1a and 1b to 4a and 4b, respectively, first involves the reduction of the
mesylates 2a and 2b, obtained by treatment with mesyl chloride and triethylamine in dichloromethane,
to afford a mixture of the two epimeric alcohols. From 2a there was obtained in 95% yield a 1:4

Molecules 2007, 12
240
mixture of 3aa and 3ab; from 2b there was obtained in 98% yield a 1:4 mixture of 3ba and 3bb,
respectively. Again the structural assignment of the four isomeric alcohols rested on 1H-NMR analysis
(Figure 3). Within the trans-series distinction between 3aa and 3ab readily follows from the coupling
constant pattern of the Ha proton, which indicates an axial hydroxyl group in 3aa (cf. smaller sum of
vicinal J-values for Ha) and an equatorial one in 3ab (cf. larger sum of vicinal J-values for Ha).
Furthermore a characteristic long range W coupling is observed between Ha and Hb in 3aa. The
structural assignment in the cis-series (3ba and 3bb) on the other hand rests on the observed nOe’s in
both derivatives, in particular between Ha and the olefinic proton of the hexenyl side-chain in 3ba.
Finally, Swern oxidation of both mixtures led to the desired cyclohexanones 4a and 4b [10].
Conclusions
The two epimeric cyclohexanones 4a and 4b have been obtained in four steps starting from 2-
cyclohexenone. The synthesis was based on the very efficient asymmetric 1,4-introduction of the 1-
hexenyl chain using alkenylzirconocene and a chiral rhodium complex.
Experimental
General
Dichloromethane was distilled from CaH2. Diethyl ether and tetrahydrofuran (THF) were distilled
from benzophenone ketyl. TLC were run on glass plates precoated with silica gel (Merck, 60F-254).
Column chromatography was performed on silica gel (Merck, 230-400 mesh). IR spectra (KBr films)
1
were recorded on a Perkin–Elmer series 1600 FT-IR spectrometer. H-NMR and 13C-NMR spectra
were recorded on a Bruker AM-500 spectrometer operating at 500 (1H) and 125 MHz (13C),
respectively. Mass spectra (EI) were recorded on a Hewlett–Packard 5898A spectrometer at 70 eV.
(2R,3S)-3-((E)-Hex-1-enyl)-2-(hydroxymethyl)cyclohexanone (1a) and (2S,3S)-3-((E)-hex-1-enyl)-2-
(hydroxylmethyl)cyclohexanone (1b).
Dry formaldehyde was prepared as follows: paraformaldehyde is predried overnight in vacuo at 60
°C in a three-necked 100-mL, round-bottom flask. The flask is equipped with an inlet for N2 (dried
over molecular sieves) and is connected via Teflon tubing to the reaction flask. The latter is then
equipped with a CaCl2 drying tube. The entire system is evacuated, filled with N2 and the dried
paraformaldehyde is depolymerised in a stream of N2 by heating at 180 °C. To a suspension of
Cp2ZrHCl (6.20 g, 24 mmol) in dry THF (80 mL) under Ar was added 1-hexyne (2.76 mL, 24 mmol)
and the mixture was stirred at rt for 45 minutes to give a solution of 1-hexenyl-zirconocene chloride.
In a two-necked 250-mL flask under Ar, [Rh(cod)Cl]2 (247 mg, 1 mmol) and (R)-BINAP (749 mg, 1.2
mmol) were dissolved in dry THF (40 mL) and the solution was stirred at rt for 0.5 h. To the solution
of rhodium catalyst, cyclohexenone (1.94 mL, 20 mmol) and the solution of 1-hexenylzirconocene
chloride were added and the mixture was stirred at rt for 3 h. The reaction mixture was cooled to –78
°C and quenched with gaseous dry formaldehyde (see above). After warming up the mixture to rt, an
aqueous saturated NH4Cl solution (3 mL) was added and the resulting mixture was stirred for 0.5 h. t-
Butylmethyl ether (MTBE; 200 mL) was added and the precipitate formed was removed by filtration.

Molecules 2007, 12
241
After removal of the solvent under reduced pressure, the residue was purified by flash chromatography
on silica gel (n-pentane/EtOAc, 83:17 to 75:25) to give cyclohexanones 1a (2.70 g) and 1b (1.04 g) in
89% total yield.
rt
1a: Rf (isooctane/EtOAc, 1:1) 0.38; [α]D –10.0 (c 1.0, CHCl3); IR ν 3493 (br, m), 2929 (vs), 2871
1
(vs), 1701 (vs), 1459 (m), 1328 (m), 1222 (m), 1085 (m), 1052 (m), 969 (s) cm–1; H-NMR (C6D6) δ
5.29 (1 H, dt, J = 15.2, 6.7 Hz), 5.01 (1 H, ddt, J = 15.2, 8.8, 1.2 Hz), 3.85 (1 H, ddd, J = 11.6, 8.0, 3.2
Hz), 3.73 (1 H, dt, J = 11.6, 6.4 Hz), 2.85 (1 H, dd, J = 8.0, 6.4 Hz), 2.15 (1 H, app. d, J = 13.4 Hz),
2.04 (1 H, dddd, J = 11.7, 11.5, 8.8, 3.7 Hz), 1.86 (3 H, m), 1.75 (1 H, tdd, J = 13.4, 6.0, 1.0 Hz), 1.45
(2 H, m), 1.22 (4 H, m), 1.19 (1 H, tt, J = 13.5, 3.7 Hz), 1.11 (1 H, tdd, J = 13.4, 11.5, 3.7 Hz), 0.85 (3
H, t, J = 7.1 Hz) ppm; 13C-NMR (C6D6) δ 212.7 (C=O), 132.4 (=CH), 131.8 (=CH), 60.6 (CH2), 56.5
(CH), 45.0 (CH), 41.9 (CH2), 32.6 (CH2), 32.4 (CH2), 31.8 (CH2), 25.7 (CH2), 22.5 (CH2), 14.1 (CH3)
ppm; MS m/z (%) 210 (M+, 3), 192 (8), 179 (100), 163 (6), 149 (13), 135 (26), 123 (54), 110 (33), 97
(21), 79 (81), 67 (97), 55 (87), 41 (99).
1b: Rf (isooctane/EtOAc, 1:1) 0.28; [α]Drt +7.0 (c 0.9, CHCl3); IR ν 3408 (br, m), 2956 (vs), 2930 (vs),
1
2873 (vs), 1707 (vs), 1460 (m), 1379 (m), 1312 (m), 1238 (w), 1138 (m), 1025 (s), 969 (s) cm–1; H-
NMR (C6D6) δ 5.26 (1 H, dt, J = 15.2, 6.4 Hz), 5.17 (1 H, dd, J = 15.2, 8.9 Hz), 4.00 (1 H, ddd, J =
11.5, 8.8, 2.1 Hz), 3.34 (1 H, ddd, J = 11.5, 8.5, 5.3 Hz), 2.42 (1 H, dq, J = 8.9, 3.6 Hz), 2.36 (1 H, dtd,
J = 8.8, 5.3, 1.0 Hz), 2.17 (1 H, app. d, J = 13.8 Hz), 1.99 (1 H, app. d, J = 5.3 Hz), 1.82 (3 H, m), 1.58
(1 H, m), 1.30 (3 H, m), 1.19 (4 H, m), 0.83 (3 H, t, J = 7.0 Hz) ppm; 13C-NMR (C6D6) δ 212.0 (C=O),
133.1 (=CH), 128.4 (=CH), 61.5 (CH2), 55.8 (CH), 43.6 (CH), 41.7 (CH2), 32.4 (CH2), 31.8 (CH2),
31.7 (CH2), 22.9 (CH2), 22.4 (CH2), 14.0 (CH3) ppm; MS m/z (%) 210 (M+, 2), 192 (10), 179 (14), 163
(6), 149 (9), 135 (32), 123 (50), 110 (98), 107 (29), 97 (47), 86 (48), 79 (83), 67 (100), 55 (82), 41
(98).
((1R,2S)-2-((E)-Hex-1-enyl)-6-oxocyclohexyl)methyl methanesulfonate (2a) and ((1S,2S)-2-((E)-hex-1-
enyl)-6-oxocyclohexyl)methyl methanesulfonate (2b)
To an ice-cold solution of alcohol 1a (458 mg, 2.18 mmol) and Et3N (0.61 mL, 4.36 mmol) in
CH2Cl2 (22 mL) was added MsCl (0.25 mL, 3.27 mmol). After stirring for 0.5 h, the reaction mixture
was quenched with an aqueous saturated NaHCO3 solution and the product was extracted with CH2Cl2.
The combined organic extracts were consecutively washed with a HCl solution (0.5 M; 5 mL) and a
saturated NaHCO3 solution (8 mL), dried over anhydrous MgSO4 and concentrated under reduced
pressure to give mesylate 2a (604 mg, 96%). The same procedure applied to alcohol 1b afforded
mesylate 2b as a solid in 99% yield.
rt
2a: Rf (isooctane/EtOAc, 6:4) 0.37; [α]D –17.0 (c 1.0, CH3OH); IR ν 2956 (s), 2931 (s), 2860 (m),
1715 (vs), 1458 (m), 1356 (vs), 1251 (vw), 1174 (vs), 974 (s), 950 (s), 823 (w), 529 (s) cm–1; 1H-NMR
(C6D6) δ 5.37 (1 H, dt, J = 15.3, 6.6 Hz), 4.95 (1 H, dd, J = 15.3, 9.0 Hz), 4.32 (1 H, dd, J = 9.5, 1.9
Hz), 4.21 (1 H, dd, J = 9.5, 5.7 Hz), 2.49 (3 H, s), 2.15 (1 H, app. d, J = 13.9 Hz), 2.02 (1 H, tdd, J =
11.8, 9.0, 3.7 Hz), 1.90 (2 H, m), 1.75 (1 H, ddd, J = 11.8, 5.7, 1.9), 1.69 (1 H, td, J = 13.9, 6.0 Hz),
1.42 (2 H, m), 1.27 (4 H, m), 1.15 (1 H, qt, J = 14.2, 3.5 Hz), 1.02 (1 H, qd, J = 12.9, 3.3 Hz), 0.91 (3

Molecules 2007, 12
242
H, t, J = 7.3 Hz) ppm; 13C-NMR (C6D6) δ 206.5 (C=O), 132.9 (=CH), 131.0 (=CH), 66.0 (OCH2), 53.4
(CH), 44.4 (CH), 41.2 (CH2), 36.3 (SCH3), 32.4 (CH2), 32.2 (CH2), 31.6 (CH2), 25.1 (CH2), 22.4
(CH2), 14.0 (CH3) ppm; MS m/z (%) 289 (MH+, 8), 205 (4), 192 (79), 179 (17), 163 (34), 149 (36),
135 (65), 122 (66), 107 (36), 93 (43), 79 (100), 67 (42), 55 (46), 41 (47).
rt
2b: mp 39 °C; Rf (isooctane/EtOAc, 6:4) 0.37; [α]D –28.5 (c 1.0, CH3OH); IR ν 2956 (s), 2932 (s),
2873 (m), 1711 (vs), 1459 (w), 1358 (vs), 1210 (vw), 1177 (vs), 1142 (vw), 959 (vs), 866 (w), 825
1
(w), 528 (m) cm–1; H-NMR (C6D6) δ 5.32 (1 H, dt, J = – 15.1, 6.8 Hz), 5.07 (1 H, dd, J = 15.1, 9.7
Hz), 4.51 (1 H, dd, J = 10.2, 6.5 Hz), 4.00 (1 H, dd, J = 10.2, 6.8 Hz), 2.61 (1 H, dq, J = 9.7, 3.4 Hz),
2.48 (1 H, app. q, J = 6.2 Hz), 2.26 (3 H, s), 2.11 (1 H, app. d, J = 13.2 Hz), 1.80 (2 H, m), 1.73 (1 H,
td, J = 13.4, 6.0 Hz), 1.51 (1 H, m), 1.35 (3 H, m), 1.18 (4 H, m), 0.84 (3 H, t, J = 7.0 Hz) ppm; 13C-
NMR (C6D6) δ 208.0 (C=O), 134.9 (=CH), 126.3 (=CH), 68.0 (OCH2), 52.4 (CH), 43.4 (CH), 41.5
(CH2), 36.2 (SCH3), 32.3 (CH2), 31.5 (CH2), 31.2 (CH2), 22.9 (CH2), 22.3 (CH2), 13.9 (CH3) ppm; MS
m/z (%) 256 (5), 223 (4), 208 (14), 192 (24), 149 (24), 135 (16), 123 (14), 105 (16), 91 (35), 79 (56),
67 (51), 55 (76), 41 (100).
(2S,3S)-3-((E)-Hex-1-enyl)-2-methylcyclohexanol (3aa, 3ab) and (2R,3S)-3-((E)-hex-1-enyl)-2-methyl-
cyclohexanol (3ba, 3bb)
LiAlH4 (143 mg, 3.76 mmol) in dry Et2O (7.5 mL) was refluxed for 30 min. Methanesulfonate 2a
(546 mg, 1.89 mmol) in dry Et2O (7.5 mL) was dropwise added at reflux temperature over a period of
10 min. The reaction mixture was refluxed for 2 h, then cooled to 0 °C and quenched by the sequential
addition of H2O (145 µL), NaOH (15% solution; 145 µL) and H2O (300 µL). After stirring at rt for 1h,
the white precipitate was removed by filtration over Celite® and washed with EtOAc. The filtrate was
concentrated under reduced pressure and the residue was purified by flash chromatography on silica
gel (n-pentane/EtOAc, 9:1) to give alcohols 3aa (70 mg) and 3ab (285 mg) in 96% total yield. The
same procedure applied to methanesulfonate 2b (1.06 g) afforded alcohols 3ba (141 mg) and 3bb (563
mg) in 98% total yield.
rt
3aa: Rf (isooctane/EtOAc, 6:4) 0.54; [α]D –45.7 (c 1.0, CHCl3); IR ν 3392 (br, m), 2957 (s), 2928
(vs), 2872 (s), 1456 (m), 1376 (w), 1212 (w), 963 (w), 879 (w) cm–1; 1H-NMR (CDCl3) δ 5.37 (1 H, dt,
J = 15.2, 6.2 Hz), 5.15 (1 H, ddt, J = 15.2, 8.6, 1.1), 3.88 (1 H, m, ΣJ = 25 Hz), 1.96 (3 H, m), 1.81 (1
H, app. d, J = 13.2 Hz), 1.64 (2 H, m), 1.46 (2 H, m), 1.35–1.24 (5 H, m), 1.11 (1 H, m), 0.92 (3 H, d, J
= 7.0 Hz), 0.87 (3 H, t, J = 7.0 Hz) ppm; 13C-NMR (CDCl3) δ 134.7 (=CH), 130.1 (=CH), 71.1 (OCH),
41.7 (CH), 40.6 (CH), 33.3 (CH2), 33.3 (CH2), 32.3 (CH2), 31.9 (CH2), 22.2 (CH2), 19.6 (CH2), 16.7
(CH3), 14.0 (CH3) ppm; MS m/z (%) 196 (M+, <1), 178 (54), 163 (8), 149 (25), 135 (56), 121 (25), 111
(50), 93 (51), 79 (52), 67 (54), 55 (54), 41 (100).
rt
3ab: Rf (isooctane/EtOAc, 6:4) 0.47; [α]D +12.3 (c 1.0, CHCl3); IR ν 3350 (br, m), 2958 (s), 2926
(vs), 2857 (s), 1458 (m), 1376 (w), 1358 (w), 1294 (vw), 1117 (vw), 1032 (s), 966 (vs), 858 (vw) cm–1;
1H-NMR (CDCl3) δ 5.37 (1 H, dt, J = 15.2, 6.7 Hz), 5.17 (1 H, ddd, J = 15.2, 8.5, 1.2), 3.15 (1 H, m,
ΣJ = 39 Hz), 1.96 (3 H, m), 1.72 (1 H, app. d, J = 13.0 Hz), 1.57 (2 H, m), 1.43 (1 H, s), 1.37–1.20 (6
H, m), 1.10 (1 H, m), 1.06 (1 H, m), 0.97 (3 H, d, J = 6.6 Hz), 0.87 (3 H, t, J = 6.9 Hz) ppm; 13C-NMR

Molecules 2007, 12
243
(CDCl3) δ 134.0 (=CH), 130.4 (=CH), 76.1 (OCH), 47.3 (CH), 44.6 (CH), 35.5 (CH2), 33.4 (CH2),
32.2 (CH2), 31.8 (CH2), 23.9 (CH2), 22.2 (CH2), 16.0 (CH3), 14.0 (CH3) ppm; MS m/z (%) 196 (M+,
<1), 178 (22), 163 (5), 149 (22), 135 (29), 121 (42), 108 (21), 93 (40), 79 (47), 67 (52), 55 (59), 41
(100).
rt
3ba: Rf (isooctane/EtOAc, 8:2) 0.47; [α]D –40.3 (c 1.0, CHCl3); IR ν 3349 (br, m), 2956 (s), 2928
1
(vs), 2872 (s), 1460 (m), 1377 (w), 1142 (w), 1042 (m), 1017 (m), 967 (s) cm–1; H-NMR (CDCl3) δ
5.40 (2 H, m), 3.56 (1 H, td, J = 7.7, 3.8 Hz), 2.41 (1 H, m), 2.20 (2 H, m), 1.85 (1 H, m), 1.59 (3 H,
13
m), 1.50 (2 H, m), 1.41–1.28 (5 H, m), 0.90 (3 H, d, J = 6.9 Hz), 0.89 (3 H, t, J = 6.5 Hz) ppm; C-
NMR (CDCl3) δ 131.2 (=CH), 130.9 (=CH), 72.4 (CH), 41.8 (CH), 41.6 (CH), 32.7 (CH2), 32.5 (CH2),
31.9 (CH2), 29.6 (CH2), 22.2 (CH2), 20.4 (CH2), 14.5 (CH3), 14.0 (CH3) ppm; MS m/z (%) 196 (M+,
4), 178 (14), 163 (4), 149 (17), 135 (22), 121 (42), 111 (39), 93 (42), 79 (48), 67 (47), 55 (49), 41
(100).
rt
3bb: Rf (isooctane/EtOAc, 8:2) 0.47; [α]D –10.3 (c 1.0, CHCl3); IR ν 3350 (br, m), 2928 (vs), 2860
(s), 1466 (m), 1447 (m), 1378 (w), 1342 (w), 1301 (w), 1119 (w), 1053 (m), 1016 (m), 968 (s) cm–1;
1H-NMR (CDCl3) δ 5.41 (1 H, dd, J = 15.5, 5.3 Hz), 5.38 (1 H, dt, J = 15.5, 5.8 Hz), 3.72 (1 H, dt, J =
10.6, 4.1 Hz), 2.11 (1 H, m), 1.97 (3 H, m), 1.72 (1 H, m), 1.59 (1 H, app. d, J = 12.3 Hz), 1.42 (1 H,
m); 1.37–1.20 (7 H, m), 0.87 (3 H, t, J = 6.8 Hz), 0.80 (3 H, d, J = 7.0 Hz) ppm; 13C-NMR (CDCl3) δ
133.3 (=CH), 129.5 (=CH), 73.6 (CH), 42.8 (CH), 39.8 (CH), 32.4 (CH2), 31.9 (CH2), 29.0 (CH2), 24.8
(CH2), 23.2 (CH2), 22.2 (CH2), 14.0 (CH3), 6.7 (CH3) ppm; MS m/z (%) 196 (M+,<1), 178 (40), 163
(6), 149 (22), 135 (32), 122 (28), 111 (36), 108 (25), 93 (36), 79 (50), 67 (34), 55 (51), 41 (100).
(2S,3S)-3-((E)-Hex-1-enyl)-2-methylcyclohexanone (4a) and (2R,3S)-3-((E)-hex-1-enyl)-2-methyl-
cyclohexanone (4b)
To a solution of (COCl)2 (113 µL, 1.33 mmol) in dry CH2Cl2 (4 mL) was dropwise added a
solution of dimethyl sulfoxide (DMSO; 189 µL, 2.66 mmol) in dry CH2Cl2 (750 µL) at –78 °C. After 2
minutes of stirring, a mixture of alcohols 3aa and 3ab (238 mg, 1.21 mmol) in dry CH2Cl2 (3 mL) was
dropwise added over a period of 5 min and the mixture was stirred for 15 min. Et3N (845 µL, 6.66
mmol) was then added and the reaction mixture was stirred for an additional 5 min, followed by slow
warming to rt. H2O (10 mL) was added and the product was extracted with CH2Cl2. The combined
organic layers were concentrated under reduced pressure and the residue was diluted with t-butyl
methyl ether (MTBE). After washing with H2O, the organic layer was dried over anhydrous MgSO4
and evaporated under reduced pressure. The residue was purified by flash chromatography on silica
gel (n-pentane/EtOAc, 98:2) to give cyclohexanone 4a (209 mg, 89%). The same procedure applied to
the mixture of alcohols 3ba and 3bb afforded cyclohexanone 4b in 96% yield.
4a: Rf (isooctane/EtOAc, 8:2) 0.44; [α]Drt –12.0 (c 1.0, CH3OH); IR ν 2930 (vs), 2863 (vs), 1712 (vs),
1450 (m), 1376 (w), 1329 (w), 1307 (w), 1216 (w), 1181 (w), 1128 (bw), 1017 (w), 969 (s) cm–1; 1H-
NMR (C6D6) δ 5.24 (1 H, dt, J = 15.2, 6.6 Hz), 5.05 (1 H, dd, J = 15.2, 8.4 Hz), 2.26 (1 H, app. d, J =
13.4 Hz), 1.92 (2 H, m), 1.86 (1 H, td, J = 13.6, 6.0 Hz), 1.77 (1 H, m), 1.73 (1 H, m), 1.56 (1 H, m),
1.48 (1 H, app. d, J = 13.0 Hz), 1.32 (1 H, m), 1.26 (4 H, m), 1.17 (1 H, m), 1.11 (3 H, d, J = 6.0 Hz),

Molecules 2007, 12
244
0.86 (3H, t, J = 7.2 Hz) ppm; 13C-NMR (C6D6) δ 209.5 (C=O), 133.4 (=CH), 130.9 (=CH), 50.4 (CH),
49.4 (CH), 41.5 (CH2), 32.9 (CH2), 32.3 (CH2), 31.1 (CH2), 26.0 (CH2), 21.6 (CH2), 14.1 (CH3), 13.0
(CH3) ppm; MS m/z (%) 194 (M+, 9), 137 (4), 123 (30), 110 (19), 96 (4), 81 (45), 79 (32), 67 (100), 47
(67).
rt
4b: Rf (isooctane/EtOAc, 8:2) 0.44; [α]D –13.1 (c 1.0, CHCl3); IR ν 2957 (s), 2930 (vs), 2872 (s),
1713 (vs), 1448 (m), 1377 (vw), 1312 (vw), 1222 (w), 1141 (w), 1078 (w), 995 (w), 968 (m) cm–1; 1H-
NMR (C6D6) δ 5.32 (1 H, dtd, J = 15.3, 6.8, 1.1 Hz), 5.20 (1 H, ddd, J = 15.3, 8.8, 0.9 Hz), 2.36 (1 H,
m), 2.20 (2 H, m), 1.87 (3 H, m), 1.65 (1 H, m), 1.44 (3 H, m), 1.22 (4 H, m), 0.97 (3 H, dd, J = 6.8,
13
1.3 Hz), 0.83 (3 H, t, J = 7.2 Hz) ppm; C-NMR (C6D6) δ 210.6 (C=O), 133.1 (=CH), 129.0 (=CH),
48.5 (CH), 47.0 (CH), 41.0 (CH2), 32.6 (CH2), 32.0 (CH2), 31.1 (CH2), 23.5 (CH2), 22.5 (CH2), 14.1
(CH3), 12.9 (CH3) ppm; MS m/z (%) 194 (M+, 8), 179 (2), 149 (5), 138 (3), 123 (34), 110 (22), 95
(14), 81 (57), 67 (67), 55 (49), 49 (100), 41 (93).
Acknowledgements
F. V. thanks the IWT for a scholarship.
References and Notes
1. (a) Proceedings of the 12th Workshop on Vitamin D; Bouillon, R., Norman, A. W., Pasqualini, J.
R., Eds.; J. Steroid Biochem. Mol. Biol. 2004, 89–90, 1–633, and the prior 11 volumes in this
series; (b) Feldman, D., Glorieux, F. H., Pike, J. W., Eds.; Vitamin D; Academic Press: San Diego,
1997.
2. Gabriëls. S.; Van Haver, D.; Vandewalle, M.; De Clercq, P.; Verstuyf, A.; Bouillon, R. Chem.
Eur. J. 2001, 7, 520–532.
3. Oi, S.; Sato, T.; Inoue, Y. Tetrahedron Lett. 2004, 45, 5051–5055.
4. Kakuuchi, A.; Taguchi, T.; Hanzawa, Y. Tetrahedron 2004, 60, 1293–1299.
5. Nicolaou, K. C.; Tang, W.; Dagneau, P.; Faraoni, R. Angew. Chem. Int. Ed. 2005, 44, 3874–3879.
6. Under the same conditions the introduction of the hexenyl side chain on 2-methyl-2-
cyclohexenone was not successful.
7. Schwartz, J.; Hayasi, Y. Tetrahedron Lett. 1980, 21, 1497–1500.
8. Loots, M. J.; Schwartz, J. Tetrahedron Lett. 1978, 4381–4382.
9. The ee was determined by HPLC based on the racemate using a chiral stationary phase column
(Daicel CHIRALPAK® AD-H, eluent: n-hexane/EtOH, 95:5).
10. The ee of 4a and 4b was determined by HPLC based on the racemate using a chiral stationary
phase column (Daicel CHIRALPAK® AD-H, eluent: n-hexane/EtOH, 99:1); for 4a: 96.3% ee, for
4b: better than 91% ee.
Sample Availability: No samples available.
© 2007 by MDPI (http://www.mdpi.org). Reproduction is permitted for noncommercial purposes.
