KETALIZATION
OF
GLYCEROL
WITH
ACETONE
TO
O-HETEROCYCLIC COMPOUNDS OVER ZrO2-SiO2 SOLID ACID
CATALYSTS
Chunni Fan, Chenghua Xu,* Chuanqi Liu, Zunyu Huang, Jianying Liu, and
Zhixiang Ye
Air Environmental Modelling and Pollution Controlling Key Laboratory of
Sichuan Higher Education Institutes, Chengdu University of Information
Technology, Chengdu 610225, China; Email: xch@cuit.edu.cn
Abstract – The solid acid catalysts ZrO2-SiO2 mixed oxides were prepared by
sol-gel, characterized by X-ray diffraction, NH3-temperature programmed
desorption, fourier transform infrared spectroscopy, and applied in the glycerol
catalytic ketalization with acetone to O-heterocyclic compounds in the present
work. Simultaneously, the effects of the catalysts composition, calcination
temperature and ketalization parameters such as reaction time, acetone/glycerol,
catalyst amount and reaction temperature on the ketalization were also
investigated in detail. The results showed that the main product for the glycerol
ketalization with acetone was solketal with a 5-membered ring along with a small
amount of 2,2-dimethyl-1,3-dioxan-5-ol with a 6-membered ring. ZrO2-SiO2 with
o
a Zr/Si molar ratio of 0.5 calcined at 500 C exhibited the best catalytic property
in ketalization, gave 90.91% of glycerol conversion and 89.69% of solketal
selectivity under the optimum conditions. It was also found that glycerol catalytic
ketalization with acetone to solketal was mainly governed by kinetics.
Biodiesel as a renewable fuel has been paid more and more attentions recently and successfully
implemented in many countries. However, during the present biodiesel production from the
transesterification of vegetable oils and animal fats with methanol, glycerol as a by-product will be
produced.1 Therefore, the reasonable utilization is very important for the sustainable development of
biodiesel industry. As reported, glycerol can be catalytically converted to propanediols2,3 and hydrogen or
syngas4,5 over noble metal catalysts through hydrogenolysis and reforming, respectively. Additionally,

2978
HETEROCYCLES, Vol. 85, No. 12, 2012
two adjacent hydroxyl groups in glycerol molecular structure are reported to function with ethanediamine
to form value-added chemicals pyrazinyl compounds with a N-heteroatom ring.6,7
Moreover, it has also been discovered that glycerol can be used in the synthesis of ketals with an
O-heteroatomic ring through ketalization with acetone. The obtained product such as solketal
((2,2-dimethyl-1,3-dioxolan-4-yl)methanol) can serve as a high-octane component of gasolines, reduce
the freezing point of diesel fuel and improve their lubricating properties.8,9 As well known, the used
catalysts in the conventional ketalization are inorganic proton acids such as H2SO4, H3PO4 or HCl.
However, they can lead to the production of an amount of by-products along with serious erosion for
devices and environmental pollution. Therefore, the solid acidic catalysts, such as cation-exchanged
resins,10,11 heteropolyacids (HPAs),12 zeolites13,14 and Ti-exchanged montmorillonite14 have been attracted
more and more interests. In addition, some Zr-containing mixed oxides such as WOx/ZrO2, MoOx/ZrO2
2-
and SO4 /ZrO2, have also been applied in glycerol catalytic ketalization with acetone (see Scheme 1),15
however their catalytic life have not been reported. As reported, TiO2-SiO2 and ZrO2-SiO2 mixed oxides
can provide Lewis and Brønsted sites simultaneously.16-19 Our previous work20 investigated the acidity
and catalytic property of TiO2-SiO2 mixed oxides in glycerol ketalization with acetone. It indicated that
TiO2-SiO2 gave rise to a high yield of solketal (about 90%) with a 5-membered ring containing
O-heteroatom.
O
OH
O
O
O
HO
O
Catal.
+
OH
+ H2O
+
OH
OH
Scheme 1. Ketalization of glycerol with acetone
In the present work, another kind of solid acid catalysts ZrO2-SiO2 mixed oxides for glycerol catalytic
ketalization with acetone to ketals with O-heteroatomic ring are synthesized by sol-gel method,
characterized by X-ray diffraction (XRD), NH3-temperature programmed desorption (NH3-TPD), fourier
transform infrared spectroscopy (FT-IR). Moreover, the effect of ZrO2-SiO2 composition, catalysts
calcination temperature and ketalization parameters such as reaction time, acetone/glycerol, catalyst
amount and reaction temperature on the glycerol ketalization, are further investigated in detail.
CATALYST COMPOSITION
Powder XRD results of ZS samples (Figure 1) indicate that all the mixed oxides show no obvious
diffraction peaks in the 2θ range from 15o to 30o, it shows that SiO2 species in samples are amorphous.15
However, there are some strong characteristic peaks tetragonal ZrO2 (PDF No. 49-1644) of at 2θ= 30.2o,

HETEROCYCLES, Vol. 85, No. 12, 2012
2979
35.4o, 50.6o, 60.1o and 74.5o, respectively.16,18 Moreover, the intensities of these characteristic peaks
strengthen with increasing Zr amount in ZS samples. It indicates that zirconia species in samples mainly
exist as tetragonal phase and there is no evidence of the zircon (ZrSiO4) formation, which is similar to the
results reported elsewhere.16,17
ZS-2
ZS-1
ZS-0.5
ZS-0.3
10
20
30
40
50
60
70
80
2 (o)
Figure 1. XRD patterns of ZS-X samples calcined at 500 oC for 4 h
ZS-2
ZS-1
ZS-0.5
ZS-0.1
SiO2
4000
3000 2400
2000
1600
1200
800
400
Wavenumber (cm-1)
Figure 2. FT-IR spectra of compressed KBr pellets of ZS-X samples calcined at 500 oC for 4 h
FT-IR spectra of compressed KBr pellets containing 1 wt% ZS samples calcined at 500 oC for 4 h (Figure
2) show that all catalysts give rise to two strong adsorption peaks at about 3500 cm-1 and 1636 cm-1,
respectively. They are generally assigned to the stretching and bending vibration of H-O-H bonds of
water molecules adsorbed on the samples.21 Moreover, two peaks are reduced with an increasing Zr/Si
molar ratio in ZS samples, indicating that their hydrophilicity is also decreased. From Figure 2, it can be
also found that pure SiO2 exhibits a broad band at 1097 cm-1 with a shoulder at about 1220 cm-1 which is
due to the Si-O-Si asymmetric stretching vibration, and simultaneously gives other two peaks assigned to

2980
HETEROCYCLES, Vol. 85, No. 12, 2012
the Si-OH stretching of terminal silanols and the ring structure of Si-O-Si bridges at 960 cm-1 and 800
cm-1,16,22 respectively. Moreover, these peaks are also reduced with an increase of Zr/Si ratio. These
results indicate that the presence of ZrO2 leads to the formation Si-O-Zr linkages in replacement of
Si-O-Si bonds, and Zr species can also interact with the terminal Si-OH groups to form Si-O-Zr linkages
in ZS samples.
From NH3-TPD results of ZS samples (Figure 3), it is not difficult to discover that NH3-adsorption ability
of ZS catalysts increases with the increasing ZrO2 content and reaches the maximum when Zr/Si molar
ratio = 0.5. Moreover, pure SiO2 only exhibits a weak NH3-desorption peak, which is due to only the
presence of terminal Si-OH groups only providing some weak Brønsted acidic sites.17 With the increase
of ZiO2 content, the formation of more Zr-O-Si linkages in ZS-X samples will give rise to the formation
of new Lewis acidic sites, and activate the ionization of terminal Si-OH groups to increase the strength of
Brønsted acidic sites due to the difference of the polarity between Si-O and Zr-O bonds. However, the
presence of too much ZrO2 species will consume the terminal Si-OH groups during the formation of
Zr-O-Si linkages tested by the above FT-IR results, thus the amount of total acidic sites will be decreased
in some extent.
300
(b)
(a)
100 mV
250
200
150
100
50
ZS-2
ZS-1
ZS-0.5
ZS-0.33
ZS-0.1
SiO2
0
0.0
0.5
1.0
1.5
2.0
0
100 200 300 400 500 600 700 800
Temperature (oC)
Zr/Si molar ratio
Figure 3. NH3-TPD curves (a) and amount of acidic sites (b) of ZS-X samples calcined at 500 oC for 4 h
Figure 4 exhibits the catalytic property of ZS-X mixed oxide catalysts with a different Zr/Si moral ratios
in the glycerol ketalization with acetone under the conditions of catalyst amount 2.2 g per 100 g glycerol,
acetone/glycerol molar ratio 4 and reaction at 70 oC for 3 h. It can be observed that pure SiO2 as catalyst
gives a poor glycerol conversion, the glycerol conversion and solketal selectivity over ZS-X catalysts are
found to increase with the increasing ZrO2 amount to a maximum of 90.2% when Zr/Si molar ratio = 0.5,
and then decrease in some extent with the further increasing Zr/Si molar ratio. This trend is completely
coincident with the relationship between the amount of total acidic sites and ZrO2 content in ZS-X

HETEROCYCLES, Vol. 85, No. 12, 2012
2981
catalysts (compare Figure 3(b) and Figure 4). These results indicate that the glycerol ketalization with
acetone mainly occurs over the Lewis and Brønsted acidic sites provided by Si-O-Zr linkages or terminal
Si-OH groups, respectively. Meanwhile, the selectivity towards solketal is found to be higher than that of
2,2-dimethyl-1,3-dioxan-5-ol (5-ol). The similar results have also been obtained over the other solid acid
catalysts reported in previous studies.12-15
90
80
70
60
glycerol conversion
solketal selectivity
5-ol selectivity
40
50
30
20
10
0
0.0
0.5
1.0
1.5
2.0
Zr/Si molar ratio
Figure 4. Catalytic properties of ZS-X samples with different Zr/Si molar ratio in the ketalization of
glycerol with acetone
CALCINATION TEMPERATURE
(a)
(b)
300
250
200
150
100
50
300 oC
400 oC
500 oC
600 oC
700 oC
300 350 400 450 500 550 600 650 700
Calcination temperature (oC)
0
100
200
300
400
500
600
Temperature (oC)
Figure 5. NH3-TPD curves (a) and amount of total acidic sites (b) of ZS-0.5 catalysts calcined at a
different temperature
From the above results, it is found that the ZS-0.5 catalyst with a Zr/Si ratio of 0.5 provides the most
amount of total acidic sites and also exhibits the highest catalytic activity in glycerol ketalization with
acetone. The present work also investigates the effect of calcination temperature on physicochemical

2982
HETEROCYCLES, Vol. 85, No. 12, 2012
property and catalytic activity of ZS-0.5 catalysts. From Figure 5, it can be observed that too low or too
high calcination temperature can lead to the formation of less total acidic sites over the surface of ZS-0.5
catalyst. It is perhaps because that the low temperature is disadvantageous to the formation of Zr-O-Si
linkages, however, the too high calcination temperature can lead to the destruction of Zr-O-Si linkages.
They will result in the decrease on the total acidic sites. From the XRD results (Figure 6), it can be found
that the intensities of peaks characteristic of tetragonal zirconia at 2θ= 30.2o, 35.4o, 50.6o and 60.1o,
o
increase when ZS-0.5 catalyst is calcined at a low temperature (400 C) and too high temperature (>600
oC). It shows that the formation of Zr-O-Si linkages which can provides more acidic sites, mainly from
the interaction between amorphous SiO2 species and tetragonal zirconia phase.
700 oC
600 oC
500 oC
400 oC
300 oC
10
20
30
40
50
60
70
2/(o)
Figure 6. XRD patterns of ZS-0.5 catalysts calcined at the different temperature
90
80
70
60
glycerol conversion
solketal selectivity
50
5-ol selectivity
40
30
20
10
300
400
500
600
700
Calcination temperature (oC)
Figure 7. Effect of calcination temperature on catalytic properties of ZS-0.5 in glycerol ketalization with
acetone. Reaction conditions are same as those mentioned above

HETEROCYCLES, Vol. 85, No. 12, 2012
2983
Figure 7 shows the catalytic results of glycerol ketalization with acetone over ZS-0.5 catalysts calcined at
the different temperature. It can be clearly observed that both glycerol conversion and solketal selectivity
first increase and then decrease with the increasing calcination temperature, while the selectivity towards
5-ol with a 6-membered ring exhibits a reverse trend. It further proves that too low or high calcination
temperature will influence the formation of Zr-O-Si linkages related with the acidic sites of catalysts.
More acidic sites and strong acidity are helpful to the glycerol ketalization with acetone and the formation
of 5-membered ring ketal (solketal).12,13
KETALIZATION PARAMETERS
90
80
70
60
(a)
(b)
90
80
70
glycerol conversion
solketal selectivity
5-ol selectivity
glycerol conversion
solketal selectivity
5-ol selectivity
20
15
10
5
20
15
10
20
(c)
40 60
80 100 120 140 160 180
2
3
4
5
6
Molar ratio of acetone to glycerol
Reaction time (min)
95
90
85
80
75
(d)
90
85
80
glycerol conversion
solketal selectivity
5-ol selectivity
glycerol conversion
solketal selectivity
5-ol selectivity
20
15
10
5
15
10
1.0
1.5
2.0
2.5
3.0
3.5
40
50
60
70
80
90
Reaction temperature (oC)
Catalyst amount (g/100g glycerol)
Figure 8. Effect of reaction parameters on the glycerol ketalization with acetone over ZS-0.5 catalyst
calcined at 500 oC for 3 h
Under the conditions of catalyst amount 2.2 g per 100 g glycerol, molar ratio of acetone to glycerol 4 and
reaction temperature 70 oC, the effect of reaction time on the glycerol ketalization with acetone over ZS-X
o
catalyst calcined at 500 C is investigated. From Figure 8(a), it is easily found that both glycerol
conversion and solketal selectivity increase with the increasing reaction time. It indicates that a long

2984
HETEROCYCLES, Vol. 85, No. 12, 2012
reaction time is helpful to glycerol conversion. In consideration of the increase rate of glycerol conversion
with reaction time, the proper reaction time is selected to be 180 min in the following work.
The effect of acetone/glycerol molar ratio on the glycerol ketalization is also investigated while the
catalyst amount, reaction temperature and time (180 min) are kept constant. From Figure 8(b), it can be
discovered that both glycerol conversion and solketal selectivity also increase with the increasing acetone
amount when molar ratio of acetone to glycerol being < 4, and exhibit no obvious increase with the
further increasing acetone amount (acetone/glycerol molar ratio >4). It is possibly because that the
presence of proper excess acetone can lead to the ample dispersion of glycerol in reaction mixture which
is advantageous to ketalization, and however too much acetone can result in the decrease on the catalyst
concentration which is disadvantageous to ketalization and the formation of product solketal with
5-membered ring.
As well-known, an important function of catalyst is to reduce the activation energy. According to
Arrhenius’ law, both adding catalyst and increasing reaction temperature can increase the reaction rate.
From Figure 8(c) and Figure 8(d), it can be found that the increase of reaction temperature and catalyst
amount promotes the conversion of glycerol and formation of solketal, and inhibit the formation of 5-ol.
It proves that the formation of solketal with 5-membered ring is the kinetics-governed reaction which
possesses a higher activation energy than the thermodynamics-governed one (5-ol formation).12,13
From the catalytic cycle results (Figure 1S in the Supplementary material) of ZS-0.5, it is shown that its
catalytic activity almost has no obvious decrease after 5 cycles under the conditions of catalyst amount
o
2.2 g per 100 g glycerol, molar ratio of acetone to glycerol 4, and reaction at 70 C for 180 min, the
glycerol conversion can keep a stable value of about 85%. It indicates that ZS-0.5 exhibits an excellent
catalytic stability in the glycerol ketalization with acetone.
EXPERIMENTAL
CATALYSTS PREPARATION
ZrO2-SiO2 mixed oxides were synthesized by sol-gel method as follows: 22.3 mL tetraethyl orthosilicate
(TEOS) as Si sources were added to 50 mL anhydrous EtOH. After the ample mixture, 50 mL distilled
water and 10 mL AcOH were successively titrated under the vigorous stirring to form homogeneous
solution A. Additionally, 10 mL AcOH were added into another aqueous solution containing a certain
amount of ZrOCl2 and stirred for 30 min to obtain solution B. After finishing, solution B was introduced
into solution A under stirring, thus a transparent sol solution would be obtained and subsequently aged for
o
24 h at room temperature to form gel. The gel was dried at 120 C for 12 h and calcined at a desired

HETEROCYCLES, Vol. 85, No. 12, 2012
2985
temperature for 4 h. The white ZrO2-SiO2 mixed oxides powder materials with different Zr contents
(denoted as ZS-X, wherein X was the Zr/Si molar ratio) would be prepared.
CATALYSTS CHARACTERIZATION
XRD patterns of catalysts were recorded on a DX-2700 powder diffractometer (Dandong, China)
operated at 30 kV and 20 mA, using Cu Kα radiation. FT-IR spectra were recorded by using compressed
KBr pellets containing 1 wt% of dry catalyst on a Shimadzu RF-IRPrestige-21 spectrophotometer in the
range of 400-4000 cm-1. The surface acidity of catalyst was tested by NH3-TPD on a TP-5080 adsorption
instrument (Tianjing, China): 0.2 g samples (0.38-0.83 mm) was loaded and pretreated with N2 at 400 oC
for 1 h to remove the adsorbed water. The adsorption of NH3 and the removal of physically-adsorbed NH3
on catalyst surface were carried out at room temperature. The desorption of chemically-adsorbed NH3
was carried out by heating from 30 to 850 oC (heating rate of 10 oC·min-1) in a 30 mL·min-1 of Ar gas, the
desorbed NH3 amount per gram catalyst, which was detected by the thermal conductivity detector (TCD),
represented the total acidity.
CATALYTIC TEST
Glycerol catalytic ketalization with acetone was carried out in a 50 mL glass reactor fitted with a
condenser, magnetic stirrer and thermostat. ZS-X mixed oxides as catalyst, glycerol and acetone were
added successively into the reactor. The reaction started when the temperature reached up to the desired
value. The catalytic test involved the effect of reaction temperature, acetone/glycerol molar ratio, catalyst
amount and reaction time on ketalization. The unconverted glycerol and formed products were analyzed
quantitatively by a GC-2000 gas chromatography (Chongqing, China) equipped a KB-Wax column (30 m
×0.32 mm ×0.5 um, Kromat Co., USA) and a flame ionization detector (FID). The qualitative analysis of
the goal products was carried out on an HP 6890/5973 GC/MS gas chromatography-mass spectroscopy.
The typical GC pattern of sample including acetone, glycerol, solketal and 5-ol was shown in Figure 2S
of Supporting Information.
ACKNOWLEDGEMENTS
We are grateful to the Youth Science and Technology Foundation of Sichuan Province in China (Grant
No. 2012JQ0047) for financial support of this project.
REFERENCES AND NOTES
1. R. S. Karinen and A. O. I. Krause, Appl. Catal. A, 2006, 306, 128.
2. E. P. Maris and R. J. Davis, J. Catal., 2007, 249, 328.

2986
HETEROCYCLES, Vol. 85, No. 12, 2012
3. T. Kurosaka, H. Maruyama, I. Naribayashi, and Y. Sasaki, Catal. Commun., 2008, 9, 1360.
4. A. J. Byrd, K. K. Pant, and R. B. Gupta, Fuel, 2008, 87, 2956.
5. D. A. Simonetti, E. L. Kunkes, and J. A. Dumesic, J. Catal., 2007, 247, 298.
6. R. Sarkari, C. Anjaneyulu, V. Krishna, R. Kishore, M. Sudhakar, and A. Venugopal, Catal.
Commun., 2011, 12, 1067.
7. C. Q. Liu, C. H. Xu, T. W. Xia, Y. Guo, and J. Y. Liu, Heteroat. Chem., 2012, 23, 377.
8. A. L. Maksimov, A. I. Nekhaev, D. N. Ramazanov, Y. A. Arinicheva, A. A. Dzyubenko, and S. N.
Khadzhiev, Pet. Chem., 2011, 51, 61.
9. L. N. Batista, R. A. S. S. Gil, and L. B. R. Lopes, J. Therm. Anal. Calorim., 2011, 106, 697.
10. J. Deutsch, A. Martin, and H. Lieske, J. Catal., 2007, 245, 428.
11. L. Roldan, R. Mallada, J. M. Fraile, J. A. Mayoral, and M. Menéndez, Asia-Pac. J. Chem. Eng., 2009,
4, 279.
12. P. Ferreira, I. M. Fonseca, A. M. Ramos, J. Vital, and J. E. Castanheiro, Appl. Catal. B, 2010, 98, 94.
13. C. X. A. Silva, V. L. C. Goncalves, and C. J. A. Mota, Green Chem., 2009, 11, 38.
14. T. Mitsudome, T. Matsuno, S. Sueoka, T. Mizugaki, K. Jitsukawa, and K. Kaneda, Heterocycles,
2012, 84, 371.
15. R. S. Reddy, P. Sudarsanam, B. Mallesham, G. Raju, and B. M. Reddy, J. Ind. Eng. Chem., 2011, 17,
377.
16. P. K. Doolin, S. Alerasool, D. J. Zalewski, and J. F. Hoffman, Catal. Lett., 1994, 25, 209.
17. Y. Zhang, L. Pan, C. G. Gao, and Y. X. Zhao, J. Sol-Gel Sci. Technol., 2011, 58, 572.
18. Y. Wang, J. H. Ma, D. Liang, M. M. Zhou, F. X. Li, and R. F. Li, J. Mater. Sci., 2009, 44, 6736.
19. S. W. Wang, X. X. Huang, and J. K. Guo, J. Mater. Sci., 1997, 32, 197.
20. C. N. Fan, C. H. Xu, C. Q. Liu, Z. Y. Huang, J. Y. Liu, and Z. X. Ye, React. Kinet. Mech. Catal.,
2012, 107, 189.
21. M. W. Jung, J. Sol-Gel Sci. Technol., 2000, 19, 563.
22. Z. Q. Zhan and H. G. Zeng, J. Non-Cryst. Solids, 1999, 243, 26.
