M. López-Viveros, et al.
CatalysisTodayxxx(xxxx)xxx–xxx
reactors, an important increase of the catalytic efficiency of the mem-
branes has been already achieved before by our group when using
membranes in forced flow-through configuration for the Suzuki-
Miyaura CeC cross-coupling reaction compared to batch configuration
under the same conditions [33,34]. Thus, we aim presenting here the
results obtained in hydrogenation reactions using polymeric catalytic
membranes, which contain immobilized PdNP, under a forced flow-
through configuration. Moreover, we report innovative results on the
hydrogenation of nitroarenes using a polymeric hollow-fiber contactor.
2. Materials and methods
2.1. Materials
Scheme 1. Experimental set-up for continuous flow hydrogenation reactions
Microfiltration PES flat sheet membranes MicroPES® were pur-
chased from Membrana-3 M (Wuppertal, Germany) with a nominal
pore size of 0.2 μm. Microfiltration MicroPES® hollow fibers were
purchased from Membrana-3 M (Wuppertal, Germany), nominal pore
using flat sheet membranes in flow-through configuration.
For PdNP characterization, grafted membrane samples were first
embedded in resin and then thin slices (80 nm) were cut with a mi-
crotome. Micrographs of PdNP were obtained by Transmission Electron
Microscopy (TEM, JEOL Jem 1400). For each membrane, at least 10
slices were analyzed. Size distribution of PdNP were determined using
size of 0.2 μm, inner diameter of 300
40 μm and wall thickness of
100
25 μm. All chemical reagents were obtained from Sigma-Aldrich
and used without further purification.
2.2. Methods
2.2.3. Catalytic experiments
2.2.1. Membrane surface modification
Surface of flat sheet PES membranes (12.4 cm2) was functionalized by
UV photo-grafting radical polymerization using a Heraeus TQ 150 lamp
with a quartz filter. Membranes were dipped into monomer solutions
containing 5 wt% of acrylic acid as monomer and 1.5 wt% of diethylene-
di-acrylate as crosslinker (0.1 mol crosslinker /mol of monomer) and then
irradiated for 3 min (total energy dose received 6.3 J cm−2).
2.2.3.1. Continuous flow hydrogenations using catalytic flat-sheet
membranes. Reactions were carried out in flow-through configuration
with the as-prepared catalytic flat sheet membranes. Solutions
containing the substrate were pre-saturated with H2 using a hollow-
fiber contactor. The Gas/Liquid hollow-fiber contactor was designed to
assure H2 saturation of solutions [39].
The experimental set-up developed to perform the hydrogenation
reactions in continuous mode is presented in Scheme 1.
Surface of hollow PES membranes was functionalized by UV photo-
grafting radical polymerization as previously described [35,36] using
two high power Mercury lamps, UVA-PRINT LE, Hoenle UV France,
with a line rate of 10 m min−1 and an intensity of the lamps of 110 %
(total energy dose received 21.3 J cm-2). Monomer solutions containing
20 wt% of acrylic acid as monomer and 0.85 wt% of N,N’-methylenebis
(acrylamide) as crosslinker (0.027 mol crosslinker /mol of monomer).
The change on the cross-linker was simply due to follow a previously
established protocol for hollow fibers. Although both cross-linkers have
different nature, the polymer gel grafted on the membrane presented
the same swelling behavior in water and ethanol (probably due to si-
milar short distances between C = C, for diethylene-diacrylate: the
C = C to C = C distance is 1.012 nm; for bisacrylamide, the C = C to
C = C distance is 0.859 nm, according to molview modelling).
netic stir bar, was placed on a hot-plate at 65 °C. The flow rate of
ethanol solution containing the substrate was controlled by a gear
pump (Scheme 1, (1)). The solution was sent into to a home-made
tion with H2 using a hydrogen generator (Schmidlin-FDBS). The home-
made hollow fiber contactor module contained 15 fibers, an effective
length of 0.3 m and 4.0 10−3 m of diameter. The H2 saturated solution
(Scheme 1, (2)) went into the filtration cell where it flowed through the
membrane. 25 ml of permeate were taken for further analyses after
attaining steady-state (established when passing 4 times the total dead
volume: reactor volume + connection pipes volume, ca. 4⨯85 mL).
The reaction time is expressed as the residence time
actant inside the membrane using the following equation:
of the re-
To evaluate the functionalization of the grafted membranes, ATR-
FTIR was performed using a Thermo-Nicolet Nexus 670 spectro-
photometer in the region of 400 to 4000 cm−1 and SEM images were
obtained with Tabletop Microscope Phenom XL after cryofracturation.
L
F
S
(1)
with L as the membrane thickness (110·10−4 cm), F the permeate
2.2.2. In-situ synthesis of palladium nanoparticles and their
characterization
flow rate (mL s-1) and S the membrane surface area (12.4 cm2). The
membrane porosity was taken as 0.8 [40].
The synthesis of PdNP was carried out based on the intermatrix
method [37]. Grafted membranes were immerged at room temperature
in a 0.02 M aqueous solution of [Pd(NH3)4]Cl2, H2O for 18 h. PdNP
were then formed by reduction of Pd(II) ions through immersion of the
membrane in a 0.1 M aqueous solution of NaBH4 for 1 h. Membranes
were thoroughly washed (30 ml of ethanol for 1 h each time) and
stocked in ethanol before use.
If only the grafted layer of thickness l, where the palladium nano-
particles are found, is taken into account for the calculation, the re-
sidence time is defined as:
l
F
*
S
(2)
Palladium content was determined by Inductively Coupled Plasma
Optical Emission Spectrometry analyses (ICP-OES, Ultima 2, Horoba
Jobin Yvon). The ICP-OES detection limit for palladium is 3 ppb.
Palladium loading is expressed as μg of Pd per cm²; for flat sheet
membranes, the mean value was obtained for at least 3 membrane
samples of 1 cm² of surface; for hollow fibers, the mean value was
obtained for at least 3 membrane samples of 2 cm length.
Permeates (Scheme 1, (3)) were analyzed by gas chromatography (GC)
(FID), coupled to a Perkin Elmer Clarus MS56 mass spectrometer (MS),
with a SGE BPX5 column composed by 5% of phenylmethylsiloxane and
by 1H NMR using a Bruker Avance-III 300 (300 MHz) spectrometer. De-
cane was used as internal standard. The palladium content in the filtered
solutions and purified product was determined by ICP-OES.
