Ultrasonic activation of the arylation reaction of styrene catalyzed by transition metals

Article abstract of DOI:10.3906/kim-1701-31

The arylation reaction of styrene was tested in the presence of different transition metal-based catalysts, mainly iron-based, given its low cost and its nonpolluting and nontoxic characteristics. The study of the effect of sonochemical activation on the evolution of the selectivity of the reaction is also proposed. Higher efficiency was observed for a very short period of time of just a few minutes. Furthermore, an improvement of the selectivity of the arylation of the external carbon of styrene was observed.

Full text of DOI:10.3906/kim-1701-31

Turk J Chem
Turkish Journal of Chemistry
(2017) 41: 587 – 600
¨
http://journals.tubitak.gov.tr/chem/
˙
c
⃝ TUBITAK
doi:10.3906/kim-1701-31
Research Article
Ultrasonic activation of the arylation reaction of styrene catalyzed by transition
metals
∗
¨
Dhiab ATOUI, Khemais SAID, Ridha BEN SALEM
Organic Chemistry Laboratory (LR17/ES08), Department of Chemistry, Sciences Faculty of Sfax,
University of Sfax, Sfax, Tunisia
Received: 12.01.2017
•
Accepted/Published Online: 22.03.2017
•
Final Version: 05.09.2017
Abstract:The arylation reaction of styrene was tested in the presence of different transition metal-based catalysts, mainly
iron-based, given its low cost and its nonpolluting and nontoxic characteristics. The study of the effect of sonochemical
activation on the evolution of the selectivity of the reaction is also proposed. Higher efficiency was observed for a very
short period of time of just a few minutes. Furthermore, an improvement of the selectivity of the arylation of the external
carbon of styrene was observed.
Key words: Stilbene, iron, ultrasound, arylation, selectivity
1. Introduction
In recent years, there has been a strong tendency to develop new methods to activate the C-H bond and the
application of these methods in the synthesis of target molecules such as natural products and pharmaceutical
compounds. Thus, new C-C bond formation reactions based on transition metal catalysis have been discovered.
These have offered new synthesis perspectives and have allowed researchers to access increasingly complex
molecules that were inaccessible through conventional methods. The Heck coupling reaction1,2 is one of the
most important methods used for C-C bond formation with transition metals as catalysts.3−10
Among the various transition metals used, palladium has proven to be the metal of choice for performing
C-C coupling reactions. However, the use of this type of palladium complex has a major disadvantage for this
method given the high cost of the complex and given that several scientific studies show that it has harmful
effects on health and the environment.11−13 For these reasons, the search for new more cost-effective and green
routes for the formation of C-C bonds has become a major problem for industrial and academic research teams.
In this regard, we have tested the arylation reaction of styrene in the presence of a new iron-based
catalyst, which has the advantage of being less expensive, nonpolluting, and nontoxic.14,15 The aim of this
work was to study the effect of the reaction parameters and the effect of ultrasonic activation on the evolution
and selectivity of the reaction by comparing the results obtained with those obtained through the conventional
(thermal) method.
2. Results and discussion
Different conditions were studied for the arylation reaction of styrene under thermal conditions (24 h at 100
◦ C) or under ultrasonic irradiation (20 min at 25 ◦ C), during which several products were detected (Scheme).
∗Correspondence: ridhabensalem@yahoo.fr
587

ATOUI et al./Turk J Chem
Scheme. The arylation reaction of styrene.
2.1. Thermal activation
2.1.1. Effect of the nature of the solvent
Table 1 summarizes the conversions and yields obtained in various solvents. From all the solvents tested, it
appears that an aprotic polar solvent such as DMF is the most suitable for carrying out the arylation of styrene
β -carbon. The yield reached in this case is 55% for the trans form and 17% for the cis form. The use of
n-hexane, chloroform, THF, acetic acid, and water instead of DMF makes it possible to improve the arylation
of styrene by forming tetraphenylethylene in yields reaching up to 91% when using THF. However, in a polar
protic medium, the results show lower reactivity with slightly lower yields of 89% in water, which decreases to
29% in acetic acid. This seems to be due to the secondary reactions that take place in a polar protic medium.16
However, the most plausible explanation seems to be the polarity of the environment.
Table 1. Influence of the nature of the solvent on the arylation reaction of styrene.
Conversion (%)a Yield (%)b
Product Solvent
Dipole moment (D)
5
-
3/4
57/18
5
-
3/4
55/17
1
2
3
4
5
6
DMF
n-Hexane
Chloroform 1.04
THF 1.75
Acetic acid 1.74
Water 1.85
3.82
0.00
> 99
95
> 99
31
-
-
-
-
-
88
85
91
29
89
-
-
-
-
-
98
Procedure A: FeCl3 .6H2 O (0.025 mmol), PPh3 (0.05 mmol), Na2 CO3 (3.125 mmol), iodobenzene (2.5 mmol), styrene
(2.25 mmol), solvent (3 mL), 100 ◦ C, 24 h. a The conversions were determined by HPLC on the basis of area percentage,
b isolated yield.
In the ground state, the two π electrons of an alkene are symmetrically located with regards to the two
carbon atoms and there is no charge excess or charge defect. The movement of an electron from the π orbital to
the π* orbital results in the destruction of the π bond in the excited state. The two electrons are then located in
the two 2p atomic orbitals of each carbon atom, which are now perpendicular. These orbitals then interact with
the nonbinding orbital of the oxygen in DMF, resulting in two interactions with three weakly bonding electrons:
the π* level moves down.17,18 This state with separated electrons is more stable, with stronger interactions,
and so the solvent is more polar.
In order to explain the formation of the different products obtained, we propose the following reaction
mechanism (Figure 1): the cycle begins with the reduction of FeIII by adding a phosphine as a reaction
medium,19 followed by an oxidative addition of the aryl halide to FeI , which gives rise to an organo-iron
product. A syn-insertion of styrene into this last complex (Ph-Fe-I) then results in the formation of a new
588

ATOUI et al./Turk J Chem
unstable C-C bond. This involves an internal rotation around this bond so that the β -hydrogen of the metal
center is in the syn-position relative to the iron and thus leads to a β -elimination, which forms the new
substituted alkene (stilbene) and the iron hydride. Finally, the presence of a base decomposes the iron hydride
into FeI and traps the HI acid produced.
Figure 1. Proposed catalytic mechanism of the arylation reaction of styrene.
2.1.2. Effect of the nature of the halogen
The effect of the nature of the halogen in the arylation reaction of styrene is shown in Table 2.
In light of the results shown in Table 2, the effect of the halogen nature on the evolution of the arylation
reaction of styrene is clearly seen. The analyses show that the use of iodobenzene generates the arylation of the
styrene external carbon producing both the trans and the cis forms with yields of 55% and 17%, respectively.
However, the use of bromobenzene, chlorobenzene, and 1-bromo-4-chlorobenzene involves the tri-arylation of
styrene with yields of 85%, 80%, and 90%, respectively. The analyses show that the use of iodobenzene generates
the arylation of the styrene external carbon, producing both the trans and the cis forms with yields of 55% and
17%, respectively. However, the use of bromobenzene, chlorobenzene, and 1-bromo-4-chlorobenzene involves
the tri-arylation of styrene with yields of 85%, 80%, and 90%, respectively. This result was confirmed by
Hajipour and Azizi,15 who showed that iodobenzene was the only reagent participating in the reaction and
bromobenzene was fully recovered after purification. On the other hand, 1-bromo-4-iodobenzene was converted
into methyl-4-bromocinnamate as the only product.
In order to interpret the results obtained, we propose a reaction mechanism illustrating the styrene
arylation reaction according to the nature of the halogen used (Figure 2). Thus, the regiochemistry of the final
product depends on the reaction mechanism.
589

ATOUI et al./Turk J Chem
Table 2. Effect of the halide on the yield of the coupling of styrene.
Conversion (%)a
Yield (%)b
Product Aryl halide
5
-
6
-
3/4
57 /18
5
-
6
-
3/4
55/17
1
7
8
9
C6H5-I
C6H5-Br
C6H5-Cl
Cl-C6H4-Br
> 99
> 99
-
-
-
-
-
85
80
-
-
-
90
-
-
-
-
100
Procedure A: FeCl3 .6H2 O (0.025 mmol), PPh3 (0.05 mmol), Na2 CO3 (3.125 mmol), aryl halide (2.5 mmol), styrene
(2.25 mmol), DMF (3 mL), 100 ◦ C, 24 h. a The conversions were determined by HPLC on the basis of area percentage,
b isolated yield.
• In the case of iodine, the main mechanism seems to involve passing through the neutral intermediate.
Indeed, the iron-halogen bond is a strong bond.
• In the case of Br or Cl, the iron-halogen bond is much more unstable and so a reaction proceeding through
the cationic intermediate is more frequent.
This result is confirmed by the work of Ludwig et al.,20 who showed the effect of the aryl halide on the
regioselectivity of the Heck reaction when passing from X = I, OAc to BF4 . In our case, the formation of TPE
can be explained by the formation of 1,1-diphenylethylene while the arylation of the styrene external carbon
leads to lower values of the steric hindrance and the electronic density.21
2.1.3. Effect of the nature of the ligand
The spectroscopic analyses show a difference in the nature of the adduct compound for each ligand used. Thus,
the use of P(p-Ph-Cl)3 results in the formation of two trans-stilbene and cis-stilbene isomers. However, the use
of PPh3 , P(p-Ph-CH3)3 , and P(p-Ph-OCH3)3 involves the formation of tetraphenylethylene.
Table 3 shows the conversions and yields obtained for each type of ligand used.
The results obtained show a better reactivity for all the reactions studied but different regioselectivities.
The internal arylation of styrene has already been explained above with the use of bromobenzene, which favors
a cationic mechanism.20
The use of P(p-Ph-Cl)3 results in arylation at the styrene β -position. This result can be explained at
590

ATOUI et al./Turk J Chem
Figure 2. Neutral and cationic mechanisms of the arylation reaction of styrene according to the nature of the aryl
halide.
Table 3. Influence of the nature of the ligand of the arylation reaction of styrene.
Conversion (%)a Yield (%)b
Product Ligand
5
3/4
-
-
99/1
-
5
3/4
-
-
96/1
-
7
PPh3
P(p-Ph-CH3)3
P(p-Ph-Cl)3
> 99
> 99
-
85
96
-
10
11
12
P(p-Ph-OCH3)3 100
98
Procedure A: FeCl3 .6H2 O (0.025 mmol), ligand (0.05 mmol), Na2 CO3 (3.125 mmol), (2.5 mmol) bromobenzene,
styrene (2.25 mmol), DMF (3 mL), 100 ◦ C, 24 h. a The conversions were determined by HPLC on the basis of area
percentage, b isolated yield.
591

ATOUI et al./Turk J Chem
first by the presence of chlorine in the sphere of the complex formed after the oxidative addition step. Thus,
it can modify the initial cationic nature and the neutral route will be favored. The electronic environment of
the metal is easily adjusted by the appropriate choice of ligands, which influences both the reactivity and the
selectivity of the reactions. The most plausible explanation seems to be due to the Tolman cone angle, which
affects the reactivity of the ligands in the Heck coupling reaction.22
From the results collected in Table 4, it can be concluded that the yield depends on both the steric and
the electrical effects of the ligand used.23 Some studies state that the more cluttered the ligand is, the greater
the metal–phosphorus distance will be, and therefore the more unstable the bond.24 This was explained by the
results obtained by Cooley et al.,25 where they showed that the fastest reductive elimination was observed for
the ligands with the largest cone angles.
Table 4. Variation of the steric and electrical characteristics of the different ligands.
Yield (%)b
Tolman cone
Product Ligand
Frequencies
angle (◦)
145
145
5
3/4
-
-
96/1
-
7
PPh3
2068.9
2066.7
2072.8
2066.1
95
96
-
10
11
12
P(p-Ph-CH3)3
P(p-Ph-Cl)3
176.6
P(p-Ph-OCH3)3 143.6
98
bIsolated yield.
Similarly, Fu et al. showed that the combination of hindered and electron-rich phosphines with palladium
sources generates a highly active species for coupling reactions.26−28
It can therefore be concluded from the results shown in Table 4 that the arylation of the external carbon
in styrene, in the case where P (p-Ph-Cl)3 is used, is due to the electronic and steric effects of this type of
ligand.
2.1.4. Effect of the nature of the base
The effect of the nature of the base in the arylation reaction of styrene is shown in Table 5.
Table 5. Influence of the nature of the base on the arylation reaction of styrene.
Conversion (%)a Yield (%)b
Product Base
5
5
7
Na2CO3
NEt3
NBu3
NaOH
K2CO3
85
82
91
83
84
13
14
15
16
> 99
Procedure A: FeCl3 .6H2 O (0.025 mmol), PPh3 (0.05 mmol), base (3.125 mmol), bromobenzene (2.5 mmol), styrene
(2.25 mmol), DMF (3 mL), 100 ◦ C, 24 h. a The conversions were determined by HPLC on the basis of area percentage,
b isolated yield.
These results show total site-selectivity of the arylation of styrene in the α-position due to the use of
bromobenzene.20 However, these bases did not kinetically affect the reactivity relative to the cationic complexes.
Thus, the conversions obtained for the different bases used are almost identical. These results allow us to state
that the base has no effect on the styrene insertion step.
592

ATOUI et al./Turk J Chem
2.1.5. Effect of the nature of the catalyst
The conversions and yields obtained are shown in Table 6.
Table 6. Influence of the nature of the catalyst on the arylation of styrene.
Conversion (%)a Yield (%)b
Product Catalyst
5
3/4
-
-
-
-
2/<1
59/41
99/<1
5
3/4
7
FeCl3.6H2O > 99
85
83
74
90
-
-
-
-
17
18
19
20
21
22
Ag
CuO
ZrO2
Ni(OAc)2
Pd(OAc)2
Fe(OAc)2
> 99
77
> 99
98
-
-
79 2/<1
-
-
55/35
94/<1
Procedure A: Catalyst (0.025 mmol), PPh3 (0.05 mmol), Na2 CO3 (3.125 mmol), bromobenzene (2.5 mmol), styrene
(2.25 mmol), DMF (3 mL), 100 ◦ C, 24 h. a The conversion was determined by HPLC on the basis of area percentage,
b isolated yield.
These results show that only palladium acetate, nickel acetate, and iron acetate lead to the formation of
stilbene while the others involve the tri-arylation of styrene.
They show the efficiency of the catalytic system in the arylation reactions studied. However, the selective
arylation at the styrene α or β positions varies when the catalyst system is changed.
These results show that the type of transition metal is not responsible for the selectivity between the
external and internal position of styrene but, in fact, is responsible for the type of ligand coordinated with
it. Thus, the use of two forms of iron (FeCl3 .6H2 O and Fe(OAc)2) yields a change in the arylation position.
Furthermore, the use of the acetate ligand (OAc) coordinated with different transition metals (Ni, Pd, Fe)
always results in the external arylation of styrene. This was explained by Amatore et al.,29 who found better
reactivity of the PhPd(OAc)(PPh3)2 species compared to PhPdI(PPh3)2 . They deduced that the acetate
ligand helped in the release of a coordination site, which favors the insertion of the alkene into the palladium.
2.2. Ultrasonic activation
2.2.1. Effect of the nature of the ligand
The influence of the sonochemical activation on the yields of the coupling reactions studied is shown in the
results listed in Table 7. According to this table, it appears that activation by an ultrasonic probe greatly
favors the reactions studied.
Comparing these yields with those obtained by thermal activation (Table 8) shows that the sonochemical
activation improves the arylation of the styrene β carbon atom. Thus, the results obtained show that the
arylation, in an irradiated medium, becomes more selective on styrene’s external carbon.
The ultrasound effects observed for the styrene arylation reaction are due to the cavitation phenomenon.30
Thus, when the ultrasound propagates through the reaction medium, the molecule oscillations form compression
and decompression zones due to the creation of acoustic pressure. These pressure variations involve the
movement of the molecules, thus causing the molecular groups to move closer and further apart (Figure 3).
• During the rarefaction cycle, the distance increases.
• During the compression cycle, the distance decreases.
593

ATOUI et al./Turk J Chem
Table 7. Influence of ultrasonic activation on ligand reactivity.
Conversion (%)a Yield (%)b
Product Ligand
5
3/4
5
3/4
46 52/1
9 30/6
23
24
25
26
PPh3
P(p-Ph-CH3)3
P(p-Ph-Cl)3
60 12/1
10 32/7
15 13/18
13 13/16
62 8/14
P(p-Ph-OCH3)3 64 9/16
Procedure B: FeCl3 .6H2 O (0.025 mmol), ligand (0.05 mmol), Na2 CO3 (3.125 mmol), bromobenzene (2.5 mmol),
styrene (2.25 mmol), DMF (3 mL), 25 ◦ C, 20 min. a The conversions were determined by HPLC on the basis of area
percentage, b isolated yield.
Table 8. Effect of the ligand on the reactivity of the arylation reaction of styrene under thermal activation and ultrasonic
irradiation.
Yield (%)*b Yield (%)**b
Ligand
5
3/4
-
-
96/1
-
5
3/4
46 52/1
9 30/6
PPh3
P(p-Ph-CH3)3
P(p-Ph-Cl)3
85
96
-
13 13/16
62 8/14
P(p-Ph-OCH3)3 98
*Procedure A: FeCl3 .6H2 O (0.025 mmol), ligand (0.05 mmol), Na2 CO3 (3.125 mmol), bromobenzene (2.5 mmol),
b
styrene (2.25 mmol), DMF (3 mL), 100 ◦ C, 24 h. Isolated yield.
**Procedure B: FeCl3 .6H2 O (0.025 mmol), ligand (0.05 mmol), Na2 CO3 (3.125 mmol), bromobenzene (2.5 mmol),
b
styrene (2.25 mmol), DMF (3 mL), 25 ◦ C, 20 min. Isolated yield.
Figure 3. Propagation of the ultrasonic wave in the reaction medium.
Each liquid medium has a critical molar distance. Above this characteristic threshold, the cohesive
forces in the liquid are overcome and cavitation microbubbles, containing the liquid’s vapor and dissolved gases,
594

ATOUI et al./Turk J Chem
appear. With the growth of these bubbles, very high temperatures and pressures are produced inside them to
the point where they become unstable. As a result, their collapse produces enormous amounts of energy within
the reaction medium (Figure 4). This favors the formation of high yields of stilbene for a very short time.31
Figure 4. Creation of bubbles followed by their implosion.
2.2.2. Effect of the nature of the catalyst
Table 9 shows the conversions and yields for the styrene arylation reaction activated by sonochemical irradiation
when applying different transition metal-based complexes.
Table 9. Influence of the catalytic system on the arylation of styrene under ultrasonic irradiation.
Conversion (%)a Yield (%)b
Product Catalyst
5
3/4
5 3/4
46 52/1
23
27
28
29
30
31
FeCl3.6H2O 46 12/1
Ag
CuO
ZrO2
Ni(OAc)2
Pd(OAc)2
8
6
5
77/10
89/3
91/2
7
5
4
77/10
88/2
89/2
48 25/7
42 17/6
40 25/7
40 16/6
Procedure B: Catalyst (0.025 mmol), PPh3 (0.05 mmol), Na2 CO3 (3.125 mmol), bromobenzene (2.5 mmol), styrene
(2.25 mmol), DMF (3 mL), 25 ◦ C, 20 min. a The conversions were determined by HPLC on the basis of area percentage,
b isolated yield.
The results shown in this table depict excellent selectivity of external styrene arylation while using
FeCl3 .6H2 O, Ag, CuO, and ZrO2 . The yields reached were 52%, 77%, 88%, and 89%, respectively. These are
better yields than those obtained when using nickel or palladium, the metal of choice for the Heck reaction.
In order to clearly visualize the effect of sonochemical activation on the reactivity of the catalytic system,
Table 10 lists the yields resulting from the two activation methods used.
It follows that the sp2 hybridized carbon selective arylation is improved in the irradiated medium.
Furthermore, certain catalytic systems that are less active during the thermal activation are more efficient in
producing stilbene and, more specifically, the trans form. These results are confirmed by those obtained by
Srinivosans et al.,32 who observed that applying sonochemical irradiation to the arylation reaction of certain
activated alkenes leads to both significant yields over a very short period of time and excellent selectivity for
the E-form.
Similarly, Samant et al.33 showed that Pd/C, when using ultrasound, can be used as a recyclable catalyst
for this type of coupling reaction. As a result, it can reenter a new reaction cycle.
595

ATOUI et al./Turk J Chem
Table 10. Effect of the catalyst on the reactivity of the arylation reaction of styrene under thermal activation and
ultrasonic irradiation.
Yield (%)*b Yield (%)**b
Catalyst
5
3/4
5 3/4
46 52/1
FeCl3.6H2O 85
-
-
-
-
Ag
CuO
ZrO2
Ni(OAc)2
Pd(OAc)2
83
74
90
7
5
4
77/10
88/2
89/2
79 2/<1
55/35
40 25/7
40 16/6
-
*Procedure A: Catalyst (0.025 mmol), PPh3 (0.05 mmol), Na2 CO3 (3.125 mmol), bromobenzene (2.5 mmol), styrene
b
(2.25 mmol), DMF (3 mL), 100 ◦ C, 24 h. Isolated yield.
**Procedure B: Catalyst (0.025 mmol), PPh3 (0.05 mmol), Na2 CO3 (3.125 mmol), bromobenzene (2.5 mmol), styrene
b
(2.25 mmol), DMF (3 mL), 25 ◦ C, 20 min. Isolated yield.
2.3. Conclusions
The study of the sonochemical activation of the styrene arylation reaction has shown excellent efficiency for
a very short period of just a few minutes. In addition, it has also shown an improvement of some catalytic
systems that are less active in the conventional mode. Moreover, it has been shown that the coupling reactivity
and selectivity are affected by the experimental conditions. Indeed, in an aprotic polar medium, the arylation
becomes more selective on styrene’s external carbon, and the more important the M-X bond is, the more
selective the arylation becomes on the β -carbon of styrene. It has also been found that the evolution and
selectivity of the reaction is affected by both electronic and steric effects of the ligand.
3. Experimental
3.1. General procedure
3.1.1. Classical procedure
Procedure A: 0.025 mmol of catalyst, 0.05 mmol of ligand, and 3.125 mmol of base were introduced into a
steel tube. Next, 2.5 mmol of halogenobenzene was added together with 2.25 mmol of styrene, and then 3 mL
of the solvent was finally added. The steel reactor was placed in a thermostatic oil bath maintained at 100
◦ C for 24 h. After the reaction, the mixture was cooled and the organic phase was extracted three times with
n-hexane or cyclohexane and then with the saturated NaCl solution. The adduct obtained was then dried using
Na2 SO4 , filtered, and placed in a 25-mL ground flask. The solvent was evaporated using a rotary evaporator
(Rotavapor). The final adduct was subjected to a TLC thin-layer chromatography test using n-hexane as an
eluent and treated with silica gel column chromatography with the same eluent: n-hexane. Finally, the products
obtained were analyzed using the usual analysis methods.
3.1.2. Ultrasound procedure
Procedure B: The experimental procedure was the same as that of A, but the mixture obtained was subjected
to ultrasonic irradiation for 20 min at room temperature (25 ◦ C). At the end of the reaction the products
obtained were analyzed using the usual analysis methods.
596

ATOUI et al./Turk J Chem
3.2. Characterization
Preparative column chromatography was carried out on 60 A silica gel with a particle size of 5–14 µm. The
elution conditions are those described in the procedure.
The wavelengths used during the chromatographic analyses were measured with a HELIOS Omega UV-
Visible apparatus, where the products were eluted in dichloromethane.
Chromatographic analyses were performed on a PerkinElmer HPLC equipped with a 200 series pump,
to which a 20-µL automatic loop injector and a UV-Vis detector were connected. The wavelength used was
235 nm. The column used was a C18-type column. The mobile phase used was a mixture of 80% acetone and
20% water with an initial 0.5 mL/min for 30 min. All analyses were processed using TotalChrom Navigator
software.
Melting points were measured on a K¨ofler Bench after calibration with pure compounds, which had
melting points similar to the expected values.
FT-IR spectra were recorded using a PerkinElmer Spectrum 100 apparatus. The absorption frequencies
(ν) are expressed in cm−1
.
The 1 H NMR and 13 C NMR spectra of the synthesized compounds were recorded on a Bruker AC 400
apparatus with Fourier transform and a nominal frequency of 100 MHz. Chemical shifts are expressed in parts
per million (ppm) relative to tetramethylsilane (TMS), used as an internal reference. The spectra were recorded
in deuterated chloroform CDCl3 .
Irradiation was guaranteed by using an ultrasonic probe (Sonopuls HD 3200 model, 20 kHz, 200 W) with
an ultrasonic generator (Sonics VC 505, 300 W). The ultrasonic probe (Φ = 3 mm) was immersed directly
in the reactor (JENAer GLAS 25-mL beaker). The sonication was carried out at a low frequency of 20 kHz
(amplitude of 45%) at room temperature for 20 min with a 3-s pulsation.
3.2.1. (E)-Stilbene
Mp: 123–124 ◦ C; IR (KBr, cm−1)ν = 3020 (CHaro), 1750 (CHethyl), 1597 (C=Cethyl), 1490 (C=Caro); 1 H
NMR (400 MHz, CDCl3)δ (ppm) = 7.51 (d, 4H, J = 6.4 Hz), 7.35 (t, 4H, J = 6.4 Hz), 7.25–7.29 (m, 2H),
7.09–7.13 (m, 2H); 13 C NMR (100 MHz, CDCl3)δ (ppm) = 137.4, 128.8, 127.7, 126.6.
Figure 5. HSQC (CDCl3 ) spectrum of E-stilbene.
597

ATOUI et al./Turk J Chem
Figure 6. Comparison of 13 C NMR (CDCl3 ) spectrum and DEPT-135 (CDCl3 ) spectrum of tetraphenylethylene
(TPE).
The spectral study of the HSQC NMR (Figure 5) showed an agreement with the other structures under
consideration. They are mainly characterized by the peak correlation at 128.8 ppm with the two signs relating
to the protons at 7.11 ppm and 7.35 ppm.
3.2.2. Tetraphenylethylene (TPE)
Mp: 223–226 ◦ C; IR (KBr, cm−1)ν = 3062 (CHaro), ν = 1642 (C = Cethyl), ν = 1469 (C = Caro); 1 H NMR
(400 MHz, CDCl3)δ (ppm) = 7.31–7.33 (m, 20H); 13 C NMR (100 MHz, CDCl3)δ (ppm) = 137.2, 137.1, 133.8,
133.6, 128.7, 128.5, 128.4.
Figure 7. HSQC (CDCl3 ) spectrum of tetraphenylethylene (TPE).
598

ATOUI et al./Turk J Chem
The DEPT-135 spectrum (Figure 6) confirms the assignment of the 13 C NMR spectrum. Thus, a
comparison of the two spectra shows the absence of two peaks at 137.1 ppm and 137.2 ppm, which proves that
these two are proportional to the quaternary carbons.
The HSQC spectroscopy analysis (Figure 7) confirmed once more that the two peaks at 137.1 ppm and
137.2 ppm belong to the quaternary carbons due to the absence of correlation with an H proton. Moreover,
this analysis verified that the other five peaks belong to the nonquaternary aromatic carbons.
The HMBC NMR spectra (Figure 8) showed an agreement with the expected structures. They are mainly
characterized by the correlation of the peak at 137.1 ppm with the multiplet of the aromatic protons. This
confirms that this peak is proportional to the aromatic quaternary carbons and not to the ethylenic carbons.
Figure 8. HMBC (CDCl3 ) spectrum of tetraphenylethylene (TPE).
Acknowledgment
We gratefully acknowledge the financial support of the Ministry of Higher Education and Scientific Research of
Tunisia.
References
1. Mizoroki, T.; Mori, K.; Ozaki, A. Bull. Chem. Soc. Jpn. 1971, 44, 581-584.
2. Heck, R. F.; Nolley, J. P.; J. Org. Chem. 1972, 37, 2320-2322.
3. Beletskaya, P.; Cheprakov, A. V. Chem. Rev. 2000, 100, 3009-3066.
4. Hassan, J.; Vignon, M. S.; Gozzi, C.; Schulz, E.; Lemaire, M. Chem. Rev. 2002, 102, 1359-1469.
5. Farina, V. Adv. Synth. Catal. 2004, 346, 1553-1582.
6. Nicolaou, K. C.; Bulger, P. G.; Sarlah, D. Angew. Chem. 2005, 117, 4516-4563.
7. Phan, N. T. S.; Van der Sluys, M.; Jones, C. W. Adv. Synth. Catal. 2006, 348, 609-679.
8. Kohler, K.; Prockl, S. S.; Kleist, W. Curr. Org. Chem. 2006, 10, 1585-1601.
9. Yasuda, S.; Yorimitsu, H.; Oshima, K. Organometallics 2010, 29, 2634-2636.
599

ATOUI et al./Turk J Chem
10. Kalsi, D.; Sundararaju, B. Chemical Reviews 2015, 115, 3170-3387.
11. Terao, J.; Kambe, N. Acc. Chem. Res. 2008, 41, 1545.
12. Kambe, N.; Iwasaki , T.; Terao, J. Chem. Soc. Rev. 2011, 40, 4937.
13. Jana, R.; Pathak, T. P.; Sigman, M. S. Chem. Rev. 2011, 111, 1417.
14. Loska, R.; Rao Volla, C. M.; Vogel, P. Adv. Synth. Catal. 2008, 350, 2859-2864.
15. Hajipour, A. R.; Azizi, G. Green Chem. 2013, 15, 1030-1034.
16. Wang, H.; Cheng, H.; Zhao, F. Green and Sustainable Chemistry 2014, 4, 1-6.
17. Benali, B.; Fadouach, M.; Kabouchi, B.; Kadiri, A. Spectrochim. Acta 1993, 49A, 1163-1169.
18. Kojima, M.; Nebashi, S.; Ogawa, K.; Kurita, N. J. Phys. Org. Chem. 2005, 18, 994-1000.
19. Mako, T. L.; Byers, J. A. Inorg. Chem. Front. 2016, 3, 766-790.
˚
20. Ludwig, M.; Stromberg, S.; Svensson, M.; Akermark, B. Organometallics 1999, 18, 970-975.
21. Noel, S.; Luo, C.; Pinel, C.; Djakovitch, L. Adv. Synth. Catal. 2007, 349, 1128-1140.
22. Tolman, C. A. Chem. Rev. 1977, 77, 313.
23. Tolman, C. A. J. Am. Chem. Soc. 1970, 92, 2956.
24. Tolman, C. A. J. Am. Chem. Soc. 1974, 96, 53.
25. Calhorda, J. S.; Brown, J. M.; Cooley, N. A. Organometallics 1991, 10, 1431-1438.
26. Littke, F.; Fu, G. C. Angew. Chem. Int. Ed. 1999, 38, 2411-2413.
27. Littke, F.; Fu, G. C. J. Org. Chem. 1999, 64, 10-11.
28. Littke, F.; Fu, G. C. Org. Synth. 2005, 81, 63-69.
29. Amatore, C.; Carr´e, E.; Jutand, A.; M’Barki, M. A.; Meyer, G. Organometallics 1995, 14, 5605-5614.
30. Sa¨ıd, K.; Moussaoui, Y.; Kammoune, M.; Ben Salem, R. Ultrason. Sonochem. 2011, 18, 23-27.
31. Said, K.; Ben Salem, R. Chemical Engineering and Science 2016, 6, 111-123.
32. Deshmukh, R. R.; Rajagopal, R.; Srinivasan, K. V. Chem. Commun. 2001, 7, 1544-1545.
33. Ambulgekar, V. G.; Bhanage, M. B.; Samant, D. S. Tetrahedron Lett. 2005, 46, 2483-2485.
600
