X-Ray Crystal Structure
Determinations of
Galactosylacetylene
Building Blocks
David J. Leaver,1 Andrew B. Hughes,1 Anastasios Polyzos,2
and Jonathan M. White3
1Department of Chemistry, La Trobe University, Melbourne, Victoria 3086, Australia
2CSIRO Materials Science and Engineering, Clayton South, Victoria 3169, Australia;
and Department of Chemistry, University of Cambridge, Cambridge CB2 1EW,
United Kingdom
3Bio21 Institute, School of Chemistry, University of Melbourne, Parkville,
Victoria 3010, Australia
We report the crystal structures of two galactosylacetylenes: 3,7-anhydro-4,5,6,8-
tetra-O-benzyl-1,1,2,2-tetradehydro-1,2-dideoxy-1-C-(trimethylsilyl)-D-glycero-L-mann
ooctitol (7) and 3,7-anhydro-4,5,6,8-tetra-O-benzyl-1,1,2,2-tetradehydro-1,2-D-glycero-
L-mannooctitol (8). A short overview of the synthetic chemistry used to obtain these
targets is mentioned.
Keywords X-ray crystal structure; Galactosylacetylene; Structure; Synthesis
INTRODUCTION
Glycosylacetylene building blocks have been appearing in the literature[1,2] and
are proving to be valuable building blocks in carbohydrate chemistry. Galacto-
sylacetylenes are an important member of this group and have been used in the
ever expanding area of 1,3-dipolar cycloaddition of terminal azides and alkynes
(Huisgen reactions), which are a subset of “click” chemistry.[3–6] “Click” chem-
istry of azides and alkynes has been heavily utilized due to its robust nature
in facilitating aqueous or oxygenated conditions, uncomplicated operation and
workup, and high-yielding transformations.[7,8] The glycosylacetylenes, includ-
ing the galactosylacetylenes, have also been used in C-glycosylamino acid and
Received August 27, 2010; accepted January 11, 2011.
Address correspondence to Andrew B. Hughes, Department of Chemistry, La Trobe Uni-
versity, Melbourne, Victoria 3086, Australia. E-mail: a.hughes@latrobe.edu.au
379

D.J. Leaver et al.
380
glycopeptide synthesis.[5,6,9–13] Due to 7 and 8 being widely used as building
blocks for C-glycosylamino acids, glycopeptides, and other carbohydrate-based
structures, it is important to confirm the anomeric configurations.
RESULTS AND DISCUSSION
The synthesis of compounds 7 and 8 is shown in Scheme 1. Key to the synthe-
sis of the anomer-substituted galactosylacetylene 8 was the alkynyl addition
to the lactone intermediate 5. Accordingly, the synthesis of D-galactonolactone
5 was readily achieved by oxidation of the methyl 2,3,4,6-tetra-O-benzyl-D-
galactoside 3 via the methyl-D-galactopyranoside 2.[14–16]
Scheme 1: Synthesis of galactosylacetylenes 7 and 8.
Reagents and conditions: (i) Amberlite IR 120, 115◦C, MeOH, 92% (lit.[17]
78%); (ii) BnBr, NaH, Bu4NI, DMF, 84% (lit.[14] 82%); (iii) AcOH (80%), 1M
H2SO4, 145◦C, 70% (lit.[14] 62%); (iv) Ac2O, DMSO, 88% (lit.[16] 90%); (v) Li-
TMS acetylene, CeCl3, THF, 80% (lit.[9] 91%); (vi) Et3SiH, BF3·OEt2, CH3CN-
CH2Cl2, 73% (lit.[9] 71%); (vii) NaOH, MeOH-CH2Cl2, 90% (lit.[9] 99%).
Deprotection of the methyl acetal 3 to the hemiacetal 4 was carried out
with 80% AcOH and 1M H2SO4 at reflux.[14] The oxidation method used
for the tetraacetate analogue of galactonolactone 5 was used successfully
for the oxidation of compound 4 to 5.[15,16] We noted, however, that insuffi-
ciently pure methyl α/β-D-galactoside gave unwanted 2,3,4,6-tetra-O-benzyl-
D-galactonofurano-δ-lactone, which was evidenced by the 13C NMR analysis,
where the furano carbonyl peak was deshielded by δ 2.2 ppm relative to the
corresponding pyrano carbonyl signal.[16,18–21]

Galactosylacetylene Building Blocks
381
Alkyne addition to the galactolactone 5 was mediated by lithiated
trimethylsilyl (TMS)-acetylene in the presence of CeCl3 affording the hemiac-
etal 6 in 80% yield.[9] Treatment of 6 with a Lewis acid promoted the formation
of the oxonium ion, which was stereoselectively intercepted by triethylsi-
lane to afford the protected alkynylgalactose 7 in good yield.[9] The struc-
ture of this compound was verified by X-ray crystallography (Fig. 1), which
showed that the product is in the beta configuration and is the pyranose iso-
mer. 3,7-Anhydro-4,5,6,8-tetra-O-benzyl-1,1,2,2-tetradehydro-1,2-D-glycero-L-
mannooctitol 8 was also successfully crystallized and analyzed by X-ray
crystallography (Fig. 2), which again confirmed the beta configuration of the
alkyne and the pyranose form.
We noted that 7 was successfully crystallized, while previous workers re-
ported this compound as an oil.[9]
Both compounds 7 and 8 crystallized in the monoclinic space group P21,
compound 7 having two independent molecules in the asymmetric unit. The
two molecules differed slightly with respect to the conformations of the 2- and
Figure 1: Thermal ellipsoid plot for compound 7, molecule 1. Ellipsoids are at the 20%
probability level.

D.J. Leaver et al.
382
Figure 2: Thermal ellipsoid plot for compound 8. Ellipsoids are at the 20% probability level.
3-O-benzyl substituents; however, the bond distances and angles for the two
molecules were not significantly different from one another. Selected bond dis-
tances and angles for the pyranose rings of 7 and 8 and of the anomeric alkyne
substituents are presented in Table 1.
Table 1: Selected bond distances (Å) and angles (◦) for compounds 7 (both
molecules), 8, 9, and 10
7(M1)
7(M2)
8
9
10
C1-C2
1.547(3)
1.471(4)
1.507(4)
1.528(3)
1.518(4)
1.432(3)
1.433(3)
1.421(3)
1.426(3)
1.426(3)
1.544(3)
1.476(4)
1.517(4)
1.525(4)
1.522(3)
1.431(3)
1.431(3)
1.419(3)
1.433(3)
1.422(3)
1.540(4)
1.462(4)
1.517(4)
1.538(4)
1.520(4)
1.427(3)
1.433(3)
1.434(3)
1.430(3)
1.418(3)
1.528
1.475
1.513
1.534
1.543
1.434
1.416
1.421
1.419
1.422
1.544
1.484
1.521
1.545
1.528
1.441
1.425
1.427
1.410
C1-C7
C2-C3
C3-C4
C4-C5
C5-O1
O1-C1
C2-O2
C3-O3
C4-O4
O1-C1-C2
C1-C2-C3
C2-C3-C4
C3-C4-C5
C4-C5-O1
C5-O1-C1
O1-C1-C7
110.8(2)
111.6(2)
110.7(2)
110.3
110.3
107.5(2)
109.7(2)
108.0(2)
110.8(2)
111.5(2)
108.6(2)
109.1(2)
110.9(2)
107.6(2)
113.6(2)
112.4(2)
107.5(2)
109.8(2)
111.2(2)
107.5(2)
110.1(2)
110.6(2)
107.5(2)
110.7
110.1
110.2
108.9
114.0
112.0
111.7
109.2
109.5
109.0
113.2
113.2

Galactosylacetylene Building Blocks
383
Both alkynes 7 and 8 have the β-configuration and the C1 C7 bond dis-
tances are not significantly different from one another. It is of interest to com-
pare these structures with other anomeric alkynes, particularly those with
the α-configuration, as these may reveal structural effects arising from the
anomeric effect. A survey of the Cambridge Crystallographic database[22] gave
the structures 9 and 10, which were deemed accurate enough and suitable for
comparison.[23] The C1-C7 bond distance in compound 9, which is an anomeric
alkyne having the α-configuration, is not significantly different from either 7
or 8; however, the C C bond distance in the anomeric alkyne 10 is lengthened
slightly compared to the nonanomeric alkyne at the 4-position in the same
structure, suggesting that the nO-σ∗
interaction is lengthening this bond.
CC
Comparison with a larger range of structures needs to be made before any
conclusions can be made as to whether there are any significant structural
differences between α- and β-anomeric alkynes.
CONCLUSION
We have successfully solved the X-ray crystal structures of 3,7-anhydro-
4,5,6,8-tetra-O-benzyl-1,1,2,2-tetradehydro-1,2-dideoxy-1-C-(trimethylsilyl)-D-
glycero-L-mannooctitol 7 (Fig. 1) and 3,7-anhydro-4,5,6,8-tetra-O-benzyl-1,1,
2,2-tetradehydro-1,2-D-glycero-L-mannooctitol 8 (Fig. 2), which were success-
fully synthesized via Scheme 1. These novel XRD crystal structures clearly
confirmed the relative configuration of 7 and 8. Compounds such as 8 are
proving to be useful building blocks in carbohydrate synthesis.
EXPERIMENTAL
Crystallography
Intensity data for compound 8 was collected with an Oxford Diffrac-
tion Sapphire CCD diffractometer using Cu-Ka radiation (graphite crys-
tal monochromator ꢁ = 1.54184); intensity data for 7 was collected with a
Bruker SMART Apex CCD detector using Mo-Ka radiation (graphite crys-
tal monochromator ꢁ = 0.71073). The temperature during data collection was
maintained at 130.0(1) K.

D.J. Leaver et al.
384
Crystal data for 7
The crystals obtained for
7
were recrystallized from hexane-
dichloromethane, mp 78–80◦C. C39H44O5Si, M = 620.83, T = 130.0(2) K,
˚
˚
ꢁ = 0.71073 A, Monoclinic, space group P21 a = 18.607(1), b = 7.5190(5), c
ꢀR
◦
3
−3
˚
= 25.337(2) A,
= 99.639(1) . V 3494.8(4) A , Z = 4, Dc = 1.180 mg M
ꢂ(Mo-Kꢃ) 0.109 mm−1, F(000) = 1328, crystal size 0.5 × 0.45 × 0.40 mm. 18212
reflections measured, 9143 independent reflections (Rint = 0.0335); the final R
was 0.042, [I > 2ꢂ(I)] and wR(F2) was 0.0987 (all data).
Crystal data for 8
The crystals obtained for
8
were recrystallized from hexane-
dichloromethane, mp 81–83◦C (lit.[11] 79–80◦C (pentane)). C36H36O5, M =
˚
548.65, T = 130.0(2) K, ꢁ = 1.54184 A, Monoclinic, space group P21 a =
ꢀR
◦
3
˚
˚
11.2772(3), b = 8.4295(2), c = 16.5947(2) A, = 109.206(2) . V 1489.71(6) A ,
Z = 2, Dc = 1.223 mg M−3 ꢂ(Mo-Kꢃ) 0.642 mm−1, F(000) = 584, crystal size 0.5
× 0.45 × 0.40 mm. 5898 reflections measured, 4399 independent reflections
(Rint = 0.0351); the final R was 0.045, [I > 2ꢂ(I)] and wR(F2) was 0.0984 (all
data).
ACKNOWLEDGMENTS
DL acknowledges the Australian government for the provision of an Australian
Postgraduate Award (APA) and La Trobe University/CSIRO for the La Trobe
University/CSIRO Aurora PhD top-up scholarship.
REFERENCES
1. Stichler-Bonaparte, J.; Bernet, B.; Vasella, A. Oligosaccharide analogues of
polysaccharides. Part 25. Synthesis of mono- and diethynylated analogues of 2-
acetamido-2-deoxy-D-glucopyranose. Helv. Chim. Acta 2002, 85, 2235–2257.
2. Miao, Z.; Xu, M.; Hoffmann, B.; Bernet, B.; Vasella, A. Functionalised bicyclic exo-
glycals by alkynol cycloisomerisation of hydroxy 1,3-diynes and hydroxy haloalkynes.
Helv. Chim. Acta 2005, 88, 1885–1912.
3. Vecchi, A.; Melai, B.; Marra, A.; Chiappe, C.; Dondoni, A. Microwave-enhanced
ionothermal CuAAC for the synthesis of glycoclusters on a calix[4]arene platform.
J. Org. Chem. 2008, 73, 6437–6440.
4. Marra, A.; Vecchi, A.; Chiappe, C.; Melai, B.; Dondoni, A. Validation of the
copper(I)-catalyzed azide-alkyne coupling in ionic liquids. Synthesis of a triazole-linked
C-disaccharide as a case study. J. Org. Chem. 2008, 73, 2458–2461.
5. van Kasteren, S.I.; Kramer, H.B.; Jensen, H.H.; Campbell, S.J.; Kirkpatrick, J.;
Oldham, N.J.; Anthony, D.C.; Davis, B.G. Expanding the diversity of chemical protein
modification allows post-translational mimicry. Nature 2007, 446, 1105–1109.
6. Dondoni, A.; Giovannini, P.P.; Massi, A. Assembling heterocycle-tethered C-
glycosyl and α-amino acid residues via 1,3-dipolar cycloaddition reactions. Org. Lett.
2004, 6, 2929–2932.

Galactosylacetylene Building Blocks
385
7. Evans, R.A. The rise of azide-alkyne 1,3-dipolar ‘click’ cycloaddition and its appli-
cation to polymer science and surface modification. Aust. J. Chem. 2007, 60, 384–395.
8. Meldal, M.; Tornoe, C.W. Cu-catalyzed azide-alkyne cycloaddition. Chem. Rev.
2008, 108, 2952–3015.
9. Lowary, T.; Meldal, M.; Helmboldt, A.; Vasella, A.; Bock, K. Novel type of rigid C-
linked glycosylacetylene-phenylalanine building blocks for combinatorial synthesis of
C-linked glycopeptides. J. Org. Chem. 1998, 63, 9657–9668.
10. Nishikawa, T.; Koide, Y.; Kanakubo, A.; Yoshimura, H.; Isobe, M. Synthesis of β-
analogues of C-mannosyltryptophan, a novel C-glycosylamino acid found in proteins.
Org. Biomol. Chem. 2006, 4, 1268–1277.
11. Dondoni, A.; Mariotti, G.; Marra, A. Synthesis of α- and β-glycosyl asparagine
ethylene isosteres (C-glycosyl asparagines) via sugar acetylenes and Garner aldehyde
coupling. J. Org. Chem. 2002, 67, 4475–4486.
12. Dondoni, A.; Mariotti, G.; Marra, A. General, stereoselective synthesis of ethylene
isosteres of α- and β-glycosylasparagines. Tetrahedron Lett. 2000, 41, 3483–3487.
13. Dedola, S.; Nepogodiev, S.A.; Field, R.A. Recent applications of the CuI-catalysed
Huisgen azide-alkyne 1,3-dipolar cycloaddition reaction in carbohydrate chemistry.
Org. Biomol. Chem. 2007, 5, 1006–1017.
14. Arya, P.; Barkley, A.; Randell, K.D. Automated high-throughput synthesis of ar-
tificial glycopeptides. Small-molecule probes for chemical glycobiology. J. Comb. Chem.
2002, 4, 193–198.
15. Namchuk, M.N.; McCarter, J.D.; Becalski, A.; Andrews, T.; Withers, S.G. The role
of sugar substituents in glycoside hydrolysis. J. Am. Chem. Soc. 2000, 122, 1270–1277.
16. Overkleeft, H.S.; van Wiltenburg, J.; Pandit, U.K. A facile transformation of sugar
lactones to azasugars. Tetrahedron 1994, 50, 4215–4224.
17. Mowery, D.F., Jr.; Coelho, R.A. A modification of the mechanism of formation of
methyl galactosides by the Fischer reaction including a computer simulation. Carbo-
hydr. Res. 1986, 155, 33–44.
18. Bessmertnykh, A.; Henin, F.; Muzart, J. Palladium-catalyzed oxidation of benzy-
lated aldose hemiacetals to lactones. Carbohydr. Res. 2004, 339, 1377–1380.
19. Xie, J.; Molina, A.; Czernecki, S. Alkylidenation of sugar lactones and further
transformation to C-glycosides. J. Carbohydr. Chem. 1999, 18, 481–498.
20. Dondoni, A.; Scherrmann, M.-C. Thiazole-based synthesis of formyl C-glycosides.
J. Org. Chem. 1994, 59, 6404–6412.
21. Jensen, H.S.; Limberg, G.; Pedersen, C. Benzylation of aldonolactones with benzyl
trichloroacetimidate. Carbohydr. Res. 1997, 302, 109–112.
22. Allen, F.H. The Cambridge structural database: a quarter of a million crystal
structures and rising. Acta Cryst. 2002, B58, 380–388.
23. Bernet, B.; Bu¨rli, R.; Xu, J.; Vasella, A. Influence of an ethynyl or a buta-1,3-diynyl
group on the chemical shifts of hydroxy groups of glucopyranoses. Helv. Chim. Acta
2002, 85, 1800–1811.
