Verification of the Necessity of the Tolyl Group of
PF-543 for Sphingosine Kinase 1 Inhibitory Activity
Su Bin Kim 1,†, Taeho Lee 2,†, Hong Seop Moon 1, Sung Hwan Ki 3, Yoon Sin Oh 4, Joo-Youn Lee 5,
Sang-Bum Kim 6, Jeong-Eun Park 6, Yongseok Kwon 7, Sanghee Kim 8,
Dong Jae Baek 1,* and Eun-Young Park 1,*
1
College of Pharmacy, Mokpo National University, Jeonnam 58554, Korea; rlatnqls0801@naver.com (S.B.K.);
hbsmoon@mokpo.ac.kr (H.S.M.)
2
College of Pharmacy, Research Institute of Pharmaceutical Sciences, Kyungpook National University,
Daegu 41566, Korea; tlee@knu.ac.kr
3
College of Pharmacy, Chosun University, Gwangju, 61452, Korea; shki@chosun.ac.kr
4
Department of Food and Nutrition, Eulji University, Seongnam 13135, Korea; ysoh@eulji.ac.kr
5
Chemical Data-Driven Research Center, Korea Research Institute of Chemical Technology, 141 Gajeong-ro,
Yuseong-gu, Daejeon 34114, Korea; leejooyoun@snu.ac.kr
6
New Drug Development Center, Daegu-Gyeongbuk Medical Innovation Foundation, 80 Cheombok-ro,
Dong-gu, Daegu 41061, Korea; ksb2014@dgmif.re.kr (S.-B.K.); parkje6605@dgmif.re.kr (J.-E.P.)
7
Department of Chemistry, Sogang University, Seoul 04107, Korea; ykwon@sogang.ac.kr
8
College of Pharmacy, Seoul National University, Seoul 08826, Korea; pennkim@snu.ac.kr
* Correspondence: dbaek@mokpo.ac.kr (D.J.B.); parkey@mokpo.ac.kr (E.-Y.P.);
Tel.: +82-61-450-2705 (D.J.B.); +82-61-450-2706 (E.-Y.P.)
†
These authors contributed equally to this work.
Academic Editors: Diego Muñoz-Torrero and Beatriz De Pascual-Teresa
Received: 20 April 2020; Accepted: 26 May 2020; Published: 27 May 2020
Abstract: PF-543, the most potent sphingosine kinase (SK) inhibitor, does not demonstrate effective
anticancer activity in some cancer cells, unlike other known SK1 inhibitors. PF-543 has a non-lipid
structure with a unique toluene backbone; however, the importance of this structure remains
unclear. Therefore, the purpose of this study was to investigate changes in SK inhibitory and
anticancer activities and to explore the role of the tolyl group structure of PF-543 through various
modifications. We transformed the methyl group of PF-543 into hydrogen, fluorine, and hydroxy.
PF-543 derivatives in which the methyl group was substituted by hydrogen and fluorine
(compound 5) demonstrated SK1 inhibitory and anticancer activities similar to PF-543. Moreover,
we performed molecular modeling studies of PF-543 and compound 5. To assess the metabolic
stability of PF-543 and compound 5, we determined their degree of degradation using the liver
microsomes of four different animal species (human, dog, rat, and mouse). However, both PF-543
and compound 5 showed poor microsomal stability. Therefore, for the medical applications of PF-
543, the structural modifications of its other parts may be necessary. Our results provide important
information for the design of additional PF-543 analogs.
Keywords: sphingosine kinase; PF-543; BODIPY; anticancer; inhibitor; derivative
1. Introduction
Sphingolipids are structurally modified by various enzymes and regulate various biological
activities through the regulation of cancer cell signaling. Sphingosine and ceramide mediate
apoptosis, whereas sphingosine-1-phosphate (S1P), sphingomyelin, and glucosylceramide have
Molecules 2020, 25, 2484; doi:10.3390/molecules25112484
www.mdpi.com/journal/molecules

Molecules 2020, 25, 2484
2 of 14
antiapoptotic and prosurvival roles. The majority of enzymes involved in sphingolipid metabolism
have been identified through comprehensive research, and the regulation of these enzymes has the
potential to be developed as a therapeutic agent for various diseases, including cancer [1].
Sphingosine kinase (SK) has two isoforms, i.e., SK1 and SK2, and these play various roles at different
positions; thus, the development of selective inhibitors is required. SK transforms sphingosine into
S1P, which induces cell growth [1]. In fact, S1P and SK activities increase in various forms of cancers,
which can be suppressed through SK inhibition. While the association between SK1 and cancer has
been extensively studied, the role of SK2 in cancer remains unclear thus far [2]. Nevertheless,
ABC294640 (an SK2 inhibitor developed by Apogee Biotechnology) has been shown to inhibit cell
growth in various forms of cancer (Figure 1) [3]. Moreover, in vivo efficacy evaluation has
demonstrated the effect that SK2 can have on various solid cancers and hematologic malignancies
[4].
ABC294640 successfully completed Phase I clinical trials for various solid cancers, during which
rapid and biphasic reductions in plasma levels of S1P were reported [5]. Phase Ib and Phase II clinical
trials are underway for cholangiocarcinoma, liver cancer, multiple myeloma, lymphoma and sarcoma
using ABC294640 as a target for SK2 [1,6]. These trials show that the ceramide induction or S1P
suppression could be used as a new chemotherapy strategy.
Amgen 82, developed by Amgen Inc. (California, CA, USA, Figure 1), as another nonlipid SK
inhibitor, inhibits human SK1 and SK2 (IC50 = 20 and 100 nM, respectively). Amgen 82 displayed
anticancer activities in human melanoma and human breast cancer cell lines [7]. However, many SK
inhibitors have a sphingolipid structure. For example, many SK inhibitors of the FTY720 type, such
as RB-005 and ROME ((R)-FTY720-OMe), have already been classified as sphingolipids (Figure 1) [8].
RB-005 is a sphingosine-based SK1-selective inhibitor (IC50 = 3.6 μM) and induced the proteasomal
degradation of SK1 in human pulmonary arterial smooth muscle cells [9]. ROME, an SK2 inhibitor
(Ki = 16 μM), can reduce MCF-7 breast cancer cell proliferation and prevent cell migration [9].
In 2010, FTY720 (Fingolimod, Gilenya, and Novartis) became the first oral treatment for multiple
sclerosis to be approved by the US FDA (Figure 1) [10]. FTY720 also activates protein phosphatase
2A to inhibit cell growth in various forms of cancers (hematologic malignancies and liver, bladder,
and colorectal cancers). Additionally, FTY720 inhibits SK1 activity [11]. Diverse in vivo effects of
these sphingolipids and FTY720 analogs have been a major obstacle in their development as drugs.
Thus, the development of a sphingolipid regulator with a nonlipid structure and selective function is
required.
Figure 1. Known sphingosine kinase inhibitors and FTY720.

Molecules 2020, 25, 2484
3 of 14
PF-543
[(R)-(1-(4-((3-methyl-5-(phenylsulfonyl)phenoxy)methyl)benzyl)pyrrolidin-2-
yl)methanol] is a nonlipid SK1 inhibitor (IC50 = 2.0 nM) developed by Pfizer Inc. (NYC, NY, USA) and
is the most potent SK1 inhibitor to date (Figure 1) [12]. Despite its high SK1 inhibitory effects, PF-543
has been reported to be less effective against certain forms of cancer, including prostate cancer [13].
The assumed reason for this is that PF-543 increases cellular sphingosine levels. Thus, the
development of various derivatives of PF-543 is required.
PF-543 has a backbone linked by oxygen and a benzene sulfonyl tail, neither of which exists in
other SK inhibitors. Additionally, PF-543 has a unique toluene structure and is generally unstable
during in vivo metabolism [14]. Pfizer synthesized a derivative of PF-543, which was modified to
have a benzene backbone (26a; Figure 1). However, its study revealed that its selective SK1 inhibitory
effect was lower than that of PF-543. No additional studies have been conducted on its anticancer
activities against compound 26a [15]. The current knowledge regarding the crystal structures of SK1
and PF-543 make it difficult to confirm whether the toluene structure of PF-543 is needed [16]. We
recently reported studies on the PF-543 analogs compound 2a, which has an aliphatic side chain, and
compound 2b, which has a diphenyl ethane backbone (Figure 1) [17,18]. In both analogs, the
inhibitory effect of SK1 was similar to that of PF-543, but the anticancer activities were similar to or
slightly improved from PF-543. These results indicate the need for the further investigation of
whether the presence of the tolyl group in the PF-543 structure is important for its anticancer activity.
Despite the high SK1 inhibitory effect of PF-543, many analogs have not been developed due to
its low anticancer activity. PF-543 analogs reported only SK1/2 inhibitory effects, and based on these
results, it is difficult to determine whether anticancer activity improved. Therefore, this study aimed
to confirm the effect of the presence of the tolyl group in the PF-543 structure on anticancer activity
and to investigate the structural necessity.
2. Results and Discussion
2.1. Chemical Synthesis
PF-543 analogs containing fluorine and hydroxyl groups in their modified benzene backbones
were synthesized using orcinol and 3-fluoro-5-methylphenol as starting materials, respectively
(Scheme 1).

Molecules 2020, 25, 2484
4 of 14
Scheme 1. Synthesis of PF-543 derivatives (2–10). Reagents and conditions: i) Ac2O, pyridine, rt, 12 h;
ii) NBS, EtOAc, 60 °C, 2 d, 52%, iii) PhSO2Na, tetrahydrofuran (THF)/ dimethylformamide (DMF)
(2/1), 80 °C, 4 d, 68%; iv) sat. NaHCO3, MeOH, rt, 1 d, 82%; v) 4-(bromomethyl)benzaldehyde, K2CO3,
THF, 12 h, 62%; vi) cyclic amines, sodium triacetoxyborohydride (STB), 1,2-dichloroethane, rt, 12 h,
58%–68%.
First, compounds 11 and 12 were synthesized by protecting the hydroxyl groups of the starting
materials with acetyl. To synthesize PF-543 derivatives that had been modified from toluene to
benzene, a reaction was carried out using commercially available m-toly acetate. Compounds 11 and
12 and m-toly acetate were brominated with N-bromosuccinimide, and sulfonyl groups were
introduced using benzenesulfonyl sodium salts. After deprotecting the acetyl groups of the obtained
compounds (16–18), compounds 22–24 (containing aldehyde) were synthesized using 4-
(bromomethyl)benzaldehyde in the same manner as PF-543. Previous results reported by Pfizer
revealed slightly elevated SK1 inhibitory effects and selectivity of PF-543 derivative with a
hydroxypyrrolidine head group (22c; Figure 1) [15]. In addition, some SK inhibitors with an
introduced piperidine head group demonstrated high SK1 selectivity and anticancer activity (RB005;
Amgen82; Figure 1) [4,8]. These results indicate that the structure of the head group of SK inhibitors
is highly important for SK1/2 selectivity and anticancer activity. Therefore, we introduced (R)-
prolinol, (S)-(-)-3-hydroxypyrrolidine and 4-hydroxypiperidine into compounds 22–24 using

Molecules 2020, 25, 2484
5 of 14
reductive amination. Finally, compounds 2–10 with PF-543 containing benzene, fluorobenzene, and
phenol were obtained.
2.2. SK Activity Assay of PF-543 (1) and Derivatives (2–10)
Once synthesized, compounds 2–10 were treated with 20 μM using a sphingosine kinase assay
kit to measure SK1/2 inhibition (Figure 2). Compounds 8–10, which contained an introduced
hydroxyl group, showed a weaker SK1 inhibitory effect. Among compounds 2–7 (which contained
the introduced hydrogen and fluorine), the SK1 inhibitory effects reduced in compounds 4 and 7,
which also contained an introduced 4-hydroxypiperidine. As a result, it was confirmed that the
backbone structure of the polar phenol group replacing methylbenzene in the PF-543 structure
reduced SK1 inhibition. Compounds 2 and 5, which had the same headgroups as PF-543, and
compounds 3 and 6, which had the same headgroups as compound 22c (Figure 1), inhibited 100% of
SK1 similar to PF-543 (at the same concentration). Compounds 4 and 7 had a 4-hydroxypiperidyl
headgroup and displayed significantly reduced SK inhibition. This indicates that the pyrrolidine
structure is an effective headgroup in PF-543 analogs compared with the piperidine structure. The
SK inhibitory effects of compounds 2, 3, 5, and 6 indicated that the presence of the tolyl group in the
PF-543 structure did not alter the inhibitory effects of SK.
Figure 2. Effect of PF-543 (1) and derivatives (2–10) on SK1/2 activity.
2.3. Cytotoxic Effects of PF-543 (1) and Derivatives (2–10) in Cancer Cells
The cytotoxicity of compounds 2–10 and PF-543 at concentrations of 20 and 40 μM, respectively,
was tested against HT29 cancer cells (Figure 3a). The cytotoxic effects of compounds 8–10 were
weaker than those of PF-543 in colorectal cancer cells, similar to their decreased SK1 inhibitory effects.
This indicates that polar groups in the SK1 inhibitor backbones may have reduced SK1 inhibitory and
anticancer activities. In contrast, compounds 2–7 (including compounds 4 and 7) demonstrated
anticancer activity similar to PF-543 against colorectal cancer cells. Additional studies were
conducted on compound 5, which had the same headgroup structure as PF-543, to confirm the
necessity of the tolyl group. Because compound 2, which also had the same headgroup as PF-543, is
a known compound [15], anticancer activities were confirmed using compound 5 introduced with
fluorine, which is a bioisostere of hydrogen. An evaluation of compound 5 revealed both SK1
inhibitory activity and cytotoxicity. The cytotoxic effect of compound 5 was similar to that of PF-543.

Molecules 2020, 25, 2484
6 of 14
The apoptotic effects of compound 5 and PF-543 were further compared at concentrations of 20 and
40 μM, respectively. It was revealed that compound 5 had similar apoptotic effects. Therefore, the
tolyl group in the PF-543 structure did not affect the anticancer activity in the same way as the SK1
inhibitory effects.
Figure 3. Cytotoxic effects of PF-543 (1) and derivatives (2–10) in cancer cells. a) Cell viability was
measured in HT29 cells treated with 20 and 40 μM PF-543 and derivatives. b) Compound 5 and PF-
543 were treated in HT29 cells. c) Apoptotic cells were stained with annexin-V-FITC (fluorescein
isothiocyanate). * p < 0.05, ** p < 0.01, *** p < 0.001compared with control cells.
2.4. Docking Study of PF-543 and Compound 5
Molecular modeling studies of PF-543 and compound 5 were conducted. The hydroxymethyl-
pyrrolidine (OH and N of pyrrolidine) of compound 5 showed both hydrogen bonding and
electrostatic interaction with Asp264 (protonated amine form). The phenyl linker of compound 5
showed hydrophobic interactions involving Ile260, Val263, Leu354 and Met358, while the benzene
backbone of compound 5 showed hydrophobic interactions with the surrounding Phe389 and Met392.
The terminal phenyl group of compound 5, similar to that of PF-543, formed hydrophobic
interactions with aromatic rings and the surrounding Ala360 and Phe374. It was thus determined
that compound 5 showed a binding mode similar to PF-543, indicating that its structure can replace
the methyl group of PF-543 (Figure 4).
a)
b)
Figure 4. Docking model of 5 (light green, ball and stick model) superimposed with the x-ray binding
conformation of PF-543 (gray, stick model) to SK1 (blue ribbon model) a). The hydrogen bond is

Molecules 2020, 25, 2484
7 of 14
shown as a green dashed line, and electrostatic interactions are displayed as an orange dashed line.
Moreover, the hydrophobic interactions are shown as a pink dashed line and the surface model of the
active site bound to 5 is displayed b). For clarity, only the key residues are visible in the stick model
and are labeled using the 1-letter amino acid code.
2.5. Metabolic Stability of PF-543 and Compound 5
To assess the metabolic stability of PF-543 and compound 5, we determined their degree of
degradation using the liver microsomes of four different animal species (human, dog, rat, and mouse).
PF-543 and compound 5 both demonstrated a low microsomal stability of <10% in all animal species
(Table 1). These results show that the tolyl group of PF-543 did not affect the stability of PF-543.
Table 1. In vitro profile of PF-543 and compound 5 determined using human (HLM), dog (DLM), rat
(RLM) and mouse (MLM) liver microsomal stability (% remaining during 30 min).
HLM
6.4
DLM
7.3
RLM
7.8
MLM
9.4
Compound
PF-543
5
7.6
5.5
6.8
9.8
3. Experimental Section
3.1. Synthesis in General
The reagents used in the reaction were used by purchasing a commercially available reagent.
Column chromatography was performed on silica gel grade 60 (230–400 mesh). All solvents used in
1
the reaction were commercially available anhydrous solvents. H-NMR and 13C-NMR used JEOL
ECZ500R (JEOL Co., Tokyo, Japan) and were measured using deuterated solvents at 500 and 125
MHz, respectively. High-resolution mass spectra were measured using an Agilent Technologies
G6520A Q-TOF mass spectrometer (Santa Clara, CA, USA) instrument using electrospray ionization
(ESI).
3.2. Synthesis
3.2.1. 3-Fluoro-5-methylphenyl acetate (11)
3-Fluoro-5-methyl phenol (2 g, 0.016 mol) was dissolved in pyridine (80 mL), acetic anhydride
(3.0 mL, 0.032 mol) was added, and the mixture was stirred at room temperature for 12 h. Water was
added to stop the reaction, and it was concentrated under reduced pressure after EtOAc extraction
and MgSO4 drying. The mixture was separated by column chromatography (n-hexane:EtOAc = 20:1)
to give compound 11 (2.64 g, 98%): 1H-NMR (500 MHz, CDCl3) δ 6.78–6.74 (m, 1H), 6.69 (ddd, J = 2.7,
1.4, 0.7 Hz, 1H), 6.66–6.62 (m, 1H), 2.33 (s, 3H), 2.27 (s, 3H); 13C-NMR (125 MHz, CDCl3) δ 169.3, 163.8,
161.8, 151.3, 151.2, 141.2, 141.1, 118.1, 113.8, 113.6, 106.9, 106.7, 21.5, 21.2; ESI-HRMS (M + H)+ m/z
calcd for C9H10FO2 169.0665, found 169.0632.
3.2.2. 3-(Bromomethyl)-5-fluorophenyl acetate (14)
Compound 11 (1.5 g, 0.0089 mol) was placed in a sealed tube, dissolved in EtOAc (30 mL), and
N-bromosuccinimide (1.59 g, 0.0089 mol) was added thereto, followed by stirring at 60 °C for 2 days.
The reaction was terminated with water and EtOAc, and the organic layer was dried over MgSO4 and
concentrated under reduced pressure. The resulting mixture was separated by column
1
chromatography (n-hexane:EtOAc = 20:1) to give compound 14 (1.03 g, 47%): H-NMR (500 MHz,
CDCl3) δ 7.00–6.96 (m, 1H), 6.94–6.93 (m, 1H), 6.80 (dt, J = 9.1, 2.2 Hz, 1H), 4.40 (s, 2H), 2.29 (s, 3H);
13C-NMR (125 MHz, CDCl3) δ 168.9, 163.7, 161.7, 151.6, 151.5, 140.6, 118.2, 118.1, 113.7, 113.5, 109.9,
109.7, 31.7, 31.6, 21.2; ESI-HRMS (M + H)+ m/z calcd for C9H9BrFO2 246.9770, found 246.9733.

Molecules 2020, 25, 2484
8 of 14
3.2.3. 5-(Bromomethyl)-1,3-phenylene diacetate (15)
Orcinol (2 g, 0.016 mol) was dissolved in pyridine (80 mL), acetic anhydride (4.57 mL, 0.048 mol)
was added thereto, and the mixture was stirred at room temperature for 12 h. Water was added to
stop the reaction, and it was concentrated under reduced pressure after EtOAc extraction and MgSO4
drying. The resulting mixture 12 (1.7 g, 0.008 mol) was dissolved in EtOAc (50 mL) without
purification, and N-bromosuccinimide (1.89 g, 0.01 mol) was added thereto and stirred at 60 °C for 2
days. The reaction was terminated with water and EtOAc, and the organic layer was dried over
MgSO4 and concentrated under reduced pressure. The resulting mixture was separated by column
1
chromatography (n-hexane:EtOAc = 5:1) to give compound 15 (1.19 g, 52%): H-NMR (500 MHz,
CDCl3) δ 7.02 (d, J = 2.1 Hz, 2H), 6.86 (t, J = 2.1 Hz, 1H), 4.41 (s, 2H), 2.26 (s, 6H); 13C-NMR (125 MHz,
CDCl3) δ 168.9, 515.1, 139.9, 119.7, 115.5, 31.9, 21.2; ESI-HRMS (M + H)+ m/z calcd for C11H12BrO4
286.9919, found 286.9947.
3.2.4. 3-Fluoro-5-((phenylsulfonyl)methyl)phenyl acetate (17)
Compound 14 (1.1 g, 0.0045 mol) was placed in a sealed tube, dissolved in THF/DMF (2/1, 30
mL), and benzene sulfinic acid sodium salt (2.2 g, 0.013 mol) was added thereto. The reaction was
stirred for 3 days while heating to 80 °C. After the reaction was cooled to room temperature, the
reaction was terminated with water and EtOAc, dried over MgSO4 and concentrated under reduced
pressure. The mixture was separated by column chromatography (n-hexane:EtOAc = 2:1) to give
compound 17 (1.1 g, 80%): 1H-NMR (500 MHz, CDCl3) δ 7.69–7.65 (m, 2H), 7.65–7.60 (m, 1H), 7.51–
7.46 (m, 2H), 6.84 (t, J = 2.2 Hz, 0.5H), 6.82 (t, J = 2.2 Hz, 0.5H), 6.71 (t, J = 6.71 Hz, 2H), 6.68 (t, J = 2.1
Hz, 0.5H), 6.66 (t, J = 2.0 Hz, 0.5H), 4.26 (s, 2H), 2.25 (s, 3H); 13C-NMR (125 MHz, CDCl3) δ 168.8, 163.5,
161.5, 151.5. 151.4, 137.5, 134.2, 131.0, 130.9, 129.3, 128.7, 120.1, 115.5, 115.3, 110.5, 110.3, 62.2, 21.1; ESI-
HRMS (M + H)+ m/z calcd for C15H14FO4S 309.0597, found 309.0543.
3.2.5. 5-((Phenylsulfonyl)methyl)-1,3-phenylene diacetate (18)
Compound 15 (0.9 g, 0.0031 mol) was dissolved in 25 mL of THF/DMF (2/1) mixed solvent in a
sealed tube, benzenesulfinic acid sodium salt (777 mg, 0.0047 mol) was added, and the mixture was
stirred at 80 °C for 4 days. The reaction was terminated with water and EtOAc, dried over MgSO4
and concentrated under reduced pressure. The mixture was separated by column chromatography
(n-hexane:EtOAc = 3:1) to give compound 18 (744 mg, 68%): 1H-NMR (500 MHz, CDCl3) δ 7.53–7.61
(m, 2H), 7.59–7.56 (m, 1H), 7.44–7.43 (m, 2H), 6.87 (t, J = 2.1 Hz, 1H), 6.73 (d, J = 2.1 Hz, 2H), 4.24 (s,
2H), 2.21 (s, 6H); 13C-NMR (125 MHz, CDCl3) δ 168.5, 150.8, 137.3, 133.7, 128.9, 128.4, 121.2, 115.8, 61.9,
20.8; ESI-HRMS (M + H)+ m/z calcd for C17H17O6S 349.0746, found 349.0721.
3.2.6. 3-((Phenylsulfonyl)methyl)phenol (19)
m-Toly acetate (2 g, 0.013 mol) was dissolved in EtOAc (150 mL), and N-bromosuccinimide (2.37
g, 0.0133 mol) was added thereto, followed by stirring for 3 days while heating to 70 °C. After cooling
to room temperature, water and EtOAc were added thereto and the reaction was completed. The
organic layer was separated, dried over MgSO4, and concentrated to obtain a mixture of compound
13. Compound 13 was placed in a sealed tube and dissolved in 120 mL of THF/DMF (2/1).
Benzenesulfinic acid sodium salt (4.27 g, 0.026 mol) was added thereto, followed by stirring for 3 days
while heating to 80 oC. The reaction was cooled to room temperature, water and EtOAc were added
and the reaction was completed. The organic layer was separated, dried over MgSO4, and
concentrated to obtain mixture compound 18. The reaction mixture was dissolved in 150 mL of
MeOH/H2O (1/1), NaHCO3 (5 g) was added thereto, and the mixture was stirred for 12 h while heating
at 40 °C. The reaction was cooled to room temperature, water and EtOAc were added thereto and the
reaction was completed. The organic layer was separated, dried over MgSO4, and concentrated. The
mixture was separated by column chromatogrphy (n-hexane:EtOAc = 2:1) to obtain compound 19.
The chemical spectrum of compound 19 was consistent with that previously reported [15].

Molecules 2020, 25, 2484
9 of 14
3.2.7. 3-Fluoro-5-((phenylsulfonyl)methyl)phenol (20)
Compound 17 (1.0 g, 0.0032 mol) was dissolved in MeOH/H2O (1/1, 60 mL) and NaHCO3 (2 g)
was added thereto. The reaction was stirred for 1 day while heating to 40 °C. The reaction was
terminated with water and EtOAc, dried over MgSO4 and concentrated under reduced pressure. The
mixture was separated by column chromatography (CH2Cl2:MeOH = 20:1) to give compound 20 (783
mg, 92%): 1H-NMR (500 MHz, CDCl3) δ 7.66 (dd, J = 5.2, 3.4 Hz, 2H), 7.62 – 7.57 (m, 1H), 7.46 (t, J =
7.8 Hz, 2H), 6.53 (t, J = 2.3 Hz, 0.5 H), 6.51 (t, J = 2.2 Hz, 0.5 H), 6.50 (t, J = 1.7 Hz, 1H), 6.25–6.23 (m,
0.5H), 6.23–6.21 (m, 0.5H), 4.21 (s, 2H); 13C-NMR (125 MHz, CDCl3) δ 164.3, 163.4, 162.3, 158.1, 158.0,
137.5, 134.2, 130.4, 130.3, 129.3, 129.2, 128.6, 114.1, 109.5, 109.4, 104.0, 103.8, 62.5; ESI-HRMS (M + H)+
m/z calcd for C13H12FO3S 267.0491, found 267.0466.
3.2.8. 5-((Phenylsulfonyl)methyl)benzene-1,3-diol (21)
Compound 18 (700 mg, 0.002 mol) was dissolved in MeOH (25 mL) and aq. NaHCO3 (10 mL)
was added thereto. It was stirred at room temperature for 1 day. The reaction was terminated with
water and EtOAc, dried over MgSO4 and concentrated under reduced pressure. The mixture was
separated by column chromatography (CH2Cl2:MeOH = 10:1) to give compound 21 (436 mg, 82%): 1H
NMR (500 MHz, CDCl3) δ 7.68 (dd, J = 8.4, 1.2 Hz, 2H), 7.62–7.57 (m, 1H), 7.49–7.41 (m, 2H), 6.30 (t, J
= 2.2 Hz, 1H), 6.15 (d, J = 2.2 Hz, 2H), 5.28 (s, 2H); 13C-NMR (125 MHz, CDCl3) δ 158.0, 137.7, 133.9,
129.4, 129.0, 128.5, 109.5, 103.2, 62.6; ESI-HRMS (M + H)+ m/z calcd for C13H13O4S 265.0535, found
265.0581.
3.2.9. 4-((3-((Phenylsulfonyl)methyl)phenoxy)methyl)benzaldehyde (22)
Compound 19 (292 mg, 1.176 mmol) was dissolved in MeCN (10 mL), and K2CO3 (488 mg, 3.528
mmol) and 4-(bromomethyl)benzaldehyde (257 mg, 1.294 mmol) were added thereto, and the
mixture was stirred for 12 h while heating to 60 °C. After cooling the reaction to room temperature,
the reaction was terminated with water and EtOAc, dried over MgSO4 and concentrated under
reduced pressure. The reaction was washed with n-hexane/EtOAc (3/1) to give compound 22. The
chemical spectrum of compound 22 was consistent with that previously reported [15].
3.2.10. 4-((3-Fluoro-5-((phenylsulfonyl)methyl)phenoxy)methyl)benzaldehyde (23)
Compound 20 (0.7 g, 0.0026 mol) was dissolved in MeCN (30 mL), and K2CO3 (1.09 g, 0.079 mol)
and 4-(bromomethyl)benzaldehyde (569 mg, 0.0029 mmol) were added thereto. The reaction was
stirred at room temperature for 12 h, the reaction was terminated with water and EtOAc, dried over
MgSO4 and concentrated under reduced pressure. The mixture was washed with (n-hexane:EtOAc =
1
3:1) to give compound 23 (730 mg, 73%): H-NMR (500 MHz, CDCl3) δ 10.00 (s, 1H), 7.88 (d, J = 8.2
Hz, 2H), 7.66 (dd, J = 8.4, 1.2 Hz, 2H), 7.64–7.59 (m, 1H), 7.52 (d, J = 8.1 Hz, 2H), 7.49–7.43 (m, 2H),
6.63 (t, J = 2.3 Hz, 0.5H), 6.61 (t, J = 2.3 Hz, 0.5H), 6.56 (t, J = 1.7 Hz, 1H), 6.41–6.40 (m, 0.5H), 6.39–6.38
(m, 0.5H), 5.03 (s, 2H), 4.23 (s, 2H); 13C-NMR (125 MHz, CDCl3) δ 191.9, 164.2, 162.3, 159.6, 159.5, 143.0,
137.8, 136.2, 134.1, 131.0, 130.2, 129.2, 128.6, 127.6, 113.1, 110.9, 110.8, 103.5, 103.3, 69.6, 62.5; ESI-HRMS
(M + H)+ m/z calcd for C21H18FO4S 385.0910, found 385.0981.
3.2.11. 4-((3-Hydroxy-5-((phenylsulfonyl)methyl)phenoxy)methyl)benzaldehyde (24)
Compound 21 (310 mg, 1.173 mmol) was dissolved in THF (15 mL), and K2CO3 (650 mg, 4.70
mmol) and 4-(bromomethyl)benzaldehyde (210 mg, 1.056 mmol) were added thereto. The reaction
was stirred at room temperature for 12 h and terminated with water and EtOAc. Then, it was dried
over MgSO4 and concentrated under reduced pressure. The mixture was separated by column
1
chromatography (CH2Cl2:MeOH = 20:1) to give compound 24 (278 mg, 62%): H-NMR (500 MHz,
CDCl3) δ 9.93 (s, 1H), 7.84 (d, J = 8.0 Hz, 2H), 7.64 – 7.60 (m, 2H), 7.58 (d, J = 7.3 Hz, 1H), 7.50 (d, J =
8.0 Hz, 2H), 7.45 (d, J = 7.7 Hz, 2H), 6.36 (t, J = 2.2 Hz, 1H), 6.17 (t, J = 1.6 Hz, 1H), 6.15 (t, J = 1.6 Hz,
1H), 4.96 (s, 2H), 4.20 (s, 2H); 13C-NMR (125 MHz, CDCl3) δ 192.7, 159.5, 158.3, 144.2, 137.7, 135.8,

Molecules 2020, 25, 2484
10 of 14
133.9, 130.0, 129.0, 128.5, 127.5, 111.2, 108.5, 102.9, 69.1, 62.7; ESI-HRMS (M + H)+ m/z calcd for
C21H19O5S 383.0953, found 383.0914.
3.2.12. (R)-(1-(4-((3-((Phenylsulfonyl)methyl)phenoxy)methyl)benzyl)pyrrolidin-2-yl)methanol (2)
Compound 22 (63 mg, 0.17 mmol) was dissolved in 1,2-dicholroethane (5 mL), and (R)-(-)-
prolinol (52 mg, 0.516 mmol) and sodium triacetoxyborohydride (73 mg, 0.34 mmol) were added
thereto. The mixture was stirred for 12 h at room temperature. The reaction was terminated with
water and EtOAc, dried over MgSO4 and concentrated under reduced pressure. The mixture was
separated by column chromatography (CH2Cl2:MeOH = 5:1) to give compound 2 (46 mg, 60%) [15]:
1H-NMR (500 MHz, CDCl3) δ 7.63 (dd, J = 8.4, 1.2 Hz, 2H), 7.61–7.57 (m, 1H), 7.45 (d, J = 7.6 Hz, 2H),
7.43 (d, J = 7.6 Hz, 2H), 7.36 (d, J = 8.1 Hz, 2H), 7.15–7.10 (m, 1H), 6.89 (ddd, J = 8.3, 2.5, 0.8 Hz, 1H),
6.74–6.70 (m, 1H), 6.62 (d, J = 7.6 Hz, 1H), 4.93 (s, 2H), 4.25 (s, 2H), 4.14 (d, J = 13.1 Hz, 1H), 3.70 (dt, J
= 16.6, 8.3 Hz, 2H), 3.58 (dd, J = 11.8, 3.9 Hz, 1H), 3.18–3.16 (m, 1H), 3.11–3.01 (m, 1H), 2.53 (dd, J =
16.7, 8.6 Hz, 1H), 1.97 (ddd, J = 15.8, 9.6, 5.8 Hz, 2H), 1.84 (ddtd, J = 15.8, 12.3, 8.4, 4.6 Hz, 4H); 13C-
NMR (125 MHz, CDCl3) δ 158.7, 138.0, 133.9, 130.0, 129.7, 129.5, 129.0, 128.7, 127.9, 123.6, 117.0, 115.8,
69.6, 62.9, 61.5, 58.6, 54.3, 27.2, 23.5; ESI-HRMS (M + H)+ m/z calcd for C26H30NO4S 452.1896, found
452.1877.
3.2.13. (S)-1-(4-((3-((Phenylsulfonyl)methyl)phenoxy)methyl)benzyl)pyrrolidin-3-ol (3)
Using compound 22 (63 mg, 0.17 mmol) and (S)-(-)-3-hydroxy pyrrolidine (45 mg, 0.516 mmol),
compound 3 (38 mg, 52%) was obtained by the same method as the synthesis method of compound
1
2: H-NMR (500 MHz, CDCl3) δ 7.63 (dd, J = 8.4, 1.2 Hz, 2H), 7.61–7.57 (m, 1H), 7.46–7.44 (m, 2H),
7.45–7.42 (m, 2H), 7.16–7.09 (m, 1H), 6.92–6.85 (m, 1H), 6.74–6.70 (m, 1H), 6.61 (d, J = 7.6 Hz, 1H), 4.92
(s, 2H), 4.40–4.39 (m, 1H), 4.25 (s, 2H), 3.90 (d, J = 7.9 Hz, 2H), 3.17–3.07 (m, 1H), 2.95 (d, J = 11.1 Hz,
1H), 2.88 (dd, J = 11.1, 5.0 Hz, 1H), 2.72 (dd, J = 15.2, 9.2 Hz, 1H), 2.25–2.13 (m, 1H), 1.95–1.82 (m, 1H);
13C-NMR (125 MHz, CDCl3) δ 158.7, 137.9, 137.0, 133.9, 130.0, 129.7, 129.4, 129.2, 128.7, 127.9, 123.7,
117.1, 115.7, 70.5, 69.6, 62.9, 62.0, 59.5, 52.4, 34.3; ESI-HRMS (M + H)+ m/z calcd for C25H28NO4S 438.1739,
found 438.1702.
3.2.14. 1-(4-((3-((Phenylsulfonyl)methyl)phenoxy)methyl)benzyl)piperidin-4-ol (4)
Using compound 22 (63 mg, 0.17 mmol) and 4-hydroxypiperidine (52 mg, 0.516 mmol),
1
compound 4 (53 mg, 69%) was obtained by the same method as the synthesis of compound 2: H-
NMR (500 MHz, CDCl3) δ 7.63–7.60 (m, 2H), 7.58 (dd, J = 10.6, 4.4 Hz, 1H), 7.43 (dd, J = 8.1, 7.6 Hz,
2H), 7.40 (d, J = 7.9 Hz, 2H), 7.34 (d, J = 8.0 Hz, 2H), 7.12 (t, J = 7.9 Hz, 1H), 6.94–6.87 (m, 1H), 6.75–
6.69 (m, 1H), 6.60 (d, J = 7.6 Hz, 1H), 4.92 (s, 2H), 4.25 (s, 2H), 3.77–3.74 (m, 1H), 3.68 (s, 2H), 2.94–2.82
(m, 1H), 2.57–2.44 (m, 2H), 2.03–1.90 (m, 2H), 1.71–1.57 (m, 2H); 13C-NMR (125 MHz, CDCl3) δ 158.7,
137.9, 136.5, 133.9, 130.2, 129.7, 129.5, 129.1, 128.8, 127.7, 123.6, 117.0, 115.8, 69.7, 62.9, 61.9, 50.7, 33.0;
ESI-HRMS (M + H)+ m/z calcd for C26H30NO4S 452.1896, found 452.1890.
3.2.15. (R)-(1-(4-((3-Fluoro-5-((phenylsulfonyl)methyl)phenoxy)methyl)benzyl)pyrrolidin-2-
yl)methanol (5)
Using compound 23 (84 mg, 0.22 mmol) and (R)-(-)-prolinol (66 mg, 0.656 mmol), compound 5
(72 mg, 70%) was obtained by the same method as the synthesis of compound 2: 1H-NMR (500 MHz,
CDCl3) δ 7.65 (dd, J = 8.3, 1.2 Hz, 2H), 7.64–7.59 (m, 1H), 7.51 (d, J = 8.0 Hz, 2H), 7.49–7.44 (m, 2H),
7.36 (d, J = 8.0 Hz, 2H), 6.60 (dt, J = 10.4, 2.3 Hz, 1H), 6.52–6.51 (m, 1H), 6.40–6.34 (m, 1H), 4.92 (s, 2H),
4.29 (d, J = 13.1 Hz, 1H), 4.21 (s, 2H), 3.90 (d, J = 13.1 Hz, 1H), 3.81–3.66 (m, 2H), 3.33–3.22 (m,2H),
2.74–2.66 (m, 1H), 2.04–1.79 (m, 4H); 13C-NMR (125 MHz, CDCl3) δ 164.2, 162.2, 159.8, 137.8, 137.0,
134.1, 130.8, 129.2, 128.6, 127.9, 113.1, 110.6, 110.5, 103.4, 103.2, 69.8, 67.4, 62.5, 61.3, 58.7, 54.0, 53.6,
50.7, 26.8, 23.4; ESI-HRMS (M + H)+ m/z calcd for C26H29FNO4S 470.1801, found 470.1819.

Molecules 2020, 25, 2484
11 of 14
3.2.16. (S)-1-(4-((3-fluoro-5-((phenylsulfonyl)methyl)phenoxy)methyl)benzyl)pyrrolidin-3-ol (6)
Using compound 23 (65 mg, 0.17 mmol) and (S)-(-)-3-hydroxy pyrrolidine (44 mg, 0.51 mmol),
1
compound 6 (43 mg, 56%) was obtained by the same method as the synthesis of compound 2: H-
NMR (500 MHz, CDCl3) δ 7.68–7.64 (m, 2H), 7.64–7.60 (m, 1H), 7.50–7.45 (m, 2H), 7.40 (d, J = 8.0 Hz,
2H), 7.34 (d, J = 8.1 Hz, 2H), 6.62 (dt, J = 10.4, 2.3 Hz, 1H), 6.52–6.51 (m, 1H), 6.40–6.35 (m, 1H), 4.92 (s,
2H), 4.22 (s, 2H), 4.08 (d, J = 13.1 Hz, 1H), 3.69 (dd, J = 11.5, 3.3 Hz, 1H), 3.61–3.49 (m, 2H), 3.15–3.06
(m, 1H), 2.97–2. 92 (m, 1H), 2.44 (dt, J = 15.7, 8.0 Hz, 1H), 2.02–1.82 (m, 2H); 13C-NMR (125 MHz, CDCl3)
δ 164.2, 162.3, 159.9, 137.8, 134.1, 130.8, 129.8, 129.2, 128.7, 127.8, 113.1, 110.6, 110.4, 103.5, 103.3, 70.1,
62.6, 61.6, 58.5, 54.4, 31.0; ESI-HRMS (M + H)+ m/z calcd for C25H27FNO4S 456.1645, found 456.1697.
3.2.17. 1-(4-((3-Fluoro-5-((phenylsulfonyl)methyl)phenoxy)methyl)benzyl)piperidin-4-ol (7)
Using compound 23 (65 mg, 0.17 mmol) and 4-hydroxypiperidine (51 mg, 0.51 mmol),
1
compound 7 (56 mg, 71%) was obtained by the same method as the synthesis of compound 2: H-
NMR (500 MHz, CDCl3) δ 7.66 (dd, J = 8.4, 1.2 Hz, 2H), 7.62 (ddt, J = 8.7, 7.4, 1.2 Hz, 1H), 7.49–7.45 (m,
2H), 7.36 (d, J = 8.0 Hz, 2H), 7.31 (d, J = 8.1 Hz, 2H), 6.62 (dt, J = 10.4, 2.3 Hz, 1H), 6.54–6.51 (m, 1H),
6.39–6.34 (m, 1H), 4.91 (s, 2H), 4.22 (s, 2H), 3.79–3.65 (m, 1H), 3.55 (s, 2H), 2.86–2.70 (m, 2H), 2.31–2.17
(m, 2H), 1.94–1.86 (m, 2H), 1.65–1.56 (m, 2H); 13C-NMR (125 MHz, CDCl3) δ 164.2, 162.3, 160.0, 137.8,
134.1, 130.8, 129.7, 129.2, 128.7, 127.6, 113.1, 110.5, 110.3, 103.4, 103.2, 70.2, 62.7, 53.5, 50.9, 34.1, 31.0;
ESI-HRMS (M + H)+ m/z calcd for C26H29FNO4S 470.1801, found 470.1840.
3.2.18. (R)-3-((4-((2-(Hydroxymethyl)pyrrolidin-1-yl)methyl)benzyl)oxy)-5-
((phenylsulfonyl)methyl)phenol (8)
Compound 24 (58 mg, 0.15 mmol) was dissolved in 1,2-dichloroethane (5 mL), and (R)-(-)-
prolinol (46 mg, 0.45 mmol) and sodium triacetoxyborohydride (64 mg, 0.303 mmol) were added. It
was stirred at room temperature for 12 h. The reaction was terminated with water and EtOAc, dried
over MgSO4 and concentrated under reduced pressure. The mixture was separated by column
1
chromatography (CH2Cl2:MeOH = 5:1) to give compound 8 (41 mg, 58%): H-NMR (500 MHz,
CDCl3/CD3OD = 3/1) δ 7.52–7.48 (m, 2H), 7.46 (td, J = 2.0, 1 Hz), 7.35–7.30 (m, 2H), 7.21 (d, J = 8.0 Hz,
2H), 7.18 (d, J = 8.0 Hz, 2H), 6.23 (t, J = 2.2 Hz. 1H), 6.08–6.02 (m, 1H), 6.01–5.98 (m, 1H), 4.72 (s, 2H),
3.17 (d, J = 1.6 Hz, 2H), 2.92 (dd, J = 5.7, 2.9 Hz, 1H), 2.83 (d, J = 3.3 Hz, 1H), 2.37 (dd, J = 16.7, 9.1 Hz,
1H), 1.91–1.76 (m, 2H), 1.70–1.55 (m, 4H); 13C-NMR (125 MHz, CDCl3/CD3OD = 3/1) δ 159.8, 158.2,
137.7, 133.9, 129.9, 129.7, 129.0, 128.5, 127.7, 111.0, 108.6, 103.0, 69.6, 65.7, 62.8, 62.1, 58.6, 54.3, 29.6,
27.3, 22.8.; ESI-HRMS (M + H)+ m/z calcd for C26H30NO5S 468.1845, found 468.1849.
3.2.19. (S)-1-(4-((3-Hydroxy-5-((phenylsulfonyl)methyl)phenoxy)methyl)benzyl)pyrrolidin-3-ol (9)
Compound 24 (58 mg, 0.15 mmol) was dissolved in 1,2-dichloroethane (5 mL), and then (S)-(-)-
3-hydroxypyrrolidine (40 mg, 0.45 mmol) and sodium triacetoxyborohydride (64 mg, 0.455 mmol)
were added. It was stirred at room temperature for 12 h. The reaction was terminated with water and
EtOAc, dried over MgSO4 and concentrated under reduced pressure. The mixture was separated by
column chromatography (CH2Cl2:MeOH = 5:1) to give compound 9 (44 mg, 64%): 1H-NMR (500 MHz,
CDCl3/CD3OD = 3/1) δ 7.49 (dd, J = 5.9, 4.7 Hz, 2H), 7.46 (d, J = 7.5 Hz, 1H), 7.32 (t, J = 7.8 Hz, 2H), 7.28
(d, J = 8.1 Hz, 2H), 7.21 (d, J = 8.1 Hz, 2H), 6.23 (t, J = 2.1 Hz, 1H), 6.03 (d, J = 1.6 Hz, 1H), 6.01 (d, J =
1.7 Hz, 1H), 4.72 (s, 2H), 4.36–4.20 (m, 1H), 4.05 (s, 2H), 3.01–2.91 (m, 2H), 2.86–2.78 (m, 1H), 2.73 (d,
J = 11.6 Hz, 1H), 2.12 – 1.95 (m, 1H), 1.78–1.64 (m, 1H); 13C-NMR (125 MHz, CDCl3/CD3OD = 3/1) δ
159.7, 158.2, 137.6(2C), 133.9, 130.0, 129.7, 129.0(2C), 128.5, 127.9, 111.0, 108.6, 103.0, 69.7, 69.4, 62.7,
61.4, 59.7, 52.4, 33.7; ESI-HRMS (M + H)+ m/z calcd for C25H28NO5S 454.1688, found 454.1673.
3.2.20. 1-(4-((3-Hydroxy-5-((phenylsulfonyl)methyl)phenoxy)methyl)benzyl)piperidin-4-ol (10)
Compound 24 (58 mg, 0.15 mmol) was dissolved in 1,2-dichloroethane (5 mL), 4-
hydroxypiperidine (46 mg, 0.45 mmol) and sodium triacetoxyborohydride (64 mg, 0.455 mmol) were
added and stirred at room temperature for 12 h. The reaction was terminated with water and EtOAc,

Molecules 2020, 25, 2484
12 of 14
dried over MgSO4 and concentrated under reduced pressure. The mixture was separated by column
1
chromatography (CH2Cl2:MeOH = 5:1) to give compound 10 (48 mg, 68%): H-NMR (500 MHz,
CDCl3/CD3OD = 3/1) δ 7.54–7.48 (m, 2H), 7.48–7.44 (m, 1H), 7.33 (dd, J = 7.0, 1.2 Hz, 2H), 7.26 (d, J =
8.1 Hz, 2H), 7.21 (d, J = 8.1 Hz, 2H), 6.23 (t, J = 2.2 Hz, 1H), 6.03 (d, J = 1.6 Hz, 1H), 6.01 (d, J = 1.6 Hz,
1H), 4.73 (s, 2H), 4.05 (s, 2H), 3.63–3.65 (m, 1H), 2.85 (ddd, J = 11.2, 7.8, 3.3 Hz, 2H), 2.47 (d, J = 13.7
Hz, 2H), 1.82 (dd, J = 14.8, 6.0 Hz, 2H), 1.67 – 1.62 (m, 2H); 13C NMR (125 MHz, CDCl3/CD3OD = 3/1)
δ 159.9, 158.4, 137.8, 134.1, 130.8, 129.8, 129.2, 128.7, 127.9, 111.2, 108.8, 103.2, 69.6, 62.9, 61.4, 53.9, 41.5,
31.8, 29.8; ESI-HRMS (M + H)+ m/z calcd for C26H30NO5S 468.1845, found 468.1829.
3.3. Sphingosine Kinase Activity Assay
SK 1/2 activity was measured using 20 μM PF-543 (1) and compounds 2–10 using an AdaptaTM
screening system (Thermo Fisher Scientific system, Waltham, MA, USA). The sphingosine kinase 1
activity assay used 0.04–0.16 ng SPHK1, 50 μM sphingosine lipid substrate in 32.5 mM HEPES pH
7.5, 0.005% BRIJ 35, 5 mM MgCl2, 0.5 mM ethylene glycol-bis(β-aminoethyl ether)-N,N,N′,N′-
tetraacetic acid (EGTA). The sphingosine kinase 2 activity assay detected 35 - 140 ng SPHK2, 50 μM
sphingosine lipid substrate in 32.5 mM HEPES pH 7.5, 0.5 mM EGTA, 1.5 mM MgCl2.
3.4. Cell Culture and Proliferation Assays
HT29 cells (Korean Cell Line Bank, Seoul, Korea) were maintained in RPMI (Biowest, Nuaillé,
France) media with 10% fetal bovine serum (FBS), 100 U/mL penicillin and 100 μg/mL streptomycin
at 37 °C in a humidified 5% CO2/95% air atmosphere. Cells were seeded in 96-well plates at a density
of 3000 cells/100 μL/well and incubated for 24 h. The cells were then incubated in culture medium
containing synthetic compounds. Following 24 h of incubation, the cell viability was determined
using a EZ-CYTOX kit (DaeilLab Service, Seoul, Korea) according to the manufacturer’s protocol (n
= 12).
3.5. Annexin-V Staining of PF-543 and Derivative 5
The cell apoptosis assay was determined using annexin V- fluorescein isothiocyanate (FITC)
(Biobud, Gyeonggi-do, Korea) and propedium iodide (PI) staining as described in the manufacturer’s
instructions (BioBud, Gyeonggi-do, Korea). Briefly, the cells were resuspended in binding buffer and
then incubated with annexin-V-FITC and propidium iodide at room temperature. After incubation,
stained cells were analyzed by MACSQuant Analyzer 10 Fow Cytometer (Miltenyi Biotec, Bergisch
Gladbach, Germany). The experiment was conducted three times independently (n = 6).
3.6. Molecular Modeling of PF-543 Derivative 5 Against SK1
Molecular modeling study of 5 against the SphK1 was performed using Schrödinger Suite 2019-
1 (Schrödinger, LLC, New York, NY, USA, 2019). The PF-543-bound crystal structure of SphK1 was
obtained from the Protein Data Bank (http://www.rcsb.org/pdb), the PDB code for which was 4V24
[16]. The protein preparation was revised using Protein Preparation Wizard in Maestro v11.9
(Schrödinger, NYC, NY, USA), and the receptor grid box was generated using a 25 × 25 × 25 Å cubic
size centered on complexed ligand. The ligand was minimized using an OPLS3e force field with a
dielectric constant value 80.0 in MacroModel v12.3 (Schrödinger, NYC, NY, USA). The ligand
docking was performed using the Glide v8.2 program (Schrödinger, NYC, NY, USA) with the
Standard Precision method. The figure of the proposed binding mode of C3 was created by Discovery
Studio 2018 (Dassault Systèmes, San Diego, CA, USA, 2018).
3.7. In Vitro Metabolic Stability of PF-543 and Derivative 5
Microsomal incubations were conducted in triplicate in 0.1 M potassium phosphate buffer (pH
7.4) in a clean 1.5 mL eppendorf tube. To evaluate reduced nicotinamide adenine dinucleotide
phosphate (NADPH)-dependent metabolism, PF-543, derivative 5 or Verapamil (positive control)
was incubated with pooled liver microsomes from human (HLM), dog (DLM), rat (RLM) and mouse

Molecules 2020, 25, 2484
13 of 14
(MLM) in the presence of an NADPH regenerating system in a final volume of 100 mL. The final
incubation mixtures contained 0.5 mg/mL HLM, 0.1 M potassium phosphate buffer (pH 7.4), and an
NADPH regenerating system (1 mM NADPH, 10 mM MgCl2). HLM was added and the mixture was
pre-incubated at 37 °C in a shaking incubator at approximately 350 rpm for 5 min under Thermo
mixer (Eppendorf., Hamburg, Germany). Reactions were initiated by the addition of 1 mM NADPH
and were then quenched by adding 40 μL of ice-cold acetonitrile containing 10 μM chlorproamide
(CPP) as an internal standard at 0, 30 min. The incubation mixtures were then centrifuged at 15,000×
g for 5 min at 4 °C. A 2 μL aliquot of the supernatant was directly injected into the LC-MS/MS system.
The LC-MS/MS system consisted of the Nexera XR HPLC system (Shimadzu Co., Kyoto, Japan)
coupled to the TSQ Vantage triple quadrupole mass spectrometer equipped with Xcalibur version
1.1.1 (Thermo Fisher Scientific Inc., Waltham, MA, USA).
3.8. Statistical Analysis
The data were presented as means ± SD. Non–parametric one–way ANOVA was applied to the
data with heterogeneous variance. Turkey’s post-procedures were conducted to determine
intergroup variation. The difference was considered significant if p < 0.05. Graph Pad Prizm 7
(GraphPad Sofrware, Inc., La Jolla, CA, USA) was used to analyze all the data.
4. Conclusions
In this study, we synthesized the derivatives of the tolyl group of PF-543 with benzene,
fluorobenzene, and phenol to improve the anticancer activity of PF-543. In addition, prolinol,
hydroxypyrrolidine, and piperidine were introduced into the headgroups of each backbone
derivative, and the SK1 inhibitory and anticancer activities of these synthesized compounds were
measured. The inhibitory effects of SK in compounds 4, 7, and 10 reduced when a piperidine
headgroup was introduced compared with those of PF-543 (1). All derivatives with a phenol
backbone (compounds 8–10) displayed reduced SK1 inhibitory effects. Only compound 8 showed an
inhibitory effect against SK2 alone. These results indicate that the tolyl group of PF-543 affects its SK
inhibitory effect. In contrast, compounds with a benzene and fluorobenzene backbone (2–7)
demonstrated anticancer activity similar to PF-543. In addition, the fluorine-substituted compound
5, with the same headgroup as PF-543, showed similar apoptotic effects. The molecular docking of
PF-543 and compound 5 did not reveal any difference in binding between the two compounds.
However, their microsomal stability was low in all tested animal species. Collectively, our results
indicate that, although the fluorobenzene backbone can replace the PF-543 backbone, it does not
improve its stability.
Despite the strong SK1 inhibitory effects of PF-543, various derivatives have not been developed
due to its low anticancer activity and structural instability. The PF-543 analogs reported by Pfizer and
other research groups provided only comparative information on the inhibitory effects of SK1/2;
therefore, it remains unknown if the derivatives improved anticancer activity. The purpose of this
study was to determine if the presence of the tolyl group in the PF-543 structure is required for its
anticancer activity. Our results show that the tolyl group did not significantly affect the SK1
inhibitory effects and anticancer activities of PF-543. Furthermore, synthesized PF-543 derivative did
not create additional structural stability. These results showed that it is possible to design a simplified
PF-543 analog in which the tolyl group has been removed. The structural stability of PF-543 could be
improved by designing derivatives in which a functional group other than the tolyl group is
modified. Further structural modification of other parts of PF-543 may be warranted to make it
suitable for medical use.
Author Contributions: T.L. and S.K. designed the compounds, S.-B.K. and J.-E.P. measured the metabolic
stability, D.J.B. and Y.K. synthesized compounds, S.B.K., S.W.K., S.H.K., Y.S.O., and E.-Y.P. did the biological
studies, J.-Y.L did the molecular modeling studies, H.S.M., D.J.B. and E.-Y.P wrote this paper. All authors have
read and agreed to the published version of the manuscript.

Molecules 2020, 25, 2484
14 of 14
Funding: This research was supported by Basic Science Research Program through the National Research
Foundation of Korea (NRF) funded by the Ministry of Science, ICT & Future Planning (2018R1C1B6001892 and
2017R1D1A1B03032529). This work was carried out by the Convergence Research Laboratory established by the
Mokpo National University (MNU) Innovation Support Project.
Conflicts of Interest: All authors declare no financial/commercial conflict of interests.
References
1.
2.
Ogretmen, B. Sphingolipid metabolism in cancer signalling and therapy. Nat. Rev. Cancer 2018, 18, 33–50.
Pyne, S.; Adams, D.R.; Pyne, N.J. Sphingosine 1-phosphate and sphingosine kinases in health and disease:
Recent advances. Prog. Lipid Res. 2016, 62, 93–106.
3.
French, K.J.; Zhuang, Y.; Maines, L.W.; Gao, P.; Wang, W.; Beljanski, V.; Upson, J.J.; Green, C.L.; Keller, S.N.;
Smith, C.D. Pharmacology and antitumor activity of ABC294640, a selective inhibitor of sphingosine
kinase-2. J. Pharmacol. Exp. Ther. 2010, 333, 129–139.
4.
5.
Pitman, M.R.; Costabile, M.; Pitson, S.M. Recent advances in the development of sphingosine kinase
inhibitors. Cell. Signal. 2016, 28, 1349–1363.
Britten, C.D.; Garrett-Mayer, E.; Chin, S.H.; Shirai, K.; Ogretmen, B.; Bentz, T.A.; Brisendine, A.; Anderton,
K.; Cusack, S.L.; Maines, L.W.; et al. A phase I study of ABC294640, a first-in-class sphingosine kinase-2
inhibitor, in patients with advanced solid tumors. Clin. Cancer Res. 2017, 23, 4642–4650.
6.
7.
8.
9.
US
National
Library
of
Medicine.
ClinicalTrials.gov
2016.
Available
online:
https://clinicaltrials.gov/ct2/show/NCT02939807 (accessed on 23 April 2020)
Rex, K.; Jeffries, S.; Brown, M.L.; Carlson, T.; Coxon, A.; Fajardo, F.; Frank, B.; Gustin, D.; Kamb, A.; Kassner,
P.D.; et al. Sphingosine kinase activity is not required for tumor cell viability. PLoS One. 2013, 8, e68328.
Sanllehi, P.; Abad, J.L.; Casas, J.; Delgado, A. Inhibitors of sphingosine-1-phosphate metabolism
(sphingosine kinases and sphingosine-1-phosphate lyase). Chem. Phys. Lipids 2016, 197, 69–81.
Pyne, S.; Bittman, R.; Pyne, N.J. Sphingosine kinase inhibitors and cancer: Seeking the golden sword of
hercules. Cancer Res. 2011, 71, 6576–6582.
10. Zhang, L.; Wang, H.D.; Ji, X.J.; Cong, Z.X.; Zhu, J.H.; Zhou, Y. FTY720 for cancer therapy. Oncol. Rep. 2013,
30, 2571–2578.
11. Tonelli, F.; Lim, K.G.; Loveridge, C.; Long, J.; Pitson, S.M.; Tigyi, G.; Bittman, R.; Pyne, S.; Pyne, N.J. FTY720
and (S)-FTY720 vinylphosphonate inhibit sphingosine kinase 1 and promote its proteasomal degradation
in human pulmonary artery smooth muscle, breast cancer and androgen-independent prostate cancer cells.
Cell. Signal. 2010, 22, 1536–1542.
12. Schnute, M.E.; McReynolds, M.D.; Kasten, T.; Yates, M.; Jerome, G.; Rains, J.W.; Hall, T.; Chrencik, J.; Kraus,
M.; Cronin, C.N.; et al. Modulation of cellular S1P levels with a novel, potent and specific inhibitor of
sphingosine kinase-1. Biochem. J. 2012, 444, 79–88.
13. Ju, T.; Gao, D.; Fang, Z.Y. Targeting colorectal cancer cells by a novel sphingosine kinase 1 inhibitor PF-543.
Biochem. Biophys. Res. Commun. 2016, 470, 728–734.
14. Tassaneeyakul, W.; Birkett, D.J.; Edwards, J.W.; Veronese, M.E.; Tassaneeyakul, W.; Tukey, R.H.; Miners,
J.O. Human cytochrome P450 isoform specificity in the regioselective metabolism of toluene and o-, m- and
p-Xylene. J. Pharmacol. Exp. Ther. 1996, 276, 101–108.
15. Schnute, M.E.; McReynolds, M.D.; Carroll, J.; Chrencik, J.; Highkin, M.K.; Iyanar, K.; Jerome, G.; Rains, J.W.;
Saabye, M.; Scholten, J.A.; et al. Discovery of a potent and selective sphingosine kinase 1 inhibitor through
the molecular combination of chemotype-distinct screening hits. J. Med. Chem. 2017, 60, 2562–2572.
16. Wang, J.; Knapp, S.; Pyne, N.J.; Pyne, S.; Elkins, J.M. Crystal structure of sphingosine kinase 1 with PF-543.
ACS Med. Chem. Lett. 2014, 5, 1329–1333.
17. Kim, S.W.; Lee, T.; Oh, Y.S.; Shin, S.M.; Lee, J.-Y.; Kim, S.; Baek, D.J.; Park, E.-Y. Synthesis and biological
evaluation of PF-543 derivative containing aliphatic side chain. Chem. Pharm. Bull. 2019, 67, 599–603.
18. Kim, S.W.; Lee, T.; Lee, J.-Y.; Kim, S.; Jun, H.-S.; Park, E.-Y.; Baek, D.J. Synthesis and biological evaluation
of PF-543 derivative. Lett. Org. Chem. 2019, 16, 2–5.
Sample Availability: Samples of the compounds are not available.
© 2020 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
(CC BY) license (http://creativecommons.org/licenses/by/4.0/).
