Crystal-to-crystal photodimerization of trans-cinnamamides

Article abstract of DOI:10.1107/S0108768100002329

In the crystals of trans-4-methylcinnamamide, C₁₀H₁₁NO (I), trans-4-chlorocinnamamide, C₉H₈ClNO (II), trans-3-(2-thienyl)acrylamide, C₇H₇NOS (III), and trans-cinnamamide, C₉H₉NO (IV), the shortest intermolecular C...C distances between the C=C double bonds are 3.670 (2), 3.632 (2), 3.762 (3) and 4.120 (2) A, respectively, for the pair of molecules related by a center of symmetry. The structure analysis was also carried out for trans-2-(p-chlorophenyl)-cis-4-(p-chlorophenyl)-1-trans-3-diamidocyclobutane, C₁₈H₁₆Cl₂-N₂O₂ (V), which is the α-type photodimer of (II). The N -H...O hydrogen-bond networks in (I)-(III) are composed of two-dimensional pleated sheets, and those in (IV) and (V) of one-dimensional flat ribbons. The single crystals of (I), (II) and (IV) were photoirradiated with a 250 W ultra-high-pressure mercury lamp through a band-pass filter or a long-pass filter for 2-5 h. The photodimer was produced in each crystal with retention of the single-crystal form. The populations of the dimers were converged to 86.2 (4), 48.4 (6) and 4.5 (2)% in the refinement of the crystals after photoirradiation, (I′), (II′) and (IV′), respectively. Although the intermolecular N-H...O hydrogen-bond network remained in (I′) and (II′), the network was partly broken in (IV′) in the process of photoreaction.

Full text of DOI:10.1107/S0108768100002329

research papers
Acta Crystallographica Section B
Structural
Crystal-to-crystal photodimerization of
Science
trans-cinnamamides
ISSN 0108-7681
a
Received 22 July 1999
Accepted 8 February 2000
Hiroyuki Hosomi, Yoshikatsu
In the crystals of trans-4-methylcinnamamide, C H NO (I),
10 11
b
a
Ito and Shigeru Ohba *
trans-4-chlorocinnamamide, C
nyl)acrylamide, C H NOS (III), and trans-cinnamamide,
H ClNO (II), trans-3-(2-thie-
9 8
7
7
C H NO (IV), the shortest intermolecular CÁ Á ÁC distances
9
9
a
Department of Chemistry, Faculty of Science
between the C C double bonds are 3.670 (2), 3.632 (2),
Ê
.762 (3) and 4.120 (2) A, respectively, for the pair of
and Technology, Keio University, Hiyoshi 3,
Kohoku-ku, Yokohama 223-8522, Japan, and
3
molecules related by a center of symmetry. The structure
b
Department of Synthetic Chemistry and
Biological Chemistry, Faculty of Engineering,
Kyoto University, Kyoto 606-8501, Japan
analysis was also carried out for trans-2-(p-chlorophenyl)-cis-
4
-(p-chlorophenyl)-1-trans-3-diamidocyclobutane, C H Cl -
18 16 2
N O (V), which is the ꢀ-type photodimer of (II). The NÐ
2
2
HÁ Á ÁO hydrogen-bond networks in (I)±(III) are composed of
two-dimensional pleated sheets, and those in (IV) and (V) of
one-dimensional ¯at ribbons. The single crystals of (I), (II)
and (IV) were photoirradiated with a 250 W ultra-high-
pressure mercury lamp through a band-pass ®lter or a long-
pass ®lter for 2±5 h. The photodimer was produced in each
crystal with retention of the single-crystal form. The popula-
tions of the dimers were converged to 86.2 (4), 48.4 (6) and
Correspondence e-mail: ohba@chem.keio.ac.jp
4
tion, (I ), (II ) and (IV ), respectively. Although the inter-
.5 (2)% in the re®nement of the crystals after photoirradia-
0
0
0
molecular NÐHÁ Á ÁO hydrogen-bond network remained in
0 0 0
I ) and (II ), the network was partly broken in (IV ) in the
process of photoreaction.
(
1
. Introduction
Solid-state [2 + 2] photodimerization of trans-cinnamic acids
was extensively investigated by Schmidt and coworkers to
establish the topochemical principles (Cohen & Schmidt, 1964;
Cohen et al., 1964; Schmidt, 1964). The crystal structures and
hydrogen-bond networks of the trans-cinnamamide (IV) and
the 4-chloro derivative (II) were also investigated (Rabino-
vich, 1969; Leiserowitz & Schmidt, 1969) as well as the [2 + 2]
photoreaction of (I)±(III) (Hung et al., 1972). An exposure of
a single-crystal of (IV) to sunlight deformed the X-ray
diffraction peaks, suggesting lattice distortion owing to
photoreaction (Osaki & Schmidt, 1972). The photoreactivities
of (I)±(IV) redetermined in the present study are shown in
Table 1. The yields of ꢀ-type dimers of (I)±(III) were 97±100%
after photoirradiation for 20 h. On the other hand, the yield of
the dimer was only 18% for (IV). The CÁ Á ÁC distance between
Ê
the C C double bonds in (IV) was reported to be 4.109 (4) A
(Iwamoto et al., 1989), which is almost the maximum limit for
the solid-state reaction. Moreover, the intermolecular NÐ
HÁ Á ÁO hydrogen-bond network in (IV) is different from that
in (II). The hydrogen-bond networks in (I) and (III) are
expected to be similar to that of (II) (Leiserowitz & Schmidt,
1969).
#
2000 International Union of Crystallography
Printed in Great Britain ± all rights reserved
6
82 Hosomi et al. ꢀ trans-Cinnamamides
Acta Cryst. (2000). B56, 682±689

research papers
Table 1
Photoreactivities of trans-cinnamamides in the solid state.
(III): An orientational disorder of the
thiophene ring was treated according to
the convenient method by Pelletier &
Brisse (1994), assuming that the S1 and
C10* atoms (and the S1* and C10 atoms)
share the same positional and displace-
ment parameters. The site occupation
factor of S1 was re®ned to 0.825 (3). The
positional parameters of the H10 and
H10* atoms were calculated and ®xed
with Uiso (H) = 1.2Ueq (parent atom).
Compound
(I)
(II)
(III)
(IV)
Aromatic moiety
Radiation time (h)²
Product yield (%)³
4-Me-Ph
20
100
4-Cl-Ph
20
100
2-Thienyl
20
97
Ph
20
18
²
Powdered crystals were spread between two Pyrex plates and irradiated with a 400 W high-pressure mercury lamp
under an argon stream at room temperature. ³ Only the ꢀ-truxillamides were obtained. The yields were estimated by
NMR spectra.
A single-crystal-to-single-crystal transformation is an
excellent method to observe in situ the reactions in the solid
state (Suzuki, 1996; Tokitoh et al., 1998; Hosomi et al., 1998;
Leibovitch et al., 1998; Harada et al., 1999; Hosomi et al., 2000,
Other H atoms were re®ned isotropically.
0
Structure (I ): A single crystal of (I) was photoirradiated
with the 250 W ultra high-pressure Hg lamp through a band-
pass ®lter BP365 (T = 50% at 365 nm, half-height width
10 nm). The photoreaction was followed by measuring the
lattice constants repeatedly on a four-circle diffractometer.
The ꢁvalue increased continuously and became obtuse from
ꢁ
acute [87.69 (2) ]. The X-ray diffraction ability of the crystal
decreased as the reaction proceeded and the X-ray measure-
ment became impossible after photoirradiation for 10 h. To
ensure suf®cient resolution of the structure analysis, several
crystals were photoirradiated for 5 h and X-ray intensities
were measured on a crystal whose typical peak half-width was
ꢁ
0
8
.45 . The population of the dimer was converged to
6.2 (4)%, and that of the monomer to 13.8 (4)%. The posi-
and references therein). Photoirradiation far into the long
wavelength absorption tail is effective for protecting the single
crystals from degradation by the photoreaction (Enkelmann et
al., 1993; Novak et al., 1993). This technique has been applied
to the [2 + 2] photodimerization of trans-cinnamamides to see
whether the photoreaction proceeds keeping the inter-
molecular hydrogen bonds.
tional and isotropic displacement parameters of the atoms of
the monomer were ®xed to the corresponding values of (I).
For the dimer, the non-H atoms were re®ned anisotropically.
Structure (II ): A single crystal of (II) was photoirradiated
for 6 h with a 250 W ultra-high-pressure Hg lamp through a
0
2. Experimental
trans-4-Chlorocinnamamide (II) and trans-cinnamamide (IV)
were commercially available. trans-4-Methylcinnamamide (I)
and trans-3-(2-thienyl)acrylamide (III) were prepared
according to the method reported (Hung et al., 1972; Mason &
Nord, 1951). The ꢀ-type photodimer (V) was prepared by the
solid-state reaction of (II). The crystals were grown by slow
evaporation from ethanol (I), 2-propanol/ethanol (II),
methylene chloride (III) and chloroform (IV)±(V) solutions.
Crystal data, experimental conditions and re®nement
1
details are listed in Table 2. Absorption corrections were
made by integration from crystal shape (Coppens et al., 1965)
for (II)±(III), and by -scan for (V) (North et al., 1968).
Selected bond distances and angles are listed in Table 3, and
the hydrogen-bonding geometry in Table 4.
Structure (I): There is a rotational disorder of the methyl-H
atoms. Two sets of positions [H12A/H12C and H12*A/H12*C]
were assumed with site occupancy factor 50% each. Structure
Figure 1
(a) The structure of a pair of molecules in (I) related by a center of
symmetry; (b) the disordered structure in (I ) which consists of the
monomer (open bonds) 13.8 (4)% and the dimer (solid bonds) 86.2 (4)%.
Displacement ellipsoids are plotted at the 30% probability level. H atoms
are shown as spheres of arbitrary size.
0
1
Supplementary data for this paper are available from the IUCr electronic
archives (Reference: OA0024). Services for accessing these data are described
at the back of the journal.
Acta Cryst. (2000). B56, 682±689
Hosomi et al. ꢀ trans-Cinnamamides 683

research papers
Table 2
Experimental details.
Atomic scattering factors were taken from International Tables for Crystallography (1992, Vol. C). For all compounds, data collection and cell re®nement:
MSC/AFC Diffractometer Control Software (Molecular Structure Corporation, 1993); data reduction: TEXSAN (Molecular Structure Corporation, 1999); program
used to solve structure: SIR92 (Altomare et al., 1994); program used to re®ne structure: SHELXL97 (Sheldrick, 1997); software used to prepare material for
publication: TEXSAN and ORTEPII (Johnson, 1976).
0
0
