Comparing substrate specificity of two UDP-sugar pyrophosphorylases and efficient one-pot enzymatic synthesis of UDP-GlcA and UDP-GalA

Article abstract of DOI:10.1016/j.carres.2015.04.001

Uridine 5′-diphosphate-glucuronic acid (UDP-GlcA) and UDP-galacturonic acid (UDP-GalA), the unique carboxylic acid-formed sugar nucleotides, are key precursors involved in the biosynthesis of numerous cell components. Limited availability of those components has been hindering the development of efficient ways towards facile synthesis of bioactive glycans such as glycosaminoglycans. In current study, we biochemically characterized two UDP-sugar pyrophosphorylases from Arabidopsis thaliana (AtUSP) and Bifidobacterium infantis ATCC15697 (BiUSP), and compared their activities towards a panel of sugar-1-phosphates and derivatives. Both enzymes showed significant pyrophosphorylation activities towards GlcA-1-phosphate, and AtUSP also exhibited comparable activity towards GalA-1-phosphate. By combining with monosaccharide-1-phosphate kinases, we have developed an efficient and facile one-pot three-enzyme approach to quickly obtain hundreds milligrams of UDP-GlcA and UDP-GalA.

Full text of DOI:10.1016/j.carres.2015.04.001

Accepted Manuscript
Comparing substrate specificity of two UDP-sugar Pyrophosphorylases and Efficient
One-pot Enzymatic Synthesis of UDP-GlcA and UDP-GalA
Yuxi Guo, Junqiang Fang, Tiehai Li, Xu Li, Cheng Ma, Xuan Wang, Peng G. Wang,
Lei Li
PII:
S0008-6215(15)00102-0
10.1016/j.carres.2015.04.001
CAR 6973
DOI:
Reference:
To appear in: Carbohydrate Research
Received Date: 23 November 2014
Accepted Date: 3 March 2015
Please cite this article as: Guo Y, Fang J, Li T, Li X, Ma C, Wang X, Wang PG, Li L, Comparing
substrate specificity of two UDP-sugar Pyrophosphorylases and Efficient One-pot Enzymatic Synthesis
of UDP-GlcA and UDP-GalA, Carbohydrate Research (2015), doi: 10.1016/j.carres.2015.04.001.
This is a PDF file of an unedited manuscript that has been accepted for publication. As a service to
our customers we are providing this early version of the manuscript. The manuscript will undergo
copyediting, typesetting, and review of the resulting proof before it is published in its final form. Please
note that during the production process errors may be discovered which could affect the content, and all
legal disclaimers that apply to the journal pertain.

ACCEPTED MANUSCRIPT

ACCEPTED MANUSCRIPT
Comparing substrate specificity of two UDP-sugar Pyrophosphorylases and
Efficient One-pot Enzymatic Synthesis of UDP-GlcA and UDP-GalA
†
‡
†
†
†
†
,†,‡
,†
Yuxi Guo, Junqiang Fang, Tiehai Li, Xu Li, Cheng Ma, Xuan Wang, Peng G. Wang* , and Lei Li,*
†
Department of Chemistry and Center for Diagnostics & Therapeutics, Georgia State University, Atlanta, GA
3
0303
‡
National Glycoengineering Research Center, Shandong University, Jinan, Shandong, 250100, China
*
Corresponding author: pwang11@gsu.edu, or lli22@gsu.edu
Abstract
Uridine 5’-diphosphate-glucuronic acid (UDP-GlcA) and UDP-galacturonic acid (UDP-GalA), the
unique carboxylic acid-formed sugar nucleotides, are key precursors involved in the biosynthesis of
numerous cell components. Limited availability of those components has been hindering the
development of efficient ways towards facile synthesis of bioactive glycans such as
glycosaminoglycans. In current study, we biochemically characterized two UDP-sugar
pyrophosphorylases from Arabidopsis thaliana (AtUSP) and Bifidobacterium infantis ATCC15697
(BiUSP), and compared their activities towards a panel of sugar-1-phosphates and derivatives. Both
enzymes showed significant pyrophosphorylation activities towards GlcA-1-phosphate, and AtUSP
also exhibited comparable activity towards GalA-1-phosphate. By combining with monosaccharide-1-
phosphate kinases, we have developed an efficient and facile one-pot three-enzyme approach to
quickly obtain hundreds milligrams of UDP-GlcA and UDP-GalA.
Key words: UDP-GalA, UDP-GlcA, UDP-sugar pyrophosphorylase, Synthesis

ACCEPTED MANUSCRIPT
1
. Introduction
Hexuronic acids (HexAs), a class of sugar acids with both carbonyl and carboxylic acid functional
groups, are the oxidation products of the corresponding monosaccharides. Glucuronic acid (GlcA) is
1
one of the most commonly found HexAs in the plant and animal kingdoms. It is also prevalent in
2
carbohydrate chains of proteoglycans. Galacturonic acid (GalA) is a major sugar residue of plant
3
pectic polysaccharides and a minor component of certain plant arabinogalactan proteins. GalA is also
4
,5
found in various cell surface polysaccharides of different gram-negative bacteria, as well as capsular
6
polysaccharide of the gram-positive human pathogens, such as type I Streptococcus pneumonae.
Because of the biological significance and structure complexity, glycans containing HexAs have
7
-9
attracted considerable attention in past decades. One of the major bottlenecks in basic research and
application of these components is the limited and cost-effective availability of uridine 5’-diphosphate
glucuronic acid (UDP-GlcA) and uridine 5’-diphosphate galacturonic acid (UDP-GalA), the active
forms of corresponding monosaccharides. UDP-GlcA and UDP-GalA are essential glycosyl donors for
glycosyltransferases in the biosynthesis of various cell components including glycosaminoglycans,
1
0,11
some N- and O-linked glycans, glycosphingolipids, pectins, etc.
Recently, several chemical or
coupled enzymatic approaches have been developed for the synthesis of UDP-GlcA and UDP-
1
2,13
GalA.
However, low yield, tedious steps and strict condition requirements have restricted the
1
4
application of these approaches in large scale sugar nucleotide preparation. Therefore, a simple, cost-
effective and efficient approach for the preparation of UDP-GlcA and UDP-GalA is highly desirable
for subsequent glycosyltransferase-catalyzed reactions.
Enzymatic synthesis, which mimics the biosynthesis pathway, is considered more attractive with
advantages of high conversion rate and mild reaction conditions. As shown in Figure 1, the de novo
biosynthesis of UDP-GlcA initiates from glucose-6-phosphate (Glc-6-P), an intermediate of the
glycolytic pathway. Three enzymatic catalyzed steps were involved, including the equilibrium
conversion of Glc-6-P and Glc-1-P, the pyrophosphorylation step to yield UDP-Glc, and the

ACCEPTED MANUSCRIPT
oxidoreduction step catalyzed by UDP-Glc 6’-oxidoreductase. The complication of the pathway, the
+
similarities between the final product and intermediates, as well as the consuming of expensive NAD
+
or NADP have highly limited the application of such a pathway in large scale UDP-GlcA preparation.
The de novo biosynthetic pathway of UDP-GalA is even more complicated (Fig. 1).
In contrast, salvage biosynthetic pathways of sugar nucleotides, usually involving only two
reactions (sugar-1-phosphate kinase catalyzed formation of sugar-1-P from monosaccharide and ATP,
and NDP-sugar pyrophosphorylase catalyzed formation of NDP-sugar from sugar -1-P and NTP) were
found much more practical in large scale synthesis of sugar nucleotides. Using recombinant enzymes
from salvage pathways, we have successfully developed efficient approaches for 100 mg scale
1
5-22
synthesis of UDP-Gal, UDP-GlcNAc, UDP-GalNAc, GDP-Fuc, GDP-Man and derivatives.
Recently, a salvage biosynthetic pathway of UDP-GlcA had been discovered in Arabidopsis thaliana
2
3
(
Fig. 1). In such a pathway, GlcA is first catalyzed by a glucuronokinase (AtGlcAK) to form GlcA-1-
2
+
P in the presence of ATP and Mg . Subsequently, a UDP-sugar pyrophosphorylase (AtUSP) catalyzes
2
+ 24,25
the conversion of GlcA-1-P into UDP-GlcA in the presence of UTP and Mg .
A galacturonokinase
AtGalKA) was also found in A. thaliana implies that a salvage biosynthetic way of UDP-GalA may
also exist.
In this study, we cloned and characterized a UDP-sugar pyrophosphorylase from Bifidobacterium
2
3
(
infantis ATCC15697 (BiUSP) which exhibited significant activity towards GlcA-1-P. In addition, we
codon optimized the gene encoding AtUSP, and performed heterogeneous overexpression. AtUSP
showed significant activities towards both GlcA-1-P and GalA-1-P. Furthermore, substrate specificity
study exhibited that both USPs were promiscuous towards a panel of sugar-1-phosphates. Finally, by
combing sugar-1-P kinases with USPs as well as pyrophosphatase, we developed an efficient one-pot
three-enzyme approach to prepare hundreds of milligrams of UDP-GlcA and UDP-GalA.

ACCEPTED MANUSCRIPT
2
2
. Results and discussion
.1 Gene cloning, expression, and purification of AtGlcAK, AtUSP, and BiUSP
Genes encoding AtGlcAK and AtUSP from A. thaliana were codon optimized (see DNA
sequences in supporting information) and synthesized to achieve better heterologous expression in E.
coli. The synthesized genes were cloned into pQE80L, a tightly controlled E. coli protein expression
vector with a T5 promoter. Given that inductions were performed at a low temperature (16 °C) and
with a low concentration of IPTG (0.2 mM), AtGlcAK and AtUSP were expressed almost entirely in
soluble form. As shown in Figure 2, after one-step Ni-NTA affinity chromatography, both enzymes
6
with N-terminal His -tag were purified to 90% with high yields (90 mg for AtGlcAK, 42 mg AtUSP
per L of LB cultures). The apparent molecular weights of the enzymes on SDS-PAGE (Fig. 2, Lane 1
&
2) are consistent with theoretical values.
A bacterial UDP-sugar pyrophosphorylase gene, Blon_1169, was cloned from B. infantis ATCC
1
5697. The enzyme (BiUSP) encoded by this gene is highly identical (98%) to a previously reported
2
6
UDP-sugar pyrophosphorylase, BLUSP. BiUSP was expressed and purified with a C-terminal His -
6
tag followed the abovementioned methods. The yield of pure BiUSP from 1 L of cultures is 43 mg. An
approximate molecular weight of 60 KDa was observed on SDS-PAGE (Fig. 2, Lane 4), consistent
with theoretical value (58 KDa).
2
.2 Pyrophosphorylase activities of AtUSP and BiUSP
Capillary Electrophoresis (CE) was used to analyze the formation of UDP-sugars. Retention times
of 21.7, 18.2, 16.6 min were observed on CE profiles for UTP, UDP-GlcA and UDP-GalA standards
Fig 3A, B & C), respectively. The results shows that BiUSP could catalyze the formation of UDP-
(
GlcA from GlcA-1-P and UTP efficiently (Fig. 3D), whereas the formation of UDP-GalA was not
clearly observed (CE profile not shown), indicating that the C-4 hydroxyl group may be necessary for
BiUSP recognition. This is opposite with results yielded form activity assays towards Glc-1-P and Gal-

ACCEPTED MANUSCRIPT
1
-P, where both substrate can be well accepted (Table 2). One possible explanation could be the bulky
carboxylic acid group on C-6 position altered the configuration of C-4 hydroxyl group, makes GalA
not tolerable by BiUSP.
On the other hand, AtUSP could efficiently (68% and 65% towards GlcA-1-P and GalA-1-P)
catalyze the formation of both UDP-GlcA and UDP-GalA (Fig. 3E & F). The activity of BiUSP and
AtUSP towards GlcA-1-P are comparable (Fig. 3D & E). It is worth to note that AtUSP can be stored
for up to 6 months at -20 °C without significant activity loss, whereas BiUSP showed dramatically
activity decrease after 6 months storage under the same condition.
Freshly prepared AtUSP or BiUSP was applied in time course experiment and kinetics studies. As
shown in Figure 4, time course results implies that for AtUSP, the formation rate of UDP-GalA is
slightly lower than that of UDP-GlcA. In kinetics studies, to ensure initial reaction rates, enzyme
dilutions were selected so that less than 15% of substrate conversion was achieved within 5 min for
each reaction. Kinetic parameters were calculated according to Lineweaver–Burk equation (Table 1).
-3
-3
The K value of AtUSP towards GlcA-1-P and GalA-1-P are 2.36 × 10 µM and 5.50 × 10 µM,
m
indicates that AtUSP has a higher affinity for GlcA-1-P that GalA-1-P. The kcat/K
m
values of AtUSP
towards GlcA-1-P is 1.8 times as that of GalA-1-P, implies that AtUSP is more efficient for the
3
-1
-1
pyrophosphorylation of GlcA-1-P. The k /K values of AtUSP (4.66 × 10 s µM ) and BiUSP (4.72
cat
m
3
-1
-1
×
10 s µM ) towards GlcA-1-P are similar, indicating they are equally efficient in the synthesis of
UDP-GlcA. The kinetics of reverse reactions (hydrolysis of UDP-GlcA and UDP-GalA) (Table 1)
revealed that AtUSP and BiUSP are equally active towards UDP-GlcA, whereas only AtUSP can
catalyze the hydrolysis of UDP-GalA. Such results are consistent with that of forward reactions
(formation of UPD-GlcA and UDP-GalA).
2
.3 Substrate specificity study of AtUSP and BiUSP towards sugar-1-phosphates

ACCEPTED MANUSCRIPT
It was previously reported that AtUSP possessed relaxed substrate specificity towards sugar-1-
phosphate. For example, it could well accept Gal-1-P, Glc-1-P, 4-deoxy-4-azido-Gal-1-P,
D
-Fuc-1-P,
To further investigate the substrate specificities of AtUSP and BiUSP,
the specific activities towards a panel of sugar-1-phosphates were measured. Not surprisingly, BiUSP
2
1,24,25
L-Ara-1-P, and Xyl-1-P.
2
6
exhibited similar substrate specificity as BLUSP towards sugar-1-phosphates (Table 2). In addition,
both AtUSP and BiUSP showed broad substrate specificities, but towards partially different sugar-1-
phosphates. For example, AtUSP are highly active towards GlcA-1-P, GalA-1-P, Glc-1-P, Gal-1-P,
Fuc-1-P, 2-deoxy-Glc-1-P, 2-deoxy-Gal-1-P, whereas BiUSP are highly active towards GlcA-1-P, Glc-
-P, Gal-1-P, Man-1-P, 2-deoxy-Glc-1-P, and 2-deoxy-2-amino-Glc-1-P. Such information are of great
importance in applying the USPs in large scale synthesis of UDP-sugar and derivatives.
D-
1
2
.4 Preparation and characterization of UDP-GlcA and UDP-GalA
Given the stability and efficiency, AtUSP was chosen for hundreds milligrams scale synthesis of
UDP-HexA. As shown in Figure 5, a one-pot three enzyme approach was employed. In the case of
UDP-GlcA preparation, the monosaccharide GlcA was first converted into GlcA-1-P catalyzed by
2
3
AtGlcAK, the glucuronokinase from A. thaliana. The formation of UDP-GlcA was then achieved by
2
+
AtUSP catalyzed reaction in the presence of UTP, and Mg . Since UDP-sugar pyrophosphorylases
3
catalyzed relations are usually reversible, a pyrophosphatase from E. coli (EcPpA) was added to
2
0
digest the diphosphate byproduct. The same as previously proved, addition of EcPpA greatly
improved the final yield (207 mg pure UDP-GlcA in a yield of 89%) by driving the reaction forward.
The synthesis of UDP-GalA was performed following the same route, except that AtGlcAK was
substituted by BiGalK, a promiscuous galactokinase exhibiting phosphorylation activity towards
2
7
GalA. The total yield of UDP-GalA after P2 purification was 70% (162 mg).
.4.1 Spectroscopic data of Uridine 5’-diphosphate glucuronic acid
HRMS (ESI): Calcd 580.0343 for C15 ; found: 579. 0256 [M-H ] ;
2
+
-
22 2 18 2
H N O P

ACCEPTED MANUSCRIPT
1
H NMR (400 MHz, D
2
O): δ 3.51 (t, J = 9.6 Hz, 1 H), 3.57-3.60 (m,1 H), 3.74 (s,1 H), 3.79 (t, J = 9.6
Hz, 1H), 4.14 (d, J = 10.4 Hz, 1H), 4.20-4.29 (m,2 H), 4.37-4.38 (m,2 H), 5.62 (dd, J = 2.8 Hz, J = 7.2
1
3
Hz,1 H), 5.97-5.99 (m,2 H), 7.95 (d, J = 8.0 Hz, 1 H); C NMR (100 MHz, D
2
O): δ 58.33, 63.95 (JC-
P= 20.4 Hz), 68.65, 70.37 (J = 33.6 Hz), 70.85, 71.58, 72.02, 72.77, 82.27 (J = 35.6 Hz), 87.27,
C-P
C-P
31
9
4.36 (J = 26.0 Hz), 101.68, 140.56, 150.84, 165.23; P NMR (162 MHz, D O): δ -12.06, -10.40;
C-P 2
2
.4.2 Spectroscopic data of Uridine 5’-diphosphate galacturonic acid
+
-
HRMS (ESI): Calcd 580.0343 for C H N O P ; found: 579. 0258 [M-H ] ;
1
5
22
2
18 2
1
H NMR (400 MHz, D O): δ 3.83 (d, J = 10.4 Hz, 1 H), 3.98 (dd, J = 3.2 Hz, J = 10.4 Hz,1 H), 4.17-
2
4
.22 (m,2 H), 4.29-4.32 (m,2 H), 4.36-4.37 (m,2 H), 4.53 (s,1 H), 5.68-5.69 (m,1 H), 5.97-5.99 (m,2
1
3
H), 7.96 (d, J = 8.0 Hz, 1 H); C NMR (100 MHz, D
2
O): δ 58.31, 63.91 (JC-P= 16.0 Hz), 67.50 (JC-P
=
2
1
9.2 Hz), 68.32, 68.63, 69.57, 71.70, 72.78, 82.28 (J = 35.6 Hz), 87.25, 94.71 (J = 20.4 Hz),
C-P
C-P
3
1
01.67, 140.57, 150.84, 165.23; P NMR (162 MHz, D O): δ -11.90, -10.35; HRMS (ESI):
2
3
. Conclusion
In summary, we have biochemically characterized two highly efficient UDP-sugar
pyrophosphorylases (AtUSP and BiUSP) for the purpose of large scale UDP-HexA preparation. Genes
or expression conditions were optimized to obtain high yields of enzymes (40-90 mg per L culture).
Both enzymes showed comparable activities towards GlcA-1-P, whereas only AtUSP exhibited
activity towards GalA-1-P. Specific activity study revealed that both USPs possessed broad substrate
specificity, but towards partially different sugar-1-phosphates. In addition, we have developed a one-
pot three-enzyme approach for efficient and rapid preparation of UDP-GlcA and UDP-GalA starting
from inexpensive monosaccharides and nucleotides. Using such an approach, 207 and 162 mgs of
UDP-GlcA and UDP-GalA were prepared within one week.
4
. Experimental section

ACCEPTED MANUSCRIPT
4
.1 Materials
All chemical reagents were purchased from Sigma unless otherwise noted. Ni-NTA agarose was
2
0
27
27
20
purchased from Qiagen. Talose-1-P,
D-Fucose-1-P, 2-deoxy-Gal-1-P, 2-deoxy-Glc-1-P were
prepared as previously described. The preparation of 6-deoxy-6-azido-Gal-1-P will be reported
subsequently. Codon optimized gene of AtGlcAK, AtUSP were synthesized by Genscript (Piscataway,
NJ). Genomic DNA of B. infantis ATCC 15697 was purchase from ATCC. E. coli DH5α and BL21
(DE3), as well as vector pET22b were purchased from EMD Millipore (Bilerica, MA). Vector
pQE80Lwas purchased from Qiagen (Germantown, MD). BiGalK expression E. coli strain was kept by
our group.
4
.2 Molecular Cloning, Protein Expression and Purification
The glucuronokinase gene (AtGlcAK) and UDP-sugar pyrophosphorylase gene (AtUSP) from A.
thaliana was codon optimized and synthesized with restriction sites (SacI and HindIII) (see supporting
information for optimized DNA sequences). The genes were then cleaved by SalI and HindIII, and
inserted into pQE80L pretreated with corresponding restriction enzymes. The UDP-sugar
pyrophosphorylase gene (BiUSP, Blon_1169) from B. infantis was amplified by PCR using B. infantis
ATCC15697 genomic DNA as templates. Primers used are, Blon_1169F:
GAGCATATGACCGAAATAAACGATAAGGCC and Blon_1169R:
TATCTCGAGCACCCAATCGTCCGGTTCGAT. Yielded PCR fragments were digested with NdeI
and HindIII and subsequently inserted into pET22b pretreated with corresponding enzymes. The
recombinant plasmids were verified by DNA sequencing and transformed into E. coli BL21 (DE3) for
protein expression.
E. coli BL21(DE3) cells harboring the above recombinant plasmids were grown in LB medium at
3
7 °C with shaking (20 rpm) till OD600 reached 0.6-0.8, followed by addition of isopropyl-β-
D-
thiogalactopyranoside (IPTG) to a final concentration of 0.2 mM. After 20 h induction at 16 °C the

ACCEPTED MANUSCRIPT
cells were harvested by brief centrifugation, and stored at -80 °C until used. Protein purification was
performed utilizing a Ni-NTA resin (Qiagen) column according to the manufacture instructions. The
purified proteins were desalted by PD-10 column (GE life science, USA) against 50 mM Tris-HCl (pH
8
4
1
.0) and 20% of glycerol. Enzymes were kept at -20 °C until used.
.3 Activity assays of AtUSP and BiUSP towards GlcA-1-P and GalA-1-P
A 50 µL reaction system in 20 mM Tris-HCl (pH 8.0) consisted of 0.8 mM GlcA-1-P or GalA-1-P,
mM UTP, 2 mM MgCl , and varying amount of purified AtUSP or BiUSP. Reactions were allowed
2
to proceed at 37 °C for 20 min, and quenched by the addition of equal volumes of cold ethanol. The
formation of UDP-HexA and consumption of UTP was analyzed by Capillary Electrophoresis
(Beckman Coulter) using the following conditions: 75 µm i.d. capillary (Beckman Coulter), 25
KV/140 µA, 5 s vacuum injection, 50 mM sodium tetraborate running buffer, pH 9.4., monitored at
2
54 nm.
4
.4 Determination of kinetic parameters
Kinetic parameters of both AtUSP and BiUSP towards Glc-1-P and Gal-1-P were measured in 50
µL reactions in 20 mM Tris-HCl (pH 8.0). The reaction mixtures contain varying concentrations of
GlcA-1-P or GalA-1-P (0.05, 0.1, 0.2, 0.4, 0.6, 0.8 mM), 1 mM UTP, 2 mM MgCl . Reactions were
2
initiated by the addition of 40 ng of AtUSP or BiUSP, performed at 37 °C for 5 min, and quenched by
addition of equal volumes of cold ethanol. The sugar-1-P substrate concentrations used in the time
course studies were 0.05 and 0.8 mM. The reactions were quenched at 0, 2, 5, 10, 15, 30, and 60 min.
Analysis were performed by CE as described above, and the average value of triplicate assays was
employed to generate Line-weaver-Burk plot, and K , Vmax, k values were calculated accordingly.
m
cat
Kinetic parameters of AtUSP and BiUSP towards UDP-GlcA and UDP-GalA were measured similarly,

ACCEPTED MANUSCRIPT
by replacing GlcA-1-P or GalA-1-P into UDP-GlcA or UDP-GalA, and replacing UTP into
pyrophosphate.
4
.5 Substrate specificity study of AtUSP and BiUSP towards various sugar-1-phosphates
The reaction mixtures (50 µL total volume) contain 0.8 mM of different sugar-1-phosphates
(
Table 2), 1 mM UTP and 2 mM MgCl
0.4-40 µg, to make sure the reactions convert no more than 25%) of AtUSP or BiUSP, performed at
7 °C for 10 min, and quenched by the addition of equal volumes of cold ethanol. Analysis were
2
. Reactions were initiated by the addition of varying amounts
(
3
performed by CE as described above, and the average value of triplicate assays was employed to
generate specific activities towards each sugar-1-phosphate.
4
.6 One-pot three-enzyme synthesis of UDP-GlcA and UDP-GalA
Preparative-scale synthesis of UDP-GlcA and UDP-GalA were performed in a 20 mL reaction
system containing 50 mM pH 8.0 Tris-HCl buffer, 20 mM GlcA or GalA, 22 mM ATP, 22 mM UTP,
0 mM MgCl , and 0.1 to 2 mg of different enzymes. For the synthesis of UDP-GlcA, 0.6 mg of
2
2
2
0
AtGlcAK, 0.4 mg of AtUSP, and 0.1 mg of EcPpA were employed; for the synthesis of UDP-GalA,
mg of BiGalK, 0.4 mg of AtUSP, and 0.1 mg of EcPpA were employed. The reaction mixtures were
incubated at 37 °C for 4 to 12 hours with gentle shaking. The generation of UDP-sugars were
monitored by TLC (Isopropanol: NH OH: H O = 7: 3: 2). After 90% of monosaccharides converted
2
4
2
into UDP-sugar, reactions were quenched by boiling for 5 min, centrifuged to remove precipitants, and
concentrated for separation. The separation of UDP-sugars from the reaction mixtures were performed
by gel filtration (Bio-Gel P2, Bio-Rad), fractions containing products were pooled and lyophilized.
Digestion of nucleotides by alkaline phosphatase and further P2 purification were applied to achieve
minimum 95% purity. The final products were lyophilized and characterized by HR-MS and NMR.

ACCEPTED MANUSCRIPT
Acknowledgement
This work was supported by National Institutes of Health (Grant No.: R01 GM085267 & R01
AI083754 to P.G.W).
Supplementary materials
Supplementary materials associated with this article can be found in the online version.
Reference
1
2
3
4
5
6
7
Banhegyi, G.;Braun, L.;Csala, M.;Puskas, F.Mandl, J. Free Radic Biol Med 1997,23, 793-803.
Selleck, S. B. Trends Genet 2000,16, 206-212.
Ohashi, T.;Cramer, N.;Ishimizu, T.Hase, S. Anal Biochem 2006,352, 182-187.
Roberts, I. S. Annu Rev Microbiol 1996,50, 285-315.
Knirel' Iu, A.Kochetkov, N. K. Biokhimiia 1994,59, 1784-1851.
Stroop, C. J.;Xu, Q.;Retzlaff, M.;Abeygunawardana, C.Bush, C. A. Carbohydr Res 2002,337, 335-344.
Xu, Y.;Cai, C.;Chandarajoti, K.;Hsieh, P. H.;Li, L.;Pham, T. Q.;Sparkenbaugh, E. M.;Sheng, J.;Key, N.
S.;Pawlinski, R.;Harris, E. N.;Linhardt, R. J.Liu, J. Nat Chem Biol 2014,10, 248-250.
Xu, Y.;Masuko, S.;Takieddin, M.;Xu, H.;Liu, R.;Jing, J.;Mousa, S. A.;Linhardt, R. J.Liu, J. Science
8
9
2
011,334, 498-501.
Leach, F. E., 3rd;Ly, M.;Laremore, T. N.;Wolff, J. J.;Perlow, J.;Linhardt, R. J.Amster, I. J. J Am Soc Mass
Spectrom 2012,23, 1488-1497.
1
1
1
1
1
0
1
2
3
4
Freeze, H. H.Elbein, A. D. in Essentials of Glycobiology (eds A. Varki et al.) (2009).
Ridley, B. L.;O'Neill, M. A.Mohnen, D. Phytochemistry 2001,57, 929-967.
Broach, B.;Gu, X.Bar-Peled, M. FEBS J 2012,279, 100-112.
Kleczkowski, L. A.;Decker, D.Wilczynska, M. Plant Physiol 2011,156, 3-10.
Tanaka, H.;Yoshimura, Y.;Jorgensen, M. R.;Cuesta-Seijo, J. A.Hindsgaul, O. Angew Chem Int Ed Engl
2
012,51, 11531-11534.
Cai, L.;Guan, W.;Wang, W.;Zhao, W.;Kitaoka, M.;Shen, J.;O'Neil, C.Wang, P. G. Bioorg Med Chem Lett
009,19, 5433-5435.
Cai, L.;Guan, W.;Kitaoka, M.;Shen, J.;Xia, C.;Chen, W.Wang, P. G. Chem Commun (Camb) 2009,2944-
946.
1
1
1
5
6
7
2
2
Yi, W.;Liu, X.;Li, Y.;Li, J.;Xia, C.;Zhou, G.;Zhang, W.;Zhao, W.;Chen, X.Wang, P. G. Proc Natl Acad Sci
U S A 2009,106, 4207-4212.
1
1
2
2
8
9
0
1
Cai, L.;Guan, W.;Chen, W.Wang, P. G. J Org Chem 2010,75, 3492-3494.
Zhao, G.;Guan, W.;Cai, L.Wang, P. G. Nat Protoc 2010,5, 636-646.
Li, L.;Liu, Y.;Wan, Y.;Li, Y.;Chen, X.;Zhao, W.Wang, P. G. Org Lett 2013,15, 5528-5530.
Liu, J.;Zou, Y.;Guan, W.;Zhai, Y.;Xue, M.;Jin, L.;Zhao, X.;Dong, J.;Wang, W.;Shen, J.;Wang, P. G.Chen,
M. Bioorg Med Chem Lett 2013,23, 3764-3768.
2
2
Zou, Y.;Xue, M.;Wang, W.;Cai, L.;Chen, L.;Liu, J.;Wang, P. G.;Shen, J.Chen, M. Carbohydr Res
2
013,373, 76-81.
2
2
3
4
Pieslinger, A. M.;Hoepflinger, M. C.Tenhaken, R. J Biol Chem 2010,285, 2902-2910.
Kotake, T.;Hojo, S.;Yamaguchi, D.;Aohara, T.;Konishi, T.Tsumuraya, Y. Biosci Biotechnol Biochem
2
007,71, 761-771.
2
2
2
5
6
7
Litterer, L. A.;Schnurr, J. A.;Plaisance, K. L.;Storey, K. K.;Gronwald, J. W.Somers, D. A. Plant Physiol
Biochem 2006,44, 171-180.
Muthana, M. M.;Qu, J.;Li, Y.;Zhang, L.;Yu, H.;Ding, L.;Malekan, H.Chen, X. Chem Commun (Camb)
2
012,48, 2728-2730.
Li, L.;Liu, Y.;Wang, W.;Cheng, J.;Zhao, W.Wang, P. Carbohydr Res 2012,355, 35-39.

ACCEPTED MANUSCRIPT
Figure Legends:
Figure 1. De novo and salvage biosynthetic pathway of UDP-GlcA and UDP-GalA. A),
Glucuronokinase (GlcAK); B) UDP-sugar pyrophosphorylase (USP); C) UDP-glucose 6-
dehydrogenase; D) Phosphoglucomutase; E) UTP: glucose-1-phosphate uridylyltransferase (GalU); F)
UDP-Glc 4’-epimerase (GalE); G) UDP-galactose 6-dehydrogenase; H) galacturonokinase (GalAK); I)
UDP- galacturonate pyrophosphorylase.
Figure 2. SDS-PAGE analysis of purified enzymes. Lanes: 1, AtGlcAK; 2, AtUSP; 3, BiGalK; 4,
BiUSP.
Figure 3. CE Profiles of compound standards, and BiUSP/AtUSP catalyzed reactions. (A) 0.5 mM
UTP; (B) 0.5 mM UDP-GlcA; (C) 0.5 mM of UDP-GalA; (D) BiUSP catalyzed generation of UDP-
GlcA; (E) AtUSP catalyzed generation of UDP-GlcA; (F) AtUSP catalyzed generation of UDP-GalA.
For each reaction, 0.8 mM sugar-1-P, 1 mM UTP, and 1 µg enzyme was used in a total 50 µL system,
reactions were proceeded at 37 °C for 20 min. UTP has a retention time of 21.7 ± 0.1 min, UDP-GlcA
has a retention time of 18.2 ± 0.1 min, and UDP-GalA has a retention time of 16.6 ± 0.1 min.
Figure 4. Time course for UDP-GlcA and UDP-GalA reactions. Reactions contains 1 mM UTP, 40 ng
of At USP or BiUSP, and: 1, AtUSP and 0.05 mM GlcA-1-P; 2, AtUSP and 0.8 mM GlcA-1-P; 3,
AtUSP and 0.05 mM GalA-1-P; 4, AtUSP and 0.8 mM GalA-1-P; 5, BiUSP and 0.05 mM GlcA-1-P; 6,
BiUSP and 0.8 mM GlcA-1-P.
Figure 5. One-pot three-enzyme synthesis of UDP-GlcA and UDP-GalA. Enzymes used: AtGlcAK:
Glucuronokinase from A. thaliana; BiGalK, Galactokinase from B. infantis ATCC15697; AtUSP,
UDP-sugar pyrophosphorylase from A. thaliana; EcPpA, Pyrophosphatase from E. coli.

ACCEPTED MANUSCRIPT
Table 1
Kinetic parameters of AtUSP and BiUSP towards GlcA-1-P, GalA-1-P, UDP-GlcA and UDP-GalA.
Km
M)
Vmax
k
k
(s
/Km
cat
-1
cat
-1
-1
-1
(
µ
(
µΜ mg ) (s )
µM )
AtUSP
GlcA-1-P
GalA-1-P
-
3
-4
-4
-4
-4
3
2.36×10-
3.63×10
4.45×10
4.06×10
4.59×10
11.0
13.5
12.3
13.9
4.66×103
2.45×103
4.64×103
2.80×10
3
5.50×10-
3
UDP-GlcA 2.65×10-
3
UDP-GalA 4.96×10
BiUSP
GlcA-1-P
GalA-1-P
UDP-GlcA 2.02×10
UDP-GalA
-
3
-4
-4
3
1.76×10
-
3.38×10
8.30
4.72×10
-
3.71×10
-
-
9.12
-
-
-3
3
4.51×10
-
-
Table 2
Substrate specificity of AtUSP and BiUSP towards sugar-1-phosphates. Specific activity of AtUSP
-1
-1
towards GlcA-1-P (12.4 µmol min mg ) was set as 100. ND, not detected.
Sugar-1-phosphate
Relative activities
AtUSP
BiUSP
GlcA-1-P
GalA-1-P
Glc-1-P
100
75.7
130
123
ND
ND
ND
ND
61.7
73.8
53.2
11.6
7.50
ND
91
ND
141
136
ND
ND
37.2
9.65
15.4
82.0
ND
ND
41.8
ND
Gal-1-P
GlcNAc-1-P
GalNAc-1-P
Man-1-P
Talose-1-P
D-Fuc-1-P
2
2
6
2
2
-deoxy-Glc-1-P
-deoxy-Gal-1-P
-deoxy-6-azido-Gal-1-P
-deoxy-2-amino-Glc-1-P
-deoxy-2-amino-Gal-1-P

ACCEPTED MANUSCRIPT

ACCEPTED MANUSCRIPT

ACCEPTED MANUSCRIPT

ACCEPTED MANUSCRIPT

ACCEPTED MANUSCRIPT

ACCEPTED MANUSCRIPT
UDP-sugar pyrophosphorylase (AtUSP) from Arabidopsis thaliana showed significant
activity towards both GlcA-1-P and GalA-1-P
UDP-sugar pyrophosphorylase (BiUSP) from Bifidobacterium infantis showed
significant activity towards GlcA-1-P
Both USPs showed broad substrate specificity towards various sugar-1-phosphates.
Both AtUSP an BiUSP were expressed and purified in high yields (over 40 mg per L);
A one-pot three-enzyme approach was applied efficiently for hundreds mgs scale of
UDP-GlcA and UDP-GalA.

ACCEPTED MANUSCRIPT
Comparing substrate specificity of two UDP-sugar Pyrophosphorylases and
Efficient One-pot Enzymatic Synthesis of UDP-GlcA and UDP-GalA
†
‡
†
†
†
†
,†,‡
Yuxi Guo, Junqiang Fang, Tiehai Li, Xu Li, Cheng Ma, Xuan Wang, Peng G. Wang* ,
and Lei Li,*,
†
†Department of Chemistry and Center for Diagnostics & Therapeutics, Georgia State University,
Atlanta, GA 30303
‡
National Glycoengineering Research Center, Shandong University, Jinan, Shandong, 250100,
China
*
Corresponding author: pwang11@gsu.edu, or lli22@gsu.edu
Supporting Information
Codon optimized AtGlcAK gene:
ATGGATCCGAACAGCACCGTTTCTGGCGATGGTCAGGCTACCGCAGCGATTGAACAC
CGCTCCTTTGCCCGCATTGGCTTTCTGGGTAACCCGTCAGATGTTTATTTTGGCCGCA
CCATTTCGCTGACGATCGGTAATTTCTGGGCGAGCGTCAAACTGGAACCGTCTGAAC
ATCTGGTGATTAAACCGCATCCGTTTCACGATCTGGTGCAGTTCACCAGCCTGGACC
ACCTGCTGAACCGTCTGCAAAATGAAGGCTATTACGGCGGTGTTCGCCTGCTGATGG
CGATCTGCAAAGTCTTCCGTAACTACTGTAAAGAAAACGATATCCAGCTGCATCAAG
CCAACTTCTCACTGTCGTACGACACCAATATTCCGCGCCAGACGGGCCTGAGTGGTA
GCTCTGCAATCGTCTCCGCGGCCCTGAACTGCCTGCTGGATTTTTATAATGTGCGCCA
TCTGATTAAAGTGCAAGTTCGTCCGAACATCGTGCTGAGTGCTGAAAAAGAACTGGG
CATTGTTGCAGGTCTGCAGGATCGTGTTGCTCAAGTCTACGGCGGTCTGGTTCACATG
GATTTCAGTAAAGAACATATGGACAAACTGGGCCACGGTATTTATACCCCGATGGAT
ATCTCCCTGCTGCCGCCGCTGCATCTGATCTACGCCGAAAATCCGAGCGACTCTGGC
AAAGTGCACAGCATGGTTCGCCAGCGTTGGCTGGATGGTGACGAATTCATCATCAGT
1

ACCEPTED MANUSCRIPT
TCCATGAAAGAAGTTGGCAGCCTGGCCGAAGAAGGTCGTACCGCACTGCTGAACAA
AGATCACTCTAAACTGGTGGAACTGATGAACCTGAATTTTGATATTCGTCGCCGTAT
GTTCGGCGACGAATGCCTGGGTGCGATGAATATCGAAATGGTCGAAGTGGCACGCC
GTGTGGGTGCAGCTAGTAAATTTACGGGTTCCGGCGGTGCAGTGGTTGTCTTCTGCC
CGGAAGGTCCGTCTCAGGTTAAACTGCTGGAAGAAGAATGTCGTAAAGCAGGTTTTA
CCCTGCAGCCGGTCAAAATTGCTCCGTCATGTCTGAACGATTCGGACATCCAAACGC
TGTAA
Codon optimized AtUSP gene:
ATGGCGTCAACGGTGGATAGTAACTTCTTCTCATCTGTCCCGGCACTGCACTCAAAC
CTGGGTCTGCTGTCCCCGGATCAAATCGAACTGGCGAAAATTCTGCTGGAAAACGGC
CAGAGTCACCTGTTTCAGCAATGGCCGGAACTGGGTGTGGATGACAAAGAAAAACT
GGCGTTTTTCGATCAAATTGCCCGTCTGAACAGCTCTTATCCGGGCGGTCTGGCGGCC
TACATCAAAACCGCAAAAGAACTGCTGGCTGATAGTAAAGTCGGCAAAAATCCGTA
TGACGGTTTCAGCCCGTCTGTGCCGTCCGGCGAAAACCTGACGTTTGGTACCGATAA
TTTCATTGAAATGGAAAAACGTGGCGTGGTTGAAGCACGCAACGCAGCTTTTGTCCT
GGTGGCTGGCGGTCTGGGTGAACGTCTGGGCTATAATGGTATCAAAGTTGCACTGCC
GCGTGAAACCACGACCGGTACCTGCTTCCTGCAGCATTACATTGAATCAATCCTGGC
ACTGCAGGAAGCGAGCAACAAAATTGATAGTGACGGTTCCGAACGGATATCCCGTTT
ATTATCATGACGTCAGATGACACCCATTCGCGCACGCTGGACCTGCTGGAACTGAAT
AGCTATTTCGGCATGAAACCGACCCAGGTCCACCTGCTGAAACAAGAAAAAGTGGC
ATGTCTGGATGACAACGATGCGCGTCTGGCCCTGGACCCGCACAATAAATATTCAAT
TCAGACGAAACCGCATGGCCACGGTGATGTGCATTCGCTGCTGTACAGTTCCGGCCT
GCTGCACAAATGGCTGGAAGCCGGTCTGAAATGGGTGCTGTTTTTCCAGGATACCAA
2

ACCEPTED MANUSCRIPT
CGGCCTGCTGTTTAATGCAATTCCGGCTAGTCTGGGTGTTTCCGCAACGAAACAATA
TCATGTCAATTCTCTGGCTGTGCCGCGCAAAGCGAAAGAAGCCATTGGCGGTATCAG
CAAACTGACCCACGTGGATGGCCGTTCTATGGTCATCAACGTGGAATACAATCAGCT
GGACCCGCTGCTGCGTGCAAGCGGTTTCCCGGATGGTGACGTTAACTGCGAAACCGG
CTTTTCTCCGTTCCCGGGTAACATTAATCAGCTGATCCTGGAACTGGGTCCGTATAAA
GATGAACTGCAAAAAACGGGCGGTGCGATCAAAGAATTCGTTAACCCGAAATACAA
AGATAGCACGAAAACCGCCTTCAAATCATCGACCCGTCTGGAATGTATGATGCAGGA
CTATCCGAAAACCCTGCCGCCGACGGCACGTGTGGGCTTTACGGTTATGGATATCTG
GCTGGCATACGCTCCGGTGAAAAACAATCCGGAAGACGCGGCCAAAGTTCCGAAAG
GCAACCCGTATCACTCAGCAACCTCGGGTGAAATGGCGATTTACCGTGCCAATTCAC
TGATCCTGCAGAAAGCTGGCGTTAAAGTCGAAGAACCGGTTAAACAGGTCCTGAAC
GGTCAAGAAGTGGAAGTTTGGAGCCGCATTACCTGGAAACCGAAATGGGGCATGAT
TTTTAGCGATATTAAGAAAAAAGTTTCTGGTAACTGCGAAGTCAGCCAGCGTTCTAC
GATGGCGATTAAAGGCCGCAATGTGTTCATCAAAGATCTGAGTCTGGACGGTGCGCT
GATTGTTGATTCCATCGATGACGCCGAAGTCAAACTGGGCGGTCTGATCAAAAACAA
TGGTTGGACCATGGAAAGTGTGGATTATAAAGACACGTCCGTTCCGGAAGAAATTCG
TATCCGCGGCTTTCGCTTCAATAAAGTTGAACAGCTGGAGAAAAAACTGACCCAACC
GGGTAAATTTAGCGTCGAAGATTAA
3

ACCEPTED MANUSCRIPT
1H NMR Spectrum of UDP-GlcA
13C NMR Spectrum of UDP-GlcA
4

ACCEPTED MANUSCRIPT
31P NMR Spectrum of UDP-GlcA
1H NMR Spectrum of UDP-GalA
5

ACCEPTED MANUSCRIPT
13C NMR Spectrum of UDP-GalA
31P NMR Spectrum of UDP-GlcA
6
