Prasun Mukherjee, Asish R. Das*
Department of Chemistry, University of Calcutta, Kolkata-700009, India
*
Tel.: +913323501014, +919433120265; fax: +913323519754; E-mail: ardchem@caluniv.ac.in,
ardas66@rediffmail.com.
Graphical abstract
Abstract
A robust intramolecular cyclopropanation reaction was first performed on pyrano-pyrazole and
pyrano-pyrimidine dione derivatives to obtain spiro-cyclopropyl pyrazolones and barbiturates,
using iodosylbenzene (PhIO) or the combination of iodobenzene diacetate (PIDA)/ molecular
iodine (I ), under mild reaction conditions. Syntheses of functionally and stereochemically
2
diversified, novel spiropyrazolone fused 2-iminothiophene and spiropyrazolone fused pyrroline
scaffolds were also demonstrated via Lewis acid catalyzed highly diastereoselective (3+2)
cycloaddition reactions of the synthesized spiro-cyclopropyl pyrazolones with phenyl
isothiocyanate and benzonitrile respectively.
