An eco-friendly approach to the cyclohexane oxidation catalyzed by manganese
porphyrins: green and solvent-free systems
Adriano Silva Guimarães, Bernardo Schmitberger, Alexandre Moreira
Meireles, Dayse Carvalho da Silva Martins, Gilson DeFreitas-Silva
PII:
S0277-5387(19)30123-8
https://doi.org/10.1016/j.poly.2019.02.022
POLY 13766
DOI:
Reference:
Polyhedron
To appear in:
Received Date:
Revised Date:
Accepted Date:
4 December 2018
24 January 2019
14 February 2019
Please cite this article as: A.S. Guimarães, B. Schmitberger, A.M. Meireles, D.C. da Silva Martins, G. DeFreitas-
Silva, An eco-friendly approach to the cyclohexane oxidation catalyzed by manganese porphyrins: green and
solvent-free systems, Polyhedron (2019), doi: https://doi.org/10.1016/j.poly.2019.02.022
This is a PDF file of an unedited manuscript that has been accepted for publication. As a service to our customers
we are providing this early version of the manuscript. The manuscript will undergo copyediting, typesetting, and
review of the resulting proof before it is published in its final form. Please note that during the production process
errors may be discovered which could affect the content, and all legal disclaimers that apply to the journal pertain.

An eco-friendly approach to the cyclohexane oxidation catalyzed by manganese porphyrins:
green and solvent-free systems
Adriano Silva Guimarães, Bernardo Schmitberger, Alexandre Moreira Meireles, Dayse Carvalho da
Silva Martins, and Gilson DeFreitas-Silva*
*gilsonufmg@ufmg.br
Departamento de Química, Instituto de Ciências Exatas, Universidade Federal de Minas Gerais,
31270-901, Belo Horizonte, MG, Brazil.
* Corresponding author:
Prof. Gilson de Freitas Silva (G. DeFreitas-Silva)
Departamento de Química – Instituto de Ciências Exatas – Universidade Federal de Minas Gerais
Belo Horizonte, MG, 31270-901, BRAZIL
Tel.: +55 31 3409 5762.
E-mail address: gilsonufmg@ufmg.br
Declarations of interest: none.

Abstract
The selective cyclohexane oxidation to cyclohexanone and cyclohexanol based on a green strategy
has been a challenge. A new manganese porphyrin [MnIII(T2,4,5TMPP)Cl] was prepared and its
activity and selectivity as a catalyst were studied together with the classical manganese porphyrin
[MnIII(TPP)Cl] using green solvents (dimethyl carbonate or ethyl acetate) and solvent-free systems.
The effects of the solvent (or its absence), oxidant, and co-catalyst were investigated. Under the
studied conditions, the new catalyst showed a higher selectivity for cyclohexanol (above 78%) in
solvent-free systems compared to the [MnIII(TPP)Cl]. The highest total yield of the products (89%) was
observed in ethyl acetate/PhIO/water system.
Keywords
Manganese porphyrins, Cyclohexane oxidation, Green solvents, iodobenzene diacetate
Introduction
Cyclohexane oxidation under mild temperature and pressure conditions has been a challenge
for the scientific community due to the high thermodynamic stability of the C-H bonds (95.5 kcal mol-1)
[1]. Moreover, its industrial process has assumed a new dimension [2], and the development of new
oxidation routes displays a great economic interest because of the importance of its intermediates
cyclohexanol and cyclohexanone to the synthesis of many polymers [3, 4].
The search for more efficient processes also presents an increasing concern for the
environment. Thus, researchers have been attempting to develop systems that meet the tenets of
green chemistry established by Anastas e Warner [5], such as the use of catalysis and safer solvents
or auxiliaries. Therefore, sustainable routes to the cyclohexane oxidation become an interesting target
which may be explored by employing green solvents and catalysts.
Among the different catalysts used in the cyclohexane oxidation, the metalloporphyrins,
especially the manganese porphyrins (MnP) [6-8], are highlighted because these compounds
mimetize the P450 cytochrome and catalyze the oxidation of different compounds at room
temperature and pressure. The first MnP catalytic system was described by Hill and Schardt in 1980
[9] in which cyclohexane was oxidized by PhlO (iodosylbenzene) using dichloromethane as solvent.
Since then, aiming at more selective systems or higher yields, a variety of manganese porphyrins
have been synthesized and employed as catalysts. However, the chlorinated solvents, which are toxic
and environmentally detrimental, prevail as the mean to perform the reaction in the majority of these
systems, leading to unsustainable practices [10-16]. To the best of our knowledge, the development of
catalytic systems for cyclohexane oxidation based on MnP employing green solvents or in the
absence of solvents are scarcely reported in the literature [17].
This work aims to evaluate the cyclohexane oxidation by PhlO and PhI(OAc)2 (iodobenzene
diacetate) in the presence of green solvents (dimethyl carbonate or ethyl acetate) and in solvent-free

systems. Two MnP {clorido-5,10,15,20-(tetraphenylporphyrinato)manganese(III) – [MnIII(TPP)Cl]) –
and the new compound clorido-5,10,15-20-(2,4,5-trimethoxyphenylporphyrinato)manganese(III) –
[MnIII(T2,4,5TMPP)Cl]} were employed as catalysts (Figure 1), and the use of water or imidazole as
additives was also evaluated in order to achieve more efficient systems.
Figure 1. Structure of the manganese porphyrin catalysts.
Experimental
General Information
The pyrrole was obtained from Fluka and distilled under reduced pressure immediately before
use. Dichloromethane (CH2Cl2) and methanol (CH3OH) were obtained from Vetec and submitted to
distillation before use. Iodosylbenzene (PhIO) was prepared following the procedure proposed by
Saltzman e Sharefkin [18], stored at –20 oC in a freezer and periodically tested by iodometric titration.
The catalyst clorido-5,10,15,20-(tetraphenylporphyrinato)manganese(III) – [MnIII(TPP)Cl] – was
obtained as described in the literature [19]. 2,4,5-trimethoxybenzaldehyde, nitrobenzene, propionic
acid, iodobenzene diacetate {PhI(OAc)2}, dimethyl carbonate {(CH3O)2CO} and ethyl acetate
(CH3COOC2H5) were obtained from Sigma-Aldrich with analytical degree and used without further
purification.
Absorption spectra in the UV-vis region (190-1100 nm) were recorded on an HP-8453A diode-
array spectrophotometer. Infrared (IR) spectra were recorded on a Perkin Elmer BXFTIR spectrometer
with samples prepared in KBr pellets. Hydrogen nuclear magnetic resonance (1H NMR) spectra were
obtained in CDCl3 at room temperature (25 oC) on a Bruker DPX-200 Advance spectrometer operating
at 200 MHz with tetramethylsilane (TMS) as the internal standard. The ESI-MS analyzes were
conducted on a Bruker micrOTOF-Q II mass spectrometer equipped with electrospray ionization (ESI)
source operating in the positive ion mode and using acetonitrile as the solvent. The oxidation products
were analyzed on a gas chromatographer (Shimadzu GC-17A) with flame ionization detector equipped
with an Altech Econo-Cap capillary (30.0 m in length, 0.32 mm in diameter and 0.25 μm film thickness)
with Carbowax® stationary phase. A mixture of synthetic air and hydrogen was used for the flame and

hydrogen was employed as the carrier gas. The ultrasound equipment Unique® MaxiClean 1400 (40
kHz) was also used in the experiments.
Obtaining of the new metalloporphyrin catalyst
5,10,15-20-(2,4,5-trimethoxyphenylporphyrin) – H2T2,4,5TMPP
H2T2,4,5TMPP was obtained by reacting 2,4,5-trimethoxybenzaldehyde (3.8910 g, 19.831
mmol) and pyrrole (1.40 mL, 20.1 mmol) in 50 mL of a mixture of propionic acid:nitrobenzene (7:3)
(adaptation of the method described by Gonsalves et. al.) [20] The solution was kept under reflux and
magnetic stirring for 1 hour. After cooling, the addition of 50 mL of methanol led to the precipitation of
the porphyrin. The product was purified by column chromatography using neutral alumina (column
height = 30 cm; column diameter = 2.50 cm) and CH2Cl2 as eluent. The yield of H2T2,4,5TMPP was
15.4% (745.6 mg, 0.7646 mmol). UV-Vis (CH2Cl2), λmax, nm (log ε): 424 (4.36); 516 (3.24); 553 (2.84);
592 (2.74); 652 (2.58). IR in KBr pellets (cm-1): (3316) N-Hpyrrole; (1346) C=Npyrrole; (1229) ”breathing” of
porphyrin skeleton; (1210) assymetric C-O-Cether; (1015) symetric C-O-Cether; (978)  N-Hpyrrole. ESI-MS in
1
acetonitrile: [H2T2,4,5MPP + H]+ m/z 975.37. H NMR (CDCl3) δ ppm: -2.60 (s, 2H), 3.52 (m, 12H, -
6
OCH3, para), 3.91 (m, 12H, -OCH3, meta), 4.20 (m, 12H, -OCH3, ortho), 6.98 (m, 4H, H ortho aryl),
7.57 (m, 4H, 5H meta aryl), 8.81 (m, 8H β-pyrrole). Elemental analysis (%): H2T2,4,5MPP
(C56H54N4O12). Calculated: C (68.98), H (5.58), N (5.75). Experimental: C (68.45), H (4.20), N (6.06).
clorido-5,10,15-20-(2,4,5-trimethoxyphenylporphyrinato)manganese(III) – [MnIII(T2,4,5TMPP)Cl]
The catalyst [MnIII(T2,4,5TMPP)Cl] was obtained from the metallation of H2T2,4,5TMPP (100
mg, 0,102 mmol) with MnCl2.4H2O (200.0 mg, 1.025 mmol) in 15 mL of N,N'-dimethylformamide
(DMF) (adaptation of the method described by Adler et al.) [21]. The reaction mixture was kept under
reflux and magnetic stirring for 24 hours. The reaction was monitored by absorption spectroscopy in
the UV-vis region until the porphyrin precursor was absent. The product was purified by neutral
alumina column chromatography (column height = 15 cm; column diameter = 2.50 cm) using CH2Cl2
as eluent and then a mixture of CH2Cl2:CH3OH (10:1) to collect the green fractions related to the
complex. The yield of [MnIII(T2,4,5TMPP)Cl] was 91% (97.0 mg, 0.0912 mmol). UV–Vis (CH2Cl2), λmax
nm (log ε): 376 (4.66); 482 (4.93); 585 (3.98); 622 (4.00). IR in KBr pellets (cm-1): (1349) C=Npyrrole
,
;
(1230) ”breathing” of porphyrin skeleton; (1208) assymetric C-O-Cether; (1013) symetric C-O-Cether; (1007) 
Mn-Npyrrole. ESI-MS in acetonitrile: [MnIII(T2,4,5TMPP)]+ m/z 1027.29. Elemental analysis (%):
[MnIII(T2,4,5TMPP)Cl].0.5CH2Cl2 (C56H52N4O12MnCl.0.5CH2Cl2). Calculated: C(61.36), H(4.83),
N(5.07). Experimental: C(62.01), H(4.00), N(5.75).
Cyclohexane oxidation

The cyclohexane oxidation in the presence of the solvent was performed according to the
methodology described by Da Silva et al. [22]. In the case of solvent-free reactions, the employed
methodology was the one described by Tôrres et al. [17]. The effect of imidazole was studied only for
systems with solvents (by adding a 20 L aliquot of a 1.0 × 10-2 mol L-1 imidazole solution prepared in
the appropriate solvent) since this additive is insoluble in cyclohexane. The effect of H2O was studied
by adding an aliquot of 0.5 L to the reaction medium.
Results and Discussion
Obtaining of the metalloporphyrin catalyst
H2T2,4,5TMPP was initially characterized by absorption spectroscopy in the UV-Vis region
(Figure 2) with a characteristic spectrum of a free base porphyrin [19]. [MnIII(T2,4,5TMPP)Cl] (Figure
1) was obtained and confirmed by the loss of fluorescence (red) under ultraviolet light [23],
characteristic of H2T2,4,5TMPP. The UV-vis spectrum of the catalyst [MnIII(T2,4,5TMPP)Cl], when
compared to the free base porphyrin, revealed a bathochromic shift of the Soret band and a decrease
in the number of bands [19]. The Mn(III) porphyrin spectrum is very peculiar because of the bands
resulting from the ligand-metal charge transfer due to the interaction of Mn3+ ion orbitals with the
porphyrin π system [24].
Figure 2. Absorption spectra in the UV-vis region of H2T2,4,5TMPP (3.34 × 10-5 mol L-1) and
[MnIII(T2,4,5TMPP)Cl] (9.08 × 10-6 mol L-1) in CHCl3.
1
The characterization of H2T2,4,5TMPP by H NMR spectroscopy was performed in CDCl3
(Figure 3a). Two N-H pyrrole hydrogen (δ -2.60), eight hydrogen in the β-pyrrole positions (δ 8.81),
four hydrogen in the ortho-aryl (δ 6.98) and meta-aryl (δ 7.57) positions were observed in the
spectrum. In relation to the hydrogen of the three methoxy groups (-OCH3), the spectrum indicated the

existence of three hydrogen atoms for each of the ortho (δ 4.20), meta (δ 3.91) and para (δ 3.52)
positions of the aryl groups in the meso positions of the macrocycle (Figure 3b).
(b)
(a)
o
Figure 3. (a) 1H NMR spectrum of H2T2,4,5TMPP in CDCl3 (200 MHz, TMS) at 25 C. δ -2.60 (s, 2H,
N-Hpyrrolic), δ 3.52 (m, 12H, -OCH3, para-), δ 3.91 (m, 12H, -OCH3, meta-), δ 4.20 (s, 12H, -OCH3,
ortho-), δ 6.98 (m, 4H, 6H ortho-aryl), δ 7.57 (m, 4H, 5H meta-aryl), δ 8.81 (m, 8H β-pyrrolic); (b)
Hydrogen atoms labeling in the structure of H2T2,4,5TMPP.
H2T2,4,5TMPP and [MnIII(T2,4,5TMPP)Cl] were also characterized by infrared spectroscopy
(Figures S1-S4, Supplementary Material). By the results we confirmed the formation of the free base
porphyrin H2T2,4,5TMPP, evidenced by the bands referring to the groups (-OCH3), C-O-C stretch,
aromatic ether stretch, macrocycle deformation and N-H deformation (pyrrole) (Figure S2,
Supplementary Material) [25]. Its metallation was confirmed by the absence of the deformation band
(out of plane) of the N-H bond of the pyrrole groups, and a new band was observed referring to the
deformation of the pyridinic Mn-N bond (Figure S4, Supplementary Material) [26].
The free base porphyrin H2T2,4,5TMPP and the new catalyst [MnIII(T2,4,5TMPP)Cl] were
characterized by mass spectrometry (Figures S5 and S6, Supplementary Material) with a signal
centered at m/z 975.37 and 1027.29, respectively. These signals were associated with the species
[H2T2,4,5TMPP + H]+ and [MnIII(T2,4,5TMPP)]+ with the loss of the chloride ion.
Cyclohexane oxidation
The cyclohexane oxidation using manganese porphyrins as catalysts has been studied for
almost 40 years [9]. However, the vast majority of reports employs the use of chlorinated solvents
(dichloromethane, for example) [10-14] and, to the best of our knowledge, none has described the use
of green solvents. In this sense, we decided to evaluate the use of two green solvents in the
cyclohexane oxidation reaction using [MnIII(TPP)Cl] as a catalyst. The following observed results for

this catalyst stimulated the search for a more efficient catalyst, such as the new obtained catalyst
[MnIII(T2,4,5TMPP)Cl], as will be shown in this work.
Among the green solvent options, we have chosen ethyl acetate and dimethyl carbonate
mainly because of the catalyst solubility. Moreover, ethyl acetate has shown itself to be a very useful
green solvent. For example, at MADIX polymerization, Levere and co-workers observed that this
solvent allowed the production of polymers with a high monomer conversion (near 100%) and high
molecular weights [27]. Dimethyl carbonate is a biodegradable solvent that has demonstrated many
efficient applications, for example, to synthesize unsymmetrical 2,6-diarylated aniline derivatives. The
expected product was obtained in yields up to 91% [28]. In this way, these were the two green
solvents selected for the present work. In order to verify the green solvent effect, we decided to study
the standard oxygen donor iodosylbenzene (PhIO) and its precursor iodobenzene diacetate
[PhI(OAc)2].
In systems using PhIO as an oxidant (FIGURE 4a), both green solvents provided a slight
increase in the selectivity for cyclohexanol and in the catalyst stability. However, the total yield for the
products is practically unchanged. Our research group has shown that PhI(OAc)2 can advantageously
replace PhIO as an oxidant because it is commercially available, more stable, non-explosive and
easily stored [14, 17, 22, 29-31]. In previous works, we demonstrated that the cyclohexane oxidation
by [MnIII(TPP)Cl] discretely increased the alcohol selectivity in the presence of PhI(OAc)2 as an
oxidant [56% with PhIO versus 65% with PhI(OAc)2] [14]. Figure 4b shows that ethyl acetate increased
the total product yield (25% and 54% with PhIO and PhI(OAc)2, respectively) with little variation in
selectivity. On the other hand, the catalyst stability was slightly lower in the PhI(OAc)2 system. This
behavior has already been observed in other systems in the literature [14, 29, 32], in which
dichloromethane was employed as the solvent.
Figure 4. Cyclohexane oxidation reactions by (a) PhIO or (b) PhI(OAc)2, in different solvents catalyzed
o
by [MnIII(TPP)Cl]. Reaction conditions: MnP/Oxidant/cyclohexane molar ratio = 1:10:4625, 25 C,
magnetic stirring, 90 min. of reaction. Yields (%) based on the oxidant. C-ol: cyclohexanol and C-one:
cyclohexanone. Selectivity for the alcohol was determined from the relation: Selectivity = 100 × [%C-
ol/(%C-ol + %C-one)]. The degree of destruction of the catalyst was calculated based on the UV–Vis
absorption spectra recorded at the end of the reaction.

Considering that ethyl acetate provided an increase in the total yield of the substrate oxidation
system in the presence of iodobenzene diacetate (compared to dichloromethane), and that we have
already shown the increase in total yield (with no changes of alcohol selectivity) in the presence of
additives (imidazole and water) [14, 22, 29-31, 33, 34], we decided to verify the effect of these
additives in the systems with the green solvents. It is important to emphasize that the amount of
imidazole/water employed in this work was very small, showing that it is not necessary to use such a
large excess of this additive as it has been observed in most studies [10, 33-35]. For example, in the
work by Li and Xia, the molar ratio catalyst:imidazole was 1:50 [33], meanwhile in this work it is 1:1
(0.02% catalyst amount). Thus, we studied the effect of imidazole and water on cyclohexane oxidation
by PhI(OAc)2 catalyzed by [MnIII(TPP)Cl] in ethyl acetate (Figure 5a). Figure 5a shows that the
addition of water or imidazole reduces the total yield, but it slight increases of the selectivity and
stability of the catalyst. This result was unexpected because, in most of the reports in the literature,
imidazole and water provided systems which increased the total yield [14, 22, 29-31].
Figure 5. Cyclohexane oxidation reactions catalyzed by [MnIII(TPP)Cl] in presence of additives (water
or imidazole) with: (a) PhI(OAc)2/ethyl acetate; (b) PhIO/ethyl acetate; (c) PhI(OAc)2/dimethyl
carbonate; (d) PhIO/dimethyl carbonate. Reaction conditions: MnP/Oxidant/cyclohexane molar ratio =
o
1:10:4625, 25 C, magnetic stirring, 90 min. of reaction. Yields (%) based on the oxidant. C-ol:
cyclohexanol and C-one: cyclohexanone. Selectivity for the alcohol was determined from the relation:

Selectivity = 100 × [%C-ol/(%C-ol + %C-one)]. The degree of destruction of the catalyst was
calculated based on the UV–Vis absorption spectra recorded at the end of the reaction.
Facing these results, we decided to evaluate the way these same additives affected systems
containing PhIO as an oxidant (in both green solvents) and the reaction performed with dimethyl
carbonate/PhI(OAc)2 (Figure 5b,c,d). For most of these systems, an increase in the total yield was
observed with no changes of selectivity, highlighting the use of imidazole as additive ([MnIII(TPP)Cl] +
PhIO + ethyl acetate + imidazole, with 89% total yield). This result is associated with the
destabilization of the high valence active species, caused by the presence of the axial ligand [36, 37].
Despite the higher total yields, the studied catalyst [MnIII(TPP)Cl] was more degraded in the
presence of additives (between 52 and 87% degradation) due to its structural and electronic
characteristics. This catalyst belongs to the 1st generation MnP group, which are more easily degraded
in the reaction medium due to the lack of substituents in the aryl group of the macrocycle at meso
positions [38].
Thus, we decided to obtain a new catalyst that could present selectivity similar to the one
observed in these systems {using [MnIII(TPP)Cl]} with an increase of its stability in the catalytic
systems. We have shown that cyclohexane oxidation by PhIO in dichloromethane and addition of
imidazole have increased the total yield (with no changes of selectivity) when MnP containing two
methoxy groups (positions 3 and 5 of the aryl group related to the porphyrin macrocycle) was
compared to that containing only one group (position 4 of the aryl group related to the porphyrin
macrocycle). Thus, we attempted to prepare a MnP containing three methoxy groups in order to
further increase this total yield. In this sense, the [MnIII(T2,4,5TMPP)Cl] complex, which contains three
substituents in the aryl group at the meso positions of the macrocycle, was synthesized. This
metalloporphyrin was inspired by these two previous works about manganese porphyrins with one or
two methoxy substituents on the aryl group [30, 31]. Among the possible aldehydes precursors for the
desired catalyst, the one with the methoxy groups at the 2, 4 and 5 positions of the phenyl ring was
chosen because of its low commercial cost. This MnP was obtained relatively simply and with good
yield (15.4%), using an adaptation of the method proposed by Gonsalves et al [20].

Figure 6. Cyclohexane oxidation reactions catalyzed by [MnIII(T2,4,5TMPP)Cl] in presence of
additives (water or imidazole) with: (a) PhIO/CH2Cl2; (b) PhI(OAc)2/CH2Cl2; (c) PhIO/ethyl acetate; (d)
PhI(OAc)2/ethyl acetate; (e) PhIO/dimethyl carbonate; (f) PhI(OAc)2/dimethyl carbonate. Reaction
o
conditions: MnP/Oxidant/cyclohexane molar ratio = 1:10:4625, 25 C, magnetic stirring, 90 min. of
reaction. Yields (%) based on the oxidant. C-ol: cyclohexanol and C-one: cyclohexanone. Selectivity
for the alcohol was determined from the relation: Selectivity = 100 × [%C-ol/(%C-ol + %C-one)]. The
degree of destruction of the catalyst was calculated based on the UV–Vis absorption spectra recorded
at the end of the reaction.

The experiments described in Figure 6 were performed using the new [MnIII(T2,4,5TMPP)Cl]
catalyst, reproducing those already demonstrated (Figures 4 and 5) for their first generation analog
[MnIII(TPP)Cl]. Comparing the systems with both catalysts, it was observed that the selectivity of the
catalyst systems was similar (which was already expected) and the stability of the new catalyst was
higher than the one observed for the first generation compound.
In general, the yields in the non-additive system in the presence of the green solvents for
[MnIII(T2,4,5TMPP)Cl] were higher when ethyl acetate was used. Probably, these differences are
associated with the formation time of the active species in each system. A follow-up of the
cyclohexane oxidation by UV-vis spectroscopy shows that, in dimethyl carbonate, this
metalloporphyrin was not fully converted into the active species, maintaining a part in the form of
MnIIIP (Figure 7), for both tested oxidants. On the other hand, in an analogous system involving the
same catalyst, but in ethyl acetate, there is a complete conversion of the metalloporphyrin to the active
species, with a very low amount of MnIIIP (Figure 7). The dipole moment values and dielectric constant
for ethyl acetate are close to those for dichloromethane, which probably justifies the greater formation
of the active species and higher yields for systems with ethyl acetate are higher than those observed
in dimethyl carbonate.
Figure 7. Evolution of the UV-vis absorption spectrum of the cyclohexane oxidation catalyzed by
[MnIII(T2,4,5TMPP)Cl] in the green solvents: (a) PhIO/ethyl acetate; (b) PhI(OAc)2/ethyl acetate; (c)
PhIO/dimethyl carbonate; (d) PhI(OAc)2/dimethyl carbonate.

The dichloromethane/PhIO/[MnIII(T2,4,5TMPP)Cl] system yielded the products (16% alcohol
and 24% total) to a similar extent to those when using the catalysts with only one methoxy ([MnIIIT4(-
OMe)PPCl], 18% alcohol and 23% total) [31] or two methoxy groups ([MnIIIT3,5DMPP]Cl], 14% alcohol
and 21% total) [30], while the dichloromethane/PhI(OAc)2/[MnIII(T2,4,5TMPP)Cl] system showed yields
of the products (23% alcohol and 33% total) to a greater extent than those observed when using
catalysts with only one methoxy {[MnIIIT4(-OMe)PPCl], 14% alcohol and 19% total} [31] or two
methoxy groups {[MnIII(T3,5DMPP)Cl], 14% alcohol and 19% total} [30]. These latter results confirm
that the presence of three methoxy groups in the aryl group of the metalloporphyrin at meso positions
afforded a more robust catalyst.
Once the metalloporphyrin [MnIII(T2,4,5TMPP)Cl] was shown to be more stable in the reaction
medium than the first-generation catalyst, we decided to evaluate the influence of temperature on
o
product yields. When the reaction was carried out in ethyl acetate, using PhIO as oxidant, at 0 C the
o
total yield decreased to 21% and at 40 C, this value increased to 84%; for both cases these results
are following by an increase of the selectivity for alcohol and an decrease in the catalyst stability
(Table S1, Supplementary Material). However, we believe that conducting the reaction at a higher
temperature is not adequate, since we are seeking to develop efficient systems that meet the
principles of green chemistry and under mild conditions.
We decided to evaluate how the change in catalyst concentration would affect the reaction
yield in the system [MnIII(T2,4,5TMPP)Cl]/PhIO/ethyl acetate (Results in Figure S7, Supplementary
Material). It can be seen that the increase or decrease of the amount of catalyst in the medium do not
cause an increase in yield for cyclohexanol or even in total yield (data not shown). For the case of the
molar ratio 0.5:10 (catalyst:oxidant) there is a higher decrease in yields, probably because the number
of effective collisions between reacting particles decreases. On the other hand, for the molar ratio
4:10, a higher catalyst destruction should occur. Thus, the 1:10 molar ratio proved to be the most
adequate for the studied systems.
The systems using the new catalyst, in the presence of PhIO and additives, were more
efficient than those already reported in the literature [30, 31]. In addition, an increase in the catalyst
stability was observed, which probably explains the better catalytic efficiency of [MnIII(T2,4,5TMPP)Cl]
compared to analog systems. This same behavior was observed when PhI(OAc)2 replaced PhIO.
Thus, these results reinforce the possibility of using PhI(OAc)2 instead of PhIO.
When we verified the performance of the second generation metalloporphyrin
{[MnIII(T2,4,5TMPP)Cl]} in the green solvents, in the presence or absence of the additive, the highest
total yields (cyclohexanol + cyclohexanone) were obtained when using ethyl acetate, a similar trend
observed for the first generation catalyst ([MnIII(TPP)Cl]). We believe that these differences in yields in
the two green solvents are directly associated with the formation of the active species (as observed in
figure 7). For a better understanding of the process, in the different solvents studied, it is necessary to
carry out theoretical studies to evaluate the influence in the formation/stabilization of the active
species responsible for the oxidation of the substrate. To the best of our knowledge, these studies
have not been developed in cyclohexane oxidation catalyzed by metalloporphyrins so far.

Considering only the selectivity for alcohol and the use of additives it was possible to observe
the highest value of 70% was achieved for the systems with both catalysts in PhI(OAc)2/water/dimethyl
carbonate. A higher selectivity for alcohol (100%) has already been observed for second generation
metalloporphyrins in acetonitrile (which is not a green solvent) [12] or in the absence of solvent [17].
In order to develop an even greener system and minimize waste generation, we tested the
efficiency of the catalysts [MnIII(TPP)Cl] and [MnIII(T2,4,5TMPP)Cl] in the cyclohexane oxidation in the
absence of solvent (Table 1). For these systems, imidazole was not evaluated as additive because it
was insoluble in cyclohexane.
Table 1. Product yields obtained during the cyclohexane oxidation by PhIO or PhI(OAc)2 in absence of
solvents and under aerobic conditions, with and without water as an additive.
Yields (%)
Selectivityc
Catalyst
Bleachingd (%)
System
C-ola
15
34
20
7
C-onea
Totalb
19
49
25
9
(%)
79
69
80
78
63
75
83
[MnIII(TPP)Cl]/PhIO
[MnIII(TPP)Cl]/PhIO/water
[MnIII(T2,4,5TMPP)Cl]/PhIO
[MnIII(T2,4,5TMPP)Cl]/PhIO/water
[MnIII(TPP)Cl]/PhI(OAc)2
[MnIII(TPP)Cl]/PhI(OAc)2/water
[MnIII(T2,4,5TMPP)Cl]/PhI(OAc)2
[MnIII(T2,4,5TMPP)Cl]/PhI(OAc)2/water
4
15
5
72
68
60
93
50
52
86
62
2
5
3
8
33
10
12
11
2
44
12
14
2
86
o
Reaction conditions: MnP/Oxidant/cyclohexane molar ratio = 1:10:13870, 25 C, magnetic stirring,
90 min. of reaction. a Yields (%) based on the oxidant. C-ol: cyclohexanol and C-one: cyclohexanone.
b
c
Total yields = (%C-ol + %C-one). Selectivity for the alcohol was determined from the relation:
d
Selectivity = 100 × [%C-ol/(%C-ol + %C-one)]. The degree of destruction of the catalyst was
calculated based on the UV–Vis absorption spectra recorded at the end of the reaction.
Despite the lack of solvent (with or without additive), the systems showed an increase in the
alcohol selectivity. The values were limited to 86% and the total yields were not higher than the ones
in the presence of solvents. We believe that the differences observed for the second generation
metalloporphyrin are due to the type of substituent in the aryl group of the meso positions of the
macrocycle. In the work of Góes et al. [17], in which 100% alcohol selectivity was observed, the
catalysts contained one or two nitro groups, which are electron withdrawing groups that promote
destabilization of the MnVOP active species, favoring the exclusive formation of the alcohol. On the
other hand, in the present work, the three substituents are an -OCH3 type, which are donor groups of
electronic density, justifying the lower alcohol selectivity [39, 40]. In addition, the catalyst
[MnIII(TPP)Cl], without any group that promotes this destabilization of the MnVOP active species, also
did not present 100% selectivity for the oxidation of cyclohexane in the absence of solvents (greatest
selectivity: 79%). Even in the presence of water [with PhIO or PhI(OAc)2], the yields were still lower
than those already observed for systems in the presence of the solvent.

Conclusions
Metalloporphyrin compounds have proved themselves to be of great interest for use as
catalysts in the search for more efficient cyclohexane oxidation systems. Aiming to develop eco-
friendly systems for this reaction, the known [MnIII(TPP)Cl] and new [MnIII(T2,4,5TMPP)Cl] catalysts
were obtained and their activity was evaluated using green solvents (ethyl acetate and dimethyl
carbonate) and solvent-free systems. In addition, the effect of additives (water and imidazole) was
also studied.
Ethyl acetate was an appropriate solvent to replace the chlorinated solvents in the
cyclohexane oxidation. In some systems, the addition of small amounts of additives (water or
imidazole) improved the performance of the catalysts. It is important to emphasize that the amount of
imidazole/water employed in this work was very small. Moreover, each metalloporphyrin must have its
activity studied in each system of transformation of organic substrates, in order to determine which is
the "ideal" system for its maximum performance.
We believe that these results may stimulate the development of new cyclohexane oxidation
systems that employ other green solvents and/or environmentally friendly oxidants.
Acknowledgments
This study was financed in part by the Coordenação de Aperfeiçoamento de Pessoal de
Nível Superior – Brasil (CAPES) – Finance Code 001, Fundação de Amparo à Pesquisa do
Estado de Minas Gerais (FAPEMIG) and Conselho Nacional de Desenvolvimento Científico e
Tecnológico (CNPq).
References
[1] Z. Tian, A. Fattahi, L. Lis, S. Kass, Cycloalkane and cycloalkene C-H bond dissociation energies, J.
Am. Chem. Soc., 128 (2006) 17087-17092.
[2] R. Jevtic, P. Ramachandran, M. Dudukovic, Effect of Oxygen on Cyclohexane Oxidation: A Stirred
Tank Study, Ind. Eng. Chem. Res, 48 (2009) 7986-7993.
[3] U. Schuchardt, W.A. Carvalho, E.V. Spinace, Why is it interesting to study cyclohexane oxidation,
Synlett, (1993) 713-718.
[4] U. Schuchardt, D. Cardoso, R. Sercheli, R. Pereira, R.S. de Cruz, M.C. Guerreiro, D. Mandelli, E.V.
Spinace, E.L. Fires, Cyclohexane oxidation continues to be a challenge, Appl. Catal. A-Gen., 211
(2001) 1-17.
[5] P.T.W. Anastas, J. C., Green Chemistry: Theory and Practice, Oxfor University Press, New York,
1998.
[6] C.M. Che, V.K.Y. Lo, C.Y. Zhou, J.S. Huang, Selective functionalisation of saturated C-H bonds
with metalloporphyrin catalysts, Chem. Soc. Rev., 40 (2011) 1950-1975.

[7] H.J. Lu, X.P. Zhang, Catalytic C-H functionalization by metalloporphyrins: recent developments and
future directions, Chem. Soc. Rev., 40 (2011) 1899-1909.
[8] M. Costas, Selective C-H oxidation catalyzed by metalloporphyrins, Coord. Chem. Rev., 255 (2011)
2912-2932.
[9] C.L. Hill, B.C. Schardt, Alkane activation and functionalization under mild conditions by a
homogeneus manganese(III) porphyrin-iodosylbenzene oxidizing sysem, J. Am. Chem. Soc., 102
(1980) 6374-6375.
[10] F.G. Doro, J.R.L. Smith, A.G. Ferreira, M.D. Assis, Oxidation of alkanes and alkenes by
iodosylbenzene and hydrogen peroxide catalysed by halogenated manganese porphyrins in
homogeneous solution and covalently bound to silica, J. Mol. Catal. A-Chem., 164 (2000) 97-108.
[11] G.M. Ucoski, K. Castro, K.J. Ciuffi, G.P. Ricci, J.A. Marques, F.S. Nunes, S. Nakagaki, Use of iron
and manganese porphyrins in solution and immobilized on silica obtained by the sol-gel process as
catalyst in the oxidation of organic substrates, Appl. Catal. A-Gen., 404 (2011) 120-128.
[12] B.R.S. Lemos, D. CarvalhoDa-Silva, D.Z. Mussi, L.D. Santos, M.M. da Silva, M. de Carvalho, J.S.
Reboucas, Y.M. Idemori, High selectivity toward cyclohexanol in oxidation of cyclohexane using
manganese aminophenylporphyrins as catalysts, Appl. Catal. A-Gen., 400 (2011) 111-116.
[13] G. Ferreira, K. Castro, G. Machado, R. Ribeiro, K. Ciuffi, G. Ricci, J. Marques, S. Nakagaki,
Manganese porphyrin in solution and heterogenized in different materials mediates oxidation of
hydrocarbons by iodosylbenzene, J. Mol. Catal. A-Chem., 378 (2013) 263-272.
[14] V.S. da Silva, A.M. Meireles, D.C. da Silva Martins, J.S. Reboucas, G. DeFreitas-Silva, Y.M.
Idemori, Effect of imidazole on biomimetic cyclohexane oxidation by first-, second-, and third-
generation manganese porphyrins using Phi and PhI(OAc)(2) as oxidants, Appl. Catal. A-Gen., 491
(2015) 17-27.
[15] J.A. Smegal, C.L. Hill, Hydrocarbon functionalization by the (iodosylbenzene)manganese(IV)
porphyrin complexes from the (tetraphenylporphinato)manganese(III)-iodosylbenzene catalytic
hydrocarbon oxidation system – mechanism and reaction chemistry, J. Am. Chem. Soc., 105 (1983)
3515-3521.
[16] M. Fontecave, D. Mansuy, Monooxygenas-like oxidations of olefins and alkanes catalyzed by
manganese porphyrins – comparison of systems involving either O2 and ascorbate or
iodosylbenzene, Tetrahedron, 40 (1984) 4297-4311.
[17] M.G.d.A. Tôrres, V.S. Silva, Y.M. Idemori, G. DeFreitas-Silva, Manganese porphyrins as efficient
catalysts in solvent-free cyclohexane oxidation., Arab. J. Chem., 2017.
[18] J.G. Sharefkin, H. Saltzman, Iodosobenzene, Org. Synth., 43 (1963) 658-660.
[19] T.P. Wijeskera, D. Dolphin, Synthetic Aspects of Porphyrin and Metalloporphyrin Chemistry, in:
R.A. Sheldon (Ed.) Metalloporphyrins in Catalytic Oxidations, Marcel Dekker, Inc., New York, 1994,
pp. 193-239.
[20] A.M.R. Gonsalves, J.M.T.B. Varejão, M.M. Pereira, Some new aspects related to the synthesis of
meso-substituted porphyhrins, J. Heterocyclic Chem., 28 (1991) 635-640.
[21] A.D. Adler, F.R. Longo, F. Kampas, J. Kim, On preparation of metalloporphyrins, J. Inorg. Nuc.
Chem., 32 (1970) 2443-2445.

[22] V.S. da Silva, L.I. Teixeira, E. do Nascimento, Y.M. Idemori, G. DeFreitas-Silva, New manganese
porphyrin as biomimetic catalyst of cyclohexane oxidation: Effect of water or imidazole as additives,
Appl. Catal. A-Gen., 469 (2014) 124-131.
[23] A. Harriman, Luminescence of porphyrins and metalloporphyrins. 2. Copper(II), chromium(III),
manganese(III), iron(II) and iron(III) porphyrins, J. Chem. Soc. Farad. T. 1, 77 (1981) 369-377.
[24] L.J. Boucher, Manganese porphyrin complexes, Coord. Chem. Rev., 7 (1972) 289-329.
[25] K. Nakamoto, Infrared and Raman Spectra of Inorganic and Coordination Compounds, 5th ed.,
Wiley, New York, 1997.
[26] L.J. Boucher, J.J. Katz, Infrared spectra of metalloporphyrins (4000-160 cm-1), J. Am. Chem.
Soc., 89 (1967) 1340-1345.
[27] M. Levere, P. Chambon, S. Rannard, T. McDonald, MADIX polymerization of vinyl acetate using
ethyl acetate as a green solvent; near-complete monomer conversion with molecular weight control, J.
Polym. Sci. Pol. Chem., 55 (2017) 2427-2431.
[28] M. Sahoo, J. Rana, M. Subaramanian, E. Balaraman, Room-Temperature Direct Arylation of
Anilides under External Oxidant-Free Conditions Using CO2-Derived Dimethyl Carbonate (DMC) as a
'Green' Solvent, ChemistrySelect, 2 (2017) 7565-7569.
[29] D.C. da Silva, G. DeFreitas-Silva, E. do Nascimento, J.S. Reboucas, P.J.S. Barbeira, M. de
Carvalho, Y.M. Idemori, Spectral, electrochemical, and catalytic properties of a homologous series of
manganese porphyrins as cytochrome P450 model: The effect of the degree of beta-bromination, J.
Inorg. Biochem., 102 (2008) 1932-1941.
[30] V.S. da Silva, S. Nakagaki, G.M. Ucoski, Y.M. Idemori, G. DeFreitas-Silva, New highly brominated
Mn-porphyrin: a good catalyst for activation of inert C-H bonds, Rsc Adv., 5 (2015) 106589-106598.
[31] V.S. da Silva, W.C.D. Vieira, A.M. Meireles, G.M. Ucoski, S. Nakagaki, Y.M. Idemori, G.
DeFreitas-Silva, Biomimetic oxidation of cyclic and linear alkanes: high alcohol selectivity promoted by
a novel manganese porphyrin catalyst, New J. Chem., 41 (2017) 997-1006.
[32] G.D. Silva, D.C. da Silva, A.S. Guimaraes, E. do Nascimento, J.S. Reboucas, M.P. de Araujo, M.
de Carvalho, Y.M. Idemori, Cyclohexane hydroxylation by iodosylbenzene and iodobenzene, diacetate
catalyzed by a new beta-octahalogenated Mn-porphyrin complex: The effect of meso-3-pyridyl
substituents, J. Mol. Catal. A-Chem., 266 (2007) 274-283.
[33] Z. Li, C.G. Xia, Oxidation of hydrocarbons with iodobenzene diacetate catalyzed by
manganese(III) porphyrins in a room temperature ionic liquid, J. Mol. Catal. A-Chem., 214 (2004) 95-
101.
[34] Z. Li, C. Xia, C. Xu, Oxidation of alkanes catalyzed by manganese(III) porphyrin in an ionic liquid
at room temperature, Tetrahedron Lett., 44 (2003) 9229-9232.
[35] K. W. Kwong, T.-H. Chen, W. Luo, H. Jeddi, R. Zhang, A biomimetic oxidation catalyzed by
manganese(III) porphyrins and iodobenzene diacetate: Synthetic and mechanistic investigations,
Inorg. Chim. Acta, 430 (2015) 176-183.
[36] M.J. Gunter, P. Turner, The role of the axial ligand in meso-tetraarylmetalloporphyrin models of
the P-450 cytrochromes, J. Mol. Catal., 66 (1991) 121-141.

[37] K. Christoforidis, D. Pantazis, L. Bonilla, E. Bletsa, M. Louloudi, Y. Deligiannakis, Axial ligand
effect on the catalytic activity of biomimetic Fe-porphyrin catalyst: An experimental and DFT study, J.
Catal., 344 (2016) 768-777.
[38] B. Meunier, Metalloporphyrins as versatile catalysts for oxidations reactions and oxidative DNA
cleavage, Chem. Rev., 92 (1992) 1411-1456.
[39] J.F. Bartoli, O. Brigaud, P. Battioni, D. Mansuy, Hydroxylation of linear alkanes catalyzed by iron
porphyrins – particular efficacy and regioselectivity of perhalogenated porphyrins, J. Chem. Soc.
Chem. Commun., (1991) 440-442.
[40] E. Baciocchi, T. Boschi, C. Galli, A. Lapi, P. Tagliatesta, Epoxidation and hydroxylation reactions
catalyzed
by
the
manganese
and
iron
complexes
of
5,10,15,20-tetrakis(2,6-
dimethoxyphenyl)porphyrin, Tetrahedron, 53 (1997) 4497-4502.

An eco-friendly approach to the cyclohexane oxidation catalyzed by
manganese porphyrins: green and solvent-free systems
Graphical Abstract Synopsis
Total yields (cyclohexanol + cyclohexanone) up to 90% were achieved in cyclohexane oxidation using
ethyl acetate, which is an efficient green solvent to replace dichloromethane.
