radical I-b was essentially unreactive toward
electron-poor olefins [calculated rate constant
kcalc ~ 10−1 M–1 s–1 (21)], bromine abstraction
became possible, providing the desired prod-
ucts in good yields.
formation (via VIII) without the need for pre-
cious metals (see fig. S14 for a proposed mech-
anism). As shown in Fig. 4A, we found this
dual XAT–[Co] protocol feasible, thus allowing
direct olefination of primary, secondary, and
tertiary alkyl iodides and bromides exclusively
as the E isomers (51 to 74, with the exception
of 54 and 62). The broad functional group
compatibility was demonstrated with the suc-
cessful engagement of substrates containing
phenol, aniline, and benzoic acid moieties, as
well as aryl bromide, boronic acid, and phos-
phine groups that could limit application under
transition metal catalysis. The olefination was
also very effective in intramolecular settings,
as showcased by the construction of tricyclic
75 in good yield. Couplings with aryl iodides
were attempted but generally resulted in low
yields.
In a final effort to establish the generality
of this XAT strategy, we turned our attention
to the direct aromatic C–H alkylation via rad-
ical intermediates (Fig. 4B; see fig. S15 for a
proposed mechanism). Recently, the use of
zinc alkylsulfinates has provided a powerful
and effective solution to this synthetic chal-
lenge (41, 42). Because these reagents are often
prepared from the corresponding halides, a
methodology that directly uses these building
blocks would obviate multistep synthesis of
any reactive intermediate. In this case, how-
ever, a photoredox system for a-aminoalkyl
radical generation is difficult to implement,
owing to the mechanistic requirement of a
second oxidation after radical addition to the
arene to allow rearomatization (IX→X). The
broad set of reactivity modes for a-aminoalkyl
radical generation enabled identification of
simple thermal, net oxidative conditions for
the direct alkylation of caffeine with alkyl
iodides, without the need for light or catalysts
(76 to 80). This manifold for aromatic C–H
alkylation was compatible with the installa-
tion of primary, secondary, and tertiary alkyl
groups and could be extended to other hete-
roarenes commonly found in bioactive mol-
ecules, such as indoles and azoles as well as
benzenoids (43) (81 to 87). Furthermore, we
demonstrated that aryl iodide activation and
subsequent sp2-sp2 coupling (44) is also pos-
sible, as shown by the successful preparation
of 88 to 91.
2. S. P. Pitre, N. A. Weires, L. E. Overman, J. Am. Chem. Soc. 141,
2800–2813 (2019).
3. C. K. Prier, D. A. Rankic, D. W. C. MacMillan, Chem. Rev. 113,
5322–5363 (2013).
4. J. Xuan, Z.-G. Zhang, W.-J. Xiao, Angew. Chem. Int. Ed. 54,
15632–15641 (2015).
5. J. K. Matsui, S. B. Lang, D. R. Heitz, G. A. Molander, ACS Catal.
7, 2563–2575 (2017).
6. A. Togni et al., Angew. Chem. Int. Ed. 10.1002/anie.201911660
(2019).
7. J. D. Nguyen, E. M. D’Amato, J. M. R. Narayanam,
C. R. J. Stephenson, Nat. Chem. 4, 854–859 (2012).
8. H. Kim, C. Lee, Angew. Chem. Int. Ed. 51, 12303–12306
(2012).
9. Y. Shen, J. Cornella, F. Juliá-Hernández, R. Martin, ACS Catal.
7, 409–412 (2017).
10. D. Alpers, M. Gallhof, J. Witt, F. Hoffmann, M. Brasholz,
Angew. Chem. Int. Ed. 56, 1402–1406 (2017).
11. J. L. Kuo, C. Lorenc, J. M. Abuyuan, J. R. Norton, J. Am. Chem. Soc.
140, 4512–4516 (2018).
12. G. Nocera et al., J. Am. Chem. Soc. 140, 9751–9757
(2018).
13. W. P. Neumann, Synthesis 1987, 665–683 (1987).
14. C. Chatgilialoglu, C. Ferreri, Y. Landais, V. I. Timokhin, Chem.
Rev. 118, 6516–6572 (2018).
15. H. Yorimitsu, K. Oshima, in Radicals in Organic Synthesis,
P. Renaud, M. P. Sibi, Eds. (Wiley, 2008), pp. 11–27.
16. C. Le, T. Q. Chen, T. Liang, P. Zhang, D. W. C. MacMillan,
Science 360, 1010–1014 (2018).
17. P. Zhang, C. C. Le, D. W. C. MacMillan, J. Am. Chem. Soc. 138,
8084–8087 (2016).
We next explored the alkyl iodide scope
by using Boc-protected dehydroalanine as an
olefin acceptor, thus providing convenient ac-
cess to unnatural amino acids (24 to 35). In
this case, a variety of organyl groups bearing
common functionalities (e.g., free alcohol, alkyl
chloride, silane, and terminal alkyne) were
compatible, reflecting the mildness of the re-
action conditions. This protocol has also been
carried out at gram scale without erosion in
yield. The ability to generate primary alkyl
radicals complements approaches that use
oxalates and trifluoroborates, which are
known to experience sluggish fragmentations
(34, 35). When alkyl halides activated toward
SN2 (second-order nucleophilic displacement)
attack by Et3N (e.g., 29 and 32) were em-
ployed, the desired products were, unsurpris-
ingly, obtained in low yields. This hurdle was
addressed by adjusting the steric properties
of the XAT reagent: Efficient couplings were
achieved with the use of the bulkier amine
1,2,2,6,6-pentamethylpiperidine (PMP; 1c). We
have also been able to extend this methodol-
ogy to unactivated aryl iodides by using the
more hindered but less stabilized a-aminoalkyl
radical derived from triisobutylamine (1d).
These conditions enabled direct access to aryl
radicals by sp2 C–I bond cleavage and were
applied to the one-pot transformation of to-
sylated serine into phenylalanine derivatives
(36 to 39). Overall, these results illustrate how
the large structural diversity of available ter-
tiary amines facilitates the rational tailoring
of the a-aminoalkyl radical reactivity to ad-
dress different challenges in carbon-halogen
bond activation.
The XAT strategy for cross-electrophile cou-
pling is not restricted to electron-poor olefins.
We also achieved efficient allylation of alkyl
and aryl halides by using simple allyl chlorides
and other pseudohalides (40 to 50) (Fig. 3C;
see fig. S12 for a proposed mechanism). This
approach bypasses the conventional conver-
sion of one of the two coupling partners into a
Grignard or organozinc reagent (36) and there-
fore tolerates functionalities, such as free alco-
hol and ketone, that are often troublesome
with organometallics.
To further demonstrate the versatility of
this activation mode, we sought to adapt it to
target the use of alkyl halides in Heck-type
olefinations, a long-standing challenge in con-
ventional palladium catalysis, owing to unde-
sired b-hydride elimination (37–39). Specifically,
we questioned whether, after addition of alkyl
radicals to suitable olefins (VII), a cobaloxime
cocatalyst might trigger a dehydrogenation re-
action (40), thus leading to sp3-sp2 C–C bond
18. W. H. Tamblyn, E. A. Vogler, J. K. Kochi, J. Org. Chem. 45,
3912–3915 (1980).
19. See the supplementary materials for more information.
20. J. C. Scaiano, in Reactive Intermediate Chemistry, R. A. Moss,
M. S. Platz, M. Jones, Eds. (Wiley, 2005), pp. 847–871.
21. J. Lalevée, B. Graff, X. Allonas, J. P. Fouassier, J. Phys. Chem. A
111, 6991–6998 (2007).
22. K. U. Ingold, J. Lusztyk, J. C. Scaiano, J. Am. Chem. Soc. 106,
343–348 (1984).
23. K. Nakajima, Y. Miyake, Y. Nishibayashi, Acc. Chem. Res. 49,
1946–1956 (2016).
24. S. G. Cohen, A. Parola, G. H. Parsons, Chem. Rev. 73, 141–161
(1973).
25. J. K. Laha, K. S. S. Tummalapalli, A. Nair, N. Patel, J. Org.
Chem. 80, 11351–11359 (2015).
26. D. D. M. Wayner, J. J. Dannenberg, D. Griller, Chem. Phys. Lett.
131, 189–191 (1986).
27. J. Luo, J. Zhang, ACS Catal. 6, 873–877 (2016).
28. V. Soulard, G. Villa, D. P. Vollmar, P. Renaud, J. Am. Chem. Soc.
140, 155–158 (2018).
29. D. A. Everson, D. J. Weix, J. Org. Chem. 79, 4793–4798
(2014).
30. E. Richmond, J. Moran, Synthesis 50, 499–513 (2018).
31. K. M. M. Huihui, R. Shrestha, D. J. Weix, Org. Lett. 19, 340–343
(2017).
32. F. Zhou, J. Zhu, Y. Zhang, S. Zhu, Angew. Chem. Int. Ed. 57,
4058–4062 (2018).
33. R. A. Aycock, C. J. Pratt, N. T. Jui, ACS Catal. 8, 9115–9119
(2018).
34. C. C. Nawrat, C. R. Jamison, Y. Slutskyy, D. W. C. MacMillan,
L. E. Overman, J. Am. Chem. Soc. 137, 11270–11273
(2015).
35. C. Lévêque, L. Chenneberg, V. Corcé, C. Ollivier, L. Fensterbank,
Chem. Commun. 52, 9877–9880 (2016).
36. H. Yorimitsu, K. Oshima, Angew. Chem. Int. Ed. 44, 4435–4439
(2005).
37. M. R. Netherton, G. C. Fu, in Palladium in Organic Synthesis,
J. Tsuji, Ed. (Springer, 2005), pp. 85–108.
38. G.-Z. Wang, R. Shang, W.-M. Cheng, Y. Fu, J. Am. Chem. Soc.
139, 18307–18312 (2017).
The results presented here demonstrate that
alkyl and aryl halides can be converted to
carbon radicals by XAT using a-aminoalkyl
radicals. We believe that the broad scope, func-
tional group tolerance, and modularity of this
approach for carbon-halogen bond activation
will likely be of great utility to chemists in both
academia and industry.
39. D. Kurandina, M. Parasram, V. Gevorgyan, Angew. Chem. Int.
Ed. 56, 14212–14216 (2017).
40. X. Sun, J. Chen, T. Ritter, Nat. Chem. 10, 1229–1233
(2018).
41. Y. Fujiwara et al., Nature 492, 95–99 (2012).
42. R. Gianatassio et al., Angew. Chem. Int. Ed. 53, 9851–9855
(2014).
43. Z. Jiao, L. H. Lim, H. Hirao, J. S. Zhou, Angew. Chem. Int. Ed.
57, 6294–6298 (2018).
REFERENCES AND NOTES
44. I. Ghosh, T. Ghosh, J. I. Bardagi, B. König, Science 346,
725–728 (2014).
1. J. M. Smith, S. J. Harwood, P. S. Baran, Acc. Chem. Res. 51,
1807–1817 (2018).
