molecules
Article
Design, Synthesis, and Biological Evaluation of Some
Novel Pyrrolizine Derivatives as COX Inhibitors with
Anti-Inflammatory/Analgesic Activities and Low
Ulcerogenic Liability
Ahmed M. Gouda 1,2,*, Hamed I. Ali 1,3, Waleed H. Almalki 4, Mohamed A. Azim 1,5
Mohammed A. S. Abourehab 6 and Ahmed H. Abdelazeem 2
,
1
Department of Pharmaceutical Chemistry, Faculty of Pharmacy, Umm Al-Qura University, Makkah 21955,
Saudi Arabia; hamed_ali37@yahoo.com (H.I.A.); mohammadazim97@yahoo.com (M.A.A.)
Department of Medicinal Chemistry, Faculty of Pharmacy, Beni-Suef University, Beni-Suef 62514, Egypt;
ahmed.abdelazeem@pharm.bsu.edu.eg
Rangel College of Pharmacy, Health Science Center, Texas A & M University, Kingsville, TX 78363, USA
Department of Pharmacology, Faculty of Pharmacy, Umm Al-Qura University, Makkah 21955, Saudi Arabia;
whmalki@uqu.edu.sa
Department of Pharmaceutical Chemistry, Faculty of Pharmacy, Cairo University, Cairo 11562, Egypt
Department of Pharmaceutics, Faculty of Pharmacy, Umm Al-Qura University, Makkah 21955, Saudi Arabia;
maabourehab@uqu.edu.sa
2
3
4
5
6
*
Correspondence: amsaid@uqu.edu.sa or ahmed5_pharm5@yahoo.com; Tel.: +966-599-940-159;
Fax: +966-2527-0000 (ext. 4217)
Academic Editor: Wei-Zhu Zhong
Received: 18 December 2015; Accepted: 1 February 2016; Published: 8 February 2016
Abstract: Non-steroidal anti-inflammatory drugs (NSAIDs) are the most commonly prescribed
anti-inflammatory and pain relief medications. However, their use is associated with many drawbacks,
including mainly serious gastric and renal complications. In an attempt to circumvent these risks,
a set of N-(4-bromophenyl)-7-cyano-6-substituted-H-pyrrolizine-5-carboxamide derivatives were
designed, synthesized and evaluated as dual COX/5-LOX inhibitors. The structural elucidation,
in vivo anti-inflammatory and analgesic activities using a carrageenan-induced rat paw edema model
and hot plate assay, were performed, respectively. From the results obtained, it was found that the newly
synthesized pyrrolizines exhibited IC50 values in the range of 2.45–5.69
µM and 0.85–3.44 µM for COX-1
and COX-2, respectively. Interestingly, compounds 12 13 16 and 17 showed higher anti-inflammatory
,
,
and analgesic activities compared to ibuprofen. Among these derivatives, compounds 16 and 19
displayed better safety profile than ibuprofen in acute ulcerogenicity and histopathological studies.
Furthermore, the docking studies revealed that compound 17 fits nicely into COX-1 and COX-2 binding
sites with the highest binding affinity, while compound 16 exerted the highest binding affinity for 5-LOX.
In light of these findings, these novel pyrrolizine-5-carboxamide derivatives represent a promising
scaffold for further development into potential dual COX/5-LOX inhibitors with safer gastric profile.
Keywords: pyrrolizine; anti-inflammatory; analgesic; COX; 5-LOX; ulcerogenicity
1. Introduction
NSAIDs are some of the most frequently used medications in the world [
is usually associated with several serious side effects and complications [ ]. Erosion and bleeding of
the gastric mucosa are the most prevalent risks. Many of these complications can be life-threatening
1]. Their widespread use
2–4
and several mortalities have been reported [
4
,5
]. The gastrointestinal toxicity of NSAIDs is mediated
Molecules 2016, 21, 201; doi:10.3390/molecules21020201
www.mdpi.com/journal/molecules

Molecules 2016, 21, 201
2 of 21
either by the inhibition of the cytoprotective PGs biosynthesis [
6] or by the induction of GIT necrotic
effects [
7]. These necrotic effects were detected for selective and nonselective COX inhibitors [8], even
at low prophylactic doses [9].
To date, there is no safe nonsteroidal anti-inflammatory agent that could be used in patients with
peptic ulcers, renal failure or asthma. However, on reviewing the literature, several strategies were found
to afford GIT safer anti-inflammatory agents. Of these strategies, conversion of the acidic COX inhibitors
into non-acidic prodrugs [10], improving selectivity for the COX-2 enzyme [11] and development of nitric
oxide releasing NSAIDs [12] were the most commonly utilized. Recently, introducing dual COX/5-LOX
inhibitors were the focus of researchers in order to develop safer anti-inflammatory agents [13]. Several
pyrrolizine derivatives (Figure 1) were identified to have anti-inflammatory, analgesic, and antipyretic
activities. Of these derivatives, ketorolac (
2.9 for COX-1 [14]. Owing to its potent analgesic activity, ketorolac is often used in the treatment of severe
neuropathic pain [15]. Moreover, licofelone ( ) acts as a dual COX/5-LOX inhibitor with IC50 values
1) is a nonselective COX-1/2 inhibitor with a selectivity ratio of
2
in the submicromolar range [16]. Interestingly, licofelone revealed anti-inflammatory and analgesic
efficiency in asthmatic patients. Compared to other COX/5-LOX inhibitors which showed also good GIT
tolerance, licofelone is the only COX/5-LOX inhibitor that showed an acceptable safety level in clinical
use [17]. The replacement of the 4-chlorophenyl group at C5 in licofelone with a 5-chlorothiophen-2-yl
moiety in compound 3 resulted in almost the same COX-1/5-LOX inhibitory activity [18].
Figure 1. The IC50 values of pyrrolizine-based anti-inflammatory agents 1–3 linked with a carboxylic
acid moiety.
In order to avoid the gastric side effects, several reported pyrrolizines with nonselective COX
inhibitory activity lacking the distinctive free carboxylic group were designed [19 21]. For instance,
the diphenylpyrrolizine 19] and the 1-methoxypyrrolizine 20] showed anti-inflammatory activity
mediated by COX/5-LOX inhibition. Additionally, masking the carboxylic group in licofelone (
using a tolylsulfonimide moiety as in compound retained the 5-LOX inhibition (IC50 = 0.26 M) and
–
4
[
5 [
2
)
6
µ
increased the mPGES-1 inhibitory activity [21], as shown in Figure 2.
Figure 2. The IC50 values of pyrrolizine-based anti-inflammatory agents 4–6 lacking the free carboxylic
acid group.

Molecules 2016, 21, 201
3 of 21
Earlier, we have reported several pyrrolizine derivatives with moderate to high anti-inflammatory
activities [22]. In this report, compound exhibited approximately 50% reduction in rat paw edema
7
in comparison with ketorolac (Figure 3). Prompted by the aforementioned findings, we aimed in
this work to develop novel potent anti-inflammatory and analgesic agents with low GIT side effects.
We have designed several different analogs based on our previously reported anti-inflammatory
agent
in compound
7
using a lead optimization approach in drug design. In doing so, the free carboxylic group
was replaced with other non-acidic fragments (R1) to avoid the direct gastric insult
7
complications of the carboxylic group.
The impact of the electronic effect of these substituents (R1) on COX-1/-2 binding patterns was
evaluated by a molecular docking study. Moreover, the variation in the length of the spacer between
the pyrrolizine ring and the terminal (R) moiety was conducted. Seven compounds 12–18 from the
virtual designed library were selected for synthesis (Schemes 1–3) and biological evaluation based on
an initial filtration process using the docking tool against COX enzymes (Figure 3). Finally, a hybrid
compound 19 composed of the pyrrolizine precursor 12 and ibuprofen was designed to evaluate the
possible synergism resulted from the combination of these two compounds into one scaffold.
Scheme 1. Synthesis of compound 12. Reagents and reaction conditions: (a) (CH3)2SO4, benzene, CH2(CN)2;
(b) ClCH2COCl, AcOH, CH3COONa; (c) acetone, K2CO3, reflux, 24 h.
Scheme 2. Synthesis of compounds 13
48 h; ( ) 1-methylpiperazine, NaHCO3, absolute ethanol, reflux, 6 h; (
(d) benzoyl chloride, benzene, rt, 48 h.
–
16. Reagents and reaction conditions: (
a) ClCH2COCl, benzene,
b
c) KHCO3, DMF, rt, 48 h;

Molecules 2016, 21, 201
4 of 21
Scheme 3. Synthesis of compounds 17
chloride, acetone, K2CO3; rt, 12 h; ( ) oxalyl chloride, dry acetone, rt, 24 h; (
2. compound 12, dry benzene, rt, 24 h.
–
19. Reagents and reaction conditions: (
a) p-toluenesulfonyl
b
c) 1. ibuprofen, SOCl2;
Figure 3. Design strategies for compounds 12–18.
2. Results and Discussion
2.1. Chemistry
The synthesis of compounds
9 [23] and 11 [24] described in Scheme 1 involved previously
reported procedures. The pyrrolizine 12 was obtained from the reaction of N-(4-bromophenyl)-
2-chloroacetamide (11) with 2-(pyrrolidin-2-ylidene)malononitr´il1e (
9) as reported before [25]. The IR
spectrum of compound 12 revealed a stretching band at 2218 cm for the cyano group, in addition to
an absorption band at 1652 cm assigned for the carbonyl group (Figure S1). The 1H-NMR spectrum
´1
of compound 12 revealed three signals at
of the pyrrolizine nucleus in addition to two singlet signals at
δ
2.55, 3.00 and 4.41 ppm indicating the three CH2 groups
3.57 and 9.64 ppm attributed to the
δ
NH2 and NH protons, respectively (Figure S17a–c). The 13C-NMR spectrum revealed 13 signals and
DEPT-135 spectrum was used to differentiate between primary, secondary and tertiary carbon atoms
(Figures S18a–c and S19). The mass spectrum of compound 12 revealed the expected molecular ion
peak at m/z 344 (Figure S9).

Molecules 2016, 21, 201
5 of 21
Compounds 13 and 16 were prepared by acylation of the amino group at C6 in the parent
compound 12 using chloroacetyl chloride and benzoyl chloride, respectively (Scheme 2). The chloro
group in compound 13 was subjected to a nucleophilic substitution with N-methylpiperazine to afford
1
compounds 14. The structure of compound 13 was confirmed by its H-NMR spectrum where a
singlet signal at
δ 4.33 ppm was assigned for the CH2-Cl protons and two other singlets at δ 9.59 and
10.28 ppm were assigned for the two amidic protons (Figure S20a–c), whereas the 1H-NMR spectrum
of compound 14 showed an additional singlet at
δ 2.34 for its N-CH3, and two multiplets at δ 2.57 and
2.75 ppm attributed to the eight piperazine protons (Figure S22a–c). The 13C-NMR of compound 14
revealed the aliphatic carbons of the pyrrolizine and piperazine rings in the δ 25.02–61.16 ppm range
(Figure S23a–c).
Moreover, stirring compound 13 in DMF furnished the diazepine derivative 15 via an
intramolecular cyclization reaction. The structure of compound 15 was elucidated using different
analytical methods. The 1H-NMR spectrum of compound 15 revealed only one singlet at
δ
10.37 ppm
corresponding to the protons of the CONH function (Figure S24a–c), while the 13C-NMR spectrum
revealed two signals at 164.86 and 172.64 ppm assigned to the two carbonyl groups (Figure S25a–c).
On the other hand, compound 16 was obtained by acylation of the parent pyrrolizine 12 with benzoyl
chloride. The 1H-NMR spectrum of compound 16 revealed the two amide protons as singlets at
8.04
and 9.98 ppm (Figure S26a–c), while the 13C-NMR spectrum revealed the two carbonyl carbons at
157.54 and 169.18 ppm (Figure S27a–c). The mass spectra of compounds 13 15, and 16 showed the
δ
δ
δ
,
corresponding molecular ion peaks at 420, 384 and 448, respectively (Figures S10, S12 and S15).
6-(4-Methylphenylsulfonamido)-2,3-dihydro-1H-pyrrolizine (17), the dimer 18 and the hybrid
19 were obtained from the reaction of compound 12 with 4-tolylsulfonyl chloride, oxalyl chloride
and the acid chloride of ibuprofen, respectively (Scheme 3). The structural elucidation of compounds
17–19 was done using spectral and elemental analysis. The IR spectra of compounds 17–19 revealed
stretching bands at the range of 2222–2231 cm´1 indicating a cyano group, and other absorption
bands at the 1660–1746 cm´1 range indicating the carbonyl groups (Figures S6–S8). The 1H-NMR
spectra of compounds 17
assigned to the protons in the NH groups, in addition to a singlet at
protons in compound 17 (Figures S28, S30 and S33). Two signals at the range of
in the 13C-NMR spectrum of compound 19 were due to the two carbonyl carbons (Figure S34a–c).
–
19 displayed two signals in each compound in the
2.49 ppm attributed to the methyl
157.47–177.14 ppm
δ 6.57–10.72 ppm range
δ
δ
The mass spectra of compounds 17, 18 and 19 all showed the molecular ion peaks at 498, 742, and 532,
respectively (Figures S14–S16).
2.2. Biological Evaluation
2.2.1. In Vitro COX Inhibitory Assay
COX inhibition is the main mechanism of action of NSAIDs so far. The ability of the new
compounds 12 18 to inhibit COX enzymes was determined in an attempt to investigate their
–
mechanism of action. Both COX-1 and COX-2 inhibitory activities were evaluated using a COX
colorimetric inhibitor screening assay kit (Catalog No. 701050, Cayman Chemical Inc., Ann Arbor,
MI, USA) according to the previous reports [26–28]. The pyrrolizines 12–18 were tested against
indomethacin (as a nonselective COX inhibitor) and celecoxib (as a selective COX-2 inhibitor).
The results were expressed in terms of IC50 values and COX-1/COX-2 selectivity index (SI) was
calculated, (Table 1). The results demonstrated that the newly synthesized compounds 12
IC50 values in the range of 2.45–5.69 M for COX-1 and 0.85–3.44 M for COX-2. It was noteworthy
18 showed good COX-2 selectivity over COX-2, with selectivity indexes in the
–18 have
µ
µ
that compounds 12
–
2.89–6.03 range.

Molecules 2016, 21, 201
6 of 21
Table 1. In vitro COX-1/2 enzymes inhibition results of compounds 12–18.
COX-1
(IC50 µM) a
COX-2
(IC50 µM) a
SI b
Compd. No.
12
13
14
15
16
17
18
4.64
5.69
3.50
3.37
2.45
5.01
5.10
0.73
15.6
1.27
1.64
1.09
1.06
0.85
1.72
0.85
32.6
0.32
3.64
3.48
3.21
3.17
2.89
2.91
6.03
0.02
48.75
Indomethacin
Celecoxib
a
IC50 was calculated using three determinations for COX-1 (ovine) and COX-2 (human recombinant) screening
assay kit (Cat. No 701050, Cayman Chemical Inc.); b in vitro COX-2 selectivity index (SI) = IC50 of COX-1/IC50
of COX-2.
2.2.2. In Vivo Biological Evaluation
Anti-Inflammatory Activity
The carrageenan-induced rat paw edema model was utilized to investigate the anti-inflammatory
activity of compounds 12 19 relative to ibuprofen as a reference drug [29]. The mean changes in
edema thickness and anti-inflammatory activities of compounds 12 19 are presented in Figure 4
and Table 2. The parent compound 12 displayed higher anti-inflammatory activity than that of
ibuprofen. The additional 2-chloroacetyl, benzoyl and 4-tolylsulfonyl moieties in compounds 13 16
–
–
,
,
and 17, respectively, resulted in a remarkable increase in the anti-inflammatory activities compared
to compound 12. The replacement of the chloro atom in compound 13 by a 4-methylpiperazin-1-yl
in compound 14 resulted in a sharp decrease in the anti-inflammatory activity. Moreover, the dimer
18 showed lower activity than both ibuprofen and the parent compound 12, while the hybrid 19
showed weak activity after the first hour. However, an increase in the activity was observed after
three hours to be comparable to that of ibuprofen. Among all the newly synthesized compounds,
6-(2-chloroacetamido)-pyrrolizine-5-carboxamide (13) showed the highest anti-inflammatory activity,
while compound 14 was the least active one.
Figure 4. Change in edema thickness using carrageenan-induced rat paw edema mode of compounds
12
–
19 at 1 h (
ꢀ
), 2 h (
ꢀ
) and 3 h (
ꢀ
) after induction of inflammation; data expressed as mean ˘ SEM
,
(n = 6); data were analyzed by One way ANOVA followed by student-Newman-Keuls multiple
comparison test; a statistically significant from control (p < 0.001); b statistically significant from control
(p < 0.01); c statistically significant from control (p < 0.05).

Molecules 2016, 21, 201
7 of 21
Table 2. The anti-inflammatory activity (% inhibition of edema thickness) and ulcer indices of
compounds 12–19.
% Inhibition in Edema Thickness
Ulcerogenicity
% Protection c
Compd.
Potency a
UI b
1 h
2 h
3 h
Control
-
-
-
0
0
100
66.38
68.18
66.38
80.66
83.69
83.69
68.18
100
12
13
14
15
16
17
18
21.20
16.13
8.30
10.60
29.95
27.19
6.91
37.40
35.43
9.84
16.54
37.80
40.55
17.72
22.44
33.46
44.79
52.31
16.37
24.91
50.58
49.47
22.42
38.79
40.82
1.10
1.28
0.40
0.61
1.24
1.21
0.55
0.95
1.00
4.66
4.41
4.66
2.68
2.26
2.26
4.41
0
19
13.82
25.81
Ibuprofen
13.86
0
Anti-inflammatory activity (% inhibition of edema thickness) = (1
´
Lt/Lc)
ˆ
100; Lt is the mean increase in
paw thickness in rats treated with the tested compounds; Lc is the mean increase in paw thickness in control
group; a Potency = anti-inflammatory activity of tested compound/anti-inflammatory activity of ibuprofen
after 3 h of induction of inflammation; b Ulcer index (UI) = sum of (% incidence/10), average number of ulcers
c
and average severity; n = 6; percentage protection of ulcer (% inhibition of ulcer relative to ibuprofen) =
(UISt – UITest/UISt) ˆ 100.
Comparing the activity of compounds 13–18 with that of the parent compound 12, it was
conceptualized that the acylation of the amino group at C6 with aromatic/electron withdrawing groups
such as 2-chloroacetyl (13), benzoyl (16), 4-tolylsulfonyl (17), resulted in an observed improvement of
the anti-inflammatory activity. On the other hand, the replacement of the chloro atom in compound 13
with a 4-methylpiperazinyl moiety or the cyclization of the side chain as in diazepine derivative 15
decreases the inflammatory activity (Figure 5).
Figure 5. Relationship between the in vivo anti-inflammatory (at 3 h) and analgesic (at 2 h) activities of
the new compounds 12
–19 at a dose of 0.48 mmol/kg with the modifications in the chemical structure;
* activity means both anti-inflammatory and analgesic activities.
Analgesic Activity
The analgesic activities of the novel compounds 12
hot plate method. Ibuprofen and the tested compounds 12
–
19 were determined in rats using the well-known
–19 were injected intraperitoneally at a dose
of at 0.24 mmol/kg and 0.48 mmol/kg. A hot-plate was used to induce thermal pain and the cutoff
time was fixed to 15 s [30]. The analgesic responses were calculated as percent changes and results
were presented in Figure 6. Compounds 12, 13, 16 and 17 displayed higher analgesic activity than

Molecules 2016, 21, 201
8 of 21
ibuprofen, with analgesic potencies in the range of 1.03 to 1.27 times higher than ibuprofen at a dose of
0.48 mmol/kg. Compound 17 was the most active, at a dose of 0.48 mmol/kg. Moreover, compound
16 showed good activity comparable to that of ibuprofen. On the other hand, the analgesic activities
of compounds 14, 15, 18 and 19 were lower than that of ibuprofen, where compound 14 was the least
active, at 0.48 mmol/kg dose.
Figure 6. The analgesic activity results using hot-plate test for control, compound 12–19, and
ibuprofen at 0.24 (
ꢀ
) and 0.48 mmol/kg (
ꢀ
); data were represented as means
˘
SEM, n = 6; data
were analyzed by One way ANOVA followed by student-Newman-Keuls multiple comparison
a
test; % change = 100 ˆ (T1 ´ T0)/T0
;
statistically significant from control (p < 0.001); b statistically
significant from control (p < 0.01); c statistically significant from control (p < 0.05); d statistically not
significant from control.
Acute Ulcerogenicity Studies
GIT toxicity is the main serious side effect of the NSAIDs. In this work, the ulcerogenicity of
the novel compounds 12
–19 was evaluated according to the previous reported methodology [31
,32].
The tested compounds 12
–
19 and ibuprofen were given orally in a dose of 0.48 mmol/kg. The results
revealed that all the new compounds were safer than ibuprofen with protection percentages in the
range of 66.38%–100%. The hybrid 19 showed zero ulcer index. The data including ulcer index and
protection percentages were calculated and the results were presented in Table 2.
Histopathological Studies
The stomachs of the rats used in ulcerogenicity test were subjected to a histopathological study to
visualize the deep effects of ibuprofen and tested compounds on the stomach mucosa, submucosa and
mucosal glands. The specimens were stained with haematoxylin and eosin stain [33]. Representative
transverse sections (TSs) of the rat stomach treated with the new compounds are presented in
Figure 7. It was found that the TSs in the stomach wall of the rats of the control group showed
no histopathological effect and normal mucosal glands, while the TSs in the stomach of the rats treated
with ibuprofen showed severe damage represented by leukocytes infiltration and necrosis in the
mucosa layer with hypertrophy in mucosal glands. The TSs in stomachs treated with compound 12
and 14 showed variable degrees of necrosis with some leukocytes infiltration, while those treated with
compounds 15 17 and 18 exhibited little histopathological effects such as congested blood vessels and
, 13
,
variable degrees of leukocytes infiltration. Higher safety profiles were observed with compounds 16
and 19, where the TSs showed normal mucosal glands with no histopathological effects.

Molecules 2016, 21, 201
9 of 21
Figure 7. The histological TSs (C–L) in the stomach of rat treated with compounds 12–19, respectively
in comparison to control (A) and ibuprofen (B), using haematoxylin and eosin stain, 400ˆ.
2.3. Molecular Docking Study
2.3.1. Docking Study into COX-1 Enzyme
The co-crystallized ibuprofen was used as a reference drug for the docking study of the newly
synthesized pyrrolizines into the ovine COX-1 (pdb code: 1EQG) [34]. The binding site of COX-1
composed of the following amino acids: His90, Arg120, Val349, Leu352, Ser353, Tyr355, Arg513, Ala516,
Phe518, Gly526, and Ala527. The bound ibuprofen was docked into COX-1 to validate the performance
of AutoDock program in comparison to the biological experiment. It was docked superimposed onto
the position of co-crystalized ligand within root mean square deviation (RMSD) of 0.62 Å, and it
exhibited two hydrogen bonds between its COOH group and NH2 of Arg120 (Figure 8).
Figure 8. Ibuprofen docked superimposed onto the position of co-crystalized ligand within RMSD of
0.62 Å, and exhibited two hydrogen bonds between its COOH group and NH2 of Arg120.
In accordance to this successful performance of the AutoDock program, docking of compounds
12–18 were done into COX-1 enzymes. They were docked within RMSD of 2.27 to 4.47 Å from
the co-crystalized ibuprofen, and up to three hydrogen bonds were detected with the key amino
acids Arg120 and Tyr355. Compounds 17 and 19 exhibited the highest binding affinities into COX-1
enzyme with binding free energies of
exhibited one hydrogen bond between their pyrrolizin-2-sulfonamide and pyrrolizin-2-carboxamide
´
10.31 and
´
9.71 Kcal/mol, respectively (Table 3). Both of them

Molecules 2016, 21, 201
10 of 21
and phenolic OH of Tyr355 and NH2 of Arg120, respectively. On the other hand, the cyclized diazepine
15 exhibited less binding affinity at ´6.65 Kcal/mol (Table 3).
Table 3. Results of the flexible docking of compounds 12–19 into ovine COX-1 (pdb: 1eqg) [34] in
comparison to the native co-crystallized ibuprofen.
Hydrogen Bonds between Atoms of
Compounds and Amino Acids of COX-1
a
∆Gb
b
RMSD c (Å)
Compd.
Ki
(kcal/mol)
Atom of Compd.
Amino Acid
5-Ph-NH
5-Ph-NHC=O
OH of Tyr355
HN of Arg120
´9.00
12
250.88 nM
2.92
13
14
´9.34
´6.41
142.76 nM
7-CN
6-NH
HN of Arg120
OH of Tyr355
3.41
1.99
20.18 µM
10-CN
2-C=O
2-C=O
HO of Tyr385
HO of Ser530
HN of Leu531
13.26 µM
´6.65
15
0.83
16
17
18
19
´8.14
´10.31
´0.68
´9.71
1.08 µM
27.77 nM
316.74 mM
76.20 nM
5-Ph-CONH
6-NHS=O
OH of Tyr355
HO of Tyr355
HN of Arg120
HN of Arg120
2.27
2.29
2.62
3.49
5-Ph-NHC=O
6-NHC=O
H1N of Arg120
COO
COOH
Ibuprofen
´9.40
128.86 nM
0.62
H2N of Arg120
a
Binding free energy; b Inhibition constant; c Root mean square deviation.
2.3.2. Docking Study into COX-2 Enzyme
The native co-crystallized 1-phenylsulfonamido-3-trifluoromethyl-5-(p-bromophenyl)pyrazole
ligand (S58) was used to parameterize molecular docking study against COX-2 (pdb code: 1cx2) [35].
The key amino acids of the binding site include: His90, Arg120, Val349, Leu352, Ser353, Tyr355, Arg513,
Ala516, Phe518, Gly526, and Ala527. The docking performance was initially evaluated by docking
of the native S58 ligand, where it revealed RMSD of 0.38 Å and formed four hydrogen bonds with
Hist90, Arg120, Arg513, and Phe518. Furthermore, S58 exhibited excellent binding affinity (∆Gb:
´11.49 Kcal/mol) (Figure 9A).
Figure 9.
ligands S58 into COX-2; (
arachidonic acid into 5-LOX.
(
A
) Validation of the performance of AutoDock program by docking of the native co-crystallized
B) Validation of the performance of AutoDock program by docking of
These results revealed an extremely acceptable performance of the AutoDock program, which
enables us to go further for investigation of the docking mode and the binding affinity of the newly
synthesized compounds. Our compounds were docked within RMSD of 0.49 to 5.79 Å from the native
co-crystalized ligand and revealed up to five hydrogen bonds. Compounds 17 and 18 exhibited the

Molecules 2016, 21, 201
11 of 21
highest binding affinities into COX-2 enzyme of binding free energies of
respectively, Table 4. Compound 17 conserved four hydrogen bonds between its sulfonamide and aniline
´
11.63 and
´
10.93 Kcal/mol,
NH moieties and NH2 of Arg120, phenolic OH of Tyr355, and carbonyl group of Leu352, Figure 10.
Figure 10. Docking mode of compound 17 (ball and stick) into COX-2 (pdb code: 1cx2). It revealed
four hydrogen bonds (green dotted lines) with Arg120, Leu352, and Tyr355, within RMSD of 1.45 Å
from the co-crystallized S58 ligand (yellow sticks).
On the other hand compound 18 showed two hydrogen bonds between its pyrrolizine-6-amide
group and phenolic OH of Tyr355, and carbonyl group of Glu524. Whereas, the cyclized diazepine
form of compound 15 {4-(4-bromophenyl)-2,5-dioxo-1,2,3,4,5,7,8,9-octahydro-[1,4]diazepino[5,6-b]
pyrrolizine-10-carbonitrile} revealed poor binding affinity of ´8.73 Kcal/mol (Table 4).
Table 4. Results of the flexible docking of compounds 12–19 into COX-2 (pdb: 1cx2) [35] in comparison
to the native co-crystallized S58 ligand.
Hydrogen Bonds between Atoms of
Compounds and Amino Acids of COX-2
a
∆Gb
b
RMSD c (Å)
Compd.
Ki
(kcal/mol)
Atom of Compd.
Amino Acid
5-Ph-NH
5-Ph-NHC=O
5-Ph-NHC=O
5-NH
O=C of Glu524
H1N of Arg120
H2N of Arg120
OH of Tyr355
HN of His90
H1N of Arg120
H2N of Arg120
´8.79
12
13
362.12 nM
46.35 nM
3.39
0.49
7-CN
´10.01
5-NHC=O
d
14
15
16
´9.82
´8.73
´8.81
63.40 nM
400.2 nM
347.43 nM
1.13
1.78
1.13
–
10-CN
HO of Ser530
HN of Arg120
6-Ph-C=O
5-Ph-NH
6-NHS=O1
6-NHS=O1
6-NHS=O2
O=C of Leu352
H1N of Arg120
H2N of Arg120
HO of Tyr355
´11.63
17
3.00 nM
1.45
6-NH
6-NHC=O
O=C of Glu524
HO of Tyr355
´10.93
´10.27
18
19
9.80 nM
5.79
1.59
29.51 nM
7-CN
HO of Ser530
3-CF
HN of Arg120
HN of His90
HN of Arg513
O=C of Phe518
p-Ph-S=O1
p-Ph-S=O2
p-Ph-SONH
S58 Ligand e
´11.49
3.81 nM
0.38
a
b
c
d
Binding free energy; Inhibition constant; Root mean square deviation; No hydrogen bond detected;
e
1-Phenylsulfonamido-3-trifluoromethyl-5-(p-bromophenyl)pyrazole.

Molecules 2016, 21, 201
12 of 21
2.3.3. Docking Study into 5-LOX Enzyme
Because there is no reference co-crystalized ligand for the 5-LOX (pdb code: 3O8Y) [36],
molecular overlay superimposition was applied for human 5-LOX (pdb code: 3O8Y) and the mutated
15-lipoxygenase (pdb code: 3V99) [37]. The new center of the co-crystalized arachidonic acid (ACD)
was utilized as a reference for docking of our compounds into 3O8Y, Figure 9B. Additionally, the two
active site of 5-LOX (pdb code: 3V99) around the catalyst non-hem iron atom were used as the binding
site. The first active site (AC1) has a three conserved histidines (His367, His372, and His550), as well
as Asn554. The second active site (AC2) is composed of three key amino acids Phe177, Gln363, and
Leu607. Compounds 16 and 17 revealed the highest binding affinities, means the lowest binding free
energies of
´
11.06 and
´
10.84 kcal/mol, respectively. They formed (1-2) hydrogen bonds mainly with
OH of Tyr181, and NH and CO Gln363 (Table 5).
Surprisingly the reference arachidonic acid (ACD) revealed a poorer binding affinity ( 4.50 kcal/mol)
´
than our compounds, where it interacts hydrophobically without any detected hydrogen bonds
(Figure 11).
Table 5. Results of the flexible docking of compounds 12–19 into 5-LOX (pdb: 3o8y) [36] in comparison
to the reference arachidonic acid (ACD).
Hydrogen Bonds between Atoms of
Compounds and Amino Acids of 5-LOX
a
∆Gb
b
RMSD c (Å)
Compd.
Ki
(kcal/mol)
Atom of Compd.
Amino Acid
5-Ph-NH
5-Ph-NHC=O
7-CN
O=C of Gln363
HO of Tyr181
HN of Ala424
´8.78
12
13
365.81 nM
174.81 nM
5.80
5.42
5-Ph-NH
5-Ph-NHC=O
7-CN
O=C of Gln363
HO of Tyr181
HN of Asn425
´9.22
14
15
´7.48
´7.89
3.31 µM
1.66 µM
6-NH
OH of Tyr181
2.73
5.86
2-C=O
5-C=O
HO of Thr364
HN of His367
5-Ph-NHC=O
6-NH
6-NHS=O1
6–NHS=O2
HN of Gln363
OH of Tyr181
´11.06
´10.84
16
17
18
7.78 nM
2.68
3.55
4.25
HN of Gln363
HN of His367
11.26 nM
5-Ph-NH
7-CN
O=C of Ile673
HN of Gln363
d
+6.69
–
19
´12.16
1.23 nM
6-NHC=O
HO of Tyr181
3.24
2.27
ACD Ligand e
´4.50
502.87 µM
d
–
a
b
c
d
Binding free energy; Inhibition constant; Root mean square deviation; No hydrogen bond detected;
ACD—Arachidonic acid.
e
Figure 11. The binding mode of the interaction of compound 19 (ball and stick) into the target enzyme
(5-LOX; pdb code: 3o8y). It bounds with Tyr181 by one hydrogen bond (green dotted lines) within
RMSD of 3.24 Å from the reference ACD (yellow sticks).

Molecules 2016, 21, 201
13 of 21
Compound 18 revealed high binding energy (i.e., low affinity) into COX-1 (
and 5-LOX (
selective binding affinity into COX-2 better than its affinity into COX-1 and 5-LOX as clearly noticed in
Tables 3–5. Therefore, it hold the lowest binding free energy into COX-2 ( Gb: 10.93 kcal/mol) and
∆
Gb:
´
0.68 kcal/mol)
∆
Gb: +6.69 kcal/mol) (Figure 12A,C). On the other hand, it revealed a remarkable
∆
´
two hydrogen bonds with Tyr355 and Glu525 (Figure 12B). The selective affinity of compound 18 into
COX-2 over COX-1 and 5-LOX, may be attributed to its inferior stability into the latter targets by the
external bonds (shown in purple lines) with the surrounding amino acids, namely: Arg120 and Tyr355
of COX-1 (Figure 12A), and Gln363, Leu607, and Ile673 of 5-LOX (Figure 12C). This steric hindrance
was averted in the binding mode of compound 18 into COX-2 (Figure 12B).
Figure 12.
(A) The binding interactions of compound 18 into COX-1; (B) binding interactions of
compound 18 into COX-2; and (C) binding interactions of compound 18 into 5-LOX illustrated by Ligplot.
3. Experimental Section
3.1. General Information
Chemical reagents and solvents were obtained from Sigma-Aldrich (Bayouni Company, Jeddah,
Saudi Arabia). Solvents are dried by standard methods when necessary. Melting points (m.p.) were
uncorrected and were carried out by open capillary tube method using an IA 9100MK-Digital Melting
Point Apparatus. Microanalyses were carried out at the Microanalytical Center, Faculty of Science,
Cairo University. Infrared spectra (IR) were recorded using a TENSOR 37 spectrophotometer (Bruker,
Billerica, MA, USA, ATR accessory) and absorption were expressed in wave number (cm´1) using
KBr disc. The proton magnetic resonance 1H-NMR spectra were recorded in the specified solvent
at 500 MHz on a Bruker AVANCE II spectrometer, chemical shifts were reported on the δ scale and
were related to that of the solvent and J values are given in Hz. 13C-NMR and DEPT135 spectra were
obtained at 125 MHz on the same spectrometer. Mass spectra were recorded on a GCMS QP5050A
spectrometer (Shimadzu, Europe) at 70 eV (EI). Thin layer chromatography, was done using Alugram
Sil G/UV254 silica gel plates (Macherey-Nagel, Duren, Germany) and benzene-ethanol (9.5:0.5) as
the eluting system. Compounds
reported procedures.
9 [23], 11 [24] and 12 [25] were prepared according to the previously
3.2. Chemistry
6-Amino-N-(4-bromophenyl)-7-cyano-2,3-dihydro-1H-pyrrolizine-5-carboxamide (12): A mixture of
N-(4-bromophenyl)-2-chloroacetamide (11, 1.86 g, 7.5 mmol), 2-(pyrrolidin-2-ylidine)malononitrile
(9, 1 g, 7.5 mmol), and anhydrous potassium carbonate (1.04 g, 7.5 mmol) in dry acetone (50 mL)
was stirred for 24 h under reflux. The reaction mixture was filtered while hot, concentrated and left
aside. The crystals that separated were collected, dried and recrystallized from an ethanol-acetone
˝
´1
υmax/cm
mixture to give pale yellow crystals of the title compound, m.p. 228–230 C, yield 68%, IR
3343, 3275 (NHs), 3068 (C-H aromatic), 2970 (C-H aliphatic), 2218 (CN), 1703, 1652 (C=O). 1H-NMR
(CDCl3, 500 MHz, ppm): 2.55 (m, 2H, CH2-2), 3.00 (t, 2H, J = 7.5 Hz, CH2-1), 3.57 (s, 2H, NH2),
δ

Molecules 2016, 21, 201
14 of 21
4.41 (t, 2H, J = 7.5 Hz, CH2-3), 7.46 (d, 2H, J = 10 Hz, aromatic CH-31, CH-51), 7.55 (d, 2H, J = 8.7 Hz,
1
1
aromatic CH-2 , CH-6 ), 9.64 (s, H, NH). 13C-NMR (CDCl3, 125 MHz,
δ ppm): 24.80, 25.44, 49.71, 83.48,
114.13, 114.66, 116.37, 121.24, 132.00, 137.24, 137.46, 145.24, 158.43. MS (EI): m/z (%) 346 (M+ + 2, 1),
344 (M+, 1); 298 (85), 262 (3), 235 (46), 219 (100), 207 (13), 191 (32), 174 (27), 165 (25), 146 (7), 109 (11),
95 (15), 77 (35). Anal. Calcd. for C15H13BrN4O (345.19): C, 52.19; H, 3.80; N, 16.23. Found: C, 51.81;
H, 4.23; N, 16.35.
N-(4-Bromophenyl)-6-(2-chloroacetamido)-7-cyano-2,3-dihydro-1H-pyrrolizine-5-carboxamide (13): A mixture
of 6-amino-N-(4-bromophenyl)-7-cycno-2,3-dihydro-1H-pyrrolizine-5-carboxamide (12, 1 g, 2.9 mmol)
and chloroacetyl chloride (5.8 mmol) in dry benzene (20 mL) was stirred for 2 h and left aside to
stand for 48 h at room temperature. The formed precipitate was filtered, washed with water and hot
ethanol–acetone mixture. Compound 13 was obtained as white crystals, m.p. 300–302 ˝C, yield 71%,
IR
υ
max/cm´1 3269, 3236 (NHs), 3060 (C-H aromatic), 2996 (C-H aliphatic), 2226 (CN), 1674, 1651
1
(COs). H-NMR (DMSO-d6, 500 MHz,
δ ppm): 2.45 (m, 2H, CH2-2), 3.00 (t, 2H, J = 7.5 Hz, CH2-1),
4.27 (t, 2H, J = 7.5 Hz, CH2-3), 4.33 (s, 2H, CH2-Cl), 7.52 (d, 2H, J = 10 Hz, aromatic CH-31, CH-51),
7.63 (d, 2H, J = 8.7 Hz, aromatic CH-2 , CH-6 ), 9.59 (s, H, NH), 10.28 (s, H, NH). 13C-NMR (DMSO-d6,
1
1
125 MHz, ppm): 23.75, 24.59, 42.15, 48.72, 83.50, 113.77, 114.80, 116.79, 121.32, 125.57, 130.89, 137.27,
δ
145.62, 156.81, 165.48. MS (EI): m/z (%) 420 (M+, 1), 387 (4), 372 (4), 351 (6), 322 (8), 294 (5), 267 (16), 252
(31), 236 (16), 228 (25), 220 (32), 195 (100), 186 (55), 174 (42), 168 (35), 155 (42), 146 (20), 134 (93), 126 (26),
111 (34), 94 (18), 77 (9). Anal. Calcd. for C17H14BrClN4O2 (421.68): C, 48.42; H, 3.35; N, 13.29. Found:
C, 47.96; H, 3.70; N, 13.48.
N-(4-Bromophenyl)-7-cyano-6-(2-(4-methylpiperazin-1-yl)acetamido)-2,3-dihydro-1H-pyrrolizine-5-carbox-amide
(14): A mixture of N-(4-bromophenyl)-6-(2-chloroacetamido)-7-cycno-2,3-dihydro-1H-pyrrolizine-5-
carboxamide (13, 3.8 mmol), N-methylpiperazine (0.76 g, 7.6 mmol) and anhydrous potassium
carbonate (1.04 g, 7.5 mmol) in absolute ethanol (20 mL) was refluxed for 6 h. The separated product
was filtered, washed ˝with water and recrystallized from ethanol–acetone mixture to give white
´1
crystals, m.p. 220–223 C, yield 65%, IR υmax/cm 3215 (NHs), 3057 (C-H aromatic), 2940, 2823 (C-H
1
aliphatic), 2225 (CN), 1671, 1651 (COs). H-NMR (CDCl3, 500 MHz,
δ ppm): 2.34 (s, 3H, CH3), 2.57
(m, 6H, CH2-2, CH2-3”, CH2-5”), 2.75 (m, 4H, CH2-2”, CH2-6”), 3.05 (t, 2H, J = 7.5 Hz, CH2-1), 3.26 (s,
2H, J = 7.5, COCH2), 4.40 (t, 2H, J = 7.5 Hz, CH2-3), 7.45 (d, 2H, J = 10 Hz, aromatic CH-31, CH-51),
7.51 (d, 2H, J = 10 Hz, aromatic CH-21, CH-61), 9.42 (s, H, NH), 10.04 (s, H, NH). 13C-NMR (CDCl3,
125 MHz,
δ
ppm): 25.02, 25.62, 45.96, 49.33, 53.73, 55.20, 61.16, 83.89, 113.90, 116.71, 120.20, 121.09,
15, 1), 421 (4), 401 (2), 376 (9),
124.31, 131.98, 137.41, 145.66, 157.48, 172.67. MS (EI): m/z (%) 469 (M+
´
362 (18), 308 (21), 286 (5), 262 (10), 242 (5), 222 (8), 199 (13), 174 (14), 156 (65), 140 (21), 112 (35), 97 (32),
82 (19), 78 (5), 40 (100). Anal. Calcd. for C22H25BrN6O2 (485.38): C, 54.44; H, 5.19; N, 17.31. Found:
C, 54.67; H, 4.85; N, 17.24.
4-(4-Bromophenyl)-2,5-dioxo-1,2,3,4,5,7,8,9-octahydro-[1,4]diazepino[5,6-b]pyrrolizine-10-carbonitrile (15):
A mixture of 13 (0.76 g, 1.8 mmol) and anhydrous potassium carbonate (0.25 g, 1.8 mmol) in dry
DMF (20 mL) was stirred at room temperature for 24 h. The reaction mixture was poured onto
ice-cooled water. The formed precipitate was filtered off, washed with water, dried and crystallized
from ethanol–acetone mixture to give compound 15b as white crystals, m.p. 256–258 ˝C, yield 61%,
IR
1588, 1545, 1487, 1312 (C-N, N-H, C-O). 1H-NMR (DMSO-d6, 500 MHz,
3.00 (t, 2H, J = 7.8 Hz, CH2-1), 3.76 (t, 2H, J = 7.2 Hz, CH2-3), 4.57 (s, 2H, COCH2), 7.50–7.54 (m, 4H,
υ
max/cm´1 3314, 3238 (NHs), 3068 (C-H aromatic), 2995 (C-H aliphatic), 2216 (CN), 1704, (C=O),
ppm): 2.01 (m, 2H, CH2-2),
δ
aromatic protons), 10.37 (s, H, NH). 13C-NMR (DMSO-d6, 125 MHz,
δ ppm): 19.72, 36.40, 43.57, 50.67,
59.59, 115.73, 116.30, 118.04, 121.74, 132.16, 134.01, 138.43, 164.86, 172.64. MS (EI): m/z (%) 384 (M+, 2),
357 (100), 328 (2), 276 (6), 198 (3), 171 (4), 152 (34), 138 (3), 124 (6), 104 (4), 92 (4), 77 (5). Anal. Calcd. for
C17H13BrN4O2 (385.21): C, 53.00; H, 3.40; N, 14.54. Found: C, 52.71; H, 3.42; N, 14.24.

Molecules 2016, 21, 201
15 of 21
6-Benzamido-N-(4-bromophenyl)-7- cyano-2,3-dihydro-1H-pyrrolizine-5-carboxamide (16): A mixture of 12
(1 g, 2.9 mmol) and benzoyl chloride (5.8 mmol) in dry benzene (30 mL) was stirred for 2 h and left
to stand overnight at room temperature. The formed precipitate was filtered, washed with water
and recrystallized from an ethanol–acetone mixture. Compound 16 was obtained as a white solid,
m.p. 285–288 ˝C, yield 66%, IR
2223 (CN), 1664, 1642 (COs). H-NMR (CDCl3, 500 MHz,
υ
max/cm´1 3210 (NHs), 3041 (C-H aromatic), 2982 (C-H aliphatic),
ppm): 2.60 (m, 2H, CH2-2), 3.08 (t, 2H,
1
δ
J = 7.5 Hz, CH2-1), 4.44 (t, 2H, J = 7.5 Hz, CH2-3), 7.42–7.68 (m, 9H, aromatic protons), 8.04 (s, H, NH),
9.98 (s, H, NH). 13C-NMR (CDCl3, 125 MHz,
ppm): 25.05, 25.67, 49.63, 84.56, 114.09, 116.81, 120.67,
δ
121.10, 124.59, 127.66, 129.19, 131.99, 132.33, 133.28, 137.26, 145.78, 157.54, 169.18. MS (EI): m/z (%) 448
(M+), 352 (31), 324 (5), 311 (6), 291 (79), 263 (22), 252 (13), 195 (100), 186 (28), 174 (43), 171 (16); 161 (17),
155 (22); 146 (32), 126 (29), 112 (23), 92 (21), 77 (46). Anal. Calcd. for C22H17BrN4O2 (449.30): C, 58.81;
H, 3.81; N, 12.47. Found: C, 59.22; H, 3.68; N, 12.41.
N-(4-Bromophenyl)-7-cyano-6-(4-methylphenylsulfonamido)-2,3-dihydro-1H-pyrrolizine-5-carboxamide (17):
A mixture of compound 12 (1 g, 2.9 mmol) and 4-toluenesulfonyl chloride (2.9 mmol), anhydrous
potassium carbonate (0.5 g, 3.65 mmol) in dry acetone (30 mL) was stirred under reflux for 4 h and
left to stand, filtered, and the solvent was evaporated to dryness under reduced pressure. The formed
precipitate was washed with water and recrystallized from ethanol–acetone mixture. Compound 17
was obtained as white crystals, m.p. 272–274 ˝C, yield 74%, IR
3033 (C-H aromatic), 2919, 2800 (C-H aliphatic), 2222 (CN), 1668 (COs), 1595 (C=C), 1310, 1291 (SO2N).
1H-NMR (CDCl3, 500 MHz,
ppm): 2.49 (s, 3H, CH3), 2.53 (m, 2H, CH2-2), 2.93 (t, 2H, J = 7.5 Hz,
υ
max/cm´1 3358, 3272 (NHs), 3063,
δ
CH2-1), 4.48 (t, 2H, J = 7.5 Hz, CH2-3), 6.57 (broad s, H, SO2NH), 7.37 (d, 2H, J = 7.8 Hz, aromatic
protons), 7.48 (d, 2H, J = 8.0 Hz, aromatic protons), 7.61 (d, 2H, J = 8.1 Hz, aromatic protons), 7.74 (d,
2H, J = 7.8 Hz, aromatic protons), 9.75 (s, H, CONH). 13C-NMR (CDCl3, 125 MHz,
δ ppm): 21.77, 24.82,
25.35, 50.30, 86.22, 112.64, 117.03, 121.66, 121.99, 123.00, 128.22, 130.22, 131.97, 133.98, 137.00, 145.59,
145.74, 156.89. MS (EI): m/z (%) 501 (M+ + 3, 1), 500 (M+ + 2, 6), 499 (M+ + 1, 2), 498 (M+, 6), 343 (9),
328 (25), 315 (100), 301 (19), 264 (43), 235 (15), 208 (7), 174 (9), 155 (4), 146 (10), 117 (15), 91 (38), 65 (21).
Anal. Calcd. for C22H19BrN4O3S (499.38): C, 52.91; H, 3.83; N, 11.22. Found: C, 53.28; H, 4.03; N, 11.42.
N1,N2-Bis(5-((4-Bromophenyl)carbamoyl)-7-cycno-2,3-dihydro-1H-pyrrolizin-6-yl)oxalamide (18): A mixture
of compound 12 (1 g, 2.9 mmol) and oxalyl chloride (5.8 mmol) in dry benzene (20 mL) was stirred for
2 h. The reaction mixture was left aside overnight at room temperature. The formed precipitate was
filtered off, washed with two portions of water, dried and washed with hot acetone to give compound
˝
18 as white crystals, m.p. 318–321 C, yield 63%, IR
υ
max/cm´1 3274 (NHs), 3066 (C-H aromatic),
1
2989, 2852 (C-H aliphatic), 2231 (CN), 1746, 1700, 1660 (COs). H-NMR (DMSO-d6, 500 MHz,
δ ppm):
2.47 (m, 4H, CH2-2 + CH2-21), 3.01 (t, 4H, J = 7.5 Hz, CH2-1 + CH2-11), 4.28 (t, 2H, J = 7.5 Hz, CH2-3
+ CH2-31), 7.53 (d, 4H, J = 10 Hz, aromatic CH-3 + CH-3 and CH-5 + CH-51), 7.60 (d, 4H, J = 10 Hz,
aromatic CH-2 + CH-21 and CH-6 + CH-61), 9.70 (s, 2H, two CON
H
Ph), 10.72 (s, 2H, N
HCOCONH).
13C-NMR (DMSO-d6, 125 MHz,
δ ppm): 24.82, 25.72, 49.73. 56.50, 84.57, 114.97, 115.89, 117.73, 122.47,
131.98, 138.40, 146.77, 157.93, 161.72. MS (EI): m/z (%) 747 (M+ + 5, 1), 746 (M+ + 4, 1), 744 (M+ + 2, 2),
743 (M+ + 1, 1), 742 (M+, 3), 729 (4), 657 (2), 371 (3), 344 (17), 310 (4), 262 (72), 228 (36), 206 (4), 186 (10),
174 (37), 162 (32), 146 (100), 119 (13), 91 (15), 60 (26). Anal. Calcd. for C32H24Br2N8O4 (744.39): C, 51.63;
H, 3.25; N, 15.05. Found: C, 52.08; H, 3.72; N, 15.34.
(R,S)-N-(4-Bromophenyl)-7-cycno-6-(2-(4-isobutylphenyl)propanamido)-2,3-dihydro-1H-pyrrolizine-5-carboxamide
(19): A mixture of ibuprofen (1.5 g, 7.5 mmol) and thionyl chloride (2 mL) was heated on water bath
for one hour. The reaction mixture was cooled and the excess thionyl chloride was removed under
vacuum. The residue obtained was dissolved in 20 mL dry benzene and pyrrolizine-5-carboxamide
12 (1 g, 2.9 mmol) was added. The reaction mixture was stirred for two hours then left aside to
stand for 48 h at room temperature. The formed precipitate was filtered, washed with water, and
recrystallized from ethanol–acetone to give compound 19 as white crystals, m.p. 217–219 ˝C, yield
58%, IR υ
max/cm´1 3402, 3289 (NHs), 3060, 3018 (C-H aromatic), 2954, 2868 (C-H aliphatic), 2225 (CN),

Molecules 2016, 21, 201
16 of 21
1
1732, 1663 (COs). H-NMR (CDCl3, 500 MHz,
δ
ppm): 0.88 (d, 6H, J = 5 Hz, CH(CH3)2), 1.66 (d, 3H,
J = 7 Hz, COCHCH3), 1.82 (m, H, CH(CH3)2), 4.43 (d, 2H, J = 5 Hz, Ph-CH2), 2.51 (m, 2H, CH2-2),
2.98 (t, 2H, J = 7.5 Hz, CH2-1), 3.83 (q, H, J = 7 Hz, COCHCH3), 4.28–4.37 (m, 2H, CH2-3), 7.08 (d, 2H,
J = 10 Hz, two aromatic CH), 7.23 (d, 3H, J = 10 Hz, two aromatic CH + CONH), 7.34 (d, 2H, J = 10 Hz,
two aromatic CH), 7.38 (d, 2H, J = 10 Hz, two aromatic CH), 9.54 (s, H, CONH). 13C-NMR (CDCl3,
125 MHz,
δ ppm): δ 18.10, 22.34, 22.37, 24.49, 25.61, 30.13, 44.98, 46.97, 49.48, 84.40, 113.69, 116.75,
120.30, 121.14, 124.47, 127.41, 130.12, 131.88, 136.38, 141.78, 1455.63, 157.47, 177.14. MS (EI): m/z (%)
532 (M+, 1), 394 (2), 373 (2), 362 (14), 335 (10), 319 (2), 286 (35), 262 (8), 209 (30), 202 (33), 161 (100),
145 (17), 117 (8), 81 (10). Anal. Calcd. for C28H29BrN4O2 (533.46): C, 63.04; H, 5.48; N, 10.50. Found:
C, 63.37; H, 5.20; N, 10.62.
3.3. Biological Evaluation
3.3.1. In Vitro COX-1/2 Inhibitory Assay
The ability of the tested compound 12–18 to inhibit COX-1 (ovine) and COX-2 (human recombinant)
was measured using COX colorimetric inhibitor screening assay kit provided by Cayman Chemical,
Ann Arbor, MI, USA (Catalog No. 701050). The assay was carried out according to the manufacturer’s
instructions and as described before [26–28].
3.3.2. In Vivo Biological Evaluation
Animals
Adult albino rats of both sex weighing 100–140 g were used in evaluation of the anti-inflammatory,
analgesic, ulcerogenic activity in addition to the histopathological study of the new pyrrolizines 12–19.
Animal ethical use clearance was obtained from the Ethical Committee at the College of Pharmacy,
Umm Al-Qura University. Normalization of the animals with laboratory conditions were achieved by
keeping them in laboratory one week before starting the experiments. Standard rat pellet diet was
used for feeding animals and water ad libitum.
Anti-Inflammatory Activity
The anti-inflammatory activity of the novel compounds 12–19 was evaluated in comparison with
ibuprofen as a standard, using a rat paw edema model as described by Winter et al. [29]. Adult albino
rats of both sexes (100–140 gm) were used. Rats were uniformly hydrated by giving 3 mL water
for each rat through gastric inoculation to reduce variability to edema response. Animals were then
divided into groups of six animal each. The control group was given saline solution containing few
drops of sodium carboxymethyl cellulose (CMC) 1% and DMSO. Ibuprofen (50 and 100 mg/kg) was
given as standard drug. The new compounds 12–19 in a dose molecularly equivalent to ibuprofen
were dissolved in 0.5 mL DMSO and CMC 1% was added dropwise with continuous triturating
to complete the specified volume. The tested compounds were administered intraperitoneally (IP).
The induction of inflammation was achieved by subcutaneous (SC) injection of carrageenan-sodium
gel, into the sub-plantar region of the right hind paw. The dorsoventral diameter (thickness) of the
right and left hind paw of each rat was measured using digital calipers with accuracy of 0.01 mm
(Cole-Parmer, Vernon Hills, IL, USA). The thickness of edema was measured 1, 2 and 3 h after induction
of inflammation. The left hind paw diameter served as a control for the degree of inflammation in
the right hind paw. The changes in the edema thickness were expressed as mean
The anti-inflammatory activity was calculated as % inhibition of inflammation = (1
Where Lt is the mean increase in paw thickness in rats treated with the tested compounds and Lc is the
mean increase in paw thickness in control group. Data were collected, and statistically analyzed by
One way ANOVA followed by student-Newman-Keuls multiple comparison test, Table 2.
˘
SEM, Figure 4.
Lt/Lc) 100.
´
ˆ

Molecules 2016, 21, 201
17 of 21
Analgesic Activity
The analgesic activity of the novel pyrrolizines were carried out using the thermal model (hot-plate
test) according to a previous report [30]. An electronically controlled hot-plate (Harvard Apparatus
˝
Ltd., Kent, UK) was used and the cut-off time was 15 s and the temperature was adjusted to 52 ˘ 0.1 C
Animals were then divided into groups of six animal each. Rats were assigned numbers of 1–6 in each
group. The reference drug was given intraperitoneally at a dose of 50 mg/kg (0.24 mmol/kg) and
.
100 mg/kg (0.48 mmol/kg). The tested compounds 12–19 were given in a dose molecularly equivalent
to ibuprofen. The basal time was measured for each rat just immediately after injecting the drugs
(T0) and two hours after injecting the tested compounds (T1). The response latencies (time elapsed
until licking paw or jumping) were measured and expressed as mean
(analgesic effects) of the tested compounds were calculated as percent change in latencies divided by
˘
SEM. The percent changes
baseline time (100 ˆ (T1 ´ T0)/T0) and results were expressed as % change ˘ SEM, Figure 6.
Acute Ulcerogenicity Study
GIT toxicity was evaluated according to the previous report [31]. Adult albino rats of both sexes
were divided into groups of six animals each. The test compounds were dissolved first in 0.5 mL DMSO,
then CMC (1%) was added dropwise with trituration. Rats were fasted 20 h before drug administration.
The eight tested compounds and ibuprofen were given orally in a dose of 0.24 and 0.48 mmol/kg/day
suspended in 1% CMC, while the control group received vehicle (1% CMC containing few drops of
DMSO). Rats were then fasted for 2 h, allowed to feed for 2 h then fasted again for another 20 h. Other
doses were given in the second and third days. In the fourth day, Pentobarbital (60 mg/kg IP) was
used to induce deep anesthesia then rats were sacrificed. The stomachs were removed, opened along
with the greater curvature and rinsed with 0.9% saline. The number of mucosal damages (red spots)
were counted using magnifying lens and their severity (ulcerogenic severity) was graded in a scale
from 0 to 3 as follows: (0) normal (no injury), (0.5) red coloration, (1) spot ulcer, (1.5) hemorrhagic
streaks, (2) ulcer > 3 mm, (3) ulcer > 5 mm. The ulcer index was calculated using the following equation
ulcer index (UI) = UN + US + UP/10, where UN is the average number pf ulcers per animal, US is
the average of severity score, UP is the percent of animal with ulcer [32]. UI and % protection were
calculated for each compound and presented in Table 2.
Histopathological Study
The rats sacrificed three days post-treatment with ibuprofen and tested with compounds 12–19
in ulcerogenic studies were used in this study. The study investigated the deep effect of the tested
compounds on the mucosa, submucosa and mucosal gland. The stomachs which were opened
longitudinally along the greater curvature were used and the specimens were taken from the stomachs
of all cases. These specimens were fixed in 10% formalin solution for 72 h. The samples were processed
and embedded in paraffin wax. Microtomy was done and 5 microns tissue sections were obtained
and mounted on clean glass slides. The later was stained with haematoxylin and eosin stain [33].
The results of the histopathological study were presented in Figure 7.
3.4. Molecular Docking Study
This comparative docking study was performed by docking our compounds 12–19 into the two
COX isoforms: COX-1 and COX-2 in addition to 5-LOX and compared with the parent co-crystallized
ligands. The main purpose of this study was to predict the binding mode and the binding affinity of
the newly synthesized compounds with relevant amino acids in the binding sites of COX-1, COX-2,
and 5-LOX enzymes.

Molecules 2016, 21, 201
18 of 21
3.4.1. Preparation of the COX-1, COX-2, and 5-LOX Protein and Ligands (12–19)
The protein structures were handled by using Accelrys Discovery Studio Visualize v4.1 software
(Accelrys Inc., San Diego, CA, USA (2005)). The crystal structures of proteins were retrieved from
Protein Data Bank (http://www.rscb. org/pdb) in a pdb format. COX-1, COX-2, and 5-LOX (PDB code:
1EQG, 1CX2, and 3O8Y) of X-ray resolutions: 2.61, 3.0, and 2.39 Å, respectively) [34
molecules were removed because the extra water molecules will mask the protein surface from the
ligand. The three-dimensional structures (pdb format) of the ligands (12 19) were constructed using
–36]. All water
–
Chem3D Ultra 8.0 software, then energetically minimized by using MOPAC with 100 iterations and
minimum RMS gradient of 0.10. The AutoDock Tool (ADT) automatically computes Gasteiger charges
to the 3D structures of the ligands.
3.4.2. Preparation of the Flexible Residue File
AutoDock 4.2 has the ability to manipulate the flexibility not only of the ligand but also for the
flexible moieties of the protein structure during docking process. Therefore, we have to consider this
advancement by selecting the key amino acid residues that are able to modulate their conformation
during ligand interaction into the binding site. In this study, the flexible residues for COX-1 are Arg120
and Tyr355, for COX-2 are Arg120 and His90, and for 5-LOX are Ser171, Phe177, Leu607, and Gln363.
3.4.3. Calculation of Affinity Maps by Using AutoGrid
AutoGrid calculates grid parameter files and generates maps for each type of atom within a given
area. We used the 3D grid of 60
33.106, and 200.251 Å for docking into COX-1, at 23.947, 21.582, and 15.436 Å for docking into COX-2,
and centered at 2.917, 19.760, and 1.690 Å for docking into 5-LOX. The co-crystallized ibuprofen was
ˆ
60
ˆ
60 Å size (x, y, z) with a spacing of 0.375 Å centered at 26.643,
´
´
used to guide the docked inhibitors within COX-1 receptor while S58 native ligand was used within
COX-2 receptor, whereas, the co-crystalized arachidonic acid (ACD) into the mutated 15-lipoxygenase
(pdb code: 3V99) [37] was used to guide the docking into human 5-LOX (pdb code: 3O8Y) [36] because
the human 5-LOX has no bound ligand. Therefore, molecular overlay superimposition was applied for
human 5-LOX (3O8Y) and the mutated 15-lipoxygenase (3V99). The new center of the co-crystalized
arachidonic acid (ACD) was utilized as a reference for the docking of our compounds into 3O8Y.
3.4.4. Defining the Docking Parameters and Running the Docking Simulation
The default values of AutoDock4.2 program were set during the ten docking runs, and
the Lamarckian Genetic Algorithm, which is the most recent docking algorithm, was involved.
Ten conformations were obtained for the protein-ligand complex and the flexible residues (namely:
Arg120 and Tyr355 for COX-1, Arg120 and His90 for COX-2, and Ser171, Phe177, Leu607, and Gln363
for 5-LOX) within the binding pocket. The docking clusters were scored and ranked descendingly by
the program according their calculated binding free energies. The binding interactions were analyzed
and images were generated using Accelrys Discovery Studio visualizer v4.1 software.
4. Conclusions
In summary, a series of novel 6-amino-N-(4-bromophenyl)-7-cyano-2,3-dihydro-1H-pyrrolizine-5-
carboxamide 12 and its derivatives 13–19 was designed and synthesized. Some of these new
compounds have displayed anti-inflammatory and analgesic activities higher than ibuprofen.
The molecular mechanism underlying the anti-inflammatory activity of these derivatives was
investigated via the ability of these compounds to inhibit COX-1/-2 enzymes. In addition, almost
all the newly synthesized compounds showed a safer gastric profile than ibuprofen as indicated by
their low ulcerogenic indices and the histopathological studies. The docking studies revealed that the
new compounds have variable degrees of binding affinity for COX/5-LOX enzymes. This binding
affinity was modulated with the change of the substituents on the 6-amino group of the pyrrolizine

Molecules 2016, 21, 201
19 of 21
scaffold. The results obtained in this study warrant that the new pyrrolizine derivatives 12
–19 represent
a promising scaffold for further development into potent and safe anti-inflammatory/analgesic agents.
Supplementary Materials: Supplementary materials including all spectral data and copies of IR, Mass, 1H-NMR
and 13C-NMR spectra, of all final compounds (Figures S1–S35). Supplementary materials can be accessed at:
http://www.mdpi.com/1420-3049/21/2/201/s1.
Acknowledgments: This work was supported by the grant number (43310004) from the Institute of Scientific
Research and Revival of Islamic Heritage, Umm Al-Qura University, Makkah, Saudi Arabia.
Author Contributions: Research design: Ahmed M. Gouda; Literature review: Hamed I. Ali and
Ahmed H. Abdelazeem; Conducted experiments: Ahmed M. Gouda, Hamed I. Ali, and Ahmed H. Abdelazeem
;
Data analysis:
Ahmed M. Gouda
,
Hamed I. Ali
,
Ahmed H. Abdelazeem and Mohamed A. Azim
,
Mohammed A.S. Abourehab
, and Waleed H. Almalki; Manuscript writing (wrote and contributed):
Ahmed M. Gouda, Hamed I. Ali, Ahmed H. Abdelazeem, Mohamed A. Azim, Mohammed A.S. Abourehab, and
Waleed H. Almalki. Authors disclosed no actual or potential conflict of interest, and have approved the article.
Conflicts of Interest: The authors declare no conflict of interest.
References
1.
Roberts, L.J.; Morrow, J.D. The Pharmacological Basis of Therapeutics, 10th ed.; Goodman, L.S., Gilman, A.G.,
Hardman, J.G., Limbird, A.E., Eds.; McGraw Hill: New York, NY, USA, 2001; pp. 687–733.
Mounier, G.; Guy, C.; Berthoux, F.; Beyens, M.N.; Ratrema, M.; Ollagnier, M. Severe renal adverse events
with arylcarboxylic non-steroidal anti-inflammatory drugs: Results of a eight-year French national survey.
Therapie 2006, 61, 255–266. [CrossRef] [PubMed]
2.
3.
Schneider, V.; Levesque, L.E.; Zhang, B.; Hutchinson, T.; Brophy, J.M. Association of selective and
conventional nonsteroidal antiinflammatory drugs with acute renal failure: A population-based, nested
case-control analysis. Am. J. Epidemiol. 2006, 164, 881–889. [CrossRef] [PubMed]
Cryer, B. NSAID-associated deaths: The rise and fall of NSAID-associated GI mortality. Am. J. Gastroenterol.
2005, 100, 1694–1695. [CrossRef] [PubMed]
4.
5.
6.
7.
Singh, G. Recent considerations in nonsteroidal anti-inflammatory drug gastropathy. Am. J. Med. 1998, 105,
31S–38S. [CrossRef]
Vane, J.R.; Botting, R.M. Mechanism of action of anti-inflammatory drugs. Scand. J. Rheumatol. Suppl. 1996
,
102, 9–21. [CrossRef] [PubMed]
Tomisato, W.; Tsutsumi, S.; Rokutan, K.; Tsuchiya, T.; Mizushima, T. NSAIDs induce both necrosis and
apoptosis in guinea pig gastric mucosal cells in primary culture. Am. J. Physiol. Gastrointest. Liver Physiol.
2001, 281, G1092–G1100. [PubMed]
8.
9.
Tomisato, W.; Tsutsumi, S.; Hoshino, T.; Hwang, H.-J.; Mio, M.; Tsuchiya, T.; Mizushima, T. Role of direct
cytotoxic effects of NSAIDs in the induction of gastric lesions. Biochem. Pharmacol. 2004, 67, 575–585.
[CrossRef] [PubMed]
Yeomans, N.D.; Hawkey, C.J.; Brailsford, W.; Naesdal, J. Gastroduodenal toxicity of low-dose acetylsalicylic
acid: A comparison with non-steroidal anti-inflammatory drugs. Curr. Med. Res. Opin. 2009, 25, 2785–2793.
[CrossRef] [PubMed]
10. Redasani, V.K.; Bari, S.B. Synthesis and evaluation of mutual prodrugs of ibuprofen with menthol, thymol
and eugenol. Eur. J. Med. Chem. 2012, 56, 134–138. [CrossRef] [PubMed]
11. Masferrer, J.L.; Zweifel, B.S.; Manning, P.T.; Hauser, S.D.; Leahy, K.M.; Smith, W.G.; Isakson, P.C.; Seibert, K.
Selective inhibition of inducible cyclooxygenase 2 in vivo is antiinflammatory and nonulcerogenic. Proc. Natl.
Acad. Sci. USA 1994, 91, 3228–3232. [CrossRef] [PubMed]
12. Chiroli, V.; Benedini, F.; Ongini, E.; del Soldato, P. Nitric oxide-donating non-steroidal anti-inflammatory
drugs: The case of nitro derivatives of aspirin. Eur. J. Med. Chem. 2003, 38, 441–446. [CrossRef]
13. Inagaki, M.; Tsuri, T.; Jyoyama, H.; Ono, T.; Yamada, K.; Kobayashi, M.; Hori, Y.; Arimura, A.; Yasui, K.;
Ohno, K.; et al. Novel antiarthritic agents with 1,2-isothiazolidine-1,1-dioxide (γ-sultam) skeleton: Cytokine
suppressive dual inhibitors of cyclooxygenase-2 and 5-lipoxygenase. J. Med. Chem. 2000, 43, 2040–2048.
[CrossRef] [PubMed]

Molecules 2016, 21, 201
20 of 21
14. Jett, M.F.; Ramesha, C.S.; Brown, C.D.; Chiu, S.; Emmett, C.; Voronin, T.; Sun, T.; O’Yang, C.; Hunter, J.C.;
Eglen, R.M.; et al. Characterization of the analgesic and anti-inflammatory activities of ketorolac and its
enantiomers in the rat. J. Pharmacol. Exp. Ther. 1999, 288, 1288–1297. [PubMed]
15. Lashbrook, J.M.; Ossipov, M.H.; Hunter, J.C.; Raffa, R.B.; Tallarida, R.J.; Porreca, F. Synergistic antiallodynic
effects of spinal morphine with ketorolac and selective COX1- and COX2-inhibitors in nerve-injured rats.
Pain 1999, 82, 65–72. [CrossRef]
16. Laufer, S.; Augustin, J.; Dannhardt, G.; Kiefer, W. (6,7-Diaryldihydropyrrolizin-5-yl)acetic acids, a novel class
of potent dual inhibitors of both cyclooxygenase and 5-lipoxygenase. J. Med. Chem. 1994, 37, 1894–1897.
[CrossRef] [PubMed]
17. Tries, S.; Laufer, S. The pharmacological profile of ML3000: A new pyrrolizine derivative inhibiting the
enzymes cyclo-oxygenase and 5-lipoxygenase. Inflammopharmacology 2001, 9, 113–124. [CrossRef]
18. Laufer, S.; Striegel, H.G.; Neher, K.; Zechmeister, P.; Donat, C.; Stolingwa, K.; Baur, S.; Tries, S.;
Kammermeier, T.; Dannhardt, G.; et al. Synthesis and evaluation of a novel series of pyrrolizine derivatives
as dual cyclooxygenase-1 and 5-lipoxygenase inhibitors. Arch. Pharm. 1997, 330, 307–312. [CrossRef]
19. Ulbrich, H.; Fiebich, B.; Dannhardt, G. Cyclooxygenase-1/2 (COX-1/COX-2) and 5-lipoxygenase (5-LOX)
inhibitors of the 6,7-diaryl-2,3–1H-dihydropyrrolizine type. Eur. J. Med. Chem. 2002, 37, 953–959. [CrossRef]
20. Laufer, S.; Tollmann, K.; Striegel, H.-G. Anti-Inflammatory Oxo Derivatives and Hydroxy Derivatives of
Pyrrolizines, and Their Pharmaceutical Use. U.S. Patent No. US6,878,738 B1, 12 April 2005.
21. Liedtke, A.J.; Keck, P.R.; Lehmann, F.; Koeberle, A.; Werz, O.; Laufer, S.A. Arylpyrrolizines as inhibitors of
microsomal prostaglandin E2 synthase-1 (mPGES-1) or as dual inhibitors of mPGES-1 and 5-lipoxygenase
(5-LOX). J. Med. Chem. 2009, 52, 4968–4972. [CrossRef] [PubMed]
22. Abbas, S.E.; Awadallah, F.M.; Ibrahim, N.A.; Gouda, A.M. Novel substituted and fused pyrrolizine
derivatives: Synthesis, anti-inflammatory and ulcerogenecity studies. Eur. J. Med. Chem. 2010, 45, 482–491.
[CrossRef] [PubMed]
23. Etienne, A.; Correia, Y. Derivatives of 2-pyrrolidone. Bull. Soc. Chem. 1969, 10, 3704–3712.
24. Jacobs, W.A.; Heidelberger, M. The ferrous sulfate and ammonia method for the reduction of nitro to amino
compounds. J. Am. Chem. Soc. 1917, 39, 1435–1439. [CrossRef]
25. Gouda, A.M.; Abdelazeem, A.H.; Arafa, E.-S.; Abdellatif, K.R. Design, synthesis and pharmacological
evaluation of novel pyrrolizine derivatives as potential anticancer agents. Bioorg. Chem. 2014, 53, 1–7.
[CrossRef] [PubMed]
26. Praveen Rao, P.N.; Amini, M.; Li, H.; Habeeb, A.G.; Knaus, E.E. Design, synthesis, and biological evaluation
of 6-substituted-3-(4-methanesulfonylphenyl)-4-phenylpyran-2-ones: A novel class of diarylheterocyclic
selective cyclooxygenase-2 inhibitors. J. Med. Chem. 2003, 46, 4872–4882. [CrossRef] [PubMed]
27. Liu, W.; Zhou, J.; Bensdorf, K.; Zhang, H.; Liu, H.; Wang, Y.; Qian, H.; Zhang, Y.; Wellner, A.; Rubner, G.; et al.
Investigations on cytotoxicity and anti-inflammatory potency of licofelone derivatives. Eur. J. Med. Chem.
2011, 46, 907–913. [CrossRef] [PubMed]
28. Abdelazeem, A.H.; Salama, S.A.; Maghrabi, I.A. Design, Synthesis, and Anti-Inflammatory Evaluation of
Novel Diphenylthiazole-Thiazolidinone Hybrids. Arch. Pharm. 2015, 348, 518–530. [CrossRef] [PubMed]
29. Winter, C.A.; Risley, E.A.; Nuss, G.W. Carrageenan-induced edema in hind paw of the rat as an assay for
antiiflammatory drugs. Proc. Soc. Exp. Biol. Med. 1962, 111, 544–547. [CrossRef] [PubMed]
30. Eddy, N.B.; Leimback, D. Synthetic analgesics. II. Dithienylbutenyl- and dithienylbutylamines. J. Pharmacol.
Exp. Ther. 1953, 107, 385–393. [PubMed]
31. Meshali, M.; El-Sabbagh, H.; Foda, A. Effect of encapsulation of flufenamic acid with acrylic resins on its
bioavailability and gastric ulcerogenic activity in rats. Acta Pharm. Technol. 1983, 29, 217–219.
32. Sivaraman, D.; Muralidharan, P. Anti-ulcerogenic evaluation of root extract of Ficus hispida Linn. in aspirin
ulcerated rats. Afr. J. Pharm. Pharmacol. 2010, 4, 079–082.
33. Bancroft, J.D.; Stevens, A.; Turmer, R. Theory and Practice of Histological Techniques, 4th ed.; Churchill
Livingstone: Edinburgh, London, UK; Melbourne, Australia, 1996; pp. 47–67.
34. Selinsky, B.S.; Gupta, K.; Sharkey, C.T.; Loll, P.J. Structural analysis of NSAID binding by prostaglandin
H2 synthase: Time-dependent and time-independent inhibitors elicit identical enzyme conformations.
Biochemistry 2001, 40, 5172–5180. [CrossRef] [PubMed]

Molecules 2016, 21, 201
21 of 21
35. Kurumbail, R.G.; Stevens, A.M.; Gierse, J.K.; McDonald, J.J.; Stegeman, R.A.; Pak, J.Y.; Gildehaus, D.;
Miyashiro, J.M.; Penning, T.D.; Seibert, K.; et al. Structural basis for selective inhibition of cyclooxygenase-2
by anti-inflammatory agents. Nature 1996, 384, 644–648. [CrossRef] [PubMed]
36. Gilbert, N.C.; Bartlett, S.G.; Waight, M.T.; Neau, D.B.; Boeglin, W.E.; Brash, A.R.; Newcomer, M.E.
The structure of human 5-lipoxygenase. Science 2011, 331, 217–219. [CrossRef] [PubMed]
37. Gilbert, N.C.; Rui, Z.; Neau, D.B.; Waight, M.T.; Bartlett, S.G.; Boeglin, W.E.; Brash, A.R.; Newcomer, M.E.
Conversion of human 5-lipoxygenase to a 15-lipoxygenase by a point mutation to mimic phosphorylation at
Serine-663. FASEB J. 2012, 26, 3222–3229. [CrossRef] [PubMed]
Sample Availability: Samples of the compounds 12–19 are available from the authors.
©
2016 by the authors; licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons by Attribution
(CC-BY) license (http://creativecommons.org/licenses/by/4.0/).
