The SBA-15/SO3H nanoreactor as a highly efficient and reusable catalyst for
diketene-based, four-component synthesis of polyhydroquinolines and
dihydropyridines under neat conditions
*
Sadegh Rostamnia , Fatemeh Pourhassan
Organic and Nano Group (ONG), Department of Chemistry, Faculty of Science, University of Maragheh, P.O. Box 55181-83111, Maragheh, Iran
A R T I C L E I N F O
A B S T R A C T
Article history:
An efficient diketene ring-opening synthesis of polyhydroquinoline derivatives using SBA-15 sulfonic
acid modified mesoporous substrates a green and reusable catalyst in a single-pot four-component
coupling reaction of diketene, alcohol, enamine, and aldehydes is reported. Dihydropyridine derivatives
based on neat adduct of diketene, alcohols and aldehydes using SBA-15/SO3H nanoreactor as catalyst via
a four-component reactions are also synthesized. The advantages of the present method include the use
of a small amount catalyst, simple procedure with an easy filterable work-up, waste-free, green and
direct synthetic method with an excellent yield of products with efficient use of catalyst and a short
reaction time.
Received 4 January 2013
Received in revised form 2 February 2013
Accepted 28 February 2013
Available online xxx
Keywords:
SBA-15/SO3H
Nanoreactor
Diketene
ß 2013 Sadegh Rostamnia. Published by Elsevier B.V. on behalf of Chinese Chemical Society. All rights
reserved.
Polyhydroquinoline
1. Introduction
however, there exist significant drawbacks, such as high tempera-
ture, long reaction time, low product yields and requirements for
The functionalized SBA-15 silica family of mesoporous materi-
als with nano-channels have shown excellent catalytic perfor-
mance because of their high surface area, high thermal and
mechanical stability as a result of small nanoparticle pore sizes [1].
Hydrothermally stable, the sulfonic acid modified SBA-15 nanor-
eactor (SBA-15/PrSO3H or SBA-15/SO3H) with organic–inorganic
mesochannels as catalyst provides a synergistic means to acidic
sites, and suitable mesochannels to drive out the products for
further recycles [1]. Additionally, based on green chemistry
desires, the development of new strategies for recycling of the
catalyst, which minimizes the consumption of auxiliary sub-
stances, energy and time required in achieving separations, can
result in significant economic and environmental benefits [1].
Polyhydroquinolines, as interesting and versatile N-hetero-
cycles, have attracted much attention due to their pharmacological
properties, such as antitumor, bronchodilator, antidiabetic, anti-
inflammatory, antibacterial, and antimalarial agents [2]. Conse-
quently, many different synthetic methods for producing poly-
hydroquinolines derivatives have been reported using ionic
liquids, molecular iodine, HClO4–SiO2, HY-zeolites, CAN, hetero-
polyacid, and polymers [3]. With regard to most of these methods,
high amounts of organic solvents and catalysts. In addition, the use
of soluble metal catalysts in organic reactions requires several
catalyst separation steps. As a result, the challenge in this field
becomes that of developing waste-free and effective green
approaches with high yields.
Veryrecently,wediscoveredanewmulti-componentmethod[4]
for the ring-opening of diketenes to achieve some interesting
heterocycles based on Biginelli condensation [5]. In this work, our
aim has been to investigate fabrication of the mesoporous sulfonic
acid catalyst to accomplish the desired polyhydroquinolines with a
minimum of by-products, based on ring-opening of the diketene
under clean, neat conditions.
2. Experimental
In this work SBA-15 nanoreactor was synthesized by the
procedure reported by Zhao et al. [6a] and then modified with
mercaptopropyltrimethoxysilane (MPTMS) and oxidized to the
sulfonic acid [6b] nanoparticle using hydrogen peroxide (Fig. 1).
A mixture of diketene (3 mmol), aldehyde (1 mmol), enamine
(1 mmol) and alcohol (4 mL) and SBA-15/SO3H (0.07 g,
ꢀ4 mol%) was reacted under neat conditions for appropriate
time (TLC). After that, 20 mL hot EtOH was added to the reaction
vessel and, with simple centrifuging, the catalyst was removed
as filtrate, washed and then the product recrystallized from hot
ethanol. All of the products are synthesized by four-component
* Corresponding author.
E-mail addresses: rostamnia@maragheh.ac.ir, srostamnia@gmail.com
(S. Rostamnia).
1001-8417/$ – see front matter ß 2013 Sadegh Rostamnia. Published by Elsevier B.V. on behalf of Chinese Chemical Society. All rights reserved.
http://dx.doi.org/10.1016/j.cclet.2013.03.020
Please cite this article in press as: S. Rostamnia, F. Pourhassan, The SBA-15/SO3H nanoreactor as a highly efficient and reusable catalyst
for diketene-based, four-component synthesis of polyhydroquinolines and dihydropyridines under neat conditions, Chin. Chem. Lett.
(2013), http://dx.doi.org/10.1016/j.cclet.2013.03.020

G Model
CCLET-2505; No. of Pages 3
2
S. Rostamnia, F. Pourhassan / Chinese Chemical Letters xxx (2013) xxx–xxx
Fig. 1. SEM and TEM images of SBA-15/SO3H nanoreactor.
method and were identified by their physical and spectral data
(mp, IR, 1H NMR and 13C NMR). Methyl 4-(2-chlorophenyl)-
2,7,7-trimethyl-5-oxo-1,4,5,6,7,8-hexahydro-3-quinolinecar-
boxylate (3d, Table 1). IR (KBr, cmÀ1): vmax 3289, 2951, 1707,
1654, 1608, 1490, 1222, 1080, 1034, 827, 773, 540. 1H NMR
40.96, 50.62, 50.83, 105.17, 111.37, 126.42, 127.26, 129.61,
131.64, 131.64, 133.10, 143.87, 144.33, 148.92, 167.91, 195.51.
Diethyl 2,6-dimethyl-4-phenyl-1,4-dihydropyridine-3,5-dicar-
boxylate (Table 2, entry 4). IR (KBr, cmÀ1): vmax 3346, 1703,
1657, 1473, 1198. 1H NMR (300 MHz, CDCl3):
d 1.20 (t, 6 H,
(300 MHz, CDCl3):
H), 3.57 (s, 3 H), 5.38 (s, 1 H), 6.81 (s, 1 H), 7.00–7.34 (m, 4 H).
13C NMR (75 MHz, CDCl3):
d
0.91 (s, 3H), 1.07 (s, 3 H), 2.04–2.36 (m, 7
J = 7.0 Hz, 2Â OCH2CH3), 2.31 (s, 6H, 2Â CH3), 4.09 (q, 4 H,
J = 7.0 Hz, 2Â OCH2CH3), 5.01 (s, 1 H, CH), 6.20 (s, 1 H, NH), 7.10–
7.39 (m, 5H, C6H5).
d 19.19, 27.15, 29.37, 32.54, 35.61,
Table 1
SBA-15/SO3H catalyzed the neat four-component synthesis of polyhydroquinolines derivatives of 3.
O
O
Ar
O
O
+
SBA-15/SO3H
4 mol%
O
R
R
OH
+
+
Ar
O
60 oC
O
NH2
(excess)
N
H
2
3
1
.
Entry
Ar
R
Time (min)
mp (8C)
Yield (%)
Found
Reported [3]
3a
3b
3c
3d
3e
3f
C6H5
H
25
25
25
25
30
30
25
20
25
35
257–259
220–222
260–264
235–238
247–250
217–223
244–246
234–243
238–240
201–205
258–260
221–222
–
90
90
85
85
90
85
95
90
90
85
4-Cl-C6H4
H
2-Me-C6H4
2-Cl-C6H4
H
H
–
4-OMe-C6H4
2-Cl-C6H4
H
–
Me
Me
Me
Me
Me
208–210
242–244
257–259
245–246
–
3g
3h
3i
4-NO2-C6H4
4-OMe-C6H4
4-Cl-C6H4
3j
2-Me-C6H4
Table 2
The neat four-component synthesis of dihydropyridines derivatives of 4.
O
Ar
O
O
+
SBA-15/SO3H
4 mol%
O
R
O
O
R
R
OH +
+
Ar
2
O
60 o
C
O
OH.NH3
(excess)
N
H
1
2
4
.
Entry
Ar
R
mp (8C)
Yield (%)
Found [4b]
Reported
1
2
3
4
5
6
7
8
C6H5
Me
H
150–153
168–169
163–165
160–162
122–126
123–124
146–149
125–129
152–153
171–172
161–165
164–166
123–126
120–125
144–147
124–126
90
84
80
84
80
91
91
93
3-OMe-C6H4
4-NO2-C6H4
2-OMe-C6H4
2-Cl-C6H4
H
H
Me
Me
Me
Me
3-Cl-C6H4
4-Cl-C6H4
4-NO2-C6H4
Please cite this article in press as: S. Rostamnia, F. Pourhassan, The SBA-15/SO3H nanoreactor as a highly efficient and reusable catalyst
for diketene-based, four-component synthesis of polyhydroquinolines and dihydropyridines under neat conditions, Chin. Chem. Lett.
(2013), http://dx.doi.org/10.1016/j.cclet.2013.03.020

G Model
CCLET-2505; No. of Pages 3
S. Rostamnia, F. Pourhassan / Chinese Chemical Letters xxx (2013) xxx–xxx
3
of polyhydroquinoline and dihydropyridine derivatives based on
the diketene ring-opening reaction under neat conditions and
short reaction times. Simple separation, easy recovery and
reusability of the catalyst make it a highly efficient and
convenient catalyst.
References
[1] (a) X.J. Feng, M. Yan, X. Zhang, M. Bao, Preparation and application of SBA-15-
supported palladium catalyst for Heck reaction in supercritical carbon dioxide,
Chin. Chem. Lett. 22 (2011) 643–646;
(b) H.R. Pei, X. Yan, X.Z. Lan, Unusual phase behavior of decane–dodecane mixtures
confined in SBA-15: size effect on binary phase diagram, Chin. Chem. Lett. 23
(2012) 1173–1176;
(c) Q. Yang, M.P. Kapoor, S. Inagaki, Sulfuric acid-functionalized mesoporous
benzene–silica with a molecular-scale periodicity in the walls, J. Am. Chem. Soc.
124 (2002) 9694–9695.
Fig. 2. Recycle of the SBA-15/SO3H catalyst.
[2] (a) V. Klusa, Cerebrocrast (IOS-1.1212). Neuroprotectant, cognition enhancer,
Drugs Future 20 (1995) 135–138;
(b) A. Sausins, G. Duburs, Synthesis of 1, 4-dihydropyridines by cyclocondensation
reaction, Heterocycles 27 (1988) 279–289.
3. Results and discussion
[3] (a) R. Sridhar, P.T. Perumal, A new protocol to synthesize 1,4-dihydropyridines by
using 3,4,5-trifluoroenzeneboronic acid as a catalyst in ionic liquid: synthesis of
novel 4-(3-carboxyl-1H-pyrazol-4-yl)-1,4-dihydropyridines, Tetrahedron 61
(2005) 2465–2470;
In continuation of our investigations on the synthesis of
heterocycles and the use of heterogeneous nanocatalysts for
chemical preparation, we developed the applicability of reusable
SBA-15/SO3H as an efficient and convenient catalyst in synthesis of
polyhydroquinolines by a one-pot, four-component reaction of
diketene, alcohols, enamine, and aldehydes under neat conditions.
The SBA-15/SO3H heterogeneous nanocatalyst was synthesized
by grafting of –SO3H onto the SBA-15 by refluxing a mixture of
calcinated SBA-15 and MPTMS in dry toluene. Then the resulting
solid product was oxidized with H2O2 (Fig. 1).
(b) S. Ko, M. Sastry, C. Lin, C. Yao, Molecular iodine-catalyzed one-pot synthesis of
4-substituted-1,4-dihydropyridine derivatives via Hantzsch reaction, Tetrahedron
Lett. 46 (2005) 5771–5774;
(c) B. Das, B. Ravikanth, R. Ramu, B. Rao, An efficient one-pot synthesis of poly-
hydroquinolines at room temperature using HY-zeolite, Chem. Pharm. Bull. 54
(2006) 1044–1045;
(d) S. Ko, C. Yao, CAN (ceric ammonium nitrate) catalyze the one-pot synthesis
of polyhydroquinoline via Hantzch reaction, Tetrahedron 62 (2006) 7293–
7299.
[4] (a) S. Rostamnia, K. Lamei, Diketene-based neat four-component synthesis of the
dihydropyrimidinones and dihydropyridine backbones using silica sulfuric acid
(SSA), Chin. Chem. Lett. 23 (2012) 930–932;
Then as a method reaction the mixture of enamine, aldehydes,
diketene and methanol as reactant and solvent in the presence of
SBA-15/SO3H, after 16 min the reaction was completed with high
yield of product 3.
(b) A. Alizadeh, S. Rostamnia, Adducts of diketene, alcohols, and aldehydes: useful
building blocks for 3,4-dihydropyrimidinones and 1,4-dihydropyridines, Synthesis
(2010) 4057–4060.
[5] (a) S. Rostamnia, Eco-friendly supported nanoparticles as a green approach, Res. J.
Chem. Environ. 15 (2011) 89–91;
The activity and recyclability of the catalyst were studied
(Fig. 2) using the reaction of a mixture of enamine, benzaldehyde,
diketene and methanol in the presence of SBA-15/SO3H, to achieve
3a. After completion of the reaction, the catalyst was separated by
simply centrifuging, and then washed with hot EtOH and water,
supporting the use of the modified catalyst in the reaction method
for at least 5 times.
The neat reaction of diketene, aldehydes 1, alcohols 2, with
ammonium acetate in the presence of the SBA-15/SO3H catalyst
was found to generally afford the 1,4-dihydropyridines (DHPs) 4 in
good yields (Table 2).
(b) S. Rostamnia, Z. Karimi, M. Ghavidel, Cetyltrimethylammonium bromide-
surfactant aqueous micelles as a green and ultra-rapid reactor for synthesis of
5-oxo-2-thioxo-2, 5-dihydro-3-thiophenecarboxylate derivatives, J. Sulf. Chem. 33
(2012) 313–318;
(c) S. Rostamnia, A. Zabardasti, SBA-15/TFE (SBA-15/2,2,2-trifluoroethanol) as
suitable and efficient metal-free catalyst for preparation of the tri- and tetra-
substituted imidazoles via one-pot multicomponent method, J. Fluorine Chem. 144
(2012) 69–72;
(d) S. Rostamnia, K. Lamei, M. Mohammadquli, M. Sheykhan, A. Heydari, Nano-
magnetically modified sulfuric acid (g-Fe2O3@SiO2-OSO3H): an efficient, fast and
reusable green catalyst for Ugi-like Groebke-Blackburn-Bienayme´ 3-CR in solvent-
free condition, Tetrahedron Lett. 53 (2012) 5257–5260;
(e) S. Rostamnia, K. Lamei, A rapid, catalyst-free, three-component synthesis of
Rhodanines in water using ultrasound, Synthesis (2011) 3080–3082.
[6] (a) D. Zhao, J. Feng, Q. Huo, et al., Triblock copolymer syntheses of mesoporous
silica with periodic 50 to 300 angstrom pores, Science 279 (1998) 548–552;
(b) B. Karimi, D. Zareyee, Design of a highly efficient and water-tolerant sulfonic
acid nanoreactor based on tunable ordered porous silica for the von Pechmann
reaction, Org. Lett. 10 (2008) 3989–3992.
4. Conclusion
In conclusion, we demonstrated that covalently bonded
sulfonic acid SBA-15 is an efficient solid catalyst for the synthesis
Please cite this article in press as: S. Rostamnia, F. Pourhassan, The SBA-15/SO3H nanoreactor as a highly efficient and reusable catalyst
for diketene-based, four-component synthesis of polyhydroquinolines and dihydropyridines under neat conditions, Chin. Chem. Lett.
(2013), http://dx.doi.org/10.1016/j.cclet.2013.03.020
