Guest recognition enhanced by lateral interactions
Tianyu Jiao,1,2 Kang Cai,2 Zhichang Liu,3 Guangcheng Wu,1 Libo Shen,1 Chuyang Cheng,2
Yuanning Feng,2 Charlotte L. Stern,2 J. Fraser Stoddart*,2,4,5 and Hao Li*,1
1
2
3
4
5
Department of Chemistry, Zhejiang University, Hangzhou 310027, P. R. China
Department of Chemistry, Northwestern University, 2145 Sheridan Road, Evanston, Illinois 60208, USA
School of Science, Westlake University, 18 Shilongshan Road, Hangzhou 310024, P. R. China
Institute for Molecular Design and Synthesis, Tianjin University, Tianjin 300072, P. R. China
School of Chemistry, University of New South Wales, Sydney, NSW 2052, Australia
Abstract
A hexacationic triangular covalent organic cage AzaEx2Cage6+ has been synthesized by
means of a tetrabutylammonium iodide-catalyzed SN2 reaction. The prismatic cage is
composed of two triangular 2,4,6-triphenyl-1,3,5-triazine (TPT) platforms bridged
face-to-face by three 4,4′-bipyridinium (BIPY2+) spacers. The rigidity of these building
blocks leads to a shape-persistent cage cavity with an inter-platform distance of
approximately 11.0 Å. This distance allows the cage to accommodate two aromatic guests,
each of which is able to undergo π‒π interactions with one of the two TBT platform
simultaneously, in an A‒D‒D‒A manner. In the previously reported prism-shaped cage, the
spacers (pillars) are often considered passive or non-interactive. In the current system, the
three BIPY2+ spacers are observed to play an important role in guest recognition. Firstly, the
BIPY2+ spacers are able to interact with the carbonyl group in a pyrene-1-carbaldehyde
(PCA) guest, by introducing lateral dipole‒cation or dipole‒dipole interactions. As a
consequence, the binding affinity of the cage towards the PCA guest is significantly larger
than that of pyrene as the guest, even although the latter is often considered to be a better
π-electron
donor.
Secondly,
in
the
case
of
the
guest
1

Chemical Science
Page 2 of 26
View Article Online
1,5-bis[2-(2-(2-(2-hydroxyethoxy)ethoxy)ethoxy)ethoxy]naphthalene (BH4EN),DOthI:e10.1p03il9l/aCr9sSC00591A
can provide higher binding forces compared to the TPT platform. Hence, peripheral
complexation occurs when AzaEx2Cage6+ accommodates BH4EN in MeCN. Thirdly, when
both PCA and BH4EN are added into a solution of AzaEx2Cage6+, inclusion and peripheral
complexation occur simultaneously to PCA and BH4EN respectively, even though the
accommodation of the former guest seems to attenuate the external binding of the latter. This
discovery of the importance of lateral interactions highlights the relationship between the
electrostatic properties of a highly charged host and its complexation behavior, and as such,
provides insight into the design of more complex hosts that bind guests in multiple locations
and modes.
Introduction
Cyclophanes, such as calix[n]arenes,1 oxacalixarenes,2 resorcinarenes,3 pillar[n]arene,4
calixpyrroles,5 as well as cationic ones,6 including cyclobis(paraquat-p-phenylene)
(CBPQT4+)7 and its extended counterparts,8 represent one of the major focuses in the field of
supramolecular chemistry. In the frameworks of these cyclophanes, various arenes are
connected by a number of aliphatic linkers such as methylene units, resulting in relatively
rigid and preorganized cavities where guest encapsulation could occur without significant
entropy loss. For example, in the case of CBPQT4+, π-electron-deficient 4,4′-bipyridinium
(BIPY2+) are separated by two p-xylene spacers in a face-to-face manner by approximately 7
Å, which is two times longer than a typical π‒π interaction distance. These geometrical
properties imply that CBPQT4+ could accommodate a π-conjugated guest within its cavity,
where π‒π interactions9 could occur between the guest and both the two BIPY2+ platforms in
2

Page 3 of 26
Chemical Science
View Article Online
DOI: 10.1039/C9SC00591A
the host.
These kind of host-guest recognition features of CBPQT4+ and its homologous
cyclophanes can be used to fulfill various tasks, including the construction of molecular
switches10 and machines11 in the form of rotaxanes12 and catenanes,13 water purification via
the extraction of aromatic compounds into the host14 and the stabilization of unusual guest
conformations.15 There are still several limitations, however, in the design principles of these
cyclophanes.
Firstly, the spacers that connect the π-electron-deficient moieties often behave as “passive”
or non-interactive building blocks in terms of molecular recognition – except for a few
examples where these spacers can take part in relatively weak [C−H···π] interactions.16
Secondly, in most cases, host-guest complexation occurs within the host cavity wherein the
interactions between the guests and the two platforms occur simultaneously. Furthermore,
these interactions are often strengthened by solvophobic effects in polar solvents. As a
consequence, most of these cages or rings only have one binding mode or site. There are very
few examples17 of external guest binding to these hosts.
In the current work, we report the design and synthesis of a hexacationic triangular prism,
AzaEx2Cage6+, which is composed of two TPT platforms connected face-to-face by three
BIPY2+ pillars. The distance between the two platforms is approximately 11.0 Å, which is
approximately three-times larger than a typical π‒π interactions distance, implying that the
cavity in this prism could encapsulate two aromatic guest molecules such as pyrene.
Interestingly, in contrast to previously reported hosts that contain phenyl or biphenyl spacers,
the BIPY2+ spacers in AzaEx2Cage6+ play a more important role in host-guest complexation.
3

Chemical Science
Page 4 of 26
View Article Online
DOI: 10.1039/C9SC00591A
The host exhibits significantly better binding affinity towards pyrene-1-carbaldehyde
(PCA) than towards pyrene in both organic solvents and water because the former guest
contains a partially negatively charged carbonyl group that can undergo dipole-cation or
dipole-dipole interactions with the positively charged BIPY2+ pillars. Furthermore, the
BIPY2+ pillars allow the cage to form an external complex with
1,5-bis[2-(2-(2-(2-hydroxyethoxy)ethoxy)ethoxy)ethoxy]naphthalene (BH4EN), a guest
containing two tetraethylene glycol chains grafted onto a 1,5-dioxynaphthalene (DNP)
moiety. This external binding is driven by the donor-acceptor interactions between the DNP
unit in the guest and the BIPY2+ pillar in the host, as well as hydrogen bonding between the
glycol oxygen atoms and the relatively acidic protons in the BIPY2+ units. The assumption
that the DNP unit prefers to interact with the more electron-deficient BIPY2+ pillar instead of
the triazine-containing platform inside the cage is supported by both single-crystal X-ray
diffraction analysis and theoretical calculations. Furthermore, guest encapsulation and
external binding to the cage occur simultaneously in the presence of both PCA and BH4EN,
even though binding of the latter slightly decreases upon encapsulation of the former.
We envision that our findings will promote the fundamental understanding, and thus
design, of hosts that are able to accommodate guests in multiple modes or sites.
Experimental section
Synthesis and Characterization of AzaEx2Cage•6PF6
2,4,6-Tris[4-(bromomethyl)phenyl]-1,3,5-triazine (TBT) ‒ a molecule that comprises three
benzyl bromide functions grafted onto a TPT moiety ‒ was synthesized in high yield from
the acid-catalyzed trimerization of 4-cyanobenzyl bromide.18 TBT was added slowly into a
4

Page 5 of 26
Chemical Science
View Article Online
DOI: 10.1039/C9SC00591A
refluxing solution containing a 40-fold excess of 4,4′-bipyridine in MeCN and DMF (1:1 v/v)
o
at 90 C in several aliquots over the course of 6 h, yielding the triscationic compound
TBTP•3PF6 after counterion exchange. A 1:1 mixture of TBT and TBTP•3PF6 was then
combined and heated at 80 oC in MeCN in the presence of 0.2 equiv of tetrabutylammonium
iodide (TBAI) as a catalyst, leading to the formation (Scheme 1) of a substantial amount of
1
yellow precipitate. The H NMR spectrum of the precipitate, recorded in CD3SOCD3,
indicates that the cage AzaEx2Cage6+, the counterions of which could be either Br−, I− or
−
PF6 , represents the major product in the precipitate, along with a variety of oligomers or
polymers as the minor products. Pure AzaEx2Cage•6PF6 was obtained in 16 % yield by
means of silica gel chromatography (1% NH4PF6 in MeCN (w/v)), before which counterion
exchange was performed. Two more water-soluble counterparts, namely AzaEx2Cage•6Cl
and AzaEx2Cage•6CF3CO2, were then obtained from AzaEx2Cage•6PF6 by counterion
exchange.
Results and Discussion
AzaEx2Cage•6PF6 was fully characterized by NMR spectroscopy, high-resolution mass
1
spectrometry (HRMS), and X-ray diffraction analysis. Its H NMR spectrum is remarkably
simple (Figure 1b), indicating that the cage has averaged D3h symmetry in solution.
Single crystals of both AzaEx2Cage•6PF6 and AzaEx2Cage•6CF3CO2 were obtained by
vapor diffusion of iPr2O into the corresponding MeCN solutions. Crystal twinning was
observed, however, in the case of the former crystals (Figures S40 and 41). As expected, in
the solid-state structure (Figure 2) of AzaEx2Cage•6CF3CO2, the two TPT platforms in a
cage framework are separated by a distance of approximately 11.0 Å, which is three-times
5

Chemical Science
Page 6 of 26
View Article Online
larger than a typical π‒π interaction distance,19 indicating that the cage DiOsI: 10a.b10l3e9/Ct9oSC00591A
accommodate two aromatic guests in an A‒D‒D‒A (A = acceptor; D = donor) manner. The
distance between two adjacent methylene linkers within each TPT platform is around 11.6 Å.
As a result, the cage framework has three relatively large (11.0 Å × 11.6 Å) rectangular pore
windows. These large windows allow potential guests to undergo relatively fast
association/dissociation with the cage. The CF3CO2 counterions are located close to the
−
BIPY2+ pillars. Hydrogen-bonding interactions occur between the CF3CO2 counterions and
the protons of the cage in the solid state. Furthermore, pairs of adjacent cage frameworks
undergo stacking with each other, driven by π‒π interactions between a triazine unit in the
platform of one cage and a phenyl moiety of the other.
Cyclic voltammetry (CV) analysis (Figure S36a) of AzaEx2Cage•6PF6 in degassed DMF
reveals two consecutive reversible redox processes. The reduction processes at ‒0.264 and
–0.662 V can be assigned to two consecutive three-electron reductions, i.e., BIPY2+/BIPY+•
and BIPY+•/BIPY0, by three identical BIPY2+ pillars in a cage. The simultaneous reduction
of the three pillars indicates the absence of electron communication between the BIPY2+
units within the cage framework.
The UV-Vis-NIR absorption spectrum (Figure S36b) of AzaEx2Cage3(+•) was obtained by
adding Zn dust as a reductant to a solution of AzaEx2Cage•6PF6 in MeCN. The spectrum is
similar to that of 4,4′-dimethylviologen radical cations, further demonstrating that neither
radical pairing nor dimerization occurs between any two of the three BIPY+• pillars of the
cage AzaEx2Cage3(+•). The absence of intramolecular radical pairing interactions20 is not
surprising because the three BIPY+• units are separated by approximately 11.6 Å within the
6

Page 7 of 26
Chemical Science
View Article Online
DOI: 10.1039/C9SC00591A
rigid cage framework.
Host-Guest Recognition
We first investigated the ability of AzaEx2Cage6+ to accommodate two π-electron-rich
1
guests, since the two TPT platforms are π-electron acceptors. The H NMR resonances for
AzaEx2Cage•6PF6 recorded in CD3CN exhibit only relatively small shifts upon addition of
different guests, including pyrene, triphenylene, and perylene. For example, upon addition of
8.37 equiv of pyrene, the resonances of the Hc and Hd protons in the phenylene residues of
AzaEx2Cage•6PF6 undergo (Figure 1c) upfield shifts of just −0.02 and −0.06 ppm,
respectively. These findings indicate that the ability of AzaEx2Cage6+ to accommodate
pyrene within its cavity is remarkably small. Side-on interactions between the host platforms
and the guests in a external manner may also contribute to the upfield shifts of the cage
1
proton resonances in the H NMR spectra, at least partially. For example, after adding 30
equiv of pyrene into a solution of TBT in CD3CN, the resonances of the corresponding
phenylene protons undergo upfield shifts of −0.02 and −0.04 ppm, respectively. In fact, the
binding constants of AzaEx2Cage6+ to two pyrene molecules in CD3CN, i.e., K1 and K2, are
1
too low to be determined accurately by means of H NMR titration experiments. A 1:1
binding model was employed to fit the NMR titration data, for which Keq = 11.1 ± 0.2 M─1
was determined (Figures S22 and S23). Several attempts were made to obtain single crystals
of the complex (pyrene)2⊂AzaEx2Cage6+ by vapor diffusion of iPr2O into MeCN solutions
containing both pyrene and AzaEx2Cage•6PF6 at different guest-to-host ratios ranging from
5:1 to 40:1. All of these attempts, however, yielded only a few single crystals corresponding
to “empty” AzaEx2Cage•6PF6 cages, further supporting our conclusion that the binding
7

Chemical Science
Page 8 of 26
View Article Online
DOI: 10.1039/C9SC00591A
affinity of (pyrene)2⊂AzaEx2Cage6+ is at best very weak.
We also envisioned that AzaEx2Cage•6Cl might be capable of accommodating pyrene in
water by taking advantage of the hydrophobic effect. After sonicating suspensions of pyrene
o
in D2O solutions of AzaEx2Cage•6Cl (1.0 mM) at both room temperature and 80 C for no
less than 5 h, however, no resonances corresponding to pyrene were observed in the 1H NMR
spectra. In addition, the resonances of the cage protons remained almost completely unshifted.
These results are in contrast to our previously reported findings, i.e., that the two smaller
14
cages, namely ExCage6+
and AzaExCage6+,21 can encapsulate a variety of polycyclic
aromatic hydrocarbons with remarkably high binding constants in both organic solvents and
water. For example, the Ka values for pyrene⊂ExCage6+ and pyrene⊂AzaExCage6+ are 6.77
× 105 14 and 4.93 × 105 M-1,21 respectively, in MeCN. The lower binding affinity in the case
of AzaEx2Cage6+ could be explained by the facts that (i) the TPT platform of AzaEx2Cage6+
is a weaker π-electron acceptor than the more electron-deficient triscationic counterparts such
as 1,3,5-pyridinium-phenyl in ExCage6+ and 2,4,6-pyridinium-1,3,5-triazine in AzaExCage6+,
(ii) the formation the 2:1 complex (pyrene)2⊂AzaEx2Cage6+ is less entropically favored than
formation of the 1:1 complexes pyrene⊂ExCage6+ and pyrene⊂AzaExCage6+(i.e., ExCage6+
and AzaExCage6+ have more preorganized cavities for encapsulating pyrene guests) and (iii)
the A‒D‒D‒A binding mode in the case of (pyrene)2⊂AzaEx2Cage6+ involves a less favored
D‒D interaction, making its formation more energetically demanding than that of the
A‒D‒A mode that occurs in both pyrene⊂ExCage6+ and pyrene⊂AzaExCage6+.
Pyrene-1-carbaldehyde (PCA) is considered to be a weaker π-electron donor than pyrene,
since it contains an electron-withdrawing formyl group. Surprisingly, PCA undergoes
8

Page 9 of 26
Chemical Science
View Article Online
DOI: 10.1039/C9SC00591A
significantly stronger binding within the cavity of AzaEx2Cage•6PF6 compared to that of
pyrene. For example, upon addition of 10.8 equiv of PCA to a CD3CN solution of
AzaEx2Cage•6PF6 (Figure 1d), the resonances of the Hc and Hd protons in the platforms of
the cage undergo much more significant upfield shifts, i.e., Δδ for Hc and Hd are −0.154 and
−0.618 ppm, respectively, compared with −0.02 and −0.06 ppm, respectively, when 8.37
equiv of pyrene is added (Figure 1c). The upfield shifts reveal the presence of π‒π
interactions between the TPT platform and the pyrene moiety in the guest, providing the
phenylene units in the platform with a magnetically shielded environment. Only one set of
1
sharp resonances corresponding to either the host or the guest is observed in the H NMR
spectra (Figures 1d and 3b), regardless of the host-to-guest ratio, indicating that host-guest
association/dissociation occurs relatively rapidly on the 1H NMR timescale. This observation
is consistent with the solid-state structure of AzaEx2Cage6+ ‒ i.e., each cage contains three
large pore windows allowing for rapid guest exchange.
1H NMR Titration experiments (Figures 3b and 3c) revealed that the binding constants for
the formation of (PCA)2⊂AzaEx2Cage6+ in CD3CN, i.e., K1 and K2, are 23 ± 3 and 730 ±
160 M-1, respectively. The positive cooperativity effect is not surprising, given that the cage
cavity with a length of 11 Å is too large and less preorganized to accommodate the first guest,
which is able to undergo π-π interactions with only one of the two platforms in the host. After
accommodation of the first guest, the cavity becomes smaller in size and therefore more
complementary towards binding of the second guest molecule. In addition, the encapsulation
of the second guest is driven by an extra guest-guest π–π interaction, which does not occur in
the case of the first guest. The 2:1 complex (PCA)2⊂AzaEx2Cage6+ forms exclusively in
9

Chemical Science
Page 10 of 26
View Article Online
DOI: 10.1039/C9SC00591A
D2O upon sonicating a PCA solid in a D2O solution of AzaEx2Cage•6Cl (1.0 mM) at room
temperature. Measuring the integration of the resonances for the protons corresponding to
1
both the host and guest in the H NMR spectrum (Figure 3d) confirms the 1:2 host-to-guest
stoichiometry of the complex, which is largely a result of the low solubility of the unbound
guest in water. The 2D DOSY spectrum (Figure 3d) further confirms the formation of the
complex (PCA)2⊂AzaEx2Cage6+. In addition, in water, the resonance for the formyl proton
in PCA undergoes a remarkable upfield shift, i.e., δ = 8.41 ppm; Δδ ≈ 2 ppm. This
observation indicates that a short contact occurs between the aldehyde and one of the
viologen pillars in the host. The latter unit thus provides a shielded magnetic chemical
environment for the former group, which supports our assumption that formyl group can
undergo cation–dipole interactions with one of the viologen pillars.
Single crystals of (PCA)2⊂AzaEx2Cage·6PF6 suitable for X-ray diffraction were obtained
o
by vapor diffusion of iPr2O into its MeCN solution at 4 C over 3 days, providing
unambiguous evidence for the formation of a 2:1 complex (Figure 4). As expected, two guest
molecules are accommodated within the cavity of the cage framework. π‒π stacking
interactions occur between the two platforms in the host and the two guests in an A‒D‒D‒A
manner, as inferred from the observation that the distances between triazine / pyrene, pyrene /
pyrene, and pyrene / triazine are 3.42, 3.46, and 3.46 Å, respectively. The closest contacts
between the two carbonyl oxygen atoms and the corresponding BIPY2+ pillars of the host are
2.78 and 3.01 Å, indicating the occurrence of dipole‒cation or dipole‒dipole interactions.
This secondary interaction is responsible for the enhanced binding affinities of PCA with the
cage cavity relative to those of pyrene. It is noteworthy that, in the solid state, the two
10

Page 11 of 26
Chemical Science
View Article Online
carbonyl groups of the two guests interact with two different BIPY2+ pillars inDtOhI:e10c.1a0g39e/Ci9nSC00591A
order to minimize the repulsion between the partially anionic carbonyl oxygen atoms. Thus,
(PCA)2⊂AzaEx2Cage·6PF6 exhibits axial chirality in the solid state, even though both of the
two enantiomers co-crystallize in a racemic crystal lattice.
BH4EN, which is another π-electron-rich compound that bears two tetraethylene glycol
chains grafted onto a 1,5-dioxynaphthalene (DNP) moiety, was also added into a CD3CN
solution of AzaEx2Cage·6PF6 in order to investigate their recognition behavior. Interestingly,
instead of forming an inclusion complex in either a 1:1 or 1:2 manner, it seems that the
external complex BH4EN•AzaEx2Cage6+ is formed. This assumption was supported initially
by the 1H NMR spectrum (Figure 1e). Upon addition of 11.4 equiv of BH4EN, the resonance
of the Hb proton in BIPY2+ undergoes a significant upfield shift (Δδ ≈ −0.229 ppm), while
those of Hc and Hd in the platforms are barely shifted. This observation indicates that, instead
of undergoing π‒π interactions with the cage platform, the DNP moiety prefers to interact
with the BIPY2+ pillars in the host, which therefore experience a magnetically shielded
environment. No NOESY cross-peaks between the phenylene units in the host platforms and
DNP protons in the guest are observed in the NOESY spectrum (Figure S27) of the complex
BH4EN•AzaEx2Cage6+, indicating that the interactions between DNP and BIPY2+ occur on
the periphery of the cage molecule. The formation of a external complex was unambiguously
confirmed by single-crystal X-ray diffraction. In the solid state (Figure 5), the face-to-face
distance between DNP and BIPY2+ is around 3.46 Å, confirming the occurrence of π-electron
donor‒acceptor interactions. The two glycol chains of the guest penetrate into the cavities of
two adjacent cage molecules. The shortest contact between an oxygen atom in the glycol
11

Chemical Science
Page 12 of 26
View Article Online
DOI: 10.1039/C9SC00591A
chain and one of the Hb protons in BIPY2+ is around 2.24 Å, indicating the existence of
[C−H···O] interactions. The combination of donor‒acceptor and hydrogen bonding
interactions make the formation of the external complex more thermodynamically favorable
than formation of the inclusion complex wherein the DNP guest undergoes π‒π interactions
with the triazine residue in the platforms. In water, the recognition mode for BH4EN and
AzaEx2Cage6+ is similar, i.e., adding BH4EN to a solution (1.0 mM) of AzaEx2Cage·6Cl in
D2O also results in an upfield shift of the resonances for the BIPY2+ protons. However, an
interesting difference is that strong NOESY cross-peaks between the DNP protons (Hy and/or
Hz) and the phenylene protons (Hc and Hd) in the host platforms are observed (Figure 6).
These observations indicate that, in water, the complex BH4EN⊂AzaEx2Cage6+ may exist in
the form of an inclusion complex instead of the external complex observed in CD3CN. This
observation could be explained by the fact, that in water where the hydrophobic effect
becomes predominant, the formation of the inclusion complex is more thermodynamically
favored than formation of the external complex. Our attempts to obtain single crystals of the
complex BH4EN⊂AzaEx2Cage6+ from water proved unsuccessful, probably because of the
relatively high aqueous solubilities of both the host AzaEx2Cage·6Cl and the guest BH4EN.
When both PCA and BH4EN are added to a CD3CN solution of AzaEx2Cage•6PF6,
inclusion and external complexation occur simultaneously, as inferred from the
1
corresponding H NMR spectroscopic analyses (Figures S30‒S33), in which the proton
resonances of both the platforms and pillars undergo shifts upon addition of PCA and
BH4EN,
respectively.
Diffraction-grade
single-crystals
of
BH4EN•(PCA)2⊂AzaEx2Cage•6PF6 were obtained by slow vapor diffusion of iPr2O into a
12

Page 13 of 26
Chemical Science
View Article Online
DOI: 10.1039/C9SC00591A
three-component 10:4:1 mixture of PCA, BH4EN and AzaEx2Cage·6PF6 in MeCN (2.0 mM)
at 4 oC over a period of 3 days. In the solid state (Figure 7), the cavity of a cage is occupied
by two PCA guests, while a BH4EN guest resides on the external surface of a BIPY2+ pillar
in the host. The glycol chains of the BH4EN guest are excluded from the cage cavity by the
two PCA guests. This observation implies that hydrogen bonding between the glycol chains
and the BIPY2+ units in the host might be attenuated to some extent in the solid state.
1
A H NMR titration experiment was performed to evaluate the impact of PCA on the
binding affinity of between AzaEx2Cage·6PF6 and BH4EN. In the absence of PCA, the
binding constant (Ka) for the complex BH4EN•AzaEx2Cage6+ (Figures S26 and S33) is
approximately around 36.7 ± 0.4 M-1 in CD3CN, while upon adding 26.6 equiv of PCA, the
Ka value decreases to 4.9 ± 0.1 M-1. The decrease of the binding constant in solution is
consistent with the solid-state observation that encapsulation of PCA guests expels the glycol
chains of BH4EN from the cage cavity and helps to decrease the strength of hydrogen
bonding. Interestingly, in the presence of 7.8 equiv of BH4EN, the binding constants
between the cage and two PCA guests (Figure S31) seem to be barely changed as compared
with those in the absence of BH4EN. This observation may be because the impact of external
binding on the environment inside the cage is of less importance.
Quantum Mechanical Calculations
In order to gain a better understanding of the recognition characteristics of AzaEx2Cage6+
in terms of both inclusion and peripheral complexation, we have performed density
functional theory (DFT) calculations to investigate the electronic properties AzaEx2Cage6+.
Geometry
optimization
of
AzaEx2Cage6+,
BH4EN•AzaEx2Cage6+,
13

Chemical Science
Page 14 of 26
View Article Online
(pyrene)2⊂AzaEx2Cage6+, and (PCA)2⊂AzaEx2Cage6+ were performed at the MD0O6I:-120X.103l9e/vCe9SlC00591A
of theory22 with the 6-31G(d) basis set.23 The single-point energies and solvent effects in
MeCN were computed at the M06-2X level of theory with the 6-311++G(d,p) basis set for all
the atoms, based on the optimized gas-phase structures. Solvation energies were evaluated by
a self-consistent reaction field (SCRF) using the SMD model.24 Natural population analysis25
of AzaEx2Cage6+ demonstrates that the bipyridinium, methylene and TPT units take +1.301,
+0.327 and +0.074 (see the Supporting Information), respectively, implying that the BIPY2+
pillars of the cage, including both pyridinium moieties and the methylene linkers, takes up
most of the positive charge on the cage. Expressed another way, the BIPY2+ pillars are more
electron-deficient than the TPT platforms (Figure 8a). On one hand, since the DNP unit in a
BH4EN guest represents a π-electron-rich donor, it is not surprising that DNP prefers to
interact with BIPY2+, forming a BH4EN•AzaEx2Cage6+ complex (Figure 8b) whose
formation is also strengthened by hydrogen bonding interactions. On the other hand, the
guests pyrene and PCA have larger π-electron surfaces. As a consequence, they prefer to
interact with the TPT platform driven by π‒π stacking interactions as well as solvophobic
effects. To visualize the cation–dipole interactions, we performed the reduced density
gradient (RDG) analysis26 on the (PCA)2⊂AzaEx2Cage6+. The analysis shows clearly the
occurrence of noncovalent bonding interactions (Figure S50) between the formyl group on
PCA and the viologen pillars in AzaEx2Cage6+.
DFT calculations were also performed to evaluate the free energy change (ΔG), which is
defined as the free energy difference between the complex and the corresponding unbound
guest and host (Figures 8c and 8d), for the formation of (pyrene)2⊂AzaEx2Cage6+ and
14

Page 15 of 26
Chemical Science
View Article Online
DOI: 10.1039/C9SC00591A
(PCA)2⊂AzaEx2Cage6+. The ΔG values for the formation of (pyrene)2⊂AzaEx2Cage6+ and
(PCA)2⊂AzaEx2Cage6+ were calculated to be –3.9 and –7.5 kcal mol-1, respectively. The
more negative ΔG for (PCA)2⊂AzaEx2Cage6+ indicates that its formation is more
thermodynamically favored than that of (pyrene)2⊂AzaEx2Cage6+. These results are
consistent with the observations that the formation of the former complex is enhanced by
dipole–cation or dipole–dipole interactions between the guest carbonyl oxygen atoms, which
bear partially negative charges, and the dicationic BIPY2+ units in the host.
Conclusion
In summary, we have introduced a hexacationic triangular prismatic cage that is composed of
two TPT platforms connected by three BIPY2+ pillar-shaped spacers. Both the platforms and
the pillars play important roles in host-guest recognition. The cage can form 2:1 inclusion
complexes with polycyclic aromatic hydrocarbons, including pyrene and PCA. The latter
guest exhibits remarkably enhanced binding affinities within the cage cavity compared with
those of the former, owing to dipole‒cation and dipole‒dipole interaction between the
carbonyl groups and the laterally pillar-shaped spacers in the host. In addition, because the
three BIPY2+ pillars represent both an efficient π-electron acceptor and hydrogen bonding
donor, one of them can interact with a BH4EN guest, which contains a π-electron-donating
DNP unit and two hydrogen-bond-accepting glycol chains. external complexation occurs in
organic solvents, while inclusion complexation can occur in water. When both PCA and
BH4EN are present, both inclusion and peripheral complexation occur simultaneously, even
though accommodation of the former guests seems to suppress the external binding of the
latter.
15

Chemical Science
Page 16 of 26
View Article Online
DOI: 10.1039/C9SC00591A
These findings improve our fundamental understanding of the relationship between the
electrostatic properties of the building blocks of supramolecular systems and their host-guest
recognition properties. Specifically, laterally charged moieties within host molecules could
supply effective intermolecular interaction to drive the inclusion and peripheral
complexations. Furthermore, this work will inform the development of a design principle for
more complex cage molecules that can bind guests in multiple modes and sites.
ASSOCIATED CONTENT
Supporting Information
The Supporting Information is available free of charge on the ACS Publications website.
AUTHOR INFORMATION
Corresponding Author
*lihao2015@zju.edu.cn
*stoddart@northwestern.edu
ACKNOWLEDGMENT
This work was supported by the Chinese “Thousand Youth Talents Plan”, the National
Natural Science Foundation of China (No. 21772173), the Natural Science Foundation of
Zhejiang Province (No. LR18B020001). H.L. and T.J. also wish to express their appreciation
for the financial support from Zhejiang University. Z.L. thanks Westlake University for the
startup funds. J.F.S. expresses appreciation to King Abdulaziz City for Science and
Technology (KACST) and Northwestern University (NU) for support of this work. We thank
Prof. Xin Hong (Department of Chemistry, Zhejiang University) for his help with the
computational resources used in this investigation.
16

Page 17 of 26
Chemical Science
View Article Online
DOI: 10.1039/C9SC00591A
REFERENCES
(1) A. Ikeda and S. Shinkai, Chem. Rev., 1997, 97, 1713–1734.
(2) W. Maes and W. Dehaen, Chem. Soc. Rev., 2008, 37, 2393–2402.
(3) P. Timmerman, W. Verboom and D. N. Reinhoudt, Tetrahedron, 1996, 52, 2663–2704.
(4) T. Ogoshi, S. Kanai, S. Fujinami, T. A. Yamagishi and Y. Nakamoto, J. Am. Chem. Soc., 2008, 130,
5022–5023.
(5) P. A. Gale, P. Anzenbacher and J. L. Sessler, Coord. Chem. Rev., 2001, 222, 57–102.
(6) (a) F. Diederich, Angew. Chem., Int. Ed. Engl., 1988, 27, 362–386. (b) M. Buhner, W. Geuder, W. K. Gries,
S. Hunig, M. Koch and T. Poll, Angew. Chem., Int. Ed. Engl., 1988, 27, 1553–1556.
(7) (a) B. Odell, M. V. Reddington, A. M. Z. Slawin, N. Spencer, J. F. Stoddart and D. J. Williams, Angew.
Chem., Int. Ed. Engl., 1988, 27, 1547–1550. (b) P. R. Ashton, B. Odell, M. V. Reddington, A. M. Z. Slawin, J. F.
Stoddart and D. J. Williams, Angew. Chem., Int. Ed. Engl., 1988, 27, 1550–1553.
(8) (a) M. Asakawa, P. R. Ashton, S. Menzer, F. M. Raymo, J. F. Stoddart, A. J. P. White and D. J. Williams,
Chem.-Eur. J., 1996, 2, 877–893. (b) P. R. Ashton, S. E. Boyd, A. Brindle, S. J. Langford, S. Menzer, L.
Perez-Garcia, J. A. Preece, F. M. Raymo, N. Spencer, J. F. Stoddart, A. J. P. White and D. J. Williams, New. J.
Chem., 1999, 23, 587–602. (c) H. Y. Gong, B. M. Rambo, E. Karnas, V. M. Lynch and J. L. Sessler, Nat. Chem.,
2010, 2, 406–409. (d) E. J. Dale, N. A. Vermeulen, M. Juríček, J. C. Barnes, R. M. Young, M. R. Wasielewski
and J. F. Stoddart, Acc. Chem. Res., 2016, 49, 262–273. (e) E. J. Dale, D. P. Ferris, N. A. Vermeulen, J. J.
Henkelis, I. Popovs, M. Juríček, J. C. Barnes, S. T. Schneebeli and J. F. Stoddart, J. Am. Chem. Soc., 2016, 138,
3667–3670. (f) X. Gong, R. M. Young, K. J. Hartlieb, C. Miller, Y. Wu, H. Xiao, P. Li, N. Hafezi, J. Zhou, L.
Ma, T. Cheng, W. A. Goddard, III, O. K. Farha, J. T. Hupp, M. R. Wasielewski and J. F. Stoddart, J. Am. Chem.
Soc., 2017, 139, 4107–4116. (g) I. Roy, S. Bobbala, J. Zhou, M. T. Nguyen, S. K. M. Nalluri, Y. Wu, D. P.
Ferris, E. A. Scott, M. R. Wasielewski and J. F. Stoddart, J. Am. Chem. Soc., 2018, 140, 7206–7212. (h) Y. Shi,
K. Cai, H. Xiao, Z. C. Liu, J. W. Zhou, D. K. Shen, Y. Y. Qiu, Q. H. Guo, C. Stern, M. R. Wasielewski, F.
Diederich, W. A. Goddard, III and J. F. Stoddart, J. Am. Chem. Soc., 2018, 140, 13835–13842.
(9) (a) C. A. Hunter and J. K. M. Sanders, J. Am. Chem. Soc., 1990, 112, 5525–5534. (b) L. M. Salonen, M.
Ellermann and F. Diederich, Angew. Chem., Int. Ed., 2011, 50, 4808–4842.
(10) (a) Molecular Switches (Ed.: B. L. Feringa), Wiley-VCH, Weinheim, 2001. (b) M. A. Olson, Y. Y. Botros
and J. F. Stoddart, Pure Appl. Chem, 2010, 82, 1569–1574. (c) R. Klajn, J. F. Stoddart and B. A. Grzybowski,
Chem. Soc. Rev., 2010, 39, 2203–2237. (d) Y. R. Hua and A. H. Flood, J. Am. Chem. Soc., 2010, 132,
12838–12840. (e) A. I. Share, K. Parimal and A. H. Flood, J. Am. Chem. Soc., 2010, 132, 1665–1675.
(11) (a) B. L. Feringa, R. A. van Delden, N. Koumura and E. M. Geertsema, Chem. Rev., 2000, 100,
1789–1816. (b) R. Ballardini, V. Balzani, A. Credi, M. T. Gandolfi and M. Venturi, Acc. Chem. Res., 2001, 34,
445–455. (c) A. Harada, Acc. Chem. Res., 2001, 34, 456–464. (d) C. A. Schalley, K. Beizai and F. Vögtle, Acc.
Chem. Res., 2001, 34, 465–476. (e) J. P. Collin, C. Dietrich-Buchecker, P. Gavina, M. C. Jimenez-Molero and
J.-P. Sauvage, Acc. Chem. Res., 2001, 34, 477–487. (f) V. Balzani, A. Credi and M. Venturi, Molecular Devices
and Machines: a Journey into the Nanoworld, 2nd ed., Wiley-VCH, Weinheim, 2006. (g) E. R. Kay, D. A. Leigh
and F. Zerbetto, Angew. Chem., Int. Ed., 2007, 46, 72–191. (h) J. F. Stoddart, Nat. Chem., 2009, 1, 14–15. (i) M.
M. Boyle, R. A. Smaldone, A. C. Whalley, M. W. Ambrogio, Y. Y. Botros and J. F. Stoddart, Chem. Sci., 2011,
2, 204–210. (j). C. Y. Cheng, P. R. McGonigal, S. T. Schneebeli, H. Li, N. A. Vermeulen, C. F. Ke and J. F.
Stoddart, Nat. Nanotechnol., 2015, 10, 547–553.
(12) (a) D. H. Qu, Q. C. Wang and H. Tian, Angew. Chem., Int. Ed., 2005, 44, 5296–5299. (b) H. Zheng, W.
Zhou, J. Lv, X. Yin, Y. Li, H. Liu and Y. Li, Chem.-Eur. J., 2009, 15, 13253–13262. (c) Q. Jiang, H. Y. Zhang,
17

Chemical Science
Page 18 of 26
M. Han, Z. J. Ding and Y. Liu, Org. Lett., 2010, 12, 1728–1731. (d). C. Romuald, E. Busseron and F. CoutrVoietw,AJr.ticle Online
DOI: 10.1039/C9SC00591A
Org. Chem., 2010, 75, 6516–6531.
(13) (a) A. Livoreil, C. O. Dietrichbuchecker and J.-P. Sauvage, J. Am. Chem. Soc., 1994, 116, 9399–9400. (b)
M. Asakawa, P. R. Ashton, V. Balzani, A. Credi, C. Hamers, G. Mattersteig, M. Montalti, A. N. Shipway, N.
Spencer, J. F. Stoddart, M. S. Tolley, M. Venturi, A. J. P. White and D. J. Williams, Angew. Chem., Int. Ed.,
1998, 37, 333–337. (c) D. Cao, M. Amelia, L. M. Klivansky, G. Koshkakaryan, S. I. Khan, M. Semeraro, S.
Silvi, M. Venturi, A. Credi and Y. Liu, J. Am. Chem. Soc., 2010, 132, 1110–1122. (d) J. C. Barnes, A. C.
Fahrenbach, D. Cao, S. M. Dyar, M. Frasconi, M. A. Giesener, D. Benítez, E. Tkatchouk, O. Chernyashevskyy,
W. H. Shin, H. Li, S. Sampath, C. L. Stern, A. A. Sarjeant, K. J. Hartlieb, Z. C. Liu, R. Carmieli, Y. Y. Botros, J.
W. Choi, A. M. Z. Slawin, J. B. Ketterson, M. R. Wasielewski, W. A. Goddard III and J. F. Stoddart, Science,
2013, 339, 429–433.
(14) E. J. Dale, N. A. Vermeulen, A. A. Thomas, J. C. Barnes, M. Juríček, A. K. Blackburn, N. L. Strutt, A. A.
Sarjeant, C. L. Stern, S. E. Denmark and J. F. Stoddart, J. Am. Chem. Soc., 2014, 136, 10669–10682.
(15) (a) M. Juríček, N. L. Strutt, J. C. Barnes, A. M. Butterfield, E. J. Dale, K. K. Baldridge, F. Stoddart and J.
S. Siegel, Nat. Chem., 2014, 6, 222–228. (b) B. M. Schmidt, T. Osuga, T. Sawada, M. Hoshino and M. Fujita,
Angew. Chem., Int. Ed., 2016, 55, 1561–1564.
(16) (a) P. R. Ashton, C. L. Brown, E. J. T. Chrystal, T. T. Goodnow, A. E. Kaifer, K. P. Parry, D. Philp, A. M.
Z. Slawin, N. Spencer, J. F. Stoddart and D. J. Williams, J. Chem. Soc., Chem. Comm., 1991, 634–639. (b) M. V.
Reddington, A. M. Z. Slawin, N. Spencer, J. F. Stoddart, C. Vicent and D. J. Williams, J. Chem. Soc., Chem.
Comm., 1991, 630–634.
(17) (a) B. E. Tiedemann and K. N. Raymond, Angew. Chem., Int. Ed., 2005, 45, 83–86. (b) C. Sgarlata, J. S.
Mugridge, M. D. Pluth, B. E. Tiedemann, V. Zito, G. Arena and K. N. Raymond, J. Am. Chem. Soc., 2010, 132,
1005–1009. (c) T. Sawada and M. Fujita, J. Am. Chem. Soc., 2010, 132, 7194–7201. (d) W. J. Ramsay and J. R.
Nitschke, J. Am. Chem. Soc., 2014, 136, 7038–7043. (e) F. J. Rizzuto, W. Y. Wu, T. K. Ronson and J. R.
Nitschke, Angew. Chem., Int. Ed., 2016, 55, 7958–7962. (f) D. Preston, J. E. Lewis and J. D. Crowley, J. Am.
Chem. Soc., 2017, 139, 2379–2386. (g) X. Bai, C. Jia, Y. Zhao, D. Yang, S. C. Wang, A. Li, Y. T. Chan, Y. Y.
Wang, X. J. Yang and B. Wu, Angew. Chem., Int. Ed., 2018, 57, 1851–1855.
(18) J. Samanta and R. Natarajan, Org. Lett., 2016, 18, 3394–3397.
(19) (a) M. Yoshizawa, J. Nakagawa, K. Kumazawa, M. Nagao, M. Kawano, T. Ozeki and M. Fujita, Angew.
Chem., Int. Ed., 2005, 44, 1810–1813. (b) M. M. Zhang, M. L. Saha, M. Wang, Z. X. Zhou, B. Song, C. J. Lu,
X. Z. Yan, X. P. Li, F. H. Huang, S. C. Yin and P. J. Stang, J. Am. Chem. Soc., 2017, 139, 5067–5074.
(20) A. Trabolsi, N. Khashab, A. C. Fahrenbach, D. C. Friedman, M. T. Colvin, K. K. Coti, D. Benítez, E.
Tkatchouk, J. C. Olsen, M. E. Belowich, R. Carmielli, H. A. Khatib, W. A. Goddard, III, M. R. Wasielewski
and J. F. Stoddart, Nat. Chem., 2010, 2, 42–49.
(21) N. Hafezi, J. M. Holcroft, K. J. Hartlieb, E. J. Dale, N. A. Vermeulen, C. L. Stern, A. A. Sarjeant and J. F.
Stoddart, Angew. Chem., Int. Ed., 2015, 54, 456–461.
(22) (a) Y. Zhao and D. G. Truhlar, Acc. Chem. Res., 2008, 41, 157–167. (b) Y. Zhao and D. G. Truhlar, Theor.
Chem. Acc., 2008, 120, 215–241.
(23) W. J. Hehre, L. Radom, P. v. R. Schleyer, J. A. Pople, Ab Initio Molecular Orbital Theory; Wiley: New
York, 1986.
(24) A. V. Marenich, C. J. Cramer and D. G. Truhlar, J. Phys. Chem. B, 2009, 113, 6378–6396.
(25) A. E. Reed, R. B. Weinstock, F. Weinhold, J. Chem. Phys. 1985, 83, 735–746.
(26) E. R. Johnson, S. Keinan, P. Mori-Sanchez, J. Contreras-Garcia, A. J. Cohen and W. T. Yang, J. Am.
Chem. Soc., 2010, 132, 6498–6506.
18

Page 19 of 26
Chemical Science
View Article Online
DOI: 10.1039/C9SC00591A
Captions to Scheme and Figures
Scheme 1. Synthesis of AzaEx2Cage•6PF6 from TBT.
Figure 1. a) Schematic representation of the ability of AzaEx2Cage6+ to recognize a variety
of guests, including pyrene, PCA, and BH4EN. In the cases of pyrene and PCA, 2:1
complexes are formed, even though the ability of the cage to host the former guest is much
weaker. In the case of BH4EN, the complex BH4EN•AzaEx2Cage6+ forms in a peripheral
and inclusion manner in CD3CN and D2O, respectively. 1H NMR Spectra of
AzaEx2Cage·6PF6 (500 MHz, 1.0 mM in CD3CN, 298 K) (b) before and after adding (c)
pyrene (8.4 equiv), (d) PCA (10.8 equiv), and (e) BH4EN (11.4 equiv). The resonances of
the protons in AzaEx2Cage6+ are labeled in the corresponding spectra. Addition of pyrene
and PCA results in upfield shifts of the resonances of the phenylene residues (Hc and Hd) in
AzaEx2Cage6+, while the presence of BH4EN leads to upfield shifting of the resonances for
the protons on BIPY2+ (Ha and Hb).
Figure 2. Solid-state (super)structures of AzaEx2Cage•6CF3CO2 obtained by single-crystal
–
X-ray crystallography. a) Stick representation of AzaEx2Cage•6CF3CO2, CF3CO2
counterions are omitted for the sake of clarity. b) and c) Side-on views of the packing
structure revealing that π–π and hydrogen bonding interactions play important roles in the
−
crystal packing. The close contacts in the range of 2.22−2.46 Å between CF3CO2
counteranions and the protons in the cage indicate the occurrence of hydrogen bonding
interactions, which are labeled with dashed lines. Hydrogen atoms and disordered solvent
molecules are omitted for the sake of clarity. C, gray; N, blue; F, green; O, red.
Figure 3. a) Schematic representation of the ability of AzaEx2Cage6+ to accommodate two
PCA guests, in which the corresponding binding constants K1 and K2 determined by 1H NMR
1
spectroscopy in CD3CN at room temperature are shown. b) Stacked H NMR spectra of
AzaEx2Cage•6PF6 in CD3CN upon addition of 0 to 45.6 equiv of PCA relative to
AzaEx2Cage6+. c) Plot of the downfield resonance shifts of Hb protons in AzaEx2Cage6+ (Δδ)
versus the amount of PCA guest added relative to AzaEx2Cage6+. [AzaEx2Cage•6PF6] =
0.904 mM for all spectra. d) 2D DOSY spectrum of the (PCA)2⊂AzaEx2Cage6+ recorded in
D2O.
Figure 4. a) Side-on stick diagrams view of the crystal structures of (PCA)2⊂AzaEx2Cage6+
forms with different chirality including a) R (blue) and b) S (red). The axial chirality of the
complex results from the different relative rotation directions of the carbonyl groups in the
two PCA guests within the cage cavity. The interplane distances between the platforms in the
19

Chemical Science
Page 20 of 26
View Article Online
host and the two guests are 3.42, 3.46, and 3.46 Å, indicating the occurrence of π–π stacking
DOI: 10.1039/C9SC00591A
interactions. c) Top view of the X-ray crystal structure of (PCA)2⊂AzaEx2Cage6+. The
distances between the two carbonyl oxygen atoms and the corresponding BIPY2+ pillars are
2.78 and 3.01 Å, respectively, indicating the occurrence of dipole–cation or dipole–dipole
interactions. d) Side-on stick diagram view overlaid with a space-filling representation of the
crystal structure of (PCA)2⊂AzaEx2Cage6+. e) Side view of the crystal lattice of
(PCA)2⊂AzaEx2Cage•6PF6 showing that complexes of different chirality undergo stacking
–
with each other, making the crystal lattice a racemic mixture. PF6 counterions are omitted for
the sake of clarity.
Figure 5. a) Side view of the crystal structure of the complex BH4EN•AzaEx2Cage•6PF6 in
the form of a stick diagram. b) Top view of the complex BH4EN•AzaEx2Cage•6PF6,
showing that each BH4EN molecule interacts with two BIPY2+ pillars in two adjacent cages.
−
PF6 counterions are omitted for the sake of clarity.
1
Figure 6. H–1H NOESY spectrum of a 1:6 mixture of AzaEx2Cage•6Cl and BH4EN (500
MHz, D2O, 298 K). Through-space proton couplings between the Hc and Hd protons in the
phenylene groups of the cage and the Hy and/or Hz protons in the guests are labeled in the
spectrum, demonstrating that BH4EN•AzaEx2Cage6+ may exist in the form of an inclusion
complex in water.
Figure 7. a) Side view of the crystal structure of the complex
BH4EN•(PCA)2⊂AzaEx2Cage•6PF6 in the form of a stick diagram. b) Top view of the
−
complex BH4EN•(PCA)2⊂AzaEx2Cage•6PF6. PF6 counterions are omitted for the sake of
clarity.
Figure 8. a) Electrostatic potential maps for a) AzaEx2Cage6+ and b)
BH4EN•AzaEx2Cage6+ obtained by using DFT calculations. Light-yellow and deep-blue
colors in the maps represent negative and positive electrostatic potentials, respectively,
demonstrating that the BIPY2+ units represent better π-electron acceptors on account of their
stronger π-electron deficiency. DFT-Optimized structures of c) (PCA)2⊂AzaEx2Cage6+ and
d) (pyrene)2⊂AzaEx2Cage6+. The free energy changes (ΔG) for the formation of
(PCA)2⊂AzaEx2Cage6+ and (pyrene)2⊂AzaEx2Cage6+ complexes are calculated to be −7.5
and −3.9 kcal mol-1, respectively.
20

Page 21 of 26
Chemical Science
View Article Online
DOI: 10.1039/C9SC00591A
Scheme 1
Figure 1

Chemical Science
Page 22 of 26
View Article Online
DOI: 10.1039/C9SC00591A
Figure 2
Figure 3

Page 23 of 26
Chemical Science
View Article Online
DOI: 10.1039/C9SC00591A
Figure 4
Figure 5

Chemical Science
Page 24 of 26
View Article Online
DOI: 10.1039/C9SC00591A
Figure 6

Page 25 of 26
Chemical Science
View Article Online
DOI: 10.1039/C9SC00591A
Figure 7
Figure 8

Chemical Science
Page 26 of 26
View Article Online
DOI: 10.1039/C9SC00591A
Guest recognition enhanced by lateral interactions
Tianyu Jiao,1,2 Kang Cai,2 Zhichang Liu,3 Guangcheng Wu,1 Libo Shen,1
Chuyang Cheng,2 Yuanning Feng,2
Charlotte L. Stern,2 J. Fraser Stoddart*,2,4,5 and Hao Li*,1
1
2
Department of Chemistry, Zhejiang University, Hangzhou 310027, P. R. China
Department of Chemistry, Northwestern University, 2145 Sheridan Road, Evanston, Illinois 60208,
USA
3
School of Science, Westlake University, 18 Shilongshan Road, Hangzhou 310024, P. R. China
4
5
Institute for Molecular Design and Synthesis, Tianjin University, Tianjin 300072, P. R. China
School of Chemistry, University of New South Wales, Sydney, NSW 2052, Australia
Lateral interactions enhance the guest inclusion and peripheral complexation
within a highly charged covalent cage.
