Bull. Chem. Soc. Ethiop. 2015, 29(2), 239-245.
Printed in Ethiopia
DOI: http://dx.doi.org/10.4314/bcse.v29i2.7
ISSN 1011-3924
 2015 Chemical Society of Ethiopia
INVESTIGATION OF WASTE BANANA PEELS AND RADISH LEAVES FOR THEIR
BIOFUELS POTENTIAL
*
Abdul Majeed Khan , Shaista Khaliq and Rabia Sadiq
Department of Chemistry, Federal Urdu University, Gulshan-e-Iqbal Campus,
University Road, Karachi-75300, Pakistan
(
Received October 17, 2013; revised January 27, 2015)
ABSTRACT. This article is mainly based on the production of biodiesel and bioethanol from waste banana
peels and radish leaves. The oily content from both the samples were converted to biodiesel by acid catalyzed and
base catalyzed transesterification using methanol and ethanol. The biodiesel so obtained was subjected to analysis
in accordance with the American Standard for Testing Materials (ASTM). The carbohydrates were extracted by
distilled water and characterized by physical, chemical and biochemical methods. The carbohydrates were
subjected to anaerobic fermentation using Saccharomyces cerevisiae to produce bioethanol which was confirmed
by the preparation of UV active derivatives namely ethyl benzoate and ethyl salicylate. The highest % yield of
fatty acid methyl ester and fatty acid ethyl ester was found to be 75% and 38%, respectively. The yield of
bioethanol from banana peels and radish leaves was found to be 1.37% and 1.23%, respectively.
KEY WORDS: Oil, Transesterification, Biodiesel, Carbohydrates, Fermentation, Saccharomyces cerevisiae,
Bioethanol
INTRODUCTION
Previously, the biodiesel and bioethanol are reported from different bioresources including
wheat, maize, sugar beet, potatoes, palm tree, sun flower, fruits and vegetable wastes, and algae
[
1-4]. The biodiesel is obtained from bioresources that are rich in oily content. The oils are
converted to biodiesel by transesterification particularly with methanol or ethanol. Biodiesel and
bioethanol are carbon neutral fuels because their renewable sources have an ability to absorb the
CO
the CO
2
emitted by the combustion of these fuels. Therefore, there is no any significant increase in
concentration in the atmosphere. Bioethanol can be obtained from biological resources
2
that contain substantial amount of carbohydrates which can be converted to bioethanol [5, 6].
The industrial and research applications has gradually increased the production of bioethanol
[
7]. The bioethanol emit lesser amount of toxic and greenhouse gases as compare to petroleum
or gasoline. It can be used alone or mixing with gasoline [8].
We report here the production of biofuels from banana peels and radish leaves. The
production of biofuels from vegetable oil and other edible resources is not feasible because it
can cause food shortage. Therefore, the conversion of waste to energy is a best approach to save
the edible resources. In addition, the consumption of waste for energy also reduces the
environmental pollution. These features attracted us to use waste banana peels and radish leaves
for the production of biofuels. Banana (Musa paradisiacal) is a fruit which belongs to the
Musacease family. Its outer covering is known as peels and inner part is known as pulp.
The waste banana peels play a significant role to pollute our environment because all the
biowastes release toxic gases when they undergo decomposition and biodegradation. To
overcome this problem, the best alternate use of banana peels is to consume it for the production
of biofuels [9]. Banana peels contain carbohydrates (59.5%), proteins (4.77%), metals and oily
contents [10-12]. Production of bioethanol has previously been reported from the banana peels
by the process of fermentation in biocontrol fermenter using five different strains of
Saccharomyces cerevisiae [13].
_
*
_________
Corresponding author. E-mail: dr.abdulmajeedkhan@fuuast.edu.pk

240
Abdul Majeed Khan et al.
The botanical name of radish leaves is Raphanus sativus and belongs to the family
Brassicaceae [14]. Raphanus sativus grows in temperate climates at height between 190 and
240 m and it is 30–90 cm tall [15]. It is the rich source of carbohydrates, sugar, dietary fiber,
1
fats, proteins, vitamins, and some metals [16]. Radish leaves has also been used for the
o
production of biogas at a specific temperature of 37 C [17]. The literature showed that the
production of biodiesel is also reported from radish [14].
EXPERIMENTAL
Biodiesel production
Banana peels (6.4 kg) were collected from different fruit shops located in Karachi, Pakistan.
They were dried under shadow for one week and dried peels were ground into the powder form
(
855 g). The water content in banana peels was found to be 87%. The oily content from the
banana peels was extracted by solvent extraction technique [18, 19]. The peel’s powder was
soaked in n-hexane (2 L) for three days. The n-hexane extract was separated by decantation and
further by filtration. The soaking process was repeated three times using overall 5 L of n-
hexane. The n-hexane was evaporated on a rotary evaporator (Buchi, Germany) under reduced
pressure that yielded 71 g of crude, dark green and gummy oily content. About 8.3% oily
content was extracted from banana peels using n-hexane as a solvent. Initially, the oily content
was subjected to depigmentation with charcoal and column chromatography using silica gel
(
100-200 mesh size) as stationary phase and n-hexane as mobile phase. Through this process,
most of the pigments and solid impurities have been removed from the crude oily extract. The
oil was again purified by column chromatography using the column of longer length (diameter:
2
.5 cm; length: 50 cm) that also removed the other impurities. It yielded semi-pure dark yellow
oil (68 g) that was then analyzed by thin layer chromatography (TLC).
Radish leaves (3.13 kg) were collected from the vegetable shops, dried under shadow and
then converted into the powder form (0.95 kg). The powder was soaked in n-hexane (5 L) for
three days. The n-hexane extract was separated by decantation and further by filtration. The
soaking process was repeated three times using overall 15 L of n-hexane. The n-hexane was
evaporated by rotary evaporator (Buchi, Germany) under reduced pressure that yielded 58 g
gummy oily content. The oily content was passed through the process of charcoaling then other
impurities were removed by column chromatography that yielded pure oil (56 g).
Characterization of oily contents
The oily contents so obtained from banana peels and radish leaves were characterized in
accordance with the ASTM standards including pour point, cloud point, acid value, iodine
value, saponification value, density, viscosity, and rancidity (Table 1).
Methanolysis and ethanolysis
The oily contents (1 g from each source) were subjected to transesterification under acidic
(
conc. HCl, 5 drops) as well as basic (0.2 g NaOH powder) conditions using methanol (4 mL)
and ethanol (4 mL) separately. The reaction mixtures were refluxed for 12 hours. The glycerol
and soap were separated by hot water whereas the biodiesel was extracted by using n-
hexane:chloroform (1:1). The biodiesel was purified by column chromatography using silica gel
(
100-200 mesh size) as stationary phase whereas n-hexane:chloroform (9:1) as mobile phase.
The purified biodiesel (88%) was characterized by ASTM standards (Table 1).
Bull. Chem. Soc. Ethiop. 2015, 29(2)

Investigation of waste banana peels and radish leaves for their biofuels potential
241
Bioethanol production
After the extraction of oily contents, the residue (784 g) of banana peels powder was soaked in
distilled water (4.5 L) for three days. The water extract that contained carbohydrates was
separated by filtration. The same process of soaking was repeated three times that yielded 11 L
o
of water extract. It was evaporated on the water bath at 100 C that yielded gummy and blackish
water extract (122 g) that contained carbohydrates (Scheme 1).
The residue of radish leaves was soaked in distilled water (15.5 L) for a week. The water
extract was separated by using cotton cloth then it was subjected to filtration using Watmann
filter paper and the soaking process was repeated three times. After complete extraction process,
o
1
5.25 L water extract was obtained. The water was evaporated on water bath at 100 C that
resulted in the gummy and dark green concentrated water extract (180 g).
The concentrated water extracts of each sample (20 g each) were again dissolved in distilled
water (440 mL) and subjected to column filled with activated charcoal and washed with distilled
water. Through this process the unwanted solid impurities and some pigments were removed
that resulted in the semi-refined water extract. After pretreatment, the water extracts of both the
samples were subjected to biochemical analysis by performing different reported tests including
Molisch Test, Fehling’s Solution Test and Combur Test [20, 21].
Fermentation
After pretreatment and biochemical analysis of water extracts, they were subjected to partial
anaerobic fermentation. Firstly, crude gummy water extract (20 g each) was dissolved in
distilled water (440 mL). The pH of water extract of banana peels and radish leaves were found
to be 6.9 and 6.0, respectively. Now, partial anaerobic fermentation of water extract that
contained carbohydrates was conducted inside the earth’s surface (2 feet deep). After
fermentation, the pH of the fermented mixture of banana peels and radish leaves was found to
be 6.1 and 5.6, respectively. The color of the solution was changed from dark green to the light
green for both samples.
Confirmation of bioethanol
The bioethanol is a volatile liquid and it is quite difficult to characterize in its volatile liquid
form at laboratory scale, therefore, the bioethanol obtained from banana peels was directly
converted into its UV active and non-volatile derivative namely ethyl benzoate whereas the
bioethanol from radish leaves converted into ethyl salicylate. For this purpose, fermented
mixture (440 mL) containing bioethanol, benzoic acid (1 g) or salicylic acid (1 g) and conc. HCl
(
0.2 mL for each) were taken in an Erlenmeyer flask and fitted with the water condenser using
chiller (Buchi, Germany) separately. The reaction assemblies were placed in the water bath and
o
refluxed at 100 C for 12 hours. The product mixtures were allowed to cool down at room
temperature. The desired products ethyl benzoate and ethyl salicylate were extracted from the
crude mixture by using n-hexane:ethyl acetate (100 mL:100 mL). The content of the flask was
thoroughly mixed and then allowed to settle down for the separation of the layers. The water
layer (lower) and organic solvent layer (upper) were separated by separating funnel, and process
of extraction was repeated three times. The water layer was discarded and the organic solvent
layers were concentrated using rotary evaporator. The concentrated ethyl benzoate (59.3%) and
ethyl salicylate (62.5%) were examined by thin layer chromatography (TLC) using standard
ethyl benzoate and ethyl salicylate prepared by the same procedure using known starting
materials. n-Hexane was used as the solvent system for TLC. The spots were identified by UV
lamp at 254 nm. The spots of the sample ethyl benzoate and standard were appeared at the same
R
R
f
value (0.76) whereas the spots of sample ethyl salicylate and standard were appeared at 0.74
value.
f
Bull. Chem. Soc. Ethiop. 2015, 29(2)

242
Abdul Majeed Khan et al.
Scheme 1. Production of biodiesel and bioethanol from banana peels and radish leaves.
RESULTS AND DISCUSSION
Biodiesel
The global threats like energy crisis, global warming, pollution and biodiversity stimulated us to
conduct the research on the alternative, green and environmental friendly biofuels that can
overcome the current challenges. In this regards we conducted the research on biowastes
including banana peels and radish leaves. The oily contents of both the wastes were
characterized by ASTM standards and then subjected to methanolysis and ethanolysis under
acidic and basic conditions. The oily contents extracted from banana peels and radish leaves
were found to be 8.3% and 5.4%, respectively. Two types of biodiesels namely fatty acid methyl
ester (FAME) and fatty acid ethyl ester (FAEE) which were synthesized under acidic as well as
basic conditions were characterized by different tests that are necessary for the identification of
biodiesel. These tests include TLC examination, acid values, saponification values, iodine
values, cloud point, pour point and some others (Table 1). The results of various tests were
found to be very close to the ASTM standard values that confirm the presence of biodiesel. The
yield of FAME and FAEE was found to be 75% and 37% from banana peels under acidic
condition whereas it was found to be 63% and 49% under basic condition respectively. On the
other hand, their % yield from radish leaves was found to be 63% and 44% under acidic
condition whereas under basic condition it was found to be 45% and 38%, respectively (Table
2
). When triglycerides reacted with alcohol under acidic condition then biodiesel and glycerol
are formed (Scheme 2) whereas under basic condition biodiesel, glycerol and soap are formed
Scheme 3).
(
Bull. Chem. Soc. Ethiop. 2015, 29(2)

Investigation of waste banana peels and radish leaves for their biofuels potential
243
OCOR
+
OH
OH
OH
ROH, H
+
OCOR
OCOR
RCOOR
Biodiesel
Triglyceride
Glycerol
Scheme 2. Conversion of triglyceride to biodiesel and glycerol.
OCOR
OH
ROH, NaOH
RCOOR
Biodiesel
+
OH
OH
+
RCOONa
Soap
OCOR
OCOR
Triglyceride
Glycerol
Scheme 3. Conversion of triglyceride to biodiesel, glycerol and soap.
Table 1. The detailed characterization of biodiesel derived from banana peels and radish leaves.
*
**
†
S.No. Parameters
Oil
0.38
1.58
95
26.0
0.09
35.5
1.41448
Negative
9
FAME
0.56
0.14
67
2.65
0.04
3.4
FAEE
0.48
0.29
65
4.23
0.01
5.2
ASTM standards
1
2
3
4
5
6
7
8
9
1
1
1
.
.
.
.
.
.
.
.
.
TLC (R
Acid values (mg/g)
Saponification values (g)
Iodine values (g/100 g)
Moisture content (%)
Viscosity (mm /s)
Refractive index (ratio)
Rancidity (pink color)
f
values, ratio)
-
0.8 mg NaOH/g
-
2
2
1.9 to 6.0 mm /s
1.46560
Negative
11
1.48038
Negative
12
-
o
o
o
Cloud point ( C)
-3 C to 12 C
o o
o
0. Pour point ( C)
1. Specific gravity (ratio)
2. Absorbance and transmittance
5
3
3
-15 C to 16 C
0.9086
0.8934
0.8863
0.875 to 0.9
-
0.422 and 36.4 0.457 and 35.5 0.460 and 35.6
(
at 701 nm)
3
1
1
1
3. Density (g/cm )
4. Solidification rate (s)
5. pH
0.91
55
6.1
0.85
85
5.3
0.88
105
4.5
-
-
-
*
**
†
FAME: Fatty acid methyl ester; FAEE: Fatty acid ethyl ester; [22-24].
Table 2. Yields (%) of biodiesels, glycerol, soap and bioethanol produced from biowastes.
Sources Oil
Acidic
Acidic
Basic methanolysis
Basic ethanolysis
Fermentation
(
%) methanolysis
ethanolysis
FAME Glycerol FAEE Glycerol FAME Glycerol Soap FAEE Glycerol Soap Bioethanol
(
%)
(%)
(%)
(%)
(%)
(%)
(%) (%)
(%)
(%)
(%)
Banana 8.3
peels
75
7
37
4
63
3.5
21.5 49
5.2
20.0
1.37
Radish 5.4
leaves
63
6
43
4.5
45
4.2
23.0 38
3.5
18.5
1.23
Bioethanol
The carbohydrates and other polar compounds of banana peels and radish leaves were extracted
by distilled water. The carbohydrates were further converted to bioethanol fuel by the process of
fermentation. The pre-treated water extracts were subjected to different biochemical tests
including Molisch Test, Fehling’s Solution Test and Combur Test which were found to be
Bull. Chem. Soc. Ethiop. 2015, 29(2)

244
Abdul Majeed Khan et al.
significantly positive. The Combur Test showed 1000 mg/dL of glucose and 500 mg/dL of
proteins. This test showed the pH level slightly acidic (6.9). The result obtained from Molisch
Test and Fehling’s Solution Test evidenced that banana peels and radish leaves contain
carbohydrates.
After preliminary examination and pre-treatment, the water extracts were treated with yeast
(
Saccharomyces cerevisiae) under partial anaerobic conditions. After seven days of the
fermentation process, the pH of the solution was found to be 6.5. It is lower than the pH value
before the fermentation (6.9). It showed that the acidic strength of the fermented solution has
been increased due to the formation of carboxylic acids. The ethanol is a volatile liquid therefore
it is quite difficult to extract it from the product mixture at the laboratory scale experimentation.
To overcome this drawback, the bioethanol obtained from banana peels was converted directly
into its non-volatile and UV active derivative like ethyl benzoate (Scheme 4) whereas the
bioethanol derived from radish leaves was converted into ethyl salicylate (Scheme 5). The
percent yields of ethyl benzoate and ethyl salicylate were found to be 59.3% and 62.5%
respectively. In addition, the % yield of bioethanol from banana peels and radish leaves was
found to be 1.37% and 1.23%, respectively.
COOH
OOCHCH3
C
2
HCl (Conc.)
CH CH OH
+
H2O
+
3
2
n-hexane, o
Reflux (100 C)
Bioethanol
Ethyl benzoate
12 hours
Benzoic acid
1 g)
(59.3 %)
(
Scheme 4. Synthesis of ethyl benzoate from benzoic acid.
O
O
OH
OCH
CH
2 3
Conc. H SO4
2
+
CH CH OH
3 2
o
+
H O
Refluxed (100 C)
12 hours
2
Bioethanol
OH
OH
Ethyl salicylate
Salicylic acid
2
g
1.5 g, 62.5%
Scheme 5. Synthesis of ethyl salicylate from salicylic acid.
CONCLUSION
This article presents the conversion of oily content of banana peels and radish leaves to
biodiesel through transesterification as well as carbohydrates of both the wastes to bioethanol
through fermentation. The biodiesel was characterized by ASTM standards whereas bioethanol
was confirmed by the synthesis of UV active derivatives formation. The transesterification using
methanol and ethanol was carried out under acidic as well as basic conditions that produced
fatty acid methyl ester and fatty acid ethyl ester with a significant yield. The fermentation of
carbohydrates extracted from banana peels and radish leaves produced 1.37% and 1.23%
bioethanol, respectively. This significant research can help us to develop the alternative
approaches for the conversion of wastes to energy that overcome the energy crisis and help to
reduce the environmental pollution.
Bull. Chem. Soc. Ethiop. 2015, 29(2)

Investigation of waste banana peels and radish leaves for their biofuels potential
245
ACKNOWLEDGEMENT
The principal author is greatly thankful to the administration of Federal Urdu University for the
provision of financial support for this research work under “Mini Research Project Program-
2012”.
REFERENCES
1
2
. Khan, A.M. J. Chem. Soc. Pak. 2010, 32, 379.
. Khan, A.M.; Attaullah; Ahmad, I.; Shaheen, A.; Malik, F.; Shahid, H.A. J. Chem. Soc. Pak.
2011, 33, 269.
3
4
5
6
7
8
. Balat, M. Energy Expl. Exploit. 2007, 25, 195.
. Schneider, U.A.; Mccarl, B.A. Environ. Res. Econ. 2003, 24, 291.
. Malça, J.; Freire, F. Energy Sour. 2006, 31, 3362.
. Peskett, L.; Slater, R.; Stevens, C.; Dufey, A. Agric. Pov. Red. 2007, 107, 1.
. Dhabekar, A.; Chandak, A. Asian J. Biotech. Res. 2010, 1, 8.
. Arredondo, V.H.I.; Ruiz, C.A.A.; Colorado, R.A. A.; Junior, O.S. Energy Renew. Anal.
Introd. J. Therm. 2009, 12, 155.
9
1
. Krishna, P.R.; Srivastava, A.K.; Ramawamy, N.K.; Suprsanna, P.; Souza, S.F.D. Ind. J.
Biotech. 2012, 11, 314.
0. Tartrakoon, T.; Chalearmsan, N.; Vearasilp, T.; Meulen, U. The nutritive value of banana
peel (Musa sapieutum L.) in growing pigs, Deutscher Tropentag 1999, Berlin. Proc. Sust.
Technol. Dev. Animal Agric. 1999.
1
1
1. Essien, J.P.; Akpan, E.J.; Essien, E.P. Biores. Technol. 2005, 96, 1451.
2. Shah, A.M.; Qureshi, M.; Memon, Z.N.; Memon, S.N.; Syed, S.K. Sindh Uni. Res. 2012, 44,
71.
1
1
1
1
1
1
3. Manikandan, K.; Saravanan, V.; Viruthagiri, T. Ind. J. Biotech. 2008, 7, 83.
4. Avila, R.N.D.A.; Sodre, J.R. Ind. Crop. Prod. 2012, 38, 54.
5. Gutierrez, R.M.P.; Perez, R.L. Sci. World J. 2004, 4, 811.
6. Khattak, K.F. Pak. J. Pharm. Sci. 2011, 24, 277.
7. Mandal, T.; Mandal, N.K. Energy Cons. Manag. 1997, 38, 679.
8. Topare, N.S.; Raut, S.J.; Renge, V.C.; Khedkar, S.V.; Chavan, Y.P.; Bhagat, S.L. Int. J.
Chem. Sci. 2011, 9, 1746.
19. Ali, M.A.; Saeed, M.A.; Alam, M.S., Yasmin, M.S.; Khan, A.M.; Muhammad, I.I. Bull.
Chem. Soc. Ethiop. 2012, 26, 55.
20. Kalaiarasan, A.; John, S.A. Int. J. Medicobiol. Res. 2010, 1, 94.
21. Khan, A.M.; Ali, M.M.; Naz, S.; Sohail, M. J. Chem. Soc. Pak. 2010, 32, 209.
22. Chopade, S.G.; Kulkarni, K.S.; Kulkarni, A.D.; Topare, N.S., Acta Chim. Pharm. Indica
2012, 2, 8.
2
2
3. Ofoefule, A.U.; Ibeto, C.N.; Ugwuamoke, I.E. Int. Res. J. Pure App. Chem. 2013, 3, 357.
4. AOCS Official Methods and Recommended Practices, Am. Oil. Chem. Soc.: Champaign
USA; 1997.
Bull. Chem. Soc. Ethiop. 2015, 29(2)
