Phase equilibria in the system Tl2Te-SnTe-TlBiTe2

Article abstract of DOI:10.1134/S0020168508100063

The phase equilibria in the system Tl₂Te-SnTe-TiBiTe₂ (A) have been studied using differential thermal analysis, x-ray diffraction, and microhardness measurements. We have constructed the T-x phase diagrams along the SnTe-TlBiTe₂, SnTe-Tl₉BiTe₆, and Tl ₄SnTe₃-TlBiTe₂ joins, the 600-and 800-K sections of the phase diagram of system A, and its liquidus diagram. The results demonstrate that the system contains broad ranges of Tl₅Te ₃-structured and SnTe-based solid solutions (δ and γ₁ phases, respectively). There are also relatively small fields of the Tl₂Te-based phase (α) and low-and high-temperature TlBiTe₂-based solid solutions (γ₂ and γ′₂). The liquidus surface of system A comprises the primary crystallization fields of the δ, γ₁, and γ′₂ phases. The liquidus of the α phase is degenerate. The ternary eutectic between the δ, γ₁, and γ′₂ phases melts at 755 K.

Full text of DOI:10.1134/S0020168508100063

ISSN 0020-1685, Inorganic Materials, 2008, Vol. 44, No. 10, pp. 1060–1065. © Pleiades Publishing, Ltd., 2008.
Original Russian Text ©M.B. Babanly, G.B. Dashdieva, F.N. Guseinov, 2008, published in Neorganicheskie Materialy, 2008, Vol. 44, No. 10, pp. 1187–1192.
*
Phase Equilibria in the System Tl Te–SnTe–TlBiTe2
2
M. B. Babanly, G. B. Dashdieva, and F. N. Guseinov
Baku State University, ul. Khalilova 23, Baku, AZ1148 Azerbaijan
e-mail: babanly_mb@rambler.ru
Received September 14, 2007
Abstract—The phase equilibria in the system Tl Te–SnTe–TlBiTe (A) have been studied using differential
2
2
thermal analysis, x-ray diffraction, and microhardness measurements. We have constructed the T–x phase dia-
grams along the SnTe–TlBiTe , SnTe–Tl BiTe , and Tl SnTe –TlBiTe joins, the 600- and 800-K sections of
2
9
6
4
3
2
the phase diagram of systemA, and its liquidus diagram. The results demonstrate that the system contains broad
ranges of Tl Te -structured and SnTe-based solid solutions (δ and γ phases, respectively). There are also rela-
5
3
1
tively small fields of the Tl Te-based phase (α) and low- and high-temperature TlBiTe -based solid solutions
2
2
(
γ and γ' ). The liquidus surface of system A comprises the primary crystallization fields of the δ, γ , and γ'
2
2
1
2
phases. The liquidus of the α phase is degenerate. The ternary eutectic between the δ, γ , and γ' phases melts
1
2
at 755 K.
DOI: 10.1134/S0020168508100063
I N* TRODUCTION
tions (δ phase), crystallizes in tetragonal symmetry
Tl Te structure, sp. gr. I4/mcm). The lattice parame-
(
5
3
Tellurides of heavy p-metals are thought to be
attractive hosts for the preparation of new thermoelec-
tric materials [1, 2]. In this family of compounds, tin,
bismuth, and thallium tellurides are of considerable
practical importance [1–5]. One way of enhancing the
ters of Tl SnTe are a = 8.82 Å and c = 13.01 Å (Z = 4)
4
3
[
15]. The Tl Te–TlBiTe system contains a compound of
2 2
composition Tl BiTe , which melts congruently at 830 K,
9
6
also has a tetragonal structure of the Tl Te type (a =
5
3
performance of thermoelectric materials is by utilizing 8.855 Å, c = 13.048 Å, Z = 2) [10, 16], and forms a con-
multicomponent compounds with complex structures tinuous series of solid solutions with Tl Te [10].
2
[
2, 6]. The key to the targeted synthesis of new multi-
As shown by Mazelsky and Lubell [17], the SnTe–
component tellurides of the above elements lies in
knowing the phase equilibria in the corresponding sys-
tems.
TlBiTe system contains limited solid solutions based
2
on SnTe (56 mol %) and TlBiTe (21 mol %).
2
This led us to study the phase equilibria in the com-
Dashdieva et al. [18] studied the phase equilibria in
position region Tl Te–SnTe–TlBiTe (A) of the quater- the composition region Tl Te–Tl SnTe –Tl BiTe of
2
2
2
4
3
9
6
nary system Tl–Sn–Bi–Te. The constituent binary tellu- system A. According to their results, the Tl SnTe -
4
3
rides Tl Te and SnTe melt congruently at 698 and 1080 K, Tl BiTe join is pseudobinary, with a continuous series
2
9
6
respectively [1, 7, 8]. Tl Te has a monoclinic structure of Tl Te -structure solid solutions (δ phase). Their lat-
2
5
3
[
9], and SnTe has a primitive cubic unit cell [7]. The ter- tice parameters follow Vegard’s law (a = 8.821–8.854 Å,
nary compound TlBiTe exists in two crystalline poly- c = 13.01–13.05 Å). The δ phase field extends over
2
morphs. At 780 K, the low-temperature, orthorhombic most of the Tl Te–Tl SnTe –Tl BiTe system [18].
2
4
3
9
6
phase transforms into the high-temperature, disordered
phase of variable composition, which melts congru-
ently at 830 K [10–12].
EXPERIMENTAL
The constituent binaries of system A have been
The constituent tellurides of system A were synthe-
sized by melting appropriate high-purity elemental
studied by several groups. The Tl Te–SnTe system was
2
reported to contain a ternary compound of composition
mixtures in silica tubes sealed off under a vacuum of
Tl SnTe , which has a broad homogeneity range
4
3
–2
~
10 Pa, followed by slow cooling. The synthesis tem-
(
[
12−40 mol % SnTe) and melts congruently at 825 K
13, 14]. This compound, as well as related solid solu-
perature was 750 (Tl Te), 1150 (SnTe), or 900 K
2
(
TlBiTe ), that is, slightly above the corresponding
2
*
melting point. The synthesized compounds were iden-
tified by differential thermal analysis (DTA) and x-ray
diffraction (XRD).
Presented in part at the XII Conference High-Purity Substances
and Materials: Preparation, Analysis, and Application, Nizhni
Novgorod, Russia, May 28–31, 2007.
1
060

PHASE EQUILIBRIA IN THE SYSTEM Tl Te–SnTe–TlBiTe
1061
2
2
Alloys of system A were prepared by vacuum-melt-
a, Å
ing telluride mixtures. We prepared SnTe–TlBiTe2,
Tl SnTe -TlBiTe , and SnTe–Tl BiTe alloys and a
6.5
(c)
4
3
2
9
6
number of alloys beyond these joins. Using DTA results
6
6
.4
.3
for a number of unhomogenized alloys and earlier data
[
10, 13, 18], we selected heat-treatment temperatures at
which the alloys were equilibrated for 500 h. The alloys
annealed at 600 K were furnace-cooled, and those
annealed at 800 K were quenched in cold water.
H, åP‡
(
(
b)
a)
1500
1
000
500
The alloys were characterized by DTA (NTR-74
pyrometer, Chromel–Alumel thermocouples), XRD
(
DRON-2 powder diffractometer, CuK radiation), and
α
T, K
microhardness measurements (PMT-3 tester, 0.2-N
indentation load).
1
100
1080
RESULTS AND DISCUSSION
1000
L
The present experimental data and earlier results
[
10, 13, 14, 18] for the constituent binaries and the
2
9
8
00
00
Tl Te–Tl SnTe –TlBi Te system are summarized in
4
3
6
2
L + γ1
Figs. 1–6.
8
7
30
80
The present T–x phase diagram of the SnTe–
e1 γ'2
TlBiTe system (Fig. 1a) differs somewhat from that
2
γ +γ'
1
2
reported by Mazelsky and Lubell [17]. According to
γ1
our results, this system involves both eutectic and
e
1
γ2
eutectoid phase relations. The eutectic (Â ) is located at
700
Sn Te
1
γ1+γ2
ꢀ85 mol % TlBiTe , with a melting point of 815 K.
2
The homogeneity range of the SnTe-based phase (γ1
phase) extends to 80 mol % TlBiTe at 800 K and to
20
40
mol %
60
80 TlBiTe2
2
7
2 mol % TlBiTe at 600 K. The formation of low- and
2
Fig. 1. T–x phase diagram of the SnTe–TlBiTe system (a);
2
high-temperature TlBiTe -based solid solutions (γ -
and γ' phases) is accompanied by a reduction in the
temperature of the polymorphic transformation from
2
2
composition dependences of the microhardness (b) and lat-
tice parameter (c). The crosses in panels b and c represent
samples quenched from 800 K.
2
7
65 to 750 K and a transition to eutectoid phase rela-
tions. The eutectoid point (Â ) is located at ꢀ90 mol %
2
Fig. 2, the 600-K section comprises single- (δ, γ , and
1
TlBiTe and 750 K (Fig. 1a). The width of the homoge-
neity range of the γ' phase is 10 mol % (800 K), and
that of the γ phase is ꢀ5 mol % (600 K).
2
γ ), two-, and three-phase fields. The γ and γ phase
2
1
2
2
fields extend along the constituent binary SnTe–
2
TlBiTe and are 2–3 mol % in width. The δ phase field
2
XRD and microhardness data are consistent with the extends over most of the Tl Te–Tl SnTe –Tl BiTe
2 4 3 9 6
T–x phase diagram of the SnTe–TlBiTe system. Pow- region. In addition, there are two fields (α and ï) near
2
der XRD patterns of the alloys containing 0–70 mol % Tl Te. The alloys in the α field are isostructural with
2
TlBiTe (annealing at 600 K) or 0–80 mol % TlBiTe2 Tl Te. We failed to detect an α + δ two-phase field,
2
2
(
quenching after annealing at 800 K) show only reflec- which leads us to assume that the α
δ phase trans-
tions from an SnTe-based cubic phase, and its lattice formation is morphotropic. In the ï field, the Tl Te–
2
parameter varies almost linearly with composition,
from a = 6.327 (SnTe) to 6.465 Å (80 mol % TlBiTe2)
SnTe–TlBiTe plane is unstable: the equilibrium alloys
2
contain, in addition to the α and δ phases, a Tl-based
(Fig. 1c). The microhardness ç of the γ phase rises
1
metallic phase [18]. This rare effect, also encountered
steadily from ꢀ850 (SnTe) to ꢀ1400 MPa (80 mol %
TlBiTe ), and that of the γ phase rises from ꢀ500
in the constituent system Tl Te–SnTe, was analyzed in
2
2
2
detail elsewhere [13, 14].
(
TlBiTe ) to 600 MPa (95 mol % TlBiTe ). The micro-
2
2
The phase diagram of the SnTe–Tl BiTe system
hardness of the samples quenched from 800 K slightly
9
6
exceeds that of the corresponding samples annealed at (Fig. 3) is similar in appearance to that of a pseudobin-
6
00 K (Fig. 1b).
The XRD, DTA, and microhardness data for the
ary eutectic, but this system is not pseudobinary. The
alloys of this system consist of two phases, γ + δ, but,
1
alloys annealed at 600 K were used to map out the sub- as seen in Fig. 2, the compositions of the equilibrium γ
solidus phase diagram of system A (Fig. 2). As seen in and δ phases lie beyond this join. Comparison of Figs. 3
1
INORGANIC MATERIALS Vol. 44 No. 10 2008

1
062
BABANLY et al.
Tl Te
2
α
X
δ
Tl BiTe
6
8
0
9
Tl SnTe
4
3
6
0
γ2 +δ
4
0
γ1 + δ
2
0
γ1 + γ
2
γ1
γ2
TlBiTe2
SnTe
20
40
60
80
mol % TlBiTe2
Fig. 2. 600-K section of the T–x–y phase diagram of the Tl Te–SnTe–TlBiTe system.
2
2
and 5 demonstrates that the SnTe–Tl BiTe join passes
Because of the very small slope of the Â Ö curve
2
9
6
through primary crystallization fields and intersects the over the SnTe–Tl BiTe join, this eutectic transforma-
9
6
eutectic curve  Ö, representing the univariant equilib- tion occurs in a very narrow temperature range, and is
2
rium
represented by a single, sharp DTA peak. For this rea-
son, the L + γ + δ field in Fig. 3 is marked by a dashed
1
L
γ1+ δ.
(1)
line. Along this join, the homogeneity ranges of the γ1
and δ phases are ꢀ3–4 mol % in width (600 K).
More complex phase relations were found along the
T, K
Tl SnTe -TlBiTe join (Fig. 4), which passes through
4
3
2
1
080
five phase fields below the solidus (Fig. 2). Its liquidus
comprises three branches, corresponding to the primary
crystallization of the δ-, γ -, and γ' phases, which are
1
2
1
000
L
separated by the eutectic curves Â Ö and Â Ö (Fig. 5).
1
2
The 755-K horizontal represents the four-phase equi-
librium
9
8
00
00
LE
γ + γ' + δ,
(2)
1
2
L + γ1
830
65
and the 748-K horizontal represents the eutectoid equi-
librium
γ1
L + δ
7
δ
γ2'
γ + γ + δ.
(3)
1
2
7
00
Below this horizontal, the alloys containing 50–
γ1 + δ
8
7 mol % TlBiTe consist of three phases: γ + γ + δ
2
1
2
(
Fig. 2). In the composition ranges ꢀ7–50 and 80–90
8
mol % TlBiTe , the solidus line represents the univari-
2
2
0
40
60
mol %
80 Tl BiTe
9 6
SnTe
ant eutectic processes (1) and (4), respectively:
Fig. 3. T–x phase diagram of the SnTe–Tl BiTe system.
LE
γ2' + δ.
(4)
9
6
INORGANIC MATERIALS Vol. 44 No. 10 2008

PHASE EQUILIBRIA IN THE SYSTEM Tl Te–SnTe–TlBiTe
1063
2
2
T, K
8
30
8
8
25
00
L + γ + γ'
1
2
L + δ
L + γ'2
γ'2
L + γ1
780
δ
7
7
50
00
L + γ + δ
1
γ + γ' + δ
1
2
γ1 + δ
γ + γ + δ
1
2
γ2
0
.33 Tl SnTe 20
40
60
80
TlBiTe2
4
3
mol %
Fig. 4. T–x phase diagram of the Tl SnTe –TlBiTe system.
4
3
2
Tl Te
2
D (830 K)
8
0
2
D
1
3
(
825 K)
6
0
8
00
e2
780 K)
e3(763 K)
(
(755K)
E
4
0
1
2
0
2
SnTe
20
40
60
80
e
TlBiTe2
1
(
815 K)
mol %
Fig. 5. Liquidus diagram of the Tl Te–SnTe–TlBiTe system. Primary crystallization fields: (1) γ , (2) γ' , (3) δ. The dashed line
2
2
1
2
represents the pseudobinary join Tl SnTe –Tl BiTe .
4
3
9
6
INORGANIC MATERIALS Vol. 44 No. 10 2008

1
064
BABANLY et al.
Tl Te
2
L
L + δ
8
0
Tl BiTe
9 6
δ
Tl SnTe
4
3
L + δ
6
0
L
4
0
2
0
L + γ1
γ'2
SnTe
20
γ1
40
60
80 γ + γ TlBiTe2
1
2
mol %
Fig. 6. 800-K section of the Tl Te–SnTe–TlBiTe phase diagram.
2
2
The homogeneity ranges of the δ and γ phases along
REFERENCES
2
the Tl SnTe -TlBiTe join are no wider than 5 mol %.
4
3
2
1. Shelimova, L.E., Tomashik, V.N., and Grytsiv, V.I., Dia-
grammy sostoyaniya v poluprovodnikovom materia-
lovedenii (Phase Diagrams in Semiconductor Materials
Research), Moscow: Nauka, 1991.
The liquidus surface of system A comprises three
primary crystallization fields, those of the δ-, γ -, and
1
γ' phases (Fig. 5). The eutectic curves e E, e E, and
e1E, separating these fields, represent the univariant
equilibria (1), (4), and
2. Shelimova, L., Karpinskii, O.G., and Zemskov, V.S.,
Promising Thermoelectric Materials Based on Layered
Tetradymite-Like Chalcogenides, Perspekt. Mater.,
2
2
3
2
000, no. 5, pp. 23–32.
3
. Karpinskii, O.G., Shelimova, L.E., Kretova, M.A., et al.,
X-Ray Diffraction Study of Mixed-Layer Compounds in
the Pseudobinary System SnTe–Bi Te , Neorg. Mater.,
L
γ + γ' .
1
2
e1E
2
3
The ternary eutectic point E is located at ꢀ45 mol %
Tl Te and ꢀ10 mol % SnTe.
2003, vol. 39, no. 3, pp. 305–311 [Inorg. Mater. (Engl.
Transl.), vol. 39, no. 3, pp. 240–246].
2
4
. Wolfing, B., Kloc, C., Teubner, J., and Bucher, E., High
The dashed line in Fig. 5 represents the only pseudo-
Performance Thermoelectric Tl BiTe
with an
9
6
binary join (Tl SnTe –Tl BiTe ) in systemA. The liqui-
Extremely Low Thermal Conductivity, Phys. Rev. Lett.,
001, vol. 36, no. 19, pp. 4350–4353.
4
3
9
6
2
dus surface of the Tl Te-based phase (α) is degenerate.
2
5
6
7
. Yamanaka, Sh., Kosuka, A., and Korosaki, K., Thermo-
Figure 6 shows the isothermal section of the phase
diagram of system A inferred from the data for alloys
quenched after 800-K annealing and from the position
of the corresponding isotherms in Fig. 5. From the posi-
tion of tie lines in the two-phase regions L + γ , L + γ' ,
electric Properties of Tl BiTe , J. Alloys Compd., 2003,
9
6
vol. 352, pp. 275–278.
. Ioffe, A.F., Poluprovodnikovye termoelementy (Semi-
conductor Thermoelements), Moscow: Akad. Nauk
SSSR, 1960.
1
2
. Fiziko-khimicheskie svoistva poluprovodnikovykh vesh-
chestv. Spravochnik (Physicochemical Properties of
Semiconductors: A Handbook) Novoselova, A.V. and
Lazarev, V.B., Eds., Moscow: Nauka, 1976.
and L + δ, one can select melt compositions for the
crystal growth of solid solutions of controlled composi-
tion by directional solidification.
INORGANIC MATERIALS Vol. 44 No. 10 2008

PHASE EQUILIBRIA IN THE SYSTEM Tl Te–SnTe–TlBiTe
1065
2
2
8
9
. Asadov, M.M., Babanly, M.B, and Kuliev, A.A., Phase
Equilibria in the Tl–Te System, Izv. Akad. Nauk SSSR,
Neorg. Mater., 1977, vol. 13, no. 8, pp. 1407–1410.
Tl Te−PbTe, Uch. Zap. MV SSO Az. SSR, Ser Khim.
Nauk, 1978, no. 3, pp. 30–32.
2
1
4. Gotuk Ali Alarik, Babanly, M.B., and Kuliev, A.A.,
Phase Equilibria in the System Tl–Sn–Te, Izv. Akad.
Nauk SSSR, Neorg. Mater., 1979, vol. 15, no. 8,
pp. 1356–1361.
. Cerny, R., Joubert, J.M., Filinchik, Y., and Feutelais, Y.,
Tl Te and Its Relationship with Tl Te , Acta Crystal-
2
5
3
logr., Sect. C: Cryst. Struct. Commun., 2002, vol. 58,
no. 5, pp. 163–165.
1
1
1
5. Bradtmöller, S. and Böttcher, P., Darstellung und Kri-
1
1
0. Babanly, M.B., Akhmad’yar, A., and Kuliev, A.A., Sys-
stallstruktur von SnTl Te und PbT Te , Z. Anorg. Allg.
4
3
l4
3
tem Tl Te–Bi Te –Te, Zh. Neorg. Khim., 1985, vol. 30,
Chem., 1993, vol. 619, pp. 1155–1160.
2
2
3
no. 9, pp. 2356–2361.
6. Doert, T. and Böttcher, P., Crystal Structure of Bismuth-
nonathallium Hexatelluride BiTl9Te6, Z. Kristallogr.,
1994, vol. 209, p. 95.
1. Pradel, A., Tedenac, J.C., Brun, G., and Maurin, M.,
Mise au point dans le ternaire Tl–Bi–Te. Existence de
deux phases nonstoechiometriques de type TlBiTe2,
J. Solid State Chem., 1982, vol. 5, no. 1, pp. 99–111.
7. Mazelsky, R. and Lubell, M.S., Solid Solution Study of
Some Post-Transition Metal Tellurides of the Rock Salt
Structural Type, J. Phys. Chem., 1962, vol. 66, no. 8,
pp. 1408–1411.
1
1
2. Voroshilov, Yu.V., Evstigneeva, T.A., and Nekrasov, I.Ya.,
Kristallokhimicheskie tablitsy troinykh khal’-kogenidov
(
Crystal-Chemical Tables for Ternary Chalcogenides),
1
8. Dashdieva, G.B., Guseinov, F.N., and Babanly, M.B.,
Phase Equilibria in the System Tl Te–Tl SnTe –
Moscow: Nauka, 1989.
2
4
3
3. Gotuk Ali Alarik, Babanly, M.B., and Kuliev, A.A.,
Tl BiTe Vestn. Bakinsk. Univ., Ser. Estestv. Nauk, 2007,
9 6,
Phase Equilibria in the Systems Tl Te–SnTe and
no. 1, pp. 38–42.
2
INORGANIC MATERIALS Vol. 44 No. 10 2008
