A nitrogen-doped porous carbon materials (CPNs) with supported Co nanoparticles (Co@CPNs) with lamellar structure, high surface area and excellent magnetic properties was synthesized successfully by one-pot method. The Co@CPNs exhibited an excellent catalytic activity with 99% conversion and selectivity for hydrogenation of furfural (FAL) to furfuryl alcohol (FOL) under the pressure of H₂. In addition, the Co@CPNs were further investigated in the kinetic study and selective hydrogenation of the other α, β unsaturated carbonyl compounds. The study of the Co@CPNs indicated that it was suitable for selective hydrogenation of the α, β unsaturated carbonyl compounds in the industry.

Full text of DOI:10.1016/j.catcom.2018.03.017

Accepted Manuscript
Highly selective hydrogenation of α, β-unsaturated carbonyl
compounds over supported Co nanoparticles
Pengbo Jiang, Xinlin Li, Wenbin Gao, Xiang Wang, Yu Tang, Kai
Lan, Bin Wang, Rong Li
PII:
S1566-7367(18)30109-2
doi:10.1016/j.catcom.2018.03.017
CATCOM 5358
DOI:
Reference:
To appear in:
Catalysis Communications
Received date:
Revised date:
Accepted date:
5 January 2018
10 March 2018
15 March 2018
Please cite this article as: Pengbo Jiang, Xinlin Li, Wenbin Gao, Xiang Wang, Yu Tang,
Kai Lan, Bin Wang, Rong Li , Highly selective hydrogenation of α, β-unsaturated carbonyl
compounds over supported Co nanoparticles. The address for the corresponding author
was captured as affiliation for all authors. Please check if appropriate. Catcom(2018),
doi:10.1016/j.catcom.2018.03.017
This is a PDF file of an unedited manuscript that has been accepted for publication. As
a service to our customers we are providing this early version of the manuscript. The
manuscript will undergo copyediting, typesetting, and review of the resulting proof before
it is published in its final form. Please note that during the production process errors may
be discovered which could affect the content, and all legal disclaimers that apply to the
journal pertain.

ACCEPTED MANUSCRIPT
Highly selective hydrogenation of α, β-unsaturated carbonyl
compounds over supported Co nanoparticles
Pengbo Jiang, Xinlin Li, Wenbin Gao, Xiang Wang, Yu Tang, Kai Lan, Bin Wang and
*
Rong Li
State Key Laboratory of Applied Organic Chemistry (SKLAOC), College of
Chemistry and Chemical Engineering, Lanzhou University, Lanzhou 730000, PR
China. E-mail: liyirong@lzu.edu.cn; Fax: +86-931-891-2582; Tel: +86-18919803060.
=

ACCEPTED MANUSCRIPT
Abstract
A nitrogen-doped porous carbon materials (CPNs) with supported Co nanoparticles
Co@CPNs) with lamellar structure, high surface area and excellent magnetic
(
properties was synthesized successfully by one-pot method. The Co@CPNs exhibited
an excellent catalytic activity with 99% conversion and selectivity for hydrogenation
of furfural (FAL) to furfuryl alcohol (FOL) under the pressure of H . In addition, the
2
Co@CPNs were further investigated in the kinetic study and selective hydrogenation
of the other α, β unsaturated carbonyl compounds. The study of the Co@CPNs
indicated that it was suitable for selective hydrogenation of the α, β unsaturated
carbonyl compounds in the industry.
Keywords: Furfural, Furfuryl alcohol, Kinetic study, Selective hydrogenation,
Liquid phase
=

ACCEPTED MANUSCRIPT
Introduction
Furfuryl alcohol (FOL) is an important intermediate for the production of lysine,
ascorbic, drugs, and various lubricants, which also deserves attention as a potential
platform for biofuels to take place of the fossil fuels [1-3]. The industrial method of
producing FOL is hydrogenation of furfural (FAL), which can be obtained from the
lignocellulosic biomass by catalytic dehydration [4], by the catalysts of copper
chromate [5]. However, many factors including partial size, reaction temperature and
pressure of H influence the activity and selectivity of catalysts [6, 7]. Therefore,
2
accomplishing chemical selectivity is considerably challenging for hydrogenation of
all C=O and C=C unsaturated bonds of furfural, which may respectively lead to
tetrahydrofurfural or tetrahydrofurfuryl alcohol. In addition, the poisonous Cr O is a
2
3
serious contaminant, which promotes the investigators to develop other metals to take
the place of Cr. Recently, abundant of supported bimetallic (Cu-Ni [8], Pd-Fe [9]),
precious metal (Ru [10], and Pd [11]) or metallic oxide (Co O [12]) catalysts were
3
4
reported for the gas phase, liquid phase hydrogenation with H or transfer
2
hydrogenation [13]. Nevertheless, most synthesis methods of the catalysts are
complicated and the use of noble metals can increase the expenditure. Hence, it’s
essential that project and compound of efficient catalysts with high selectivity, activity
and low cost.
Co, a cheap and high activity non-noble metal, has been loaded on SBA-15 [14],
TiO [15] and carbonaceous materials [16], which were studied in selective
2
hydrogenation of FAL. It is found that the Co is low active at low temperature and
=

ACCEPTED MANUSCRIPT
low selective at high temperature. Hence, Co based catalysts with excellent activity
and selectivity are still necessary. And the Nitrogen-doped carbon materials have
advantages of high surface area, facile and have involved broad investigation as
catalysts carriers during the past several years.
In this work, Co nanoparticles were supported on nitrogen-doped porous carbon
materials (CPNs) by one-pot method, and characterized by X-ray diffraction (XRD),
Scanning electron microscopy (SEM), transmission electron microscopy (TEM) etc.
This study affords the encouraging potential application of Co@CPNs catalysts in the
selective hydrogenation reactions. Compared with noble metal catalysts, such as
Au/Al O [17], Pt/MgO [18], Co@CPNs possesses non-poisonous peculiarity, simple
2
3
synthesis method and low price. Co/CPNs also exhibits superiority on conversion and
selectivity (both 99%) compared with the non-noble metal catalysts Fe-Cu/γAl O
2
3
catalyst with 93% furfural conversion and 98% selectivity to furfuryl alcohol [19] and
Fe-promoted Cu/SiO maintains 95% conversion and 87 % selectivity to FOL [20].
2
2
. Experimental Section
2
.1. Reagents and chemicals
All reagents and chemicals were of analytical grade and used as received without
any further purification. Cobalt ( Ⅱ) nitrate hexhydrate (Co(NO ) ·6H O, 99.0%) was
3
2
2
purchased from Shanghai Zhongqin Chemical Reagents Co., Ltd. Sodium chloride
(NaCl, 99.5% ) was purchased from Tianjin Guangfu Chemical Reagents Co., Ltd.
=

ACCEPTED MANUSCRIPT
Melamine (C N (NH ) ) was purchased from Sinopharm Chemical Reagents Co., Ltd.
3
3
2 3
Chitosan was purchased from Reagents Co., Ltd.
2
1
.2. Synthesis of the catalysts
.5 g Chitosan, 1.5 g Melamine, 1.0 g Co(NO ) ·6H O, and 4.0 g NaCl were
3
2
2
thoroughly mixed, and the resulting mixture were transferred into a porcelain boat and
heated up to 500 ℃ in 220 min, then it was kept at 500 ℃ for 60 min. Then, the
mixture was heated up to desired temperature at a rate of 3.75 ℃/min and was hold for
6
0 min under the nitrogen atmosphere. After the temperature cooled down to room
temperature, the mixture was washed by 200 mL deionized water in the ultrasonic
irradiation to promote the dissolve of NaCl and in the Fig. 2c were not found the
elements of Cl and Na, this phenomenon provide the NaCl was remove clearly.
Finally, the mixture were filtrated and dried at 60 ℃ for 12 h and got the Co@CPNs
catalysts. The schematic caption of the synthesis of catalysts were shown in Fig. 1.
=

ACCEPTED MANUSCRIPT
Fig. 1 the schematic caption of the synthetize catalyst.
3
. Results and discussion
3
.1. Characterizations of the catalysts
The ingredient and morphology of the catalysts are displayed in Fig. S2 with TEM
and SEM. Fig. S2a presents that the Co nanoparticles were well-proportioned
dispersed on the CNPs. Fig. S2b show that the average sizes of Co nanoparticles is
about 31.2 nm. Fig.2c was the EDX of the catalysts, which shows that the catalysts
have the elements of C, N, O and Co. HR-TEM (Fig. S2d) shows that the lattice
distance is 0.209 nm, which can be assigned to the (111) planes of metallic Co. Fig.
S2e is the result of mapping zone and the results are presented in the Fig. S2f. In Fig.
S2f, the green zone is the mapping of cobalt, and the other two yellow and red zones
=

ACCEPTED MANUSCRIPT
are the N and C, respectively. It is obvious that the zone of elements of C, N were
mostly overlap, and the element of Co is inserted into the other two elements. And
from the Fig. S1, It could be obverted that the cobalt was observed with a thin layer of
carbon and the thickness of the carbon is about 1.89 nm [21].
The patterns of XRD were displayed in Fig. S3a, which could provide the
composition of catalysts. The two peaks of 2θ =26.0° and 44.0° were corresponding to
(002) and (101) planes of carbon (JCPDS 75-1621) [22]. In addition, It can be found
that the (101) peak of carbon is the same as the (111) peak of cobalt. The peaks
located at 2θ= 44.0°, 51.5°, and 75.8° were corresponding to the Co lattice planes of
(111), (200) and (220) (JCPDS 1-1255) [23]. Therefore, the cobalt existed in the
0
Co@CPNs-1.5-1.5-4 with state of Co , which fitted in with the result of TEM.
The XPS were displayed in the Fig. S3b-f, which provided the chemical elements
valence states and molar fraction of Co (7.83%), C (74.63%), N (1.58%), and O
(15.96%) on the surface of the catalysts, and all the binding energys from the XPS
analysis were calibrated by using the C1s peak at 284.6 eV. The Fig. S3b shows the
wide survey spectrum of the Co@CPNs, and the peaks at the binding energies of
2
85.2 eV, 399.8 eV, 531.3 eV and 780.3 eV were attributed to the C 1s, N 1s, O 1s,
and Co 2p species, respectively [24]. From the high-resolusion spectrum it can be
observed that the C 1s (Fig. S3c) peak components with binding energys at 286.6 eV,
2
85.0 eV and 284.3 eV were related to the C-O, C-C, and C-N, respectively [25, 26].
The N 1s spectrum (Fig. S3d) was deconvoluted into two peaks that corresponding to
=

ACCEPTED MANUSCRIPT
the following functional groups: 401.1 eV for C-N and 399.1 eV for C=N [27, 28].
There were three signals observed of O 1s (Fig
.
S3e) (532.8 eV for C-O-C, 531.4 eV for Co-O and 530.1 eV for C-O)[29, 30]. Co
2
p (Fig. 3f) was spilt into Co 2p3/2 at 778.3 eV and Co 2p1/2 at 793.2 eV, these two
peaks stand for metal of cobalt and the results was corresponded to the results of the
XRD [31]. The binding energys of oxidised Co of 2p3/2 was located at 781.7 eV and
the 2p1/2 was located at 803.6 eV [32, 33]. There are two reasons of having peaks of
oxidised cobalt, one was that the suffice of cobalts have a little oxidation when the
catalysts were exposured to air and the other was that the oxygen in the chitosan have
a reaction with the cobalt at high tempeture. However, from the image of XRD, there
were not the peaks of cobaltous oxide, this phenomenon may be caused by the lattice
of oxidised cobalt was amorphous and these species were not detected by XRD.
3
.2 Performance of catalysts
The performance of catalysts were tested by selective hydrogenation of FAL to
FOL(Table 1). All the types of the catalysts were tested at 3 MPa of H , 453 k for 2.5
2
h, and the iPrOH as solvent. Starting to stirring when the temperature reached to 453
k. From the Table 1, It could see that the catalyst perform the highest activity when
the mass of chitosan and melamine were both 1.5 g, the mass of NaCl was 4.0 g, and
the temperature of calcination was 1073 k. From the Table 1, the mass of NaCl
influence the surface area of the catalysts was very obviously and the influence of the
reaction activity was also distinct. It was deduced that the NaCl was influencing the
=

ACCEPTED MANUSCRIPT
surface area of the catalysts, which can increase the exposure of the center of activity
of catalysts.
a
Table 1 the selective hydrogenation of the FAL with the different catalysts .
Entry
Catalyst
Conversion
%)
Selectivity
(%)
Yield
(%)
TOF
-1
(
h
1
2
3
4
5
6
7
8
9
Co@CPNs1.5-1.5-0
Co@CPNs1.5-1.5-2
Co@CPNs1.5-1.5-4
Co@CPNs1.5-1.5-6
Co@CPNs1.0-2.0-4
Co@CPNs2.0-1.0-4
Co@CPNs1.5-1.5-4
Co@CPNs1.5-1.5-4
CPNs
75
81
99
53
52
35
78
70
0
95
71
14.5
15.6
19.3
10.3
9.0
98
99
94
98
99
98
96
0
79
98
50
51
34
76
67
0
8.8
b
c
15.1
13.5
0
1
0
Co@C
31
97
30
10.9
(a) reaction conditions: furfural (4 mmol), catalyst (20 mg), isopropanol (20 mL), 3
MPa H , 453 k, reaction time 2.5 h. Conversion and selective were determined by
2
GC-MS (b) the highest calcination temperature is 1173 k, (c) the highest calcination
temperature is 973 k, and the mass content of cobalt of entry 1-4, 5, 6 and10 are
around 20.4%, 22.8%, 15.5% and 11.2%, respectively.
=

ACCEPTED MANUSCRIPT
It also tested the activity of catalysts (Table 1 Entry 3) in different solvent and the
results were shown in Table 2. From the results, it can be got that the catalysts have a
good activity when the solvent have hydroxyl and high polarity. When the solvent was
the water there have a low conversion, this may be the substrate could not dissolve in
the water and the substrate could not exposure adequately with H .When the solvent
2
was methyl alcohol, the catalysts behaved high activity, however, the selective was
not very well, the reaction produced too much byproducts The main reaction of the
generation of byproducts were that the methyl alcohol and FAL have an aldol
condensation reaction and the mechanism was shown in Fig. S7 [34]. Considering the
rate of reaction and the yield of objective product, the iPrOH was chose as the final
solvent. We also test the final solvent with GC-MS, there was no acetone founded, it
could dope out that the hydrogen donors was H but not the iPrOH.
2
Table 2 Effect of solvents on the selective hydrogenation of furfural using
a
Co@CPNs-1.5-1.5-4 .
Entry
solvent
Conversion
%)
Selective
(%)
Yield
(%)
polarity
(
1
2
3
4
5
6
water
5
99
85
80
90
99
95
4.9
10.2
6.6
Methyl alcohol
Ethyl alcohol
n-hexane
99
98
85
21
16
84.2
78.4
76.6
20.7
15.2
4.3
0.06
0.1
cyclohexane
1,4-dioxane
4.8
=

ACCEPTED MANUSCRIPT
7
8
9
1
toluene
15
85
21
99
99
90
99
99
14.8
76.5
20.7
98
2.4
3.7
4.3
4.3
n-butyl alcohol
ethyl acetate
isopropanol
0
(a) reaction conditions: furfural 4 mmol, Co@CPNs-1.5-1.5-4 20 mg, solvent 20
mL, 3 MPa H , 453 k, 2.5 h. Conversion and selective were determined by GC-MS.
2
From the Table 3, it could see that at high temperature the catalysts have a well
activity and the best reaction temperature was 453 k. At the lower temperature, the
higher yield can be get through the increase the reaction time (entry 2 and 4). From
the entry 7-9, we found that the conversion will increase with the increase the
pressure of H and when the pressure was 3MPa, the conversion achieve the highest.
2
Table 3 Effect of temperature on the selective hydrogenation of furfural using
a
Co@CPNs-1.5-1.5-4 .
Entry
T (k)
P (MPa)
Conversion
Selective
(%)
99
Yield
(%)
(
%)
24
54
53
68
70
99
99
1
423
423
433
433
443
453
463
3.0
3.0
3.0
3.0
3.0
3.0
3.0
23.8
53.5
52.5
67.3
68.6
98.1
94.0
b
2
99
3
99
b
4
99
5
6
7
98
99
95
=

ACCEPTED MANUSCRIPT
8
9
1
453
453
453
2.5
2.0
1.5
78
61
46
99
99
99
77.2
60.4
45.5
0
(
a) reaction conditions: furfural (4 mmol), Co@CPNs-1.5-1.5-4 (20 mg),
isopropanol (20 mL), reaction time 2.5 h. Conversion and selective were
determined by GC-MS.(b) the reaction time was 5 h.
Finally, the selective hydrogenation of various α, β-unsaturated carbonyl or ketone
were also tested with the catalysts, and the results were shown in the Table 4. From
the table 4 we can see that the catalysts also behave high activity and selectivity
with other compounds except the acid, this may be the carboxyl was too stable.
a
Table 4 Selective hydrogenation of various α, β-unsaturated carbonyl or ketone .
Entry
Substrate
Product
%)
Conversion
Selective
(%)
(
(%)
98
1
92
b
2
99
99
99
99
99
95
99
80
3
4
c
5
=

ACCEPTED MANUSCRIPT
6
7
8
99
95
30
90
80
90
(a) reaction conditions: substrate (5 mmol), Co@CPNs-1.5-1.5-4 (20 mg),
isopropanol (20 mL), 3 MPa H , 453 k, reaction time 2.5 h. (b)the reaction
2
time is 1 h, (c)the reaction time is 0.6 h Conversion and selective were
determined by GC-MS.
So as to test the ability of the circulation of catalysts, selective hydrogen of FAL was
performed at 453 k, 3 MPa of H for 2.5 h. The used catalysts were washed by iPrOH
2
for five times for the next cycle, and the results were shown in Table 5. After four
times cycling, the activity and the selectivity of the catalysts were not changed
apparently, this results suggested that the cycling ability of catalysts were favorable.
We also analyzed the catalysts after the recycle by ICP and the mass content of cobalt
was 17.29%, which was less about 3% than the fresh catalysts. The loss of the cobalt
in the reaction may result the decline of the conversion.
=

ACCEPTED MANUSCRIPT
Table 5 The recycles ability of the Co@CPNs-1.5-1.5-4.
4
. Conclusion
In this study, Co nanoparticles were supported on nitrogen-doped carbon porous
materials (CPNs) by single pot method and utilized to selective hydrogenation of the
FAL to FOL. After the screening of the reaction condition, satisfactory conversion and
selectivity were obtained. Co@CPNs-1.5-1.5-4 exhibited best catalysts activity
among all types of the catalysts, which performs the high activity, conversion (99%)
and selectivity (99%) of FAL to FOL. Avoiding the noble metal shortcoming of the
high cost and the non-noble metal weakness of low catalytic activity. This study
demonstrated the high catalytic activity Co@CPNs-1.5-1.5-4 were prepared in the
selective hydrogenation of FAL to FOL.
=

ACCEPTED MANUSCRIPT
Reference
[
[
[
1] Y. Nakagawa, M. Tamura, K. Tomishige, ACS Catal 3 (2013) 2655-2668.
2] M. Besson, P. Gallezot, C. Pinel, Chem. Rev. 114 (2014) 1827-1870.
3] J.N. Appaturi, M.R. Johan, R.J. Ramalingam, H.A. Al-Lohedan, J.J. Vijaya, RSC
Adv 7 (2017) 55206-55214.
[
[
4] P. Zhou, Z. Zhang, Catal. Sci. Technol. 6 (2016) 3694-3712.
5] B.M. Nagaraja, A.H. Padmasri, B. David Raju, K.S. Rama Rao, J. Mol. Catal. A:
Chem. 265 (2007) 90-97.
[
[
[
[
[
6] L.J. Malobela, J. Heveling, W.G. Augustyn, L.M. Cele, Ind Eng Chem Res 53
(
2014) 13910-13919.
7] Y.W. Weiyong Yu, Hanfan Liu * , Wen Zheng, J. Mol. Catal. A: Chem 112 (1996)
05-113.
8] J. Wu, G. Gao, J. Li, P. Sun, X. Long, F. Li, Applied Catalysis B: Environmental
03 (2017) 227-236.
9] N. Pino, S. Sitthisa, Q. Tan, T. Souza, D. López, D.E. Resasco, J. Catal. 350
2017) 30-40.
1
2
(
10] Q. Yuan, D. Zhang, L.v. Haandel, F. Ye, T. Xue, E.J.M. Hensen, Y. Guan, J. Mol.
Catal. A: Chem. 406 (2015) 58-64.
[
[
11] K. Yan, C. Jarvis, T. Lafleur, Y. Qiao, X. Xie, RSC Adv 3 (2013) 25865.
12] X.D. Guang-Hui Wang, Dong Gu, Kun Chen, Harun Tîysîz, Bernd Spliethoff,
Hans-, C.W. Josef Bongard, Wolfgang Schmidt, and Ferdi Schîth*, Angew.
Chem 55 11101-11105.
[
[
[
13] N.S. Biradar, A.M. Hengne, S.S. Sakate, R.K. Swami, C.V. Rode, Catal. Lett.
1
46 (2016) 1611-1619.
14] M. Audemar, C. Ciotonea, K. De Oliveira Vigier, S. Royer, A. Ungureanu, B.
Dragoi, E. Dumitriu, F. Jerome, ChemSusChem 8 (2015) 1885-1891.
15] J. Lee, S.P. Burt, C.A. Carrero, A.C. Alba-Rubio, I. Ro, B.J. O’Neill, H.J. Kim,
D.H.K. Jackson, T.F. Kuech, I. Hermans, J.A. Dumesic, G.W. Huber, J. Catal.
3
30 (2015) 19-27.
[
[
16] X. Chen, X. Li, S. Liu, Z. Li, Ind Eng Chem Res 54 (2015) 4756-4762.
17] M. Li, Y. Hao, F. Cárdenas-Lizana, M.A. Keane, Catal. Commun. 69 (2015)
119-122.
[
[
18] M.J. Taylor, L.J. Durndell, M.A. Isaacs, C.M.A. Parlett, K. Wilson, A.F. Lee, G.
Kyriakou, Appl Catal B-Environ 180 (2016) 580-585.
19] A.K.V. Marimuthu Manikandan, Atul S. Nagpure, SatyanarayanaChilukuri and,
T. Raja, RSC Adv 6 (2016) 3888-3898.
[
[
20] H. Sheng, R.F. Lobo, ChemCatChem 8 (2016) 3402-3408.
21] Z. Wei, J. Wang, S. Mao, D. Su, H. Jin, Y. Wang, F. Xu, H. Li, Y. Wang, ACS
Catal 5 (2015) 4783-4789.
[
[
[
[
22] Z. Zhao, Y. Dai, J. Lin, G. Wang, Chem. Mater. 26 (2014) 3151-3161.
23] X. Li, W. Zhang, Y. Liu, R. Li, ChemCatChem 8 (2016) 1111-1118.
24] R. Ding, X. Li, W. Shi, Q. Xu, E. Liu, Chem. Eng. J. 320 (2017) 376-388.
25] S. Frindy, A. Primo, H. Ennajih, A. El Kacem Qaiss, R. Bouhfid, M. Lahcini,
E.M. Essassi, H. Garcia, A. El Kadib, Carbohydr. Polym. 167 (2017) 297-305.
=

ACCEPTED MANUSCRIPT
[
[
26] M. Ghasem Hosseini, E. Shahryari, J. Colloid Interface Sci. 496 (2017) 371-381.
27] M. Zhao, L. Meng, L. Ma, G. Wu, F. Xie, L. Ma, W. Wang, B. Jiang, Y. Huang,
Compos. Sci. Technol. 138 (2017) 144-150.
[
[
28] X. Zhao, S. Gao, G. Liu, J. Anal. Appl. Pyrolysis 122 (2016) 24-34.
29] S. Turczyniak, M. Greluk, G. Słowik, W. Gac, S. Zafeiratos, A. Machocki,
ChemCatChem 9 (2017) 782-797.
[
[
30] T. Abiraman, E. Ramanathan, G. Kavitha, R. Rengasamy, S. Balasubramanian,
Ultrason. Sonochem. 34 (2017) 781-791.
31] P. Bera, H. Seenivasan, K.S. Rajam, V.K. William Grips, Mater. Lett. 76 (2012)
1
03-105.
[
[
32] J. Qin, S. Wang, X. Wang, Appl Catal B-Environ 209 (2017) 476-482.
33] L. Wang, Z. Li, Y. Zhang, T. Zhang, G. Xie, J. Alloys Compd. 702 (2017)
6
49-658.
[
34] Z. Zhang, C. Pittman, S. Sui, J. Sun, Q. Wang, Energies 6 (2013) 1568-1589.
=

ACCEPTED MANUSCRIPT
Highlights

The catalysts Co@CPNs were easily prepared.


The catalysts are very cheap and can be separated by the external magnetism.
Kinetic study of the hydrogenation of the Furfural to Furfuryl alcohol.
=
