Dithienosilole- and Dibenzosilole-Thiophene Copolymers as
Semiconductors for Organic Thin-Film Transistors
Hakan Usta, Gang Lu, Antonio Facchetti,* and Tobin J. Marks*
Department of Chemistry and the Materials Research Center, Northwestern UniVersity, 2145 Sheridan Road,
EVanston, Illinois 60208
Received May 4, 2006; E-mail: a-facchetti@northwestern.edu; t-marks@northwestern.edu
Scheme 1. Synthetic Route to Polymers 1-4
The design and realization of new π-conjugated organic semi-
conductors has been a topic of great research interest for the past
decade.1 The most prominent examples of such materials are
polycondensed benzenoids, polyacetylenes, and (oligo)polyhetero-
aromatics.1,2 Among these, the silole (silacyclopentadiene) moiety
has recently been investigated as a novel conjugated system in
which the σ*-orbital of the silicon-carbon bond effectively interacts
with the π*-orbital of the butadiene fragment, leading to a low-
lying LUMO.3 In particular, since Tamao et al. reported that 2,5-
bis(2-pyridyl)silole derivatives exhibit electron-transporting prop-
erties,4 a number of applications of silole-containing small molecules
and polymers have emerged, including new conducting polymers,5
OLEDs,6 and solar cells.7 Very recently, silole-containing polymers
have also been used to fabricate organic field-effect transistors
(OFETs8).9
Table 1. Physicochemical Properties [Molecular Weight (Mw, KD),
Polydispersity (PD), Solution and Film Optical Absorption Maxima
(λ, nm),a Energy Gaps (Eg, eV)], OFET Charge Carrier Mobilities
(µ, cm2 V-1 s-1),b and Current On/Off Ratios (Ion:Ioff) in Air for
Polymers 1-6
polymer
Mw (PD)
λsol (Eg)
λfilm (Eg)
µh
Ion:Ioff
TS6T1
TS6T2
BS8T1
BS8T2
F8T1
30 (2.9)
41 (3.0)
112 (3.1)
127 (3.7)
17 (2.6)
80 (3.3)
521 (2.0)
544 (1.9)
473 (2.5)
503 (2.3)
427 (2.6)
456 (2.4)
574 (1.8)
545 (1.9)
484 (2.5)
493 (2.3)
440 (2.5)
460 (2.4)
0.02
2 × 105
5 × 105
3 × 104
2 × 106
2 × 105
2 × 105
0.06
6 × 10-5
0.006
9 × 10-5
0.006
F8T2
a λmax at the longest wavelengths. b Calculated in saturation for device
structure n2+-Si/SiO2-HMDS (300 nm)/polymer (20-30 nm)/Au contacts
(50 nm). OFETs tested in ambient conditions.
The above considerations and the possibility that incorporation
of electron-withdrawing silacycles might enhance π-electron overlap
along conjugated polymer backbones, without compromising
environmental stability, prompted us to synthesize new silole-
containing π-conjugated polymers and to investigate their properties
in OFETs. Note that from literature diffraction and computational
studies, silole-containing molecular cores are expected to be planar,
and the bulkiness of the silicon substituents should have little impact
on the ring planarity.10 In this communication, we report the
realization of four new silolearene-thiophene copolymers, 1-4,
and compare their properties with new fluorene-thiophene-based
polymer F8T1 (5) and widely investigated F8T2 (6). It is seen
that the silole-based materials can be synthesized in high yields,
are environmentally stable, and yield solution-processable films
which act as efficient hole transporters in FET devices. Carrier
mobilities as high as ∼0.06 cm2/Vs and current on/off ratios of
∼105-106 for unaligned films are measured in devices functioning
in ambient conditions.
Polymer synthetic details can be found in Supporting Information.
Briefly, polymers 1 and 2 were prepared via Stille coupling
sequences by reacting silole precursor 10 with thiophene reagents
11 and 12, respectively (Scheme 1, top), in refluxing THF using
Pd(PPh3)2Cl2 as the catalyst. The synthesis of polymers 3-6 was
then carried out using a modified Suzuki polycondensation (Scheme
1, bottom for 3 and 4) in a biphasic reaction with Pd[PPh3]4 as the
catalyst. The solvents were toluene and aqueous sodium bicarbonate,
and Aliquat 336 was used as the phase transfer agent to maximize
product molecular weight. All of the polymers were purified by
dissolution in minimal amounts of THF or TCB and precipitation
from large amounts of boiling methanol, cooled to room temper-
ature, stirred overnight, and then collected by centrifugation. The
dissolution-precipitation process was repeated multiple times. The
polymer structures were verified by 1H and 13C NMR spectroscopy
and elemental analysis. Polymer molecular weights were determined
by GPC versus polystyrene, and results are summarized in Table
1. Note that the Mw values of copolymers 3 and 4 are greater than
those of 1 and 2, and we are currently optimizing the synthesis of
1 and 2 following the Suzuki protocol.
The thermal properties of the present polymers were examined
by differential scanning calorimetry (Figure S1). Polymers 2, 3,
and 5 exhibit a single broad endotherm centered at 250-300 °C
without apparent exothermic return peaks. In contrast, polymers 1
and 4 exhibit single reversible endothermic (260 and 330 °C,
respectively) and exothermic (230 and 290 °C, respectively)
transitions, whereas F8T2 (6) behaves as previously reported.11
Thermogravimetric analysis scans of 1-4 (Figure S2) exhibit
negligible weight loss below 400 °C, demonstrating excellent
thermal stability. Optical absorption data for polymers 1-6 in THF
solutions and as thin films are summarized in Table 1, and spectra
are shown in Figure S3.
9
9034
J. AM. CHEM. SOC. 2006, 128, 9034-9035
10.1021/ja062908g CCC: $33.50 © 2006 American Chemical Society

C O M M U N I C A T I O N S
F8T2 and polythiophenes. It is likely that OFET performance can
be further improved via optimization of polymer Mw and film
deposition/processing conditions.
Acknowledgment. We thank ONR (N00014-02-1-0909), the
NSF-MRSEC program through the Northwestern Materials Re-
search Center (DMR-0076097), and the NASA Institute for
Nanoelectronics and Computing (NCC 2-3163) for support.
Supporting Information Available: Polymers 1-6 syntheses/
spectroscopic data and FET device fabrication. Figures S1-S8. This
material is available free of charge via the Internet at http://pubs.acs.org.
Figure 1. BS8T2-based FETs. (A) Transfer plots before (dotted line) and
after film annealing (solid line). (B) Output plot of an annealed device. (C)
ON-OFF cycles (0.03 Hz) under ambient conditions for the annealed device
at VDS ) -50 V for different gate biases.
References
Note that the λmax values of silole-based polymers 3 and 4 are
red-shifted by ∼40-50 nm versus fluorene-based analogues 5 and
6, demonstrating Si σ*-orbital involvement in the π-conjugation.
Furthermore, note that 1 f 3 and 2 f 4 λmax trends reflect both
the effects of the π electron-donating S atom versus simple -Cd
C- and the more planar conformation of five-five versus five-six
inter-ring linkages in contributing to the large bathochromic shifts
[40-50 nm (THF), 60-90 nm (film)]. Thus, the polymer band gaps
(Table 1) are found on average to decrease going from 5, 6 (2.4-
2.6 eV) to 3, 4 (2.3-2.5 eV) to 1, 2 (1.8-2.0 eV).
(1) (a) Vardeny, Z. V., Heeger, A. J., Dodabalapur, A., Eds. Summary of the
Fundamental Research Needs in Organic Electronic Materials; Elsevier:
Amsterdam, 2005. (b) Mu¨llen, K., Wegner, G., Eds. Electronic Materi-
als: The Oligomer Approach; Wiley-VCH: New York, 1998. (c)
Skotheim, T. A., Elsenbaumer, R. L., Reynolds, J. R., Eds. Handbook of
ConductiVe Polymers; Marcel Dekker: New York, 1998.
(2) (a) Barbarella, G.; Melucci, M.; Sotgiu, G. AdV. Mater. 2005, 17, 1581.
(b) Katz, H. E. Chem. Mater. 2004, 16, 4748. (c) Ponce Ortiz, R.; Ruiz
Delgado, M. C.; Casado, J.; Hernandez, V.; Kim, O.-K.; Woo, H. Y.;
Lopez Navarrete, J. T. J. Am. Chem. Soc. 2004, 126, 13363. (d) Reddinger,
J. L.; Reynolds, J. R. AdV. Polym. Sci. 1999, 145. (e) Handbook of Oligo-
and Polythiophenes; Fichou, D., Ed.; Wiley-VCH: Weinheim, Germany,
1999.
OFETs were fabricated as described in Supporting Information
with semiconductor films deposited by spin-coating from THF (1
and 2) or 1,2,4-trichlorobenzene (3-6) solutions. That good OFET
response is achieved using low-boiling THF12 is unprecedented and
appears to reflect the substantial microstructural ordering (vide
infra). After spin-coating and before Au contact deposition, the films
were annealed at 230-250 °C for 30 min under N2. Annealing
significantly improves device performance as shown in Figure 1A
for BS8T2. Output/transfer plots for 1-6 are shown in Figures 1
and S4-6.
(3) (a) Zhan, X.; Risko, C.; Amy, F.; Chan, C.; Zhao, W.; Barlow, S.; Kahn,
A.; Bredas, J.-L.; Marder, S. R. J. Am. Chem. Soc. 2005, 127, 9021. (b)
Risko, C.; Kushto, G. P.; Kafati, Z. H.; Bredas, J. L. J. Chem. Phys. 2004,
121, 9031. (c) Yamaguchi, S.; Tamao, K. J. Chem. Soc., Dalton Trans.
1998, 3693.
(4) Tamao, K.; Uchida, M.; Izumizawa, T.; Furukawa, K.; Yamaguchi, S. J.
Am. Chem. Soc. 1996, 118, 11974.
(5) (a) Tamao, K.; Yamaguchi, S.; Shiozaki, M.; Nakagawa, Y.; Ito, Y. J.
Am. Chem. Soc. 1992, 114, 5867. (b) Salzner, U.; Lagowski, J. B.; Pickup,
P. G.; Poirier, R. A. Synth. Met. 1998, 96, 177.
(6) (a) Chan, K. L.; McKiernan, M. J.; Towns, C. R.; Holmes, A. B. J. Am.
Chem. Soc. 2005, 127, 7662. (b) Kim, W.; Palilis, L. C.; Uchida, M.;
Kafafi, Z. H. Chem. Mater. 2004, 16, 4681. (c) Liu, M. S.; Luo, J.; Jen,
A. K.-Y. Chem. Mater. 2003, 15, 3496. (d) Murata, H.; Kafafi, Z. H.;
Uchida, M. Appl. Phys. Lett. 2002, 80, 189.
Polymers TS6T1 (1) and TS6T2 (2) exhibit high saturation hole
carrier mobilities of ∼ 0.02 and 0.06 cm2/Vs, respectively, and Ion:
Ioff > 105 when measured in air (Figure S4). This is remarkable
considering the modest molecular weights and is likely a conse-
quence of the high degree of microstructural order as supported by
film X-ray diffraction data (Figure S7). Spin-coated or solution-
cast films of regioregular polythiophenes, such as P3HT and PQT,
but not F8T2, are known to self-organize into π-stacked/edge-on
lamellar structures parallel to the HMDS-SiO2 substrate normal,
resulting in very efficient charge transport.13 Bithiophene-based
polymers BS8T2 (4) and F8T2 (6) also exhibit appreciable field-
effect mobilities (∼0.006 cm2/Vs) and Ion:Ioff ratios (>106 and >105,
respectively). The FET parameters for F8T2 are very similar to
literature values for unaligned films.14 Note that OFETs based on
silole-based polymers TS6T2 (Figure S8) and BS8T2 (Figure 1C)
can be ON-OFF cycled repeatedly under ambient conditions at
different VG values with negligible degradation of output charac-
teristics, demonstrating impressive stability. When deposited and
annealed under similar conditions, BS8T1 (3) and F8T1 (5) exhibit
far lower performance (µ ∼ 10-4 cm2/Vs and Ion:Ioff ∼ 105),
probably the combined result of lower π-conjugation and poor
crystallinity, verified by film XRD.
In conclusion, four new silolearene copolymers have been
synthesized and characterized in OFET devices. Carrier mobilities
approaching 0.1 cm2/Vs and Ion:Ioff > 105-106 have been achieved
for unaligned films. To better study and understand their physico-
chemical/OFET properties, the fluorenyl analogues F8T1 and F8T2
were also synthesized. The results clearly demonstrate that silole-
arene copolymer films are highly textured and can exhibit sub-
stantial hole mobilities and Ion:Ioff ratios, rivalling those of
comparably processed and more widely investigated/optimized
(7) (a) Wang, F.; Luo, J.; Yang, K.; Chen, J.; Huang, F.; Cao, Y.
Macromolecules 2005, 38, 2253. (b) Mi, B.; Dong, Y.; Li, Z.; Lam, J.
W. Y.; Haeussler, M.; Sung, H. H. Y.; Kwok, H. S.; Dong, Y.; Williams,
I. D.; Liu, Y.; Luo, Y.; Shuai, Z.; Zhu, D.; Tang, B. Z. Chem. Commun.
2005, 3583.
(8) (a) Locklin, J.; Roberts, M.; Mannsfeld, S.; Bao, Z. J. Macromol. Sci.,
Polym. ReV. 2006, 46, 79. (b) Facchetti, A.; Yoon, M.-H.; Marks, T. J.
AdV. Mater. 2005, 17, 1705. (c) Sirringhaus, H. AdV. Mater. 2005, 17,
2411. (d) Katz, H. E. Electroanalysis 2004, 16, 1837. (e) Horowitz, G. J.
Mater. Res. 2004, 19, 1946. (f) Newman, C. R.; Frisbie, C. D.; da Silva
Filho, D. A.; Bredas, J.-L.; Ewbank, P. C.; Mann, K. R. Chem. Mater.
2004, 16, 4436. (g) Chabinyc, M. L.; Salleo, A. Chem. Mater. 2004, 16,
4509. (h) Rogers, J. A.; Bao, Z.; Katz, H. E.; Dodabalapur, A. In Thin-
Film Transistors; Kagan, C. R., Andry, P., Eds.; Marcel Dekker: New
York, 2003; p 377. (i) Dimitrakopoulos, C. D.; Malenfant, P. R. L. AdV.
Mater. 2002, 14, 99.
(9) OFET performance was modest (µFET ∼ 10-6 cm2/Vs, Ion:Ioff < 10). See:
(a) Kim, D.-H.; Ohshita, J.; Lee, K.-H.; Kunugi, Y.; Kunai, A. Organo-
metallics 2006, 25, 1511. (b) Ohshita, J.; Lee, K.-H.; Hamamoto, D.;
Kunugi, Y.; Ikadai, J.; Kwak, Y.-W.; Kunai, A. Chem. Lett. 2004, 33,
892. (c) Wang, Y.; Hou, L.; Yang, K.; Chen, J.; Wang, F.; Cao, Y.
Macromol. Chem. Phys. 2005, 206, 2190.
(10) (a) Lee, K. H.; Ohshita, J.; Kunai, A. Organometallics 2004, 23, 5481.
(b) Ohshita, J.; Nodono, M.; Kai, H.; Watanabe, T.; Kunai, A.; Komaguchi,
K.; Shiotani, M.; Adachi, A.; Okita, K.; Harima, Y.; Yamashita, K.;
Ishikawa, M. Organometallics 1999, 18, 1453.
(11) Lim, E.; Jung, B.-J.; Lee, J.; Shim, H.-K.; Lee, J.-I.; Yang, Y. S.; Do,
L.-M. Macromolecules 2005, 38, 4531.
(12) Chang, J. F.; Sun, B. Q.; Breiby, D. W.; Nielsen, M. M.; Solling, T. I.;
Giles, M.; McCulloch, I.; Sirringhaus, H. Chem. Mater. 2004, 16, 4772.
(13) (a) Kim, D. H.; Han, J. T.; Park, Y. D.; Jang, Y.; Cho, J. H.; Hwang, M.;
Cho, K. AdV. Mater. 2006, 18, 719. (b) Joseph, K. R.; McGehee, M. D.;
Toney, M. Nat. Mater. 2006, 5, 222. (c) DeLongchamp, D. M.;
Sambasivan, S.; Fischer, D. A.; Lin, E. K.; Chang, P.; Murphy, A. R.;
Frechet, J. M. J.; Subramanian, V. AdV. Mater. 2005, 17, 2340. (d) Ong,
B. S.; Wu, Y.; Liu, P.; Gardner, S. J. Am. Chem. Soc. 2004, 126, 3378.
(e) Sirringhaus, H.; Brown, P. J.; Friend, R. H.; Nielsen, M. M.; Bechgaard,
K.; Langeveld-Voss, B. M. W.; Spiering, A. J. H.; Janssen, R. A. J.; Meijer,
E. W.; Herwig, P.; de Leeuw, D. M. Nature 1999, 401, 685.
(14) Chua, L.; Zaumseil, J.; Chang, J.; Ou, C.-W. E.; Ho, K.-H. P.; Sirringhaus,
H.; Friend, H. R. Nature 2005, 434, 194.
JA062908G
9
J. AM. CHEM. SOC. VOL. 128, NO. 28, 2006 9035
